Before You Begin Read these instructions before installing or operating this product. Note: This installation should be made by a qualified service person and should conform to local codes. This manual provides installation and operation information. To use this document, you must have the following minimum qualifications: ...
IMPORTANT SAFEGUARDS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions. 8.
Table of Contents Before You Begin Intended use Customer Support WARNINGS AND CAUTIONS: Table of Contents ..........................1 Overview Package Contents ........................4 Part Description ......................... 4 Installation Installing HDD ........................... 8 System boot up.......................... 8 Quick set up ..........................9 2.3.1 Account........................
Page 7
General buttons in Setup menu ....................28 SYSTEM ..........................29 4.2.1 System ........................29 4.2.2 Time/Date ........................31 4.2.3 Account > User ......................34 4.2.5 Configuration (Config) ....................36 CAMERA ..........................38 4.3.1 Basic .......................... 38 4.3.2 Advanced (Video, Stream and VCA) ................41 DEVICE ...........................
Overview Package Contents The device package contents consist of the following: Note Please check all components involved. Table 1-1 Package contents Name Name DC Power supply CD (Manuals and Client software) Quick guide Mouse Part Description Each part is listed in the below: Figure 1-1 Name and Connection of each front section Table 1-2 Name and Function of each front section Name...
Page 10
8ch NVR 16ch NVR Figure 1-2 Name and Connection of rear section of 4ch, 8ch and 16ch NVR Table 1-3 Name and Function of rear section of 4ch, 8ch and 16ch NVR Name Function IP CAM / PoE IP camera input port, IEEE802.3af PoE supported Network connector Network Audio Out...
Installing HDD Note: Hard disk drives are factory fitted. Withdraw the mains plug before installing HDD to reduce the risk of injury or electrical shock, or device malfunction. Attention Make sure to check the compatibility of HDD with the device. 1 Always switch off and unplug the unit.
Quick set up 2.3.1 Account 1. Click the keyboard icon to set ID and Password for users. 2. With keyboard UI, set the ID and Password, and press OK. 3.Press the Save button to save newly set ID and Password. 4.
2.3.2 System 1 Set each item in System setting screen. Language: Select system language. Device Name: Enter the device name. Keyboard ID: The RS485 Address for control via a remote keyboard Selecting the device ID. ensure that the each devise has a unique ID ...
2.3.3 Network 1 Set each item in Network setting screen. WAN Port: Select whether to use static IP or dynamic IP. IP Address, Subnet Mask, Gateway, DNS, and Port: As for dynamic IP, enter information in each space. 2 Press Save button to save set value.
2.3.4 Time/Date 1 Set each item in Time/Date setting screen. Network Time Sync: Select network for synchronizing with time server. System Time: Not for synchronizing with network time server, set the device time; otherwise (applying for Daylight saving time), select DST. Time Zone: Select time zone for the system being installed.
Live Screen Configuration Figure 3-1 UI Screen Configuration Table 3-1 Items and Description of UI Screen Configuration Item Description Setup menu Setting menu is located on the top edge of the screen. See section “04 Setup ” for more detailed information Live screen Show live video of connected cameras.
Page 19
Item Description Figure 3-4 Backup Table 3-4 Backup Item and Description Item Description Select CH Select the channels to be downloaded Select All/ Select or clear all channels. Unselect All Start Setting back-up start time (Bookmark: bookmark list). Setting back-up end time (Bookmark: bookmark list). Time Overlap Selecting the device to save back-up files to.
Icons in Live screen Chosen live screen is framed by a blue border; the segment that the mouse is Note located in is framed by a yellow border. Figure 3-2 Live screen icon Table 3-2 Live screen icon and its description Icon Description CH1 CAM1...
Live Launcher menu This chapter describes Launcher menu located at the bottom of the screen. Figure 3-3 Launcher menu Table 3-3 Launcher menu Item and Description Item Description Log in/out status and logged in ID Date & Time Displaying present date and time Displaying HDD capacity currently used Moving to previous/next partition screen Live screen sequence mode (toggle ON / OFF)
3.3.1 Backup (Down loading of video footage) Figure 3-4 Backup Table 3-4 Backup Item and Description Item Description Select CH Select the channels to be downloaded Select All/ Select or clear all channels. Unselect All Start Setting back-up start time (Bookmark: bookmark list). Setting back-up end time (Bookmark: bookmark list).
Quick menu Right click anywhere on the screen to display the Quick menu. Figure 3-5 Quick menu Table 3-5 Quick menu Item and Description Item Description Screen Mode Select the split screen mod to be displayed (Full, 2X2, 3X3, and 4x4). Zoom in Magnify the selected live full screen image (Zoom out, 2 times, 4 times, and 8 times).
3.4.1 PTZ Control PTZ Control menu can be displayed if relevant channel’s protocol is set in DEVICE > Note PTZ in the upper live screen. Figure 3-6 Quick menu > PTZ Control Table 3-6 Quick menu > PTZ Control Item and Description Item Description Direction control buttons...
Page 25
In PTZ Control screen, clicking the right button of the mouse displays Quick menu. Figure 3-7 PTZ Control Quick menu Table 3-7 PTZ Control Item and Description in Quick menu Item Description Preset Go Go to a preset position Preset Save Save a preset position Tour Run Tour function.
3.4.2 Camera Registration Connection of IP camera to the NVR Figure 3-8 Quick Menu > Camera Registration Table 3-8 Quick Menu > Camera Registration Item and Description Item Description Search for connected IP cameras. Auto Assign Automatically assign channel numbers Port Show the detected camera port (WAN or PoE).
3.4.3 Status > System log The system log information can be seen in the System log tab in Status screen. Figure 3-9 Status > System log in Quick menu Table 3-9 Status of Quick menu > System log Item and Description Item Description Start...
3.4.4 Status > Event The real-time event information of the unit in Event tab in Status screen. Figure 3-10 Status > Event in Quick menu Table 3-10 Status > Event Item and Description in Quick menu Item Description Temporary fixing or releasing an event list (toggle). Refresh Deleting the event list Event list...
3.4.5 Status > Record Users can see the recording status in Record tab in Status screen. Figure 3-11 Status > Record in Quick menu Table 3-11 Status > Record Item and Description in Quick menu Item Description Record time Displays the first and last recorded time Record list Displays the record setting status Cancel...
3.4.7 Status > Disk Users can see the disk status in Disk tab in Status screen. Figure 3-12 Status > Disk in Quick menu Table 3-12 Status > Disk Item and Description in Quick menu Item Description Disk Info Display disk temperature and S.M.A.R.T information. Rec.
Setup menu This chapter describes Setup menu located at the top edge of the screen Figure 4-1 Setup menu Selecting the menu opens the setting screen. Setup screen is also available within the Quick menu. Right click the Note mouse and select Setup. Table 4-1 Setup menu Item and Description Item Description...
Page 32
Setup menu includes: Table 4-2 Setup menu tree Level 1 Level 2 Level 3 System System F/W Upgrade Time/Date Time/Date Holiday SYSTEM Account User Export/Import Configuration Factory Default Basic Basic Audio In CAMERA Advanced Advanced Display Display Sequence Setup DEVICE Disk iSCSI Serial Device...
Page 33
Level 1 Level 2 Level 3 Basic WAN Port DVRNS/Dashboard NETWORK DVRNS/DDNS DDNS E-Mail E-Mail VIPER-H4 user manual V1.0...
General buttons in Setup menu This section describes frequently used buttons in the Setup menu. Figure 4-2 General buttons in Setup menu Table 4-3 Item and Description of General buttons in Setup menu Item Description Default Reverse changed setting value back to factory default. Save Save the set content.
SYSTEM 4.2.1 System System > System Figure 4-3 SYSTEM > System > System Table 4-4 SYSTEM > System > System Item and Description Name Function Language Set the system language. Device Name Enter the device name (Only English is possible). Video Type Select image standard types (PAL,NTSC).
Page 36
System > F/W Upgrade Use to apply new firmware to the DVR Figure 4-4 SYSTEM > System > F/W Upgrade Table 4-5 SYSTEM > System > F/W Upgrade Item and Description Name Function Current Version Displaying the present tool version. Device Connect USB memory stick, that has new firmware files saved within it’s root menu, to the USB port, select files to upgrade.
4.2.2 Time/Date Time/Date > Time/Date Set the date, time, and holidays of the system. Figure 4-5 SYSTEM > Time/Date > Time/Date Table 4-6 SYSTEM > Time/Date > Time/Date Item and Description Name Function System Time Set the date and time. ...
Page 38
Time/Date > Holiday Set holidays dates on the system. Figure 4-6 SYSTEM > Time/Date > Holiday Table 4-7 SYSTEM > Time/Date > Holiday Item and Description Name Function Year Select years to set holidays. Delete selected holidays. Add Holiday Add holidays. List Display holiday dates added to the system VIPER-H4 user...
Page 39
Clicking Add Holiday displays holiday addition screen like below. Figure 4-7 SYSTEM > Time/Date > Holiday > Add Holiday Table 4-8 SYSTEM > Time/Date > Holiday > Add Holiday Item and Description Name Function Name Enter the holiday name. Date Display chosen date.
4.2.3 Account > User Set the user’s account of the system. Figure 4-8 SYSTEM > Account > User Table 4-9 SYSTEM > Account > User Item and Description Name Function Add Group Adds extra User groups ( each can have it’s own user levels) Add User Add users to a selected group.
Page 41
Press Add Group button, then Add Group screen displays. Figure 4-9 SYSTEM > Account > User > Add Group Table 4-10 SYSTEM > Account > User > Add Group Item and Description Name Function Name Enter the group name. PERMISSION Select items which members of this group have access to.
4.2.5 Configuration (Config) Set Export/Import and Factory Default of the system. Config > Export/Import System configurations can be backed up and used for other identical devices Figure 4-11 SYSTEM > Config > Export/Import Table 4-12 SYSTEM > Config > Export/Import Item and Description Name Function Device...
Page 43
Config > Factory Default Reset the device setting to factory default settings. Figure 4-12 SYSTEM > Config > Factory Default Table 4-13 SYSTEM > Config > Factory Default Item and Description Name Function Select All Select/deselect all items to be defaulted /Unselect All Default Item Select/deselect individual items to be defaulted.
CAMERA Setup the camera configuration of each individual camera 4.3.1 Basic Basic > Basic Figure 4-13 CAMERA > Basic > Basic Table 4-14 CAMERA > Basic > Basic Item and Description Name Function Shows the channel number Title Edit the camera name. Convert Select the cameras to be set in covert mode Copy Covert...
Page 45
Press Copy Covert Setup button, then Copy Covert Setup screen displays. Figure 4-14 CAMERA > Basic > Basic > Copy Covert Setup Table 4-15 CAMERA > Basic > Basic > Copy Covert Setup Item and Description Name Function From Select a channel to copy settings from Select a channels to be copied too.
Page 46
Basic > Audio In/out Figure 4-15 CAMERA >Basic > Audio In/Out Table 4-16 CAMERA > Basic > Audio In/Out Item and Description Name Function Display channels of audio Select/deselect whether to use audio. Assign Select channels to be assigned audio. Record Select/deselect whether to save audio.
4.3.2 Advanced (Video, Stream and VCA) Figure 4-16 CAMERA > Advanced Table 4-17 CAMERA > Advanced Item and Description Name Function Display channel number. Video Setup camera image such as Colour, White Balance, WDR, AE and etc. Stream Setup camera stream such as Resolution, Framerate, Bitrate and etc. Video Analytics Setup Video Analytics function if the camera supports this function.
DEVICE This section allows the configuring of non camera external devices and HDD formatting. 4.4.1 Display Display > Display Set the parameters relating to the display Figure 4-17 DEVICE > Display > Display Table 4-18 DEVICE > Display > Display Item and Description Name Function HD Output/VGA...
Page 49
Display > OSD Set the OSD of the display device. Figure 4-18 DEVICE > Display > OSD Table 4-19 DEVICE > Display > OSD Item and Description Name Function Camera Name Select what is displayed in the camera titles (Off, CH+Title, CH). Live Bar Select the way to display the live bar (Always On, Auto Hide).
Page 50
Display > Sequence Figure 4-19 DEVICE > Display > Sequence Table 4-20 DEVICE > Display > Sequence Item and Description Name Function Quad Sequence Click the “use” box to allow sequence of quad 4 way displays Division Select screen partition mode to be marked in the below table (All, Full, and Quad).
Page 51
Clicking Add Sequence displays Add Sequence screen. Figure 4-20 DEVICE > Display > Sequence > Add Sequence Table 4-21 DEVICE > Display > Sequence > Add Sequence Item and Description Name Function Dwell Time Select time to play (3 sec, 5 sec, 10 sec, 15 sec, and 30 sec). Division Select the partition screen to play (Full, Quad).
4.4.2 Disk > Setup Figure 4-21 DEVICE > Disk > Setup Table 4-22 DEVICE > Disk > Setup Item and Description Name Function Refresh disk information. Disk Info Display the basic disk information in disc list. Model: disk model name ...
Page 53
Disk > iSCSI . Figure 4-22 DEVICE > Disk > iSCSI Table 4-23 DEVICE > Disk > iSCSI Item and Description Name Function Register Opens iSCSI registration window. Delete Delete registered iSCSI storage. Detail Display selected iSCSI IP address and port number. Clicking Register displays iSCSI register screen.
Page 54
Name Function Target Address Input IP address and ports for iSCSI Target Port HTTP Port Discover Click to search iSCSI storage. Click to register the discovered iSCSI storage. VIPER-H4 user manual V1.0...
4.4.3 PTZ > PTZ To use PTZ Function of the device, users need to match ID, protocol, and speed with each camera. Figure 4-23 DEVICE > PTZ > PTZ Table 4-24 DEVICE > PTZ > PTZ Item and Description Name Function Copy PTZ Setup Apply setting history to all or selected channels in the same way.
4.4.4 Serial Device > Serial Device (PTZ, keyboard, or Text device) Figure 4-24 DEVICE > Serial Device > Serial Device Table 4-25 DEVICE > Serial Device > Serial Device Item and Description Name Function USB (to Serial) Set communication transmission value of USB device. RS-485 Set communication transmission value of RS-485 connector.
4.4.5 TEXT > TEXT Used to configure PoS and Text devices to the DVR (Example - AVE VSI-PRO Max till interface) Figure 4-25 DEVICE > TEXT > TEXT Table 4-26 DEVICE > TEXT > TEXT Item and Description Name Function Select/deselect whether to use text function.
Page 58
Press Copy to TEXT Setup button, then Copy to TEXT Setup screen displays. Figure 4-26 DEVICE > TEXT > TEXT > Copy to TEXT Setup Table 4-27 ICE > TEXT > TEXT > Copy to TEXT Setup Item and Description Name Function From...
RECORD 4.5.1 Schedule > Schedule Each hour within each day can be allocated a different recording type Figure 4-27 RECORD > Schedule > Schedule Table 4-28 RECORD > Schedule > Schedule Item and Description Name Function Select channels to set schedules. Schedule Type Select the types of schedules.
Page 60
The function of each scheduling type involves: Table 4-29 Function of each scheduling type Color Scheduling type Function None Do not record. Continuous Record on consecutive mode when time set. Motion Record on event recording mode when motion sensitive event occurs. Alarm Record on event recording mode when alarm occurs.
Page 61
7 Copy Schedule Setup screen displays. 8 Select channels to be copied. 9 Select channels to apply copied content. 10 Copy the schedule by pressing Apply. 11 Press Save to save the schedule. VIPER-H4 user manual V1.0...
4.5.2 Stream To set the image resolution when event occurs across channels or general recording is in process. Stream > Main Stream To set the image quality and resolution of Main Stream Figure 4-28 RECORD > Stream > Main Stream Table 4-30 RECORD >...
Page 63
Clicking Copy Stream Setup opens Copy Stream Setup. Figure 4-29 RECORD > Stream > Main Stream > Copy Stream Setup Table 4-31 RECORD > Stream > Main Stream > Copy Stream Setup Item and Description Name Function From Select the channel set. Select the device to be copied.
Page 64
Stream > Second Stream To set the image quality and resolution of Second Stream Figure 4-30 RECORD > Stream > Second Stream Table 4-32 RECORD > Stream > Second Stream Item and Description Name Function Display channels. Resolution Show camera second stream setup status. Framerate Bitrate Pre-Alarm...
Page 65
Stream > Panic Figure 4-31 RECORD > Stream > Panic Table 4-33 RECORD > Stream > Panic Item and Description Name Function Panic Record Select/deselect to use immediate recording function. Display channels. Resolution Panic recording stream follows the Event stream. Frame rate Quality Dwell Time...
EVENT 4.6.1 System/Disk System/Disk > System Used to set up general system events and the actions that occur. Figure 4-32 Event > System/Disk > System Table 4-34 Event > System/Disk > System Item and Description Name Function System Restart Select/deselect whether to use system restart event. Notification Select/deselect whether to use mailing in case of an event.
Page 67
System/Disk > Disk To set disk event Figure 4-33 Event > System/Disk > Disk Table 4-35 Event > System/Disk > Disk Item and Description Name Function Disk Unplugged Select/deselect whether to use disk unplugged event Beep Select/deselect whether to use buzzer sound in case of event. Alarm out Select to end alarm time (null, Relay1-Keep, 5 sec, 10 sec, 20 sec, 30 sec, 1 min, 10 min, 30 min, and 1 hour).
4.6.2 Alarm In Alarm In > Setup To set actions required on a hard wired alarm input. Figure 4-34 Event > Alarm In > Setup Table 4-36 Event > Alarm In > Setup Item and Description Name Function Sensor Displays the sensor numbers. Select/deselect whether to use this alarm input.
Page 69
Placing your mouse on Alarm, Group Rec, Noti. Or Preset and clicking editing Icon( ) in right corner displays Event : Alarm screen. Figure 4-35 Event > Alarm In > Setup > Event : Alarm Table 4-37 Event > Alarm In > Setup > Event : Alarm Item and Description Name Function Alarm-out...
Page 70
Alarm In > Schedule To schedule the times during each day when the alarm inputs are active. Figure 4-36 Event > Alarm In > Schedule Table 4-38 Event > Alarm In > Schedule Item and Description Name Function Sensor Select the alarm input to be scheduled. Schedule Type Select between active or not active Selection...
4.6.3 Motion Motion > Setup Figure 4-37 Event > Motion > Setup Table 4-39 Event > Motion > Setup Item and Description Name Function Display channels. Select/deselect whether to use motion function in the channel. Area Display the motion area. Sens.
Page 72
Motion > Schedule To schedule the record times when the motion detection is active on each channel. Figure 4-38 Event > Motion > Schedule Table 4-40 Event > Motion > Schedule Item and Description Name Function Select channels to set schedules. Schedule Type Select the types of schedules.
4.6.4 Video Loss > Setup Figure 4-39 Event > Video Loss > Setup Table 4-41 Event > Video Loss > Setup Item and Description Name Function Display channels. Select/deselect whether to use Video Loss in the channel. Beep Select use time of buzzer sound (null, 5 sec, 10 sec, 20 sec, 30 sec, 1 min, 10 min, 30 min, and 1 hour).
4.6.5 Notification To set and schedule periodical alarms Notification > Periodic Figure 4-40 EVENT > Notification > Periodic Table 4-42 EVENT > Notification > Periodic Item and Description Name Function Periodic Select/deselect whether to use periodical alarms Notification Summary Send the save or event information. ...
Page 75
Notification > Schedule To schedule periodical alarms Figure 4-41 EVENT > Notification > Schedule Table 4-43 EVENT > Notification > Schedule Item and Description Name Function Schedule Type Select the types of schedules. Selection Schedule Table Displays each day of the week in hourly segments Drag Field Set the areas to be set by clicking and dragging the mouse.
NETWORK 4.7.1 Basic BASIC > WAN Port Figure 4-42 NETWORK > Basic > WAN Port Table 4-44 NETWORK > Basic > WAN Port Item and Description Name Function Static IP Check if you use static IP. For using static IP, enter IP address, Subnet Mask, and Gateway.
Page 77
Basic > PoE Ports To set the network PoE Ports Figure 4-43 NETWORK > Basic > PoE Ports Table 4-45 NETWORK > Basic > PoE Ports Item and Description Name Function DHCP Server Select whether to enable DHCP server. DHCP (Dynamic) Select whether to use DHCP (Dynamic). IP Address Enter the each information properly.
4.7.2 DVRNS/DDNS DVRNS/DDNS > DVRNS/Dashboard This allows the user to register all their VIPER devices on a remote server under a unique account. They can then login into the server to view: Live images; Set up the devices and view the status of each device.
Page 79
DVRNS/DDNS > DDNS To set DDNS site for remote users to access via the network connection. Figure 4-45 NETWORK > DVRNS/DDNS > DDNS Table 4-47 NETWORK > DVRNS/DDNS > DDNS Item and Description Name Function DDNS Site Select DDNS site Host Name Enter the host name.
4.7.3 E-Mail To set email server to send email on the occasion of event Figure 4-46 NETWORK > E-Mail > E-Mail Table 4-48 NETWORK > E-Mail > E-Mail Item and Description Name Function Server Type Select SMTP server. gmail.com ...
4.7.4 Warp Warp allows the unit to connect to a remote unit. Allowing live view, PTZ control, Playback and system setup, via the local monitor of the NVR Register the recorder to monitor and control remotely. Figure 4-47 NETWORK > Warp > Registration Table 4-49 NETWORK >...
Search/Play This chapter describes Live Launcher search and play menu located at the bottom of the screen. Figure 5-1 Live Launcher Search, Play menu Table 5-1 Item and Description of Live Launcher Search, Play menu Item Description Searching recording data (time, event, and thumbnail). Playing recorded data –...
Page 83
Figure 5-3 Search: Event Table 5-3 Search: Event Item and Description Item Description Select CH Select channels to be searched Select All Select/deselect all channels. /Unselect All Start Set the start time Set the end time Selecting the types of event (immediate recording, motion, Alarm-In, EVENT TYPE Video Loss, and bookmark).
Page 84
Figure 5-4 Search: Thumbnail Table 5-4 Search: Thumbnail Item and Description Item Description Calendar Select dates to search Select channels to search Time Select time to begin search Interval Setting time interval between images to be displayed Time This plays each displayed segment forward in time lapse mode Lapse/Pause Cancel Exit search screen...
Page 85
Figure 5-5 Search: Smart Search Table 5-5 Search: Smart Search Item and Description Item Description Selecting channels to search Area Setup Set up the area of the screen in which analysis is to be carried out Start Setting starting time to search Setting ending time to search (Note: Maximum period for search is limited to a one hour period)
Page 86
Figure 5-6 Search: Text Table 5-6 Search: Text Item and Description Item Description Select CH Select channels to search Select All Select/deselect all channels. /Unselect All Start Set the start time to search Set the end time to search Keyword Entering keyword to search Case Sensitive Searching items in case-sensitive...
Page 87
Figure 5-7 Search: VCA Table 5-7 Search: VCA Item and Description Item Description Select CH Selecting channels to be searched Start, End Set start time and end time. Event Type Selecting VCA event type. Search Search VCA event. Play Playback selected event. VIPER-H4 user manual V1.0...
Playback To play recorded data Figure 5-8 Playback Launcher Table 5-8 Playback Launcher Item and Description Item Description Displays present play status Date and Time Displaying date and time of video being played Moving to the first section of the video Playing the videos with multiplied speed in reverse (2~64x).
Webviewer This chapter describes webviewer for monitoring videos through a PC in remote mode. How to monitor with webviewer Table 6-1 System Requirement for Webviewer Item Recommended Minimum MicrosoftⓇ WindowsⓇ 10 x86(64bit) MicrosoftⓇ WindowsⓇ XP Home SP3 (Home Premium, Professional, Ultimate) MicrosoftⓇ...
Page 90
When Java download screen opens, download and install JAVA. Live images may be monitored. Selecting Setup Users can set the menu in similar ways with NVR connected monitor. Figure 6-1 Setup screen VIPER-H4 user manual V1.0...
Products Specifications Model 16Ch VIDEO Video Input 4 IP 8 IP 16 IP Video Input Up to 5MP Up to 5MPx4ch+3MPx4ch Up to 5MPx4ch+3MPx12ch Resolution Compression H.264 H.264 H.264 Display Output 1 VGA, 1 HD Output 1 VGA, 1 HD Output 1 VGA, 1 HD Output 1920x1080, 1280x720, 1920x1080, 1280x720,...
Page 92
3rd Party IP Camera Support API or Onvif Support API or Onvif Support API or Onvif POS/ATM POS/ATM POS/ATM Text In (VSSI-Pro, ASCII, (VSSI-Pro, ASCII, (VSSI-Pro, ASCII, Network, ) Network, ) Network, ) Mouse, IR Remote Mouse, IR Remote Control, Mouse, IR Remote Control, User Interface Control, USB/RS485...
