M SERIES M-15/45/90 Ice Dispensers INSTALLATION & SERVICE GUIDE Part Number 5011634 Manitowoc Beverage Equipment 2100 Future Drive Sellersburg, IN 47172-1868 Tel: 812.246.7000, 800.367.4233 Fax: 812.246.9922 www.manitowocbeverage.com In accordance with our policy of continuous product development and improvement, this information is subject to change at any time without notice.
FOREWORD Manitowoc Beverage Equipment (MBE) developed this manual as a reference guide for the owner/ operator, service agent, and installer of this equipment. Please read this manual before installation or operation of the machine. A qualified service technician should perform installation and start- up of this equipment, consult the Troubleshooting Guide within this manual for service assistance.
Installation and Service Manual SAFETY IMPORTANT SAFETY INSTRUCTIONS Carefully read all safety messages in this manual. Learn how to operate the SV unit properly. Do not allow anyone to operate the unit without proper training and keep it in proper working condition. Unauthorized modifications to the SV may impair function and/or safety and affect the life of the unit.
SAFETY GROUNDING IN STRUCTIONS WARNING: Risk of electrical shock. Connect to a properly grounded outlet only. This appliance must be grounded. In the event of malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This appliance is equipped with a cord having an equipment-grounding conductor and a grounding plug.
Installation and Service Manual INSTALLATION COUNTER TOP INSTALLATION Check the equipment location. Assure the proper drain and tached, these valves will be attached to the splash panel. electrical requirements are available before proceeding. Included inside the dispenser from the factory is a length Carefully remove the dispenser from the shipping carton.
Request a written inspection report from a claims inspector to document any necessary claim. ICE RECOMENDED FOR DISPENSING Servend dispensers are designed to dispense hard, cube ice up to one-inch square. The ice shapes and sizes listed above are recommended for dispensing. Warm “Super Cooled” Ice Before Dispensing “Super Cooled”...
Installation and Service Manual OPERATION SPECIFICATIONS M -15 M -45 M-90 WIDTH W idth 38.1 cm 38.1 cm 38.1 cm (15") (15") (15") D epth - overall 71.1 cm 71.1 cm 71.1 cm (28") (28") (28") D epth - cou nter 66 cm 66 cm 66 cm...
Page 10
Installation and Service Manual OPERATION ICE BIN MANUAL FILL AREA (M-200 & LARGER) AGITATOR ELECTRICAL BOX DOOR ASSEMBLY ICE CHUTE GEAR MOTOR PADDLE WHEEL DRAIN PAN BIN WIDTH REAR REAR TO BIN LEGNTH BIN DRAIN RIGHT LEFT SIDE SIDE REAR TO DRAIN PAN DRAIN BIN DRAIN...
Installation and Service Manual OPERATION AGITATION TIMER The agitation timer is standard equipment for the dispensers with 90.7 kg. (200 lbs.) and larger bin storage. This timer is available as an option for all other dispensers. The purpose of the timer is to periodically agitate the ice in the bin, preventing the ice from congealing together.
Installation and Service Manual OPERATION GEAR MOTOR REMOVAL These instructions are provided as a guide for the removal of the gear motor. Depending on the model number of your dispenser, these instructions may vary slightly. 6. Remove the four bolts from the front wall of the dis- 1.
Installation and Service Manual OPERATION BIN FLOW RESTRICTOR & ICE FLOW To install the ice flow restrictor: 1. Remove the merchandiser. 4. Place the restrictor in the chute, holding with the bolt 2. Remove the door assembly. and nut. 3. Drill 3/16” hole in top of chute from the bin as shown 5.
Installation and Service Manual EXPLODED VIEWS, PARTS & DIAGRAMS M-15A/15B/45/90 STANDARD ALL VOLTAGES TO ELECTRIC POWER SUPPLY M-15C STANDARD ALL VOLTAGES TO ELECTRIC POWER SUPPLY...
Installation and Service Manual EXPLODED VIEWS, PARTS & DIAGRAMS M-15 EXPLODED VIEW (TOP) KEY # DESCRIPTION PART NUMBER (all models) 4100075 Flipper Door 4105503 Flipper Door Rod 4100008 Flipper Door Frame 4105502 Paddlewheel 2602235 Agitator 4105706 Paddlewheel Pin 5001683 Drain Kit Assembly...
Installation and Service Manual EXPLODED VIEWS, PARTS & DIAGRAMS M-15 EXPLODED VIEW (BASE) KEY # DESCRIPTION PART NUMBER (all models) KEY # DESCRIPTION PART NUMBER (all models) Bin Insulator 2601968 Transformer 115 Volt - 60 Hz 1001424 Gearmotor 115 Volt - 60 Hz...
Installation and Service Manual EXPLODED VIEWS, PARTS & DIAGRAMS M-15 A EXPLODED VIEW (FRONT) KEY # DESCRIPTION PART NUMBER Inner Ice Shield 4100038 Push Plate Retaining Bracket 4100007 Door Assembly (LESS SOLENOID COIL) - see page 36 for 4105908 solenoid door parts...
Installation and Service Manual EXPLODED VIEWS, PARTS & DIAGRAMS M-15 B EXPLODED VIEW (FRONT) KEY # DESCRIPTION PART NUMBER Inner Ice Shield 4100038 Door Assembly (LESS SOLENOID COIL) - see page 36 for 4105908 solenoid door parts Drip Pan Assembly...
Installation and Service Manual EXPLODED VIEWS, PARTS & DIAGRAMS M-15 C EXPLODED VIEW (FRONT) KEY # DESCRIPTION PART NUMBER Door Assembly (LESS SOLENOID COIL) - see page 36 for 5002533 solenoid door parts Drip Pan Assembly 4105901 Drip Pan Rod...
Installation and Service Manual EXPLODED VIEWS, PARTS & DIAGRAMS M-45/90 EXPLODED VIEW (BASE) See Electrical view...
Page 22
Installation and Service Manual EXPLODED VIEWS, PARTS & DIAGRAMS M-45/90 EXPLODED VIEW (BASE) PART NUMBER PART NUMBER KEY # DESCRIPTION M 45 M 90 Agitator 7015702 7015702 Paddlewheel Pin 5001683 5001683 Paddlewheel 2602235 2602235 Mushroom Bushing O101702 O101702 4570035 4570035 Bin Insulator 2601968 2601968...
Installation and Service Manual EXPLODED VIEWS, PARTS & DIAGRAMS M-45/90 EXPLODED VIEW (FRONT) PART NUMBER PART NUMBER KEY # DESCRIPTION M 45 M 90 Medallion - PL 5000167 O300102 - PL with valves N / A 5006865 - PB N / A 5006866 - PB with valves N / A...
Page 24
Installation and Service Manual EXPLODED VIEWS, PARTS & DIAGRAMS M-45/90 EXPLODED VIEW (FRONT) PART NUMBER PART NUMBER KEY # DESCRIPTION M 45 M 90 Starter Base 1001006 1001006 Fluorescent Starter 1001005 1001005 Shoulder Plate 7060016 7060016 Electrical Box Cover 1000507 1000507 Electric Box 4635906...
Installation and Service Manual EXPLODED VIEWS, PARTS & DIAGRAMS M-90 EXPLODED VIEW (FRONT)
Page 26
Installation and Service Manual EXPLODED VIEWS, PARTS & DIAGRAMS M-90 EXPLODED VIEW (FRONT) KEY # DESCRIPTION PART NUMBER Left Merchandiser Angle 4590057 Right Merchandiser Angle 4590054 Ice Chute 5001991 Knurled Screw O904403 Splash Panel Punched for 4 Valves 5000403 Translight - All You Can Drink 5000635 Merchandiser 5001477...
Installation and Service Manual TROUBLESHOOTING CONDITION INVESTIGATION HOW TO CHECK CORRECTION Dispenser does not dispense There is no power to the Is the dispenser plugged in? Plug the dispenser in. ice. dispenser. The dispenser is plugged in If no power is present, check with power to the receptacle.
INDEX brixing ........2 FOREWORD ......2 Operation ........5 TROUBLESHOOTING ....27 Carbon Dioxide ......5 health department ....12 Qualified Service Personnel ..5 Unit Inspection ......8 CAUTION ......11, 12 UNPACKING ......2 claims ........8 Cleaning ........
Page 32
Manitowoc Beverage Equipment 2100 Future Drive Sellersburg, IN 47172-1868 Tel: 812.246.7000, 800.367.4233 Fax: 812.246.9922 www.manitowocbeverage.com In accordance with our policy of continuous product development and improvement, this information is subject to change at any time without notice. 5011634 March 23, 2005 REV1...
