Steamist TSC-250 Installation And Operating Instruction

Steambath Control
Important: Locate Publication No. 199 "Steam Bath Important Safety Instructions". This publication includes a Warning
label that the contractor must install on the wall near the entrance to the steam room in a highly visible location. This
!
label and its additional safety information are packaged with the generator in the envelope containing the installation
instructions. If it is lost or missing contact Steamist (201-933-0700) for a replacement Publication No. 199. This publica-
tion along with all documents must be left with the owner.
Control Features
( *New for 2017 )
1.
Display: The digital readout displays the ambient temperature,
set point and cycle time, system status, and diagnostic error
codes.
2.
Steam Icon: When illuminated the steam cycle is running.
3.
Water Icon: When steam shower is not in use the blue water
icon indicates the **InstaMist feature is on. This is also illumi-
nated during a steam bath cycle.
4.
Menu button: Used to change cycle time, turn **InstaMist on or
off and switch between ºF and ºC. When steam is off, pressing
this button will toggle between these settings. The settings are
changed with the up/down arrow buttons.
5.
Stop button: Pressing this button stops the current steam cycle
and the Menu mode.
6.
User 1 button: Starts the user one cycle and is the up function
when changing Menu settings. Pressing this button while in a
cycle will change the temperature and remaining time left on
that cycle.
7.
User 2 button: Starts the user two cycle and is the down
function when changing Menu settings. Pressing this button
while in a cycle will change the temperature and remaining time
left on that cycle.
IMPORTANT: This control must be installed inside the steam room
for proper operation of the system and
and SMP model steam generators.
TSC-250 Digital Temperature Control ( 2017 Model )
03/17
®
will ONLY function with TSG
TSC-250 Digital Temperature Control
1
4 MENU
__
__
__
__
6
Cleaning Instructions: Use a damp cloth and mild soap. Do
NOT use abrasive cleaners which might scratch the surface
or the base of the control.
*If your model TSC-250 control does not match the picture
below, please see Pub. No. 271-D.
**InstaMist option is ONLY available when connecting to a
"TSG" model steam generator (InstaMist function is not
available on the "SMP" models).
function that keeps the water heated for quick starts.
TSC-250R (Round control)
2
3
STOP
5
1 2
X
7
- 1 -
Installation & Operating Instructions
Models: TSC-250 & TSC-250R
InstaMist is a preheat
MENU STOP
__
1 2
__
__
__ X
Pub. No. 271-E
C US
®
