- Page 1 Aleis ISO-FFW Series Operational Manual Reader User Guide ISO-FFW Series Reader ISO-FFW-6000 Standard unit with Read and On LEDs Only ISO-FFW-8030 Display and 8030 Keypad ISO-FFW-8030-EXP With 9000 expansion board fitted ISO-FFW-8030- EXP-CLK With 9000 expansion board and Clock fitted...
-
Page 2: Table Of Contents
Aleis ISO-FFW Series Operational Manual TABLE OF CONTENTS Regularity Notices and Conformity ..............................4 ISO-FFW Series Reader Instructions ..............................5 The Aleis ISO-FFW Series System ............................6 Preparation for Use ...................................7 Warnings ....................................7 Care and Maintenance ................................7 Methods of connection ................................8 5.1 Direct connection with your scale indicator: ..........................8 5.2 Direct connection with your computer: ..........................8... - Page 3 Load Defaults ..............................40 17.37 Set Date/Time ..............................41 17.38 RFM Settings ..............................41 17.4 Reader Information ................................41 17.5 Memory Status ................................... 42 18.0 ISO-FFW SERIES Reader Specifiactions ..........................42 19.0 Aleis Conditions of Sale ................................43 3 of 45...
-
Page 4: Regularity Notices And Conformity
Consult the dealer or an experienced radio/TV technician for help Modification warning (FCC Part 15.21) Warning: Any changes or modifications not expressively approved by Aleis could void the user's authority to operate this equipment. Canada This Class B digital apparatus complies with Canadian ICES-003. -
Page 5: Iso-Ffw Series Reader Instructions
Non-conformance to the handling and operating instructions will immediately void all warranties for the antenna/reader and software. 1. WARNING: All Aleis warranties will be immediately voided if this reader is used in any way with Hyperterminal. -
Page 6: The Aleis Iso-Ffw Series System
Aleis ISO-FFW Series Operational Manual THE ALEIS ISO-FFW SERIES SYSTEM The ISO-FFW series is available in different configurations ISO-FFW-6000 Standard unit with Read and On LEDs Only ISO-FFW-8030 Display and 8030 Keypad ISO-FFW-8030-EXP With 9000 expansion board fitted ISO-FFW-8030- EXP-CLK... -
Page 7: Preparation For Use
Protect computer and power leads from animals if the system is left in the yards. Treat the system with care; Aleis has built this system for the cattle yards, but it is an electronic unit and must be treated accordingly. -
Page 8: Methods Of Connection
Direct connection with your computer: The ISO-FFW Series Reader can also link directly with your computer. The Aleis ISO-FFW Series Reader is compatible with all major herd management programs accepting a standard real-time RFID from a reader. You may need to contact your herd management software provider for exact setup instructions. -
Page 9: Optional Power
Aleis ISO-FFW Series Operational Manual OPTIONAL POWER Only use high quality regulated linear power supplies or solar panels. Please contact Aleis with any queries, you may have. Some switch mode power supplies are NOT suitable and must not be used. -
Page 10: How To: Read & Store Rfids
2. A working COM port – you can check this by turning your 8030 reader on, and then opening Aleis DataLink. Down the bottom right corner of the Aleis DataLink screen, you should see that the software has connected to a particular unit. -
Page 11: How To: Compare Rfids In The Reader
DataLink screen (there is a big yellow manilla folder on the button). 3. Find the file that you created, and click on the open button. 4. You will see that file name listed in the main screen of Aleis DataLink where the session names and numbers are normally displayed. - Page 12 Aleis ISO-FFW Series Operational Manual 11. Scroll down to Alert and press the OK button. 12. Ensure Condition is highlighted and press the OK button. 13. Scroll down to On Match and press the OK button – you will see a tick appear in the box.
-
Page 13: Formatting The File System
Aleis ISO-FFW Series Operational Manual 9.6 Formatting the File System Formatting of the file system is very important to keep your reader operating at its maximum performance. Once the reader has read and stored a lot of tags eg 40000+ you may notice a slow down in its performance when storing and recalling data. -
Page 14: Iso-Ffw8030 Menu Tree
Aleis ISO-FFW Series Operational Manual 10.0 ISO-FFW8030 MENU TREE The readers menu has 5 main menu and several sub menu items Session Read Setup System Setup Reader Information Memory Status 10.1 Session Menu 14 of 45... -
Page 15: Read Setup Menu
Aleis ISO-FFW Series Operational Manual 10.2 Read Setup Menu 15 of 45... -
Page 16: System Setup Menu
Aleis ISO-FFW Series Operational Manual 10.3 System Setup Menu 16 of 45... -
Page 17: Reader Information Menu
Aleis ISO-FFW Series Operational Manual 10.4 Reader Information Menu 10.5 Memory Status Menu 17 of 45... -
Page 18: Iso-Ffw8030 Audio And Visual Alerts
Aleis ISO-FFW Series Operational Manual 11.0 ISO-FFW8030 AUDIO AND VISUAL ALERTS Features Buzzer LCD Display LED’s at Top of LCD Alert LED’s – 2 on the top left side of the screen. Valid READ One beep Current RFID number, eg. -
Page 19: Iso-Ffw8030 Menu
12.0 ISO-FFW8030 MENU Main Menu (Reader selection choices) 12.1 Session 12.11 Starts a New Session 12.12 Send to PC Sends the RFIDs in the memory to the PC There are two options: Current Session All Sessions 12.13 Clear Clears the readers memory. There are two options: Current Session All Sessions 12.14 Select... -
Page 20: System Setup
Aleis ISO-FFW Series Operational Manual On Match On No-Match No Send 12.3 System Setup 12.31 Communications Interface Sets the interface the RFID is send out when a tag is read Serial RF Modem Bluetooth Protocol Sets the protocol string when a RFID is read or when... -
Page 21: Buzzer
Aleis ISO-FFW Series Operational Manual (Select required contrast Eg 90 = light contrast. 120= very dark. Subject to viewing angle) 12.33 Buzzer Turns the Buzzer On/Off 12.34 Sleep Timer Sets the Sleep Timer. The unit will turn off to save battery power if it is not... -
Page 22: Reader Information
Aleis ISO-FFW Series Operational Manual Sets TX sync mode to master or slave unit (only applicable to Wired Sync Mode). Slave Master 12.4 Reader Information (This is for technical assistance only & product identification) Reader Info Hardware: (Hardware Version) Software:... -
Page 23: The Iso-Ffw9060 Qwerty Keypad
Aleis ISO-FFW Series Operational Manual 13.0 THE ISO-FFW9060 QWERTY KEYPAD Data Entry Keys Function Keys Directional Keys Menu Keys Page 23 of 45... -
Page 24: Iso-Ffw9060 Reader Methods Of Use
Aleis ISO-FFW Series Operational Manual 14.0 ISO-FFW9060 READER METHODS OF USE There are four general methods of reading and recording data. Please read each method and follow instructions covering the method you choose with your 9060 series system. 14.1 Record RFID No’s only (no data entry) Turn Reader ON. - Page 25 Aleis ISO-FFW Series Operational Manual Field Default Data When setting up template there is no need to have a date field as this will record automatically and print with the report. There are four data fields available per template. Field column allows for three letters/numbers only for each field.
-
Page 26: Templates
Aleis ISO-FFW Series Operational Manual Session will be highlighted, press OK. will be highlighted, press OK. Follow same instructions from beginning. If same fields are required, select Same Fields instead of Blank (as in step 5) 14.3 Templates Setup New Template... - Page 27 Aleis ISO-FFW Series Operational Manual River When finished, press C (located to the left of MENU button) to return to the session screen. Lock Template From Session press down arrow to select Data Entry Locking. Press OK. By pressing OK in any box locks data to prevent it accidentally being changed when typing data into reader.
- Page 28 Aleis ISO-FFW Series Operational Manual When finished press OK. Message appears Template Saved, press OK. Press C three times to return to main reading screen. Reader is ready to read first group of animals. This process can be carried out well before using the reader.
-
Page 29: Data Entry Using Function Keys For A Pre Made Template
Aleis ISO-FFW Series Operational Manual 14.4 Data Entry using Function Keys for a pre made Template 9060 Series Function Keys 9060 series Function Keys are designed to make entering data into reader simple and quick. The function of each key is explained to the right of that key, as an example, the F1 key is used to start a new session. -
Page 30: How To: Upload Rfids Into The Reader
5. A working COM port – you can check this by turning your 9060 reader on, and then opening Aleis DataLink. Down the bottom right corner of the Aleis DataLink screen, you should see that the software has connected to a particular unit. -
Page 31: How To: Compare Rfids In The Reader
DataLink screen (there is a big yellow manilla folder on the button). 11. Find the file that you created, and click on the open button. 12. You will see that file name listed in the main screen of Aleis DataLink where the session names and numbers are normally displayed. -
Page 32: Formatting The File System
Aleis ISO-FFW Series Operational Manual 14.7 Formatting the File System Formatting of the file system is very important to keep your reader operating at its maximum performance. Once the reader has read and stored a lot of tags eg 40000+ you may notice a slow down in its performance when storing and recalling data. -
Page 33: Iso-Ffw9060 Menu Tree
Aleis ISO-FFW Series Operational Manual 15.0 ISO-FFW9060 MENU TREE The readers menu has 5 main menu and several sub menu items Session Read Setup System Setup Reader Information Memory Status 15.1 Session Menu Page 33 of 45... -
Page 34: Read Setup Menu
Aleis ISO-FFW Series Operational Manual 15.2 Read Setup Menu Page 34 of 45... -
Page 35: System Setup Menu
Aleis ISO-FFW Series Operational Manual 15.3 System Setup Menu Page 35 of 45... -
Page 36: Reader Information Menu
Aleis ISO-FFW Series Operational Manual 15.4 Reader Information Menu 15.5 Memory Status Menu Page 36 of 45... -
Page 37: Iso-Ffw9060 Audio And Visual Alerts
Aleis ISO-FFW Series Operational Manual 16.0 ISO-FFW9060 AUDIO AND VISUAL ALERTS Features Buzzer LCD Display LEDs at Top of LCD 6 Auxiliary LEDs – 3 each side of the screen Valid READ One beep Current RFID number, eg. READ LED blinks once... -
Page 38: Iso-Ffw9060 Menu
Aleis ISO-FFW Series Operational Manual 17.0 ISO-FFW9060 MENU 17.1 Session 17.11 Starts a New Session 17.12 Data Entry Setup - Sets up Data Entry Fields 17.13 Data Entry Locking - Sets up Data Entry Locking Fields 17.14 Templates Session Template... -
Page 39: Storage
Aleis ISO-FFW Series Operational Manual Action Sets the Alert Action There are 3 options: Msg = Message on screen Msg,LED’s = Message & Lights Msg, LED’s, Buzzer = Message, Lights & Buzzer Duration Sets the Alert Duration. There are 4 options... -
Page 40: Display
Aleis ISO-FFW Series Operational Manual ISO 26 Digit ISO 27 Digit 15 Digit 16 Digit Scale Interface Sets scale type, overrides Tag Output Format, Serial Baud Rate, and Download Format to suit the scale’s requirements. No Scales Ruddweigh Thunderbird Tru-Test 17.32 Display... -
Page 41: Set Date/Time
Aleis ISO-FFW Series Operational Manual 17.37 Set Date/Time -Sets Date and Time 17.38 RFM Settings FDX/HDX Mode Sets the readers FDX/HDX mode FDX/HDX With Boost FDX Only HDX Only With Boost FDX/HDX FDX/HDX Rx Only Ant Tune Mode Selects Auto or manual antenna tuing. -
Page 42: Memory Status
Aleis ISO-FFW Series Operational Manual 17.5 Memory Status Used Memory X% Percentage of Used Memory Free Memory X% Percentage of Free Memory Reclaimable Memory X% Percentage of Recoverable Cleared Memory (old Sessions) 18.0 ISO-FFW SERIES READER SPECIFIACTIONS General Frequency: 134.2Khz RFID Compatibility: ISO 11784 &11785 HDX and FDX-B... -
Page 43: Aleis Conditions Of Sale
ALEIS CONDITIONS OF SALE In these conditions: `Vendor' means Aleis Pty Ltd ACN 081 411 734 of Cnr Old Rosevale & Jandowae/Kingaroy Roads, Jandowae, Queensland, 4410 which is the seller of the goods ‘Factory’ means the Vendor’s principal place of business at Cnr Old Rosevale & Jandowae/Kingaroy Roads, Jandowae, Queensland,4410. - Page 44 Aleis ISO-FFW Series Operational Manual all freight is paid by the purchaser. If goods are not manufactured by vendor the guarantee of the manufacturer thereof shall be accepted by the purchaser and is the only guarantee given to purchaser in respect of the goods.
- Page 45 Aleis ISO-FFW Series Operational Manual Vendor shall not be under any obligation to accept goods returned by the purchaser and will do so only on terms to be agreed in writing in each individual case. All goods to be supplied by vendor shall be as described on the quotation overleaf and the description on such order modified as so agreed shall prevail over all other descriptions including any purchaser's specification or inquiry.
