Elite Pro AV WhiteBoardScreen User Manual

Dry-erase whiteboard projector screen

Advertisement

Dry-Erase Whiteboard Projector Screen
WhiteBoardScreen
TE
User's Guide
Thank you for choosing the WhiteBoardScreen TE (Thin Edge) Series dry-erase whiteboard projection screen!
Please read through this user guide before utilizing the screen. Correct usage and maintenance will ensure a
long product life.
Precautionary Notes:
Before using the dry-erase function of your whiteboard screen, please make note of the following instructions
to properly maintain and clean your dry-erase surface projection screen. These Whiteboard cleaning tips are
just as relevant with any dry-erase writing surface as they are with our Whiteboard- Projection Screens.
For a video demonstration, please visit:
http://www.elitescreens.com/whiteboardscreen-cleaning
1. Only use a high-density foam eraser when removing dry-erase markings from the WhiteBoardScreen.
2. Do not use abrasive erasers as these may scratch the surface of the screen and will not erase dry-erase pen
markings on the whiteboard screen surface.
3. Never spray the whiteboard cleaning solution onto the surface while marker writing is present and then
attempt to use a high density foam eraser to remove. This will only smear the dry-erase marker ink making the
surface more difficult to clean and will likely ruin the foam eraser.
4. If there are any dry-erase markings left behind even after attempting to remove them using our high density
erasers, spray our whiteboard cleaning solution directly onto the screen surface and use only a soft microfiber
cloth to wipe-down and clean the area.
072017 BR
www.eliteproav.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WhiteBoardScreen and is the answer not in the manual?

Questions and answers

Summary of Contents for Elite Pro AV WhiteBoardScreen

  • Page 1 WhiteBoardScreen ™ User’s Guide Thank you for choosing the WhiteBoardScreen TE (Thin Edge) Series dry-erase whiteboard projection screen! Please read through this user guide before utilizing the screen. Correct usage and maintenance will ensure a long product life. Precautionary Notes: Before using the dry-erase function of your whiteboard screen, please make note of the following instructions to properly maintain and clean your dry-erase surface projection screen.
  • Page 2 Installation Step1: Mark the location the WhiteBoardScreen will be installed and drill your holes for all of the Top Hanging Brackets (c). Once the holes have been drilled, insert and screw the wall screws (a) as shown below. It is strongly recommended to install the WhiteBoardScreen on wood studs for added stability. If the location does not have wood studs, then use the included hollow wall anchors (b).
  • Page 3 Pen Tray Installation Step 4: Line up the Tray Hanging Brackets (j) with the bottom screw holes of the bottom hanging brackets (b). Then, mark and drill the holes and install brackets to the wall. Minimum clearance requirement for pen tray installation diagram Leave a minimum (of .46”/11.75 mm) between the top of the pen tray bracket and the bottom of the whiteboard edge to allow the pen tray enough room to attach to the bracket.
  • Page 4 Step 6: Use the M4 screws (i) to lock and secure the pen tray to the brackets. Dimensions Table Diag. Aspect View Overall Viewable Tray Overall Viewable Model Size Ratio Area (HxW) Width (A) Width (A1) (A2) Height (B) Height (B1) Unit: Inches WB60VW1 60”...
