Table of Contents 1. Please read the cautions carefully before using this product. 1, 2 2. Product feature 3. Product installation 5, 6 4. Names and operation of control buttons 5. OSD MENU Selection and operation 6. MENU function 8, 9 7. -
Page 3: Please Read The Cautions Carefully Before Using This Product
Please read the cautions carefully before using this product Do not scratch the screen of the The interior part of the monitor is Take care of the LCD monitor LCD monitor with sharp materials composed of electric elements. If so that it is not damaged by the such as nails and pens. -
Page 4: Product Feature
Product features Introduction Thank you for purchasing our monitor. Our monitor is a high-resolution monitor that has features of electromagnetic wave blocking, reduction in electricity consumption and efficient use of space. This manual has been prepared to help you using this product adequately. It is recommendable to read this manual before using this product. -
Page 5: Product Installation
Product installation Checking the product Please check if the product contains the following items. If there are items missing, please contact our technical services. 1. TFT LCD monitor 2. User's manual (including product warranty card) 3. AC to DC adaptor 4. - Page 6 Names and operation of control butto MENU MENU SE L ECT SE L ECT MODE MODE POWER POWER Function of the buttons 'MENU' Show the menu screen or makes it disappear, Moreover 'SELECT' Select category within the menu window or excutes automatic screen adjustment. - ' ' / ' ' Moves to the desired category within the menu window or adjusts the value of selected category and adjust sound volume.
-
Page 7: Names And Operation Of Control Buttons
Names and operation of control buttons Auto Brightness Control The product offers built-in function that automatically adjusts to optimized brightness depending on the brightness of the area at the vicinity. (At the time of purchase, this is set as On.) * Refer to the screen category of the MENU function for detailed method of use. -
Page 8: Osd Menu Selection And Operation
OSD MENU Selection and operation You can select the OSD menu in the OSD window using all the control buttons at the bottom of the screen. To change the current settings or adjust them for the desired settings, follow the following steps. MENU SELECT (Open menu... -
Page 9: Menu Function
MENU Function Screen Automatic brightness: Turns automatic brightness function On/Off Brightness adjustment: Adjusts standard value for automatic brightness function (0-100) Horizontal location: Adjusts horizontal location on screen .(0-100) Vertical location: Adjusts vertical location on screen \.(0-100) Modulation: Adjusts focus on the screen.(0-100) Frequency: Adjusts pixel’s horizontal size.(0-100) Automatic screen adjustment: Automatically adjusts screen’s location, modulation and frequency. -
Page 10: Menu Function
MENU Function OSD Horizontal Adjustment: Adjusts OSD menu screen’s horizontal location.(0-100) OSD Vertical Adjustment: Adjusts OSD menu screen’s vertical location. (0-100) OSD Marking Time: Adjusts OSD menu screen’s marking time within the screen Possible to set the time for disappearance of OSD menu screen up to 40 seconds when OSD operation button is not pushed on. -
Page 11: Utilization Message
Explanation of message for utilization Auto Adjustment Appears when automatic screen adjustment is executed on RGB mode. Auto color Adjustment Appears when automatic color Adjustment is executed on RGB mode. Auto Brightness Appears when automatic brightness function is executed. No Signal (RGB, DVI, COMPONENT) Appears when there is no PC input signal Check cable connection . -
Page 12: Timing Guide
Timing guide Timing guide This product is a multi-frequency monitor. It functions in horizental frequencies from 30kHz to 80kHz and vertical frequencies from 56Hz to 75Hz. Due to tis design based on microprocessor, It offers the functions of automatic synchronization and automatic size. This monitor is equipped with 12 programmed configurations that are shown in the timing table. -
Page 13: Input Signal Detail
Input signal detail This signal input terminals are for 15Pin D-SUB, DVI-D, Component. Please, connect the cables of each signal to your PC's input signal port. 15Pin D-SUB DVI-D Component Please, turn off the monitor, before connecting the signal out of the system. -
Page 14: Product Specification
Product specifications Product specifications 22" diagonal viewable screen TFT(Thin Film Transistor) Active matrix panel Pixel Pitch R, G, B vertical stripe Display Color 16,777,216 colors Anti glare coating Surface Condition H / V Viewing Angle 1000 : 1 Contrast ratio Brightness 300cd/m Reponse Time... -
Page 15: Troubleshooting
Troubleshooting No power. - Flip the power switch ON. The Power LED turns on. - Make sure AC power cord is securely connected to the power jack and to a power outlet. Power on but no screen image. - Make sure the video cable attached with this monitor is tightly secured to the video output port on the back of the computer - Adjust the brightness and contrast. -
Page 16: Troubleshooting
Troubleshooting Control buttons do not work. - Press only one button at a time. ABOUT THE LCD The LCD contains over 3,932,160 thin-film transistors (TFTs). A small number of missing, discolored, or lighted dots on the screen is an intrinsic characteristic of TFT LCD technology and is not an LCD defect. - Page 17 FCC NOTE :This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
