- Page 1 VTW73M ◆ 7.3 Inch Car Rear View Mirror Monitor with Built-In Miracast VTW73M...
-
Page 2: Table Of Contents
Table of Contents User's Manual Chapter One: Product Introduction ........1 Welcome to use our 7.3 inch car rear view mirror monitor with built-in miracast 1.1 Package. -
Page 3: Chapter One: Product Introduction
1.4 Front buttons operation Chapter One: Product Introduction 1.1 Package The packing box contains the following accessories. Please confirm: ● 7.3 inch car rear view mirror monitor with mirror link ● Wire harness ● User's manual ● Wire cover ● Remote control Please check your package box for the items listed above. - Page 4 Speaker Connector Special bracket Red to ACC+ Black to GND Trigger line 1 Back car signal Video input Camera Connector cover Cable cover...
-
Page 5: Chapter Two: Installation And Wiring
2.2 Special bracket Chapter Two: Installation and Wiring 2.1 How to install Remove the original mirror Remove the original rear view mirror and remain Original car rear view mirror the metal based on the windscreen Different cars have different brackets. It depends on your vehicle maker and manufacturer. -
Page 6: How To Wire
2.3 How to wire The reversing signal is input to rear view mirror by connecting the green line. Therefore, reversing video can be displayed automatically on the wide 7.3 inch LCD monitor. The advisable installation position for camera Black to GND Red to ACC +12V green Back up video... -
Page 7: Chapter Three: Adjustable Guide Line
Chapter Three: Adjustable Guide Line 3.3 How to adjust the guide line According to the site of standard reference line, we can put reference objects such as desks in the back side of the car. Compared with the marked reference objects, 3.1 About guide line we can adjust the sites and angles of two guide lines are displayed on the monitor. -
Page 8: Chapter Four: Menu Setting
4.2.2 COLOR ADJUSTMENT Chapter Four: Menu Setting The defaulted setting is 50, ranging from 0 to 100, and only CVBS signal can work. 4.1 Remote control The menu only can be set by remote control, and kindly check its definition as below. Menu parameter increases Enter picture menu Menu parameter decreases... -
Page 9: Chapter Five: Built-In Miracast
4.2.5 START LOGO ADJUSTMENT Chapter Five: Built-In Miracast It is defaulted as “ON”, you can set it to “OFF” manually. This is a special device to project your mobile phone to rear view mirror monitor through Wi-Fi connection, and the popular standards like DLNA, Miracast and Air Play. - Page 10 5.1.2 How to connect with iPhone 1: Click the “M” button on TP button, switch the wireless mode to iOS mode. “M”button tap here tap here tap here After finishing the connection, then the phone screen is projected to the rear view mirror, you can press “CH”...
-
Page 11: Channel Switching
5.2.2 Full VIDEO1 screen display After finishing the connection, then the phone screen is projected to the rear view mirror, you can press “CH” on TP button to choose “double mobile dual mode”or “single-screen mode”. 5.2.3 Full MOBILE screen display 5.2 Channel switching Press the “CH”... - Page 12 Please note: 5.2.4 VIDEO1 and MOBILE display simultaneously 1. Both Reversing mode and non-reversing mode have seven states: built-in miracast, video+built-in miracast, built-in miracast+video, camera+built-in miracast, built-in miracast+camera, full video screen, and full camera screen. 2. Power on each time, the screen automatically keep the last status before the shut down. There are total eight states or styles---seven are listed as above, and off-screen state.
-
Page 13: Chapter Six: Firmware Update
AP. In this case, mobile phone /laptop/tablet should be connected to dongle by using soft AP again. “If new iOS releases, VTW73M may require new firmware update for Miracast function. Availability of New firmware update may take awhile after Apple's released new iOS.”...
