Page 1 OWNER HANDBOOK...
Page 2 This Owner Handbook illustrates the operating instructions of the car. Alfa Romeo provides a dedicated section available in electronic format for enthusiasts who want insights, curiosities and detailed information about the features and functions of the car. ONLINE OWNER HANDBOOK symbol appears in the Owner Handbook next to topics for which updates are available.
Page 3 (where provided). All data contained in this publication are intended to help you use your vehicle in the best possible way. Alfa Romeo S.p.A. aims at a constant improvement of the vehicles produced. For this reason it reserves the right to make changes to the model described for technical and/or commercial reasons.
Page 4 ELECTRICAL ACCESSORIES If, after buying the vehicle, you decide to add electrical accessories (with the risk of gradually draining the battery), contact an Alfa Romeo Dealership. They can calculate the overall electrical requirement and check that the vehicle's electric system can support the required load.
Page 5 USE OF THE OWNER HANDBOOK OPERATING INSTRUCTIONS Each time direction instructions (left/right or forwards/backwards) about the vehicle are given, these must be understood as regarding an occupant in the driver's seat. Special cases not complying with this rule will be specified as appropriate in the text. The figures in the Owner Handbook are provided by way of example only: this might imply that some details of the image do not correspond to the actual arrangement of your vehicle.
Page 6 SYMBOLS Some car components have coloured labels whose symbols indicate precautions to be observed when using this component. See below for a brief description of each symbol summarising the contents herein. Always take great care to all warnings herein. IT CAN START READ THE OWNER DO NOT TOUCH WITH AUTOMATICALLY ALSO...
Page 7 VEHICLE CHANGES / ALTERATIONS IMPORTANT Any change or alteration of the vehicle might seriously affect its safety and road holding, thus causing accidents, in which the occupants could even be fatally injured. IMPORTANT The use of these devices inside the passenger compartment (without an external aerial) may cause the electrical systems to malfunction.
Page 8 This page is intentionally left blank...
Page 9 KNOWING YOUR CAR KNOWING THE INSTRUMENT PANEL SAFETY STARTING AND DRIVING IN AN EMERGENCY SERVICING AND CARE TECHNICAL DATA MULTIMEDIA INDEX...
Page 11: Table Of Contents
KNOWING YOUR CAR INSTRUMENT PANEL ......10 RIGHT HAND DRIVE VERSION ..... .11 THE KEYS .
Page 12: Instrument Panel
INSTRUMENT PANEL 03036S0001EM 1. Light switch; 2. Air diffusers; 3. Left stalk; 4. Steering wheel controls; 5. Instrument panel; 6. Steering wheel; 7. Right stalk; 8. Connect; 9. Automatic dual-zone climate control system; 10. Glove compartment; 11. Passenger side air bag;...
Page 13: Right Hand Drive Version
RIGHT HAND DRIVE VERSION 03036S0020EM 1. Light switch; 2. Air diffusers; 3. Left stalk; 4. Steering wheel controls; 5. Instrument panel; 6. Steering wheel; 7. Right stalk; 8. Connect; 9. Automatic dual-zone climate control system; 10. Glove compartment; 11. Passenger side air bag;...
Page 14: The Keys
Prolonged pressing of button : all windows closed. REQUEST FOR ADDITIONAL KEYS If you need a new electronic key, go to an Alfa Romeo Dealership, taking an ID 04016S0010EM document and the car ownership documents. Briefly press the button: unlocking of...
Page 15: Ignition Device
IGNITION DEVICE AVV: engine starting. This state can be symbol on the instrument panel entered by pressing the ignition device will remain on, indicating that the button once and pressing the steering must be initialised. To do this, OPERATION brake/clutch pedal. turn the steering wheel from one end to the other and bring it back to the centre NOTE For versions with automatic...
Page 16: Engine Immobilizer
ON position. A child could activate the electric window winders, other controls or even start the vehicle. 5) If the ignition device has been tampered with (e.g. an attempted theft), have it checked over by the Alfa Romeo Dealership before driving again.
Page 17: Alarm System
ALARM SYSTEM DOORS (where provided) LOCKING/UNLOCKING DOORS FROM THE INSIDE Activation of the alarm triggers the Central locking/unlocking acoustic warning and the direction If all doors are closed properly, they will indicators. automatically be locked once the vehicle IMPORTANT The alarm is adapted to has exceeded about 12 mph (20 km/h) meet requirements in various countries.
Page 18 LOCKING/UNLOCKING DOORS FROM Where the function is provided, grasping THE OUTSIDE the handle of the driver's door unlocks the driver's side door or all doors Locking from the outside depending on the mode set using the With the doors closed, press the Connect system.
Page 19 To extract the metal insert, proceed as Do not push the lock/unlock door button The direction indicators flash 3 times to follows: fig. 7 and push the handle simultaneously, let you know that the device is active. Pressing in the points indicated in (seefig.
Page 20 position : device engaged (door turn the key clockwise for the right 7) NEVER leave children unattended inside locked); door locks or anticlockwise for the left the car, let alone leave the car with the doors position : device not engaged (door door locks;...
Page 21: Seats
SEATS Backrest angle adjustment Longitudinal adjustment Move lever 3 fig. 14 to adjust the Push switch 1 fig. 15 forwards or backrest angle, accompanying it with the backwards to move the seat in the FRONT SEATS WITH MANUAL movement of the torso (operate the lever corresponding direction.
Page 22 Seat angle adjustment (tilting) 3 minutes after having opened the Press the buttons for a few seconds to driver's side door or until the door is activate the "fast maximum heating" (where provided) closed, even with the ignition device in function.
Page 23 04066S0005EM 04066S0007EM 04066S0008EM Partial extension of the luggage Repositioning the backrests Central backrest section repositioning compartment (1/3 or 2/3) Move the seatbelts to the side, making Using the head restraint, lift the central sure that they are correctly extended and portion upwards, accompanying it during not twisted and that they are not trapped its movement, lightly press to make sure...
Page 24: Headrests
HEADRESTS HEAD RESTRAINTS (removal) 12) Make sure the backrests are properly Proceed as follows to remove the head secured at both sides to prevent them from moving forward, in the event of sharp restraints: braking, with possible impact with of the ADJUSTMENTS raise the head restraints to their passengers.
Page 25: Steering Wheel
STEERING WHEEL To adjust the position bring the lever 1 fig. 24 down to position A after which the WARNING 14) 15) steering wheel can be adjusted to the ADJUSTMENTS most suitable position and subsequently 14) All adjustments must be carried out only locked in this position by bringing lever The steering wheel can be adjusted both with the car stationary and engine stopped.
Page 26: Rear View Mirrors
REAR VIEW MIRRORS device in position A: left mirror selected; device in position B: right mirror INTERIOR MIRROR selected. To adjust the selected mirror, use device Operate lever fig. 26 to adjust the mirror 1 in the four directions. into two different positions: normal or anti-glare.
Page 27: External Lights
EXTERNAL LIGHTS If device 1 is turned again during door mirror folding (from closed to open WARNING position and vice versa), their movement LIGHT SWITCH direction is reversed. 16) As door mirrors are curved, and The light switches fig. 30, located on the Automatic activation therefore they may slightly alter the left side (left hand drive versions) or on...
Page 28 AUTO FUNCTION (dusk sensor) DAYTIME RUNNING LIGHTS (DRL) AND To turn off the fog lights, press the SIDE/TAIL LIGHTS This is an infrared LED sensor that works button again or turn the switch to the (where provided) in conjunction with the rain sensor and is O position.
Page 29 The rear fog light switches on only when The function can be activated from the The system directs the light beam to light the dipped beam headlights or fog lights Connect system by selecting the up the road in the best way, taking into are switched on.
Page 30 Flashing the headlights The direction indicators are switched off automatically when the steering wheel is The flashing of the main beam headlights straightened. is activated by pulling the left stalk towards the steering wheel, the lights "Lane Change" function remain on while you are operating the When you want to signal the change of lever.
Page 31: Interior Lights
INTERIOR LIGHTS WINDSCREEN WIPER The control is pulsed so that for every action the level intensity increases/ decreases, up to a maximum of seven. FRONT CEILING LIGHT SCREEN WIPER/WASHER Switch 1 fig. 34 switches on/off light 7) 8) This operates only with the ignition Switch 2 is used to switch the rear device at ON.
Page 32 If operation is not Activation/deactivation subsequently restored, even after restarting IMPORTANT This function does not the engine, contact an Alfa Romeo 9) 10) activate the windscreen washer; Dealership. Rotating the ring nut fig. 35 to position...
Page 33: Climate Control
CLIMATE CONTROL AUTOMATIC DUAL-ZONE CLIMATE CONTROL SYSTEM Controls 04156S0005EM 1. Driver side temperature adjustment knob; 2. Driver side AUTO function activation button (automatic operation); 3. Driver's side air distribution selection button; 4. MAX-DEF function activation button (rapid defrosting/demisting); 5. Fan speed adjustment knob;...
Page 34 With Start & Stop Evo system on (engine Air flow to the windscreen and front Air flow distribution between off and vehicle speed equal to 0 mph side window vents to windscreen demisting/defrosting (0 km/h)), the flow is reduced as much as demist/defrost them.
Page 35: Window Winders
WINDOW WINDERS 2: front right window opening/closing. Window closing "Continuous automatic" operation during Lift the buttons to close the desired window opening/closing stage and window. ELECTRIC WINDOWS anti-pinch system activated. The window closing stage occurs 3: rear right window opening/closing. following the same logic described for "Continuous automatic"...
Page 36: Electric Sunroof
ELECTRIC SUNROOF CLOSING From the position of complete opening WARNING (where provided) press button 1 next to the symbol: the roof will close completely. 20) Incorrect use of the electric windows The electric sunroof comprises two glass The automatic motion can be interrupted may be dangerous.
Page 37: Bonnet
BONNET ANTI-PINCH SAFETY DEVICE The sun roof has an anti-pinch safety WARNING OPENING system capable of detecting the 22) 23) presence of an obstacle during the 21) When leaving the vehicle, make sure to Proceed as follows: closing movement: if this happens, the take the key with you to avoid the risk of inside the passenger compartment system intervenes and the movement of...
Page 38: Tailgate
TAILGATE IMPORTANT Always check that the bonnet is closed correctly to prevent it from opening while the vehicle is The tailgate unlocking is electrically travelling. Since the bonnet is equipped operated and is deactivated when the car with a double locking system, one for is in motion.
Page 39 Opening from the inside When unlocked, the boot can be opened IMPORTANT from inside the vehicle using the opening button fig. 42 located under the 12) When you need to disconnect or remove dashboard near the front bonnet opening the battery, do not close the boot. In order to lever until you hear the unlocking click.
Page 40: Roof Rack/Ski Rack
IMPORTANT 13) Never exceed the maximum permitted loads (see chapter "Technical specifications"). 14) Fully comply with the regulations in force concerning maximum clearance. 04256S0001EM Lineaccessori Alfa Romeo includes a dedicated roof rack/ski rack for this vehicle.
Page 41 KNOWING THE INSTRUMENT PANEL CONTROL PANEL AND ON-BOARD INSTRUMENTS ..40 DISPLAY ........42 WARNING LIGHTS AND MESSAGES .
Page 42: Control Panel And On-Board Instruments
CONTROL PANEL AND ON-BOARD INSTRUMENTS 3.5” TFT DISPLAY 05026S0001EM 1. Rev counter 2. Digital engine oil temperature gauge with overheating warning light 3. TFT Display 4. Digital fuel level gauge (the triangle on the left side of the symbol indicates the side of the vehicle with the fuel filler) 5.
Page 43 VERSIONS WITH 7” TFT DISPLAY 05026S0011EM 1. Rev counter 2. Digital engine oil temperature gauge with overheating warning light 3. TFT Display 4. Digital fuel level gauge (the triangle on the left side of the symbol indicates the side of the vehicle with the fuel filler) 5.
Page 44: Display
DISPLAY DESCRIPTION The vehicle can be equipped with a 3.5" or 7" TFT Display. RECONFIGURABLE TFT DISPLAY During operation, the display is divided into multiple sections which show driving data, warnings and failure indications. fig. 47 shows the display layout, identifying the various sections. 05036S0001EM...
Page 45 1 Gearbox Information 4 Reconfigurable main area Home Automatic transmission Can display the following screens: The parameters shown on the display, for Home. the modes: Dynamic, Normal and Displays the following information Trip A. Advanced Efficiency are: regarding the gearbox operation: Trip B (can be activated/deactivated Time fig.
Page 46 3.5” TFT Display Trip A and B The "Trip computer" can be used to display, for all driving modes (Dynamic, Normal, Advanced Efficiency and RACE) and with the ignition device ON, the measurements regarding the operating state of the car. This function is characterised by two separate records, called “Trip A”...
Page 47 7” TFT Display 3.5” TFT Display 3.5” TFT Display 05036S0107EM 05036S0008EM 05036S0010EM To reset the values, press and hold down 7” TFT Display 7” TFT Display the button on the right stalk fig. 55. 05036S0009EM 05036S0111EM 05036S0002EM The screen graphically reproduces some The three central icons on the screen Performance parameters closely linked to the...
Page 48 The globe (7" TFT Display) lights up The displayed parameters are related to 5 Compass gradually according to lower vehicle stability, the graphs illustrate the Views the position indicating the cardinal consumption. trend of the longitudinal/lateral point. accelerations (G-meter information), Dynamic, 6 Milometer considering gravitational acceleration as...
Page 49 PARAMETERS SET BY USER Restore Settings (deletes the current settings and restores the factory settings). To access and set the various functions, turn and press the Rotary Pad to select and confirm the selection. Clock and Date 05036S0040EM 05036S0015EM Units & Language A series of functions programmable by the user can be set using the Connect system, this paragraph describes only the...
Page 50 Restore Settings (deletes the current Audio repeat (allows to settings and restores the factory activate/deactivate the repetition of the settings). audio (Radio and Media) function screens on the instrument panel display as well). To access and set the various functions, Nav repeat (allows to activate/ turn and press the Rotary Pad to select deactivate the repetition of the audio...
Page 51: Warning Lights And Messages
WARNING LIGHTS AND MESSAGES IMPORTANT The warning light switches on together with a dedicated message and/or acoustic signal when applicable. These indications are indicative and precautionary and as such must not be considered as exhaustive and/or alternative to the information contained in the Owner Handbook, which you are advised to read carefully in all cases.
Page 52 The warning light turns on when the level of the brake fluid in the reservoir falls below the minimum level, possibly due to a leak in the circuit. Go to an Alfa Romeo Dealership to have the system checked as soon as possible. Electric parking brake on The warning light switches on when the electric parking brake is engaged.
Page 53 Before proceeding, contact an Alfa Romeo Dealership to have the system checked immediately.
Page 54 Do not continue driving with one or more flat tyres as handling may be compromised. Stop the vehicle, avoiding sharp braking and steering. Immediately restore the correct inflation pressure using the Tire Repair Kit (see "Repairing a wheel" paragraph in the "In an emergency" chapter) and contact the dedicated Alfa Romeo Dealership as soon as possible. Tyre pressure low The warning light switches on to indicate that the tyre pressure is lower than the recommended value and/or that slow pressure loss is occurring.
Page 55 Under these conditions, the vehicle can continue travelling at moderate speed but without demanding excessive effort from the engine or high speed. Prolonged use of the car with the warning light on constantly may cause damage. Contact an Alfa Romeo Dealership as soon as possible.
Page 56 Warning What it means light FORWARD COLLISION WARNING SYSTEM (FCW) (where available) This warning light informs the driver that the frontal collision alarm function is not enabled. REAR FOG LIGHT The warning light switches on when the rear fog light is activated.
Page 57 Green warning lights Warning What it means light SIDE LIGHTS AND DIPPED BEAM HEADLIGHTS The warning light switches on when the side lights or dipped headlights are turned on. "Follow me" function engaged This function allows the headlights to remain on for 30, 60 or 90 seconds after the ignition device was placed in STOP position. FRONT FOG LIGHTS The warning light comes on when the front fog lights are turned on.
Page 58 The switching on of the symbol signals a failure in the automatic steering correction system. Contact an Alfa Romeo Dealership to have the system checked. IMPORTANT 17) If the symbol switches on when driving, stop the engine immediately and contact an Alfa Romeo Dealership.
Page 59 MIN mark. In this case, wait for the engine to cool down, then slowly and carefully open the cap, top up with coolant and check that the level is between the MIN and MAX marks on the reservoir itself. Also check visually for any fluid leaks. Contact an Alfa Romeo Dealership if the symbol comes on when the engine is started again.
Page 60 The symbol switches on, along with the respective message on the display, to indicate that the engine oil level is too high. Go to an Alfa Romeo dealership as soon as possible to have the correct level restored. Run the engine under 3000 rpm during this time.
Page 61 Engine Immobilizer system failure The symbol switches on to report a failure of the Engine Immobilizer system. Contact an Alfa Romeo Dealership as soon as possible. Break-in attempt The symbol switches on when the ignition device is moved to ON position, to indicate a possible break-in attempt detected by the alarm system.
Page 62 START & STOP EVO SYSTEM FAILURE This symbol switches on to report a Stop & Start Evo system failure. Contact an Alfa Romeo Dealership as soon as possible to have the failure eliminated. RAIN SENSOR FAILURE The symbol switches on in the case of failure of the automatic windscreen wiper.
Page 63 For reactivating the fuel cut-off system, refer to the description in the "Fuel cut-off system" section in the "In an emergency" chapter. If it is not possible to restore the fuel supply, contact an Alfa Romeo Dealership. PARK SENSORS SYSTEM FAILURE Lights up when the system has failed or is not available.
Page 64 Alfa Romeo Dealership as soon as possible to have the system checked. AUDIO SYSTEM FAILURE The symbol switches on to report a failure of the audio system. Contact an Alfa Romeo Dealership as soon as possible to have the failure eliminated. CLUTCH PEDAL (where provided) Lights up to alert the driver to press the clutch pedal in order to start the engine.
Page 65 20) The presence of water in the fuel system circuit may cause severe damage to the injection system and irregular engine operation. If the symbol is displayed contact an Alfa Romeo Dealership as soon as possible to bleed the system. If the above indications come on immediately...
Page 66 "In an emergency" chapter. If you are still able to drive the car (parking brake is not engaged), drive to the nearest Alfa Romeo Dealership and remember, when executing any manoeuvres/commands, that the electric parking brake is not operational.
Page 67 FOUR WHEEL DRIVE FAILURE This symbol switches on to report a four wheel drive system failure. Contact an Alfa Romeo Dealership as soon as possible to have the failure eliminated. AFS SYSTEM FAILURE The symbol appears to indicate the automatic directional light system failure.
Page 68 Switches on when the most comfortable suspension setting is activated. SHOCK ABSORBERS FAILURE (ADC) (where provided) While driving, if the symbol switches on, it signals a failure in the suspension system. Contact an Alfa Romeo Dealership to have the system checked.
Page 69 Green symbols Symbol What it means LOW BEAM HEADLIGHTS (on 7" TFT display) The symbol comes on when the dipped beam headlights are activated. AUTOMATIC DIPPED BEAM HEADLIGHTS (on 7" TFT display) The symbol lights up when the automatic dipped beam headlights are on. START &...
Page 70 This page is intentionally left blank...
Page 71 SAFETY ACTIVE SAFETY SYSTEMS ......70 DRIVING ASSISTANCE SYSTEMS ....73 OCCUPANT PROTECTION SYSTEMS .
Page 72: Active Safety Systems
ACTIVE SAFETY SYSTEMS The Electronic Braking Force Distribution When the road and environmental (EBD) system completes the system conditions require better traction, the The vehicle may be equipped with the allowing the brake force to be distributed vehicle automatically goes to AWD mode. following active safety devices: between the front and rear wheels.
Page 73 When the real trajectory deviates from if the slipping only involves one of the In addition, the brake pedal should be the desired trajectory, the ESC system drive wheels, the BLD (Brake Limited pressed continuously during braking, intervenes to counter the vehicle’s Differential) function is activated, avoiding intermittent presses, to get the understeer or oversteer.
Page 74 When two seconds have elapsed, without ATV (Alfa™ Active Torque Vectoring) 33) If the ABS intervenes, this indicates that SYSTEM starting, the system is automatically the grip of the tyres on the road is nearing its The dynamic drive control is used to deactivated, gradually releasing the limit: you must slow down to a speed optimize and balance the drive torque...
Page 75: Driving Assistance Systems
DRIVING ASSISTANCE 51) The PBA system cannot prevent 43) For the correct operation of the ESC SYSTEMS system, the tyres must necessarily be of the accidents, including those due to excessive same make and type on all wheels, in perfect speed on corners, driving on low-grip The vehicle can feature the following condition and, above all, of the prescribed...
Page 76 The system warns the driver about the This area begins from the door mirror and For the system to operate correctly, the presence of vehicles in the detection extends for about 20 ft (6 m) towards the rear bumper area where the radar area by lighting up, on the relevant side, rear part of the vehicle.
Page 77 RCP (Rear Cross Path detection) system The visual warning on the mirror will blink if the driver switches on the direction This system helps the driver during indicators, thus indicating the intention reverse manoeuvres in the case of to change lane. reduced visibility.
Page 78 The system may lightly brake to warn the Engagement/disengagement The system is active when: driver if a possible frontal accident is each time the engine is started; The Forward Collision Warning system detected (limited braking). Signals and is active (ON) on the Connect system; can be deactivated (and then reactivated) limited braking are intended to allow the the ignition device is at ON;...
Page 79 Alfa Romeo Dealership as soon as The system sensitivity setting is kept in contact an Alfa Romeo Dealership for a possible. the memory when the engine is switched sensor alignment check.
Page 80 The function is active with speed above Vehicles with small dimensions and/or not aligned in the driving lane 4 mph (7 km/h). The system cannot detect vehicles in Driving in special conditions front of you that are outside the range of In certain driving conditions, such as, for the radar sensor.
Page 81 Lane change by other vehicles These possible activations are a consequence of the real driving scenario Vehicles suddenly changing lane, entering coverage by the system and must not be the same lane as your car and within the regarded as faults. radar sensor’s operating range, may The system has been designed for cause the system to intervene fig.
Page 82 1 mi (1.6 km) after the aftermarket tyre sealant is used it is 3 hour interval. Operating example recommended to go to an Alfa Romeo Supposing that the prescribed cold The cold tyre inflation pressure must not Dealership to have the sensors checked.
Page 83 INSUFFICIENT TYRE PRESSURE warning light switches off when TPMS deactivation INDICATION the failure condition disappears and the The TPMS can be deactivated by If an insufficient pressure value is pressure value is displayed again in place replacing the wheels equipped with detected on one or more tyres, the of the dashes.
Page 84 In the event of a into consideration. 68) When a tyre is removed, it is advisable sensor failure, contact an Alfa Romeo 61) If the car must be placed on a roller to replace the rubber valve seal as well: Dealership.
Page 85: Occupant Protection Systems
OCCUPANT PROTECTION SEAT BELTS 29) When towing a trailer, a vehicle or during SYSTEMS loading manoeuvres on a vehicle transporter All the seatbelts have three anchoring (or in vehicle for transport), the system must Some of the most important safety points each with its own retractor.
Page 86 06056S0001EM 06056S0003EM On removal of the belt, if it jams, let it rewind for a short stretch, then pull it out again without jerking. WARNING To unfasten the seat belts, press button 3 and guide the seat belt with your hand while it is rewinding, to prevent it from 69) Never press button 3 when travelling.
Page 87: Sba (Seat Belt Alert) System
(see the in belt fastening status, the icons are following paragraphs). shown again for approximately NOTE Contact an Alfa Romeo Dealership 06066S0001EM 30 seconds before disappearing. to deactivate the acoustic warning. The As soon as the threshold of 5 mph...
Page 88: Pretensioners
30 seconds after efficiency. the last signal. If, due to unusual natural events (floods, sea storms, etc.), the device has been affected by water and/or mud, contact an Alfa Romeo Dealership to have it replaced.
Page 89 IMPORTANT To obtain the highest Pregnant women must position the lower degree of protection from the action of part of the belt very low down so that it the pretensioner, wear the seat belt tight passes over the pelvis and under the to the torso and pelvis.
Page 90: Child Protection Systems
Compared with an adult, a child's head is around the pretensioner may cause damage larger and heavier in proportion to their or make it deploy. Contact an Alfa Romeo WARNING body and the child's muscular and bone Dealership should intervention be necessary structures are not fully developed.
Page 91 Lineaccessori includes child restraint systems for each weight group. These devices are recommended having been specifically tested for Alfa Romeo cars. 06086S0001EM...
Page 92 The child restraint system is secured by Group 2 Group 3 the vehicle seat belts, as shown in Children weighing 33 (15) to 55 lb (25 kg) For children weighing 48 (22) to 80 lb fig. 86 and it must restrain the child in may be restrained directly by the car seat (36 kg), there are dedicated restraint turn with its own belts.
Page 93 PASSENGER SEAT COMPLIANCE WITH REGULATIONS ON UNIVERSAL CHILD RESTRAINT SYSTEM USE According to the European Directive 2000/3/EC the suitability of each passenger seat position for the fixing of universal child restraint systems is shown in the following table: Positioning the “Universal” child restraint system Front passenger Rear passengers Group...
Page 94 INSTALLING AN ISOFIX CHILD CARSEAT 83) 84) 85) 86) 87) The rear side seats of the vehicle are equipped with ISOFIX attachments, for fitting child restraint systems quickly, simply and safely. The ISOFIX system lets you install the ISOFIX child restraining system without using the car seat belts but connecting them directly to the carseat with three 06086S0009EM...
Page 95 SUITABILITY OF PASSENGER SEATS FOR ISOFIX CHILD RESTRAINT SYSTEM USE ISOFIX POSITIONS ON THE VEHICLE Rear central Rear side Weight categories Size category Device Front passenger passenger passengers (where provided) Group 0 (up to 22 lb ISO/R1 (10 kg)) ISO/R1 Group 0+ (up to 29 lb ISO/R2 (13 kg))
Page 96 SUITABILITY OF PASSENGER SEATS NOTE The vehicle seats, i-Size FOR i-Size CHILD RESTRAINT SYSTEM type-approved, are marked by the symbol shown in fig. 94. The rear side seats of the vehicle are type-approved to house the state-of-the-art i-Size child restraint systems.
Page 97 The following table, according to European standard ECE 129, indicates the possibility of i-Size child restraint system installation. i-Size POSITIONS ON THE VEHICLE Rear side Rear central Device Front passenger passengers passenger ISO/R2 i-Size child restraint systems ISO/F2 i-U: suitable for Universal i-Size child restraint systems, both rearward facing and forward facing. X: seat not suitable for Universal i-Size child restraint systems.
Page 98 CHILD RESTRAINT SYSTEMS RECOMMENDED BY ALFA ROMEO FOR YOUR GIULIA Lineaccessori Alfa Romeo includes a complete range of child restraint systems to be fixed using the seat belt with three anchorage points or the ISOFIX anchorages. IMPORTANT Alfa Romeo recommends fitting the child restraint system according to the instructions, which must be included.
Page 99 Fair G0/1S seat belts (forward facing only) or using the ISOFIX anchorages of the vehicle. Alfa Romeo recommends fitting it Group 1: from 20 using the rear facing ISOFIX (9) up to 40 lb platform (A RWF type - to be...
Page 100 ISOFIX anchorages of the Group 3: from 48 vehicle. (22) to 80 lb (36 kg) TAKATA MAXI PLUS Alfa Romeo recommends to install from 53 (136) to it using the ISOFIX anchorages of 60 in (150 cm) the vehicle.
Page 101 Main recommendations to carry While travelling, do not let the child sit 77) Should it be necessary to carry a child on children safely incorrectly or unfasten the belts. the passenger side front seat in a rear facing Install the child restraint systems on Never allow a child to put the belt's child restraint system, the passenger side the rear seat, which is the most protected...
Page 102: Supplementary Restraint System (Srs) - Airbag
Alfa Romeo emblem, on the dashboard, hear the click. Follow the instructions for front surface of the vehicle (e.g. wing...
Page 103 Moving the ignition device to AVV, the two LEDs switch on for a few seconds. If not, contact a Alfa Romeo Dealership. During the first seconds, the activation of the 06106S0003EM LEDs does not actually show the...
Page 104 Passenger protection activated: the LED ON fig. 99 switches on. Passenger protection deactivated: the OFF LED switches on with a steady light. 06106S0008EM...
Page 105 Passenger side front airbag and child restraint systems IMPORTANT J0A0215...
Page 106 Airbag checking, repair and replacement and window bags. must be carried out at an Alfa Romeo Dealership. Side bag If the car is scrapped, have the airbag These consist of two bags located in the system deactivated at an Alfa Romeo front seat backrests fig.
Page 107 Before continuing, contact an Alfa Romeo Dealership immediately to have the system checked. 95) In case of a LED OFF failure (located...
Page 108 This page is intentionally left blank...
Page 109 STARTING AND DRIVING STARTING THE ENGINE......108 PARKING THE VEHICLE ......109 MANUAL GEARBOX .
Page 110: Starting The Engine
STARTING THE ENGINE Versions with automatic transmission with engine idling, press the start button. Proceed as follows: engage the electric parking brake and Vehicles with electronic key (Keyless STARTING THE ENGINE set the gear lever to P (Park) or N Start) (Neutral), Before starting the engine, adjust the...
Page 111: Parking The Vehicle
(when on a steep slope), you must always used, but an Alfa Romeo Dealership must be contacted as soon as possible. engage: 35) A quick burst on the accelerator before...
Page 112 Alfa Romeo electric parking brake when the vehicle is Dealership. stationary. Release the switch on the central tunnel...
Page 113: Manual Gearbox
MANUAL GEARBOX "Safe Hold": if the vehicle speed is the driver's seat belt is not fastened; lower than 2 mph (3 km/h), on vehicles the driver side door is open; 108) with automatic transmission, the gear no attempts to apply pressure on the lever is not in P (Park) position and the brake pedal have been detected.
Page 114: Automatic Transmission
IMPORTANT Reverse can only be AUTOMATIC TRANSMISSION The positions diagram is illustrated on engaged when the vehicle is completely the top of the lever. stationary. With the engine running, wait The letter corresponding to the selected for at least 2 seconds with the clutch The vehicle can be equipped with a mode lights up and can be seen on the pedal fully pressed before engaging...
Page 115 IMPORTANT DO NOT accelerate while Steering wheel stalks shifting from position P (or N) to another (where provided) position. The gear can be manually shifted also by using the levers behind the steering IMPORTANT After selecting a gear, wait wheel, pull the right gear lever (+) a few seconds before accelerating.
Page 116 IMPORTANT In the event of a temporary (where provided) failure it is in any case recommended to Transmission operation is constantly contact an Alfa Romeo Dealership as IMPORTANT monitored to detect any fault. If a soon as possible. condition that might damage the...
Page 117: Alfa Dna™" System
"ALFA DNA™" SYSTEM DRIVING MODES It is not possible to go directly from "Dynamic" mode to "Advanced "Normal" Mode Efficiency" mode and vice versa. You Engagement/disengagement "ALFA DNA™" SYSTEM must always activate the “Normal” mode It is activated by rotating the selector to first and then select the other mode.
Page 118: Start & Stop Evo
With the vehicle stopped, the engine neutral and repeat the procedure. If the stops with gearbox in neutral and clutch problem persists, contact an Alfa Romeo pedal released. Dealership. Versions with automatic transmission...
Page 119: Speed Limiter
"off". 112) When replacing the battery, always ACTIVATING THE DEVICE contact an Alfa Romeo Dealership. Replace Automatic deactivation of the device the battery with one of the same type The function can be activated/ The device deactivates automatically in (HEAVY DUTY) and with the same deactivated on the Connect system.
Page 120: Cruise Control
CRUISE CONTROL If needed (when overtaking for instance), you can accelerate simply by pressing the accelerator; when you release the pedal, This is an electronically controlled driving the vehicle goes back to the speed stored assistance device that allows the desired previously.
Page 121: Active Cruise Control
114) In case of a malfunction or failure of press and release the RES button. the device, contact an Alfa Romeo The device allows to hold the vehicle at Dealership. DEACTIVATING THE DEVICE...
Page 122 If the sensor detects a vehicle ahead, the device automatically intervenes by braking (or accelerating) slightly in order not to exceed the original set speed, so that the vehicle keeps the preset distance, seeking to adapt to the speed of the vehicle ahead. In the cases described below, the system performance is not guaranteed, it is therefore advisable to turn the device on...
Page 123 IMPORTANT It is dangerous to leave the when the ESC system is off; device activated when it is not used. when the Forward Collision Warning There is a risk of inadvertently activating Plus system (where provided) is braking it and losing control of the vehicle due to automatically;...
Page 124 Decreasing speed The automatic transmission could change In this condition, the device no longer to a lower gears when driving downhill or provides the overtaking assist function Once the device has been activated, you when accelerating. This is normal and on the left-hand side until it determines can decrease the speed by lowering the necessary to maintain the set speed.
Page 125 Recalling an excessively high or low The setting is 4 (maximum) the first time The device automatically adjusts the speed for the current traffic and road the device is used. After the distance has car’s speed to keep the set distance, conditions could cause an acceleration or been modified by the driver, the new independently of the set speed.
Page 126 IMPORTANT The driver is fully SYSTEM LIMITED OPERATION The non-aligned car can weave in and out WARNING responsible for holding a safe distance of the driving direction causing the car to from the vehicle ahead respecting the brake or accelerate unexpectedly. If the dedicated message is shown on the highway code in force in the respective display, a condition limiting the system...
Page 127 Using the device on gradient Small cars Objects and cars moving in opposite or crosswise direction When driving on roads with variable Some narrow vehicles (e.g. bicycles and The device cannot detect the presence of gradient, the device may not detect the motorcycles fig.
Page 128: Park Sensors System
In the event of a crosswise direction and stationary objects sensor failure, contact an Alfa Romeo (e.g. a vehicle standing in a queue or a broken Dealership. 122) down vehicle).
Page 129 VERSIONS WITH 8 SENSORS The LED in the button will light up or not when the system switches from on to off The parking sensors, located in the front (and vice versa). (fig. 125 ) and rear (fig. 126 ) bumper, LED off: system activated;...
Page 130 48) Have interventions on the bumper in the an Alfa Romeo Dealership for the Park be altered by the presence of ultrasonic area of the sensors carried out only by an Sensors system update operations systems (e.g.
Page 131: Lane Departure Warning (Ldw) System
07226S0001EM exclusively an Alfa Romeo Dealership. Do not within such limits, in order to make sure replace the windscreen on your own, risk of that it remains inside the lane.
Page 132: Rear Back-Up Camera / Dynamic Gridlines
REAR BACK-UP CAMERA / Switch-off delay; 55) Camera operation may also be DYNAMIC GRIDLINES Grille. compromised by the presence of dust, condensation, dirt or ice on the windscreen, Select "Activate" to activate the camera by traffic conditions (e.g. vehicles that are view on the Connect system display.
Page 133: Refuelling The Vehicle
REFUELLING THE VEHICLE The table below shows the approximate distances for each area fig. 129: IMPORTANT Always stop the engine before refuelling. Distance from the 56) It is vital, for correct operation, that the Zone rear of the vehicle PETROL ENGINES camera is always kept clean and free from any mud, dirt, snow or ice.
Page 134 B7: diesel containing up to 7% (V/V) of FAME (Fatty Acid Methyl Esters) compliant with the EN590 specification. B10: diesel containing up to 10% (V/V) of FAME (Fatty Acid Methyl Esters) 07206S0001EM 07206S0002EM compliant with the EN16734 specification. after refuelling, before removing the The symbols, shown below, make it easier dispenser, wait for at least 10 seconds in to recognise the correct fuel type to use...
Page 135 WARNING 124) Do not apply any object/plug to the end of the filler which is not provided for the car. The use of non-compliant objects/plugs could cause a pressure increase inside the tank, resulting in dangerous situations. 125) Do not bring naked flames or lit cigarettes near to the fuel filler: fire risk.
Page 136: Towing Trailers
The tow hook structure must be secured to the body in the points shown in the fig. 132. A - A 147.5 B - B C - C 90.7 07226S0040EM IMPORTANT Contact an Alfa Romeo Dealership to install a tow hook.
Page 137 In an emergency we recommend that you call the freephone number found in the Warranty Booklet. It is also possible to call the national or international universal freephone number to search for the nearest Alfa Romeo Dealership.
Page 138: Hazard Warning Lights
HAZARD WARNING LIGHTS REPLACING A BULB Emergency braking The hazard lights are switched on and warning lights appear on the CONTROL 127) 128) 129) instrument panel in case of emergency braking and according to the mode selected by the “Alfa DNA™” selector. GENERAL INSTRUCTIONS Press the fig.
Page 139 TYPES OF BULBS The vehicle is equipped with the following bulbs Glass bulbs (type A): they are press-fitted. Pull to extract. Bayonet-type bulbs (type B): to remove them from their holder, press the bulb and turn it anticlockwise, then extract it. Tubular bulbs (type C): release them from their contacts to remove.
Page 140 Light bulbs Type Power Figure reference (1) Main beam headlights, front side lights/daylight running lights 55/15W (DRL) (1) Dipped headlamps 55 W (1) Front direction indicators PY24W (1) Fog lights 55 W Main beam/dipped beam headlights (Xenon gas discharge) 25 W Main beam/dipped beam headlights (Xenon gas discharge) 35 W Sun visor light...
Page 141 REPLACING AN EXTERNAL BULB remount the lid and cover, tightening the fixing bolts. IMPORTANT Only replace the bulb when the engine is off. Also ensure that the Main beam headlights engine is cold, to prevent the risk of To change the bulb of these lights, burns.
Page 142 turn the bulb, bulb holder and connector assembly anticlockwise and then slide it off the headlight body fig. 139; 08026S0023EM 08026S0007EM remove cover by turning it fig. 141; remove the bulb by sliding it off the bulb holder; install the new bulb, making sure it is 08026S0005EM correctly inserted in the bulb holder;...
Page 143: Replacing Fuses
130) 131) 132) 133) 134) To replace the bulbs of the main beam 59) 60) headlights/dipped headlights contact an Fuses protect the electrical system: they Alfa Romeo Dealership intervene (blow) in the event of a failure or improper action on the system. 08026S0021EM WARNING...
Page 144 The pliers fig. 146 have two different CONTROL UNIT UNDER PASSENGER the fuses are freely accessible on the SIDE FOOTBOARD ends, specifically designed to remove the control unit. different types of fuses present in the To access the fuses, proceed as follows: The number identifying the electrical vehicle.
Page 145 CONTROL UNIT UNDER PASSENGER SIDE FOOTBOARD 08036S0013EM FUNCTION FUSE AMPERE Front electric window (driver side) Front electric window (passenger side) Power supply for Connect system, Climate Control system, Alarm, Electric door mirror folding, EOBD system, USB port Power Lock Device (Driver side door unlocking - where provided)/Door unlocking, Central locking Windscreen washer pump...
Page 146 FUNCTION FUSE AMPERE Rear left electric window Rear right electric window Heater rear window coil, cigar lighter...
Page 147 LUGGAGE COMPARTMENT FUSE BOX 08036S0015EM FUNCTION FUSE AMPERE Tow hook module (TTM) Hi-Fi system KL15/a USB Recharge (C070) I-Drive / USB / AUX port KL15/a 12V Power outlet (R053)
Page 148: Tire Repair Kit
132) Contact an Alfa Romeo Dealership if a elements. The Tire Repair Kit is located in the boot, safety system (airbags, brakes), transmission system (engine, gearbox) or inside a specific container.
Page 149 IMPORTANT Only use original cartridges, Repair Kit. Drive carefully, particularly on switch 5 fig. 154 to position I (ON); which can be purchased at an Alfa Romeo bends. Do not exceed 80 km/h. Avoid sudden inflate the tyre to the pressure acceleration or braking.
Page 150: Emergency Starting
REMOTE BATTERY CONNECTION not drive any further: the Tire Repair Kit POLES cannot guarantee proper seal because the tyre is too damaged. Contact an Alfa Romeo To facilitate the operation, the remote Dealership. poles of the battery for the jump starting...
Page 151 JUMP STARTING 144) 145) 146) Proceed as follows: switch off all electrical devices in the vehicle; engage the parking brake, move the lever to P (Park), for versions equipped with automatic transmission, or neutral, for versions with manual gearbox, then set the ignition device to STOP;...
Page 152 Cable connection disconnect the terminal on the opposite end of the negative cable from IMPORTANT the negative (-) pole of the auxiliary Proceed as follows to carry out a jump battery; starting: 62) Never use a fast battery-charger to disconnect the terminal on the connect a terminal on the end of the start the engine as this could damage the opposite end of the positive (+) cable...
Page 153: Fuel Cut-Off System
(eg: door locks, anti-theft device, etc.), remain powered. IMPORTANT After the impact, carefully check the vehicle for fuel leaks, for instance in the engine compartment, under the vehicle or near the tank area. IMPORTANT Contact an Alfa Romeo Dealership to have the system checked.
Page 154: Broken-Down Vehicle Towing
BROKEN-DOWN VEHICLE FOUR-WHEEL DRIVE (AWD) VERSIONS TOWING THE VEHICLE TOWING It is recommended to tow the vehicle 147) 148) with all four wheels lifted from the In order to be able to tow the vehicle, ground on the platform of a roadside which has been in an accident or has REAR WHEEL DRIVE (RWD) VERSIONS assistance vehicle.
Page 155 WARNING 147) Move the ignition device to ON and then to STOP, without opening the door. 148) The brake servo and the electromechanical power steering will not work while the vehicle is being towed. You will therefore need to apply more force on the brake pedal and steering wheel.
Page 156 This page is intentionally left blank...
Page 157 SERVICING AND CARE SCHEDULED SERVICING ......156 ENGINE COMPARTMENT......164 BATTERY RECHARGING .
Page 158: Scheduled Servicing
SCHEDULED SERVICING PERIODIC CHECKS It is advisable to inform the Alfa Romeo Dealership of any small operating Every year or every 620 mi ( 1,000 km) Correct servicing is crucial for irregularities without waiting for the next or before long trips check and, if guaranteeing a long life for the vehicle service.
Page 159 DEMANDING USE OF THE CAR check and, if necessary, replace air cleaner; If the vehicle is used in one of the check and, if necessary, replace the following conditions: Bad Fuel fuel filter (where available). dusty roads; short, repeated journeys (less than 7-8 km) at sub-zero outside temperatures;...
Page 160 SERVICE SCHEDULE (2.0 T4 MAir petrol engine versions) The checks listed in the Scheduled Service Plan, after reaching 90,000 mi (150,000 km)/10 years, must be cyclically repeated starting from the first interval, thus following the same intervals as before. Thousands of miles Thousands of kilometres Years ●...
Page 161 Thousands of miles Thousands of kilometres Years Check operation of windscreen washer system and adjust ● ● ● ● ● jets if necessary Check cleanliness of bonnet and luggage compartment locks, ● ● ● ● ● cleanliness and lubrication of linkage Visually inspect conditions and wear of front disc brake pads ●...
Page 162 Thousands of miles Thousands of kilometres Years Change the brake fluid ● ● ● ● ● Replace the passenger compartment cleaner (5) (6) The brake fluid replacement has to be done every two years, irrespective of the mileage. (5) If the vehicle is used in dusty areas, this cleaner must be replaced every 9,000 mi (15,000 km). (o) Recommended operations (●) Mandatory operations...
Page 163 SCHEDULED SERVICING PLAN (2.2 JTD diesel engine versions) The checks listed in the Scheduled Servicing Plan, after reaching 120,000 mi (200,000 km)/10 years, must be cyclically repeated starting from the first interval, thus following the same intervals as before. Thousands of miles Thousands of kilometres Years ●...
Page 164 Thousands of miles Thousands of kilometres Years Check operation of the windscreen wiper/washer system ● ● ● ● ● and adjust jets, if necessary Check cleanliness of bonnet and luggage compartment locks, ● ● ● ● ● cleanliness and lubrication of linkage Visually inspect conditions and wear of front disc brake pads ●...
Page 165 Thousands of miles Thousands of kilometres Years ● ● ● Replace air cleaner cartridge (5) ● ● ● Replace fuel filter cartridge (7) Change the brake fluid ● ● ● ● ● Replace the passenger compartment cleaner (5) If the vehicle is used in dusty areas, this cleaner must be replaced every 12,000 mi (20,000 km). (7) If the vehicle runs on fuel with quality below the relevant European specification, this filter must be replaced every 12,000 mi (20,000 km).
Page 166: Engine Compartment
ENGINE COMPARTMENT CHECKING LEVELS 149) 150) Versions - 2.0 T4 MAir engine, fig. 163 09026S0002EM 1. Engine oil filler 2. Primary engine cooling reservoir plug 3. Brake fluid reservoir cap access cover 4. Windscreen/headlights washer fluid reservoir cap 5. Secondary engine cooling reservoir plug...
Page 167 Versions - 2.0 T4 MAir engine right-hand drive, fig. 164 09026S0006EM 1. Engine oil filler 2. Brake fluid reservoir cap access cover 3. Primary engine cooling reservoir plug 4. Windscreen/headlights washer fluid reservoir cap 5. Secondary engine cooling reservoir plug...
Page 168 Diesel versions - 2.2 JTD engine, fig. 165 09026S0503EM 1. Engine oil filler 2. Engine coolant reservoir cap 3. Brake fluid reservoir cap access cover 4. Windscreen/headlights washer fluid reservoir cap 5. Secondary engine cooling reservoir plug...
Page 169 IMPORTANT If the indication is not 3100 - 3730 mi (5000 - 6000 km). oil in excess may damage the engine. correct after the procedure, contact an Have the car checked. Never exceed the Alfa Romeo Dealership. MAX level when topping up engine oil.
Page 170 The transmission control oil level should If the level is too low, unscrew the IMPORTANT If the battery was only be checked at an Alfa Romeo reservoir cap and add the fluid described disconnected, do not start the engine Dealership.
Page 171 155) 156) 157) 158) windscreen washer is essential for an Alfa Romeo Dealership as soon as improving visibility. Repeated operation of possible to have the oil in excess removed. the system without fluid could damage or...
Page 172: Battery Recharging
BATTERY RECHARGING The vehicle is equipped with an IBS (Intelligent Battery Sensor), which is able IMPORTANT NOTES to measure the charge and discharge voltage and calculate the charge level 159) 160) and the general condition of the battery. IMPORTANT Before using the charging The sensor is placed next to the negative device, always make sure that it is terminal (-) of the battery.
Page 173: Servicing Procedures
To ensure the best possible performance, the air conditioning system must be checked and undergo maintenance at an IMPORTANT Alfa Romeo Dealership at the beginning of the summer. 70) When you need to disconnect or remove WINDSCREEN WIPER the battery, do not close the boot. In order to...
Page 174 (when necessary) may lead to more gearbox itself. clogged; use a needle to unblock them if expensive repairs, damage to other necessary. components or have a negative impact on the vehicle performance. Have any malfunction inspected immediately by an Alfa Romeo Dealership.
Page 175: Lifting The Vehicle
LIFTING THE VEHICLE WHEELS AND TYRES 76) It is recommended to have the vehicle serviced by an Alfa Romeo Dealership. When If the car needs to be jacked up, go to an carrying out normal periodic operations and Alfa Romeo Dealership which is equipped...
Page 176 IMPORTANT driveability, with the risk of losing control as possible, by contacting an Alfa Romeo of the vehicle and resulting accidents. Dealership. 80) Keep your speed down when snow chains...
Page 177: Body
BODY If you want to wash a car with automatic 82) Avoid washing with rollers and/or transmission in a car wash that moves it, brushes in washing stations. Wash the you must do the following: vehicle only by hand using neutral pH PRESERVING THE BODYWORK detergents;...
Page 178 This page is intentionally left blank...
Page 179 TECHNICAL DATA IDENTIFICATION DATA ......178 ENGINE ........179 RIMS AND TYRES .
Page 180: Identification Data
IDENTIFICATION DATA VEHICLE IDENTIFICATION NUMBER (VIN) PLATE VEHICLE IDENTIFICATION NUMBER The plate is located on the left side front The Vehicle Identification Number (VIN) door pillar fig. 173 and shows the data is stamped on a plate on the front left about: corner of the dashboard cover fig.
Page 181: Engine
ENGINE 2.0 T4 MAir engine 200 HP 280 HP Cycle Otto Otto Number and position of cylinders 4 in line 4 in line Piston bore and stroke (mm) 84 / 90 84 / 90 Total displacement (cm³) 1995 1995 Compression ratio 10 ±...
Page 182 2.2 JTD engine 136 HP 150 HP 180 HP 210 HP Cycle Diesel Diesel Diesel Diesel Number and position of cylinders 4 in line 4 in line 4 in line 4 in line Piston bore and stroke (mm) 83 / 99 83 / 99 83 / 99 83 / 99...
Page 183: Rims And Tyres
(+) Matching rims/tyres NOTE In partnership with Pirelli, Alfa Romeo has developed a range of winter tyres specially for the Alfa Romeo Giulia. They can be identified by the “AR” mark. The “AR” tyres ensure the best vehicle performance and safety. They are available in the following sizes: 205/60 R16 96H, 225/50 R17 94H and 225/45 R18 91H.
Page 184 COLD TYRE INFLATION PRESSURE When the tires are warm, the inflation pressure should be + 0.3 bar (4.4 psi) in relation to the recommended figure. However, recheck that the value is correct with the tyre cold. If it is necessary to raise the vehicle, refer to the "Raising the vehicle" paragraph in the "In an emergency" chapter. 2.0 T4 MAir and 2.2 JTD engines Unladen/medium load Full load...
Page 185 7-mm snow chains can be used on all tyres. For tyres up to 8.86 in (225 mm) in width (205/60R16, 225/55R16, 225/50R17, 225/45R18), it is also possible to install 0.35 in (9 mm) chains. We recommend using snow chains available from the Alfa Romeo Dealership. Important notes The use of snow chains should be in compliance with local regulations of each country.
Page 186: Dimensions
DIMENSIONS Dimensions are expressed in inches/millimeters and refer to the vehicle equipped with its standard-supplied tyres. Height is measured with vehicle unladen, fig. 174. 10106S0001EM...
Page 187 56.5 / 61.3 / 64 / 111 / 182.8 / 1,436 1,557 1,625 79.7 / 31.3 / 795 40.5 / 1,028 73.2 / 1,860 2,820 4,643 2,024 57 / 61.4 / 63.1 / 1,450 1,559 1,604 (+) RWD versions (*) AWD versions Small variations with respect to the reported values are possible depending on the dimensions of the rims.
Page 188: Weights
WEIGHTS Weights (lb / kg) 2.0 T4 MAir engine 2.2 JTD engine (°°) (°°) (°°) (°°) (°) (°) (+) (°°) 200 HP 280 HP LOW CO 210 HP Unladen weight (with all fluids, fuel tank 3,150 lb 3,373 lb 3,029 lb 3,086 lb 3,186 lb 3,230 lb...
Page 189 Weights (lb / kg) 2.0 T4 MAir engine 2.2 JTD engine 110 lb 110 lb 110 lb 110 lb 110 lb 110 lb 110 lb Maximum load on roof (50 kg) (50 kg) (50 kg) (50 kg) (50 kg) (50 kg) (50 kg) Maximum load on tow hitch (trailer with 141 lb...
Page 190: Refuelling
REFUELLING 2.0 T4 MAir engine 2.2 JTD engine Fuel tank (UK gal/litres) 12.76 UK gal (58 lt) 11.4 UK gal (52 lt) including a reserve of (UK gal/litres) 1.98 UK gal (9 lt) 1.76 UK gal (8 lt) Primary cooling system, versions with manual 1.89 UK gal (8.6 lt) 1.72 UK gal (8.7 lt) transmission (UK gal/litres)
Page 191 2.0 T4 MAir engine 2.2 JTD engine RDU 210/215-LSD differential (UK 0.24 UK gal (1.1 lt) 0.24 UK gal (1.1 lt) gal/litres) AWD System FAD transfer case (UK 0.11 UK gal (0.5 lt) 0.11 UK gal (0.5 lt) gal/litres) AWD System TRANSFER CASE (UK gal/litres) 0.15 UK gal (0.7 lt) 0.15 UK gal (0.7 lt)
Page 192: Fluids And Lubricants
FLUIDS AND LUBRICANTS Your car is equipped with an engine oil that has been thoroughly developed and tested in order to meet the requirements of the Scheduled Servicing Plan. Constant use of the prescribed lubricants guarantees the fuel consumption and emission specifications. Lubricant quality is crucial for engine operation and duration.
Page 193 Original fluids and Features Specification Apps lubricants TUTELA TRANSMISSION AS 8 ATF Synthetic lubricant 9.55550-AV5 Automatic transmission Contractual Technical Reference No. F139.I11 TUTELA TRANSMISSION Manual transmission SAE 70W API GEARSYNTH LV 9.55550-MZ7 GETRAG G217 / 2.2 JTD GL-4 synthetic lubricant Contractual Technical engine Reference No.
Page 194 Original fluids and Features Specification Apps lubricants Use rate 50% Not PARAFLU UP Protective agent for CUNA NC 956–16 9.55523 Contractual Technical mixable with different radiators ASTMD3306 Reference No. F101.M01 formulation products. PETRONAS DURANCE To be used diluted or Windscreen washer SC 35 CUNA NC 956-11 9.55522...
Page 195: Performance
PERFORMANCE Top performance after the initial period of vehicle usage. Acceleration from 0-62 mph sec. Versions Maximum speed mph (km/h) (0-100 km/h sec.) 2.0 T4 MAir 200 HP engine automatic transmission 146 mph (235km/h) 2.0 T4 MAir 280 HP engine automatic transmission 149 mph (240 km/h) 2.2 JTD 136 HP engine manual transmission 130 mph (210 km/h)
Page 196: Fuel Consumption
FUEL CONSUMPTION FUEL CONSUMPTION The fuel consumption figures given in the table below are determined on the basis of the type-approval tests laid down by specific European Directives. IMPORTANT The type of route, traffic conditions, weather conditions, driving style, general condition of the car, trim level/equipment/accessories, use of the climate control system, car load, presence of roof racks and other situations that adversely affect the aerodynamics or wind resistance lead to different fuel consumption values than those measured.
Page 197 Versions Urban Extra-urban Combined 2.2 JTD 180 HP engine automatic transmission 1.17 UK gal (5.3 lt) 0.77 UK gal (3.5 lt) 0.92 UK gal (4.2 lt) 1.12 UK gal (5.1 lt) 0.75 UK gal (3.4 lt) 0.88 UK gal (4.0 lt) 2.2 JTD 180 HP engine automatic transmission 2.2 JTD 180 HP engine automatic transmission LOW CO 1.06 UK gal (4.8 lt)
Page 198: Co Emissions
EMISSIONS The CO emission levels given in the following table refer to combined consumption. CO EMISSIONS Versions ACCORDING TO THE EUROPEAN DIRECTIVE IN FORCE (g/km) 2.0 T4 MAir 200 HP engine automatic transmission 2.0 T4 MAir 280 HP engine automatic transmission 2.2 JTD 136 HP engine manual transmission 2.2 JTD 136 HP engine manual transmission 2.2 JTD 150 HP engine manual transmission...
Page 199: Prescriptions For Handling The Vehicle At The End Of Its Life
You can find further information on these collection and scrapping centres either from an Alfa Romeo S.p.A. dealership or by calling the number in the Warranty Booklet or by consulting the Alfa Romeo S.p.A. website.
Page 200 This page is intentionally left blank...
Page 201 MULTIMEDIA ROAD SAFETY .......200 RECEPTION CONDITIONS ......200 CARE AND MAINTENANCE .
Page 202: Road Safety
ROAD SAFETY RECEPTION CONDITIONS CARE AND MAINTENANCE (where provided) 168) 169) 85) 86) Reception conditions change constantly Learn how to use the various system Observe the following precautions to while driving. Reception may be functions before setting off. ensure the system is fully operational: interfered with by the presence of the display lens should not come into Read the instructions for the system...
Page 203: Antitheft Protection
(e.g. horns, ambulances, police vehicles, etc.). other cars in the event of theft. If might be damaged. Contact an Alfa necessary contact an Alfa Romeo Romeo Dealership as soon as possible to Dealership. have the system repaired.
Page 204: Controls
CONTROLS CONTROLS ON TUNNEL 11036S0015EM Tunnel control summary table ON/OFF control and Volume (1) Action Function LONG PRESS switches the Connect system on and off. clockwise to increase the volume, counter-clockwise to decrease the ROTATION volume. Switches the system on if it is off. SHORT PRESS In Radio mode: activates/deactivates the Mute function.
Page 205 OPTION button (2) Pressing the "Option" button while within the modes (”RADIO”, “MEDIA”, “PHONE”, “NAVIGATION”) will open the "Settings" screen of the concerned mode. Press it again to go back to the previously selected mode. Rotary Pad (3) Action Function Within the Menus: scrolls the menu items.
Page 206 MENU button (4) Opens the main menu. 11036S0060EM...
Page 207: Controls On Steering Wheel
CONTROLS ON STEERING WHEEL DESCRIPTION The controls for the main system functions are present on the steering wheel to make control easier. The activation of the function selected is controlled, in some cases, by how long the button is pressed (short or long press) as described in the table below.
Page 208 Button Action Function In Radio mode: selects the previous radio station. SHORT PRESS In Media mode: selects the previous track. In Radio mode: scan lower frequencies until released. LONG PRESS In Media mode: fast rewind track. Voice command button (3) Action Function SHORT PRESS...
Page 209: Introduction
INTRODUCTION RADIO MODE Audio The following settings are available in the The system can be managed using the After the desired radio station is “Audio” menu present in the Options Rotary Pad. Turn it to navigate the menus, selected, the following information is menu (Option button): press it to activate/confirm the shown on the display fig.
Page 210: Media Mode
MEDIA MODE Bluetooth® SOURCE USB/iPod/AUX SUPPORT Pairing a Bluetooth® audio device There might be up to three USB portals, IMPORTANT Applications used on one under the air conditioner control portable devices may be not compatible Proceed as follows: panel, one in the glove compartment in with the Connect system.
Page 211: Phone Mode
PHONE MODE IMPORTANT The mobile phone audio is the “Bluetooth®” can be reached also transmitted through the vehicle’s audio by pressing the OPTION button in the PHONE mode can be activated from the system; the system automatically mutes PHONE or MEDIA functions. The latter main menu (MENU button) by turning and the system audio when the PHONE can be selected by turning and pressing...
Page 212: Navigation Mode
NAVIGATION MODE SETTINGS You can now either complete the word or go to the list of suggestions by moving (where provided) To access the user-programmable the Rotary Pad rightwards or by pointing functions, open the main menu by IMPORTANT In the interest of safety and to “OK”...
Page 213 The following settings can be modified Safety Lane Departure Warning when this mode is selected: To access the “Safety” function, select it This function can be used to select the Twilight Sensor; by turning the Rotary Pad and press the "readiness"...
Page 214 Driver assistance "Switching off delay": allows you to Doors & Locks delay the switching off of the camera by a To access the “Driver assistance” To access the “Doors & Locks” function, few seconds when reverse gear is function, select it by turning the Rotary select it by turning the Rotary Pad and disengaged.
Page 215: Applications
APPLICATIONS VOICE COMMANDS The following settings can be modified when this mode is selected: APPLICATIONS mode can be activated IMPORTANT For languages not Screen Off; from the main menu (MENU button) by supported by the system, voice Splitscreen (where provided); turning and pressing the Rotary Pad.
Page 216 Display Genre Navigation functions Play Genre (where provided) Display Playlist button lets you activate the Play Playlist following functions: Play song Navigate to <address> Play All Favourites Display all the albums Set 2D map Display all the artists Set detailed 3D map Display all the composers Set overhead view Display all the genres...
Page 217 IMPORTANT INFORMATION AND RECOMMENDATIONS WARNING INTERIOR FITTINGS Do not travel with the storage compartment open: it may injure the front seat occupants in the event of an accident. The cigar lighter gets extremely hot. Handle it carefully and make sure that children don’t use it: risk of fire and/or burns. Do not use the ashtray as a waste paper basket: it may catch fire in contact with cigarette stubs.
Page 218 It’s in the heart of your engine. Ask your mechanic for...
Page 219 Your car has chosen PETRONAS Selenia The engine of your car was made with PETRONAS Selenia, the range of engine oils that satisfies the most advanced international specifications. Subject to specific tests and boasting outstanding technical characteristics, PETRONAS Selenia is a lubricant designed to equip your engine with reliable, winning performance standards”...
Page 220 NOTE...
Page 223 INDEX Climate control system ..31 engine coolant level ..168 CO2 emissions ....196 Engine compartment .
Page 224 Headlight alignment adjustment ..28 Park Sensors system ..126 Scheduled servicing ...156 Headlight alignment corrector..28 Parking lights .
Page 225 Towing the vehicle ... .152 ehicle changes/alterations ..5 Wheels and tyres ... . .173 Towing trailers .
Page 226 FCA Italy S.p.A. - MOPAR - Technical Services - Service Engineering Largo Senatore G. Agnelli, 3 - 10040 Volvera - Turin (Italy) Print no. 603.93.005 - 01/2017 - Edition...
Page 227 The Alfa Romeo Genuine Spare Parts and Accessories follow the rigid component engineering and manufacturing speciﬁ cations used in the assembly line to meet the technical speciﬁ cations of your new Alfa Romeo and to enhance its style and performance. They undergo strict approval tests and quality controls to ensure they comply with safety and environmental standards.
Page 228 ENGLISH...

Alfa Romeo Giulia Owner's Handbook Manual

Knowing Your Car

Safety

Starting and Driving

In an Emergency

Servicing and Care

Technical Data

Multimedia

Quick Links

Chapters

Related Manuals for Alfa Romeo Giulia

Summary of Contents for Alfa Romeo Giulia

Table of Contents
