- Page 1 EQUITEL Network Audio Audio over IP devices Audio over IP decoders / mixers E411, E413, E415 & E417 Technical Manual Ed 2.1...
- Page 2 This document is the technical reference for the decoders of the ENA Audio over IP family of devices. Includes the E411, E413, E415 and E417 equipment. It is valid for versions: Hardware: EAIP1V133 Firmware: 3.06 © Equipos De Telecomunicación Optoelectrónicos, S.A.
-
Page 3: Table Of Contents
‘Microphone’ Source type configuration ................... 29 ‘Line’ Source type configuration ....................31 4.2.4. Network ............................33 Static mode ..........................33 Dynamic mode ........................... 34 4.2.5. Firmware updates and device reset ..................... 35 Audio over IP decoders E411, E413, E415 & E417 technical manual... - Page 4 7.1 Dimensions ............................42 7.2 Electrical Specifications ........................43 7.2.1. Power ............................43 7.2.2. Ethernet ............................43 7.2.3. Audio ............................. 44 7.2.4. Contacts ............................44 7.3 Environmental conditions ........................44 Audio over IP decoders E411, E413, E415 & E417 technical manual...
-
Page 5: Chapter 1: Introduction
The E430 is a music and announcements server that can generate audio from internally stored files. It can be used to generate background music channels and/or advertisements. Decoders (E411, E413 or E415) can receive selected channels (i.e. "streams") from the network and convert it back to an analog audio signal. - Page 6 To be used with an external amplifier. E413 - Decoder with digital I/O Same features as E411 including two digital inputs and outputs for external devices control. Digital outputs can be used to switch ON/OFF the external amplifier.
-
Page 7: Chapter 2: Functionality
SHOUTcast and ICEcast are both standards used to transmit music through Internet. There are many public radios in Internet using these protocols, and is quite easy to create a proprietary radio using one ICEcast server provided by an ISE (Internet Services Provider). Page 3 Audio over IP decoders E411, E413, E415 & E417 technical manual... - Page 8 The E417 has two analog inputs (microphone and line-in) than can be sent directly to the output. Each input can be assigned only to one of the possible audio sources. See next point for more information. Page 4 Audio over IP decoders E411, E413, E415 & E417 technical manual...
-
Page 9: Audio Layers
Analog inputs (E417) The interface for the TMH60ENA wall-mount controller is available in all the models as an option. You must add “-R” to the ordering code. Page 5 Audio over IP decoders E411, E413, E415 & E417 technical manual... -
Page 10: Audio Switching
Further this, both inputs and outputs can be managed through the control protocol of the devices from external applications, for instance to read sensors, activate doors, etc. Page 6 Audio over IP decoders E411, E413, E415 & E417 technical manual... -
Page 11: Chapter 3: Hardware Description
Amplified audio output terminals E415, E147 IP recovery and reset default button All models Power supply connector All models Remote wall-mount control connector All models with “-R” option Page 7 Audio over IP decoders E411, E413, E415 & E417 technical manual... -
Page 12: Power Supply
ERROR (Red): Indicates some kind of error. It can be a network error, a malformed audio source or a serious system failure. All the devices can be ordered with the “-P” option for PoE powering. Page 8 Audio over IP decoders E411, E413, E415 & E417 technical manual... -
Page 13: Ip Address Indication And Default Configuration Recovery
3.6.1. Inputs Inputs are designed to be connected to a switch or dry contact and are optically isolated, as seen in the schema: Figure 4: Digital inputs Page 9 Audio over IP decoders E411, E413, E415 & E417 technical manual... -
Page 14: Outputs
The stereo audio line out, also present in all decoders, is accessible via two RCA connectors ( ), with a level of 1.8Vpp on 10kΩ. The white connector corresponds to the left channel and the red one to the right channel. Page 10 Audio over IP decoders E411, E413, E415 & E417 technical manual... -
Page 15: Amplified Audio Output
The adjustment must be done experimentally, configuring the device to play a channel at maximum level and adjusting the potentiometers to obtain a good sound without distortion in the speakers. Page 11 Audio over IP decoders E411, E413, E415 & E417 technical manual... -
Page 16: Audio Inputs
The device is accessible through the network using the FTP protocol to change its content remotely Contact us at support@equitel.es if you are interested in the access method. Page 12 Audio over IP decoders E411, E413, E415 & E417 technical manual... -
Page 17: Wall-Mount Remote Control Connector
Wire Data 5V output Ground Figure 9: Adapter for wall-mount remote control connector These 3 wires must be connected to the TMH60ENA wall mount controller corresponding terminals. Page 13 Audio over IP decoders E411, E413, E415 & E417 technical manual... -
Page 18: Chapter 4: Configuration And Control Of The Device
User: admin Password admin In PoE models, you can connect the device directly to a PoE switch. You can download the applications from our website: www.ena.equitel.es Page 14 Audio over IP decoders E411, E413, E415 & E417 technical manual... - Page 19 Control Mode: When the device is properly configured, this page shows its status and allows its control (i.e. background music channel selection and volume control). See section 4.3 . Configuration Mode: To configure the device parameters. See section 4.2. Page 15 Audio over IP decoders E411, E413, E415 & E417 technical manual...
-
Page 20: Configuration
Navigating through the configuration pages doesn’t lose the temporary changes. So, you can save the changes only after all the configuration is done. Next sections show the configuration pages. Page 16 Audio over IP decoders E411, E413, E415 & E417 technical manual... -
Page 21: General Information
It sets the additional gain for the two audio inputs: line-level input and microphone. For each of the entries there is a slider to choose the gain factor from 1 to 64. Page 17 Audio over IP decoders E411, E413, E415 & E417 technical manual... -
Page 22: Audio Channels
This button will open a window with the possible configuration parameters. Some of them are present in all sources and others depend on the type of source assigned: Page 18 Audio over IP decoders E411, E413, E415 & E417 technical manual... - Page 23 USB files - Scheduled playlist (E417) USB files - Continuous playlist (E417) Microphone (E417) Line In (E417) Page 19 Audio over IP decoders E411, E413, E415 & E417 technical manual...
- Page 24 Please note that in the E417, if you use the input contacts to control the volume, they can’t be used to trigger the analog inputs for the advertisements or emergency channels. Page 20 Audio over IP decoders E411, E413, E415 & E417 technical manual...
-
Page 25: Rtp' Source Type Configuration
Default value is 8. Reception can be configured in two modes: Unicast: The device will accept the RTP packets sent to its IP address and the configured port. Page 21 Audio over IP decoders E411, E413, E415 & E417 technical manual... -
Page 26: Sip Pbx' Source Type Configuration
Password: Security password configured in the PBX for the assigned extension. Local RTP port: Port for the audio RTP. Must be an even number between 0 and 65534, and not used for other channels in the device. Page 22 Audio over IP decoders E411, E413, E415 & E417 technical manual... -
Page 27: P2P Sip' Source Type Configuration
Buffer size: number of packets in the input buffer. The greater the value, the more network jitter the decoder is able to absorb, but the greater the delay in relation to the emitter. Default value is 8. Page 23 Audio over IP decoders E411, E413, E415 & E417 technical manual... -
Page 28: Shoutcast / Icecast' Source Type Configuration
“Copy link address”, and then paste the obtained URL in the decoder configuration page, as shown in the following images: Page 24 Audio over IP decoders E411, E413, E415 & E417 technical manual... - Page 29 Figure 20: How to get an ICEcast URL from www.icecast.org streaming directory 3- Paste link using Ctrl+V (on Windows systems) Figure 21: Paste obtained URL into the source setup form Page 25 Audio over IP decoders E411, E413, E415 & E417 technical manual...
- Page 30 In case of the ENALite application, it must be the name or IP address of the computer where the application is running. [Stream name]: Represents the name given to the stream in the E430 or application. Example: http://192.168.1.185:8000/Music1.mp3 Page 26 Audio over IP decoders E411, E413, E415 & E417 technical manual...
-
Page 31: Scheduled Playlist' Source Type Configuration
IMPORTANT NOTE: Each time the device is restarted, the playing starts from the first file in the folder. In future firmware releases it is planned to add more modes as “Daily Scheduled” and “Weekly scheduled”. Page 27 Audio over IP decoders E411, E413, E415 & E417 technical manual... -
Page 32: Continuous Playlist' Source Type Configuration
Random: Files are played in random order. IMPORTANT NOTE: In ‘normal’ mode, each time the device is restarted, the playing starts from the first file in the folder. Page 28 Audio over IP decoders E411, E413, E415 & E417 technical manual... -
Page 33: Microphone' Source Type Configuration
If the microphone input is used for a Background Music layer channel, the activation/deactivation is made manually through the control mode of the web server or the TMH60ENA wall-mount controller. So, there is no option to choose the activation contact: Page 29 Audio over IP decoders E411, E413, E415 & E417 technical manual... - Page 34 June 2015 - Ed.2.1 Figure 25: Microphone Source setup in BGM layer Page 30 Audio over IP decoders E411, E413, E415 & E417 technical manual...
-
Page 35: Line' Source Type Configuration
If the line input is used for a Background Music layer channel, the activation/deactivation is made manually through the control mode of the web server or the TMH60ENA wall-mount controller. So, there is no option to choose the activation contact: Page 31 Audio over IP decoders E411, E413, E415 & E417 technical manual... - Page 36 June 2015 - Ed.2.1 Figure 27: Line Source setup in BGM layer Page 32 Audio over IP decoders E411, E413, E415 & E417 technical manual...
-
Page 37: Network
“Validate” button: Page 33 Audio over IP decoders E411, E413, E415 & E417 technical manual... -
Page 38: Dynamic Mode
If it can’t obtain the parameters in 3 minutes, it will switch automatically to the static IP mode, with these parameters: 192.168.1.1 Subnet Mask: 255.255.255.0 Gateway: 192.168.1.254 To know the IP address of the device, you can use any of the methods described in section 4.1 Page 34 Audio over IP decoders E411, E413, E415 & E417 technical manual... -
Page 39: Firmware Updates And Device Reset
Pressing the button, the device configuration is reset to its default values, except the network settings. Firmware upgrade At EQUITEL we are continuously working in the improvement of our products. As a result of this process, new firmware versions are published. -
Page 40: Control
To change the active BGM channel, simply press its play button. If an AD or EM channel is activated, it will be highlighted and its volume can be adjusted. Page 36 Audio over IP decoders E411, E413, E415 & E417 technical manual... -
Page 41: Chapter 5: Tmh60Ena Wall-Mount Controller
Description The TMH60ENA controller allows the control of the background music playing of the ENA decoders E411,E413, E415 and E417 with the “-R” option enabled. When a higher priority sound source is played (emergency or advertisements), it is shown in the display but the volume control is disabled. -
Page 42: Connection
This is the screen shown when no BGM sources are configured. In this case, the controller only can show the information of the advertisement or emergency channels when it is played (see point 5.3.5). Page 38 Audio over IP decoders E411, E413, E415 & E417 technical manual... -
Page 43: Default /Control Screen
The volume control of these channels is disabled. No action can be done in the controller while these channels are active. Page 39 Audio over IP decoders E411, E413, E415 & E417 technical manual... -
Page 44: System Info And Configuration
If for any reason the data communication between the controller and the E41x decoder fails, the TMH60ENA will show this screen. In this case, please, revise the data wire. If this doesn't solve the problem, contact us at support@equitel.es and send the error number that appears in the screen. Page 40... -
Page 45: Chapter 6: Software
For those projects where an application with specific characteristics is needed, EQUITEL can offer to create the application or, to give the information and support needed to create it. In this information, the source code of the above mentioned applications is included. -
Page 46: Chapter 7: Technical Data
There are four M3 threaded holes in the bottom that can be used to screw the optionally supplied DIN rail adaptor, either in horizontal or vertical position: Page 42 Audio over IP decoders E411, E413, E415 & E417 technical manual... -
Page 47: Electrical Specifications
PoE power options according to IEEE 802.3af PoE+ Power options according to the IEEE 802.3at 7.2.2. Ethernet Network Interface: 10/100 Base T/TX with auto-negotiation and auto MDX Page 43 Audio over IP decoders E411, E413, E415 & E417 technical manual... -
Page 48: Audio
Inputs: Opto-isolated, polarized at 5V, with surge protections Ouputs: Relays with 3 contacts (NO / NC) Environmental conditions Extended temperature range: -40 C to 74 Humidity: 0% to 95% (non-condensing) Page 44 Audio over IP decoders E411, E413, E415 & E417 technical manual... - Page 49 EQUITEL Network Audio EQUIPOS DE TELECOMUNICACIÓN OPTOELECTRÓNICOS, S.A. Polígono de Malpica, calle F Oeste, (G. Quejido) N. 74 50057 ZARAGOZA (SPAIN) Tel. +34 976 570 353 - Fax. +34 976 571 383 www.ena.equitel.es www.equitel.es...
