- Page 1 DELL ™ OPTIPLEX ™ FX130 TECHNICAL GUIDEBOOK— INSIDE THE OPTIPLEX FX130 THIN CLIENT...
- Page 2 O V E R V I E W OPTIPLEX FX130 FRONT AND BACK VIEWS D E T A IL E D E N G I NE E R I N G S P E C IF IC A T IO N S : S Y S T E M C O M P O NE N T D E T A IL S P O W E R D E T A IL S A U D IO &...
- Page 3 DELL™ OPTIPLEX™ FX130 TECHNICAL GUIDEBOOK 1.0 FR ON T A N D BA C K VI EW Front Back Number Name Number Name Power Button USB 2.0 Connectors (4) Network Activity Indicator LED DVI-I Audio Line Out PS/2 Microphone Power Connector...
-
Page 4: De Tai Le D En Gi Neer I Ng S Pe Ci Fi C A Ti O Ns
DELL™ OPTIPLEX™ FX130 TECHNICAL GUIDEBOOK 1.0 DE TAI LE D EN GI NEER I NG S PE CI FI C A TI O NS Processor CPU / Chipsets VIA Eden ULV 1GHz/VIA VX855 Memory 1GB DDR2 RAM OS Support Linux (DeTOS) - Page 5 DELL™ OPTIPLEX™ FX130 TECHNICAL GUIDEBOOK 1.0 PO WER DET AIL S AC Parameters External Power Adapter Dimensions 110.9 mm (L) x 51.9 mm (W) x 33 mm (H) Power Supply Wattage AC input Voltage Range 100-240 V AC input current (max)
- Page 6 DELL™ OPTIPLEX™ FX130 TECHNICAL GUIDEBOOK 1.0 AUDIO Integrated via 1708s High Definition Audio High Definition Stereo support Number of Channels Number of Bits / Audio resolution 16 and 24-bit resolution Sampling rate (recording/playback) Support 44.1K/48K/96K/192 kHz sample rates Signal to Noise Ratio...
-
Page 7: System Configuration
DELL™ OPTIPLEX™ FX130 TECHNICAL GUIDEBOOK 1.0 COMMUNICATIONS NETWORK ADAPTER (NIC) (CONTINUED) PCIE Realtek 8111DL-GR Ethernet LAN 10/100/1000 (continued) Management Capabilities Operating Temperature 0° C to 70° C (32° F to 158° F) Operating Humidity 20% to 80% (non-condensing) Manageability (examples WOL, PXE) WOL, PXE 2.1... -
Page 8: Power Management
ProSupport Optional For a copy of our guarantees or limited warranties, please write Dell USA L.P., Attn: Warranties, One Dell Way, Round Rock, TX 78682. For more information, visit www.dell.com/warranty. Service may be provided by third-party. Technician will be dispatched if necessary following phone-based troubleshooting. Subject to parts availability, geographical restrictions and terms of service contract.
