XP SBC BC 8310/00-1.1
Battery condition indicator
Indicates the energy level of the
rechargeable batteries during operation.
3 levels indicate the condition of the
rechargeable batteries. 3 LED's: batteries
full, 2 LED's: batteries half full, 1 LED:
Multiple speakers with one
An additional number of wireless speakers
can be used with a single transmitter if they:
- operate in the 864 MHz band
- can detect a 19 kHz pilot tone.
Please consult the appliance's electrical
speciﬁcation sheets for conﬁrmation on
This FM speaker system consists of the
1 x SBC BC8310 FM speaker
1 x SBC CS020/00 9 Volt/1000 mA
8 x rechargeable batteries LR6/AA (NiCd),
1 Charge indication LED – lights up
2 Battery condition indicator – 3 levels
3 Power indication LED –
4 Dynamic Bass Boost indicator –
5 Dynamic Bass Boost on/off –
6 Volume control –
7 Power On/Off – push the button to
8 Battery cover
9 Tuning – turn the tuning wheel until the
10 DC power – connect to the 9 Volt/1000
11 L/ L+R/ R switch – switch the L/ L+R /R
12 Controls plate
Speaker (ﬁgure 1)
when batteries are being charged.
indicate the condition of the rechargeable
batteries. 3 LED's: batteries full, 2 LED's:
batteries half full, 1 LED: batteries empty.
lights up when speaker is switched on.
lights up when DBB is switched on
push the button to switch on/off
adjust volume to your desired listening level
switch the speaker on/off.
signal is at its clearest.
mA AC/DC adapter
switch to L+R when only using one speaker.
Switch to L or R for left or right use when
using two speakers.
