1
Operator Manual
HIS-5000 5X (Huvitz Imaging System)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HIS-5000 and is the answer not in the manual?

Questions and answers

Arthur Friedman
March 29, 2025

I tried to select an image , when I clicked on the image it appeared to be selected , when I tried to print it there’s a message says “select an image” what’s wrong?

0
1 comments:
Mr. Anderson
May 14, 2025

The "select an image" message when trying to print on the Huvitz HIS-5000 could be caused by not selecting an image before attempting to print. You must select a specific image first, such as in the Compare Images window, where actions like zoom or analysis require an image to be selected with the mouse.

This answer is automatically generated

0

Related Manuals for Huvitz HIS-5000

Summary of Contents for Huvitz HIS-5000

  • Page 1 -----------------------------------------------------------------------------------HIS-5000 5X User Guide Operator Manual HIS-5000 5X (Huvitz Imaging System)
  • Page 2 HUVITZ reserves the right to make changes in its products or product specifications at any time and without prior notice, and is not required to update this documentation to reflect such changes.

  • Page 3: Table Of Contents

    -----------------------------------------------------------------------------------HIS-5000 5X User Guide CONTENTS INTRODUCTION......................5 1.1..................5 UTLINE OF THE INSTRUMENT 1.2......................5 LASSIFICATION SAFETY INFORMATION ....................6 2.1......................6 NTRODUCTION FEATURES ........................7 SYSTEM INSTALLATION....................8 4.1....................8 OFTWARE NSTALLATION 4.2....................12...
  • Page 4 HIS-5000 5X User Guide -------------------------------------------------------------------------- MEASUREMENT ......................38 7.1......................38 AMERA TART 7.2....................... 40 AMERA APTURE 7.3......................41 AMERA 7.4......................42 AMERA ESET 7.5..................... 42 AMERA ROPERTY 7.5..................... 43 AMERA ROPERTY IMAGE MANIPULATION ..................... 44 8.1.

  • Page 5: Introduction

    1.1. Outline of the instrument HIS-5000 5X (Huvitz Imaging System) is digital imaging system for slit lamp to measure and examine patient’s eye by digital imaging from high resolution digital camera. HIS-5000 5X has PC based imaging software, C-mount typed camera...

  • Page 6: Safety Information

    HIS-5000 5X User Guide -------------------------------------------------------------------------- Safety Information 2.1. Introduction Safety is everyone’s responsibility. The safe use of this equipment is largely dependent upon the installer, user, operator, and maintainer. It is imperative that personnel study and become familiar with this entire manual before attempting to install, use, clean, service or adjust this equipment and any associated accessories.

  • Page 7: Features

    -----------------------------------------------------------------------------------HIS-5000 5X User Guide Features HIS-5000 5X software manages patient’s eye images and examination information using database, and supports powerful search function by multiple conditions like diagnosis, disease, patient history, etc. Implemented user interface are well unified and intuitive, user can easily switch interesting patient information and choose eye images.

  • Page 8: System Installation

    Software Installation Step 1. Running Setup Program When HIS-5000 5X installation CD is inserted into CD-ROM, setup program starts automatically by auto-run. If it doesn’t work or is installing from local or network drive, manually run HIS-5000 5X.exe in folder by double click.
  • Page 9 -----------------------------------------------------------------------------------HIS-5000 5X User Guide Step 2. Setup Program Window Click ‘Next’ button. Step 3. End User License Agreement After reading End User License Agreement, click ‘I Agree’ button, then click Next.
  • Page 10 HIS-5000 5X User Guide -------------------------------------------------------------------------- Step 4. Install Folder Select a folder to install HIS-5000 5X software. The default path is ‘C: \Program Files\Huvitz\HIS_5000’, click ‘Browse’ button to change it. Click ‘Install’ button, it starts installation. After installation completed, confirm a okay message to register Camera driver...
  • Page 11 -----------------------------------------------------------------------------------HIS-5000 5X User Guide DLL. Step 5. Running HIS-5000 5X Software Check ‘Run application’ to start HIS-5000 5X Software immediately after this installation, then click ‘OK’ button.

  • Page 12: Camera Installation

    4.2. Camera Installation Step 1. Exiting HIS-5000 5X Software If HIS-5000 5X software is running, it must to be stopped before starting camera installation. Step 2. Preparing IEEE-1394 Interface Confirm that PC has available Fire-wire interface (IEEE-1394) port, if not, prepare extension card and install it into your PC.
  • Page 13 -----------------------------------------------------------------------------------HIS-5000 5X User Guide If installed driver is different, try updating it as following process. (Contact with your PC or Fire-wire interface card maker about details.) Select Generic 1394 host controller under IEEE 1394 Bus host controllers. Click right button of mouse, then select ‘Update Driver…’ in popup menu.
  • Page 14 HIS-5000 5X User Guide -------------------------------------------------------------------------- Select ‘Install from a list or specific location (Advanced) in Hardware Update Wizard window. Select ‘Don’t search, I will choose the driver to install’, and click ‘Next’ button.
  • Page 15 -----------------------------------------------------------------------------------HIS-5000 5X User Guide Select ‘OHCI Compliant IEEE 1394 Host Controller’ in Show compatible hardware list, and click ‘Next’ button. Click ‘Finish’ button to complete.
  • Page 16 HIS-5000 5X User Guide -------------------------------------------------------------------------- INFORMATION Generally, Fire-wire interface has two types of connections, 6 pin port (with power pins) or 4 pin port (without power pins). Camera module needs power supply via Fire-wire connection, so if your PC has just any 4 pin port, you should add Fire-wire expansion card having 6 pin port.
  • Page 17 -----------------------------------------------------------------------------------HIS-5000 5X User Guide Step 3. Installing Camera Driver Connect camera module with PC via Fire-wire cable. If this connection is the first try after software installation, then pop-up New Hardware Wizard window. Select ‘Install from a list or specific location (Advanced)’, then click Next.
  • Page 18 HIS-5000 5X User Guide -------------------------------------------------------------------------- Select ‘FireWire Digital Camera’ in Show compatible hardware list, then click Next button. Click ‘Continue Anyway’ in Hardware Installation window.
  • Page 19 -----------------------------------------------------------------------------------HIS-5000 5X User Guide Click Finish button to complete. Go to Windows Device Manager, then confirm that camera driver name is ‘FireWire Digital Camera’ under Imaging devices.
  • Page 20 HIS-5000 5X User Guide -------------------------------------------------------------------------- Step 4. Starting Camera Display Run HIS-5000 5X software, then click ‘Start Camera’ button in menu bar. Click ‘Start Camera’ button in camera window.
  • Page 21 -----------------------------------------------------------------------------------HIS-5000 5X User Guide Step 5. Updating Camera Driver After software and camera driver installation, if camera module is changed to another one and connected, its camera driver may be recognized as wrong device, or the new version of camera driver is released, it needs to update.

  • Page 22: Main Window

    HIS-5000 5X User Guide -------------------------------------------------------------------------- Main Window When you run HIS-5000 5X software, it shows Main Window like [Figure 1], which is the starting point of all other windows. Main Window is composed of menu bar, tool bar, thumbnail list, patient list.

  • Page 23: Usage Of Main Menu

    -----------------------------------------------------------------------------------HIS-5000 5X User Guide 5.1. Main Menu Main Menu is composed of the following menu items. [Exit] Ends HIS-5000 5X software. Note that all changes of patient information and eye images are saved automatically before closing it. [Physicians] Opens Physician Management window to register physician information which can be assigned for Visit Information of patient.

  • Page 24: Usage Of Main Toolbar

    HIS-5000 5X User Guide -------------------------------------------------------------------------- 5.2. Main Toolbar Main Toolbar is composed of the following menu buttons. [New Patient] Opens New Patient window to insert patient information. Newly added patient’s name and patient ID (optional) will show up at top of patient list of main window with an exam named today’s date.
  • Page 25 -----------------------------------------------------------------------------------HIS-5000 5X User Guide [Start Camera] Opens Camera Window to display and capture image from camera. Note that camera module must be connected before starting camera, if not, error message will shows up. Captured images are added into currently selected exam in patient list, and shows up in thumbnail list.
  • Page 26 HIS-5000 5X User Guide -------------------------------------------------------------------------- [Compare Images] Opens Compare Window to examine images in parallel. Note that it must be selected over two images in thumbnail list of main window before starting Compare Window. [Adjust Color] Starts Adjust Color mode instead of thumbnail list in main window.
  • Page 27 -----------------------------------------------------------------------------------HIS-5000 5X User Guide [Slide Show] Opens Slideshow Window to display full screen sized image. Note that it must be selected over one image in thumbnail list to start. [Reference Image] Opens Reference Image Window to register image as reference.
  • Page 28 HIS-5000 5X User Guide -------------------------------------------------------------------------- [Show Patient Info] Opens Patient Information Window to edit the selected patient. [Show Visit Info] Opens Visit Information Window to edit the selected exam.

  • Page 29: Patient Management

    -----------------------------------------------------------------------------------HIS-5000 5X User Guide Patient Management 6.1. Patient Register [Figure 2. Patient Register Dialog box] When [New Patient] button of the toolbar presses, with Figure 3 the patient registration dialog box appears. ① First Name It inputs the Surname of the patient.
  • Page 30 HIS-5000 5X User Guide -------------------------------------------------------------------------- ③ Patient ID It inputs the ID of the patient. ④ Gender It probably is a male, it probably is a female, it selects. ⑤ Birth Date It inputs a birth date of the patient. It will show today’s date as default.

  • Page 31: Patient Search & Open

    -----------------------------------------------------------------------------------HIS-5000 5X User Guide 6.2. Patient Search & Open [Figure 4. Patient Search Dialog box] When [Search Patient]->[Open] button of the toolbar presses, with Figure 5 the Patient search dialog box appears. The First Name or Last Name it inputs the item and [Search] button it presses it inspects the list of the patient who is register comes out.

  • Page 32: Patient Information

    HIS-5000 5X User Guide -------------------------------------------------------------------------- 6.3. Patient Information When [Show Patient Info] button of the menu bar presses, currently information dialog box of the patient who is selected appears. This dialog box is same with patient registration dialog box. It confirms information about the patient and charge surgeon and unique fact.
  • Page 33 -----------------------------------------------------------------------------------HIS-5000 5X User Guide When [Show Visit Info] button of the menu bar presses, currently the Visit dialog box of the patient who is selected appears. It will be able to confirm all Exam information about one patient and from charge surgeon’s opinion, unique fact, patient image and so on..

  • Page 34: Physician, Photographer Register

    HIS-5000 5X User Guide -------------------------------------------------------------------------- 6.5. Physician, Photographer Register [Figure 7. Physician Management Dialog box] When [Physician] button of the menu bar presses, appears physician management dialog box. ① Registered Physicians It shows the physician which is register. ② Physician Name It register it inputs the physician name.

  • Page 35: Patient Image Function

    -----------------------------------------------------------------------------------HIS-5000 5X User Guide INFORMATION It seems to the photographer register dialog box with the physician register dialog box, and it will be able to register and delete. 6.6. Patient Image Function it select an image from the Thumbnail bar and when it will press the mouse’s right button and with Figure 8 the same menu window will appear and it will be able to accomplish a some function about an image.
  • Page 36 HIS-5000 5X User Guide -------------------------------------------------------------------------- ① Eye Side It shows the direction which probably is a right eye(OD), probably is a left eye(OS) where the eye image which is measured. (OD/OS/Unknown) CAUTION The Joystick it use the button and Becomes the indication which it probably is a right eye(OD), it probably is a left eye(OS), but [Camera Capture] button, it uses the button at the PC and it is indicated ‘unknown’...

  • Page 37: Patient Exam Delete

    -----------------------------------------------------------------------------------HIS-5000 5X User Guide 6.7. Patient Exam Delete When it selects a visit date from patient list area, it will be able to confirm the image which is measured. All it selects the image which is measured and the mouse’s right button presses and when [Delete] it selects, the image is deleted.

  • Page 38: Measurement

    HIS-5000 5X User Guide -------------------------------------------------------------------------- Measurement 7.1. Camera Start When [Start Camera] button of the toolbar presses, with Figure 10 the Camera measurement dialog box appears. When it is like that, measurement it is to be a condition which is possible.
  • Page 39 -----------------------------------------------------------------------------------HIS-5000 5X User Guide [Camera Start] It starts the camera which measures an image. CAUTION With above the same error window will float and there is not a possibility which it will measure and, This it means that the camera driver is not well established.

  • Page 40: Camera Capture

    HIS-5000 5X User Guide -------------------------------------------------------------------------- 7.2. Camera Capture [Camera Capture] When the camera is started, the eye image of the patient appears and it stores this button the still screen consecutively from the screen which it wants measuring. [Camera Capture] button in the camera window, this button will be able to measure the image which wants measuring.

  • Page 41: Camera Stop

    -----------------------------------------------------------------------------------HIS-5000 5X User Guide When with Figure 11 it presses the measurement button, the image which is measured Thumbnail bar appears. To above the image which is measured it probably is a right eye(OD), left eye(OS), it is indicated, the file name of image appear. The image which is measured does not appear in the screen view and the camera image continuously appears at real-time.

  • Page 42: Camera Reset

    HIS-5000 5X User Guide -------------------------------------------------------------------------- 7.4. Camera Reset [Camera Reset] It initializes the camera property. Initializes the settings of the camera at the setting value where the camera is initially set of goods from a company. 7.5. CAUTION The possibility of trying to adjust the setting of the camera it is, but don’t adjust the setting of the camera, in order to become accurately initial setting.

  • Page 43: Camera Property

    -----------------------------------------------------------------------------------HIS-5000 5X User Guide Camera Property [Camera Setting] It regulates the settings of the camera. [Camera Setting] button in the camera window, this button will be able to adjust the setting of the camera. [Figure 12. Camera Property]...

  • Page 44: Image Manipulation

    HIS-5000 5X User Guide -------------------------------------------------------------------------- Image Manipulation The HIS-5000 5X software prepares the image manipulation tool which is various digital conversion of the image which is measured it leads accurate and there is a possibility of showing the image. It will select the image and is possible various manipulation.
  • Page 45 -----------------------------------------------------------------------------------HIS-5000 5X User Guide Previous Next Image Image Reload Bright & Image Contrast Invert Components Satuation Sharpness Red Free Gray Color Insert as Save Image Copy Delete Close Image [Figure 14. Adjust Color Toolbar] Zoom In / Out It will be able to Zoom In/out the image. When it presses the mouse’s left button, the image will be Zoom In, When it presses the mouse’s right button,...
  • Page 46 HIS-5000 5X User Guide -------------------------------------------------------------------------- Next Image It shows the next image from image of present. Reload Image It demobilizes with image of original. It will turn back around the image which is converted with image of original. Bright & Contrast It adjust in percent to brightness &...
  • Page 47 -----------------------------------------------------------------------------------HIS-5000 5X User Guide [Figure 16. Invert] Saturation It adjust in percent to saturation of image. Sharpness It leads and image it is clear and it regulates by the filter. Red Free It removes the Red component of image and it indicates.

  • Page 48: Overlay Image

    HIS-5000 5X User Guide -------------------------------------------------------------------------- 8.2. Overlay Image [Figure 17. Overlay Images window] It selects multiple images and when [Overlay Images] button of the toolbar presses, with Figure 17 the Overlay Images window appears. It piles up the image above the screen and the place where it compares and analyzes an image it is used.
  • Page 49 -----------------------------------------------------------------------------------HIS-5000 5X User Guide Invert It converts with the image of upset. Gray Color It converts an image with 12bit B/W image. Flip Image It turn over an image with top and bottom and it indicates. Reverse Image It turn over an image with right and left and it indicates.

  • Page 50: Compare Image

    HIS-5000 5X User Guide -------------------------------------------------------------------------- 8.3. Compare Image [Figure 18. Compare Images window] It selects multiple images and when [Compare Images] button of the tool bar presses, with Figure 18 the Compare Images window appears. This window are composed the buttons of almost similar function with the Overlay Images window and it compares and analyzes they are used about the multiple images.
  • Page 51 -----------------------------------------------------------------------------------HIS-5000 5X User Guide Next Image It shows the next image from image of present. Invert It converts with the image of upset. Gray Color It converts an image with 12bit B/W image. Flip Image It turn over an image with top and bottom and it indicates.

  • Page 52: Reference Image

    HIS-5000 5X User Guide -------------------------------------------------------------------------- 8.4. Reference Image [Figure 19. Reference Images window] It selects an images and when [Reference Images] button of the tool bar presses, with Figure 19 the Reference Images window appears. With the image which is selected...
  • Page 53 -----------------------------------------------------------------------------------HIS-5000 5X User Guide Next Image It shows the next image from image of present. Delete Image It deletes the image which is register. Insert as Reference It register with reference image.

  • Page 54: Make Report

    HIS-5000 5X User Guide -------------------------------------------------------------------------- 8.5. Make Report [Figure 20. Make Report window] It selects an images and when [Make Report] button of the tool bar presses, with Figure 20 it creates with word(.doc) file of report form.

  • Page 55: Specification

    -----------------------------------------------------------------------------------HIS-5000 5X User Guide Specification Technical Characters Image sensor 1/2 “ Inch interline CCD Picture size Up to 1388 x 1036 pixels Cell Size 4.65 µm x 4.65 µm Resolution Depth 8 bit or 12 bit Raw RGB, YUV4:2:2 Digital Interface...
  • Page 56 HIS-5000 5X User Guide -------------------------------------------------------------------------- Hardware and Software suggested requirements Processor Pentium IV, 2GHz 512 MB (over 1 GB recommended) Video Card ATI Radeon 9200 (128 MB) or similar Microsoft Windows NT (with Service Pack 6), Windows 2000 (with Service Pack 4), Operating System Windows XP.

  • Page 57: 10. Service Information

    -----------------------------------------------------------------------------------HIS-5000 5X User Guide 10. Service Information How to contact service: If there are any problems with the equipment, please follow the steps below: First of all, refer to the 10. Appendix sections according to the problem that you are encountered. And then follow the suggested sequences.
  • Page 58 HIS-5000 5X User Guide -------------------------------------------------------------------------- the service department of the HUVITZ using the phone number and the address written in the below table. How to Contact HUVITZ Co., Ltd Write us at: HUVITZ Co., Ltd. Tel: +82-31-442-8868 Huvitz B/D, Fax: +82-31-442-8619 689-3 Geumjeong-dong URL:http://www.huvitz.com...
  • Page 59 --------------------------------------------------------------------- HIS-5000 System Install Guide System Install Manual HIS-5000 (Huvitz Imaging System)
  • Page 60 HUVITZ reserves the right to make changes in its products or product specifications at any time and without prior notice, and is not required to update this documentation to reflect such changes.
  • Page 61 --------------------------------------------------------------------- HIS-5000 5X System Install Guide CONTENTS COMPONENT AND ACCESSORIES 1.1 For HS-5000( HS-7000) (HAAG TYPE)…………..…….………………………………..4 1.2 For HS-5500,(HS-7500) (ZEISS TYPE)…………………………………………………..5 SYSTEM INSTALLATION 2.1 For HS-5000( HS-7000) (HAAG TYPE)……..………………………………………………6 2.1.1. The Case which will be combined the Slit-lamp, HS-5000(HS-7000)……………………6 2.1.2. The Case which will not be combined the Slit-lamp, HS-5000(HS-7000)…..……………13 2.2 For HS-5500( HS-7500) (ZEISS TYPE)…….………………………………………………..25...
  • Page 62 HIS-5000 5X System Install Guide--------------------------------------------------------------------- Component and Accessories 1.1 HIS-5000 5X for HS-5000( HS-7000) (HAAG TYPE) (1) Camera Ass’y (2) Camera communication cable (3) Auxiliary light cable (4) FireWire IEEE 1394 cable (5) Software CD (6) Light sensor plate (7) Light sensor PCB...
  • Page 63 --------------------------------------------------------------------- HIS-5000 5X System Install Guide 1.2, HIS-5000 5X for HS-5500( HS-7500) (ZEISS TYPE) (1) Camera Ass’y (2) Camera communication cable (3) FireWire IEEE 1394 cable (4) Software CD (5) Light sensor plate (6) Light sensor PCB (7) Auxiliary light Ass’y...

  • Page 64: For Hs-5000( Hs-7000) (Haag Type)

    2.1 For HS-5000( HS-7000) (HAAG TYPE) 2.1.1 The Case which will be combined the Slit-lamp, HS-5000(HS-7000) The case where the HIS-5000 5X is combined in the Slit-lamp, HS-5000(HS-7000) the R/L sensor PCB or auxiliary light ass’y will become establishment. It will affix the camera module which is included consequently in the accessories and it will be able to establish the HIS-5000 5X.
  • Page 65 --------------------------------------------------------------------- HIS-5000 5X System Install Guide Step 2. Combine Auxiliary light cable. It combines the cable in auxiliary light Ass’y and supporter.
  • Page 66 HIS-5000 5X System Install Guide--------------------------------------------------------------------- Step 3. Combine Camera Ass’y. The Microscope separates and after affixing a camera ass’y, it combines again...
  • Page 67 --------------------------------------------------------------------- HIS-5000 5X System Install Guide Step 4. Connect cable on the Camera Ass’y. It connects the camera communication cable and the IEEE 1394 cable in camera ass’y. Step 5. Connect Camera communication cable. It connects the camera communication cable in the base.
  • Page 68 HIS-5000 5X System Install Guide--------------------------------------------------------------------- Step 6. Fix the cable. It fixes in the cable fixation holder and it does there not to be an effect in operation. Step 7. Combine FireWire IEEE 1394 PCI Card It establishes the FireWire IEEE 1394 PCI card in the PCI slot of the PC. The notebook establishes the FireWire IEEE 1394 PCMCIA card in the ramyon PCMCIA slot.
  • Page 69 --------------------------------------------------------------------- HIS-5000 5X System Install Guide Step 9. Be sure the PC is turned off. Turn on the PC and turn on the Slit-lamp, HS-5000(HS-7000).

  • Page 70: The Case Which Will Not Be Combined The Slit-Lamp, Hs-5000(Hs-7000)

    HIS-5000 5X System Install Guide--------------------------------------------------------------------- 2.1.2 The Case which will not be combined the Slit-lamp, HS-5000(HS-7000) To install HIS-5000 5X system, perform the following steps: Step 1. Disassemble the HS-5000(HS-7000). It refers to Manual of the HS-5000(HS-7000) and after separating, the base together...
  • Page 71 --------------------------------------------------------------------- HIS-5000 5X System Install Guide Step 2. Combine Light sensor PCB. It connects in the light sensor PCB socket and it affixes the PCB.
  • Page 72 HIS-5000 5X System Install Guide--------------------------------------------------------------------- Step 3. Combine Base cover. Step 4. Affix Light sensor plate.
  • Page 73 --------------------------------------------------------------------- HIS-5000 5X System Install Guide Step 5. Affix Cable fixation holder. It combines the HS-5000(HS-7000) and it attaches the cable fixation holder in microscope arm.
  • Page 74 HIS-5000 5X System Install Guide--------------------------------------------------------------------- Step 6. Combine Scatter. Step 7. Combine Auxiliary light cable supporter. It lifts the scaled ring and it affixes it fixes the auxiliary light cable supporter.
  • Page 75 --------------------------------------------------------------------- HIS-5000 5X System Install Guide Step 8. Disassemble lamp cover. It separates the lamp cover and it separates the inner cover.
  • Page 76 HIS-5000 5X System Install Guide--------------------------------------------------------------------- Step 9. Disassemble light Ass’y. It separates the light ass’y.
  • Page 77 --------------------------------------------------------------------- HIS-5000 5X System Install Guide Step 10. Combine Auxiliary light Ass’y. It affixes the auxiliary light Ass’y...
  • Page 78 HIS-5000 5X System Install Guide--------------------------------------------------------------------- Step 11. Combine Auxiliary light cable. It combines the cable in auxiliary light Ass’y and supporter.
  • Page 79 --------------------------------------------------------------------- HIS-5000 5X System Install Guide...
  • Page 80 HIS-5000 5X System Install Guide--------------------------------------------------------------------- Step 12. Combine Camera Ass’y. The Microscope separates and after affixing a camera ass’y, it combines again.
  • Page 81 --------------------------------------------------------------------- HIS-5000 5X System Install Guide Step 13. Connect cable on the Camera Ass’y. It connects the camera communication cable and the IEEE 1394 cable in camera ass’y. Step 14. Connect Camera communication cable. It connects the camera communication cable in the base.
  • Page 82 HIS-5000 5X System Install Guide--------------------------------------------------------------------- Step 15. Fix the cable. It fixes in the cable fixation holder and it does there not to be an effect in operation. Step 16. Combine FireWire IEEE 1394 PCI Card It establishes the FireWire IEEE 1394 PCI card in the PCI slot of the PC. The notebook establishes the FireWire IEEE 1394 PCMCIA card in the ramyon PCMCIA slot.
  • Page 83 --------------------------------------------------------------------- HIS-5000 5X System Install Guide Step 18. Be sure the PC is turned off. Turn on the PC and turn on the Slit-lamp, HS-5000.(HS-7000)

  • Page 84: For Hs-5500( Hs-7500) (Zeiss Type)

    2.2 For HS-5500( HS-7500) (ZEISS TYPE) 2.1.1 The Case which will be combined the Slit-lamp, HS-5500(HS-7500) The case where the HIS-5000 5X is combined in the Slit-lamp, HS-5500(HS-7500) the R/L sensor PCB or auxiliary light ass’y will become establishment. It will affix the camera module which is included consequently in the accessories and it will be able to establish the HIS-5000 5X.
  • Page 85 --------------------------------------------------------------------- HIS-5000 5X System Install Guide Step 2. Connect cable on the Camera Ass’y. It connects the camera communication cable and the IEEE 1394 cable in camera ass’y.
  • Page 86 HIS-5000 5X System Install Guide--------------------------------------------------------------------- Step 3. Connect Camera communication cable. It connects the camera communication cable in the base. Step 4 Fix the cable. It fixes in the cable fixation holder and it does there not to be an effect in operation.
  • Page 87 --------------------------------------------------------------------- HIS-5000 5X System Install Guide Step 5 Combine Auxiliary light Ass’y It combines the auxiliary light Ass’y in HS-5500(HS-7500) Step 6. Connect Auxiliary light Ass’y cable. It connects the Auxiliary light Ass’y cable in the SMPS...
  • Page 88 HIS-5000 5X System Install Guide--------------------------------------------------------------------- Step 7. Combine FireWire IEEE 1394 PCI Card It establishes the FireWire IEEE 1394 PCI card in the PCI slot of the PC. The notebook establishes the FireWire IEEE 1394 PCMCIA card in the ramyon PCMCIA slot.

  • Page 89: The Case Which Will Not Be Combined The Slit-Lamp, Hs-5500(Hs-7500)

    --------------------------------------------------------------------- HIS-5000 5X System Install Guide 2.2.2 The Case which will not be combined the Slit-lamp, HS-5500(HS-7500) To install HIS-5000 5X system, perform the following steps:...
  • Page 90 HIS-5000 5X System Install Guide--------------------------------------------------------------------- Step 1. Disassemble the HS-5500(HS-7500). It refers to Manual of the HS-5500(HS-7500) and after separating, the base together with the picture it turns over.
  • Page 91 --------------------------------------------------------------------- HIS-5000 5X System Install Guide Step 2. Combine Light sensor PCB. It connects in the light sensor PCB socket and it affixes the PCB.
  • Page 92 HIS-5000 5X System Install Guide--------------------------------------------------------------------- Step 3. Combine Base cover. Step 4. Affix Light sensor plate.
  • Page 93 --------------------------------------------------------------------- HIS-5000 5X System Install Guide Step 5. Affix Cable fixation holder. It combines the HS-5500(HS-7500) and it attaches the cable fixation holder in microscope arm.
  • Page 94 HIS-5000 5X System Install Guide--------------------------------------------------------------------- Step 6. Combine Camera Ass’y. The Microscope separates and after affixing a camera ass’y, it combines again...
  • Page 95 --------------------------------------------------------------------- HIS-5000 5X System Install Guide Step 7. Connect cable on the Camera Ass’y. It connects the camera communication cable and the IEEE 1394 cable in camera ass’y. Step 8. Connect Camera communication cable. It connects the camera communication cable in the base.
  • Page 96 HIS-5000 5X System Install Guide--------------------------------------------------------------------- Step 9 Fix the cable. It fixes in the cable fixation holder and it does there not to be an effect in operation.
  • Page 97 --------------------------------------------------------------------- HIS-5000 5X System Install Guide Step 10 Combine Auxiliary light Ass’y It combines the auxiliary light Ass’y in HS-5500(HS-7500) Step 11. Connect Auxiliary light Ass’y cable. It connects the Auxiliary light Ass’y cable in the SMPS...
  • Page 98 HIS-5000 5X System Install Guide--------------------------------------------------------------------- Step 12. Combine FireWire IEEE 1394 PCI Card It establishes the FireWire IEEE 1394 PCI card in the PCI slot of the PC. The notebook establishes the FireWire IEEE 1394 PCMCIA card in the ramyon PCMCIA slot.

  • Page 99: Service Information

    Dealer Phone No. : Model No.: Serial No.:  If you can’t contact with your local distributor, you can directly get in touch with the service department of the HUVITZ using the phone number and the address written in the below table.
  • Page 100 HIS-5000 5X System Install Guide--------------------------------------------------------------------- How to Contact HUVITZ Co., Ltd Write us at: Tel: +82-31-442-8868 HUVITZ Co., Ltd. Fax: +82-31-442-8619 Huvitz B/D, 689-3 Geumjeong-dong URL:http://www.huvitz.com Gunpo-si Gyeonggi-do, South Korea e-mail: info@huvitz.com 435-862...
