Parts List - Fujitsu AUG54AGB3W Service Manual

Hide thumbs

Advertisement

AUG54ALB3W
AUG54RLB3W
AUY54ALB3W
AUY54RLB3W
AUT54ALB3W
AUT54RLB3W
INDOOR UNIT
Ref.
Description
No.
34
Capacitor (Fan Motor)
47-1
Rubber (Discha. Pipe)
61
Decoration Plate
67
Rubber (Vibration Proof)
71
Grille Hook Holder
93
Filter
117-3
Hex. Nut w / Spring Washer
122
Louver Support Holder
127
Drain Hose
138
Separate Wall
143-1
Clamp NK-3N
143-3
Clamp NK-6N
146-1
Evaporator-A Assy
146-2
Evaporator-B Assy
155
Special Nut M6
160
Drain Pan Assy
164
Fan Motor Assy-IN
168
Cabinet-E
184-1
Thermo. Spring-A
187
Clamp No. 1219
195
Clamp SKB-100
196-2
Clamp SKB-150
197
Wind Guide Board
223
Control Box
226
Motor Gear
234
Thermistor Assy-Room
235
Thermistor Assy-Pipe
236
Controller PCB Assy
236
Controller PCB Assy
240
Remote Control Unit
240
Remote Control Unit
244
Pipe Cover
245
Cable Clamp
337-1
Reinforcement (Eva.)-A
337-2
Reinforcement (Eva.)-B
338
Motor Holder
381
Locking Spacer
457
Reinforcement (Drain Pan)
460-1
Pump Cover-A
460-2
Pump Cover-B
462
Top Cover Plate
464
Cabinet-A
465
Cabinet-B
467
Drain Port
468
Special Nut-A (Large)
469
Special Nut-B (Small)
472-1
Grille Reinforcement-T-A
472-2
Grille Reinforcement-T-B
472-3
Grille Reinforcement-T-C
472-4
Grille Reinforcement-T-D
472-5
Grille Reinforcement-T-E
474
Turbo Fan Assy
476-2
Special Washer
477
Bellmouth (B)
479
Float Switch
481
Insulation (Grille)-A
481-1
Insulation (Grille)-B
482
Pump Unit
484
Hook
487
Grille Hinge Wire
P A R T S
AUG54ALB3W
AUG54RLB3W
9703306068
9703306068
313194159807
313194159807
9363131000
9363131000
9362783002
9362783002
9362782005
9362782005
9362766005
9362766005
301721180114
301721180114
9362799003
9362799003
9362784009
9362784009
9362737005
9362737005
313361274700
313361274700
9305657001
9305657001
9363149005
9364804002
9363150001
9364805009
9307615016
9307615016
9362804004
9362804004
9600878019
9600878019
9362735001
9362735001
313728262708
313728262708
313361271706
313361271706
313361275805
313361275805
313035356905
313035356905
9363117004
9363117004
9362762007
9362762007
9362764001
9362764001
9703299025
9703299025
9703297014
9703297014
9704557346
9704557346
--------
--------
--------
9371438016
9703173028
--------
9362748001
9362748001
313714181904
313714181904
9362749008
9362749008
9362750004
9362750004
9362765008
9362765008
313209391506
313209391506
9362757003
9362757003
9362775007
9362775007
9362776004
9362776004
9362806015
9362806015
9362800013
9362800013
9362801010
9362801010
9362786003
9362786003
313005446653
313005446653
313005446759
313005446759
9362738002
9362738002
9362739009
9362739009
9362740005
9362740005
9362741002
9362741002
9362742009
9362742009
9362803014
9362803014
9362756006
9362756006
9362774000
9362774000
9703285004
9703285004
9362780001
9362780001
9362781008
9362781008
9703125010
9703125010
9362736008
9362736008
9362754002
9362754002
- 21 -
L I S T
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
Part No.
AUY54ALB3W
AUY54RLB3W
9703306068
9703306068
313194159807
313194159807
9362787000
9362787000
9362783002
9362783002
9362782005
9362782005
9362766005
9362766005
301721180114
301721180114
9362799003
9362799003
9362784009
9362784009
9362737005
9362737005
313361274700
313361274700
9305657001
9305657001
9363149005
9364804002
9363150001
9364805009
9307615016
9307615016
9362804004
9362804004
9600878019
9600878019
9362735001
9362735001
313728262708
313728262708
313361271706
313361271706
313361275805
313361275805
313035356905
313035356905
9363117004
9363117004
9362762007
9362762007
9362764001
9362764001
9703299025
9703299025
9703297014
9703297014
9704557346
--------
--------
9704557179
--------
9371438016
9703173028
--------
9362748001
9362748001
313714181904
313714181904
9362749008
9362749008
9362750004
9362750004
9362765008
9362765008
313209391506
313209391506
9362757003
9362757003
9362775007
9362775007
9362776004
9362776004
9362806015
9362806015
9362800013
9362800013
9362801010
9362801010
9362786003
9362786003
313005446653
313005446653
313005446759
313005446759
9362738002
9362738002
9362739009
9362739009
9362740005
9362740005
9362741002
9362741002
9362742009
9362742009
9362803014
9362803014
9362756006
9362756006
9362774000
9362774000
9703285004
9703285004
9362780001
9362780001
9362781008
9362781008
9703125010
9703125010
9362736008
9362736008
9362754002
9362754002
AUT54ALB3W
AUT54RLB3W
9703306068
9703306068
313194159807
313194159807
9362787000
9362787000
9362783002
9362783002
9362782005
9362782005
9362766005
9362766005
301721180114
301721180114
9362799003
9362799003
9362784009
9362784009
9362737005
9362737005
313361274700
313361274700
9305657001
9305657001
9363149005
9364804002
9363150001
9364805009
9307615016
9307615016
9362804004
9362804004
9600878019
9600878019
9362735001
9362735001
313728262708
313728262708
313361271706
313361271706
313361275805
313361275805
313035356905
313035356905
9363117004
9363117004
9362762007
9362762007
9362764001
9362764001
9703299025
9703299025
9703297014
9703297014
--------
--------
9704557179
9704557179
--------
9703173035
9703173042
--------
9362748001
9362748001
313714181904
313714181904
9362749008
9362749008
9362750004
9362750004
9362765008
9362765008
313209391506
313209391506
9362757003
9362757003
9362775007
9362775007
9362776004
9362776004
9362806015
9362806015
9362800013
9362800013
9362801010
9362801010
9362786003
9362786003
313005446653
313005446653
313005446759
313005446759
9362738002
9362738002
9362739009
9362739009
9362740005
9362740005
9362741002
9362741002
9362742009
9362742009
9362803014
9362803014
9362756006
9362756006
9362774000
9362774000
9703285004
9703285004
9362780001
9362780001
9362781008
9362781008
9703125010
9703125010
9362736008
9362736008
9362754002
9362754002
