EXTREME SWITCHING ISW 4-10/100P Command Reference Manual

Isw series managed industrial ethernet switch
Hide thumbs Also See for ISW 4-10/100P:
Table of Contents

Advertisement

Quick Links

ISW Series Managed
Industrial Ethernet Switch
Command Reference Guide
ISW 4-10/100P, 2-10/100T, 2-SFP
ISW 4GbP, 2GbT, 2-SFP
ISW 8-10/100P, 4-SFP
ISW 8GbP, 4-SFP
9034963-01 Rev. 02
Published May 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ISW 4-10/100P and is the answer not in the manual?

Questions and answers

Related Manuals for EXTREME SWITCHING ISW 4-10/100P

Summary of Contents for EXTREME SWITCHING ISW 4-10/100P

  • Page 1 ISW Series Managed Industrial Ethernet Switch Command Reference Guide ISW 4-10/100P, 2-10/100T, 2-SFP ISW 4GbP, 2GbT, 2-SFP ISW 8-10/100P, 4-SFP ISW 8GbP, 4-SFP 9034963-01 Rev. 02 Published May 2017...

  • Page 2: Legal Notice

    Copyright © 2017 Extreme Networks, Inc. All rights reserved. Legal Notice Extreme Networks, Inc. reserves the right to make changes in specifications and other information contained in this document and its website without prior notice. The reader should in all cases consult representatives of Extreme Networks to determine whether any such changes have been made.

  • Page 3: Table Of Contents

    Table of Contents Preface............................4 Text Conventions...................................4 Getting Help.................................... 4 Extreme Networks Publications.............................5 Providing Feedback to Us..............................5 Chapter 1: Introduction to the Industrial Switches Command Referene Guide....6 Chapter 2: Getting Started with the ISW Switch..............7 Connecting to the ISW Interface........................... 7 Execution Modes...................................

  • Page 4: Preface

    Preface Text Conventions The following tables list text conventions that are used throughout this guide. Table 1: Notice Icons Icon Notice Type Alerts you to... General Notice Helpful tips and notices for using the product. Note Important features or instructions. Caution Risk of personal injury, system damage, or loss of data.

  • Page 5: Extreme Networks Publications

    Preface • Email: support@extremenetworks.com. To expedite your message, enter the product name or model number in the subject line. • GTAC Knowledge — Get on-demand and tested resolutions from the GTAC Knowledgebase, or create a help case if you need more guidance. •...

  • Page 6: Chapter 1: Introduction To The Industrial Switches Command Referene Guide

    Introduction to the Industrial Switches Command Referene Guide Scope This user guide describes the commands and parameters of the Command Line Interface (CLI) as implemented in the current version of Extreme Networks ISW Series Industrial Switches software. These commands are used to set up, administer, and maintain the system. Audience The guide is intended for Operating personnel.

  • Page 7: Chapter 2: Getting Started With The Isw Switch

    Getting Started with the ISW Switch Connecting to the ISW Interface Execution Modes Using the CLI Help Terminal Key Function Notation Conventions Access to the switch is protected by a logon security system. You can log on to the switch with the user name and password.

  • Page 8: Execution Modes

    Getting Started with the ISW Switch Figure 1: Screen Description Execution Modes The CLI contains several execution modes. Users will see different set of commands under different execution modes. The following table lists all the execution modes and their purposes. When you enter a certain execution mode, the corresponding mode prompt will be displayed automatically on the screen.

  • Page 9: Using The Cli Help

    Getting Started with the ISW Switch Table 3: List of Execution Modes (continued) Mode Access Level Prompt VLAN (Virtual LAN) Interface Config Mode Engineer (vlan-intf-conf)# IGMP (Internet Group Management Protocol) Engineer (igmp-mvr-profile-conf)# MVR Profile Config Mode IGMP ACL Profile Config Mode Engineer (igmp-acl-profile-conf)# RingV2 Group Config Mode...

  • Page 10: Syntax Conventions

    Getting Started with the ISW Switch Table 4: List of Terminal Keys (continued) [CTRL] + [F] [Backspace] Erase the character before the cursor [CTRL] + [H] Notation Conventions The notation conventions for the parameter syntax of each CLI command are as follows: •...

  • Page 11: Chapter 3: Isw Commands

    ISW Commands Initialize Mode Commands Enable Mode Commands Configure Mode Commands VLAN Mode Commands Interface VLAN Mode Commands RingV2 Group Mode Commands Spanning Tree sFlow Configure Command SNMP Configure Command QoS Function Command IGMP Functional Commands MVR Functional Commands MLD Functional Commands Authenticate Mode Commands Loop-Protection Configure commands LLDP Configure commands...

  • Page 12: Configure Terminal

    ISW Commands Parameters None. configure terminal Description Enter configuration mode. Syntax configure terminal Parameters None. enable Description Enter enable mode. Syntax enable Parameters None. show terminal Description Show CLI environment variables. Syntax show terminal Parameters None. ISW Series Managed Industrial Ethernet Switch Command Reference Guide...

  • Page 13: Show History

    ISW Commands show history Description Show command history. Note Commands issued in one execution mode only appear in history of that execution mode. Syntax show history Parameters None. show clock Description Show current time. Syntax show clock [ detail Parameters None.

  • Page 14: Show Aaa

    ISW Commands disable Description Enter init mode. Syntax disable Parameters None. show aaa Description Show AAA. Syntax show aaa Parameters None. show access management Description Access management configuration. Syntax show access managemnet [ | access_id_list] statistics Parameters Name Description Statistics data. statistics ID of access management entry.
  • Page 15 ISW Commands Syntax show access-list [ [(port_type [ v_port_type_list])]] [ interface rate- limiter [rate_limiter_list]] [ ace statistics [ace_list]] show access-list ace-status [ static link-oam loop-protect dhcp upnp arp-inspection ipmc ip-source-guard ip-mgmt conflicts switch switch_list] Parameters Name Description Select an interface to configure interface The local ACEs status ace-status...

  • Page 16: Show Aggregation

    ISW Commands Parameters None. show aggregation Description Aggregation. Syntax show aggregation [ mode Parameters Traffic distribution mode. mode show aging time Description Show aging time for MAC learning table (system-wide). Syntax show aging time Parameters None. show alarm Description Alarm information. Syntax show alarm [ history...

  • Page 17: Show Dot1X

    ISW Commands show cpu-load Description CPU load. Syntax show cpu-load Parameters None. show ddmi Description Show DDMI configuration. Syntax show ddmi Parameters None. show dot1x Description Show dot1x information. Syntax show dot1x Parameters None. show dot1x status Description Show dot1x stats. Syntax show dot1x status [ interface...

  • Page 18: Show Dot1X Statistics

    ISW Commands show dot1x statistics Description Show dot1x statistics Syntax show dot1x statistics { eapol radius interface (port_type [v_port_type_list])] Parameters Name Description Show EAPOL statistics eapol Show Backend Server statistics radius Show all dot1x statistics GigabitEthernet, 1 Gigabit Ethernet Port port_type PORT_LIST, Port list in 1/1-14 v_port_type_list...
  • Page 19 ISW Commands Parameters Name Description Shows green ethernet EEE status for a specific port or ports. Shows green ethernet energy-detect status for a specific port or ports. energy- detect Shows green ethernet short-reach status for a specific port or ports. short-reach Shows green ethernet status for a specific port or ports.
  • Page 20 ISW Commands show interface gigabit <portNo> storm-control Description Show storm control information per gigabit port. Syntax show interface gigabit portNo storm-control Parameters Name Description Port type in Fast, Giga or Tengiga Ethernet port_type Valid values: 1–10 portNo Type: Mandatory show interface gigabit <portNo> transceiver Description Show interface transceiver Syntax...

  • Page 21: Show Interface

    ISW Commands show interface Description Show interface information per port. Syntax show interface port_type [port_type_list] status Parameters Name Description Port type in Fast, Giga or Tengiga Ethernet port_type Valid values: 1 – 10 portNo Type: Mandatory show interface priority Description Show QoS (Quality of Service) per gigabit port.
  • Page 22 ISW Commands Parameters Name Description Port type in Fast, Giga or Tengiga Ethernet port_type Valid values: 1 – 10 portNo Type: Mandatory Show Gigabit Ethernet counter counter show interface vlan Description Show interface information of all or specific VLANs. Syntax show interface vlan {vlanid} Parameters Name...

  • Page 23: Show Ipv6

    ISW Commands Name Description Secure Shell Traffic statistics statistics verify command verify show ipmc Description IPMC information. Syntax show ipmc profile [profile_name] [ detail show ipmc range [entry_name] Parameters Name Description IPMC profile configuration. profile A range of IPv4/IPv6 multicast addresses for the profile. range Profile name in 16 characters.

  • Page 24: Show Lacp

    ISW Commands show lacp Description LACP information. Syntax show lacp { internal statistics system-id neighbour Parameters Name Description internal Internal LACP configuration. neighbour Neighbour LACP status. statistics Internal LACP statistics. system-id LACP system ID. show line Description Alive line information. Syntax show line [ alive...
  • Page 25 ISW Commands Parameters Name Description Valid values are 1 – 4294967295 log_id Error error Infomation info Warning warning show loop-protec Description Loop protect information. Syntax show loop-protect [ (port_type [plist])] interface Parameters Name Description interface Interface status and configuration. GigabitEthernet, 1 Gigabit Ethernet Port. port_type Port list in 1/1 –...
  • Page 26 ISW Commands Syntax show mac address-table [ | {{ conf static aging-time learning count interface port_type [port_type_list]]} | { address mac_addr [ vlan vlan_id ]} | vlan_id | port_type [port_type_list]] vlan interface Parameters None. show mac address table learning Description Learn/disable/secure stat.
  • Page 27 ISW Commands Syntax show mac address-table { vlan_id learning count vlan Parameters Name Description Valid values: 1 – 4094 vlan_id Type: Mandatory show mac address-table conf Description User-added static MAC addresses. Syntax show mac address-table | {{ conf static aging-time learning count interface...
  • Page 28 ISW Commands Parameters Name Description portNo Valid values: 1 – 10 Type: Mandatory show mac address-table static Description Show all static MAC addresses. Syntax show mac address-table [ conf static aging-time | {{ learning count (port_type [v_port_type_list])]} | { v_mac_addr [ interface address vlan...

  • Page 29: Show Mvr

    ISW Commands None. show mvr Description MVR information. Syntax show mvr [v_vlan_list | mvr_name] [ vlan name group-database interface (port_type [v_port_type_list])] [ sfm-information ]] [ detail Parameters Name Description Search by VLAN. vlan MVR multicast VLAN list. v_vlan_list name Search by MVR name. MVR multicast VLAN name.
  • Page 30 ISW Commands Syntax show platform phy [ (port_type [v_port_type_list])] interface show platform phy id [ (port_type [v_port_type_list])] interface show platform phy instance show platform phy status [ port_type [v_port_type_list])] interface Parameters Name Description PHY Instance Information instance Status status Interface interface Gigabit Ethernet, 1 Gigabit Ethernet Port port_type...
  • Page 31 ISW Commands None. show port-security Description Port security. Syntax show port-security Parameters Name Description Show MAC Addresses learned by Port Security port Show Port Security status switch Interface interface Gigabit Ethernet, 1 Gigabit Ethernet Port port_type Port list in 1/1 – 14 v_port_type_list show port-shaper Description...
  • Page 32 ISW Commands show protocol-vlan Description Show protocol based VLAN information for all entries. Syntax show protocol-vlan Parameters None. show pvlan isolation [interface <port_type> [<port_type_list>]] Description Show all port isolation information. Syntax show pvlan isolation [ port_type [port_type_list]] interface Parameters Name Description Port type in Fast, Giga or Tengiga Ethernet port_type...

  • Page 33: Show Qos

    ISW Commands show qos Description QoS interface information Syntax show qos [{ [(port_type [port])]} interface Parameters Name Description Interface interface GigabitEthernet, 1 Gigabit Ethernet Port port_type PORT_LIST, Port list in 1/1-14 port show qos maps Description MAPS Syntax show qos maps { maps dscp-cos dscp-ingress-translation...
  • Page 34 ISW Commands Parameters None. show qos qce Description Syntax show qos { [qce]} Parameters Name Description QCE ID. Valid values are 1 – 256. show qos storm Description Show storm control information by VLAN. Syntax show vlan unknown-uc show vlan unknown-mc show vlan broadcast Parameters Name...
  • Page 35 ISW Commands Syntax show queue-scheduler profile Parameters None. show queue-shaper Description Show queue shaper information. Syntax show queue-shaper Parameters None. show radius-server [statistics] Description show radius-server statistics Syntax show radius-server [ statistics Parameters Name Description Count radius packet statistics statistics show rfc2544 profile Description Show rfc2544 profile name.

  • Page 36: Show Rmon

    ISW Commands show ringv2 Description Show ring protect information Syntax show ring Parameters None. show rmon Description Syntax show rmon alarm [id_list] show rmon event [id_list] show rmon history [id_list] show rmon statistics [id_list] Parameters Name Description Display the RMON alarm table alarm Display the RMON event table event...
  • Page 37 ISW Commands show running-config interface Gigabit Description Show port configuration. Syntax show running-config interface (port_type [list]) [ all-defaults Parameters Name Description Port list in 1/1 – 14. list Include most/all default values. all-defaults show running-config interface vlan Description Show default running configuration. Syntax show running-config interface vlan vlan_list [ all-defaults...
  • Page 38 ISW Commands show running-config feature Description Show running configuration feature. Syntax show running-config feature feature_name [ all-defaults Parameters Name Description Include all default values. all-defaults CWORD feature_name Valid values are : GVRP | access | access-list | aggregation | alm_profile | arp-inspection | auth | clock | dhcp | dhcp-snooping | dhcp_server | dns | dot1x | green-ethernet | http | icli | ip-igmp-snooping | ip-igmp-snooping-port | ip-igmp-snooping-vlan | ipmc-profile | ipmc-profile-range | ipv4 | ipv6 | ipv6-mld-snooping | ipv6-mld-snooping-port | ipv6-...

  • Page 39: Show Sflow

    ISW Commands Parameters Name Description List of VLAN numbers. list Include most/all default values. all-defaults show sflow Description Sflow information Syntax show sflow show sflow statistics { [rcvr_idx_list] | receiver samplers interface [samplers_list] (port_type [v_port_type_list])]} Parameters Name Description Show statistics for receiver receiver Show statistics for samplers samplers...
  • Page 40 ISW Commands Parameters Name Description access configuration access Group name group_name any security model v1 security model v2c security model v3 security model authNoPriv Security Level auth noAuthNoPriv Security Level noauth authPriv Security Level priv Community community Specify community name community Set SNMP host's configurations host...
  • Page 41 ISW Commands show spanning-tree Description System-wide Spanning Tree setting/status. Syntax show spanning-tree [ (port_type summary active interface [v_port_type_list])} | { detailed interface port_type [v_port_type_list_1])]} | { | {instance [ configuration interface (port_type [v_port_type_list_2])]}]}] Parameters Name Description STP (Spanning Tree Protocol) active interfaces active STP statistics detailed...

  • Page 42: Show Version

    ISW Commands Syntax show tacacs server Parameters None. show version Description Show firmware hardware and software status update status. Syntax show version Parameters None. show vlan Description Show bridge port memberset/status. Syntax show vlan Parameters None. show vlan brief Description VLAN summary information Syntax show vlan [...

  • Page 43: Show Vlan Id

    ISW Commands Name Description A VLAN name up to 32 characters. name VLAN summary information. brief show vlan id Description Show bridge port memberset/status per VLAN index. Syntax show vlan id vlan_id Parameters Name Description Valid values: 1 – 4094 vlan_id Type: Mandatory.
  • Page 44 ISW Commands Parameters Name Description Show a specific MAC entry address <mac_ucast> The specific MAC entry to show mac_addr show vlan name Description Show bridge port memberset/status per VLAN name. Syntax show vlan name vword32 Parameters Name Description Valid values: 32 words vword32 Type: Mandatory.
  • Page 45 ISW Commands Name Description ssap <0x0-0xff> SSAP (Range: 0x00 - 0xFF) SNAP-based VLAN status snap <0x0-0xffffff> SNAP OUI (Range 0x000000 - 0XFFFFFF) rfc-1042 SNAP OUI is rfc-1042 SNAP OUI is 8021h snap-8021h show vlan status Description Show the VLANs configured for each interface Syntax show vlan status [ interface...
  • Page 46 ISW Commands Parameters None. show voice Description Vlan for voice traffic Syntax show voice vlan [ oui | interface (port_type [port_list])] Parameters Name Description VLAN for voice traffic vlan OUI configuration OUI value interface Select an interface to configure port_type GigabitEthernet, 1 Gigabit Ethernet Port port_list Port list in 1/1-14...

  • Page 47: Configure Mode Commands

    ISW Commands Configure Mode Commands Commands that can be executed under Configure Mode. To enter Configure Mode, type the command: terminal. The prompt will now show (config)#. configure Description Authentication Syntax aaa authentication Parameters Name Description Authentication authentication access Description Management configuration Syntax access management...

  • Page 48: Aggregation Mode

    ISW Commands account add <username> Description Add an account. Syntax username word31 0-15 word4-44 privilege password encrypted Parameters Name Description Valid values: 1 – 31 characters word31 Type: Mandatory Valid values: 0 – 15 0-15 Type: Mandatory Valid values: 4-44 characters word4-44 debug Type: Mandatory...
  • Page 49 ISW Commands Name Description Destination MAC affects the distribution dmac IP address affects the distribution IP port affects the distribution port Source MAC affects the distribution smac alarm history clear Description Clear alarm history Syntax alarm history clear Parameters None. banner Description Banner control...

  • Page 50: Clear Logging

    ISW Commands clear ip igmp snooping [vlan vlan_list] statistics Parameters Name Description VLAN list. vlan_list clear logging Description Clear logging Syntax clear logging [info] [warning] [error] [switch switch_list] Parameters Name Description Information info Warning warning Error error List of switch ID, e.g., 1,3-5,6 switch_list clear mac address-table Description...

  • Page 51: Clock Timezone

    ISW Commands Name Description year 2000-2037 month 1-12 Date 1-31 Hour 0-23 minute 0-59 Second 0-59 clock summer-time set [start-time] [end-time] Description Set date/time. Syntax clock summer-time word16 [1-12 1-31 2000-2097 hhmm 1-12 1-31 date 2000-2097 hhmm [1-1440]] Parameters Name Description Valid values: please see 'list timezone' word16...
  • Page 52 ISW Commands Parameters Name Description Valid values: please see 'list timezone' word16 Type: Mandatory configuration save and replace Description Save and install configuration Syntax copy { startup-config running-config | Filename} { startup-config | Filename} [ running-config syntax-check Parameters Name Description Currently running configuration running-config Startup configuration...
  • Page 53 ISW Commands Parameters Name Description Word for prompt in 32 characters. word default access-list rate-limiter Description Rate limiter Syntax default access-list rate-limiter [rate_limiter_list] Parameters Name Description Rate limiter ID. Valid values are 1 – 16. RateLimiterId delete Description Delete one file in flash: file system Syntax delete word Parameters...
  • Page 54 ISW Commands Description To run exec commands in config mode Syntax do line Parameters Name Description Exec Command line duplex Description Set duplex mode Syntax duplex { half full auto half full Parameters Name Description Forced half duplex. half Forced full duplex. full Auto negotiation of duplex mode.
  • Page 55 ISW Commands Firmware swap and upgrade Syntax firmware { swap upgrade Parameters Name Description Swap between Active and Alternate firmware image swap Firmware upgrade upgrade flowcontrol Description Enable/Disable flow control. Syntax flowcontrol {on | off} Parameters Name Description Enable flow control. Disable flow control.
  • Page 56 ISW Commands frame-sizes Description Select the frame sizes that the enabled tests will loop through Syntax frame-sizes {[64] [128] [256] [512] [1024] [1280] [1518] [2000] [9600]} Parameters Name Description Enable testing with 64-byte TST PDUs Enable testing with 128-byte TST PDUs Enable testing with 256-byte TST PDUs Enable testing with 512-byte TST PDUs Enable testing with 1024-byte TST PDUs...
  • Page 57 ISW Commands green-etherneteee urgent-queues Description Enables EEE urgent queue. An urgent queue means that latency is kept to a minimum for traffic going to that queue. Note: EEE power savings will be reduced. Syntax green-etherneteee urgent-queues [range_list] Parameters Name Description EEE Interface.
  • Page 58 ISW Commands interface vlan vlanid Parameters Name Description Valid values: 1 – 4094 vlanid Type: Mandatory iparp inspection Description IPARP inspection Syntax iparp inspection Parameters ip arp inspection translate Description IP ARP inspection entry interface configuration Syntax ip arp inspection translate [ interface port_type port_type_id vlan_id mac_ucast ipv4_ucast]...

  • Page 59: Ip Arp Inspection Vlan

    ISW Commands ip arp inspection entry interface port_type in_port_type_id vlan_var mac_var ipv4_var Parameters Name Description port_type Port type in Fast, Giga or Tengigaethernet in_port_type_id Port ID in the format of switch-no/port-no vlan_var Select a VLAN id to configure mac_var Select a MAC address to configure ipv4_var Select an IP Address to configure ip arp inspection vlan...
  • Page 60 ISW Commands Parameters ip http secure-server Description IP Secure HTTP web server Syntax ip http secure-server Parameters ip source binding interface Description IP source binding entry interface configuration Syntax ip source binding interface port_type port_type_id vlan_id ipv4_ucast mac_ucast Parameters Name Description Port type in Fast, Giga or Tengigaethernet port_type...
  • Page 61 ISW Commands ip name-server Description IP name server Syntax ip name-server {v_ipv4_ucast | v_vlan_id]} dhcp interface vlan Parameters Name Description v_ipv4_ucast A valid IPv4 unicast address dhcp Dynamic Host Configuration Protocol v_vlan_id VLAN identifier(s): VID ip route Description IP Route Syntax ip route v_ipv4_addr v_ipv4_netmask v_ipv4_gw Parameters...
  • Page 62 ISW Commands IP verify Syntax ip verify [ source translate Parameters Name Description source verify source translate ip verify source translate all entries ipmc profile Description IPMC profile configuration Syntax ipmc profile Parameters ipmc range Description A range of IPv4/IPv6 multicast addresses for the profile Syntax ipmc range word16 { [ipv4_mcast] |...
  • Page 63 ISW Commands Syntax lacp system-priority v_1_to_65535 Parameters Name Description system-priority System priority v_1_to_65535 Priority value, lower means higher priority line Description Console terminal control Syntax line {0–16 | 0–15} console Parameters Name Description List of line numbers <0–16> console Console terminal line Virtual terminal login host Description...
  • Page 64 ISW Commands Log level Syntax logging level { info warning error Parameters Name Description Error error info Information warning Warning login on Description Log on Syntax logging on Parameters logout Description System logout Syntax logout Parameters mac address-table aging-time Description MAC table entries/configuration Syntax mac address-table aging-time v_0_10_to_1000000...
  • Page 65 ISW Commands Name Description Aging time in seconds, 0 disables aging <v_0_10_to_1000000> mac address-table aging-time <time> Description Configure aging time for a bridge port. Syntax mac address-table aging-time time Parameters Name Description Valid values: 10 – 1000000 (seconds), 0: disable aging time Type: Mandatory mac address-table static...
  • Page 66 ISW Commands Parameters Name Description rj45 interface (copper interface). rj45 sfp interface (fiber interface). Dual media interface (cu & fiber interface). dual monitor destination interface Description The destination port. That is the port that trafficked should be mirrored to. Syntax monitor destination interface port_type port_type_id Parameters Name...
  • Page 67 ISW Commands Syntax monitor source {{ (port_type [v_port_type_list])} interface Parameters Name Description port_type 1 Gigabit Ethernet Port v_port_type_lis Port list more Description File in FLASH or on TFTP server Syntax more Path Parameters mtu <value> Description MTU size. Syntax mtu value Parameters Name Description...
  • Page 68 ISW Commands Name Description Debugging functions debug Port security (PSEC limit) port-securit Set terminal line parameters terminal ntp server <1-5> ip-address <ip> Description Set NTP server address. Syntax ntp server 1-5 ip-address {ipv4_ucast | ipv6_ucast | hostname} Parameters Name Description index number Type: Mandatory ipv4...
  • Page 69 ISW Commands Syntax port-security [ v_10_to_10000000] aging time Parameters Name Description aging Enable/disable port security aging Time in seconds between check for activity on learned MAC addresses time 10 – 10000000 seconds v_10_to_10000000 port {enable/disable} Description Set interface gigabit port enable or disable. Syntax port {enable | disable} Parameters...
  • Page 70 ISW Commands Name Description IPMC Profile Mode ipmc-profile Line configuration mode line RFC2544 Profile Mode rfc2544-profile SNMP Server Host Mode snmps-host STP Aggregation Mode stp-aggr profile sch Description Enter Scheduling Profile Config Mode Syntax profile sch Parameters None. reload Description System or configuration reset Syntax reload {...

  • Page 71: Rmon Alarm

    ISW Commands Parameters Name Description Configure an RMON alarm alarm Configure an RMON event event rmon alarm Description RMON Alarm Syntax rmon alarm id oid_str interval { absolute delta rising-threshold rising_threshold [rising_event_id] falling_threshold falling-threshold [falling_event_id] {[ rising falling both Parameters Name Description Alarm entry ID...
  • Page 72 ISW Commands Name Description Specify a description of the event description Generate RMON log when the event fires Generate SNMP trap when the event fires trap speed (Ethernet) Description Configure gigabit Ethernet speed and Copper/SFP for gigabit port 7–8. Note Ports 1–6 Only support copper.
  • Page 73 ISW Commands Parameters Name Description 10 Gbps 25 Gbps 2500 1 Gbps 1000 100 Mbps Auto-negotiation auto 10 Mbps 100 Mbps 1000 Mbps (1 Gbps) 1000 syslog {enable | disable} Description Disable or enable Syslog service. Syntax logging on no logging on Parameters None.
  • Page 74 ISW Commands tacacs-server key Description Configure TACACS+ encryption key Syntax tacacs-server key line1-63 Parameters Name Description The shared key line1-63 terminal Description Terminal control. Syntax terminal { editing exec-timeout help history length width Parameters Name Description Enable command line editing editing Set the EXEC timeout exec-timeout...
  • Page 75 ISW Commands Name Description Wait time in seconds 1-1000 traps Description trap event configuration Syntax traps [ aaa authentication system coldstart warmstart ]] [ switch rmon Parameters Name Description AAA authentication fail event aaa authentication Cold start event coldstart Warm start event warmstart STP event RMON event...

  • Page 76: Upnp Ttl

    ISW Commands Name Description advertising duration 100-86400 upnp ttl Description Set UPnP's TTL value Syntax upnp ttl 1-255 Parameters Name Description TTL value 1-255 username Description User account Syntax username username priv encry_password privilege password encrypted username username privilege priv password none username username priv...
  • Page 77 ISW Commands Configure VLAN. Syntax vlan vlanid Parameters Name Description Create an empty VLAN index. vlanid Valid values: 1 – 4094 Type: Mandatory vlan <vlanid> <name> Description Configure VLAN’s name. Syntax vlan vlanid name Parameters Name Description Create an empty VLAN index. vlanid Valid values: 1 –...

  • Page 78: Vlan Mode Commands

    ISW Commands Description Configure web privilege group names and levels. Syntax web privilege group group_name cro] [ crw] [ sro] level srw]}*1 Parameters Name Description Web privilege privilege group Web privilege group group_name Valid words are Aggregation | DHCP | Debug | Dhcp_Client | Diagnostics | EEE | Green_Ethernet | IP2 | IPMC_Snooping | LACP | LLDP | Loop_Protect | MAC_Table | MVR | Maintenance | Mirroring | NTP | Ports | Private_VLANs | QoS | RPC | Security | Spanning_Tree | System | Timer | VCL | VLANs | Voice_VLAN | XXRP | sFlow...
  • Page 79 ISW Commands vlan ethertype s-custom-port Description Vlan Ether type for custom S-ports configuration Syntax vlan ethertype s-custom-port 0x0600-0xffff Parameters Name Description Ethertype range 0x0600-0xffff vlan protocol Description Syntax Syntax vlan protocol {{ {0x600-0xffff | }} | { eth2 snap {0x0-0xffffff | rfc_1042 snap_8021h } 0x0-0xffff} | {...

  • Page 80: Switchport Access Vlan

    ISW Commands vlan-trunking Description Change whether trunking of unknown VLANs is enabled Syntax vlan-trunking Parameters switchport access vlan Description Set switch access mode of the interface Syntax switchport access vlan vlan_id Parameters Name Description VLAN ID of the VLAN when this port is in access mode vlan_id switchport forbidden vlan Description...
  • Page 81 ISW Commands Syntax switchport hybrid acceptable-frame-type { tagged untagged Parameters Name Description Allow all frames Allow only tagged frames tagged Allow only untagged frames untagged switchport hybrid allowed vlan Description Set allowed VLAN characteristics when interface is in hybrid mode Syntax switchport hybrid allowed vlan { none...

  • Page 82: Switchport Mode

    ISW Commands Name Description No egress tagging none Tag all frames Tag all frames except frames classified to native VLAN of the hybrid port except-native switchport hybrid ingress-filtering Description VLAN Ingress filter configuration Syntax switchport hybrid ingress-filtering Parameters switchport mode Description Set switching mode Syntax...

  • Page 83: Interface Vlan Mode Commands

    ISW Commands Name Description All VLANs No VLANs none Add VLANs to the current list Remove VLANs from the current list remove All VLANs except the following except VLAN IDs of the allowed VLANs when this port is in trunk mode vlan_list switchport vlan protocol group Description...

  • Page 84: Interface Vlan

    ISW Commands interface vlan Description VLAN interface configurations Syntax interface vlan vlan_list Parameters Name Description List of VLAN interface numbers, range is 1 – 4095 vlan_list ip address Description IPv4 address configurations Syntax ip address {{ipv4_addr ipv4_netmask} | { dhcp fallback ipv4_addr ipv4_netmask [...

  • Page 85: Ip Dhcp Pool

    ISW Commands Parameters Name Description A valid IPv4 unicast address ipv4_ucast VLAN identifier(s): VID vlan_id ip dhcp excluded-address Description Prevent DHCP from assigning certain addresses Syntax ip dhcp excluded-address low_ip [high_ip] Parameters Name Description low_ip Low IP address high_ip High IP addres ip dhcp pool Description Pool name in 32 characters...

  • Page 86: Ip Dhcp Relay Information Option

    ISW Commands ip dhcp relay Description DHCP relay agent configuration Syntax ipdhcp relay Parameters None. ip dhcp relay information option Description IP DHCP relay information option(Option 82) Syntax ipdhcp relay information option Parameters None. ip dhcp retry interface vlan Description Restart the DHCP query process Syntax ipdhcp retry interface vlan vlan_id...

  • Page 87: Ipv6 Address

    ISW Commands Parameters None. ip helper-address Description DHCP relay server Syntax ip helper-address <v_ipv4_ucast> Parameters Name Description IP address of the DHCP relay server v_ipv4_ucast ipv6 address Description Configure the IPv6 address of an interface Syntax ipv6 address ipv6_subnet Parameters Name Description IPv6 prefix x:x::y/z...

  • Page 88: Ringv2 Group Mode Commands

    ISW Commands RingV2 Group Mode Commands ringv2 protect Description To configure ring protection. Syntax ring protect Parameters Name Description group1 Configure ring protection v2 group1 (Ring) group2 Configure ring protection v2 group2 (Ring) group3 Configure ring protection v2 group3 (Chain) guard-time Description Set guard time...
  • Page 89 ISW Commands Name Description Set the specified Ring group to Disabled disable enable Set the specified Ring group to Enabled node1 interface GigabitEthernet <portNo>} Description Set interface of ring protection node Syntax node1 interface GigabitEthernet portNo Parameters Name Description Valid values: 1–max port index. portNo node2 interface GigabitEthernet <portNo>} Description...

  • Page 90: Spanning Tree

    ISW Commands Name Description Set role to ring master ring-master Set role to ring slave ring-slave Set role to coupling primary coupling- primary Set role to coupling backup coupling- backup Set role to dual homing dual-homing Set role to chain head chain-head Set role to chain member chain-member...
  • Page 91 ISW Commands Parameters None. spanning-tree auto-edge Description Auto detect edge status Syntax spanning-tree auto-edge Parameters spanning-tree bpdu-guard Description Enable/disable BPDU guard Syntax spanning-tree bpdu-guard Parameters None. spanning-tree edge Description Edge port spanning-tree STP Bridge Syntax spanning-tree edge Parameters None. spanning-tree edge bpdu-filter Description Enable BPDU filter (stop BPDU tx/rx) ISW Series Managed Industrial Ethernet Switch Command Reference Guide...
  • Page 92 ISW Commands Syntax spanning-tree edge bpdu-filter Parameters None. spanning-tree mode Description Spanning Tree mode STP protocol mode 802.1D Spanning Tree rstp Rabid Spanning Tree (802.1w) mstp Multiple Spanning Tree (802.1s) Syntax spanning-tree mode { rstp mstp Parameters Name Description 802.1D Spanning Tree Rabid Spanning Tree (802.1w) rstp Multiple Spanning Tree (802.1s)
  • Page 93 ISW Commands Name Description instance 0-7 (CIST=0, MST2=1...) STP Cost of this port 1-200000000 spanning-tree mst port-priority Description port-priority Syntax spanning-tree mst 0-7 0-240 port-priority Parameters Name Description instance 0-7 (CIST=0, MST2=1...) STP priority of this port 0-240 spanning-tree mst priority Description Priority of the instance.
  • Page 94 ISW Commands Parameters Name Description instance 0-7 (CIST=0, MST2=1...) Range of VLANs vlan_list spanning-tree mst forward-time Description forward-time Delay between port states Syntax spanning-tree mst forward-time 4-30 Parameters Name Description Delay between port states 4-30 spanning-tree mst max-age Description Max bridge age before timeout. Syntax spanning-tree mst max-age 6-40 [forward-time 4-30 ] Parameters...
  • Page 95 ISW Commands spanning-tree mst max-hops 6-40 Parameters Name Description MSTP bridge max hop count 6-40 spanning-tree mst name Description Name of the bridge Revision Revision keyword Syntax spanning-tree mst name word32 revision 0-65535 Parameters Name Description Name of the bridge word32 Revision keyword 0-65535...

  • Page 96: Sflow Configure Command

    ISW Commands spanning-tree recovery Description Recovery Syntax spanning-tree recovery interval interval Parameters Name Description The interval interval Interval : 30-86400 seconds interval; spanning-tree transmit Description Transmit Syntax spanning-tree transmit hold-count holdcount Parameters Name Description Max number of transmit BPDUs per sec hold-count <Holdcount : 1-10>...
  • Page 97 ISW Commands sflow agent-ip Description The agent IP address used as agent-address in UDP datagrams. Defaults to IPv4 loopback address. Syntax sflow agent-ip { ipv4_addr | ipv6_addr} ipv4 ipv6 Parameters Name Description IPv4 address ipv4_addr IPv6 address ipv6_addr sflow collector-address Description Sflow runtime, see sflow_icli_functions Syntax...
  • Page 98 ISW Commands sflow max-sampling-size Description Specifies the maximum number of bytes to transmit per flow sample. Syntax sflow max-sampling-size [sampler range_list] [14-200] Parameters Name Description Sampler instance range_list packet byte 200-1468 sflow collector-port Description Collector UDP port Syntax sflow collector-port [receiver rcvr_idx_list] collector_port Parameters Name Description...

  • Page 99: Snmp Configure Command

    ISW Commands sflow timeout Description Receiver timeout measured in seconds. The switch decrements the timeout once per second, and as long as it is non-zero, the receiver receives samples. Once the timeout reaches 0, the receiver and all its configuration is reset to defaults. Syntax sflow timeout [receiver range_list] 0-2147483647 Parameters...
  • Page 100 ISW Commands Name Description security level level authNoPriv Security Level auth | noauth | priv noAuthNoPriv Security Level authPriv Security Level specify a read view for the group read read view name word255 snmp-server community v2c Description Set the SNMP v2c community Syntax snmp-server community word127 [...
  • Page 101 ISW Commands snmp-server host Description Set SNMP server's configurations Syntax snmp-server host word32 Parameters Name Description Name of the host configuration word32 snmp-server host traps Description Set SNMP host's configurations Syntax snmp-server host Name of the host configuration traps linkup linkdown lldp Parameters...
  • Page 102 ISW Commands snmp-server user Description Set the SNMPv3 user's configurations Syntax snmp-server user Username Engine ID octet string [{ word8-32 engine-id word8-40} [ priv } word8-32]] Parameters Name Description 32 words Username word10-32 Engine ID octet string Set MD5 (Message-Digest algorithm 5) protocol Set SHA protocol SHA password word8-40...
  • Page 103 ISW Commands Parameters Name Description MIB view name word32 MIB view OID word255 Included/Excluded type from the view include | exclude SNMP trap receive ipv6 host Description host configuration Syntax host ipv6_ucast [1-65535] [ traps informs Parameters Name Description IP address of SNMP trap host ipv6_ucast UDP port of the trap messges 1-65535...
  • Page 104 ISW Commands Syntax snmp-server engine-id local engineID Parameters Name Description Set SNMP local engine ID local engineID <Engineid : word10-32> local engine ID snmp-server location Description SNMP server loation Syntax snmp-server location v_line255 Parameters Name Description v_line255 <line255> location string snmp-server security-to-group Description SNMP server security...

  • Page 105: Qos Function Command

    ISW Commands Name Description group security group group_name <GroupName : word32> security group name SNMP trap receive ipv4 host Description Host configuration Syntax host {ipv4_ucast | hostname} [1-65535 ] [ traps informs Parameters Name Description IP address of SNMP trap host ipv4_ucast hostname of SNMP trap host hostname...

  • Page 106: Qos Cos

    ISW Commands qos storm Description QoS storm Syntax qos storm { } {{rate [ ]} | { unicast multicast broadcast kfps 1024 kfps Parameters Name Description Police broadcast frames broadcast Police multicast frames multicast Police unicast frames unicast 1024, Rate is 1024 kfps rate <Rate : 1,2,4,8,16,32,64,128,256,512>...
  • Page 107 ISW Commands qos dscp-remark Description Set qos dscp-remark Syntax qos dscp-remark { rewrite | remap | remap-dp } Parameters None. qos dscp-translate Description Enable Qos DSCP-translate mode Syntax qos dscp-translate Parameters None. qos map cos-dscp Description Configure cos mapping to dscptable Syntax qos map cos-dscp 0–7 dpl 0–1 dscp {0-63 | { af11...
  • Page 108 ISW Commands Name Description Assured Forwarding PHB 41–43(DSCP 34,36,38) Af41–43 Class Selector PHB CS1–7 precedence 1–7(DSCP 8*(cs value)) cs1–7 Expedited Forwarding PHB(DSCP 46) Voice Admit PHB(DSCP 44) qos map cos-dscp Description Configure dscp mapping to cos table Syntax qos map dscp-cos {0–63 | { af11 af12 af13...
  • Page 109 ISW Commands qos map dscp-egress-translation {0–63 | { af11 af12 af13 af21 af22 af23 af31 af32 af33 af41 af42 af43 }} 0–1 {0-63 | { af11 af12 af13 af21 af22 af23 af31 af32 af33 af41 af42 af43 Parameters Name Description Cos level 0–7 Dscp level...

  • Page 110: Qos Policer

    ISW Commands Name Description Assured Forwarding PHB 31–33(DSCP 26,28,30) af31–33 Assured Forwarding PHB 41–43(DSCP 34,36,38) af41–43 Class Selector PHB CS1–7 precedence 1–7(DSCP 8*(cs value)) cs1–7 Expedited Forwarding PHB(DSCP 46) Voice Admit PHB(DSCP 44) Specific drop precedence level 0–1 qos policer Description Configure qos policer Syntax...

  • Page 111: Igmp Functional Commands

    ISW Commands Configure queue-shaper command Syntax qos queue-shaper queue 0–7 unit [ excess Parameters Name Description every level proportion 1-100 unit Traffic meter excess Agree the shaper could be excess or not qos queue-policer Description Configure queue-policer command Syntax qos queue-policer queue 0–7 unit Parameters Name Description...

  • Page 112: Ip Igmp Snooping

    ISW Commands ip igmp host-proxy [leave-proxy] Description IGMP proxy for leave configuration Syntax ip igmp host-proxy [ leave-proxy Parameters Name Description IGMP proxy for leave leave-proxy ip igmp snooping Description Snooping IGMP Syntax ip igmp snooping Parameters None. ip imp snooping immediate-leave Description IP IGMP snooping immediate leave configuration Syntax...

  • Page 113: Ip Igmp Snooping Mrouter

    ISW Commands Parameters Name Description 0 - 31744 tenths of seconds 0-31744 ip igmp snooping max-groups Description IGMP group throttling configuration Syntax ip igmp snooping max-groups 1-10 Parameters Name Description Maximum number of IGMP group registration 1-10 ip igmp snooping mrouter Description IP IGMP snooping Multicast router port configuration Syntax...

  • Page 114: Ip Igmp Snooping Vlan

    ISW Commands Name Description Act as an IGMP Querier to join Querier-Election election IGMP Querier address configuration address A valid IPv4 unicast address ipv4_ucast ip igmp snooping query-interval Description IP IGMP snooping Query-Interval in seconds Syntax ip igmp snooping query-interval 1-31744 Parameters None.

  • Page 115: Mvr Functional Commands

    ISW Commands Parameters Name Description v_ipv4_mcast Valid IPv4 multicast address ipv4_prefix_length Length ip igmp unknown-flooding Description IP IGMP flooding unregistered IPv4 multicast traffic Syntax ip igmp unknown-flooding Parameters None. clear ip igmp snooping statistics Description Clear IP IGMP snooping statistics Syntax clear ip igmp snooping [vlan vlan_list] statistics Parameters...
  • Page 116 ISW Commands None. mvr immediate-leave Description MVR immediate leave configuration Syntax mvr immediate-leave Parameters None. mvr name channel Description Multicast VLAN name and channel configuration Syntax mvr name word16 channel word16 Parameters Name Description name MVR multicast VLAN name Profile name in 16 char's channel <...
  • Page 117 ISW Commands mvr name <word16> frame tagged Description MVR control frame in TX, Tagged IGMP/MLD frames will be sent Syntax mvr name word16 frame tagged Parameters Name Description MVR multicast VLAN name name mvr name <word16> igmp-address <ipv4_ucast> Description MVR address configuration used in IGMP Syntax mvr name word16 igmp-address ipv4_ucast Parameters...

  • Page 118: Mvr Vlan

    ISW Commands mvr name <word16> mode Description Dynamic MVR operation mode Syntax mvr name word16 mode { dynamic compatible Parameters Name Description Dynamic MVR operation mode dynamic Compatible MVR operation mode compatible mvr name <word16> type Description MVR port role configuration Syntax mvr name word16 type { source...
  • Page 119 ISW Commands mvr vlan <vlan_list> channel Description MVR channel configuration Syntax mvr vlan vlan_list channel word16 Parameters Name Description MVR multicast VLAN list vlan_list MVR multicast channel name in 16 char's word16 mvr vlan <vlan_list> frame priority Description Interface CoS priority Syntax mvr vlan vlan_list frame priority 0-7 Parameters...
  • Page 120 ISW Commands mvr vlan <vlan_list> igmp-address Description Set tagged IGMP/MLD frames will be sent Syntax mvr vlan vlan_list igmp-address ipv4_ucast Parameters Name Description < vlan_list > MVR multicast VLAN list <ipv4_ucast> A valid IPv4 unicast address for IGMP mvr vlan <vlan_list> mode Description Dynamic MVR vlan operation mode Syntax...

  • Page 121: Mld Functional Commands

    ISW Commands Name Description MVR multicast VLAN list vlan_list MVR source port source MVR receiver port receiver MLD Functional Commands ipv6 mld host-proxy Description IPv6 MLD proxy configuration Syntax ipv6 mld host-proxy [ leave-proxy Parameters Name Description MLD proxy for leave configuration leave-proxy ipv6 mld snooping Description...
  • Page 122 ISW Commands Name Description Compatible with MLDv1/MLDv2 auto Forced MLDv1 Forced MLDv2 ipv6 mld snooping immediate-leave Description IPv6 MLD snooping immediate-leave configuration Syntax ipv6 mld snooping immediate-leave Parameters None. ipv6 mld snooping last-member-query-interval Description IPv6 MLD snooping last member query interval in tenths of seconds Syntax ipv6 mld snooping last-member-query-interval 0-31744 Parameters...

  • Page 123: Ipv6 Mld Snooping Vlan

    ISW Commands ipv6 mld snooping mrouter Description IPv6 MLD snooping multicast router port configuration Syntax ipv6 mld snooping mrouter Parameters None. ipv6 mld snooping query-interval Description IPv6 MLD snooping query interval in seconds Syntax ipv6 mld snooping query-interval 1-31744 Parameters Name Description 1 - 31744 seconds...

  • Page 124: Ipv6 Route

    ISW Commands Syntax ipv6 mld snooping vlan vlan_list Parameters Name Description VLAN identifier(s): VID vlan_list ipv6 mld ssm-range Description SSM range Syntax ipv6 mld ssm-range v_ipv6_mcast ipv6_prefix_length Parameters Name Description v_ipv6_mcast Valid IPv6 multicast address ipv6_prefix_length length ipv6 mld unknown-flooding Description Flooding unregistered IPv6 multicast traffic Syntax...

  • Page 125: Authenticate Mode Commands

    ISW Commands Parameters Name Description v_ipv6_subnet IPv6 prefix x:x::y/z v_ipv6_ucast IP address of the DHCP relay server v_vlan_id VLAN ID v_ipv6_addr IP address Authenticate Mode Commands radius-server attribute 32 Description Configure radius-server attribute Syntax radius-server attribute 32 id Parameters Name Description Id : line 1-253 radius-server attribute 4...
  • Page 126 ISW Commands Syntax radius-server attribute 95 ipv6_ucast Parameters Name Description ipv6_ucast address ipv6_ucast radius-server deadtime Description Configure RADIUS (Remote Authentication Dial In User Service)-server deadtime Syntax radius-server deadtime 1-1440 Parameters Name Description Time in minutes 1-1440 radius-server host [ auth-port] [acct-port] [timeout] [retransmit] [key] Description Configure RADIUS-server host behavior Syntax...
  • Page 127 ISW Commands RADIUS-server key Syntax radius-server key key Parameters Name Description <Key : line1-63> The shared key radius-server retransmit Description RADIUS server retransmit Syntax radius-server retransmit retries Parameters Name Description <Retries : 1-1000> Number of retries for a transaction retries radius-server timeout Description RADIUS-server timeout...
  • Page 128 ISW Commands tacacs-server deadtime 1-1440 Parameters Name Description Time in minutes 1-1440 tacacs-server host [auth-port] [timeout] [key] Description Configure TACACS+ server host behavior Syntax tacacs-server host word1-255 [port 0-65535] [ timeout 1-1000] [key line1-63] Parameters Name Description TCP port number 1-1440 tacacs-server deadtime <1-1440>...
  • Page 129 ISW Commands Name Description Time in minutes 1-1440 dot1x feature Description Globally enables/disables a dot1x feature functionality Syntax dot1x feature {[ guest-vlan radius-qos radius-vlan Parameters Name Description Globally enables/disables state of guest-vlan guest-vlan Globally enables/disables state of RADIUS-assigned QoS. radius-qos Globally enables/disables state of RADIUS-assigned VLAN.

  • Page 130: Dot1X Timeout

    ISW Commands dot1x max-reauth-req 1-255 Parameters Name Description number of times <1-255> dot1x re-authentication Description re-authentication Syntax dot1x re-authentication Parameters None. dot1x system-auth-controln Description System authentication control Syntax dot1x system-auth-control Parameters None. dot1x timeout Description Timeout control Syntax dot1x timeout { quiet-period v_10_to_1000000} | { tx-period...

  • Page 131: Dot1X Initialize

    ISW Commands dot1x guest-vlan Description G Enables/disables Guest VLAN globally or on one or more ports Syntax dot1x guest-vlan dot1x guest-vlan 1-4095 Parameters Name Description Guest VLAN ID used when entering the Guest VLAN. 1-4095 dot1x initialize Description Forces a re-initialization of the clients on the port and thereby an immediate reauthentication Syntax dot1x initialize [ port_type [port_type_list]]...
  • Page 132 ISW Commands Name Description Port access is allowed force-authorized Port access is not allowed force-unauthorized Port-based 802.1X Authentication auto Single Host 802.1X Authentication single Multiple Host 802.1X Authentication multi Switch authenticates on behalf of the client mac-based dot1x radius-vlan Description Enables/disables per-port state of RADIUS-assigned VLAN.

  • Page 133: Loop-Protection Configure Commands

    ISW Commands Parameters Name Description Assign the privileged level clear password password Assign the privileged level secret secret Description Level exit Syntax Parameters None. exit Description Level exit Syntax Parameters None. hostname Description This system's network name Syntax hostname hostname Parameters None.
  • Page 134 ISW Commands loop-protect Description Loop protection configuration on port Syntax loop-protect Parameters None. loop-protect action Description Loop protection configuration on port Syntax loop-protect action {[ shutdown Parameters Name Description Shutdown port shutdown Generate log loop-protect shutdown-time Description Loop protection shutdown time interval Syntax loop-protect shutdown-time 0-604800 Parameters...

  • Page 135: Lldp Configure Commands

    ISW Commands Syntax loop-protect transmit-time 1-10 Parameters None. loop-protect tx-mode Description Loop protection actively generate PDUs Syntax loop-protect tx-mode Parameters None. LLDP Configure commands lldp holdtime Description Sets LLDP hold time (The neighbor switch will discarded the LLDP information after \"hold time\" multiplied with \"timer\"...
  • Page 136 ISW Commands Parameters Name Description datum Datum (geodetic system) type • nad83-mllw: Mean lower low water datum 1983 • nad83-navd88: North American vertical datum 1983 • wgs84: World Geodetic System 1984 Number of times to repeat LLDP frame transmission at fast start fast <v_1_to_10>...
  • Page 137 ISW Commands Sets LLDP TX interval (the time between each LLDP frame transmitted in seconds). Syntax lldp timer 5-32768 Parameters Name Description 5-32768 seconds. 5-32768 lldp tlv-select Description Which optional TLVs to transmit. Syntax lldp tlv-select { management-address port-description system- capabilities system-description system-name...

  • Page 138: Rfc2544 Testing Configure Commands

    ISW Commands lldp transmit Description Enable/Disabled transmission of LLDP frames. Syntax lldp transmit Parameters None. RFC2544 Testing Configure Commands rfc2544 profile <word32> Description RFC2544 profile configuration Syntax rfc2544 profile word32 Parameters Name Description Profile name up to 32 characters long word32 rfc2544 rename profile Description...
  • Page 139 ISW Commands rfc2544 save <word32> <word> Description Save a report to a file on a TFTP server Syntax rfc2544 save word32 word Parameters Name Description Name of existing report to save <word32> TFTP server URL on the form tftp://server[:port]/path-to-file <word> rfc2544 start <word32>...

  • Page 140: Gvrp Configure Commands

    ISW Commands show rfc2544 profile [ <word32> ] Description show rfc2544 profile name Syntax show rfc2544 profile [word32] Parameters Name Description rfc2544 profile name word32 GVRP Configure Commands gvrp Description Enable GVRP on port(s) Syntax gvrp Parameters None. gvrpjoin request vlan Description Emit a Join-Request for test purpose Syntax...

  • Page 141: Voice Vlan Configure Commands

    ISW Commands Emit a leave-Request for test purpose Syntax gvrp leave-request vlan vlan_list Parameters Name Description List of VLANs vlan_list gvrp max-vlans Description GVRP maximum number of VLANs Syntax gvrp max-vlans 1-4095 Parameters Name Description A valid range is from 1-4095. <1-4095>...

  • Page 142: Voice Vlan

    ISW Commands voice vlan Description Vlan for Voice appliance attributes Syntax voice vlan Parameters None. voice vlan aging-time Description Set secure learning aging time for voice traffic Syntax voice vlan aging-time 10-10000000 Parameters Name Description Aging time, 10-10000000 seconds 10-10000000 voice vlan class Description Set voice traffic class...

  • Page 143: Profile Alarm Commands

    ISW Commands voice vlan oui Description Set voice traffic OUI configuration Syntax voice vlan oui oui [ line32] description Parameters Name Description OUI value Set description for the OUI description Description line line32 voice vlan vid Description Set voice VLAN ID Syntax voice vlan vid vlan_id Parameters...

  • Page 144: Poe Commands

    ISW Commands alarm Description Set alarm content Syntax alarm alarmId { mask unmask major minor Parameters 101–114: GE-1–14 Port link down (for 14 port model) Name Description alarmId 151: set Power alarm mask Set alarm as mask, it means event will not be send notify unmask Set alarm as un-mask, it means event will be send notify major...

  • Page 145: Poe Mode

    ISW Commands Max. port power determined by LLDP Media protocol, and power is managed lldp-consumption according to power consumption. Max. port power determined by LLDP Media protocol, and power is managed lldp-reserved-power according to reserved power. poe supply Description Use PoE supply to specify the maximum power the power supply can deliver. Syntax poe supply power Parameters...

  • Page 146: Poe Priority

    ISW Commands Name Description Set operation mode to 802.3af(Maximum power 15.4W) Set operation mode to 802.3at(Maximum power 30.0 W) poe power Description Set maximum power for port in allocation mode. Syntax poe power limit power Parameters Name Description Maximum power for the interface (0-15.4 Watt for PoE standard mode, 0-30.0 power Watt for PoE plus mode) poe priority...

  • Page 147: Configuring Erps From The Cli

    ISW Commands 0-59 minute Day(s): range_list • 1: Sunday • 2: Monday • 3: Tuesday • 4: Wednesday • 5: Thursday • 6: Friday • 7: Saturday poe schedule Description Set PoE power scheduling during the week. Syntax poe schedule day range_list Parameters Name Description...
  • Page 148 ISW Commands #disable Loop Protection no loop-protect Configuring MEP and ERPS on Switch 1 (RPL Owner) #create mep 1 on port 1 mep 1 down domain port level 0 interface GigabitEthernet 1/1 #set vlan for MEP traffic mep 1 vid 3001 #set id of peer mep mep 1 peer-mep-id 5 #enable ccm;...
  • Page 149 ISW Commands mep 6 vid 3001 mep 6 peer-mep-id 4 mac D8-84-66-56-FE-2E mep 6 cc 7 fr10s mep 6 aps 7 raps erps 1 major port0 interface GigabitEthernet 1/1 port1 interface GigabitEthernet 1/2 erps 1 mep port0 sf 5 aps 5 port1 sf 6 aps 6 erps 1 vlan 1 You can check the ERPS (Ethernet Ring Protection Switching) status with the show erps command.

  • Page 150: Appendix A: Regulatory And Compliance Information

    Regulatory and Compliance Information Federal Communications Commission (FCC) Notice This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 151 Regulatory and Compliance Information FCC 47 CFR Part 15 Subpart B Class A (US), ICES-003 (Canada) EN 55022 (ITE Emissions), EN 55024 (ITE Immunity) 2014/30/EU (EMC Directive), EN 50121-4: 2006, EN 55011(ISM) EN 61000-6-2 (Ind. Immunity), EN61000-6-4 Ind. Emissions) RCM (Australia), MSIP KCC (Korea), BSMI (Taiwan) Korea EMC Statement (KCC) BSMI EMC Statement - Taiwan This is a Class A product.

  • Page 152: Glossary

    Glossary An Access Control List is a mechanism for filtering packets at the hardware level. Packets can be classified by characteristics such as the source or destination MAC, IP address, IP type, or QoS (Quality of Service) queue. Once classified, the packets can be forwarded, counted, queued, or dropped. ad-hoc mode An 802.11 networking framework in which devices or stations communicate directly with each other, without the use of an AP.
  • Page 153 Glossary BGP communicates within one AS using Interior BGP (IBGP) because BGP does not work well with IGP. Thus the routers inside the AS maintain two routing tables: one for the IGP and one for IBGP. BGP uses exterior BGP (EBGP) between different autonomous systems. BPDU In STP (Spanning Tree Protocol), a Bridge Protocol Data Unit is a packet that initiates communication between devices.
  • Page 154 Glossary In an MSTP (Multiple Spanning Tree Protocol) environment, Common and Internal Spanning Tree is a single spanning tree domain that connects MSTP regions. The CIST is responsible for creating a loop- free topology by exchanging and propagating BPDU (Bridge Protocol Data Unit)s across MSTP regions. You can configure only one CIST on each switch.
  • Page 155 Glossary Data Center Bridging is a set of IEEE 802.1Q extensions to standard Ethernet, that provide an operational framework for unifying Local Area Networks (LAN), Storage Area Networks (SAN) and Inter-Process Communication (IPC) traffic between switches and endpoints onto a single transport layer.
  • Page 156 Glossary Extreme Automatic Protection Switching is an Extreme Networks-proprietary version of the Ethernet Automatic Protection Switching protocol that prevents looping Layer 2 of the network. This feature is discussed in RFC 3619. ECMP Equal Cost Multi Paths is a routing algorithm that distributes network traffic across multiple high- bandwidth OSPF (Open Shortest Path First), BGP (Border Gateway Protocol), IS-IS, and static routes to increase performance.
  • Page 157 Glossary EAA, formerly Purview ™ , is a network powered application analytics and optimization solution that captures and analyzes context-based application traffic to deliver meaningful intelligence about applications, users, locations, and devices. EAA provides data to show how applications are being used. This can be used to better understand customer behavior on the network, identify the level of user engagement, and assure business application delivery to optimize the user experience.
  • Page 158 Glossary that 'hops' in a random but predictable sequence from frequency to frequency as a function of time over a wide band of frequencies. This technique reduces interference. If synchronized properly, a single logical channel is maintained. (Compare with DSSS (Direct-Sequence Spread Spectrum).) GARP Generic Attribute Registration Protocol registers an attribute with other participants.
  • Page 159 Glossary Internal Protocol Television uses a digital signal sent via broadband through a switched telephone or cable system. An accompanying set top box (that sits on top of the TV) decodes the video and converts it to standard television signals. In Independent VLAN Learning, every VLAN uses its own logical source address table, as opposed to SVL (Shared VLAN Learning), where two or more VLANs share the same part of the MAC address table.
  • Page 160 Glossary Message-Digest algorithm is a hash function that is commonly used to generate a 128-bit hash value. It was designed by Ron Rivest in 1991. MD5 is officially defined in RFC 1321 - The MD5 Message-Digest Algorithm. In CFM (Connectivity Fault Management), a Maintenance End Point is an end point for a single domain, or maintenance association.
  • Page 161 Glossary Multiple Spanning Tree Instances control the topology inside an MSTP (Multiple Spanning Tree Protocol) region. An MSTI is a spanning tree domain that operates within a region and is bounded by that region; and MSTI does not exchange BPDU (Bridge Protocol Data Unit)s or send notifications to other regions. You can map multiple VLAN (Virtual LAN)s to an MSTI;...
  • Page 162 Glossary features include least-cost routing, ECMP (Equal Cost Multi Paths) routing, and load balancing. Although OSPF requires CPU power and memory space, it results in smaller, less frequent router table updates throughout the network. This protocol is more efficient and scalable than vector-distance routing protocols.
  • Page 163 Glossary Radio Frequency is a frequency in the electromagnetic spectrum associated with radio wave propagation. When an RF current is supplied to an antenna, an electromagnetic field is created that can propagate through space. These frequencies in the electromagnetic spectrum range from Ultra-low frequency (ULF):0-3 Hz to Extremely high frequency (EHF): 30 GHz–300 GHz.
  • Page 164 Glossary Secure Shell, sometimes known as Secure Socket Shell, is a UNIX-based command interface and protocol of securely gaining access to a remote computer. With SSH commands, both ends of the client/server connection are authenticated using a digital certificate, and passwords are protected by being encrypted.
  • Page 165 Glossary In Shared VLAN Learning, two or more VLANs are grouped to share common source address information in the MAC table. The common entry in the MAC table is identified by a Filter ID (FID). SVL is useful for configuration of more complex, asymmetrical cross-VLAN traffic patterns, like E-TREE (Rooted-Multipoint) and Multi-netted Server.

  • Page 166: Virtual Router

    Glossary Transition Security Network is a subset of RSN (Robust Security Network), which provides an enhanced security solution for legacy hardware. The Wi-Fi Alliance has adopted a solution called WPA, based on TSN. RSN and TSN both specify IEEE 802.1x authentication with Extensible Authentication Protocol (EAP).
  • Page 167 Glossary Wired Equivalent Privacy is a security protocol for WLAN (Wireless Local Area Network)s defined in the 802.11b standard. WEP aims to provide security by encrypting data over radio waves so that it is protected as it is transmitted from one end point to another. WLAN Wireless Local Area Network.
