Summary of Contents for iiNet MobiiConnect 4G
- Page 1 Quick Setup Guide...
- Page 3 Thanks for getting mobile with MobiiConnect 4G! With the supplied AC and car charger adapters, you can truly get online on the go with the MobiiConnect 4G. This guide will show you how to get online with your new MobiiConnect 4G.
- Page 4 MobiiConnect 4G Overview USB plug for computer, AC adapter or car charger adapter Reset button microSD™ memory card slot SIM card slot (Standard size only) LED status lights...
- Page 6 1. Open the back cover using the thumb notch...
- Page 7 2. Insert your Standard size SIM card into the SIM card slot The side with the gold panel should face down, with the cut-off corner facing out as shown below:...
- Page 8 3. OPTIONAL: Insert a memory card To use your device for portable USB storage, insert your own microSD™ card as shown. microSD(HC)™ memory cards up to 32GB are supported.
- Page 9 4. Write down the default SSID and password (case sensitive) for the Wi-Fi You’ll find these below the barcode on the sticker next to the SIM card slot. mobii...
- Page 10 5. Replace the back cover...
- Page 11 6. Plug in to a USB slot on a PC tower or laptop and then wait for the Status light to turn blue or green. Alternatively, plug in to the supplied AC adapter or car charger adapter.
- Page 12 7. Connect to the Wi-Fi Use the SSID (network name) and password (case sensitive) printed on your device and on the security sticker. You can customise your SSID and password through the Web Management Page mentioned later in this guide.
- Page 13 8. Try to browse to a website If it doesn’t work, you may need to activate your SIM card by following the instructions that came with it (or allow time for activation to complete). Adam Internet, TransACT or Internode customers may need to select a different network profile in the Web Management page.
- Page 14 Using the Web Management Page Connect your computer, laptop or other Wi-Fi device to the MobiiConnect 4G. Open your internet browser and go to http://192.168.1.1 Log in with the default password admin. To set a different network profile (Adam Internet, TransACT and Internode), select the Settings tab.
- Page 15 Settings tab. Just select Wi-Fi settings, make your changes and then click Apply. You’ll need to connect your devices to the MobiiConnect 4G Wi-Fi again using your new SSID and/or password. For more information about the Web Management page, please...
-
Page 16: Understanding The Status Lights
Understanding the status lights If you’re ever outside of a 4G coverage area, your device will default to an available 3G or 2G network. Wi-Fi Status Light Meaning Wi-Fi is Off. Use Web Management page Not Lit to turn back on Blue solid WPS (Wi-Fi Protected Setup) is active Blue blinking... - Page 17 4G Status Light Meaning Offline, not registered on a mobile network Green solid Registered on 3G or 2G network Active data transfer on 3G or 2G Green blinking network Blue solid Registered on 4G network Blue blinking Active data transfer on 4G network...
-
Page 18: Resetting To Factory Defaults
Check the MobiiConnect 4G Overview at the beginning of this guide if you’re not sure where this button is. The status lights will blink and then your MobiiConnect 4G will restart. All custom user configurations and passwords will be wiped and... -
Page 19: Warranty
■ Phone: 13 22 58 Warranty ■ Email: support@iinet.net.au How to claim under the Westnet: warranty and your rights ■ Phone: 1300 786 068 In order to claim under the ■ Email: support@westnet.com.au warranty, you should contact us to advise that you wish to claim... - Page 20 If we determine that your equipment needs to be returned, you will be sent replacement equipment and a return freight bag in which to return the faulty equipment. If the faulty equipment is not returned to us, with all cables, accessories and components, within 21 days of you receiving the replacement equipment and return freight bag, you will be charged the full price for the purchase of the equipment that we sent to you, plus any shipping costs relating to the...
- Page 21 example misuse or exposure to liquid or excessive heat); or an external event (for example a fire or flood). If on inspection of the returned equipment we determine that the fault was caused by a Non Covered Event, you will be charged for the original equipment (or if the original equipment has already been paid for, you will not be entitled to a refund) and the replacement equipment, unless: you have not used the replacement equipment;...
- Page 22 1.10 This warranty is given by iiNet Limited (ACN 068 628 937) of 1/502 Hay Street, Subiaco, WA, 6008. You can contact us on 13 22 58 or via email to support@ iinet.net.au if you have any questions regarding this warranty.
- Page 23 Warranty Period Purchase: 24 Months Rental: For the lifetime of the Rental Contract You must notify us of the fault with your equipment within the applicable Warranty Period (beginning from the date you purchased the equipment) We will repair, replace or provide credit for faulty equipment provided by us at no cost to you, if you notify us of the fault within the applicable Warranty Period.
- Page 24 Support Internode Support 13 22 58 13 66 33 support@iinet.net.au support@internode.on.net iiNet Business Support TransACT Support 13 24 49 13 30 61 bizsupport@iinet.net.au support@transact.com.au Westnet Support Adam Internet 1300 786 068 1300 002 326 support@westnet.com.au support@adam.com.au...
