Electric Induction Cooktops
Before installation, record the model and serial
as found on the bottom of your cooktop. If you require
service or call with a question, please have this
information ready.
Model:
Serial Number:
www.caloricappliances.ca
USE AND CARE GUIDE
info@caloricappliances.ca
EN
number
Models
CICT244
CICT305
CICT366
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Caloric CICT244
Summary of Contents for Caloric CICT244
- Page 1 Electric Induction Cooktops Before installation, record the model and serial number as found on the bottom of your cooktop. If you require service or call with a question, please have this information ready. Model: Serial Number: Models CICT244 CICT305 CICT366 www.caloricappliances.ca info@caloricappliances.ca...
-
Page 2: Table Of Contents
Cleaning Your Cooktop...................15 Troubleshooting Guide................16 17 Installation Instructions................18 23 Your CALORIC Induction Cooktop We thank you for purchasing the CALORIC induction cooktops. WARNING Please read the entire instruction manual prior to using your unit. We wish you find a lot of pleasure in its use. -
Page 3: Important Safety Instructions
Important Safety Instructions IMPORTANT Keep these instructions handy for future use. The appliance is manufactured in compliance with the relevant safety standard. WARNING Read all instructions carefully before installation and operation of the appliance. WARNING Failure to follow these warnings could result in a fire or explosion that causes property damage, personal injury or death. - Page 4 Important Safety Instructions WARNING Cleaning Safety CAUTION Clean Cook - Top with Do not use steam cleaners or high- Caution - If a wet sponge or cloth is pressure cleaners to clean the cooktop, used to wipe spills on a hot cooking as this may result in electric shock.
- Page 5 Important Safety Instructions Environment of Unit CAUTION Do not put detergents or flammable Do not store items of materials in the equipment installed interest to children in cabinets above under the cooktop . the range or on the backguard of a range - children climbing on the range Extreme caution must be used when to reach items could get seriously...
-
Page 6: Important Safety Instructions 1
Important Safety Instructions Service and Repair Safety WARNING Do not repair or There are no user serviceable parts on replace any part of the appliance this appliance. Only an authorized unless specifically recommended in service representative should attempt the manual. All other services should to service your cooktop. -
Page 7: Cooktop Features
Cooktop Features This manual covers different models. The cooktop you have purchased may have some or all of the features listed. 24" (59cm) Model CICT244 30" (76.2cm) Model CICT305 1. Left rear cooking e lement 2. Left front cooking element 3. - Page 8 Cooktop Features This manual covers different models. The cooktop you have purchased may have some or all of the features listed. 11. Main Power On/Off 12. Main Power indicator light 13. Controls Lock 14. Control Lock indicator light 15. Stop/Go 16.
-
Page 9: Cooktop Features
Cooktop Features Specification Model CICT244 CICT305 CICT366 Product dimension wxdxh inch 23-7/32" x 20-15/32" x 2-5/32" 30" x 21" x 2-5/32" 36" x 21" x 2-5/32" Min.:21-31/32" x 18-15/16" Min 28-3/4" x 19-21/32" Min 34-7/16" x19-21/32" Cut-out dimension(wxd) inch Max.:22-7/16" x 20-1/16"... -
Page 10: Using The Cooktop
Using The Cooktop Controls Lock To unlock Controls Lock is activated when the cooktop is off: Controls Lock prevents Touch and Hold Lock key pad for 3 activation of any sensor key, except for seconds, a beep will sound, the the Lock key pad, so you must indicator light will turn OFF. - Page 11 Using The Cooktop Power Management Touch “- ” key or “+” key to adjust the desired power level; NOTE: During cooking, the unit is equipped with safeguards against parching. Heating will appear intermittent phenomenon when cooking element is used for frying, stir-frying, grilling and other high temperature cooking formats.
- Page 12 Left Zone Right Zone Left Zone Right Zone 24" (59cm) Model CICT244 30" (76.2cm) Model CICT305 Left Zone Right Zone 36" ( 91.5 cm) Model CICT366...
- Page 13 Using The Cooktop Stop/Go Use the Stop/Go function to 'Pause' All of the buttons are inactive except cooktop for Max. 10 minutes while for Stop/Go, Lock and ON/OFF and cooking; the unit will be automatically POWER key. switched off if Stop/Go is not touched again within 10 minutes.
-
Page 14: Using The Cooktop 8
Using The Cooktop Set Timer The automatic timer settings range If you want to check the remaining from 1 minute to 99 minutes. (NOTE: time for another Cooking Element, There is no “seconds” and “hours” touch the Timer until the Time display, only minutes.) The red dot symbol indicator for the desired next to the Time symbol indicator will... -
Page 15: Operational Cooktop Noises
Operational Cooktop Noises Cookware Noise The induction fields are generated by Cookware with irregular or warped electronics equipment, which are bottoms can vibrate audibly on the pretty much silent but they do produce ceramic glass surface, though again heat at high power level. A soft- typically only at high power settings. -
Page 16: Compatible Cookware
Compatible Cookware The quality of your cooking is dependent on the cookware you use. Because induction cooking requires a magnetic vessel for heating, only certain materials can be used on your cooktop. Proper Cookware Improper Cookware Pots or pans with or made of the Flat-bottomed pots or pans with or following CANNOT be used on your made from the following:... -
Page 17: Cleaning Your Cooktop
NOTE: If the ceramic glass top of the cooktop is broken, turn off the unit; the cooktop glass will have to be replaced. In this case, contact CALORIC for assistance. -
Page 18: Troubleshooting Guide
Troubleshooting Guide If you encounter the following problems while using your cooktop, check the guide below to see if you can correct the problem yourself before calling for assistance or service: Problem Possible Cause Solutions Cooktop controls are locked Make sure Lock mode is turned off Power outage Cooktop does not work... -
Page 19: Assistance Or Service
Problem Possible Cause Solutions Total using power reach rated power 3700W (Model CICT244, Power boost does not work See POWER SHARING CICT305) or 4800W(Model CICT366) in the same section. The fans keep running for one minute after the cooking element... -
Page 20: Installation Instructions
Model CICT366 needs 50 Amp service. Maximum Connected Load Model CICT244 ..7.4 kW at 240 VAC, 6.4 kW at 208VAC Model CICT305 ..7.4 kW at 240 VAC, 6.4 kW at 208VAC Model CICT366 ..9.6 kW at 240 VAC, 8.3 kW at 208VAC... - Page 21 Installation Instructions The Caloric Induction Cooktops must connect to a separate, grounded three-wire, single phase, AC Only electrical supply with their own circuit breaker. These appliances must be installed in accordance with National Electrical Codes, as well as all state, municipal and local codes. This...
- Page 22 Installation Instructions Installation — 24" (59cm) Model CICT244 Cooktop Dimensions B. Depth C. Height A. Width 23-7/32"(590) 20-15/32"(520) 2-5/32"(55) * DO NOT obstruct these areas. Junction box Vent 4-1/2"(114) IMPORTANT: For perfect ventilation, provide a vent of Front under the countertop, in the front of the cabinet and in the back of the cabinet.
- Page 23 Installation Instructions Installation — 30" (76.2cm) Model CICT305 Cooktop Dimensions B. Depth C. Height A. Width 30"(762) 21"(533) 2-5/32"(55) * DO NOT obstruct these areas. Junction box Vent 4-1/2"(114) IMPORTANT: For perfect ventilation, provide a vent of Front under the countertop, in the front of the cabinet and in the back of the cabinet.
- Page 24 Installation Instructions Installation — 36" ( 91.5 cm) Model CICT366 Cooktop Dimensions B. Depth C. Height A. Width 36"( 21"(533) 2-5/32"(55) DO NOT obstruct these areas. Junction box Vent 4-1/2"(114) IMPORTANT: For perfect ventilation, provide a vent of Front under the countertop, in the front of the cabinet and in the back of the cabinet.
- Page 25 Installation Instructions After Installation 1. Remove all the stickers and items from the top of the cooktop surface. 2. Clean cooktop before use. Dry with a soft cloth. See Cleaning Your Cooktop for reference. 3. Read Using Your Cooktop 4. Turn on the power to the cooktop. 5.
