Page 1 Balluff BVS HS-Q Family Standard Handheld Barcode Reader Operation Manual english...
Page 2 An electronic version of this document is downloadable from the Balluff website (www.Balluff.com). If you visit our website and would like to make comments or suggestions about this or other Balluff publications, please let us know via the "Contact" page.
Page 3: Table Of Contents
About this Manual ......................... 15 Overview ......................... 15 Manual Conventions ....................... 15 Technical Support ......................... 15 Balluff Website Support ....................15 Telephone Technical Support ..................15 About the Reader ......................... 16 Programming the Reader ...................... 16 Configuration Methods ....................16 Programming Barcodes ..................
Page 4 BVS HS-Q Series Standard Hand Held Barcode Reader Global Interface Features ................... 32 Host Commands — Obey/Ignore ..............32 USB Suspend Mode ....................32 RS-232 Interface ........................33 Baud Rate ......................... 34 Data Bits ........................35 Stop Bits ........................35 Parity .........................
Page 5 EAN 8 2D Component .................. 100 UPC/EAN Global Settings ..................101 UPC/EAN Price Weight Check ..............101 UPC/EAN Quiet Zones .................. 102 Add-Ons ........................103 Optional Add-ons ..................103 Cordless models only: ................... 103 Optional Add-On Timer ................. 104 www.balluff.com...
Page 6 BVS HS-Q Series Standard Hand Held Barcode Reader Optional GS1-128 Add-On Timer ..............106 Code 39 ........................109 Code 39 Enable/Disable ................109 Code 39 Check Character Calculation ............109 Code 39 Check Character Transmission ............110 Code 39 Start/Stop Character Transmission ..........110 Code 39 Full ASCII ..................
Page 7 MSI .......................... 168 MSI Enable/Disable ..................168 MSI Check Character Calculation ..............169 MSI Check Character Transmission .............. 169 MSI Length Control ..................170 MSI Set Length 1 ..................171 MSI Set Length 2 ..................172 Plessey ........................173 www.balluff.com...
Page 8 BVS HS-Q Series Standard Hand Held Barcode Reader Plessey Enable/Disable ................. 173 Plessey Check Character Calculation ............173 Plessey Check Character Transmission ............174 Plessey Length Control ................. 174 Plessey Set Length 1 ..................175 Plessey Set Length 2 ..................176 2D Symbologies .........................
Page 9 Global AIM ID ........................ 235 Label ID ........................236 Label ID: Pre-loaded Sets ..................236 Label ID: Set Individually Per Symbology ..............238 Character Conversion ....................241 Reading Parameters ......................242 Good Read LED Duration ....................242 Reading Features ........................ 243 www.balluff.com...
Page 10 BVS HS-Q Series Standard Hand Held Barcode Reader Scan Mode ........................243 Stand Mode Off Time ....................244 Reading Active Time ..................... 245 Aiming Duration Time ....................246 Flash On Time ......................247 Flash Off Time ......................248 Multiple Labels Ordering by Code Symbology .............. 249 RF Features ........................
Page 11: End User Software License Agreement (Eula)
This Agreement does not convey ownership of the Software to End User. Title to the Software shall be and remain with Balluff or the third party from whom Balluff has obtained a licensed right. As used in this Agreement, the term "purchase"...
Page 12 User's problem reports according to Balluff's standard assistance practices. Balluff does not warrant that the product will meet End User's requirements or that use of the product will be uninterrupted or error free, or that Balluff's remedial efforts will correct any nonconformance. This limited warranty does not cover any product that have been subjected to...
Page 13 Balluff GbmH Schurwaldstraße 9, D-73765 Neuhausen/Fildern, Germany. In the defense or settlement of any such claim, Balluff may, at its option, 1) procure for End User the right to continue using the...
Page 14 11.5. German law shall apply exclusively without giving effect to its conflict of laws principles. 11.6. In addition to these EULA, the General Terms and Conditions of Balluff shall apply. In the event that individual provisions of the EULA contradict any provision of General Terms and Conditions, then, the EULA shall prevail. Without prejudice of...
Page 15: Introduction
Technical Support 2.2.1 Balluff Website The Balluff website (www.balluff.com) is the complete source for technical support and informa- tion for Balluff products. The site offers product support, warranty information, product manuals, Support and, software updates, demos, 2.2.2 Telephone If you do not have internet or email access, you may contact our technical support.
Page 16: About The Reader
The result is a precise aiming system which contributes to low eye fatigue, yet still allows top operator efficiency. The Balluff BVS HS-Q Series family reads typical printed linear barcodes as well as complex 2D barcodes displayed on the screen of a mobile device. The BVS HS-Q readers are an elegant and robust reader family that provide fast, reliable reading.
Page 17: Using The Bluetooth Base (Cradle)
“chirp” to indicate that the cradle has detected the reader connection. The LEDs on the base will indicate the status of the battery. Before using the Battery, read “Battery Safety” in the following section. Balluff recommends annual replacement of rechargeable battery packs to ensure maximum performance.
Page 18: Battery Safety
To reinstall, charge and/or perform any other action on the battery, follow the instructions in this manual. Before installing the Battery, read “Battery Safety” on this and the following pages. Balluff recommends annual replacement of rechargeable battery packs to ensure maximum performance. Do not discharge the battery using any device except for the reader. When the battery is used in devices other than the designated product, it may dam- age the battery or reduce its life expectancy.
Page 19: Replacing The Battery Pack
US and China regulatory and others laws and regulations about the environment. Replacing the Battery Pack Before proceeding, read “Battery Safety” on the preceding pages. Balluff recom- mends annual replacement of rechargeable battery packs to ensure maximum performance. 1 Using a coin or a screwdriver, unscrew the bottom of the battery pack until it is disengaged.
Page 20 BVS HS-Q Series Standard Hand Held Barcode Reader Introduction To mount the new battery pack reverse the process: 1 Insert the top of the new pack inside the reader’s handle. 2 Rotate the battery pack downward while pressing the bottom side of the battery pack (to seat securely into the contacts springs) so that the edges of the pack and the handle board are aligned, while replacing the screw in the bottom of the handle.
Page 21: Setup
(Power Off the Terminal) to supply reader power, use the approved power supply (AC Adapter). Plug the AC Adapter barrel connector into the socket on the RS-232 cable connector and the AC Adapter plug into a standard power outlet. www.balluff.com...
Page 22 BVS HS-Q Series Standard Hand Held Barcode Reader Setup Figure 3: RS-232 Connection Figure 4: USB Connection Connect the reader to a USB port on the terminal/PC using the correct USB cable for the inter- face type you ordered. Reference Figure: USB connection.
Page 23: Cordless Models
3.4.2 Base Station 1 Remove the rubber Cable Stopper from the bottom of the Base Station. Connection and 2 Securely plug the Power Cable and Interface (I/F) Cable connectors into their respective ports Routing in the underside of the Base Station. www.balluff.com...
Page 24 BVS HS-Q Series Standard Hand Held Barcode Reader Setup Power Cable I/F Cable Cable Stopper 3 After the cables are plugged in, reinsert the rubber Cable Stopper. Cable Stopper reinserted 4 Connect to an AC Adapter, and plug the AC power cord into the (wall) outlet. Wall plug Connector I/F Cable...
Page 25: Host Connection
Security Pin is 1 Power down the host system. Enabled 2 Connect the appropriate interface cable into the Base as shown. 3 Place the reader in the Base. 4 Power up the host. The reader will link to the Base www.balluff.com...
Page 26: Linking The Reader To A Base Station
2 Scan the barcode below to make the reader visible to the host computer. Link to a PC in Server Mode 3 Use the host computer’s Bluetooth manager to “Discover new devices” and select "Balluff reader" If you receive an error message, it may be necessary to disable security on the device.
Page 27: Power Off
Some interfaces require the reader to start in the disabled state when pow- ered up. If additional reader configuration is desired while in this state, pull the trigger and hold it for five seconds. The reader will change to a state that allows programming with barcodes. www.balluff.com...
Page 28: Available Interfaces
Set USB-OEM USB-OEM Interface (can be used for OPOS/UPOS/Java- Features POS) starting on page 53 Select USB-OEM Download the correct USB Com driver from www.balluff.com KEYBOARD FEATURES HA2B,P(CR) USB Keyboard with alternate key encoding Select USB Alternate Keyboard Customizing Configuration Settings 3.6.1 Configure...
Page 29: Global Interface Features
If you want to restore the Factory Configuration for your imager, scan either the Restore USA Fac- tory Configuration barcode or the Restore EU Factory Configuration barcode below. Both labels restore the reader configuration to the factory settings, including the interface type. www.balluff.com...
Page 30 BVS HS-Q Series Standard Hand Held Barcode Reader Setup Reading either of the “Restore Factory Configuration” commands below will result in the loss of any custom configuration settings for your device. Use "Restore Custom Default Configuration" above if you want to restore your custom configuration settings.
Page 31: Configuration Using Barcodes
Additional information about many features can be found in the “Refer- ences” chapter. If you make a mistake before the last character, scan the CANCEL barcode to abort and not save the entry string. You can then start again at the begin- ning. www.balluff.com...
Page 32: Global Interface Features
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes 4 Complete the programming sequence by reading the ENTER/EXIT PROGRAMMING barcode to exit Programming Mode. For more detailed descriptions, programming information and examples for setting selected con- figuration items, see "References"...
Page 33: Rs-232 Interface
Page references are also provided for feature descriptions and programming barcodes for each parameter. A column has also been provided for recording of your preferred default settings for these same configurable features. for a listing of standard factory settings. www.balluff.com...
Page 34: Baud Rate
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Baud Rate See page 224 for information on this feature. $CR2- Baud Rate = 1200 $CR2- Baud Rate = 2400 $CR2- Baud Rate = 4800 $CR2- DEFAULT Baud Rate = 9600 $CR2-...
Page 35: Data Bits
7 Data Bits CR2- DEFAULT 8 Data Bits Stop Bits Set the number of stop bits to match host device requirements. See page 224 for more informa- tion on this feature. 2ST00(CR DEFAULT 1 Stop Bit ST01(CR 2 Stop Bits www.balluff.com...
Page 36: Parity
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Parity This feature specifies parity required for sending and receiving data. Select the parity type accord- ing to host device requirements. See page 224 for more information. CR2- DEFAULT Parity = None...
Page 37: Rs-232/Usb-Com Interfaces
“Default” column of the table below. Page references are also provided for feature descriptions and programming barcodes for each parameter. A column has also been provided for recording of your preferred default settings for these same configurable features. for a listing of standard factory settings. www.balluff.com...
Page 38: Intercharacter Delay
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Intercharacter This parameter specifies the intercharacter delay between the end of one character and the Delay beginning of the next. The delay can be set within a range of zero (0) to 990 milliseconds in 10ms increments.
Page 39: Ack Nak Options
See page 226 for more information. AE00(CR DEFAULT ACK/NAK Protocol = Disable ACK/NAK AE01(CR ACK/NAK Protocol = Enable for label transmission AE02(CR ACK/NAK Protocol = Enable for host-command acknowledge AE03(CR ACK/NAK Protocol = Enable for label transmis- sion and host-command acknowledge www.balluff.com...
Page 40: Ack Character
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes ACK Character This setting specifies an ASCII character or hex value to be used as the ACK character. ASCII characters or any hex value from 0 to 0xFF can be selected. See page 226 for more information.
Page 41: Ack Nak Timeout Value
End by reading the ENTER/EXIT barcode again. Make a mistake? Scan the CANCEL barcode to abort and not save the entry string. You can then start again at the beginning. CANCEL 01 ACK NAK Timeout value is 200ms DEFAULT www.balluff.com...
Page 42: Ack Nak Retry Count
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes ACK NAK Retry This feature specifies the number of times the reader retries a label transmission due to a retry Count condition. The selectable range is from 1 to 254 retries. A selection of 0 disables the count, and a selection of 255 specifies unlimited retries.
Page 43: Indicate Transmission Failure
8-bit data is not recognized when the option Data Bits has been set as 7 Data Bits. See page 230 for more information on setting this feature. $CR2DC Select Disable Character Setting 0x44 = Disable Character is ‘D’ DEFAULT www.balluff.com...
Page 44: Enable Character
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Enable Specifies the value of the RS-232 host command used to enable the reader. Character ASCII characters or any hex value from 0 to 0xFF can be selected. Setting to previously defined characters such as XON, XOFF, or host com- mands conflicts with normal operation of these characters.
Page 45: Keyboard Settings
A column has also been provided for recording of your preferred default settings for these same configurable features. for a listing of standard factory settings. Information about control character emulation which applies to keyboard interfaces is listed in Appendix B, Appendix E: Scancode Tables. www.balluff.com...
Page 46: Country Mode
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Country Mode This feature specifies the country/language supported by the keyboard. Several languages are supported: $CKB- DEFAULT Country Mode = U.S. $CKB- Country Mode = Belgium $CKB- Country Mode = Britain $CKB-...
Page 47 $CKB- Supports only the interfaces listed in the Coun- try Mode feature description. Country Mode = Japanese 106-key $CKB- Supports only the interfaces listed in the Country Mode feature description. Country Mode = Lithuanian $CKB- Country Mode = Norway www.balluff.com...
Page 48 BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes $CKB- Supports only the interfaces listed in the Country Mode feature description. Country Mode = Poland $CKB- Supports only the interfaces listed in the Coun- try Mode feature description. Country Mode = Portugal $CKB- Supports only the interfaces listed in the...
Page 49: Send Control Characters
Alphanumeric characters Appendix D, Use the barcodes in this appendix to enter numbers as you would Set Intercode Delay select digits/characters from a keypad. rep- resenting your desired character(s). End by reading the ENTER/EXIT barcode again. www.balluff.com...
Page 50: Caps Lock State
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Make a mistake? Scan the CANCEL barcode to abort and not save the entry string. You can then start again at the beginning. CANCEL 00 = No Wedge Intercode Delay DEFAULT Caps Lock State This option specifies the format in which the reader sends character data.
Page 51: Usb Keyboard Speed
This feature applies ONLY to the USB Keyboard interface. $CKB- DEFAULT USB Keyboard Speed = 1ms $CKB- USB Keyboard Speed = 2ms $CKB- USB Keyboard Speed = 3ms $CKB- USB Keyboard Speed = 4ms $CKB- USB Keyboard Speed = 5ms $CKB- USB Keyboard Speed = 6ms www.balluff.com...
Page 52: Usb Keyboard Numeric Keypad
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes $CKB- USB Keyboard Speed = 7ms $CKB- USB Keyboard Speed = 8ms $CKB- USB Keyboard Speed = 9ms $CKB- USB Keyboard Speed = 10ms USB Keyboard This option Controls whether numeric characters will be sent using standard keys or the numeric Numeric Keypad keypad.
Page 53: Usb-Oem Interface
Page references are also provided for feature descriptions and programming barcodes for each parameter. A column has also been provided for recording of your preferred default settings for these same configurable features. for a listing of standard factory settings. www.balluff.com...
Page 54: Usb-Oem Device Usage
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes USB-OEM The USB-OEM protocol allows for the reader to be identified as one of two different types of bar- Device Usage code readers. Depending on what other readers you may already have connected to a USB-OEM POS, you may need to change this setting to enable all devices to communicate.
Page 55: Transmit Labels In Code 39 Format
Mixed IBM Standard and Code 39 format IBC302(CR) Transmit Labels in Code 39 Format = All Code 39 Format Interface This feature provides for an interface-specific control mechanism. Options IFO101(CR) DEFAULT Obey Reader Configuration Host Commands CIFO102(CR) Ignore Reader Configuration Host Commands www.balluff.com...
Page 56: Data Format
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Configuration Using Barcodes Data Format "Global Prefix/Suffix" on page 57 "Global AIM ID" on page 58 "Label ID" on page 60 "Label ID: Pre-Loaded Sets" on page 61 "Individually Set Label ID"...
Page 57: Global Prefix/Suffix
Set Global Prefix $CLFSU Set Global Suffix Make a mistake? Scan the CANCEL barcode to abort and not save the entry string. You can then start again at the beginning. CANCEL No Global Prefix DEFAULT Global Suffix = 0x0D (CR) www.balluff.com...
Page 58: Global Aim Id
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes 4.6.2 Global AIM ID This feature enables/disables addition of AIM IDs for all symbology types. AIM label identifiers (as opposed to custom characters you select yourself as with label identifiers) can be included with readed barcode data.
Page 59 EAN8 COMPOSITE FOLLET 2OF5 I2OF5 IATA INDUSTRIAL 2OF5 INDUSTRIAL 2OF5 ISBN ISBT128 CONCAT ISSN MAXICODE MICRO QR MICRO PDF PDF417 PLESSEY POSTAL AUSTRALIAN POSTAL IMB POSTAL JAPANESE POSTAL KIX POSTAL PLANET POSTAL PORTUGAL POSTAL POSTNET BB POSTAL ROYAL MAIL www.balluff.com...
Page 60: Set Aim Id Individually For Gs1-128
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes AIM ID code AIM ID code Tag Name character ASCII value POSTAL SWEDISH POSTNET QR CODE TRIOPTIC UPCA UPCA P2 UPCA P5 UPCA COMPOSITE UPCE UPCE P2 UPCE P5 UPCE COMPOSITE Set AIM ID...
Page 61: Label Id: Pre-Loaded Sets
This option controls whether a Label ID is disabled, or sent as a prefix or suffix for a given symbol- ogy type. DCO00(CR) DEFAULT Label ID Transmission = Disable IDCO01(CR) Label ID Transmission = Enable as Prefix DCO02(CR) Label ID Transmission = Enable as Suffix www.balluff.com...
Page 62 BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes − Label ID Symbology Selection 1D Symbologies This option selects the symbology for which a Label ID is to be configured. See "Label ID" on page 60 or page 238 in “References”...
Page 63 GSI DataBar Limited Composite Label ID Character(s) $CG2ID $C4BID Set GS1 DataBar 14 Label ID Character(s) Set GTIN 2 Label ID Character(s) $C4CID $CG5ID Set GS1 DataBar 14 Composite Label ID Char- Set GTIN 5 Label ID Character(s) acter(s) www.balluff.com...
Page 64 BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes $CXBID $CGBID Set GS1 DataBar Expanded Label ID Charac- Set GTIN 8 Label ID Character(s) ter(s) $CLPID $CIAID Set IATA Industrial 2 of 5 Label ID Character(s) Set LaPoste Code 39 Label ID Character(s) $CPMID $CMSID...
Page 65 Set UPC-A P5 Label ID Character(s) $CPSID $CEBID Set Swedish Postal Code Label ID Character(s) Set UPC-E Label ID Character(s) $CCTID $CE5ID Set Trioptic Code Label ID Character(s) Set UPC-E P5 Label ID Character(s) $CABID Set UPC-A Label ID Character(s) www.balluff.com...
Page 66 BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes − Label ID Symbology Selection 2D Symbologies $CAZID $CMXID Set Maxicode Label ID Character(s) Set Aztec Label ID Character(s) $CCSID $CP4ID Set China Sensible Label ID Character(s) Set PDF 417 Label ID Character(s) $CDMID $CMIID...
Page 67: Advanced Formatting: User Label Edit
Case conversion affects ONLY readed barcode data, and does not affect Label ID, Prefix, Suffix, or other appended data. $CLF- DEFAULT Case Conversion = Disable (no case conver- sion) $CLF- Case Conversion = Convert to upper case $CLF- Case Conversion = Convert to lower case www.balluff.com...
Page 68: Character Conversion
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Character Conversion Character conversion is an eight byte configuration item. The eight bytes are 4 character pairs represented in hexadecimal ASCII values. The first character in the pair is the character that will be converted.
Page 69: Reading Parameters
"Partial Label Reading Control" on page 84 "Decode Negative Labels" on page 84 "Multiple Label Reading" on page 85 "Multiple Labels per Frame" on page 85 "Multiple Labels Ordering by Code Symbology" on page 86 "Multiple Labels Ordering by Code Length" on page 86 www.balluff.com...
Page 70: Double Read Timeout
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Double Read Double Read Timeout prevents a double read of the same label by setting the minimum time Timeout allowed between reads of labels of the same symbology and data. If the unit reads a label and sees the same label again within the specified timeout, the second read is ignored.
Page 71: Led And Beeper Indicators
This feature specifies when the reader will provide indication (beep and/or flash its green LED) upon successfully reading a barcode. $CBPIN00(CR) DEFAULT Indicate Good Read = After Decode $CBPIN01(CR) Indicate Good Read = After Transmit $CBPIN02(CR) Indicate Good Read = After CTS goes inactive then active www.balluff.com...
Page 72: Good Read Beep Type
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Good Read Beep Type Specifies whether the good read beep has a mono or bitonal beep sound. $CBP- DEFAULT Good Read Beep Type = Mono $CBP- Good Read Beep Type = Bitonal Good Read Beep Frequency Adjusts the good read beep to sound at a selectable low, medium or high frequency, selectable...
Page 73: Good Read Beep Length
Good Read Beep Length = 120 msec $CBPLE0E(CR Good Read Beep Length = 140 msec $CBPLE10(CR Good Read Beep Length = 160 msec $CBPLE12(CR Good Read Beep Length = 180 msec $CBPLE14(CR Good Read Beep Length = 200 msec www.balluff.com...
Page 74: Good Read Beep Volume
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Good Read Beep Volume Selects the beeper volume (loudness) upon a good read beep. There are three selectable volume levels. Good Read Beep Volume = Beeper Off $CBP- Good Read Beep Volume = Low $CBP-...
Page 75: Good Read Led Duration
Make a mistake? Scan the CANCEL barcode to abort and not save the entry string. You can then start again at the beginning. CANCEL 003 = Good Read LED DEFAULT stays on for 300 ms. Indicators are dimmed during sleep. www.balluff.com...
Page 76: Reading Features
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Reading Scan Mode Features Selects the reader’s scan operating mode. See page 243 in “References” for descriptions. DEFAULT Scan Mode = Trigger Single Scan Mode = Trigger Hold Multiple Scan Mode = Trigger Pulse Multiple Scan Mode = Flashing Scan Mode = Always On...
Page 77: Stand Mode Indication
Change to Always On: Automatically switches the reader to Always On mode when the reader is placed in the stand. $CSMSD00(C Do Not Change Mode $CSMSD01(CR) DEFAULT Change to Stand Mode $CSMSD02(C Change to Always On $CSMSD03(C Change to Flashing www.balluff.com...
Page 78: Pick Mode
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Pick Mode Specifies the ability of the reader to decode labels only when they are close to the center of the aiming pattern. This allows the reader to accurately target labels when they are placed close together, such as on a pick sheet.
Page 79: Stand Mode Illumination Off Time
The range for this setting is from 1 to 255 seconds in 1-second increments. See page 245 in “References” for further description of this feature. CSNET03(CR Reading Active Time = 3 seconds CSNET05(CR DEFAULT Reading Active Time = 5 seconds CSNET08(CR Reading Active Time = 8 seconds www.balluff.com...
Page 80: Stand Illumination Control
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Stand Illumination Control Controls the illumination status while the reading mode is stand mode and the reader is attempt- ing to detect objects. CSMIL00(CR) DEFAULT Stand Illumination Control = OFF CSMIL01(CR) Stand Illumination Control = ON CSMIL02(CR)
Page 81: Flash Off Time
You can then start again at the beginning. CANCEL 06 = Flash is OFF for 600ms DEFAULT Aiming Pointer Enables/disables the aiming pointer for all symbologies. $CTAAP00(CR) Aiming Pointer = Disable $CTAAP01(CR) DEFAULT Aiming Pointer = Enable www.balluff.com...
Page 82: Aiming Duration Timer
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Aiming Duration Timer Specifies the frame of time the aiming pointer remains on after decoding a label, when in trigger single mode.The range for this setting is from 1 to 255 seconds in 1-second increments. See page 246 in “References”...
Page 83: Green Spot Duration
Green Spot Duration = Medium (500 msec) $CLSSP03(CR Green Spot Duration = Long (800 msec) Mobile Phone Mode This mode is useful for reading barcodes displayed on a mobile phone. $CSNPE00(CR Mobile Phone Mode = Disable $CSNPE01(CR DEFAULT Mobile Phone Mode = Enable www.balluff.com...
Page 84: Partial Label Reading Control
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Partial Label Reading Control Enable/Disable to ignore partial labels to be read within the boundary of the field of view. IPPL00 Partial Label Reading Control = Disable IPPL01 Partial Label Reading Control = Enable Decode Negative Labels...
Page 85: Multiple Label Reading
LED indication for each code read in a frame. When Multiple Labels Mode is enabled, ISBT pairing, ABC Codabar pairing, and composites are not allowed. $CSN- DEFAULT Multiple Labels per Frame = Disable $CSN- Multiple Labels per Frame = Enable www.balluff.com...
Page 86: Multiple Labels Ordering By Code Symbology
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Multiple Labels Ordering by Code Symbology This feature allows you to specify the order multiple labels are transmitted by symbology type, when Multiple Labels per Frame is enabled. See page 249 in “References”...
Page 87: D Symbologies
3 If additional input parameters are needed, go to Appendix 18, Use the barcodes in this appendix to enter numbers as you would select digits/characters from a keypad., and scan the appropriate characters from the keypad. www.balluff.com...
Page 88: Disable All Symbologies
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Additional information about many features can be found in the “Refer- ences” chapter. If you make a mistake before the last character, scan the CANCEL barcode to abort and not save the entry string.
Page 89: Code Ean/Upc
This feature is used to control the reader’s method of processing coupon labels. CPLC00(CR Coupon Control = Allow all coupon barcodes to be decoded CPLC01(CR DEFAULT Coupon Control = Enable only UPCA coupon decoding CPLC02(CR Coupon Control = Enable only GS1 DataBar™ coupon decoding www.balluff.com...
Page 90: Upc-A
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes UPC-A The following options apply to the UPC-A symbology. UPC-A Enable/Disable When disabled, the reader will not read UPC-A barcodes. ABEN00(CR UPC-A = Disable ABEN01(CR DEFAULT UPC-A = Enable UPC-A Check Character Transmission Enable this option to transmit the check character along with UPC-A barcode data.
Page 91: Expand Upc-A To Ean-13
UPC-A to EAN-13 = Don’t Expand CAB3B01(CR UPC-A to EAN-13 = Expand UPC-A Number System Character Transmission This feature enables/disables transmission of the UPC-A number system character. ABNS00(C UPC-A Number System Character = Do not transmit CABNS01(C DEFAULT UPC-A Number System Character = Transmit www.balluff.com...
Page 92: Upc-A 2D Component
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes UPC-A 2D Component This feature enables/disables a requirement that a 2D label component be decoded when a base label of this symbology is decoded. AB2D00(CR DEFAULT EAN-13 2D Component = Disable (2D component not required) AB2D01(CR...
Page 93: Upc-E Check Character Transmission
This feature enables/disables a requirement that a 2D label component be decoded when a base label for this symbology is decoded. EB2D00(CR DEFAULT UPC-E 2D Component = Disable (2D component not required) CEB2D01(CR UPC-E 2D Component = 2D component must be decoded www.balluff.com...
Page 94: Expand Upc-E To Ean-13
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Expand UPC-E to EAN-13 Expands UPC-E data to the EAN-13 data format. Selecting this feature also changes the symbol- ogy ID to match those required for EAN-13. EB3B00(CR DEFAULT UPC-E to EAN-13 = Don’t Expand...
Page 95: Upc-E Number System Character Transmission
GTIN 14-character format. If add-on information is present on the base label prior to the conversion taking place, the add-on information will be appended to the converted GTIN label. CGBEN00(C DEFAULT GTIN Formatting = Disable CGBEN01(C GTIN Formatting = Enable www.balluff.com...
Page 96: Ean 13 Enable/Disable
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes EAN 13 (Jan 13) The following options apply to the EAN 13 (Jan 13) symbology. EAN 13 Enable/Disable When disabled, the reader will not read EAN 13/JAN 13 barcodes. 3BEN00(CR EAN 13 = Disable C3BEN01(CR...
Page 97: Ean-13 Flag 1 Character
EAN-13 Flag 1 Char = Transmit EAN-13 ISBN Conversion This option enables/disables conversion of EAN 13/JAN 13 Bookland labels starting with 978 to ISBN labels. 3BIS00(CR) DEFAULT EAN-13 ISBN Conversion = Disable C3BIS01(CR) EAN-13 ISBN Conversion = Convert to ISBN www.balluff.com...
Page 98: Ean-13 2D Component
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes EAN-13 2D Component This feature enables/disables a requirement that a 2D label component be decoded when a base label of this symbology is decoded. 3B2D00(CR DEFAULT EAN-13 2D Component = Disable (2D component not required) C3B2D01(CR...
Page 99: Ean 8 Enable/Disable
EAN 8 = Enable EAN 8 Check Character Transmission Enable this option to transmit the check character along with EAN 8 barcode data. 8BCT00(CR EAN 8 Check Character Transmission = Don’t Send 8BCT01(CR DEFAULT EAN 8 Check Character Transmission = Send www.balluff.com...
Page 100: Ean 8 2D Component
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Expand EAN 8 to EAN 13 Enable this option to expand EAN 8/JAN 8 labels to EAN 13/JAN 13. 8B3B00(CR DEFAULT Expand EAN 8 to EAN 13 = Disable C8B3B01(CR Expand EAN 8 to EAN 13 = Enable EAN 8 2D Component...
Page 101: Upc/Ean Global Settings
Price Weight Check = Disabled $CPW- Price Weight Check = 4-digit price-weight check $CPW- Price Weight Check = 5-digit price-weight check $CPW- Price Weight Check = European 4-digit price-weight check $CPW- Price Weight Check = European 5-digit price-weight check www.balluff.com...
Page 102: Upc/Ean Quiet Zones
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes UPC/EAN Quiet Zones This feature specifies the number of quiet zones for UPC/EAN labels. Quiet zones are blank areas at the ends of a barcode, typically 10 times the width of the narrowest bar or space in the label. The property applies to all EAN-UPC symbologies globally and to the ADDONs.
Page 103: Add-Ons
Optional Add-Ons = Disable P2 ADO201(CR Optional Add-Ons = Enable P2 ADO500(CR DEFAULT Optional Add-Ons = Disable P5 ADO501(CR Optional Add-Ons = Enable P5 Cordless models only: ADO800(CR DEFAULT Optional Add-Ons = Disable GS1-128 ADO801(CR Optional Add-Ons = Enable GS1-128 www.balluff.com...
Page 104: Optional Add-On Timer
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Optional Add-On Timer This option sets the time the reader will look for an add-on when an add-on fragment has been seen and optional add-ons are enabled. (Also see "Optional GS1-128 Add-On Timer"...
Page 105 Configuration Using Barcodes $CAD- Optional Add-on Timer = 60ms $CAD- DEFAULT Optional Add-on Timer = 70ms $CAD- Optional Add-on Timer = 100ms $CAD- Optional Add-on Timer = 120ms $CAD- Optional Add-on Timer = 140ms $CAD- Optional Add-on Timer = 160ms www.balluff.com...
Page 106: Optional Gs1-128 Add-On Timer
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Optional GS1-128 Add-On Timer This option sets the timer expiration value to read the added part after reading the linear EAN/ UPC part. For UPC/EAN add-ons other than those of that type, see "Optional Add-On Timer"...
Page 107 Optional GS1-128 Add-On Timer = 60ms ADUT07(CR Optional GS1-128 Add-On Timer = 70ms CADUT0A(C Optional GS1-128 Add-On Timer = 100ms CADUT0C(C Optional GS1-128 Add-On Timer = 120ms ADUT0E(CR Optional GS1-128 Add-On Timer = 140ms ADUT10(CR Optional GS1-128 Add-On Timer = 160ms www.balluff.com...
Page 108 BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes ADUT12(CR Optional GS1-128 Add-On Timer = 180ms CADUT14(CR Optional GS1-128 Add-On Timer = 200ms ADUT16(CR Optional GS1-128 Add-On Timer = 220ms ADUT18(CR Optional GS1-128 Add-On Timer = 240ms CADUT1A(C Optional GS1-128 Add-On Timer = 260ms CADUT1C(C...
Page 109: Code 39 Enable/Disable
Code 39 Check Character Calculation = Calculate Std Check C3CC02(C Code 39 Check Character Calculation = Calculate Mod 7 Check CC3CC04(C Code 39 Check Character Calculation = Enable Italian Post Check CC3CC08(C Code 39 Check Character Calculation = Enable Daimler Chrysler Check www.balluff.com...
Page 110: Code 39 Check Character Transmission
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Code 39 Check Character Transmission Enable this option to transmit the check character along with Code 39 barcode data. C3CT00(CR Code 39 Check Character Transmission = Don’t Send C3CT01(CR DEFAULT...
Page 111: Code 39 Quiet Zones
Variable Length: For variable length decoding, a minimum and maximum length may be set. Fixed Length: For fixed length decoding, two different lengths may be set. C3LC00(CR DEFAULT Code 39 Length Control = Variable Length C3LC01(CR Code 39 Length Control = Fixed Length www.balluff.com...
Page 112: Code 39 Set Length 1
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Code 39 Set Length 1 This feature specifies one of the barcode lengths for Code 39 Length Control on page 111. Length 1 is the minimum label length if in Variable Length: For variable length decoding, a mini- mum and maximum length may be set.
Page 113: Code 39 Set Length 2
$CC3L2 Select Code 39 Length 2 Setting Make a mistake? Scan the CANCEL barcode to abort and not save the entry string. You can then start again at the beginning. CANCEL 50 = Length 2 is 50 Characters DEFAULT www.balluff.com...
Page 114: Trioptic Code
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Trioptic Code The following options apply to the Trioptic symbology. Trioptic Code Enable/Disable CTEN00(CR DEFAULT Trioptic Code = Disable CTEN01(CR Trioptic Code = Enable The following options apply to the Code 32 (Italian Pharmaceutical Code) symbology. Code 32 (Ital Pharmaceutical Code 32 Enable/Disable...
Page 115: Code 32 Check Char Transmission
Code 32 Check Character Transmission = Send Code 32 Start/Stop Character Transmission This option enables/disables transmission of Code 32 start and stop characters P3SS00(CR DEFAULT Code 32 Start/Stop Character Transmission = Don’t Transmit P3SS01(CR Code 32 Start/Stop Character Transmission = Transmit www.balluff.com...
Page 116: Code 39 Cip (French Pharmaceutical)
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Code 39 CIP The following options apply to the Code 39 CIP symbology. (French Code 39 CIP Enable/Disable Pharmaceutical) Enables/Disables ability of the reader to decode Code 39 CIP labels. CCCEN00(C DEFAULT Code 39 CIP = Disable...
Page 117: Code 39 Laposte
Code 39 PZN The following options apply to the Code 39 PZN symbology. Code 39 PZN Enable/Disable Enables/disables the ability of the reader to decode Code39 PZN labels. ZEN00(CR) DEFAULT Code 39 PZN = Disable PZEN01(CR) Code 39 PZN = Enable www.balluff.com...
Page 118: Code 128
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Code 128 The following options apply to the Code 128 symbology. Code 128 Enable/Disable When disabled, the reader will not read Code 128 barcodes. C8EN00(CR Code 128 = Disable CC8EN01(CR DEFAULT Code 128 = Enable...
Page 119: Code 128 Function Character Transmission
10 times the width of the narrowest bar or space in the label. $CC8- Code 128 Quiet Zones = Quiet Zones on two sides $CC8- DEFAULT Code 128 Quiet Zones = Small Quiet Zones on two sides www.balluff.com...
Page 120: Code 128 Length Control
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Code 128 Length Control This feature specifies either variable length decoding or fixed length decoding for the Code 128 symbology. See page 231 for more information. C8LC00(CR DEFAULT Code 128 Length Control = Variable Length...
Page 121: Code 128 Set Length 1
Select Code 128 Set Length 1 Setting Make a mistake? Scan the CANCEL barcode to abort and not save the entry string. You can then start again at the beginning. CANCEL 01 = Length 1 is 1 Character DEFAULT www.balluff.com...
Page 122: Code 128 Set Length 2
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Code 128 Set Length 2 This feature specifies one of the barcode lengths for Code 128 Length Control on page 120. Length 2 is the maximum label length if in Variable Length: For variable length decoding, a mini- mum and maximum length may be set.
Page 123: Gs1-128
GS1-128 = Do not transmit GS1-128 labels GS1-128 2D Component This feature enables/disables a requirement that a 2D label component be decoded when a base label of this symbology is decoded. U82D00(CR DEFAULT GS1-128 2D Component = Disable CU82D01(CR GS1-128 2D Component = Enable www.balluff.com...
Page 124: Code Isbt 128
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Code ISBT 128 The following options apply to the ISBT 128 symbology. ISBT 128 Concatenation Use this option to enable/disable ISBT128 concatenation of 2 labels. I8CE00(CR) DEFAULT ISBN 128 Concatenation = Disable CI8CE01(CR)
Page 125: Isbt 128 Concatenation Mode
Specifies the concatenation mode between Static and Dynamic. This option is only valid when ISBT 128 Concatenation is enabled (see "ISBT 128 Concatenation" on page 124). I8CM00CR) DEFAULT ISBT 128 Concatenation Mode = Static 8CM01CR) ISBT 128 Concatenation Mode = Dynamic www.balluff.com...
Page 126: Isbt 128 Dynamic Concatenation Timeout
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes ISBT 128 Dynamic Concatenation Timeout Specifies the timeout used by the ISBT 128 Dynamic Concatenation Mode. CI8DT05(CR) ISBT 128 Dynamic Concatenation Timeout = 50 msec $CI8DT0A(CR) ISBT 128 Dynamic Concatenation Timeout = 100 msec DEFAULT...
Page 127: I 2 Of 5 Enable/Disable
The following options apply to the I 2 of 5 symbology. 5 (I 2 of 5) I 2 of 5 Enable/Disable When disabled, the reader will not read I 2 of 5 barcodes. I2EN00(CR) DEFAULT I 2 of 5 = Disable CI2EN01(CR) I 2 of 5 = Enable www.balluff.com...
Page 128: I 2 Of 5 Check Character Calculation
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes I 2 of 5 Check Character Calculation This option enables/disables calculation and verification of an optional I 2 of 5 check character. I2CC00(CR) DEFAULT I 2 of 5 Check Character Calculation = Disable CI2CC01(CR) I 2 of 5 Check Character Calculation = Check Standard (Modulo 10)
Page 129: I 2 Of 5 Check Character Transmission
Length 1. See page 232 for detailed instructions on setting this feature. 2 of 5 Length 1 Setting STEP ACTION EXAMPLES Examples Desired Setting 2 Characters 6 Characters 14 Characters 50 Characters Pad with leading zeroes to yield two digits www.balluff.com...
Page 130 BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes STEP ACTION EXAMPLES Desired Setting 2 Characters 6 Characters 14 Characters 50 Characters Scan ENTER/EXIT PROGRAMMING MODE Scan SELECT I 2 of 5 LENGTH 1 SETTING Scan Two Characters From...
Page 131 Select I 2 of 5 Length 2 Setting Make a mistake? Scan the CANCEL barcode to abort and not save the entry string. You can then start again at the beginning. CANCEL 50 = Length 2 is 50 Characters DEFAULT www.balluff.com...
Page 132: Interleaved 2 Of 5 Cip Hr
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Interleaved 2 of The following options apply to the Interleaved 2 of 5 CIP HR symbology. 5 CIP HR Interleaved 2 of 5 CIP HR Enable/Disable Enables/Disables ability of reader to decode Interleaved 2 of 5 CIP HR labels.
Page 133: Standard 2 Of
Standard 2 of 5 Check Character Calculation This option enables/disables calculation and verification of an optional Standard 2 of 5 check character. S2CC00(CR DEFAULT Standard 2 of 5 Check Character Calculation = Disable S2CC01(CR Standard 2 of 5 Check Character Calculation = Enable www.balluff.com...
Page 134: Standard 2 Of 5 Check Character Transmission
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Standard 2 of 5 Check Character Transmission This feature enables/disables transmission of an optional Standard 2 of 5 check character. S2CT00(CR Standard 2 of 5 Check Character Transmis- sion = Don’t Send S2CT01(CR DEFAULT...
Page 135: Standard 2 Of 5 Set Length 1
Select Standard 2 of 5 Length 1 Setting Make a mistake? Scan the CANCEL barcode to abort and not save the entry string. You can then start again at the beginning. CANCEL 08 = Length 1 is 8 Characters DEFAULT www.balluff.com...
Page 136: Standard 2 Of 5 Set Length 2
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Standard 2 of 5 This feature specifies one of the barcode lengths for Standard 2 of 5 Length Control on page 134. Set Length 2 Length 2 is the maximum label length if in Variable Length: For variable length decoding, a mini- mum and maximum length may be set.
Page 137: Industrial 2 Of 5
Industrial 2 of 5 Check Character Calculation Enables/Disables calculation and verification of an optional Industrial 2 of 5 check character. U2CC00(C DEFAULT Industrial 2 of 5 Check Character Calculation = Disable CU2CC01(C Industrial 2 of 5 Check Character Calculation = Enable www.balluff.com...
Page 138: Industrial 2 Of 5 Check Character Transmission
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Industrial 2 of 5 Check Character Transmission Enables/disables transmission of an Industrial 2 of 5 check character. U2CT00(CR Industrial 2 of 5 Check Character Transmis- sion = Disable U2CT01(CR DEFAULT Industrial 2 of 5 Check Character Transmission...
Page 139: Industrial 2 Of 5 Set Length 1
Select Industrial 2 of 5 Set Length 1 Setting Make a mistake? Scan the CANCEL barcode to abort and not save the entry string. You can then start again at the beginning. CANCEL 01 = Length 1 is 1 Character DEFAULT www.balluff.com...
Page 140: Industrial 2 Of 5 Set Length 2
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Industrial 2 of 5 Set Length 2 This feature specifies one of the barcode lengths for Industrial 2 of 5 Length Control on page 138. Length 2 is the maximum label length if in Variable Length: For variable length decoding, a mini- mum and maximum length may be set.
Page 141: Code Iata
IATA = Disable CIAEN01(CR) IATA = Enable IATA Check Character Transmission Enables/Disables calculation and verification of an optional Industrial 2 of 5 check character. CIACT00(CR) IATA Check Character Transmission = Disable CIACT01(CR) DEFAULT IATA Check Character Transmission = Enable www.balluff.com...
Page 142: Codabar
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Codabar The following options apply to the Codabar symbology. Codabar Enable/Disable When disabled, the reader will not read Codabar barcodes. CCBEN00(C DEFAULT Codabar = Disable CCBEN01(C Codabar = Enable Codabar Check Character Calculation Enable this option to enables/disables calculation and verification of an optional Codabar check...
Page 143: Codabar Check Character Transmission
DEFAULT Codabar Check Character Transmission = Send Codabar Start/Stop Character Transmission Enable this option to enable/disable transmission of Codabar start and stop characters CCBSS00(C Codabar Start/Stop Character Transmission = Don’t Transmit CCBSS01(C DEFAULT Codabar Start/Stop Character Transmission = Transmit www.balluff.com...
Page 144: Codabar Start/Stop Character Set
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Codabar Start/Stop Character Set This option specifies the format of transmitted Codabar start/stop characters $CCB- Codabar Check Character Set = ABCD/TN*E $CCB- Codabar Check Character Set = ABCD/ABCD $CCB- Codabar Check Character Set = abcd/tn*e $CCB-...
Page 145: Codabar Quiet Zones
Variable Length: For variable length decoding, a minimum and maximum length may be set. Fixed Length: For fixed length decoding, two different lengths may be set. CBLC00(CR DEFAULT Codabar Length Control = Variable Length CBLC01(CR Codabar Length Control = Fixed Length www.balluff.com...
Page 146: Codabar Set Length 1
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Codabar Set Length 1 This feature specifies one of the barcode lengths for Codabar Length Control on page 145Cod- abar Length Control on page 145. Length 1 is the minimum label length if in Variable Length: For variable length decoding, a minimum and maximum length may be set.
Page 147: Codabar Set Length 2
Scan ENTER/EXIT PROGRAMMING MODE $CCBL2 Select Codabar Length 2 Setting Make a mistake? Scan the CANCEL barcode to abort and not save the entry string. You can then start again at the beginning. CANCEL 50 = Length 2 is 50 Characters DEFAULT www.balluff.com...
Page 148: Abc Codabar
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes ABC Codabar The following options apply to the ABC Codabar symbology. ABC Codabar Enable/Disable Enables/Disables ability of reader to decode ABC Codabar labels. CCBAB00(C DEFAULT ABC Codabar = Disable CCBAB01(C ABC Codabar = Enable ABC Codabar Concatenation Mode...
Page 149: Abc Codabar Dynamic Concatenation Timeout
$CCB- DEFAULT ABC Codabar Dynamic Concatenation Time- out = 200 msec $CCB- ABC Codabar Dynamic Concatenation Timeout = 500 msec $CCB- ABC Codabar Dynamic Concatenation Time- out = 750 msec $CCB- ABC Codabar Dynamic Concatenation Timeout = 1 Second www.balluff.com...
Page 150: Abc Codabar Force Concatenation
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes ABC Codabar Force Concatenation Forces labels starting or ending with D to be concatenated. $CCB- DEFAULT ABC Codabar Force Concatenation = Disable $CCB- ABC Codabar Force Concatenation = Enable...
Page 151: Code 11 Enable/Disable
This option enables/disables calculation and verification of optional Code 11 check character. CC1CC00(C Code 11 Check Character Calculation = Disable CC1CC01(C Code 11 Check Character Calculation = Check C CC1CC02(C Code 11 Check Character Calculation = Check K CC1CC03(C DEFAULT Code 11 Check Character Calculation = Check C and K www.balluff.com...
Page 152: Code 11 Check Character Transmission
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Code 11 Check Character Transmission This feature enables/disables transmission of an optional Code 11 check character. C1CT00(CR Code 11 Check Character Transmission = Don’t Send CC1CT01(CR DEFAULT Code 11 Check Character Transmission = Send Code 11 Length Control...
Page 153: Code 11 Set Length 1
Select Code 11 Set Length 1 Setting Make a mistake? Scan the CANCEL barcode to abort and not save the entry string. You can then start again at the beginning. CANCEL 04 = Length 1 is 4 Characters DEFAULT www.balluff.com...
Page 154 BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Code 11 Set Length 2 This feature specifies one of the barcode lengths for Code 11 Length Control on page 152. Length 2 is the maximum label length if in Variable Length: For variable length decoding, a mini- mum and maximum length may be set.
Page 155: Gs1 Databar™ Omnidirectional
GS1 DataBar™ Omnidirectional = Enable GS1 DataBar™ Omnidirectional GS1-128 Emulation When enabled, GS1 DataBar™ Omnidirectional barcodes will be translated to the GS1-128 label data format. 4BU800(CR DEFAULT GS1 DataBar™ Omnidirectional GS1-128 Emulation = Disable C4BU801(CR GS1 DataBar™ Omnidirectional GS1-128 Emu- lation = Enable www.balluff.com...
Page 156: Gs1 Databar™ Omnidirectional 2D Component
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes GS1 DataBar™ Omnidirectional 2D Component This feature enables/disables a requirement that a 2D label component be decoded when a base label for this symbology is decoded. 4B2D00(CR DEFAULT GS1 DataBar™...
Page 157: Gs1 Databar™ Expanded
GS1 DataBar™ Expanded = Enable GS1 DataBar™ Expanded GS1-128 Emulation When enabled, GS1 DataBar™ Expanded barcodes will be translated to the GS1-128 label data format. XBU800(CR DEFAULT GS1 DataBar™ Expanded GS1-128 Emula- tion = Disable XBU801(CR GS1 DataBar™ Expanded GS1-128 Emulation = Enable www.balluff.com...
Page 158: Gs1 Databar™ Expanded 2D Component
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes GS1 DataBar™ Expanded 2D Component This feature enables/disables a requirement that a 2D label component be decoded when a base label of this symbology is decoded. XB2D00(CR DEFAULT GS1 DataBar™...
Page 159: Gs1 Databar™ Expanded Length Control
Variable Length: For variable-length decoding, a minimum length may be set. Fixed Length: For fixed-length decoding, two different lengths may be set. XBLC00(CR DEFAULT GS1 DataBar™ Expanded Length Control = Variable Length XBLC01(CR GS1 DataBar™ Expanded Length Control = Fixed Length www.balluff.com...
Page 160: Gs1 Databar™ Expanded Set Length 1
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes GS1 DataBar™ Expanded Set Length 1 This feature specifies one of the barcode lengths for GS1 DataBar™ Expanded Length Control on page 159. Length 1 is the minimum label length if in Variable Length: For variable length decod- ing, a minimum and maximum length may be set.
Page 161: Gs1 Databar™ Expanded Set Length 2
Select GS1 DataBar™ Expanded Set Length 2 Setting Make a mistake? Scan the CANCEL barcode to abort and not save the entry string. You can then start again at the beginning. CANCEL 74 = Length 2 is 74 Characters DEFAULT www.balluff.com...
Page 162: Gs1 Databar™ Limited
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes GS1 DataBar™ The following options apply to the GS1 DataBar™ Limited (formerly RSS Limited) symbology. Limited GS1 DataBar™ Limited Enable/Disable When disabled, the reader will not read GS1 DataBar™ Limited barcodes. LBEN00(CR DEFAULT GS1 DataBar™...
Page 163: Gs1 Databar™ Limited 2D Component
2D component must be decoded Code 93 The following options apply to the Code 93 symbology. Code 93 Enable/Disable Enables/Disables ability of reader to decode Code 93 labels. C9EN00(CR DEFAULT Code 93 = Disable C9EN01(CR Code 93 = Enable www.balluff.com...
Page 164: Code 93 Check Character Calculation
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Code 93 Check Character Calculation Enables/disables calculation and verification of an optional Code 93 check character. CC9CC00(C Code 93 Check Character Calculation = Disable CC9CC01(C Code 93 Check Character Calculation = Enable Check C CC9CC02(C Code 93 Check Character Calculation =...
Page 165: Code 93 Length Control
Variable Length: For variable length decoding, a minimum and maximum length may be set. Fixed Length: For fixed length decoding, two different lengths may be set. C9LC00(CR DEFAULT Code 93 Length Control = Variable Length CC9LC01(CR Code 93 = Fixed Length www.balluff.com...
Page 166: Code 93 Set Length 1
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Code 93 Set Length 1 Specifies one of the barcode lengths for Code 93 Length Control on page 165. Length 1 is the minimum label length if in Variable Length: For variable length decoding, a minimum and maxi- mum length may be set.
Page 167: Code 93 Set Length 2
$CC9L2 Select Code 93 Length 2 Setting Make a mistake? Scan the CANCEL barcode to abort and not save the entry string. You can then start again at the beginning. CANCEL 50 = Length 2 is 50 Characters DEFAULT www.balluff.com...
Page 168: Code 93 Quiet Zones
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Code 93 Quiet Zones Enables/disables quiet zones for Code 93. $CC9- Code 93 Quiet Zones = Quiet Zones on two sides $CC9- DEFAULT Code 93 Quiet Zones = Small Quiet Zones on two sides The following options apply to the MSI symbology.
Page 169: Msi Check Character Calculation
MSI Check Character Calculation = Enable Mod11/10 CMSCC03(C MSI Check Character Calculation = Enable Mod10/10 MSI Check Character Transmission Enables/disables transmission of an MSI check character. CMSCT00(C MSI Check Character Transmission = Disable CMSCT01(C DEFAULT MSI Check Character Transmission = Enable www.balluff.com...
Page 170: Msi Length Control
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes MSI Length Control This feature specifies either variable length decoding or fixed length decoding for the MSI symbol- ogy. Variable Length: For variable length decoding, a minimum and maximum length may be set. Fixed Length: For fixed length decoding, two different lengths may be set.
Page 171: Msi Set Length 1
$CMSL1 Select MSI Set Length 1 Setting Make a mistake? Scan the CANCEL barcode to abort and not save the entry string. You can then start again at the beginning. CANCEL 01 = Length 1 is 1 Character DEFAULT www.balluff.com...
Page 172: Msi Set Length 2
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes MSI Set Length 2 This feature specifies one of the barcode lengths for MSI Length Control on page 170. Length 2 is the maximum label length if in Variable Length: For variable length decoding, a minimum and maximum length may be set.
Page 173: Plessey
PLCC01(CR DEFAULT Plessey Check Character Calculation = Enable Plessey std. check char. verification PLCC02(CR Plessey Check Character Calculation = Enable Anker check char. verification PLCC03(CR Plessey Check Character Calculation = Enable Plessey std. and Anker check char veri- fication www.balluff.com...
Page 174: Plessey Check Character Transmission
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Plessey Check Character Transmission Enables/disables transmission of an MSI check character. PLCT00(CR Plessey Check Character Transmission = Disable CPLCT01(CR DEFAULT Plessey Check Character Transmission = Enable Plessey Length Control This feature specifies either variable length decoding or fixed length decoding for the Plessey symbology.
Page 175: Plessey Set Length 1
$CPLL1 Select Plessey Set Length 1 Setting Make a mistake? Scan the CANCEL barcode to abort and not save the entry string. You can then start again at the beginning. CANCEL 01 = Length 1 is 1 Character DEFAULT www.balluff.com...
Page 176: Plessey Set Length 2
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Plessey Set Length 2 This feature specifies one of the barcode lengths for Plessey Length Control on page 174. Length 2 is the maximum label length if in Variable Length: For variable length decoding, a minimum and maximum length may be set.
Page 177: D Symbologies
If you make a mistake before the last character, scan the CANCEL barcode to abort and not save the entry string. You can then start again at the beginning. Complete the programming sequence by reading the ENTER/EXIT PROGRAMMING barcode to exit Programming Mode. www.balluff.com...
Page 178: D Maximum Decoding Time
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes 2D Maximum This feature specifies the maximum amount of time the software will spend attempting to decode Decoding Time a 2D label. The selectable range is 10 milliseconds to 2.55 milliseconds. $CDE- 2D Maximum Decoding Time = 100 msec $CDE-...
Page 179: D Structured Append
AIM Specification: Data Matrix, QR, MicroQR, Aztec and Chinese Sensible Code. To decode all symbologies, including linear symbologies, refer to "Decode Negative Labels" on page IPNR00(CR) DEFAULT Normal/Inverse Symbol Control = Normal CIPNR01(CR) Normal/Inverse Symbol Control = Inverse PNR02(CR) Normal/Inverse Symbol Control = Both Normal and Inverse www.balluff.com...
Page 180: Symbology Selection
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes 4.9.2 Symbology Selection 4.9.3 Aztec Code Aztec Code Enables/disables the ability of the reader to decode Aztec Code labels. Enable / Disable AZEN00(CR DEFAULT Aztec Code = Disable CAZEN01(CR Aztec Code = Enable Aztec Code...
Page 181 Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Make a mistake? Scan the CANCEL barcode to abort and not save the entry string. You can then start again at the beginning. CANCEL 0001 = Length 1 is 1 Character DEFAULT www.balluff.com...
Page 182: Aztec Code Set Length 2
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Aztec Code Set Length 2 This feature specifies one of the barcode lengths for Aztec Code Length Control on page 180. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.
Page 183: China Sensible Code
Variable Length: For variable length decoding, a minimum and maximum length may be set. Control Fixed Length: For fixed length decoding, two different lengths may be set. CSLC00(CR DEFAULT China Sensible Code Length Control = Variable Length CCSLC01(CR China Sensible Code Length Control = Fixed Length www.balluff.com...
Page 184: China Sensible Code Set Length 1
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes China Sensible Code Set Length 1 Specifies one of the barcode lengths for China Sensible Code Length Control on page 183. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.
Page 185: China Sensible Code Set Length 2
End by reading the ENTER/EXIT barcode again. Make a mistake? Scan the CANCEL barcode to abort and not save the entry string. You can then start again at the beginning. CANCEL Length 2 is 7,827 Characters DEFAULT www.balluff.com...
Page 186: Data Matrix
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes 4.9.5 Data Matrix Data Matrix Enables/disables ability of reader to decode Data Matrix labels. Enable / Disable CDMEN00(C Data Matrix = Disable CDMEN01(C DEFAULT Data Matrix = Enable Data Matrix Specifies the options available when reading Data Matrix with different form factors.
Page 187: Data Matrix Length Control
End by reading the ENTER/EXIT barcode again. Make a mistake? Scan the CANCEL barcode to abort and not save the entry string. You can then start again at the beginning. CANCEL 0001 = Length 1 is 1 Character DEFAULT www.balluff.com...
Page 188: Data Matrix Set Length 2
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Data Matrix Set Length 2 This feature specifies one of the barcode lengths for Data Matrix Length Control on page 187. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.
Page 189: Maxicode
Maxicode = Disable $CMX- Maxicode = Enable Maxicode Enables/disables the transmission of only the Primary Message when the Secondary Message is Primary not readable. Message Transmission MXPT00(CR DEFAULT Maxicode Primary Message Transmission = Disable MXPT01(CR Maxicode Primary Message Transmission = Enable www.balluff.com...
Page 190: Maxicode Length Control
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Maxicode This feature specifies either variable length decoding or fixed length decoding for this symbology. Length Control Variable Length: For variable length decoding, a minimum and maximum length may be set. Fixed Length: For fixed length decoding, two different lengths may be set.
Page 191: Maxicode Set Length 2
End by reading the ENTER/EXIT barcode again. Make a mistake? Scan the CANCEL barcode to abort and not save the entry string. You can then start again at the beginning. CANCEL Length 2 is 0145 Characters DEFAULT www.balluff.com...
Page 192: Pdf417
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes 4.9.7 PDF417 PDF417 Enable / Enables/disables the ability of the reader to decode PDF417 labels. Disable P4EN00(CR PDF417 = Disable CP4EN01(CR DEFAULT PDF417 = Enable PDF417 Length This feature specifies either variable length decoding or fixed length decoding for this symbology.
Page 193: Pdf417 Set Length 1
End by reading the ENTER/EXIT barcode again. Make a mistake? Scan the CANCEL barcode to abort and not save the entry string. You can then start again at the beginning. CANCEL 0001 = Length 1 is 1 Character DEFAULT www.balluff.com...
Page 194: Pdf417 Set Length 2
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes PDF417 Set Length 2 This feature specifies one of the barcode lengths for PDF417 Length Control on page 192. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.
Page 195: Micro Pdf417
- Code 128 / EAN128 AIM Id and label type MIU800(CR) DEFAULT Micro PDF417 Code 128 GS1-128 Emulation = Micro PDF AIM ID and label type CMIU801(CR) Micro PDF417 Code 128 GS1-128 Emulation = Code 128 / EAN128 AIM ID and label type www.balluff.com...
Page 196: Micro Pdf417 Length Control
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Micro PDF417 This feature specifies either variable length decoding or fixed length decoding for this symbology. Length Control Variable Length: For variable length decoding, a minimum and maximum length may be set. Fixed Length: For fixed length decoding, two different lengths may be set.
Page 197: Micro Pdf417 Set Length 2
End by reading the ENTER/EXIT barcode again. Make a mistake? Scan the CANCEL barcode to abort and not save the entry string. You can then start again at the beginning. CANCEL Length 2 is 0366 Characters DEFAULT www.balluff.com...
Page 198: Qr Code Enable / Disable
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes 4.9.9 QR Code QR Code Enable Enables/disables the ability of the reader to decode QR Code labels / Disable CQREN00(C QR Code = Disable CQREN01(C DEFAULT QR Code = Enable QR Code Length This feature specifies either variable length decoding or fixed length decoding for this symbology.
Page 199: Qr Code Set Length 1
End by reading the ENTER/EXIT barcode again. Make a mistake? Scan the CANCEL barcode to abort and not save the entry string. You can then start again at the beginning. CANCEL 0001 = Length 1 is 1 Character DEFAULT www.balluff.com...
Page 200: Qr Code Set Length 2
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes QR Code Set Length 2 This feature specifies one of the barcode lengths for QR Code Length Control on page 198. Length 2 is the maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode.
Page 201: Micro Qr Code
Variable Length: For variable length decoding, a minimum and maximum length may be set. Fixed Length: For fixed length decoding, two different lengths may be set. MQLC00(C DEFAULT Micro QR Code Length Control = Variable Length CMQLC01(C Micro QR Code Length Control = Fixed Length www.balluff.com...
Page 202: Micro Qr Code Set Length 1
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Micro QR Code Set Length 1 Specifies one of the barcode lengths for Micro QR Code Length Control on page 201. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode.
Page 203: Micro Qr Code Set Length 2
End by reading the ENTER/EXIT barcode again. Make a mistake? Scan the CANCEL barcode to abort and not save the entry string. You can then start again at the beginning. CANCEL Length 2 is 0035 Characters DEFAULT www.balluff.com...
Page 204: Ucc Composite
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes 4.9.11UCC Composite UCC Composite Enables/disables the ability of the reader to decode the stacked part of a UCC Composite label. Enable / Disable This feature is not effective when Global AIM IDs are enabled (see "Global AIM ID"...
Page 205: Ucc Optional Composite Timer
UCC Optional Composite Timer = Timer Disabled CCMOT01(C UCC Optional Composite Timer = 100msec CMOT02(C UCC Optional Composite Timer = 200msec CCMOT03(C UCC Optional Composite Timer = 300msec CMOT04(C UCC Optional Composite Timer = 400msec CCMOT05(C UCC Optional Composite Timer = 500msec www.balluff.com...
Page 206: Postal Code Selection
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes 4.9.12Postal Code Enables/disables the ability of the reader to decode labels of a specific postal symbology. Selection - Disable All Postal Codes - Australia Post - Postnet - Japan Post - Planet - IMB...
Page 207: Postnet Bb Control
Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Postnet BB Controls the ability of the reader to decode B and B' fields of Postnet labels. Control CPOBB00(C DEFAULT Postnet BB Control = Disable CPOBB01(C Postnet BB Control = Enable www.balluff.com...
Page 208: Wireless Features
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Configuration Using Barcodes 4.10 WIRELESS This section provides options and programming related to the reader’s wireless communication FEATURES features. Reference Appendix 16, The most common configuration settings are listed in the “Default”...
Page 209: Wireless Beeper Features
Beep Frequency Adjusts radio-specific beep indications to sound at a low, medium or high frequency, selectable from the list below (controls the beeper’s pitch/tone). $CBTBF00(CR DEFAULT Beep Frequency = Low $CBTBF01(CR Beep Frequency = Medium $CBTBF02(CR Beep Frequency = High www.balluff.com...
Page 210: Beep Duration
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Beep Duration This feature controls the duration of radio-specific beep indications. $CBTBD06(CR Beep Duration = 60 msec $CBTBD08(CR DEFAULT Beep Duration = 80 msec $CBTBD0A(C Beep Duration = 100 msec $CBTBD0C(C Beep Duration = 120 msec $CBTBD0E(CR...
Page 211: Beep Volume
Disconnect Beep Enables/disables the beep indication that a handheld has become connected or disconnected from a Base Station. The defaults are different for the STAR and BT models. $CBTDB00(CR Disconnect Beep = Disable $CBTDB01(CR DEFAULT Disconnect Beep = Enable www.balluff.com...
Page 212: Docking Beep
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Docking Beep Enables/disables a beep indication when the handheld is placed in the Base Station. $CBTCB00(CR Docking Beep = Disable $CBTCB01(C DEFAULT Docking Beep = Enable Leash Alarm This setting specifies the number of seconds to sound the Leash Mode beeps (three per second) when the handheld goes out of range.
Page 213 BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes $CBTLB05(CR Leash Alarm = 5 Seconds $CBTLB0A(CR Leash Alarm = 10 Seconds $CBTLB19(CR Leash Alarm = 25 Seconds $CBTLB1E(CR Leash Alarm = 30 Seconds www.balluff.com...
Page 214: Configuration Updates
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Configuration page 251 in “References” for detailed information and examples of these features. Updates Automatic Configuration Update When this feature is enabled, a reader and its linked Base Station can automatically ensure they stay in sync with regard to application hardware and/or configuration.
Page 215: Batch Features
When the reader is configured in Manual Batch Mode, use the following barcode to initiate send- ing of labels stored in batch memory. Do not scan an ENTER/EXIT PROGRAMMING MODE label in conjunction with this barcode. BatchSend Send Batch www.balluff.com...
Page 216: Erase Batch Memory
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Erase Batch Memory When the reader is configured in Manual Batch Mode, use the following barcode to erase any labels stored in batch memory. Do not scan an ENTER/EXIT PROGRAMMING MODE label in conjunction with this barcode.
Page 217: Direct Radio Autolink
00 06 66 00 1A ED will be sent as (shown in hex): 30 30 30 36 36 36 30 30 31 41 45 44 $CBTAS00(CR DEFAULT Source Radio Address Transmission = Do Not Include $CBTAS01(CR Source Radio Address Transmission = Prefix www.balluff.com...
Page 218: Source Radio Address Delimiter Character
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Source Radio Address Delimiter Character This option specifies the delimiter character to be placed between the label data and radio address when address stamping is enabled. This feature only applies if "Source Radio Address Transmission"...
Page 219: Bt Security Features
BT PIN Code After enabling Security Mode (see "BT Security Mode" on page 219), specify whether you want to set a 4-digit or a 16-digit PIN Code. See page 253 for detailed information and examples for set- ting this feature. www.balluff.com...
Page 220: Select Pin Code Length
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Select PIN Code Length CBTPS00\r DEFAULT Select 4-character BT PIN Code $CBTPS01\r Select 16-character BT PIN Code Set PIN Code Determine the desired characters for the PIN code, then convert to hexadecimal using the page 294 on the inside back cover of this manual.
Page 221: Other Bt Features
BT Poll Rate = 20 ms $CBT- BT Poll Rate = 50 ms $CBT- BT Poll Rate = 100 ms $CBT- BT Poll Rate = 200 ms Power Off See “Power Off” on page 27 for information about this BT feature. www.balluff.com...
Page 222: Powerdown Timeout
BVS HS-Q Series Standard Hand Held Barcode Reader Enter/Exit Programming Mode Configuration Using Barcodes Powerdown Timeout The Powerdown Timeout feature sets the time for automatically switching the unit off when the imager has been idle. $CSLPS00(CR Powerdown Timeout = Disable $CSLPS01(CR Powerdown Timeout = 10 minutes $CSLPS02(CR...
Page 223: References
Flash Off Time on page 248 Multiple Labels Ordering by Code Symbology on page 249 RF Features starting on page 251 Automatic Configuration Update on page 251 RF Address Stamping on page 252 BT Features on page 253 BT Pin Code on page 253 www.balluff.com...
Page 224: Rs-232 Parameters
BVS HS-Q Series Standard Hand Held Barcode Reader References RS-232 Parameters 5.1.1 RS-232 Baud Rate Baud rate is the number of bits of data transmitted per second. Set the reader's baud rate to match the baud rate setting of the host device. With an improper baud rate setting, data may not reach the host correctly.
Page 225: Rs-232/Usb Com Parameters
Scan Two Characters From Appendix 18, Use the barcodes in this appendix to enter ‘0’ and ‘5’ ‘5’ and ‘0’ ‘6’ and ‘0’ ‘8’ and ‘5’ numbers as you would select digits/ characters from a keypad. Scan ENTER/EXIT PROGRAMMING MODE www.balluff.com...
Page 226: Ack Nak Options
BVS HS-Q Series Standard Hand Held Barcode Reader References ACK NAK This enables/disables the ability of the reader to support the RS-232 ACK/NAK protocol. When Options configured, the reader and/or host sends an “ACK” when it receives data properly, and sends “NAK”...
Page 227: Nak Character
Scan Two Characters From Appendix 18, Use the barcodes in this appendix to enter ‘1’ and ‘5’ ‘2’ and ‘4’ ‘4’ and ‘0’ ‘3’ AND ‘E’ numbers as you would select digits/characters from a keypad. Scan ENTER/EXIT PROGRAMMING MODE www.balluff.com...
Page 228: Ack Nak Timeout Value
BVS HS-Q Series Standard Hand Held Barcode Reader References ACK NAK This option specifies the amount of time the reader waits for an ACK character from the host fol- Timeout Value lowing label transmission. The selectable timeout range is 200 milliseconds to 15,000ms (15 sec- onds) in 200ms increments.
Page 229: Ack Nak Retry Count
Appendix 18, Use the ‘0’, ‘0’ and ‘0’, ‘0’ and ‘0’, ‘5’ and barcodes in this appendix ‘2’, ‘5’ and ‘5’ ‘0’ ‘3’ ‘4’ to enter numbers as you would select digits/ characters from a keypad. Scan ENTER/EXIT PROGRAMMING MODE www.balluff.com...
Page 230: Disable Character
BVS HS-Q Series Standard Hand Held Barcode Reader References Disable Specifies the value of the RS-232 host command used to disable the reader. Character ASCII characters or any hex value from 0 to 0xFF can be selected. Setting to previously defined characters such as XON, XOFF, or host com- mands conflicts with normal operation of these characters.
Page 231: Enable Character
Length Control allows you to select either variable length decoding or fixed length decoding for the specified symbology. Variable Length: For variable length decoding, a minimum and maximum length may be set. Fixed Length: For fixed length decoding, two different lengths may be set. www.balluff.com...
Page 232: Set Length 1
BVS HS-Q Series Standard Hand Held Barcode Reader References Set Length 1 This feature specifies one of the barcode lengths for Length Control. Length 1 is the minimum label length if in Variable Length Mode, or the first fixed length if in Fixed Length Mode. Length includes the barcode’s data characters only.
Page 233: Data Editing
- You can add any character from the on page 294 (from 00-FF) on the inside back cover of this manual as a prefix, suffix or Label ID. - Enter prefixes and suffixes in the order in which you want them to appear on the output. www.balluff.com...
Page 234: Global Prefix/Suffix
BVS HS-Q Series Standard Hand Held Barcode Reader References 5.3.1 Global Prefix/ Up to 20 ASCII characters may be added as a prefix (in a position before the barcode data) and/ or as a suffix (in a position following the barcode data) as indicated in Figure 2:. Suffix Figure 2: Prefix and Suffix Positions...
Page 235: Global Aim Id
Code 93 Code 11 UPC-A and UPC-E labels are converted to EAN 13 when adding AIM IDs. ISBN (X with a 0 modifier character) Figure 3: AIM ID Prefix Label ID AIM ID Bar Code Data Label ID Suffix www.balluff.com...
Page 236: Label Id
BVS HS-Q Series Standard Hand Held Barcode Reader References 5.3.3 Label ID A Label ID is a customizable code of up to three ASCII characters (each can be one of hex 0x01- 0xFF), used to identify a barcode (symbology) type. It can be appended previous to or following the transmitted barcode data depending upon how this option is enabled.
Page 237 6D5000 380000 400000 5A0000 PDF417 500000 720000 PLESSEY 610000 610000 POSTAL AUSTRALIAN 244B00 244B00 POSTAL IMB 245600 245600 POSTAL JAPANESE 245200 245200 POSTAL KIX 245500 245500 POSTAL PLANET 245700 245700 POSTAL PORTUGAL 245000 245000 POSTAL POSTNET BB 244C00 244C00 www.balluff.com...
Page 238: Label Id: Set Individually Per Symbology
BVS HS-Q Series Standard Hand Held Barcode Reader References USA Label ID set EU Label ID set Symbology Default Default Character Default ASCII Default ASCII Character POSTAL ROYAL MAIL 244D00 244D00 POSTAL SWEDISH 245800 245800 POSTNET 310000 310000 QR CODE 515200 790000 730000...
Page 239 BVS HS-Q Series Standard Hand Held Barcode Reader References Figure 4: Label ID Position Options Prefix Label ID Aim ID Bar Code Data Label ID Suffix www.balluff.com...
Page 240 BVS HS-Q Series Standard Hand Held Barcode Reader References Label ID Examples STEP ACTION EXAMPLES Scan the ENTER/EXIT (Reader enters Programming Mode) barcode Determine placement of the Label ID characters BEFORE or AFTER with regard to Enable as Enable as Enable as Enable as Suffix readed data using...
Page 241: Character Conversion
5 Scan the ENTER/EXIT barcode to exit Programming Mode. If less than the expected string of 16 characters are selected, scan the ENTER/EXIT barcode twice to accept the selections and exit Programming Mode. www.balluff.com...
Page 242: Reading Parameters
BVS HS-Q Series Standard Hand Held Barcode Reader References Reading Parameters 5.4.1 Good Read LED This feature specifies the amount of time that the Good Read LED remains on following a good read. The good read LED on time can be set within a range of 10 milliseconds to 2,550 millisec- Duration onds (0.001 to 2.55 seconds) in 100ms increments.
Page 243: Reading Features
If the trigger is pulled, the reader acts as if it in single read mode. Double Read Timeout on page 70 prevents undesired multiple reads while in this mode. www.balluff.com...
Page 244: Stand Mode Off Time
BVS HS-Q Series Standard Hand Held Barcode Reader References 5.5.2 Stand Mode Off This feature specifies the amount of time reader illumination stays off after pulling the trigger when in Stand Mode. The configurable range is 01 to 32 by 01 in increments of 500ms (500ms to 16 Time seconds).
Page 245: Reading Active Time
Appendix 18, Use the ‘0’, ‘0’ and ‘0’, ‘9’ and ‘1’, ‘8’ and barcodes in this appendix ‘2’, ‘5’ and ‘5’ ‘1’ ‘0’ ‘0’ to enter numbers as you would select digits/ characters from a keypad. Scan ENTER/EXIT PROGRAMMING MODE www.balluff.com...
Page 246: Aiming Duration Time
BVS HS-Q Series Standard Hand Held Barcode Reader References 5.5.4 Aiming Duration Specifies the frame of time the aiming pointer remains on after decoding a label, when in trigger single mode. The range for this setting is from 1 to 255 seconds in 1-second increments. Time Follow these instructions to set this feature: 1 Determine the desired setting.
Page 247: Flash On Time
Scan Two Characters From Appendix 18, Use the barcodes in this appendix to enter ‘0’ and ‘5’ ‘1’ and ‘0’ ‘5’ and ‘2’ ‘9’ and ‘9’ numbers as you would select digits/characters from a keypad. Scan ENTER/EXIT PROGRAMMING MODE www.balluff.com...
Page 248: Flash Off Time
BVS HS-Q Series Standard Hand Held Barcode Reader References 5.5.6 Flash Off Time This feature specifies the OFF time for the indicator LED while in Flash Mode. The selectable range is 100 to 9,900 milliseconds (0.1 to 9.9 seconds), in 100 millisecond increments. Follow these instructions to set this feature.
Page 249: Multiple Labels Ordering By Code Symbology
‘2’ and ‘4’ ‘0’ and ‘E’ ‘0’ and ‘C’ ‘4’ and ‘E’ numbers as you would select digits/characters from a keypad. RESULT 0x240E0C4E0000 Scan ENTER/EXIT PROGRAMMING MODE Table on page 250 shows the hex value associated with each symbology. www.balluff.com...
Page 250 BVS HS-Q Series Standard Hand Held Barcode Reader References Symbology Hex Values Hex Hex Symbology ID Symbology ID Value Value Don't care GTIN5 UPC-A GTIN8 UPC-E S2OF5 EAN8 PDF417 EAN13 CODE11 UPC2 IATA UPC5 MICRO_PDF C128_ADDON GS1 DataBar_LIM_ID EAN128 GS1 DataBar_LIM_COMP C128_PROGRAMMING_LA- GS1 DataBar_Omnidirectional_- COMP...
Page 251: Rf Features
When this feature is enabled, the base station and reader will keep their configurations synchro- Configuration nized. If a reader's configuration is altered by reading programming labels, this change is auto- matically transferred and updated in a linked base station. Update www.balluff.com...
Page 252: Rf Address Stamping
BVS HS-Q Series Standard Hand Held Barcode Reader References 5.6.2 RF Address Stamping Source Radio This option specifies the delimiter character to be placed between the label data and radio Address address when address stamping is enabled. Delimiter Character This feature only applies if "Source Radio Address Transmission"...
Page 253: Bt Features
Scan ENTER/EXIT PROGRAMMING MODE Scan SET BT PIN CODE Scan 8 or 32 Alphanumeric Characters From Appendix 18, Use the barcodes in 44323534 53544F5231323334353637383133354D this appendix to enter numbers as you would select digits/characters from a keypad. Scan ENTER/EXIT PROGRAMMING MODE www.balluff.com...
Page 254: Appendix A: Technical Specifications
BVS HS-Q Series Standard Hand Held Barcode Reader Appendix A: Technical Specifications Appendix A: Technical Specifications This section contains Physical and Performance Characteristics, User Environment and Regula- tory information. Item Description BVS HS-QC (cable models) BVS HS-QB (bluetooth models) Physical Characteristics Color Black &...
Page 255 Minimum Element Width PDF-417 Minimum Resolution = 5 mil Data Matrix Minimum Resolution = 7.5 mil 13 mils DOF based on EAN. All other 1D codes are Code 39. All labels grade A, typical environmental light, 20°C, label inclination 10° www.balluff.com...
Page 256 BVS HS-Q Series Standard Hand Held Barcode Reader Appendix A: Technical Specifications Item Description 1D Barcodes UPC/EAN/JAN (A, E, 13, 8); UPC/EAN/JAN (including P2 /P5); UPC/ EAN/JAN (including; ISBN /Bookland & ISSN); UPC/EAN Coupons; Code 39 (including full ASCII); Code 39 Trioptic; Code39 CIP (French Pharmaceutical);...
Page 257 Reader withstands 18 drops from 1.5 meters (5.0 feet) to concrete Ambient Light Immunity Up to 86,000 Lux Contaminants Spray/ IEC 529-IP42 Rain/Dust/Particulates ESD Level 16 KV Regulatory For Regulatory approvals please refer to the chapter regulatory addendum of the specific BVS HS-Q quick guides. www.balluff.com...
Page 258: Imager Labeling
BVS HS-Q Series Standard Hand Held Barcode Reader Appendix A: Technical Specifications Imager Labeling Sample labels are shown here to illustrate their location only. Please view the labels on your prod- uct for actual details, as they may vary from those depicted. Reader Regulatory Label The BVS HS Q-series Handheld Reader is not user-serviceable.
Page 259: Standard Cable Pinouts
Interface Cable Port Figure 2: Standard Cable Pinouts: Base Station The signal descriptions in Table Standard Cable Pinouts — Handheld (BVS HS QC … model) or Base Station Side apply to the connector on the reader and are for reference only. www.balluff.com...
Page 260 BVS HS-Q Series Standard Hand Held Barcode Reader Appendix A: Technical Specifications Standard Cable Pinouts — RS-232 Handheld (BVS HS QC … model) RTS (out) or Base Station Side IBM_B IBM_A CTS (in)
Page 261: Led And Beeper Indications
Blue light flashes 2 times Image Capture When ready to capture image when updating Except when in sleep mode or when a Good Read LED Duration on page 75 other than 00 is selected www.balluff.com...
Page 262: Error Codes
BVS HS-Q Series Standard Hand Held Barcode Reader Appendix A: Technical Specifications Programming Mode Indications Programming Mode - The following indications ONLY occur when the reader is in Program- ming Mode. Label Pro- A valid programming label LED blinks continu- Reader sounds four low gramming has been readed.
Page 263: Base Station Indications (Cordless Models Only)
To push the button, insert a paper clip in the hole at the label in the bottom of the Base. BUTTON PUSH GREEN CORDLESS EVENT INDICATOR(**) INDICATOR(**) Slow blink Push at power-up force device connection Fast blink < 5 sec Paging Fast blink > 5 sec Unlink Slow blink www.balluff.com...
Page 264: Appendix B: Standard Defaults
BVS HS-Q Series Standard Hand Held Barcode Reader Appendix B: Standard Defaults Appendix B: Standard Defaults The most common configuration settings are listed in the “Default” column of the table below. Page references are also provided for feature descriptions and programming barcodes for each parameter.
Page 265 Stand Illumination Control on page 80 10 = Flash is ON for Flash On Time on page 80 1 Second 06 = Flash is OFF for Flash Off Time on page 81 600ms Aiming Pointer on page 81 Enable www.balluff.com...
Page 266 BVS HS-Q Series Standard Hand Held Barcode Reader Appendix B: Standard Defaults Page Parameter Default Your Setting Number Aiming Off Aiming Duration Timer on page 82 After Decoding Green Spot Duration on page 83 300 ms Mobile Phone Mode on page 83 Enable Partial Label Reading Control on page Enable...
Page 267 Code 39 Check Character Transmission Send on page 110 Code 39 Start/Stop Character Transmis- Don’t Transmit sion on page 110 Code 39 Full ASCII on page 110 Disable Small Quiet Zones Code 39 Quiet Zones on page 111 on two sides www.balluff.com...
Page 268 BVS HS-Q Series Standard Hand Held Barcode Reader Appendix B: Standard Defaults Page Parameter Default Your Setting Number Code 39 Length Control on page 111 Variable Code 39 Set Length 1 on page 112 Code 39 Set Length 2 on page 113 Trioptic Code Trioptic Code Enable/Disable on page Disable...
Page 269 Standard 2 of 5 Length Control on page Variable Standard 2 of 5 Set Length 1 on page Standard 2 of 5 Set Length 2 on page Industrial 2 of 5 Industrial 2 of 5 Enable/Disable on page Disable www.balluff.com...
Page 270 BVS HS-Q Series Standard Hand Held Barcode Reader Appendix B: Standard Defaults Page Parameter Default Your Setting Number Industrial 2 of 5 Check Character Calcu- Disable lation on page 137 Industrial 2 of 5 Check Character Trans- Enable mission on page 138 Industrial 2 of 5 Length Control on page Variable Industrial 2 of 5 Set Length 1 on page...
Page 271 GS1 DataBar™ Limited GS1-128 Emu- Disable lation on page 162 2D component not GS1 DataBar™ Limited 2D Component on page 163 required Code 93 Code 93 Enable/Disable on page 163 Disable Code 93 Check Character Calculation Enable Check C and on page 164 www.balluff.com...
Page 272 BVS HS-Q Series Standard Hand Held Barcode Reader Appendix B: Standard Defaults Page Parameter Default Your Setting Number Code 93 Check Character Transmission Disable on page 164 Code 93 Length Control on page 165 Variable Code 93 Set Length 1 on page 166 Code 93 Set Length 2 on page 167 Small Quiet Zones Code 93 Quiet Zones on page 168...
Page 273 QR Code Length Control on page 198 Variable QR Code Set Length 1 on page 199 QR Code Set Length 2 on page 200 7,089 Micro QR Code Enable/Disable on page Disable Micro QR Code Length Control on page Variable www.balluff.com...
Page 274 BVS HS-Q Series Standard Hand Held Barcode Reader Appendix B: Standard Defaults Page Parameter Default Your Setting Number Micro QR Code Set Length 1 on page 0001 Micro QR Code Set Length 2 on page 0035 UCC Composite Enable / Disable on Disable page 204 UCC Optional Composite Timer on page...
Page 275 4-character BT PIN Select PIN Code Length on page 220 Code 31323334 = Set PIN Code on page 220 Default Pin Code is 1234 BT Poll Rate on page 221 20 ms Powerdown Timeout on page 222 30 minutes www.balluff.com...
Page 276: Appendix C: Sample Barcodes
BVS HS-Q Series Standard Hand Held Barcode Reader Appendix C: Sample Barcodes Appendix C: Sample Barcodes The sample barcodes in this appendix are typical representations for their symbology types. 1D Barcodes UPC-A EAN-13 978033029095 Code 39 Code 128 Code 128 Interleaved 2 of 5 Code 32...
Page 277 BVS HS-Q Series Standard Hand Held Barcode Reader Appendix C: Sample Barcodes Codabar 13579 Code 93 Code 11 123456789 www.balluff.com...
Page 278: Gs1 Databar™ (Rss)
BVS HS-Q Series Standard Hand Held Barcode Reader Appendix C: Sample Barcodes GS1 DataBar™ (RSS) GS1 DataBar™ variants must be enabled to read the barcodes below (see "GS1 DataBar™ Omnidirectional" on page 155). GS1 DataBar™ Expanded Stacked 10293847560192837465019283746029478 450366523 GS1 DataBar™ Expanded 1234890hjio9900mnb GS1 DataBar™...
Page 279: Gs1 Databar™-14
BVS HS-Q Series Standard Hand Held Barcode Reader Appendix C: Sample Barcodes GS1 DataBar™-14 GS1 DataBar™ Omnidirectional Truncated 55432198673467 GS1 DataBar™ Omnidirectional Stacked 90876523412674 GS1 DataBar™ Omnidirectional Stacked 78123465709811 www.balluff.com...
Page 280: D Barcodes
BVS HS-Q Series Standard Hand Held Barcode Reader Appendix C: Sample Barcodes 2D Barcodes Aztec Datamatrix China Sensible Code MaxiCode Test Message PDF 417 Micro PDF 417 ABCabc BV17453 QR Code Micro QR Code 123456 35900G9 UCC Composite...
Page 281: Appendix D: Keypad
BVS HS-Q Series Standard Hand Held Barcode Reader Appendix D: Keypad Appendix D: Keypad Use the barcodes in this appendix to enter numbers as you would select digits/characters from a keypad. www.balluff.com...
Page 282 BVS HS-Q Series Standard Hand Held Barcode Reader Appendix D: Keypad...
Page 283: Appendix E: Scancode Tables
Alt, Control or Shift with other keys. Keys Example Consider a Control character set to 00. If AltRight+A is required before sending a label to the host, it could be done by setting three Prefix keys in this way: 0x99 0x41 0x9A. www.balluff.com...
Page 284: Interface Type, Usb-Keyboard Or Usb-Keyboard For Apple
BVS HS-Q Series Standard Hand Held Barcode Reader Appendix E: Scancode Tables Interface Type, USB-Keyboard or USB-Keyboard for APPLE Scancode Set When Control Character is 00 or 01 NULL C(S)+ C(S)+ C(S)+ C(S)+ C(S)+ C(S)+ C(S)+ C(S)+ C(S)+ C(S)+ C(S)+ C(S)+ Enter...
Page 285: Interface Type, Usb-Keyboard Or Usb-Keyboard For Apple (Continued)
Ù Ú Û Ü Ý Þ ß à á â ã ä å æ ç è é ê ë ì í î ï ð ñ ò ó ô õ ö ÷ ø ù ú û ü ý þ ÿ www.balluff.com...
Page 286: Interface Type Usb-Keyboard Alt Mode
BVS HS-Q Series Standard Hand Held Barcode Reader Appendix E: Scancode Tables Interface type USB-Keyboard Alt Mode Scancode Set When Control Character is 00 or 01 Alt+0 Alt+0 Alt+0 Alt+0 Alt+0 Alt+0 Alt+0 Alt+0 Alt+0 Alt+0 Alt+0 Alt+0 Alt+0 Enter Alt+0 Alt+0...
Page 287: Interface Type Usb-Keyboard Alt Mode (Continued)
Standard Hand Held Barcode Reader Appendix E: Scancode Tables Interface type USB-Keyboard Alt Mode (continued) Scancode Set When Control Character is 02 Enter Ar↓ Ar↑ Al↓ Al ↑ Cl ↓ Cl ↑ Cr ↓ Cr ↑  Keyp Enter    www.balluff.com...
Page 288: Digital Interface
BVS HS-Q Series Standard Hand Held Barcode Reader Appendix E: Scancode Tables Digital Interface Scancode Set When Control Character is 00 or 01 NULL C(S)+ C(S)+ C(S)+ C(S)+ C(S)+ C(S)+ C(S)+ C(S)+ C(S)+ C(S)+ C(S)+ Enter C(S)+ C(S)+ C(S)+ C(S)+ C(S)+ C(S)+...
Page 289: Ibm31Xx 102-Key
C(S)+ C(S)+ C(S)+ C(S)+ C(S)+ C(S)+ C(S)+ Spac “ & ‘ < > ‘ Sh↓ Sh↑ (keyp Enter Delet Field Field Enter Reset Insert paddl Printl Ar↓ Ar↑ Al↓ Al ↑ Cl ↓ Cl ↑ Cr ↓ Cr ↑ www.balluff.com...
Page 290 BVS HS-Q Series Standard Hand Held Barcode Reader Appendix E: Scancode Tables Scancode Set When Control Character is 02 Enter Ar↓ Ar↑ Al↓ Al ↑ Cl ↓ Cl ↑ Cr ↓ Cr ↑ Keyp Enter     Spac “...
Page 291 C(S)+ C(S)+ C(S)+ C(S)+ C(S)+ C(S)+ C(S)+ C(S)+ C(S)+ C(S)+ C(S)+ C(S)+ Spac “ & ‘ < > ‘ Sh↓ Sh↑ (keyp     Ar↓ Ar↑ Al↓ Al ↑ Cl ↓ Cl ↑ Cr ↓ Cr ↑ www.balluff.com...
Page 292 BVS HS-Q Series Standard Hand Held Barcode Reader Appendix E: Scancode Tables Scancode Set when Control Character 02 Enter Ar↓ Ar↑ Al↓ Al ↑ Cl ↓ Cl ↑ Cr ↓ Cr ↑  Keyp Enter    Spac “...
Page 293: Microsoft Windows Codepage 1252
Standard Hand Held Barcode Reader Appendix E: Scancode Tables 10.4 Microsoft Windows-1252 is a character encoding of the Latin alphabet, used by default in the legacy com- Windows ponents of Microsoft Windows in English and some other Western languages. Codepage 1252 www.balluff.com...
Page 294: Ascii Chart
BVS HS-Q Series Standard Hand Held Barcode Reader ASCII Chart ASCII ASCII ASCII ASCII Hex No. Hex No. Hex No. Char. Char. Char. Char. ‘ “ & ’ < >...
Page 295 BVS HS-Q Series Standard Hand Held Barcode Reader NOTES www.balluff.com...
Page 296 World Headquarters Subsidaries Germany Balluff GmbH Balluff Inc. Schurwaldstraße 9 8125 Holton Drive 73765 Neuhausen a.d.F. Florence, Deutschland Kentucky 41042-0937 Tel. +49 7158 173-0 Phone (859) 727-2200, Fax +49 7158 5010 1-800-543-8390 balluff@balluff.de applications@balluff.com www.balluff.com...
