Tripp Lite SRCOOL7KRM Manual

Ideal for enclosures with perforated doors (not for use in enclosures with solid/plexiglass/glass doors)
Install the unit using a bottom-mounting configuration only, with the enclosure's floor open and no tray or pan
below the SRCOOL7KRM
Evaporator coils can be vented through enclosure's rear perforated doors or optional
solid doors)
In an open frame application, cooling air delivered to the equipment is lessened, since cold air escapes into
the room. Condenser must be ducted using the SRCOOL7KDUCT.
SmartRack Rack-Mounted Server Rack Cooling Unit
- 7,000 BTU, 120V
MODEL NUMBER: SRCOOL7KRM
Description
The SRCOOL7KRM Rack-Mounted Server Rack Air Conditioner pumps 7,000 BTU/h (2.0 kW) of close-coupled cooling power into your IT equipment to
prevent shutdowns, malfunctions and failures caused by overheating. This space-saving, energy-efficient unit is perfect for data centers, server rooms,
network closets and other environments with heat-sensitive rack-mounted equipment and limited floor space.
The self-contained SRCOOL7KRM mounts just like any other rack equipment in 8U of space at the bottom of a rack enclosure. A magnetic air dam attaches to
the front door of the rack enclosure to ensure that equipment draws cool air from the SRCOOL7KRM instead of drawing warm air from the room. Because it
only cools the equipment inside the rack enclosure, the SRCOOL7KRM is much more efficient than solutions that cool an entire room to achieve the same
result. The SRCOOL7KRM filters the air, and its built-in evaporator eliminates condensation, as well as the need for a floor drain or water collection tank.
The 7-foot cord plugs into a standard 15A (NEMA 5-15R) outlet. The unit restarts automatically after power failures, and you can use the built-in timer to
schedule unattended shutdown and startup. The intuitive control panel includes a digital display and diagnostic LEDs to communicate operating conditions at a
glance.
The optional SRCOOLNET2 remote management accessory (sold separately) allows you to monitor temperatures, receive alerts, review logs and control
settings over the Ethernet network from any location via SNMP, Web, SSH or telnet. The
temperature and humidity sensor that allows you to link cooling output with temperature readings up to 12 feet away.
Features
Compact and Efficient Cooling
SRCOOL7KDUCT (no
SRCOOLNET2 accessory also includes an ENVIROSENSE®
1 / 4
Highlights
Saves valuable floor space in IT
environments
Saves energy with efficient
close-coupled cooling
Provides 7,000 BTU/h (2.0 kW) of
cooling capacity
Supports optional remote
management via Ethernet
Mounts at the bottom of an
EIA-standard 19 in. rack
Package Includes
SRCOOL7KRM SmartRack
Rack-Mounted Server Rack
Cooling Unit - 7,000 BTU, 120V
Magnetic air dam kit
Directional output vent
Mounting hardware
Owner's manual
