- Page 1 BEST Battery Testing Equipment. The BEST Customer Support. PERIOD. SG-1000 Specific Gravity Tester User Manual Copyright © 2012 Eagle Eye Power Solutions, LLC www.eepowersolutions.com V1.0...
-
Page 3: Caution
Eagle Eye SG-1000C User Manual Trouble? If abnormal measurements are experienced, It may be due to low battery power. Replace with new alkaline battery. CAUTION Care should be taken to avoid damage to the prism. Use soft tissue paper when wiping the prism surface to avoid scratching. -
Page 4: Table Of Contents
Eagle Eye SG-1000C User Manual Table of Contents CAUTION ......................2 1. Names and Functions of Parts ..............4 2. Inserting the Nozzle ................. 6 3. Inserting the Battery ................7 4. Attaching the Wrist Strap ................ 8 5. Zero Setting ....................9 6. -
Page 5: Names And Functions Of Parts
Eagle Eye SG-1000C User Manual 1. Names and Functions of Parts... - Page 6 Eagle Eye SG-1000C User Manual 1. Display The LCD provides a digital readout of the measured values. 2. SELECT key Used to select a measurement item. The item to be displayed switches between TEMPERATURE and MEASURE each time this key is pressed.
-
Page 7: Inserting The Nozzle
Eagle Eye SG-1000C User Manual 2. Inserting the Nozzle The Nozzle is packed separately from the Main unit. Insert the Nozzle to Main Unit following the procedure described below. (1) Push the Nozzle into the hole located (2) Then, fit the nozzle into the slit by at the bottom of the Sample Chamber pushing with the thumb. -
Page 8: Inserting The Battery
(3) Close the Battery Cover and using a Screwdriver, turn the locking pin to the “CLOSE” position. Note: The SG-1000 does not have a power switch. Once the battery is inserted the electric circuit of the unit is on. Remove the battery from the unit for long periods of non-use and storage. -
Page 9: Attaching The Wrist Strap
Eagle Eye SG-1000C User Manual 4. Attaching the Wrist Strap Attach the wrist strap to the hook located on the lower side of the Main Unit. When measuring samples, loop the strap around your wrist to avoid any accidents. -
Page 10: Zero Setting
Eagle Eye SG-1000C User Manual 5. Zero Setting (2) Dip the tip of the Nozzle in water, (1) Remove the Nozzle Cap and squeeze and release the Tube pump. The water will be drawn into the Sample Chamber. (3) Confirm that the Sample Chamber has been filled with water. - Page 11 Eagle Eye SG-1000C User Manual (4) Press the ZERO key. “000” will blink (5) Zero-Setting is now complete. three times and “000” will be displayed. Remove the Nozzle from the water and squeeze the Tube Pump to drain the water from the Sample Chamber.
-
Page 12: Measurement Of Sample
Eagle Eye SG-1000C User Manual 6. Measurement of Sample (1) Press the SELECT key to move the triangle mark to the desired measurement item on the display. (2) Dip the tip of the Nozzle into the electrolyte sample and squeeze and... - Page 13 Eagle Eye SG-1000C User Manual (4) The displayed value will remain on the LCD for 5 minutes. (5) To reset the display, press and hold down the START switch for 2 seconds. (6) Before storing the SG1000F, squeeze and release the Tube Pump several times to drain the sample from the Chamber.
-
Page 14: Explanation Of Error Messages
Eagle Eye SG-1000C User Manual 7. Explanation of Error Messages The SG-1000 will indicate an error message when there is a problem with the operation on the instrument. Error messages that may be displayed are explained below. “AAA” Zero-setting error “HHH”... -
Page 15: Maintenance
(4) The body casing of the unit is made of plastic. Do not use, or make contact with any organic solvents on the unit. If the SG-1000 is dropped, check for any of the below symptoms. - Page 16 Any cracks in the casing cannot be repaired. Return the unit to the manufacturer. The SG-1000 is a precision optical instrument and should be handled with care. Do not drop or subject to any heavy impact or shock. Refer to the images on the next page.
- Page 17 Eagle Eye SG-1000C User Manual...
-
Page 18: Trouble
Eagle Eye SG-1000C User Manual 10. Trouble? If any problem in operation is suspected, check the following reference list for repair before contacting the manufacturer. Symptom What to Check 1.”HHH” is displayed at Does the battery need replacement? zero-setting. -
Page 19: Battery Low
Eagle Eye SG-1000C User Manual *Is the power level of the battery low? The unit does not measure if the battery is low. The battery level can be checked by using a multimeter. If the mattery is low, replace it with a new battery. (Refer to page 8 on how to replace the battery and other remarks.) - Page 20 Eagle Eye SG-1000C User Manual *Is the Tube Pump damaged? If stained or blurred, using a soft tissue, wipe with water or ethyl or isopropyl *Is the Nozzle damaged? alcohol. *Is the cover of the Sample Chamber damaged? *Is the Nozzle loose at the...
-
Page 21: Specifications
Eagle Eye SG-1000C User Manual *Is there a difference between the room temperature and sample temperature? The unit automatically compensates for temperature by detecting the temperature of the sample in the Sample Chamber. If the temperature of the sample is different from that of the...
