iLive ITBSW397 User Manual

37 inch hd soundbar + wireless subwoofer
Hide thumbs

Advertisement

37" HD Soundbar
+ Wireless Subwoofer
User's Guide for Model ITBSW397 v1824-01
For the most up-to-date version of this User's Guide, go to www.iliveelectronics.com

Advertisement

loading

  Also See for iLive ITBSW397

  Related Manuals for iLive ITBSW397

  Summary of Contents for iLive ITBSW397

  • Page 1 37" HD Soundbar + Wireless Subwoofer User’s Guide for Model ITBSW397 v1824-01 For the most up-to-date version of this User’s Guide, go to www.iliveelectronics.com...
  • Page 2 Safety Instructions & Warnings WARNING: To reduce the risk of electric CAUTION shock, do not remove cover (or back). No RISK OF ELECTRIC SHOCK DO NOT OPEN user-serviceable parts inside. Refer servicing ATTENTION to qualified service personnel. RISQUE D' ÉLECTROCUTION NE PAS OUVRIR The exclamation point within an equilateral triangle is intended to alert the user to...
  • Page 3: Important Safety Instructions

    Important Safety Instructions Additional Warnings and Precautions • Read these Instructions. • CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY • Keep these Instructions. INSERT. • Heed all Warnings. • Mains plug is used as disconnect device and it should remain •...
  • Page 4: Table Of Contents

    Table of Contents Setup ....................5 Features &...
  • Page 5: Setup

    Setup Features & Specifications • Full-function remote with learning capability • 37" length • Optical digital audio input • Wireless subwoofer • Line In (3.5mm audio input) • Supports Bluetooth • Aux In (RCA stereo audio inputs) • Wireless range: 60 ft. •...
  • Page 6: Orientation

    Orientation Rear View DC IN OPTICAL IN LINE IN AUX IN SUB OUT Wall Mount Pegs Speaker Inputs Speaker Inputs Detail DC IN OPTICAL IN LINE IN AUX IN SUB OUT Optical Input Line In ( 3.5mm audio input) Stereo RCA Audio Inputs (AUX IN) Subwoofer Output DC Power Input...
  • Page 7: Front View

    Front View Remote IR Receiver & Function Indicator Lights Speaker Controls (Right Side) Power Press to power the unit ON or OFF. Source/Connect POWER Press to switch between Optical, Line In, Aux In, and Bluetooth modes. Press and hold to wirelessly connect to SOURCE/CONNECT the subwoofer (see pg.12).
  • Page 8: Remote

    Remote Power Mute Press to turn Press to mute the unit on or off. the volume. Treble Press to adjust the Press to switch treble up or down. to Bluetooth Mode. Bass Line In Press to adjust the Press to switch bass up or down.
  • Page 9: Bluetooth Wireless

    When pairing, remain within 3 feet of the unit. 3. Use the controls on your Bluetooth device to select ITBSW397 in your Bluetooth settings. If your device requests a password, enter the default password 0 0 0 0 . Consult the user’s manual for your specific device for more detailed instructions on pairing Bluetooth devices.
  • Page 10: Audio Inputs

    Audio Inputs Aux In (Stereo RCA Inputs) Requires RCA stereo audio cable (not included). When connecting an RCA stereo audio cable (Red/White), match the colored ports to their corresponding plugs. 1. Connect the RCA stereo audio cable (not included) to the RCA Stereo Inputs on the soundbar and the audio outputs on a television or other audio source.
  • Page 11 Aux In (Stereo RCA Inputs) - Detail DC IN OPTICAL IN LINE IN AUX IN SUB OUT Optical Input - Detail DC IN OPTICAL IN LINE IN AUX IN SUB OUT Line In - Detail DC IN OPTICAL IN LINE IN AUX IN SUB OUT DC IN...
  • Page 12: Subwoofer

    DC IN OPTICAL IN LINE IN AUX IN SUB OUT DC IN SUB IN DC IN SUB IN DC IN OPTICAL IN LINE IN AUX IN SUB OUT Wired Subwoofer ITBSW397 (example only) Soundbar...
  • Page 13: Learn Feature

    Learn Feature What is the Learn Feature? This will teach the soundbar to function with a separate remote control, such as the remote for your television or a universal remote. Teaching the bar speaker remote commands will reduce the number of remotes needed and generally improve the ease of operation.
  • Page 14: Company Information

    Company Information Contact Information Warranty For Warranty Information and the most up-to-date Website: www.iLiveElectronics.com version of this User’s Guide, go to: Email Support: prodinfo@dpiinc.com www.iLiveElectronics.com Email Parts: partsinfo@dpiinc.com Phone Support: 1-888-999-4215 International Support To download this User’s Guide in English, Spanish, and French, or to get answers to frequently asked questions, visit the support section at: www.iLiveElectronics.com Para descargar este Manual del Usuario en inglés, español y francés, o para obtener respuestas a preguntas frecuentes, visite la sección de apoyo en: www.iLiveElectronics.com...
