User Manual
Outdoor Enterprise
Access Point
WM-OAP8251AG
Quick Start Guide
V1.0
For more information on this and other Winmate
products, please visit our website at:
www.winmate.com
Document Part Number: 91521110100L
Please read these instructions carefully before using this product, and save this manual for future use.
Advertisement
Table of Contents
Related Manuals for Winmate WM-OAP8251AG
Summary of Contents for Winmate WM-OAP8251AG
-
Page 1: Quick Start Guide
Access Point WM-OAP8251AG Quick Start Guide V1.0 For more information on this and other Winmate products, please visit our website at: www.winmate.com Document Part Number: 91521110100L Please read these instructions carefully before using this product, and save this manual for future use. -
Page 2: Fcc Statement
FCC Statement Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 3: Table Of Contents
Product Overview INSTALLATION Connecting the Access Point Managed Access Point with Wireless Management Switch Stand-alone Access Point Installation Mounting Wall Mounting the AP Pole Mounting the AP GETTING STARTED Configuring Your Access Point Default Settings Web Configuration WM-OAP8251AG Quick Start Guide... -
Page 4: Getting Started
GETTING STARTED Congratulations on purchasing Winmate® Outdoor Enterprise Access Point. The WM-OAP8251AG is an enterprise class, outdoor dual radio 2.4G (11n) and 5G (11ac Wave2) concurrent 4x4 MU-MIMO access point with built-in internal antenna. The device has two Ethernet ports and one of it is a PSE port that supplies power to the remote unit. -
Page 5: Package Contents
The factory shipment list: Outdoor Enterprise User Manual Quick Start Guide Access Point EzMaster Software PoE Injector (Hardcopy) WM-OAP8251AG & User Manual Ground Cable Mounting Screws Wall Mounting Kit Pole Mounting Kit (Green) and Bolts AWG10 180cm 2.4GHz Detachable... -
Page 6: Product Overview
LAN Port 2 (802.3af PSE Output): Ethernet port for RJ-45 cable. Console/ Reset: Console panel/ reset button. LED Indicators: LED lights for Power, LAN Port 1, LAN Port 2, 2.4 GHz Connection and 5 GHz Connection. WM-OAP8251AG Quick Start Guide... - Page 7 Rear View Description Ground Mounting Holes: Using the provided mounting kits, the WM-OAP8251AG can be attached to a wall or pole. Optional M12 Connector...
-
Page 8: Installation
B. Connect another Ethernet Cable into an Ethernet Port on the front panel of the WM-OAP8251AG and the other end to the Ethernet Port on the computer. C. Screw the provided antennas to the device as shown on the illustration below. -
Page 9: Stand-Alone Access Point Installation
Stand-alone Access Point Installation Follow the instructions below to establish the connection to the Access Point. A. Connect one end of the Ethernet Cable into the main LAN Port (PoE) of the Access Point and the other end to the AP Ethernet Port. B. -
Page 10: Mounting
Mounting Wall Mounting the AP To attach the WM-OAP8251AG to a wall using wall mounting kit: A. Mark the four locations of the mounting holes on the flat mounting surface. B. Drill a 37 mm deep 8 mm hole in the markings and hammer the bolts into the openings. -
Page 11: Pole Mounting The Ap
To attach the WM-OAP8251AG to a wall using pole mounting kit: To attach the WM-OAP8251AG to a wall using provided pole mounting kit: A. Attach the device onto the wall by tightening the bolt’s flat washers and nuts to secure the mounting base to the mounting surface. - Page 12 C. Thread the open end of the Pole Strap through the two tabs on the Pole Mount Bracket. D. Lock and tighten the Pole Strap to secure the Pole Mount Bracket to the pole. Horizontal Placement Vertical Placement WM-OAP8251AG Quick Start Guide...
-
Page 13: Getting Started
GETTING STARTED Configuring Your Access Point Before you begin, the device must be able to communicate with the ezMaster server for ezMaster to manage an AP or switch. Make sure that the ezMaster server, EWS AP and EWS switch can all be reachable via HTTP/HTTPS from outside your internal network. For more information about ezMaster server settings, refer to the ezMaster Quick Start Guide included in the package. - Page 14 If successful, you will be logged in and see the WM-OAP8251AG User Menu. WM-OAP8251AG Quick Start Guide...
- Page 15 NOTES ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________...
- Page 16 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C Tel: 886-2-8511-0288 Fax: 886-2-8511-0211 Email: sales@winmate.com.tw Official website: www.winmate.com...
