Matrix X-spdif 2 Manual page 9

Settings & Usage
3. MCLK mode switch
X-SPDIF2 has two modes of MCLK output to suitable for connecting different
devices, The MCLK output frequency when switch on and off as shown in the
following table:
Switch Position
Sample Rate
44.1kHz
48kHz
88.2kHz
96kHz
176.4kHz
192kHz
352.8kHz
384kHz
705.6kHz
768kHz
Note: When using with synchronous mode X-sabre pro, please set the switch
to ON.
OFF
MCLK Frequency
512fs 22.579MHz
512fs 24.576MHz
256fs 22.579MHz
256fs 24.576MHz
128fs 22.579MHz
128fs 24.576MHz
128fs 45.1584MHz
128fs 49.152MHz
64fs 45.1584MHz
64fs 49.152MHz
ON
MCLK Frequency
128fs 5.6448MHz
128fs 6.144MHz
128fs 11.2896MHz
128fs 12.288MHz
128fs 22.579MHz
128fs 24.576MHz
128fs 45.1584MHz
128fs 49.152MHz
64fs 45.1584MHz
64fs 49.152MHz
8
