Chapter 1 - Introduction and System Requirements
IMPORTANT:
I
Read this chapter before you bep;in using the system.
WARNING!
I
Federal law restricts this device to use by oron the order of a physician.
REVIEWING SYSTEM REQUIREMENTS
Reviewing
Environmental
Requirements
The Aspen system is a stable, rugged device. However, it should
receive the care given to any precision instrument. Make sure that
the system's environment is free of fumes, dirt, and electrical
interference, e.g., brush-type motors and large fields of RF energy.
The systern is designed to operate within the following
environmental limits:
Acuson Aspen System
Temperature
Relative Humidity
Heat dissipation
Side Clearance
Rear Clearance
Environmental
Limits
15° to 33°C, 59° to 90°F
up to 90% non-eondensing
5000 Btu per hour
15.0 em (6.0 inches)
30.0 em (12 inches)
and has the following physical characteristics:
Acuson Aspen System
Height
Depth
Width
Weight
Ground Clearance
Physical ChaT8cterstics
135.64 em (53.4 in.)
116.80 em (46 in.)
62.90 em (24.8 in.)
217 kg (477 lbs.)
6.35 em (2.5 inches)
1-4 Acuson Aspen Ultrasound System 1096
