GUILD
150W 150mm Bench Grinder
Instruction Manual
Important
- Please read these instructions fully before operating or maintaining your Guild bench grinder
These instructions contain important information that will help you get the best from your Guild
bench grinder, ensuring it remains safe to operate.
If you need help or have damaged or missing parts, call the Customer Helpline on 0333 3201989
After Sales Support
UK/Ireland 0333 3201989
Help@guildpowertools.co.uk
PGB150G

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PGB150G and is the answer not in the manual?

Questions and answers

Summary of Contents for Guild PGB150G

  • Page 1 Important - Please read these instructions fully before operating or maintaining your Guild bench grinder These instructions contain important information that will help you get the best from your Guild bench grinder, ensuring it remains safe to operate. If you need help or have damaged or missing parts, call the Customer Helpline on 0333 3201989...
  • Page 2: Table Of Contents

    Contents Safety Information ����������������������������������������������������������������������������������������������������3 In The Box �����������������������������������������������������������������������������������������������������������������7 Accessories ��������������������������������������������������������������������������������������������������������������7 Assembly Instructions ����������������������������������������������������������������������������������������������8 Operating Instructions ����������������������������������������������������������������������������������������������9 Maintenance ����������������������������������������������������������������������������������������������������������� 10 Trouble Shooting ���������������������������������������������������������������������������������������������������� 10 Working Hints For Your Bench Grinder ������������������������������������������������������������������� 10 Technical Data �������������������������������������������������������������������������������������������������������� 11 Environmental Protection ��������������������������������������������������������������������������������������� 11 Guarantee ��������������������������������������������������������������������������������������������������������������� 12 Declaration of Conformity ���������������������������������������������������������������������������������������...
  • Page 3: Safety Information

    Safety Information Important - Please read these instructions fully before starting assembly Warning Symbols The following warning symbols appear throughout this assembly manual and indicate the appropriate safety measures you should take when assembling and operating the bench grinder. To reduce the risk of injury, Please read the instruction manual Wear ear protection Wear eye protection Wear dust mask...
  • Page 4 Safety Information Important - Please read these instructions fully before starting assembly Original Instruction Safety Instructions “WARNING! When using electric tools basic safety precautions should always be followed to reduce the risk of fire, electric shock and personal injury including the following.
  • Page 5 Safety Information Important - Please read these instructions fully before starting assembly Original Instruction 11 - Do not abuse the cord - Never yank the cord to disconnect it from the socket Keep the cord away from heat, oil and sharp edges. 12 - Secure work - Where possible use damps or a vice to hold the work.
  • Page 6 Safety Information Important - Please read these instructions fully before starting assembly Original Instruction 23 - If the replacement of the supply cord is necessary, this has to be done by the manufacturer or his agent in order to avoid a safety hazard. 24 - For tools intended to be connected to a water supply: - Replacement of the plug or the supply cord shall always be carried out by the manufacturer of the tool or his service organisation,...
  • Page 7: In The Box

    In The Box Parts Eye Shield Work Rest Wheel Guard Fixing Screws Grinding Wheel Mounting Holes Spark Arrester / Eye Shield Bracket On/Off Switch Accessories Work rest Eye shield Grinding disk: Φ150 X 16 X Φ12.7mm left #36 Grinding disk: Φ150 X 16 X Φ12.7mm right #60 Customer Helpline 0333 3201989...
  • Page 8: Assembly Instructions

    Assembly Instructions NOTE: Before using the tool, read the instruction book carefully. 1� ASSEMBLY Before use, the eye shields/spark arresters must be fitted to the grinder. Remove both eye shields from packaging, position the shields over the two mounting brackets above the grinding wheels with the flanges of the spark arrester facing away from you, fix with the screw and washer provided.
  • Page 9: Operating Instructions

    Operating Instructions 1� OPERATING Make sure grinder is securely mounted; mounting holes are provided in the base of the grinder for this purpose, but the screws are not provided. Plug in the mains supply and push the on/off switch right to the on position. Switch off and unplug the grinder when not in use.
  • Page 10: Maintenance

    Maintenance Remove the plug from the socket before carrying out any adjustment, servicing or maintenance� If the supply cord is damaged, it shall be replaced by the manufacturer or its service agent or similarly qualified person in order to avoid a hazard. Trouble Shooting Although your new bench grinder is really very simple to operate, if you do experience problems, check the following:...
  • Page 11: Technical Data

    Technical Data Technical Data Table Voltage 230 V-240V~50 Hz Power input 150W S2 30min No load speed 2950/min Wheel size 1 Φ150 X 16 X Φ12.7mm left #36 Φ150 X 16 X Φ12.7mm right #60 Wheel size 2 Protection class Machine weight 4.90kg Noise Information...
  • Page 12: Guarantee

    Guarantee This product is selected for DOMESTIC USE ONLY and not for business use. This product is guaranteed against manufacturing defects for a period of 24 months. This does not cover the product where the fault is due to misuse, abuse, use in contravention of the instructions, or where the product has been the subject of unauthorised modifications or alterations, or has been the subject of commercial use.
  • Page 13: Declaration Of Conformity

    Declaration of Conformity This Guild 150W 150mm Bench Grinder model number PGB150G fully complies with the Machinery Directive 2006/42/EC, Electromagnetic Compatibility Directive 2004/108/ EC(before 2016/04/20) and 2014/30/EC(since 2016/04/20), RoHS Directive 2011/65/EU and the following harmonized EU standards EN 61029-2-4: 2011...
  • Page 14: Plug Replacement (Uk & Ireland Only)

    Plug Replacement (Uk & Ireland Only) If you need to replace the fitted plug then follow the instructions below. IMPORTANT The wires in the mains lead are colored in accordance with the following code: Blue = Neutral Brown = Live Green/Yellow=Earth As the colors of the wires in the mains lead of this appliance may not correspond with the colored markings identifying the terminals in your plug, proceed as follows.
