LWMT80TS
FULLY AUTOMATIC WASHING MACHINE
Operation Manual
It is most important that this instruction book should be retained with the
appliance for future reference. Should the appliance be sold or transferred
to another owner, or should you move house and leave the appliance, always
ensure the book is supplied with the appliance in order that the new owner
can get to know the functioning of the appliance and the relevant warnings.
These warnings have been provided in the interest of safety. You MUST read
them carefully before installing or using the appliance.
Advertisement
Table of Contents
Related Manuals for Lloyd LWMT80TS
Summary of Contents for Lloyd LWMT80TS
- Page 1 LWMT80TS FULLY AUTOMATIC WASHING MACHINE Operation Manual It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure the book is supplied with the appliance in order that the new owner can get to know the functioning of the appliance and the relevant warnings.
-
Page 3: Table Of Contents
Contents Before using Parts name........1 Cautions..........2 Installation and adjustment....4 How to use drainpipe......5 Water inlet installation......6 Operation Preparation before operation ....8 Load Laundries......... 9 Use of detergent......... 9 Program operation......10 control panel instructions....10 operation steps...... - Page 4 Specification Model LWMT80TS Rated voltage and frequency 220V-240V~ 50Hz 10/70L 9/66L 8/62L 7/58L Water level/water volume about 6/54L 5/50L 4/46L 3/42L 2/38L 1/34L Inlet pressure 0.03MPa~0.85MPa Rated input power Wash 440W Spin:325W Weight About 37kg Dimensions Width580mm depth587mm height966mm...
-
Page 5: Before Using
Other functions Parts name Before using 1. Give an alarm Top lid Display Explanation Settlement Feed valve Top frame The top lid is opened Close the top lid and clear up the alarm when preset is started Detergent box Open top lid, according to before After draining 5 minutes, troubleshooting and settlement to Lint filter... - Page 6 Before using Cautions Before using Settlement Please insert the plug into the power socket with rated voltage Always unplug the appliance and turn off the water when 240V A/C. the power is cut, moving or cleaning the washing machine, or it is not in use. Do not insert or pull off the plug with wet hand. Settlement Insert the plug tightly Check the socket or change to another socket...
-
Page 7: Cautions
Troubleshooting Cautions Before using Before contacting the technicians, please make the following checks: Do not put hands into the working machine. It is dangerous to alter the specifications or It is dangerous even if the speed is very slow. attempt to modify this product in any way. Take special care of the children, and forbid them to climb on the washing machine. -
Page 8: Installation And Adjustment
Installation and adjustment Operation Before using Maintenance Maintenance methods Please install and adjust the machine according to the requirements of the manual. It is very important to your safety and correct operation. External cleaning How to clean the lintfilter Unpacking Clean the exterior cabinet of the appliance with Lint filter must be used when wash Lint filter must be cleaned timely after using... -
Page 9: How To Use Drainpipe
Operation steps How to use drainpipe Operation Before using Operation steps Install drainpipe Set drainpipe clip into the drainpipe to 2-3cm (from the drainpipe end that without pothook 1. Put through the power, press POWER SWITCH button, the machine enters into initial condition to set), then install the drainpipe into the right drianpipe connector and fix the drainpipe a. -
Page 10: Water Inlet Installation
Before using Water inlet installation Operation Before washing, the digital timer Tap selection shows prest time, unit is HOUR. If select AIR DRY, the digital timer displays air dry time, unit is MIN. Not suitable tap Suitable tap After select program, process and water level, press When washing, the digital timer shows the rest time of washing, unit is MIN. -
Page 11: Additional Functions
Control panel instruction Water inlet installation Before using Connect the inlet hose with the washing machine Mode and meaning of the indicator light on: indicate the selected mode flashing: indicate the program is running 1. Do not take off the water absorption cushion. Please Additional functions check if the cushion is dropped or damaged before each usage. -
Page 12: Operation
Preparation before operation Load laundries Operation Operation The capacity of washing and spinning of the machine refer Preparation before washing to the largest weight of the standard laundries under dry condition .Washing quantity shall be lower than the rated 1. Connect the inlet hose and open the tap. capacity.The maximum capacity of this machine is7.5kg.
