Cyclades AlterPath KVM Quick Installation Manual page 3

1. Mount the KVM/netPlus
Obtain a Phillips screwdriver and appropriate nuts and
bolts before starting the following procedure.
1. Decide whether you need to mount the KVM by the
front or back and locate the appropriate sets of holes
on the KVM.
KVMKVM
2. Use a Phillips screwdriver to tighten the screws.
Use the mounting hardware recommended for your
3.
rack to mount the KVM on a rack.
2. Make an Ethernet Connection
Use an Ethernet cable to connect the Ethernet port on
the KVM to your local area network (LAN).
3. Connect Cascaded KVM Units
to the Primary KVM [Optional]
KVM supports the cascading of four types of secondary
KVM devices: the KVM Analog , the KVM/net, the
KVM/netPlus, and the KVM Expander.
1. Power off all KVM hardware and connected devices.
Use a CAT-5 cable to connect from a KVM port on
2.
the primary KVM unit to the User 2 port on the
secondary KVM box.
Warning: In a single user configuration, ensure that the
master KVM is connected to the User 2 port on
a cascaded KVM unit.
To connect the primary KVM unit to the User 1 port
3.
of a secondary KVM box:
a. Use a CAT-5 cable to connect a KVM port on the
primary KVM to a KVM Terminator.
b. Connect the Terminator's VGA and PS/2 or USB
connectors to the User 1 port on the secondary
KVM.
4. Repeat steps 1 through 3 for each secondary KVM
connection to the primary KVM.
Note: To support two concurrent users accessing the
4. Connect Computers to KVM
Bracket
Note: If you are using a PS/2 Terminator make
5. Connect AlterPath PMs to the
AlterPath KVM Quick Installation Guide
To Connect a KVM Expander to the Primary KVM,
5.
use a CAT-5 cable to connect the KVM port on the
primary KVM to the User A or the User B port on the
secondary KVM Expander.
cascaded KVM units, ensure that both of the user
ports (User 1 and User 2 or User A and User B) are
connected to the master unit.
See Chapter 3, "Advanced Installation Procedures" in
the AlterPath KVM Installation, Administration, and
User's Guide.
Ports
The KVM components are hot-pluggable, but
components of connected devices, such as the PS/2
keyboard and mouse ports on a computer, may not be
hot-pluggable. Turn off power to all devices before
connecting them. Power on connected devices again
only after the KVM is powered on.
Connect the appropriate Terminator for the server to
1.
be connected.
connections in this order: mouse, keyboard, video.
If you are using a USB Terminator connect the
USB first and then video.
2. To extend the connection from the computer to the
KVM, use an RJ-45 to RJ-45 CAT5 cable up to 500
feet long to connect the Terminator to a KVM port on
the KVM.
3. Repeat the steps for all computers to be connected to
the KVM ports.
If this is a first-time installation, go to "Access the
4.
KVM to Perform Basic Network Configuration" on
page 4.
KVM [Optional]
By daisy-chaining any combination of PM models to
the AUX port on the KVM, you can control up to 128
outlets from one KVM.
1. Use a CAT-5 cable to connect the AUX port on the
KVM to the IN port of your AlterPath PM.
2. To connect multiple PMs to the KVM:
a. Use a CAT-5 cable to connect the OUT port of a
PM that is already connected to the AUX port of a
KVM to the IN port of the next AlterPath PM.
Page 3
