TLC DXP-3800EC Manual

8-way mpeg-2 sd encoder
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001
р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704
ОКПО 66035862 | ОКАТО 40284565000 | ОГРН 1107847196060 | т.(812)6499888 | http://www.tlct.ru http://www.rftel.ru
User Manual
DXP- - - - 3800EC
DXP
DXP
DXP
3800EC
3800EC
3800EC
ООО «ТЛК Трейд», Санкт-Петербург
Brighten Your Digital View!
8-Way MPEG-2 SD Encoder
+7 812 64 99 888
mail@tlct.ru

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DXP-3800EC and is the answer not in the manual?

Questions and answers

Related Manuals for TLC DXP-3800EC

Summary of Contents for TLC DXP-3800EC

  • Page 1 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru User Manual Brighten Your Digital View! DXP- - - - 3800EC 3800EC 3800EC 3800EC 8-Way MPEG-2 SD Encoder ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001 р/с...

  • Page 2: Table Of Contents

    ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Notice Contents Before Using the Device 1 Overview 2 Features 3 Technical Specifications 4 Block Diagram 5 Front panel and rear panel instructions 5.1 Front panel 5.2 Rear panel 6 Control with Front Panel 6.1 Overview of the Menu 6.2 Description of menu 6.2.1 Status...
  • Page 3 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Notices COPYRIGHT (Copyright © 2014 Beijing Jaeger Communication Electronic Technology Co., Ltd.) Not to be copied, used or translated in part or whole without Beijing Jaeger prior consent in writing except approval of ownership of copyright and copyright law.
  • Page 4 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru For more detailed information about recycling of this product, please contact your local Civic Office, your household waste disposal service, or the shop where you purchased the product. COPYRIGHTS Television programs, movies, video tapes, discs, and other materials may be copyrighted. Unauthorized recording of copyrighted material may be against the copyright laws in your region.
  • Page 5 Before Using the Device Thank you for purchasing the DXP-3800EC 8-Way MPEG-2 SD Encoder. This User Manual is written for operators/users of the DXP-3800EC to assist in installation and operation. Please read this user manual carefully before installation and use of the device.

  • Page 6: Overview

    8-Way MPEG-2 SD Encoder 1 Overview DXP-3800EC is an integrated 8-way high density MPEG-2 Encoder. Eight ways of Standard Definition (SD) base band real time A/V programs could be encoded simultaneously. These streams encoded could be re-multiplexed with the stream from its ASI input port. The final re-multiplexed Transport Stream (TS) is available at its Gigabit TSoverIP port and ASI output port.

  • Page 7: Technical Specifications

    ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru 1 ASI input (for daisy chain) & Redundant ASI output Full duplex Gigabit TS over IP I/O (under Full duplex operation mode) Up to 9 multicast/unicast output (under Multiple-channel operation mode) SNMP &...

  • Page 8: Block Diagram

    ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Data Transfer type Byte Packet Length 188 or 204 Bytes Signal Level 800±80mV Gigabit TS_over_IP Standard IEEE 802.3, 10/100/1000 Base-T, Full Duplex Maximum Effective Bit 80Mb/s Rate Data Protocol UDP or RTP, SPTS or MPTS Control Protocol ICMP, ARP, IGMPv2 Interfaces on Rear Panel...

  • Page 9: Front Panel And Rear Panel Instructions

    ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru 5 Front panel and rear panel instructions 5.1 Front panel ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001 р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704 ОКПО...

  • Page 10: Rear Panel

    Used to upgrade software version of this device A6 Management Ethernet (10/100 LAN) control port A7 TS/IP TS over IP I/O port 5.2 Rear panel of DXP-3800EC B1 ASI IN ASI input interface B2 ASI OUT 2 ASI output interface (output in mirror)

  • Page 11: Control With Front Panel

    ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru B6 Power Socket AC Power Input 6 Control with Front Panel With the keypad and display panel on the front panel, user can configure the device locally. 6.1 Overview of the Menu Power on the device and wait for initialization complete, the Local IP address will be displayed on the VFD panel.

  • Page 12: Description Of Menu

    ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru (1) Status: show the status of the device (2) Configuration: Configure and monitor parameters of encoding/transcoding (3) System: Configure the local settings of the device 6.2 Description of menu The main menu items can be selected with the keypad. By pressing the [Enter], the user navigates to the sub- menus, which are selected in the same manner.
  • Page 13 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Display IP in packets per UDP frame Display IP in received TS frames Display IP in fixed RTP frames TS/IP Status Display IP link Status: Link Status (Multiple 10M/100M/1000M/Disconnect Output) 6.2.2 Configuration Sub-menu Factory Default...
  • Page 14 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Hue Control: set the hue of the picture, valid range 0~255 Hue Control: 0 Brightness Control: set the brightness of the picture, valid range 0~255 Brightness Control: 135 Contrast Control: set the contrast of the picture, valid range 0~255 Contrast Control: 123 Aspect Ratio:...
  • Page 15 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Video PID: set Video PID, valid range from 32 to Output Video PID: 4001 8190 decimal Audio PID: set audio PID, valid range from 32 to Output AudioPID:4002 8190 decimal PCR PID: set PCR PID, valid range from 32 to 8190 Output PCR PID:8004 decimal...
  • Page 16 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Uni/Multi IP Address: Uni/Multi IP Address: set the uni/multicast IP address for the IP output 1~8 238.069.070.001 Channel 1~8 Uni/Multi UDP Port: set the port number, valid range Uni/Multi UDP Port: from 1~65535 (the streaming 01234...
  • Page 17 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru TS/IP Gigabit Out Switch: Enable/Disable Gigabit Out Switch: ON (Gigabit Mode: Full Protocol: Duplex) UDP: set UDP protocol to IP output Protocol: UDP RTP: set RTP protocol to IP output TS Pkts Per UDP: set the number of TS packets that can be carried by each UDP packet, valid range from TS Pkts Per UDP: 7...
  • Page 18 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru TS Clock Recovery: Auto: it is suggested to set Auto when there is accurate PCR carried by the inputted TS/IP TS Clock Recovery: Auto Fixed Rate: when fixed rate is selected, user has to configure a bit rate to regenerate the TS clock.

  • Page 19: Control With Web Server

    DXP-3800EC has an integrated web server. This web server allows the configuration and status requests with a standard web browser. To operate a DXP-3800EC, first make sure the Ethernet control port is well connected in the network and could be pinged by the host PC, and then enter the IP address of the DXP3800EC into the browser, there will be a pop-up showed asking for login user and password.
  • Page 20 TS/IP Status 7.2 Encoder There are eight encoders integrated on one DXP-3800EC, each encoder can work independently. Click on the to configure the encoder 1, the same for the rests. ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001 р/с...

  • Page 21: Video Setup

    ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Video Setup Mode: PAL/NTSC/SECAM: set the video mode Resolution: set the resolution of the output video D1 / HD1 / SIF / QSIF / Sliced Screen / 2/3D1 / 3/4D1 GOP Structure: set the structure of GOP IBBPBBPBB/IIIIIIIII/IPPPPPPPP/IBIPBPBPB GOP Size: 0-63.

  • Page 22: Aspect Ratio

    ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru latency of encoding. Saturation Control: set the saturation of the picture, valid range 0~255 Hue Control: set the hue of the picture, valid range 0~255 Brightness Control: set the brightness of the picture, valid range 0~255 Contrast Control: set the contrast of the picture, valid range 0~255 Aspect Ratio: 4:3: set video aspect ratio to 4:3...
  • Page 23 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Audio Level: Set the gain of output volume from +6dB to -17dB, or shut off the audio by select Mute. 7.3 TS/IP All models provide two TS/IP operation modes. The first is “Full Duplex”, which allows one MPTS or SPTS inputted to make up a new MPTS with local encoders, then sends the new one over IP &...
  • Page 24 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Gigabit Output Under multiple output operation mode, user can set output uni/multicast IP addresses and port number for each encoder, the built-in remux, and ASI input. Each IP output channel can be switched ON/OFF independently. The source for TS/IP output 1-8 is forced to link to the encoder 1-8 respectively and cannot be changed.
  • Page 25 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Gigabit Input Under Multiple output mode, the Gigabit Input is not available. Local Settings Set the parameters for the TS/IP output port. Gigabit Address: set the IP address of the IP port Gigabit Subnet Mask: set the net mask of the IP port Gigabit MAC Address: display the MAC address of the IP port, cannot be modified by user Gigabit Gateway: set the gateway address under which the IP port is connected...
  • Page 26 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Under full-duplex operation mode, the device supports single uni/multicast reception. Set the uni/multicast target IP address and port number in the page. Uni/Multicast IP Address: set the multicast address for the incoming IP streaming. To receive a unicast streaming, the submenu can be ignored.
  • Page 27 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru IP Out Switch: Enable or Disable the IP output Source: select the source for the IP output in the dropdown list Protocol: select UDP or RTP protocol for the IP output TS Pkts Per UDP: select the number of TS packets that can be carried by each UDP packet Time To Live: set TTL to the output IP packets Type of Service: select the service type for the outputted IP streaming...
  • Page 28 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru ProMPEG FEC Mode: select the mode of ProMPEG FEC from the dropdown list Column FEC UDP Port: set the port number for column FEC Row FEC UDP Port: set the port number for row FEC FEC Alignment: set the alignment for FEC Test Drop Packets: set the test drop packets Local Settings...
  • Page 29 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Gateway MAC Address: set the MAC address of the gateway under which the device is connected, this is necessary when the IP streaming is needed to pass through the gateways 7.4 MUX The device supports remux the 8 SPTS generated locally with the service(s) carried by the transport stream inputted via ASI In or TS/IP In (available only under full duplex mode).
  • Page 30 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru OFF: EIT will not be inserted into the output stream. Remove CA: ON: remove the CA descriptors that are carried within the inputted TS over ASI or IP OFF: keep the CA descriptors 7.5 System The system page gives all information of this device including device name, serial number, software version, and so on.
  • Page 31 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru IP Address: set the device’s IP address Network Mask: set the net mask of the device Gateway: set the gateway address of the device MAC: display the MAC address of the device, cannot be modified by user Version User can check versions of various functional blocks of the device, as it shown in figure below.

  • Page 32: Factory Default

    ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru Factory Default Click the button “Default” to restore the factory default settings to the device. Note: the IP address of the device and the operation mode of the Gigabit board will not be restored. System Reboot User can reboot this device by clicking the button “Reboot”.
  • Page 33 8 Installation It is highly recommended to fix the DXP-3800EC be mounted in EIA standard 19” rack, any other mounting method may lead to damage to the device. Open the box and take out the device with care. Inspect if there is any damage to the appearance of the device.
  • Page 34 ООО «ТЛК Трейд», Санкт-Петербург +7 812 64 99 888 mail@tlct.ru 75Ohm Loader ООО «ТЛК Трейд» | 196158, г.Санкт-Петербург, Пулковское шоссе, д.30, корп.4, оф. 213В (юр.) | ИНН 7810592830 КПП 781001001 р/с 40702810068000007550 | к/с 30101810200000000704 | Филиал ОПЕРУ ОАО Банк ВТБ в Санкт-Петербурге | БИК 044030704 ОКПО...
