Power Panel 300/400
User's Manual
Version: 2.30 (July 2010)
Model number: MAPP300.400-ENG
All information contained in this manual is current as of its creation/publication. We reserve the
right to change the contents of this manual without warning. The information contained herein is
believed to be accurate as of the date of publication; however, Bernecker + Rainer Industrie-
Elektronik Ges.m.b.H. makes no warranty, expressed or implied, with regards to the products or
the documentation contained within this book. In addition, Bernecker + Rainer Industrie-
Elektronik Ges.m.b.H. shall not be liable in the event of incidental or consequential damages in
connection with or resulting from the furnishing, performance, or use of these products. The
software names, hardware names, and trademarks used in this manual are registered by the
respective companies.
Power Panel 300/400 User's Manual V 2.30
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Power Panel 300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for B&R Industries Power Panel 300

Summary of Contents for B&R Industries Power Panel 300

  • Page 1 Elektronik Ges.m.b.H. shall not be liable in the event of incidental or consequential damages in connection with or resulting from the furnishing, performance, or use of these products. The software names, hardware names, and trademarks used in this manual are registered by the respective companies. Power Panel 300/400 User's Manual V 2.30...
  • Page 2 Power Panel 300/400 User's Manual V 2.30...
  • Page 3 Chapter 1: General information Chapter 2: Technical data Chapter 3: Commissioning Chapter 4: Software Chapter 5: Standards and certifications Chapter 6: Accessories Power Panel 300/400 User's Manual V 2.30...
  • Page 4 Power Panel 300/400 User's Manual V 2.30...
  • Page 5 Chapter 7: Maintenance / Servicing Anhang A Figure index Table index Model number index Index Power Panel 300/400 User's Manual V 2.30...
  • Page 6 Power Panel 300/400 User's Manual V 2.30...

  • Page 7: Table Of Contents

    Chapter 2: Technical data .............. 39 1. General information ......................39 1.1 Features ........................40 1.2 Advantages of Power Panel 300/400 over Power Panel 100/200 ......... 41 1.2.1 Electrical ......................... 41 1.2.2 Mechanical ......................41 2. Power Panel 300 with BIOS ....................42 2.1 Device interfaces ......................
  • Page 8 2.9.2 Temperature humidity diagram ................100 2.9.3 Dimensions ......................101 2.9.4 Cutout installation ....................102 2.9.5 Contents of delivery ....................102 2.10 Device 5PP320.1505-3B ................... 103 2.10.1 Technical data ..................... 104 2.10.2 Temperature humidity diagram ................107 Power Panel 300/400 User's Manual V 2.30...
  • Page 9 2.10.3 Dimensions ......................108 2.10.4 Cutout installation ....................109 2.10.5 Contents of delivery .................... 109 3. Power Panel 300 with Automation Runtime ..............110 3.1 Device interfaces ......................110 3.1.1 Supply voltage ...................... 110 3.1.2 Functional grounding clip ..................111 3.1.3 Serial interface COM .....................
  • Page 10 4.3.3 Dimensions ......................187 4.3.4 Cutout installation ....................188 4.3.5 Contents of delivery ....................188 4.4 Device 4PP420.0571-65 ..................... 189 4.4.1 Technical data ....................... 190 4.4.2 Temperature humidity diagram ................193 4.4.3 Dimensions ......................194 Power Panel 300/400 User's Manual V 2.30...
  • Page 11 4.11.2 Temperature humidity diagram ................242 4.11.3 Dimensions ......................243 4.11.4 Cutout installation ....................244 4.11.5 Contents of delivery .................... 244 4.12 Device 4PP420.1505-75 ................... 245 4.12.1 Technical data ..................... 246 4.12.2 Temperature humidity diagram ................249 Power Panel 300/400 User's Manual V 2.30...
  • Page 12 4.19.1 Technical data ..................... 295 4.19.2 Temperature humidity diagram ................298 4.19.3 Dimensions ......................299 4.19.4 Cutout installation ....................300 4.19.5 Contents of delivery .................... 300 4.20 Device 4PP451.1043-B5 ................... 301 4.20.1 Technical data ..................... 302 Power Panel 300/400 User's Manual V 2.30...
  • Page 13 4.27 Device 4PP480.1505-75 ................... 350 4.27.1 Technical data ..................... 351 4.27.2 Temperature humidity diagram ................354 4.27.3 Dimensions ......................355 4.27.4 Cutout installation ....................356 4.27.5 Contents of delivery .................... 356 4.28 Device 4PP480.1505-B5 ................... 357 Power Panel 300/400 User's Manual V 2.30...
  • Page 14 5.3 Power Panel 452 light / compact ................. 410 5.3.1 Technical data - Power Panel 452 light ..............410 5.3.2 Temperature humidity diagram ................413 5.3.3 Technical data - Power Panel 452 compact ............414 5.3.4 Temperature humidity diagram ................417 Power Panel 300/400 User's Manual V 2.30...
  • Page 15 Table of contents 6. Block diagram ........................418 6.1 Power Panel 300 (with no aPCI slots) ................. 418 6.2 Power Panel 400 with 1 aPCI slot ................419 6.3 Power Panel 400 with 2 aPCI slots ................420 Chapter 3: Commissioning ............421 1.
  • Page 16 2. Power Panel 300/400 with Automation Runtime .............. 484 2.1 General information ..................... 484 2.1.1 Summary screen ....................484 2.2 Control and visualization with the Power Panel 300 device ........485 2.3 Power Panel 400 with Power Panel 300 terminals ............486 2.4 Software updates ......................487 3.
  • Page 17 4.5 Conducted disturbances ....................523 4.6 Magnetic fields with electrical frequencies ..............524 4.7 Voltage dips, fluctuations, and short-term interruptions ..........524 4.8 Damped vibration ......................525 5. Mechanical conditions ...................... 526 5.1 Vibration operation ...................... 526 Power Panel 300/400 User's Manual V 2.30...
  • Page 18 5.3.1 Temperature humidity diagram - Operation and storage ........548 5.4 Dimensions ........................548 5.5 Benchmark ........................549 6. CompactFlash cards 5CFCRD.xxxx-03 ................550 6.1 General information ..................... 550 6.2 Order data ........................550 Power Panel 300/400 User's Manual V 2.30...
  • Page 19 4.2.2 10.4" devices ......................575 4.2.3 12.1" devices ......................577 4.2.4 15" devices ......................578 5. B&R Key Editor information ....................579 6. B&R Automation Device Interface (ADI) development kit ..........581 7. Glossary ..........................583 Power Panel 300/400 User's Manual V 2.30...
  • Page 20 Table of contents Power Panel 300/400 User's Manual V 2.30...

  • Page 21: Chapter 1: General Information

    - "Distribution of resources" on page 481 added. - "VESA mode support" on page 512 added. - "Power Panel 300/400 with Automation Runtime" on page 484 added. - aPCI slot cover added. - "Legend strip templates" on page 543 added.
  • Page 22 - "Distribution of resources" on page 481 updated. - "Automation Runtime summary screen - ex. 4PP420.1043-75" on page 484 changed. - Rear views added. - Chapter "Power Panel 300 with BIOS" on page 429 updated. 1.20 2007-04-20 - USB flash drive 5MMUSB.0256-00 and USB flash drive 5MMUSB.1024-00 cancelled - "Automation Runtime summary screen - ex.
  • Page 23 4PP452.0571-B5 and 5PP320.0571-39 - changes made to the technical data of the displays. - Section 7.4 "Creating a bootable USB flash drive", changed on page 479. - B&R CompactFlash card added. - Technical data for Silicon Systems CFs revised. Table 1: Manual history (Forts.) Power Panel 300/400 User's Manual V 2.30...
  • Page 24 - Section 7.4 "Creating a bootable USB flash drive" updated and moved to page 499. - Section 3.7 "Creating a bootable CompactFlash card for B&R upgrade files" on page 501 added - Section 2 "Power Panel 400 with Automation Runtime" changed to "Power Panel 300/400 with Automation Runtime" on page 484.

  • Page 25: Safety Guidelines

    Components can only be touched on the small sides or on the front plate. • Components should always be stored in a suitable medium (ESD packaging, conductive foam, etc.). Metallic surfaces are not suitable storage surfaces! Power Panel 300/400 User's Manual V 2.30...

  • Page 26: Policy And Procedures

    2.4 Transport and storage During transport and storage, devices must be protected from excessive stress (mechanical load, temperature, humidity, aggressive atmospheres, etc.). Power Panel 300/400 User's Manual V 2.30...

  • Page 27: Installation

    Automation Panel or Power Panel are protected on the front side. The rear side of all devices must be protected from dust and humidity and must be cleaned at suitable intervals. Power Panel 300/400 User's Manual V 2.30...

  • Page 28: Programs, Viruses And Dangerous Programs

    Operating and monitoring devices Uninterruptible power supply Cables Cardboard box / paper packaging Paper / cardboard recycling Plastic packaging Plastic recycling Table 2: Environmentally-friendly separation of materials Disposal must comply with the respective legal regulations. Power Panel 300/400 User's Manual V 2.30...

  • Page 29: Organization Of Safety Notices

    Disregarding the safety regulations and guidelines can result in injury or damage to material. Information: Important information for preventing errors. Table 3: Organization of safety notices 4. Guidelines European dimension standards apply to all dimensions (e.g. dimension diagrams, etc.). Power Panel 300/400 User's Manual V 2.30...

  • Page 30: Model Numbers

    (type I), ETH 10/100, RS 232, 2xUSB; battery; metal housing, IP65 protection (front side); 24VDC (Order screw clamp 0TB103.9 or cage clamp 0TB103.91 separately.) Table 4: Model number overview - Power Panel 300 devices Power Panel 300/400 User's Manual V 2.30...

  • Page 31: Power Panel 300 With Automation Runtime

    128 MB SDRAM; CompactFlash slot (type I); ETH 10/100; RS232; 2xUSB; metal housing, IP65 protection (front side); 24 VDC (Order screw clamp 0TB103.9 or cage clamp 0TB103.91 separately.) Table 5: Model number overview - Power Panel 300 devices Power Panel 300/400 User's Manual V 2.30...

  • Page 32: Power Panel 400 With Automation Runtime

    KB SRAM; CompactFlash slot (Type I); ETH 10/100; RS232; 2xUSB; battery; metal housing, IP65 protection (front side); 24 VDC (Order 0TB103.9 screw clamp or 0TB103.91 cage clamp separately). Table 6: Model number overview - Power Panel 400 devices Power Panel 300/400 User's Manual V 2.30...
  • Page 33 512 KB SRAM; CompactFlash slot (type I); ETH 10/100; RS232; 2xUSB; battery; metal Cancelled since housing, IP65 protection (front side); 24VDC (Order screw clamp 0TB103.9 or cage clamp 4/2008 0TB103.91 separately.) Table 6: Model number overview - Power Panel 400 devices (Forts.) Power Panel 300/400 User's Manual V 2.30...
  • Page 34 1 aPCI slot; 128 MB SDRAM; 512 KB SRAM; CompactFlash slot (type I); ETH 10/100; RS232; 2xUSB; battery; metal housing, IP65 protection (front side); 24 VDC (Order screw clamp 0TB103.9 or cage clamp 0TB103.91 separately.) Table 6: Model number overview - Power Panel 400 devices (Forts.) Power Panel 300/400 User's Manual V 2.30...

  • Page 35: Power Panel 400 Light / Compact

    Power Panel PP451 light TFT color, X2X, keys See page 402 Set Power Panel PP451 light X2X; 5.7'' QVGA TFT color; 128 MB SDRAM; 512 KB SRAM. Table 7: Model number overview - Power Panel light / compact devices Power Panel 300/400 User's Manual V 2.30...

  • Page 36: Software

    See page 503 Microsoft Windows CE 5.0 Professional Plus, English; for PP300 BIOS devices 5PP320.0571-29, 5PP320.0571-39, 5PP320.0573-39, 5PP320.1043-39, 5PP320.1214-39, 5PP320.1505-39, order CompactFlash separately (at least 128 MB). Table 8: Model number overview - software Power Panel 300/400 User's Manual V 2.30...

  • Page 37: Accessories

    Order CompactFlash separately (min. 512 MB). Windows Embedded Standard 2009 PP300 LX800 See page 509 5SWWXP.0721-ENG Microsoft OEM Windows embedded Standard 2009, English; for Power Panel 300; please or- der CompactFlash separately (minimum 1 GB). 5SWWXP.0722-ENG Windows Embedded Standard 2009 PP400 LX800 See page 509 Microsoft OEM Windows embedded Standard 2009, English;...
  • Page 38 RS232 DB9 null modem cable 1.8 m See page 559 Null modem cable RS232 1.8 m to connect UPS and IPC (9-pin DSUB socket - 9-pin DSUB socket) Table 9: Model number overview - accessories (Forts.) Power Panel 300/400 User's Manual V 2.30...

  • Page 39: Chapter 2: Technical Data

    PCs. For the Power Panel 300 and the Power Panel 400, B&R also implements the proven product lines of BIOS devices (Power Panel 300) and embedded devices (Power Panel 300 and Power Panel 400).

  • Page 40: Features

    BIOS (Windows XP Embedded, Windows CE 5.0 or 6.0) or Automation Runtime operating system • Real-time clock (battery-buffered) • Up to 512 MB SDRAM main memory 1) Depending on the design of the particular Power Panel device. Power Panel 300/400 User's Manual V 2.30...

  • Page 41: Advantages Of Power Panel 300/400 Over Power Panel 100/200

    Technical data • General information 1.2 Advantages of Power Panel 300/400 over Power Panel 100/200 1.2.1 Electrical • More powerful processor (Geode LX800 = more than twice the performance) • 180° rotated power supply plug • Insyde BIOS • Power button •...

  • Page 42: Power Panel 300 With Bios

    Technical data • Power Panel 300 with BIOS 2. Power Panel 300 with BIOS 2.1 Device interfaces The following section provides a description of all interfaces and plugs possible with a PowerPanel 300 device with BIOS. 2.1.1 Supply voltage Input voltage: 18 - 30 VDC The 3-pin socket required for the supply voltage connection is not included in delivery.

  • Page 43: Functional Grounding Clip

    Technical data • Power Panel 300 with BIOS 2.1.2 Functional grounding clip Next to the supply voltage plug there is a functional grounding clip. The grounding clip (functional ground) must be connected with a central grounding point on the switching cabinet using a 6.3 mm blade connector via the shortest distance and with as little resistance as possible (e.g.

  • Page 44: Serial Interface Com

    Technical data • Power Panel 300 with BIOS 2.1.3 Serial interface COM The Power Panel is equipped with a PC-compatible serial interface with a 16-byte FIFO buffer. This non-electrically isolated interface is primarily intended for programming Power Panel devices using Automation Studio.

  • Page 45: Usb Port

    Technical data • Power Panel 300 with BIOS 2.1.4 USB port The Power Panel 300/400 devices have a USB 2.0 (Universal Serial Bus) host controller with multiple USB ports, two of which are on the outside for easy user access.

  • Page 46: Mode / Node Switches

    Technical data • Power Panel 300 with BIOS 2.1.5 Mode / Node switches Power Panel devices are equipped with 2 hex switches that serve as operating mode switches. Switch positions 01 to FD are available for any purpose in an application and can be evaluated by the application program.

  • Page 47: Bios Boot Mode Switch

    Technical data • Power Panel 300 with BIOS 2.1.6 BIOS boot mode switch Power Panel devices are equipped with a BIOS boot mode switch. Figure 5: BIOS boot mode switch Switch position Function Description Right (toward CF slot) OS mode The Power Panel will boot in OS mode.
  • Page 48 Technical data • Power Panel 300 with BIOS OS mode • Standard Boot Screen (see section 1 "Power Panel 300 with BIOS" on page 429) • BIOS Setup can be started by pressing the "DEL" key. • When the switch is in the "00" position, the setup default values will be restored after restarting three times.

  • Page 49: Status Leds

    Technical data • Power Panel 300 with BIOS 2.1.7 Status LEDs Power Panels are equipped with two status LEDs that are visible on the outside. Status LEDs Color Meaning Green Supply voltage OK 1x three-color, 1x one-color The system is in standby mode...

  • Page 50: Power Button

    Technical data • Power Panel 300 with BIOS 2.1.9 Power button Due to the complete ATX power supply support, the power button serves a number of functions, which can be configured in BIOS setup. Power button The power button can be pressed with a pointed object (i.e.

  • Page 51: Compactflash Slot

    Technical data • Power Panel 300 with BIOS 2.1.11 CompactFlash slot Power Panel devices are equipped with a CompactFlash slot that is accessible from the side. Type I CompactFlash cards are supported. Ejection lever Safety latch Figure 6: CompactFlash slot It is possible to secure the CompactFlash slot using the latch provided.

  • Page 52: Stickers

    Technical data • Power Panel 300 with BIOS 2.2 Stickers 2.2.1 Device label The following sticker can be found in a suitable location on the Power Panel device: Figure 7: Device label 2.2.2 Serial number sticker General information Each B&R device is given a unique serial number sticker with a barcode that allows the device to be clearly identified.
  • Page 53 Technical data • Power Panel 300 with BIOS Information on the Internet Information about each device can also be found on the B&R homepage. Enter the device's serial number in the serial number search field on the start page www.br-automation.com. The search also works if you enter the model number or the material number in the material number search field.

  • Page 54: Device 5Pp320.0571-29

    Technical data • Power Panel 300 with BIOS 2.3 Device 5PP320.0571-29 Figure 10: Front view - 5PP320.0571-29 Battery compartment Grounding clip Power button Reset button Supply voltage CompactFlash slot (with latch) Ethernet Status LEDs (x1) (x16) Figure 11: Rear view - 5PP320.0571-29...

  • Page 55: Technical Data

    Technical data • Power Panel 300 with BIOS 2.3.1 Technical data Features 5PP320.0571-29 B&R ID-Code $23CE Boot loader / Operating system BIOS Processor Type Geode LX800 500 MHz, 32-bit x86 Expanded command set MMX technology, 3D Now L1 cache 128 KB (64 KB L cache / 64 KB D cache)
  • Page 56 Technical data • Power Panel 300 with BIOS Features 5PP320.0571-29 Serial interface Type RS232, modem-capable, not electrically isolated UART 16C550 compatible, 16-byte FIFO Transfer rate Max. 115 kBaud Connection 9-pin DSUB USB interface Type USB 1.1, USB 2.0 Amount Transfer rate Low speed (1.5 MBit/s), full speed (12 MBit/s) to high speed (480 MBit/s)
  • Page 57 Technical data • Power Panel 300 with BIOS Electrical characteristics 5PP320.0571-29 Power supply Rated voltage 18 - 30 VDC Rated current 0.45 A Starting current Max. 1.2 A Power consumption Typically 10 W Electrical isolation 0 Ω Bleeder resistance Mechanical characteristics...

  • Page 58: Temperature Humidity Diagram

    Technical data • Power Panel 300 with BIOS 7) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 2.3.2 Temperature humidity diagram Operation Temperature [°C] Figure 12: Temperature humidity diagram - 5PP320.0571-29...

  • Page 59: Dimensions

    Technical data • Power Panel 300 with BIOS 2.3.3 Dimensions 46.5 Nominal measurement General tolerance from range DIN ISO 2768 medium ± 0.1 mm up to 6 mm ± 0.2 mm over 6 to 30 mm ± 0.3 mm over 30 to 120 mm ±...

  • Page 60: Cutout Installation

    Technical data • Power Panel 300 with BIOS 2.3.4 Cutout installation The cutout hole is to be made according to the following dimensions for cutout installation. The device must be mounted using the retaining clips included in delivery. Outer contour (Power Panel) 149.5...

  • Page 61: Device 5Pp320.0571-39

    Technical data • Power Panel 300 with BIOS 2.4 Device 5PP320.0571-39 Figure 15: Front view - 5PP320.0571-39 Battery compartment Grounding clip Power button Reset button Supply voltage CompactFlash slot (with latch) Ethernet Status LEDs (x1) (x16) Figure 16: Rear view - 5PP320.0571-39...

  • Page 62: Technical Data

    Technical data • Power Panel 300 with BIOS 2.4.1 Technical data 5PP320.0571-39 ≥ Rev. D0 Features 5PP320.0571-39 < Rev. D0 B&R ID-Code $A15D Boot loader / Operating system BIOS Processor Type Geode LX800 500 MHz, 32-bit x86 Expanded command set...
  • Page 63 Technical data • Power Panel 300 with BIOS 5PP320.0571-39 ≥ Rev. D0 Features 5PP320.0571-39 < Rev. D0 Serial interface Type RS232, modem-capable, not electrically isolated UART 16C550 compatible, 16-byte FIFO Transfer rate Max. 115 kBaud Connection 9-pin DSUB USB interface Type USB 1.1, USB 2.0...
  • Page 64 Technical data • Power Panel 300 with BIOS 5PP320.0571-39 ≥ Rev. D0 Electrical characteristics 5PP320.0571-39 < Rev. D0 Power supply Rated voltage 18 - 30 VDC Rated current 0.45 A Starting current Max. 1.2 A Power consumption Typically 10 W Electrical isolation 0 Ω...

  • Page 65: Temperature Humidity Diagram

    Technical data • Power Panel 300 with BIOS 7) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 2.4.2 Temperature humidity diagram Operation Temperature [°C] Figure 17: Temperature humidity diagram - 5PP320.0571-39...

  • Page 66: Dimensions

    Technical data • Power Panel 300 with BIOS 2.4.3 Dimensions 46.5 Nominal measurement General tolerance from range DIN ISO 2768 medium up to 6 mm ± 0.1 mm ± 0.2 mm over 6 to 30 mm ± 0.3 mm over 30 to 120 mm ±...

  • Page 67: Cutout Installation

    Technical data • Power Panel 300 with BIOS 2.4.4 Cutout installation The cutout hole is to be made according to the following dimensions for cutout installation. The device must be mounted using the retaining clips included in delivery. Outer contour (Power Panel) 149.5...

  • Page 68: Device 5Pp320.0573-39

    Technical data • Power Panel 300 with BIOS 2.5 Device 5PP320.0573-39 Figure 20: Front view - 5PP320.0573-39 Battery compartment Grounding clip Power button Reset button Supply voltage CompactFlash slot (with latch) Ethernet Status LEDs (x1) (x16) Figure 21: Rear view - 5PP320.0573-39...

  • Page 69: Technical Data

    Technical data • Power Panel 300 with BIOS 2.5.1 Technical data Features 5PP320.0573-39 B&R ID-Code $23CF Boot loader / Operating system BIOS Processor Type Geode LX800 500 MHz, 32-bit x86 Expanded command set MMX technology, 3D Now L1 cache 128 KB (64 KB L cache / 64 KB D cache)
  • Page 70 Technical data • Power Panel 300 with BIOS Features 5PP320.0573-39 Serial interface Type RS232, modem-capable, not electrically isolated UART 16C550 compatible, 16-byte FIFO Transfer rate Max. 115 kBaud Connection 9-pin DSUB USB interface Type USB 1.1, USB 2.0 Amount Transfer rate Low speed (1.5 MBit/s), full speed (12 MBit/s) to high speed (480 MBit/s)
  • Page 71 Technical data • Power Panel 300 with BIOS Electrical characteristics 5PP320.0573-39 Power supply Rated voltage 18 - 30 VDC Rated current 0.54 A Starting current Max. 1.2 A Power consumption 13 W typical Electrical isolation 0 Ω Bleeder resistance Mechanical characteristics...

  • Page 72: Temperature Humidity Diagram

    Technical data • Power Panel 300 with BIOS 7) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 2.5.2 Temperature humidity diagram Operation Temperature [°C] Figure 22: Temperature humidity diagram - 5PP320.0573-39...

  • Page 73: Dimensions

    Technical data • Power Panel 300 with BIOS 2.5.3 Dimensions 46.5 Nominal measurement General tolerance from range DIN ISO 2768 medium up to 6 mm ± 0.1 mm ± 0.2 mm over 6 to 30 mm ± 0.3 mm over 30 to 120 mm ±...

  • Page 74: Cutout Installation

    Technical data • Power Panel 300 with BIOS 2.5.4 Cutout installation The cutout hole is to be made according to the following dimensions for cutout installation. The device must be mounted using the retaining clips included in delivery. Outer contour (Power Panel) 149.5...

  • Page 75: Device 5Pp320.0573-3B

    Technical data • Power Panel 300 with BIOS 2.6 Device 5PP320.0573-3B Figure 25: Front view - 5PP320.0573-3B Battery compartment Grounding clip Power button Reset button Supply voltage CompactFlash slot (with latch) Ethernet Status LEDs (x1) (x16) Figure 26: Rear view - 5PP320.0573-3B...

  • Page 76: Technical Data

    Technical data • Power Panel 300 with BIOS 2.6.1 Technical data Features 5PP320.0573-3B B&R ID-Code $A5A6 Boot loader / Operating system BIOS Processor Type Geode LX800 500 MHz, 32-bit x86 Expanded command set MMX technology, 3D Now L1 cache 128 KB (64 KB L cache / 64 KB D cache)
  • Page 77 Technical data • Power Panel 300 with BIOS Features 5PP320.0573-3B Serial interface Type RS232, modem-capable, not electrically isolated UART 16C550 compatible, 16-byte FIFO Transfer rate Max. 115 kBaud Connection 9-pin DSUB USB interface Type USB 1.1, USB 2.0 Amount Transfer rate Low speed (1.5 MBit/s), full speed (12 MBit/s) to high speed (480 MBit/s)
  • Page 78 Technical data • Power Panel 300 with BIOS Electrical characteristics 5PP320.0573-3B Power supply Rated voltage 18 - 30 VDC Rated current 0.54 A Starting current Max. 1.2 A Power consumption 13 W typical Electrical isolation 0 Ω Bleeder resistance Mechanical characteristics...

  • Page 79: Temperature Humidity Diagram

    Technical data • Power Panel 300 with BIOS 7) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 2.6.2 Temperature humidity diagram Operation Temperature [°C] Figure 27: Temperature humidity diagram - 5PP320.0573-3B...

  • Page 80: Dimensions

    Technical data • Power Panel 300 with BIOS 2.6.3 Dimensions 46,5 Allgemeintoleranz nach Nennmaßbereich DIN ISO 2768 mittel bis 6 mm ± 0,1 mm über 6 bis 30 mm ± 0,2 mm über 30 bis 120 mm ± 0,3 mm über 120 bis 400 mm...

  • Page 81: Cutout Installation

    Technical data • Power Panel 300 with BIOS 2.6.4 Cutout installation The cutout hole is to be made according to the following dimensions for cutout installation. The device must be mounted using the retaining clips included in delivery. Outer contour (Power Panel) 149.5...

  • Page 82: Device 5Pp320.1043-39

    Technical data • Power Panel 300 with BIOS 2.7 Device 5PP320.1043-39 Figure 30: Front view - 5PP320.1043-39 Battery compartment Grounding clip Power button CompactFlash slot (with latch) Reset button Supply voltage (x1) (x16) Ethernet Status LEDs Figure 31: Rear view - 5PP320.1043-39...

  • Page 83: Technical Data

    Technical data • Power Panel 300 with BIOS 2.7.1 Technical data Features 5PP320.1043-39 B&R ID-Code $23D0 Boot loader / Operating system BIOS Processor Type Geode LX800 500 MHz, 32-bit x86 Expanded command set MMX technology, 3D Now L1 cache 128 KB (64 KB L cache / 64 KB D cache)
  • Page 84 Technical data • Power Panel 300 with BIOS Features 5PP320.1043-39 Serial interface Type RS232, modem-capable, not electrically isolated UART 16C550 compatible, 16-byte FIFO Transfer rate Max. 115 kBaud Connection 9-pin DSUB USB interface Type USB 1.1, USB 2.0 Amount Transfer rate Low speed (1.5 MBit/s), full speed (12 MBit/s) to high speed (480 MBit/s)
  • Page 85 Technical data • Power Panel 300 with BIOS Electrical characteristics 5PP320.1043-39 Power supply Rated voltage 18 - 30 VDC Rated current 0.63 A Starting current Max. 2.8 A Power consumption Typically 15 W Electrical isolation 0 Ω Bleeder resistance Mechanical characteristics...

  • Page 86: Temperature Humidity Diagram

    Technical data • Power Panel 300 with BIOS 7) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 2.7.2 Temperature humidity diagram Operation Temperature [°C] Figure 32: Temperature humidity diagram - 5PP320.1043-39...

  • Page 87: Dimensions

    Technical data • Power Panel 300 with BIOS 2.7.3 Dimensions 11.5 54.5 Nominal measurement General tolerance from range DIN ISO 2768 medium ± 0.1 mm up to 6 mm ± 0.2 mm over 6 to 30 mm ± 0.3 mm over 30 to 120 mm ±...

  • Page 88: Cutout Installation

    Technical data • Power Panel 300 with BIOS 2.7.4 Cutout installation The cutout hole is to be made according to the following dimensions for cutout installation. The device must be mounted using the retaining clips included in delivery. Outer contour (Power Panel) 251.5...

  • Page 89: Device 5Pp320.1214-39

    Technical data • Power Panel 300 with BIOS 2.8 Device 5PP320.1214-39 Figure 35: Front view - 5PP320.1214-39 Battery compartment Grounding clip Power button CompactFlash slot (with latch) Reset button Supply voltage (x1) (x16) Ethernet Status LEDs Figure 36: Rear view - 5PP320.1214-39...

  • Page 90: Technical Data

    Technical data • Power Panel 300 with BIOS 2.8.1 Technical data Features 5PP320.1214-39 B&R ID-Code $23D1 Boot loader / Operating system BIOS Processor Type Geode LX800 500 MHz, 32-bit x86 Expanded command set MMX technology, 3D Now L1 cache 128 KB (64 KB L cache / 64 KB D cache)
  • Page 91 Technical data • Power Panel 300 with BIOS Features 5PP320.1214-39 Serial interface Type RS232, modem-capable, not electrically isolated UART 16C550 compatible, 16-byte FIFO Transfer rate Max. 115 kBaud Connection 9-pin DSUB USB interface Type USB 1.1, USB 2.0 Amount Transfer rate Low speed (1.5 MBit/s), full speed (12 MBit/s) to high speed (480 MBit/s)
  • Page 92 Technical data • Power Panel 300 with BIOS Electrical characteristics 5PP320.1214-39 Power supply Rated voltage 18 - 30 VDC Rated current 0.63 A Starting current Max. 2.8 A Power consumption Typically 15 W Electrical isolation 0 Ω Bleeder resistance Mechanical characteristics...

  • Page 93: Temperature Humidity Diagram

    Technical data • Power Panel 300 with BIOS 7) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 2.8.2 Temperature humidity diagram Operation Temperature [°C] Figure 37: Temperature humidity diagram - 5PP320.1214-39...

  • Page 94: Dimensions

    Technical data • Power Panel 300 with BIOS 2.8.3 Dimensions 54.5 Nominal measurement General tolerance from range DIN ISO 2768 medium ± 0.1 mm up to 6 mm ± 0.2 mm over 6 to 30 mm ± 0.3 mm over 30 to 120 mm ±...

  • Page 95: Cutout Installation

    Technical data • Power Panel 300 with BIOS 2.8.4 Cutout installation The cutout hole is to be made according to the following dimensions for cutout installation. The device must be mounted using the retaining clips included in delivery. Outer contour (Power Panel) 275.5...

  • Page 96: Device 5Pp320.1505-39

    Technical data • Power Panel 300 with BIOS 2.9 Device 5PP320.1505-39 Figure 40: Front view - 5PP320.1505-39 Battery compartment Grounding clip CompactFlash slot Power button (with latch) Reset button Supply (x1) voltage (x16) Ethernet Status LEDs Figure 41: Rear view - 5PP320.1505-39...

  • Page 97: Technical Data

    Technical data • Power Panel 300 with BIOS 2.9.1 Technical data Features 5PP320.1505-39 B&R ID-Code $23D2 Boot loader / Operating system BIOS Processor Type Geode LX800 500 MHz, 32-bit x86 Expanded command set MMX technology, 3D Now L1 cache 128 KB (64 KB L cache / 64 KB D cache)
  • Page 98 Technical data • Power Panel 300 with BIOS Features 5PP320.1505-39 Serial interface Type RS232, modem-capable, not electrically isolated UART 16C550 compatible, 16-byte FIFO Transfer rate Max. 115 kBaud Connection 9-pin DSUB USB interface Type USB 1.1, USB 2.0 Amount Transfer rate Low speed (1.5 MBit/s), full speed (12 MBit/s) to high speed (480 MBit/s)
  • Page 99 Technical data • Power Panel 300 with BIOS Electrical characteristics 5PP320.1505-39 Power supply Rated voltage 18 - 30 VDC Rated current 1.25 A Starting current Max. 2 A Power consumption Typically 30 W Electrical isolation 0 Ω Bleeder resistance Mechanical characteristics...

  • Page 100: Temperature Humidity Diagram

    Technical data • Power Panel 300 with BIOS 7) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 2.9.2 Temperature humidity diagram Operation Temperature [°C] Figure 42: Temperature humidity diagram - 5PP320.1505-39...

  • Page 101: Dimensions

    Technical data • Power Panel 300 with BIOS 2.9.3 Dimensions 11.5 60.5 Nominal measurement General tolerance from range DIN ISO 2768 medium ± 0.1 mm up to 6 mm ± 0.2 mm over 6 to 30 mm ± 0.3 mm over 30 to 120 mm ±...

  • Page 102: Cutout Installation

    Technical data • Power Panel 300 with BIOS 2.9.4 Cutout installation The cutout hole is to be made according to the following dimensions for cutout installation. The device must be mounted using the retaining clips included in delivery. Outer contour (Power Panel) Cutout Cutout dimensions 415 ±0.5 mm x 312 ±0.5 mm...

  • Page 103: Device 5Pp320.1505-3B

    Technical data • Power Panel 300 with BIOS 2.10 Device 5PP320.1505-3B Figure 45: Front view - 5PP320.1505-3B Battery compartment Grounding clip CompactFlash slot Power button (with latch) Reset button Supply (x1) voltage (x16) Ethernet Status LEDs Figure 46: Rear view - 5PP320.1505-3B...

  • Page 104: Technical Data

    Technical data • Power Panel 300 with BIOS 2.10.1 Technical data Features 5PP320.1505-3B B&R ID-Code $B2C5 Boot loader / Operating system BIOS Processor Type Geode LX800 500 MHz, 32-bit x86 Expanded command set MMX technology, 3D Now L1 cache 128 kB (64 kB I-Cache / 64 kB D-Cache)
  • Page 105 Technical data • Power Panel 300 with BIOS Features 5PP320.1505-3B Serial interface Type RS232, modem-capable, not electrically isolated UART 16C550 compatible, 16-byte FIFO Transfer rate Max. 115 kBaud Connection 9-pin DSUB USB interface Type USB 1.1, USB 2.0 Amount Transfer rate Low speed (1.5 Mbit/s), full speed (12 Mbit/s), to high speed (480 Mbit/s)
  • Page 106 Technical data • Power Panel 300 with BIOS Electrical characteristics 5PP320.1505-3B Power supply Rated voltage 18 - 30 VDC Rated current 1.25 A Starting current Max. 2 A Power consumption Typically 30 W Electrical isolation 0 Ω Bleeder resistance Mechanical characteristics...

  • Page 107: Temperature Humidity Diagram

    Technical data • Power Panel 300 with BIOS 7) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 2.10.2 Temperature humidity diagram Operation Temperature [°C] Figure 47: Temperature humidity diagram - 5PP320.1505-3B...

  • Page 108: Dimensions

    Technical data • Power Panel 300 with BIOS 2.10.3 Dimensions 11.5 60.5 Nominal measurement General tolerance from range DIN ISO 2768 medium ± 0.1 mm up to 6 mm ± 0.2 mm over 6 to 30 mm ± 0.3 mm over 30 to 120 mm ±...

  • Page 109: Cutout Installation

    Technical data • Power Panel 300 with BIOS 2.10.4 Cutout installation The cutout hole is to be made according to the following dimensions for cutout installation. The device must be mounted using the retaining clips included in delivery. Outer contour (Power Panel) Cutout Cutout dimensions 415 ±0.5 mm x 312 ±0.5 mm...

  • Page 110: Power Panel 300 With Automation Runtime

    Technical data • Power Panel 300 with Automation Runtime 3. Power Panel 300 with Automation Runtime 3.1 Device interfaces The following section provides a description of all interfaces and plugs possible with a Power Panel 300 device with Automation Runtime.

  • Page 111: Functional Grounding Clip

    Technical data • Power Panel 300 with Automation Runtime 3.1.2 Functional grounding clip Next to the supply voltage plug there is a functional grounding clip. The grounding clip (functional ground) must be connected with a central grounding point on the switching cabinet using a 6.3 mm blade connector via the shortest distance and with as little resistance as possible (e.g.

  • Page 112: Serial Interface Com

    Technical data • Power Panel 300 with Automation Runtime 3.1.3 Serial interface COM The Power Panel is equipped with a PC-compatible serial interface with a 16-byte FIFO buffer. This non-electrically isolated interface is primarily intended for programming Power Panel devices using Automation Studio.

  • Page 113: Usb Port

    Technical data • Power Panel 300 with Automation Runtime 3.1.4 USB port The Power Panel 300/400 devices have a USB 2.0 (Universal Serial Bus) host controller with multiple USB ports, two of which are on the outside for easy user access.

  • Page 114: Mode / Node Switches

    Technical data • Power Panel 300 with Automation Runtime 3.1.5 Mode / Node switches Power Panel devices are equipped with 2 hex switches that serve as operating mode switches. Switch positions 01 to FD are available for any purpose in an application and can be evaluated by the application program.

  • Page 115: Bios Boot Mode Switch

    Technical data • Power Panel 300 with Automation Runtime 3.1.6 BIOS boot mode switch Power Panel devices are equipped with a BIOS boot mode switch. Figure 52: BIOS boot mode switch Switch position Function Description Right (toward CF slot) OS mode The Power Panel will boot in OS mode.
  • Page 116 Technical data • Power Panel 300 with Automation Runtime OS mode • Standard Boot Screen (see section 1 "Power Panel 300 with BIOS" on page 429) • BIOS Setup can be started by pressing the "DEL" key. • When the switch is in the "00" position, the setup default values will be restored after restarting three times.

  • Page 117: Status Leds

    Technical data • Power Panel 300 with Automation Runtime 3.1.7 Status LEDs Power Panels are equipped with two status LEDs that are visible on the outside. Status LEDs Color Meaning Green Supply voltage OK 1x three-color, 1x one-color The system is in standby mode...

  • Page 118: Power Button

    Technical data • Power Panel 300 with Automation Runtime 3.1.9 Power button Power button The power button can be pressed with a pointed object (i.e. paper clip or tip of a pen). If the Power button is pushed, the Power Panel is switched off and remains in Standby mode.

  • Page 119: Compactflash Slot

    Technical data • Power Panel 300 with Automation Runtime 3.1.11 CompactFlash slot Power Panel devices are equipped with a CompactFlash slot that is accessible from the side. Type I CompactFlash cards are supported. Ejection lever Safety latch Figure 53: CompactFlash slot It is possible to secure the CompactFlash slot using the latch provided.

  • Page 120: Stickers

    Technical data • Power Panel 300 with Automation Runtime 3.2 Stickers 3.2.1 Device label The following sticker can be found in a suitable location on the Power Panel device: Figure 54: Device label 3.2.2 Serial number sticker General information Each B&R device is given a unique serial number sticker with a barcode that allows the device to be clearly identified.
  • Page 121 Technical data • Power Panel 300 with Automation Runtime Information on the Internet Information about each device can also be found on the B&R homepage. Enter the device's serial number in the serial number search field on the start page www.br-automation.com. The search also works if you enter the model number or the material number in the material number search field.

  • Page 122: Device 4Pp320.0571-01

    Technical data • Power Panel 300 with Automation Runtime 3.3 Device 4PP320.0571-01 Figure 57: Front view - 4PP320.0571-01 CompactFlash slot (with latch) Grounding clip Power button (x1) Reset button Supply (x16) voltage Status LEDs Ethernet Figure 58: Rear view - 4PP320.0571-01...

  • Page 123: Technical Data

    Technical data • Power Panel 300 with Automation Runtime 3.3.1 Technical data Features 4PP320.0571-01 B&R ID-Code $A15E Boot loader / Operating system Automation Runtime Processor Type Geode LX800 500 MHz, 32-bit x86 Expanded command set MMX technology, 3D Now L1 cache...
  • Page 124 Technical data • Power Panel 300 with Automation Runtime Features 4PP320.0571-01 Serial interface Type RS232, modem-capable, not electrically isolated UART 16C550 compatible, 16-byte FIFO Transfer rate Max. 115 kBaud Connection 9-pin DSUB USB interface Type USB 1.1, USB 2.0 Amount Transfer rate Low speed (1.5 MBit/s), full speed (12 MBit/s) to high speed (480 MBit/s)
  • Page 125 Technical data • Power Panel 300 with Automation Runtime Electrical characteristics 4PP320.0571-01 Power supply Rated voltage 18 - 30 VDC Rated current 0.45 A Starting current Max. 1.2 A Power consumption Typically 10 W Electrical isolation 0 Ω Bleeder resistance...

  • Page 126: Temperature Humidity Diagram

    Technical data • Power Panel 300 with Automation Runtime 3.3.2 Temperature humidity diagram Operation Temperature [°C] Figure 59: Temperature humidity diagram - 4PP320.0571-01 3.3.3 Dimensions 46.5 Nominal measurement General tolerance from range DIN ISO 2768 medium ± 0.1 mm up to 6 mm ±...

  • Page 127: Cutout Installation

    Technical data • Power Panel 300 with Automation Runtime 3.3.4 Cutout installation The cutout hole is to be made according to the following dimensions for cutout installation. The device must be mounted using the retaining clips included in delivery. Outer contour (Power Panel) 149.5...

  • Page 128: Device 4Pp320.0571-35

    Technical data • Power Panel 300 with Automation Runtime 3.4 Device 4PP320.0571-35 Figure 62: Front view - 4PP320.0571-35 CompactFlash slot (with latch) Grounding clip Power button (x1) Reset button Supply (x16) voltage Status LEDs Ethernet Figure 63: Rear view - 4PP320.0571-35...

  • Page 129: Technical Data

    Technical data • Power Panel 300 with Automation Runtime 3.4.1 Technical data 4PP320.0571-35 ≥ D0 Features 4PP320.0571-35 < D0 B&R ID-Code $A15F Boot loader / Operating system Automation Runtime Processor Type Geode LX800 500 MHz, 32-bit x86 Expanded command set...
  • Page 130 Technical data • Power Panel 300 with Automation Runtime 4PP320.0571-35 ≥ D0 Features 4PP320.0571-35 < D0 Serial interface Type RS232, modem-capable, not electrically isolated UART 16C550 compatible, 16-byte FIFO Transfer rate Max. 115 kBaud Connection 9-pin DSUB USB interface Type USB 1.1, USB 2.0...
  • Page 131 Technical data • Power Panel 300 with Automation Runtime 4PP320.0571-35 ≥ D0 Electrical characteristics 4PP320.0571-35 < D0 Power supply Rated voltage 18 - 30 VDC Rated current 0.45 A Starting current Max. 1.2 A Power consumption Typically 10 W Electrical isolation 0 Ω...

  • Page 132: Temperature Humidity Diagram

    Technical data • Power Panel 300 with Automation Runtime 3.4.2 Temperature humidity diagram Operation Temperature [°C] Figure 64: Temperature humidity diagram - 4PP320.0571-35 3.4.3 Dimensions 46.5 Nominal measurement General tolerance from range DIN ISO 2768 medium ± 0.1 mm up to 6 mm ±...

  • Page 133: Cutout Installation

    Technical data • Power Panel 300 with Automation Runtime 3.4.4 Cutout installation The cutout hole is to be made according to the following dimensions for cutout installation. The device must be mounted using the retaining clips included in delivery. Outer contour (Power Panel) 149.5...

  • Page 134: Device 4Pp320.1043-31

    Technical data • Power Panel 300 with Automation Runtime 3.5 Device 4PP320.1043-31 Figure 67: Front view - 4PP320.1043-31 Grounding clip CompactFlash slot Power button (with latch) Reset button Supply (x1) voltage (x16) Status Ethernet LEDs Figure 68: Rear view - 4PP320.1043-31...

  • Page 135: Technical Data

    Technical data • Power Panel 300 with Automation Runtime 3.5.1 Technical data Features 4PP320.1043-31 B&R ID-Code $A160 Boot loader / Operating system Automation Runtime Processor Type Geode LX800 500 MHz, 32-bit x86 Expanded command set MMX technology, 3D Now L1 cache...
  • Page 136 Technical data • Power Panel 300 with Automation Runtime Features 4PP320.1043-31 Serial interface Type RS232, modem-capable, not electrically isolated UART 16C550 compatible, 16-byte FIFO Transfer rate Max. 115 kBaud Connection 9-pin DSUB USB interface Type USB 1.1, USB 2.0 Amount Transfer rate Low speed (1.5 MBit/s), full speed (12 MBit/s) to high speed (480 MBit/s)
  • Page 137 Technical data • Power Panel 300 with Automation Runtime Electrical characteristics 4PP320.1043-31 Power supply Rated voltage 18 - 30 VDC Rated current 0.63 A Starting current Max. 2.8 A Power consumption Typically 15 W Electrical isolation 0 Ω Bleeder resistance...

  • Page 138: Temperature Humidity Diagram

    Technical data • Power Panel 300 with Automation Runtime 3.5.2 Temperature humidity diagram Operation Temperature [°C] Figure 69: Temperature humidity diagram - 4PP320.1043-31 3.5.3 Dimensions 11.5 54.5 Nominal measurement General tolerance from range DIN ISO 2768 medium ± 0.1 mm up to 6 mm ±...

  • Page 139: Cutout Installation

    Technical data • Power Panel 300 with Automation Runtime 3.5.4 Cutout installation The cutout hole is to be made according to the following dimensions for cutout installation. The device must be mounted using the retaining clips included in delivery. Outer contour (Power Panel) 251.5...

  • Page 140: Device 4Pp320.1505-31

    Technical data • Power Panel 300 with Automation Runtime 3.6 Device 4PP320.1505-31 Figure 72: Front view - 4PP320.1505-31 CompactFlash slot (with latch) Grounding clip Power button (x1) Reset button Supply (x16) voltage Status LEDs Ethernet Figure 73: Rear view - 4PP320.1505-31...

  • Page 141: Technical Data

    Technical data • Power Panel 300 with Automation Runtime 3.6.1 Technical data Features 4PP320.1505-31 B&R ID-Code $A17F Boot loader / Operating system Automation Runtime Processor Type Geode LX800 500 MHz, 32-bit x86 Expanded command set MMX technology, 3D Now L1 cache...
  • Page 142 Technical data • Power Panel 300 with Automation Runtime Features 4PP320.1505-31 Serial interface Type RS232, modem-capable, not electrically isolated UART 16C550 compatible, 16-byte FIFO Transfer rate Max. 115 kBaud Connection 9-pin DSUB USB interface Type USB 1.1, USB 2.0 Amount Transfer rate Low speed (1.5 MBit/s), full speed (12 MBit/s) to high speed (480 MBit/s)
  • Page 143 Technical data • Power Panel 300 with Automation Runtime Electrical characteristics 4PP320.1505-31 Power supply Rated voltage 18 - 30 VDC Rated current 1.25 A Starting current Max. 2 A Power consumption Typically 30 W Electrical isolation 0 Ω Bleeder resistance...

  • Page 144: Temperature Humidity Diagram

    Technical data • Power Panel 300 with Automation Runtime 3.6.2 Temperature humidity diagram Operation Temperature [°C] Figure 74: Temperature humidity diagram - 4PP320.1505-31 3.6.3 Dimensions 11.5 60.5 Nominal measurement General tolerance from range DIN ISO 2768 medium ± 0.1 mm up to 6 mm ±...

  • Page 145: Cutout Installation

    Technical data • Power Panel 300 with Automation Runtime 3.6.4 Cutout installation The cutout hole is to be made according to the following dimensions for cutout installation. The device must be mounted using the retaining clips included in delivery. Outer contour (Power Panel) Cutout Cutout dimensions 415 ±0.5 mm x 312 ±0.5 mm...

  • Page 146: Device 4Pp351.0571-01

    Technical data • Power Panel 300 with Automation Runtime 3.7 Device 4PP351.0571-01 Keys can be Keys can be labeled using labeled using legend strips legend strips Figure 77: Front view - 4PP351.0571-01 Grounding clip Power button CompactFlash slot Reset button...

  • Page 147: Technical Data

    Technical data • Power Panel 300 with Automation Runtime 3.7.1 Technical data Features 4PP351.0571-01 B&R ID-Code $A543 Boot loader / Operating system Automation Runtime Processor Type Geode LX800 500 MHz, 32-bit x86 Expanded command set MMX technology, 3D Now L1 cache...
  • Page 148 Technical data • Power Panel 300 with Automation Runtime Features 4PP351.0571-01 Serial interface Type RS232, modem-capable, not electrically isolated UART 16C550 compatible, 16-byte FIFO Transfer rate Max. 115 kBaud Connection 9-pin DSUB USB interface Type USB 1.1, USB 2.0 Amount Transfer rate Low speed (1.5 MBit/s), full speed (12 MBit/s) to high speed (480 MBit/s)
  • Page 149 Technical data • Power Panel 300 with Automation Runtime Electrical characteristics 4PP351.0571-01 Power supply Rated voltage 18 - 30 VDC Rated current 0.45 A Starting current Max. 1.2 A Power consumption Typically 10 W Electrical isolation 0 Ω Bleeder resistance...

  • Page 150: Temperature Humidity Diagram

    Technical data • Power Panel 300 with Automation Runtime 3.7.2 Temperature humidity diagram Operation Temperature [°C] Figure 79: Temperature humidity diagram - 4PP351.0571-01 3.7.3 Dimensions 46.5 Nominal measurement General tolerance from range DIN ISO 2768 medium up to 6 mm ±...

  • Page 151: Cutout Installation

    Technical data • Power Panel 300 with Automation Runtime 3.7.4 Cutout installation The cutout hole is to be made according to the following dimensions for cutout installation. The device must be mounted using the retaining clips included in delivery. Outer contour (Power Panel) 238.5...

  • Page 152: Device 4Pp351.0571-35

    Technical data • Power Panel 300 with Automation Runtime 3.8 Device 4PP351.0571-35 Keys can be Keys can be labeled using labeled using legend strips legend strips Figure 82: Front view - 4PP351.0571-35 Grounding clip Power button CompactFlash slot Reset button...

  • Page 153: Technical Data

    Technical data • Power Panel 300 with Automation Runtime 3.8.1 Technical data 4PP351.0571-35 ≥ Rev. D0 Features 4PP351.0571-35 < Rev. D0 B&R ID-Code $A541 Boot loader / Operating system Automation Runtime Processor Type Geode LX800 500 MHz, 32-bit x86 Expanded command set...
  • Page 154 Technical data • Power Panel 300 with Automation Runtime 4PP351.0571-35 ≥ Rev. D0 Features 4PP351.0571-35 < Rev. D0 Serial interface Type RS232, modem-capable, not electrically isolated UART 16C550 compatible, 16-byte FIFO Transfer rate Max. 115 kBaud Connection 9-pin DSUB USB interface Type USB 1.1, USB 2.0...
  • Page 155 Technical data • Power Panel 300 with Automation Runtime 4PP351.0571-35 ≥ Rev. D0 Electrical characteristics 4PP351.0571-35 < Rev. D0 Power supply Rated voltage 18 - 30 VDC Rated current 0.45 A Starting current Max. 1.2 A Power consumption Typically 10 W Electrical isolation 0 Ω...

  • Page 156: Temperature Humidity Diagram

    Technical data • Power Panel 300 with Automation Runtime 3.8.2 Temperature humidity diagram Operation Temperature [°C] Figure 84: Temperature humidity diagram - 4PP351.0571-35 3.8.3 Dimensions 46.5 Nominal measurement General tolerance from range DIN ISO 2768 medium up to 6 mm ±...

  • Page 157: Cutout Installation

    Technical data • Power Panel 300 with Automation Runtime 3.8.4 Cutout installation The cutout hole is to be made according to the following dimensions for cutout installation. The device must be mounted using the retaining clips included in delivery. Outer contour (Power Panel) 238.5...

  • Page 158: Device 4Pp352.0571-35

    Technical data • Power Panel 300 with Automation Runtime 3.9 Device 4PP352.0571-35 Keys can be labeled using legend strips Figure 87: Front view - 4PP352.0571-35 CompactFlash slot Grounding clip (with latch) Power button Reset button Supply voltage Ethernet Status LEDs...

  • Page 159: Technical Data

    Technical data • Power Panel 300 with Automation Runtime 3.9.1 Technical data 4PP352.0571-35 ≥ Rev. D0 Features 4PP352.0571-35 < Rev. D0 B&R ID-Code $A542 Boot loader / Operating system Automation Runtime Processor Type Geode LX800 500 MHz, 32-bit x86 Expanded command set...
  • Page 160 Technical data • Power Panel 300 with Automation Runtime 4PP352.0571-35 ≥ Rev. D0 Features 4PP352.0571-35 < Rev. D0 Serial interface Type RS232, modem-capable, not electrically isolated UART 16C550 compatible, 16-byte FIFO Transfer rate Max. 115 kBaud Connection 9-pin DSUB USB interface Type USB 1.1, USB 2.0...
  • Page 161 Technical data • Power Panel 300 with Automation Runtime 4PP352.0571-35 ≥ Rev. D0 Electrical characteristics 4PP352.0571-35 < Rev. D0 Power supply Rated voltage 18 - 30 VDC Rated current 0.45 A Starting current Max. 1.2 A Power consumption Typically 10 W Electrical isolation 0 Ω...

  • Page 162: Temperature Humidity Diagram

    Technical data • Power Panel 300 with Automation Runtime 3.9.2 Temperature humidity diagram Operation Temperature [°C] Figure 89: Temperature humidity diagram - 4PP352.0571-35 3.9.3 Dimensions 11.9 46.5 Nominal measurement General tolerance range DIN ISO 2768 medium up to 6 mm ±...

  • Page 163: Cutout Installation

    Technical data • Power Panel 300 with Automation Runtime 3.9.4 Cutout installation The cutout hole is to be made according to the following dimensions for cutout installation. The device must be mounted using the retaining clips included in delivery. Outer contour (Power Panel) 180.5...

  • Page 164: Device 4Pp381.1043-31

    Technical data • Power Panel 300 with Automation Runtime 3.10 Device 4PP381.1043-31 Keys can be Keys can be labeled using labeled using legend strips legend strips Figure 92: Front view - 4PP381.1043-31 CompactFlash slot (with latch) Grounding clip Power button...

  • Page 165: Technical Data

    Technical data • Power Panel 300 with Automation Runtime 3.10.1 Technical data Features 4PP381.1043-31 B&R ID-Code $A544 Boot loader / Operating system Automation Runtime Processor Type Geode LX800 500 MHz, 32-bit x86 Expanded command set MMX technology, 3D Now L1 cache...
  • Page 166 Technical data • Power Panel 300 with Automation Runtime Features 4PP381.1043-31 Serial interface Type RS232, modem-capable, not electrically isolated UART 16C550 compatible, 16-byte FIFO Transfer rate Max. 115 kBaud Connection 9-pin DSUB USB interface Type USB 1.1, USB 2.0 Amount Transfer rate Low speed (1.5 MBit/s), full speed (12 MBit/s) to high speed (480 MBit/s)
  • Page 167 Technical data • Power Panel 300 with Automation Runtime Electrical characteristics 4PP381.1043-31 Power supply Rated voltage 18 - 30 VDC Rated current 0.45 A Starting current Max. 1.2 A Power consumption Typically 10 W Electrical isolation 0 Ω Bleeder resistance...

  • Page 168: Temperature Humidity Diagram

    Technical data • Power Panel 300 with Automation Runtime 3.10.2 Temperature humidity diagram Operation Temperature [°C] Figure 94: Temperature humidity diagram - 4PP381.1043-31 3.10.3 Dimensions 54.5 11.5 Nominal measurement General tolerance from range DIN ISO 2768 medium ± 0.1 mm up to 6 mm ±...

  • Page 169: Cutout Installation

    Technical data • Power Panel 300 with Automation Runtime 3.10.4 Cutout installation The cutout hole is to be made according to the following dimensions for cutout installation. The device must be mounted using the retaining clips included in delivery. Outer contour (Power Panel) 349.5...

  • Page 170: Power Panel 400 With Automation Runtime

    Ground Warning! The pin's connection to the functional ground (pin 2, e.g. switching cabinet) should be as short as possible. We recommend using the largest possible conductor cross section on the supply plug. Power Panel 300/400 User's Manual V 2.30...

  • Page 171: Functional Grounding Clip

    6.3 mm blade connector via the shortest distance and with as little resistance as possible (e.g. copper strip, but must be at least 2.5 mm²). Grounding clip Figure 98: Functional grounding clip Power Panel 300/400 User's Manual V 2.30...

  • Page 172: Serial Interface Com

    The RS232 can also be used as a general interface (e.g. third-party connections, barcode reader, etc.). Serial interface (COM) Type RS232, modem-capable, not electrically isolated UART 16C550 compatible, 16-byte FIFO 9-pin DSUB plug Transfer rate Up to 115 kBaud Assignment Table 60: Pin assignments - COM Power Panel 300/400 User's Manual V 2.30...

  • Page 173: Usb Port

    Technical data • Power Panel 400 with Automation Runtime 4.1.4 USB port The Power Panel 300/400 devices have a USB 2.0 (Universal Serial Bus) host controller with multiple USB ports, two of which are on the outside for easy user access.

  • Page 174: Mode / Node Switches

    Automation Runtime run mode with node 01-FD (CompactFlash Automation Runtime or terminal operation). Device addresses can be assigned through the software. Diagnostics Automation Runtime diagnostics mode (CompactFlash Automation Runtime or terminal operation). Table 63: Switch settings for the Mode / Node switch Power Panel 300/400 User's Manual V 2.30...

  • Page 175: Bios Boot Mode Switch

    The Power Panel will boot in OS mode. Left AR mode The Power Panel will boot in AR mode. Table 64: BIOS boot mode switch positions (based on the image) Warning! Carefully use a pointed object to change switch position. Power Panel 300/400 User's Manual V 2.30...
  • Page 176 Technical data • Power Panel 400 with Automation Runtime OS mode • Standard Boot Screen (see section 1 "Power Panel 300 with BIOS" on page 429) • BIOS Setup can be started by pressing the "DEL" key. • When the switch is in the "00" position, the setup default values will be restored after restarting three times.

  • Page 177: Status Leds

    Transfer rate 10/100 MBit/s Green 100 MBit/s 10 MBit/s Orange Link Activity (blinking) (Ethernet network (Data transfer in connection progress) available) Table 66: Ethernet connection 1) Both operating modes possible. Change-over takes place automatically. Power Panel 300/400 User's Manual V 2.30...

  • Page 178: Power Button

    Pushing the reset button results in a hardware-reset. The Power Panel restarts. The MTCX processor is not reset when the reset button is pressed. Table 68: Reset button Warning! A system reset can cause data to be lost! Power Panel 300/400 User's Manual V 2.30...

  • Page 179: Compactflash Slot

    Either 1 or 2 aPCI slots are available depending on the Power Panel variant. B&R System 2005 aPCI interface modules can be inserted (available aPCI interface modules - see B&R homepage - Products - Control systems - System 2005 - Communication modules). Figure 101: aPCI Slot(s) Power Panel 300/400 User's Manual V 2.30...

  • Page 180: Stickers

    Rev. R0 91490168421 www.br-automation.com MAC: 00-60-65-00-C6-A7 Revision Standards met Model number 4PP420.1043-75 Rev. R0 Serial number 91490168421 www.br-automation.com MAC: 00-60-65-00:C6:A7 MAC address Barcode type 128 Figure 103: Design / dimensions - Serial number sticker Power Panel 300/400 User's Manual V 2.30...
  • Page 181 Enter model number here e.g. 4PP451.0571-65 Figure 104: Example - Material number search: 4PP420.0571-45 Power Panel 300/400 User's Manual V 2.30...

  • Page 182: Device 4Pp420.0571-45

    Figure 105: Front view - 4PP420.0571-45 Battery compartment aPCI Slot 1 Grounding clip Power button Reset button Supply voltage CompactFlash slot (with latch) Ethernet Status LEDs (x1) (x16) Figure 106: Rear view - 4PP420.0571-45 Power Panel 300/400 User's Manual V 2.30...

  • Page 183: Technical Data

    Connection RJ45 twisted pair (10 Base T / 100 Base T) Cables S/STP (category 5) NE2000-compatible CompactFlash Type Type I Amount 1 slot Connection Primary IDE device Table 69: Technical data - 4PP420.0571-45 Power Panel 300/400 User's Manual V 2.30...
  • Page 184 Up to 80% ±5% Degree of transmission Filter glass Degree of transmission Coating Keys/LED Function keys Soft keys Cursor keys Number block Other keys Key lifespan LED brightness Table 69: Technical data - 4PP420.0571-45 (Forts.) Power Panel 300/400 User's Manual V 2.30...
  • Page 185 5) At +25°C ambient temperature. Reducing the brightness by 50% can result in an approximate 50% increase of the half-brightness time. 6) Depending on the process or batch, there may be visible deviations in the color and surface structure. Power Panel 300/400 User's Manual V 2.30...

  • Page 186: Temperature Humidity Diagram

    Technical data • Power Panel 400 with Automation Runtime 7) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 4.3.2 Temperature humidity diagram Operation Temperature [°C] Figure 107: Temperature humidity diagram - 4PP420.0571-45 Power Panel 300/400 User's Manual V 2.30...

  • Page 187: Dimensions

    6 to 30 mm ± 0.3 mm over 30 to 120 mm ± 0.5 mm over 120 to 400 mm ± 0.8 mm over 400 to 1000 mm Figure 108: Dimensions - 4PP420.0571-45 Power Panel 300/400 User's Manual V 2.30...

  • Page 188: Cutout Installation

    The following components are included in the delivery of the Power Panel device: Amount Component Power Panel PP420 5.7" QVGA, 1 aPCI, touch screen Retaining clips included Lithium battery 3 V / 950 mAh included Table 70: Contents of delivery - 4PP420.0571-45 Power Panel 300/400 User's Manual V 2.30...

  • Page 189: Device 4Pp420.0571-65

    Figure 110: Front view - 4PP420.0571-65 Battery compartment aPCI Slot 1 Grounding clip Power button Reset button Supply voltage CompactFlash slot (with latch) Ethernet Status LEDs (x1) (x16) Figure 111: Rear view - 4PP420.0571-65 Power Panel 300/400 User's Manual V 2.30...

  • Page 190: Technical Data

    Connection RJ45 twisted pair (10 Base T / 100 Base T) Cables S/STP (category 5) NE2000-compatible CompactFlash Type Type I Amount 1 slot Connection Primary IDE device Table 71: Technical data - 4PP420.0571-65 Power Panel 300/400 User's Manual V 2.30...
  • Page 191 Up to 80% ±5% Degree of transmission Filter glass Degree of transmission Coating Keys/LED Function keys Soft keys Cursor keys Number block Other keys Key lifespan LED brightness Table 71: Technical data - 4PP420.0571-65 (Forts.) Power Panel 300/400 User's Manual V 2.30...
  • Page 192 5) At +25°C ambient temperature. Reducing the brightness by 50% can result in an approximate 50% increase of the half-brightness time. 6) Depending on the process or batch, there may be visible deviations in the color and surface structure. Power Panel 300/400 User's Manual V 2.30...

  • Page 193: Temperature Humidity Diagram

    Technical data • Power Panel 400 with Automation Runtime 7) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 4.4.2 Temperature humidity diagram Operation Temperature [°C] Figure 112: Temperature humidity diagram - 4PP420.0571-65 Power Panel 300/400 User's Manual V 2.30...

  • Page 194: Dimensions

    6 to 30 mm ± 0.2 mm over 30 to 120 mm ± 0.3 mm over 120 to 400 mm ± 0.5 mm over 400 to 1000 mm ± 0.8 mm Figure 113: Dimensions - 4PP420.0571-65 Power Panel 300/400 User's Manual V 2.30...

  • Page 195: Cutout Installation

    The following components are included in the delivery of the Power Panel device: Amount Component Power Panel PP420, 5.7" QVGA, 1 aPCI, touch screen Retaining clips included Lithium battery 3 V / 950 mAh included Table 72: Contents of delivery - 4PP420.0571-65 Power Panel 300/400 User's Manual V 2.30...

  • Page 196: Device 4Pp420.0571-75

    Figure 115: Front view - 4PP420.0571-75 Battery compartment aPCI Slot 1 Grounding clip Power button Reset button Supply voltage CompactFlash slot (with latch) Ethernet Status LEDs (x1) (x16) Figure 116: Rear view - 4PP420.0571-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 197: Technical Data

    Connection RJ45 twisted pair (10 Base T / 100 Base T) Cables S/STP (category 5) NE2000-compatible CompactFlash Type Type I Amount 1 slot Connection Primary IDE device Table 73: Technical data - 4PP420.0571-75 Power Panel 300/400 User's Manual V 2.30...
  • Page 198 Up to 80% ±5% Degree of transmission Filter glass Degree of transmission Coating Keys/LED Function keys Soft keys Cursor keys Number block Other keys Key lifespan LED brightness Table 73: Technical data - 4PP420.0571-75 (Forts.) Power Panel 300/400 User's Manual V 2.30...
  • Page 199 5) At +25°C ambient temperature. Reducing the brightness by 50% can result in an approximate 50% increase of the half-brightness time. 6) Depending on the process or batch, there may be visible deviations in the color and surface structure. Power Panel 300/400 User's Manual V 2.30...

  • Page 200: Temperature Humidity Diagram

    Technical data • Power Panel 400 with Automation Runtime 7) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 4.5.2 Temperature humidity diagram Operation Temperature [°C] Figure 117: Temperature humidity diagram - 4PP420.0571-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 201: Dimensions

    6 to 30 mm ± 0.3 mm over 30 to 120 mm ± 0.5 mm over 120 to 400 mm ± 0.8 mm over 400 to 1000 mm Figure 118: Dimensions - 4PP420.0571-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 202: Cutout Installation

    The following components are included in the delivery of the Power Panel device: Amount Component Power Panel PP420, 5.7" QVGA, 1 aPCI, touch screen Retaining clips included Lithium battery 3 V / 950 mAh included Table 74: Contents of delivery - 4PP420.0571-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 203: Device 4Pp420.0571-85

    Figure 120: Front view - 4PP420.0571-85 Battery compartment aPCI Slot 2 aPCI Slot 1 Grounding clip Power button Reset button Supply voltage CompactFlash slot (with latch) Ethernet Status LEDs (x1) (x16) Figure 121: Rear view - 4PP420.0571-85 Power Panel 300/400 User's Manual V 2.30...

  • Page 204: Technical Data

    Connection RJ45 twisted pair (10 Base T / 100 Base T) Cables S/STP (category 5) NE2000-compatible CompactFlash Type Type I Amount 1 slot Connection Primary IDE device Table 75: Technical data - 4PP420.0571-85 Power Panel 300/400 User's Manual V 2.30...
  • Page 205 Up to 80% ±5% Degree of transmission Filter glass Degree of transmission Coating Keys/LED Function keys Soft keys Cursor keys Number block Other keys Key lifespan LED brightness Table 75: Technical data - 4PP420.0571-85 (Forts.) Power Panel 300/400 User's Manual V 2.30...
  • Page 206 5) At +25°C ambient temperature. Reducing the brightness by 50% can result in an approximate 50% increase of the half-brightness time. 6) Depending on the process or batch, there may be visible deviations in the color and surface structure. Power Panel 300/400 User's Manual V 2.30...

  • Page 207: Temperature Humidity Diagram

    Technical data • Power Panel 400 with Automation Runtime 7) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 4.6.2 Temperature humidity diagram Operation Temperature [°C] Figure 122: Temperature humidity diagram - 4PP420.0571-85 Power Panel 300/400 User's Manual V 2.30...

  • Page 208: Dimensions

    6 to 30 mm ± 0.3 mm over 30 to 120 mm ± 0.5 mm over 120 to 400 mm ± 0.8 mm over 400 to 1000 mm Figure 123: Dimensions - 4PP420.0571-85 Power Panel 300/400 User's Manual V 2.30...

  • Page 209: Cutout Installation

    The following components are included in the delivery of the Power Panel device: Amount Component Power Panel PP420, 5.7" QVGA, 1 aPCI, touch screen Retaining clips included Lithium battery 3 V / 950 mAh included Table 76: Contents of delivery - 4PP420.0571-85 Power Panel 300/400 User's Manual V 2.30...

  • Page 210: Device 4Pp420.0571-A5

    Figure 125: Front view - 4PP420.0571-A5 Battery compartment aPCI Slot 2 aPCI Slot 1 Grounding clip Power button Reset button Supply voltage CompactFlash slot (with latch) Ethernet Status LEDs (x1) (x16) Figure 126: Rear view - 4PP420.0571-A5 Power Panel 300/400 User's Manual V 2.30...

  • Page 211: Technical Data

    Connection RJ45 twisted pair (10 Base T / 100 Base T) Cables S/STP (category 5) NE2000-compatible CompactFlash Type Type I Amount 1 slot Connection Primary IDE device Table 77: Technical data - 4PP420.0571-A5 Power Panel 300/400 User's Manual V 2.30...
  • Page 212 Up to 80% ±5% Degree of transmission Filter glass Degree of transmission Coating Keys/LED Function keys Soft keys Cursor keys Number block Other keys Key lifespan LED brightness Table 77: Technical data - 4PP420.0571-A5 (Forts.) Power Panel 300/400 User's Manual V 2.30...
  • Page 213 5) At +25°C ambient temperature. Reducing the brightness by 50% can result in an approximate 50% increase of the half-brightness time. 6) Depending on the process or batch, there may be visible deviations in the color and surface structure. Power Panel 300/400 User's Manual V 2.30...

  • Page 214: Temperature Humidity Diagram

    Technical data • Power Panel 400 with Automation Runtime 7) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 4.7.2 Temperature humidity diagram Operation Temperature [°C] Figure 127: Temperature humidity diagram - 4PP420.0571-A5 Power Panel 300/400 User's Manual V 2.30...

  • Page 215: Dimensions

    6 to 30 mm ± 0.3 mm over 30 to 120 mm ± 0.5 mm over 120 to 400 mm over 400 to 1000 mm ± 0.8 mm Figure 128: Dimensions - 4PP420.0571-A5 Power Panel 300/400 User's Manual V 2.30...

  • Page 216: Cutout Installation

    The following components are included in the delivery of the Power Panel device: Amount Component Power Panel PP420, 5.7" QVGA, 2 aPCI, touch screen Retaining clips included Lithium battery 3 V / 950 mAh included Table 78: Contents of delivery - 4PP420.0571-A5 Power Panel 300/400 User's Manual V 2.30...

  • Page 217: Device 4Pp420.0571-B5

    Figure 130: Front view - 4PP420.0571-B5 Battery compartment aPCI Slot 2 aPCI Slot 1 Grounding clip Power button Reset button Supply voltage CompactFlash slot (with latch) Ethernet Status LEDs (x1) (x16) Figure 131: Rear view - 4PP420.0571-B5 Power Panel 300/400 User's Manual V 2.30...

  • Page 218: Technical Data

    Connection RJ45 twisted pair (10 Base T / 100 Base T) Cables S/STP (category 5) NE2000-compatible CompactFlash Type Type I Amount 1 slot Connection Primary IDE device Table 79: Technical data - 4PP420.0571-B5 Power Panel 300/400 User's Manual V 2.30...
  • Page 219 Up to 80% ±5% Degree of transmission Filter glass Degree of transmission Coating Keys/LED Function keys Soft keys Cursor keys Number block Other keys Key lifespan LED brightness Table 79: Technical data - 4PP420.0571-B5 (Forts.) Power Panel 300/400 User's Manual V 2.30...
  • Page 220 5) At +25°C ambient temperature. Reducing the brightness by 50% can result in an approximate 50% increase of the half-brightness time. 6) Depending on the process or batch, there may be visible deviations in the color and surface structure. Power Panel 300/400 User's Manual V 2.30...

  • Page 221: Temperature Humidity Diagram

    Technical data • Power Panel 400 with Automation Runtime 7) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 4.8.2 Temperature humidity diagram Operation Temperature [°C] Figure 132: Temperature humidity diagram - 4PP420.0571-B5 Power Panel 300/400 User's Manual V 2.30...

  • Page 222: Dimensions

    6 to 30 mm over 30 to 120 mm ± 0.3 mm ± 0.5 mm over 120 to 400 mm ± 0.8 mm over 400 to 1000 mm Figure 133: Dimensions - 4PP420.0571-B5 Power Panel 300/400 User's Manual V 2.30...

  • Page 223: Cutout Installation

    The following components are included in the delivery of the Power Panel device: Amount Component Power Panel PP420, 5.7" QVGA, 2 aPCI, touch screen Retaining clips included Lithium battery 3 V / 950 mAh included Table 80: Contents of delivery - 4PP420.0571-B5 Power Panel 300/400 User's Manual V 2.30...

  • Page 224: Device 4Pp420.0573-75

    Figure 135: Front view - 4PP420.0573-75 Battery compartment aPCI Slot 1 Grounding clip Power button Reset button Supply voltage CompactFlash slot (with latch) Ethernet Status LEDs (x1) (x16) Figure 136: Rear view - 4PP420.0573-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 225: Technical Data

    Connection RJ45 twisted pair (10 Base T / 100 Base T) Cables S/STP (category 5) NE2000-compatible CompactFlash Type Type I Amount 1 slot Connection Primary IDE device Table 81: Technical data - 4PP420.0573-75 Power Panel 300/400 User's Manual V 2.30...
  • Page 226 Up to 80% ±5% Degree of transmission Filter glass Degree of transmission Coating Keys/LED Function keys Soft keys Cursor keys Number block Other keys Key lifespan LED brightness Table 81: Technical data - 4PP420.0573-75 (Forts.) Power Panel 300/400 User's Manual V 2.30...
  • Page 227 5) At +25°C ambient temperature. Reducing the brightness by 50% can result in an approximate 50% increase of the half-brightness time. 6) Depending on the process or batch, there may be visible deviations in the color and surface structure. Power Panel 300/400 User's Manual V 2.30...

  • Page 228: Temperature Humidity Diagram

    Technical data • Power Panel 400 with Automation Runtime 7) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 4.9.2 Temperature humidity diagram Operation Temperature [°C] Figure 137: Temperature humidity diagram - 4PP420.0573-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 229: Dimensions

    6 to 30 mm ± 0.3 mm over 30 to 120 mm ± 0.5 mm over 120 to 400 mm ± 0.8 mm over 400 to 1000 mm Figure 138: Dimensions - 4PP420.0573-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 230: Cutout Installation

    The following components are included in the delivery of the Power Panel device: Amount Component Power Panel PP420 5.7" VGA, 1 aPCI, touch screen Retaining clips included Lithium battery 3 V / 950 mAh included Table 82: Contents of delivery - 4PP420.0573-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 231: Device 4Pp420.1043-75

    Figure 140: Front view - 4PP420.1043-75 aPCI Slot 1 Battery compartment Grounding clip Power button CompactFlash slot (with latch) Reset button Supply voltage (x1) (x16) Ethernet Status LEDs Figure 141: Rear view - 4PP420.1043-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 232: Technical Data

    Connection RJ45 twisted pair (10 Base T / 100 Base T) Cables S/STP (category 5) NE2000-compatible CompactFlash Type Type I Amount 1 slot Connection Primary IDE device Table 83: Technical data - 4PP420.1043-75 Power Panel 300/400 User's Manual V 2.30...
  • Page 233 Up to 80% ±5% Degree of transmission Filter glass Degree of transmission Coating Keys/LED Function keys Soft keys Cursor keys Number block Other keys Key lifespan LED brightness Table 83: Technical data - 4PP420.1043-75 (Forts.) Power Panel 300/400 User's Manual V 2.30...
  • Page 234 5) At +25°C ambient temperature. Reducing the brightness by 50% can result in an approximate 50% increase of the half-brightness time. 6) Depending on the process or batch, there may be visible deviations in the color and surface structure. Power Panel 300/400 User's Manual V 2.30...

  • Page 235: Temperature Humidity Diagram

    Technical data • Power Panel 400 with Automation Runtime 7) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 4.10.2 Temperature humidity diagram Operation Temperature [°C] Figure 142: Temperature humidity diagram - 4PP420.1043-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 236: Dimensions

    6 to 30 mm ± 0.3 mm over 30 to 120 mm ± 0.5 mm over 120 to 400 mm over 400 to 1000 mm ± 0.8 mm 27.5 Figure 143: Dimensions - 4PP420.1043-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 237: Cutout Installation

    The following components are included in the delivery of the Power Panel device: Amount Component Power Panel PP420 10.4" VGA, 1 aPCI, touch screen Retaining clips included Lithium battery 3 V / 950 mAh included Table 84: Contents of delivery - 4PP420.1043-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 238: Device 4Pp420.1043-B5

    Figure 145: Front view - 4PP420.1043-B5 aPCI Slot 2 aPCI Slot 1 Battery compartment Grounding clip Power button CompactFlash slot (with latch) Reset button Supply voltage (x1) (x16) Ethernet Status LEDs Figure 146: Rear view - 4PP420.1043-B5 Power Panel 300/400 User's Manual V 2.30...

  • Page 239: Technical Data

    Connection RJ45 twisted pair (10 Base T / 100 Base T) Cables S/STP (category 5) NE2000-compatible CompactFlash Type Type I Amount 1 slot Connection Primary IDE device Table 85: Technical data - 4PP420.1043-B5 Power Panel 300/400 User's Manual V 2.30...
  • Page 240 Up to 80% ±5% Degree of transmission Filter glass Degree of transmission Coating Keys/LED Function keys Soft keys Cursor keys Number block Other keys Key lifespan LED brightness Table 85: Technical data - 4PP420.1043-B5 (Forts.) Power Panel 300/400 User's Manual V 2.30...
  • Page 241 5) At +25°C ambient temperature. Reducing the brightness by 50% can result in an approximate 50% increase of the half-brightness time. 6) Depending on the process or batch, there may be visible deviations in the color and surface structure. Power Panel 300/400 User's Manual V 2.30...

  • Page 242: Temperature Humidity Diagram

    Technical data • Power Panel 400 with Automation Runtime 7) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 4.11.2 Temperature humidity diagram Operation Temperature [°C] Figure 147: Temperature humidity diagram - 4PP420.1043-B5 Power Panel 300/400 User's Manual V 2.30...

  • Page 243: Dimensions

    6 to 30 mm ± 0.3 mm over 30 to 120 mm over 120 to 400 mm ± 0.5 mm ± 0.8 mm over 400 to 1000 mm 27.5 Figure 148: Dimensions - 4PP420.1043-B5 Power Panel 300/400 User's Manual V 2.30...

  • Page 244: Cutout Installation

    The following components are included in the delivery of the Power Panel device: Amount Component Power Panel PP420 10.4" VGA, 2 aPCI, touch screen Retaining clips included Lithium battery 3 V / 950 mAh included Table 86: Contents of delivery - 4PP420.1043-B5 Power Panel 300/400 User's Manual V 2.30...

  • Page 245: Device 4Pp420.1505-75

    Figure 150: Front view - 4PP420.1505-75 aPCI Slot 1 Battery compartment CompactFlash slot Grounding clip (with latch) Power button Reset button Supply (x1) voltage (x16) Status LEDs Ethernet Figure 151: Rear view - 4PP420.1505-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 246: Technical Data

    Connection RJ45 twisted pair (10 Base T / 100 Base T) Cables S/STP (category 5) NE2000-compatible CompactFlash Type Type I Amount 1 slot Connection Primary IDE device Table 87: Technical data - 4PP420.1505-75 Power Panel 300/400 User's Manual V 2.30...
  • Page 247 Up to 80% ±5% Degree of transmission Filter glass Degree of transmission Coating Keys/LED Function keys Soft keys Cursor keys Number block Other keys Key lifespan LED brightness Table 87: Technical data - 4PP420.1505-75 (Forts.) Power Panel 300/400 User's Manual V 2.30...
  • Page 248 5) At +25°C ambient temperature. Reducing the brightness by 50% can result in an approximate 50% increase of the half-brightness time. 6) Depending on the process or batch, there may be visible deviations in the color and surface structure. Power Panel 300/400 User's Manual V 2.30...

  • Page 249: Temperature Humidity Diagram

    Technical data • Power Panel 400 with Automation Runtime 7) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 4.12.2 Temperature humidity diagram Operation Temperature [°C] Figure 152: Temperature humidity diagram - 4PP420.1505-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 250: Dimensions

    6 to 30 mm ± 0.3 mm over 30 to 120 mm ± 0.5 mm over 120 to 400 mm ± 0.8 mm over 400 to 1000 mm 28.5 Figure 153: Dimensions - 4PP420.1505-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 251: Cutout Installation

    The following components are included in the delivery of the Power Panel device: Amount Component Power Panel PP420 15" XGA, 1 aPCI, touch screen Retaining clips included Lithium battery 3 V / 950 mAh included Table 88: Contents of delivery - 4PP420.1505-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 252: Device 4Pp420.1505-B5

    Figure 155: Front view - 4PP420.1505-B5 aPCI Slot 2 aPCI Slot 1 Battery compartment CompactFlash slot Grounding clip (with latch) Power button Reset button Supply (x1) voltage (x16) Status LEDs Ethernet Figure 156: Rear view - 4PP420.1505-B5 Power Panel 300/400 User's Manual V 2.30...

  • Page 253: Technical Data

    Connection RJ45 twisted pair (10 Base T / 100 Base T) Cables S/STP (category 5) NE2000-compatible CompactFlash Type Type I Amount 1 slot Connection Primary IDE device Table 89: Technical data - 4PP420.1505-B5 Power Panel 300/400 User's Manual V 2.30...
  • Page 254 Up to 80% ±5% Degree of transmission Filter glass Degree of transmission Coating Keys/LED Function keys Soft keys Cursor keys Number block Other keys Key lifespan LED brightness Table 89: Technical data - 4PP420.1505-B5 (Forts.) Power Panel 300/400 User's Manual V 2.30...
  • Page 255 5) At +25°C ambient temperature. Reducing the brightness by 50% can result in an approximate 50% increase of the half-brightness time. 6) Depending on the process or batch, there may be visible deviations in the color and surface structure. Power Panel 300/400 User's Manual V 2.30...

  • Page 256: Temperature Humidity Diagram

    Technical data • Power Panel 400 with Automation Runtime 7) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 4.13.2 Temperature humidity diagram Operation Temperature [°C] Figure 157: Temperature humidity diagram - 4PP420.1505-B5 Power Panel 300/400 User's Manual V 2.30...

  • Page 257: Dimensions

    ± 0.2 mm over 30 to 120 mm ± 0.3 mm ± 0.5 mm over 120 to 400 mm ± 0.8 mm over 400 to 1000 mm 28.5 Figure 158: Dimensions - 4PP420.1505-B5 Power Panel 300/400 User's Manual V 2.30...

  • Page 258: Cutout Installation

    The following components are included in the delivery of the Power Panel device: Amount Component Power Panel PP420 15" XGA, 2 aPCI, touch screen Retaining clips included Lithium battery 3 V / 950 mAh included Table 90: Contents of delivery - 4PP420.1505-B5 Power Panel 300/400 User's Manual V 2.30...

  • Page 259: Device 4Pp451.0571-45

    Figure 160: Front view - 4PP451.0571-45 aPCI Slot 1 Grounding clip Battery compartment Power button CompactFlash slot Reset button (with latch) Supply voltage Ethernet (x1) Status (x16) LEDs Figure 161: Rear view - 4PP451.0571-45 Power Panel 300/400 User's Manual V 2.30...

  • Page 260: Technical Data

    Connection RJ45 twisted pair (10 Base T / 100 Base T) Cables S/STP (category 5) NE2000-compatible CompactFlash Type Type I Amount 1 slot Connection Primary IDE device Table 91: Technical data - 4PP451.0571-45 Power Panel 300/400 User's Manual V 2.30...
  • Page 261 Typ. 12 mcd (yellow) and 20 mcd (green) Pressing more than one key at a time may result in so-called phantom keys, and may trigger unintended actions. Table 91: Technical data - 4PP451.0571-45 (Forts.) Power Panel 300/400 User's Manual V 2.30...
  • Page 262 Maximum lifespan in 24-hour operation (no buffer) 6 years at +25°C or 5 years at +50°C. Maximum lifespan switched off: 2 years at +25°C or 1 year at +50°C. 4) The actual value depends on the operating system or diver being used. Power Panel 300/400 User's Manual V 2.30...

  • Page 263: Temperature Humidity Diagram

    7) Depending on the process or batch, there may be visible deviations in the color and surface structure. 8) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 4.14.2 Temperature humidity diagram Operation Temperature [°C] Figure 162: Temperature humidity diagram - 4PP451.0571-45 Power Panel 300/400 User's Manual V 2.30...

  • Page 264: Dimensions

    6 to 30 mm ± 0.3 mm over 30 to 120 mm ± 0.5 mm over 120 to 400 mm over 400 to 1000 mm ± 0.8 mm Figure 163: Dimensions - 4PP451.0571-45 Power Panel 300/400 User's Manual V 2.30...

  • Page 265: Cutout Installation

    The following components are included in the delivery of the Power Panel device: Amount Component Power Panel PP451 5.7" QVGA, 1 aPCI, keys Retaining clips included Lithium battery 3 V / 950 mAh included Table 92: Contents of delivery - 4PP451.0571-45 Power Panel 300/400 User's Manual V 2.30...

  • Page 266: Device 4Pp451.0571-65

    Figure 165: Front view - 4PP451.0571-65 aPCI Slot 1 Grounding clip Battery compartment Power button CompactFlash slot Reset button (with latch) Supply voltage Ethernet (x1) Status (x16) LEDs Figure 166: Rear view - 4PP451.0571-65 Power Panel 300/400 User's Manual V 2.30...

  • Page 267: Technical Data

    Connection RJ45 twisted pair (10 Base T / 100 Base T) Cables S/STP (category 5) NE2000-compatible CompactFlash Type Type I Amount 1 slot Connection Primary IDE device Table 93: Technical data - 4PP451.0571-65 Power Panel 300/400 User's Manual V 2.30...
  • Page 268 Typ. 12 mcd (yellow) and 20 mcd (green) Pressing more than one key at a time may result in so-called phantom keys, and may trigger unintended actions. Table 93: Technical data - 4PP451.0571-65 (Forts.) Power Panel 300/400 User's Manual V 2.30...
  • Page 269 Maximum lifespan in 24-hour operation (no buffer) 6 years at +25°C or 5 years at +50°C. Maximum lifespan switched off: 2 years at +25°C or 1 year at +50°C. 4) The actual value depends on the operating system or diver being used. Power Panel 300/400 User's Manual V 2.30...

  • Page 270: Temperature Humidity Diagram

    7) Depending on the process or batch, there may be visible deviations in the color and surface structure. 8) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 4.15.2 Temperature humidity diagram Operation Temperature [°C] Figure 167: Temperature humidity diagram - 4PP451.0571-65 Power Panel 300/400 User's Manual V 2.30...

  • Page 271: Dimensions

    6 to 30 mm ± 0.3 mm over 30 to 120 mm ± 0.5 mm over 120 to 400 mm ± 0.8 mm over 400 to 1000 mm Figure 168: Dimensions - 4PP451.0571-65 Power Panel 300/400 User's Manual V 2.30...

  • Page 272: Cutout Installation

    The following components are included in the delivery of the Power Panel device: Amount Component Power Panel PP451 5.7" QVGA, 1 aPCI, keys Retaining clips included Lithium battery 3 V / 950 mAh included Table 94: Contents of delivery - 4PP451.0571-65 Power Panel 300/400 User's Manual V 2.30...

  • Page 273: Device 4Pp451.0571-75

    Figure 170: Front view - 4PP451.0571-75 aPCI Slot 1 Grounding clip Battery compartment Power button CompactFlash slot Reset button (with latch) Supply voltage Ethernet (x1) Status (x16) LEDs Figure 171: Rear view - 4PP451.0571-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 274: Technical Data

    Connection RJ45 twisted pair (10 Base T / 100 Base T) Cables S/STP (category 5) NE2000-compatible CompactFlash Type Type I Amount 1 slot Connection Primary IDE device Table 95: Technical data - 4PP451.0571-75 Power Panel 300/400 User's Manual V 2.30...
  • Page 275 Typ. 12 mcd (yellow) and 20 mcd (green) Pressing more than one key at a time may result in so-called phantom keys, and may trigger unintended actions. Table 95: Technical data - 4PP451.0571-75 (Forts.) Power Panel 300/400 User's Manual V 2.30...
  • Page 276 Maximum lifespan in 24-hour operation (no buffer) 6 years at +25°C or 5 years at +50°C. Maximum lifespan switched off: 2 years at +25°C or 1 year at +50°C. 4) The actual value depends on the operating system or diver being used. Power Panel 300/400 User's Manual V 2.30...

  • Page 277: Temperature Humidity Diagram

    7) Depending on the process or batch, there may be visible deviations in the color and surface structure. 8) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 4.16.2 Temperature humidity diagram Operation Temperature [°C] Figure 172: Temperature humidity diagram - 4PP451.0571-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 278: Dimensions

    6 to 30 mm ± 0.3 mm over 30 to 120 mm over 120 to 400 mm ± 0.5 mm over 400 to 1000 mm ± 0.8 mm Figure 173: Dimensions - 4PP451.0571-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 279: Cutout Installation

    The following components are included in the delivery of the Power Panel device: Amount Component Power Panel PP451 5.7" QVGA, 1 aPCI, keys Retaining clips included Lithium battery 3 V / 950 mAh included Table 96: Contents of delivery - 4PP451.0571-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 280: Device 4Pp451.0571-85

    Figure 175: Front view - 4PP451.0571-85 aPCI Slot 2 aPCI Slot 1 Grounding clip Battery compartment Power button CompactFlash slot Reset button (with latch) Supply voltage Ethernet (x1) Status (x16) LEDs Figure 176: Rear view - 4PP451.0571-85 Power Panel 300/400 User's Manual V 2.30...

  • Page 281: Technical Data

    Connection RJ45 twisted pair (10 Base T / 100 Base T) Cables S/STP (category 5) NE2000-compatible CompactFlash Type Type I Amount 1 slot Connection Primary IDE device Table 97: Technical data - 4PP451.0571-85 Power Panel 300/400 User's Manual V 2.30...
  • Page 282 Typ. 12 mcd (yellow) and 20 mcd (green) Pressing more than one key at a time may result in so-called phantom keys, and may trigger unintended actions. Table 97: Technical data - 4PP451.0571-85 (Forts.) Power Panel 300/400 User's Manual V 2.30...
  • Page 283 Maximum lifespan in 24-hour operation (no buffer) 6 years at +25°C or 5 years at +50°C. Maximum lifespan switched off: 2 years at +25°C or 1 year at +50°C. 4) The actual value depends on the operating system or diver being used. Power Panel 300/400 User's Manual V 2.30...

  • Page 284: Temperature Humidity Diagram

    7) Depending on the process or batch, there may be visible deviations in the color and surface structure. 8) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 4.17.2 Temperature humidity diagram Operation Temperature [°C] Figure 177: Temperature humidity diagram - 4PP451.0571-85 Power Panel 300/400 User's Manual V 2.30...

  • Page 285: Dimensions

    ± 0.2 mm over 6 to 30 mm ± 0.3 mm over 30 to 120 mm ± 0.5 mm over 120 to 400 ± 0.8 mm over 400 to 1000 Figure 178: Dimensions - 4PP451.0571-85 Power Panel 300/400 User's Manual V 2.30...

  • Page 286: Cutout Installation

    The following components are included in the delivery of the Power Panel device: Amount Component Power Panel PP451 5.7" QVGA, 1 aPCI, keys Retaining clips included Lithium battery 3 V / 950 mAh included Table 98: Contents of delivery - 4PP451.0571-85 Power Panel 300/400 User's Manual V 2.30...

  • Page 287: Device 4Pp451.0571-B5

    Figure 180: Front view - 4PP451.0571-B5 aPCI Slot 2 aPCI Slot 1 Grounding clip Battery compartment Power button CompactFlash slot Reset button (with latch) Supply voltage Ethernet (x1) Status (x16) LEDs Figure 181: Back view - 4PP451.0571-B5 Power Panel 300/400 User's Manual V 2.30...

  • Page 288: Technical Data

    Connection RJ45 twisted pair (10 Base T / 100 Base T) Cables S/STP (category 5) NE2000-compatible CompactFlash Type Type I Amount 1 slot Connection Primary IDE device Table 99: Technical data - 4PP451.0571-B5 Power Panel 300/400 User's Manual V 2.30...
  • Page 289 Typ. 12 mcd (yellow) and 20 mcd (green) Pressing more than one key at a time may result in so-called phantom keys, and may trigger unintended actions. Table 99: Technical data - 4PP451.0571-B5 (Forts.) Power Panel 300/400 User's Manual V 2.30...
  • Page 290 Maximum lifespan in 24-hour operation (no buffer) 6 years at +25°C or 5 years at +50°C. Maximum lifespan switched off: 2 years at +25°C or 1 year at +50°C. 4) The actual value depends on the operating system or diver being used. Power Panel 300/400 User's Manual V 2.30...

  • Page 291: Temperature Humidity Diagram

    7) Depending on the process or batch, there may be visible deviations in the color and surface structure. 8) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 4.18.2 Temperature humidity diagram Operation Temperature [°C] Figure 182: Temperature humidity diagram - 4PP451.0571-B5 Power Panel 300/400 User's Manual V 2.30...

  • Page 292: Dimensions

    ± 0.2 mm over 6 to 30 mm ± 0.3 mm over 30 to 120 mm ± 0.5 mm over 120 to 400 ± 0.8 mm over 400 to 1000 Figure 183: Dimensions - 4PP451.0571-B5 Power Panel 300/400 User's Manual V 2.30...

  • Page 293: Cutout Installation

    The following components are included in the delivery of the Power Panel device: Amount Component Power Panel PP451 5.7" QVGA, 1 aPCI, keys Retaining clips included Lithium battery 3 V / 950 mAh included Table 100: Delivery contents - 4PP451.0571-B5 Power Panel 300/400 User's Manual V 2.30...

  • Page 294: Device 4Pp451.1043-75

    Figure 185: Front view - 4PP451.1043-75 Battery compartment aPCI Slot 1 CompactFlash slot (with latch) Grounding clip Power button Reset button (x1) Supply (x16) voltage Status Ethernet LEDs Figure 186: Rear view - 4PP451.1043-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 295: Technical Data

    Connection RJ45 twisted pair (10 Base T / 100 Base T) Cables S/STP (category 5) NE2000-compatible CompactFlash Type Type I Amount 1 slot Connection Primary IDE device Table 101: Technical data - 4PP451.1043-75 Power Panel 300/400 User's Manual V 2.30...
  • Page 296 Typ. 12 mcd (yellow) and 20 mcd (green) Pressing more than one key at a time may result in so-called phantom keys, and may trigger unintended actions. Table 101: Technical data - 4PP451.1043-75 (Forts.) Power Panel 300/400 User's Manual V 2.30...
  • Page 297 Maximum lifespan in 24-hour operation (no buffer) 6 years at +25°C or 5 years at +50°C. Maximum lifespan switched off: 2 years at +25°C or 1 year at +50°C. 4) The actual value depends on the operating system or diver being used. Power Panel 300/400 User's Manual V 2.30...

  • Page 298: Temperature Humidity Diagram

    7) Depending on the process or batch, there may be visible deviations in the color and surface structure. 8) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 4.19.2 Temperature humidity diagram Operation Temperature [°C] Figure 187: Temperature humidity diagram - 4PP451.1043-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 299: Dimensions

    6 to 30 mm ± 0.2 mm over 30 to 120 mm ± 0.3 mm ± 0.5 mm over 120 to 400 ± 0.8 mm over 400 to 1000 27,5 Figure 188: Dimensions - 4PP451.1043-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 300: Cutout Installation

    The following components are included in the delivery of the Power Panel device: Amount Component Power Panel PP451 5.7" QVGA, 1 aPCI, keys Retaining clips included Lithium battery 3 V / 950 mAh included Table 102: Contents of delivery - 4PP451.1043-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 301: Device 4Pp451.1043-B5

    Figure 190: Front view - 4PP451.1043-B5 Battery compartment aPCI slot 2 aPCI slot 1 CompactFlash slot (with latch) Grounding clip Power button Reset button Supply (x1) voltage (x16) Ethernet Status LEDs Figure 191: Rear view - 4PP451.1043-B5 Power Panel 300/400 User's Manual V 2.30...

  • Page 302: Technical Data

    Connection RJ45 twisted pair (10 Base T / 100 Base T) Cables S/STP (category 5) NE2000-compatible CompactFlash Type Type I Amount 1 slot Connection Primary IDE device Table 103: Technical data - 4PP451.1043-B5 Power Panel 300/400 User's Manual V 2.30...
  • Page 303 Typ. 12 mcd (yellow) and 20 mcd (green) Pressing more than one key at a time may result in so-called phantom keys, and may trigger unintended actions. Table 103: Technical data - 4PP451.1043-B5 (Forts.) Power Panel 300/400 User's Manual V 2.30...
  • Page 304 Maximum lifespan in 24-hour operation (no buffer) 6 years at +25°C or 5 years at +50°C. Maximum lifespan switched off: 2 years at +25°C or 1 year at +50°C. 4) The actual value depends on the operating system or diver being used. Power Panel 300/400 User's Manual V 2.30...

  • Page 305: Temperature Humidity Diagram

    7) Depending on the process or batch, there may be visible deviations in the color and surface structure. 8) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 4.20.2 Temperature humidity diagram Operation Temperature [°C] Figure 192: Temperature humidity diagram - 4PP451.1043-B5 Power Panel 300/400 User's Manual V 2.30...

  • Page 306: Dimensions

    6 to 30 mm ± 0.2 mm ± 0.3 mm over 30 to 120 mm over 120 to 400 ± 0.5 mm over 400 to 1000 ± 0.8 mm 27.5 Figure 193: Dimensions - 4PP451.1043-B5 Power Panel 300/400 User's Manual V 2.30...

  • Page 307: Cutout Installation

    The following components are included in the delivery of the Power Panel device: Amount Component Power Panel PP451 5.7" QVGA, 1 aPCI, keys Retaining clips included Lithium battery 3 V / 950 mAh included Table 104: Contents of delivery - 4PP451.1043-B5 Power Panel 300/400 User's Manual V 2.30...

  • Page 308: Device 4Pp452.0571-45

    Figure 195: Front view - 4PP452.0571-45 Battery compartment aPCI slot 1 Grounding clip Power button CompactFlash slot (with latch) Reset button Supply voltage Ethernet Status LEDs (x1) (x16) Figure 196: Rear view - 4PP452.0571-45 Power Panel 300/400 User's Manual V 2.30...

  • Page 309: Technical Data

    Connection RJ45 twisted pair (10 Base T / 100 Base T) Cables S/STP (category 5) NE2000-compatible CompactFlash Type Type I Amount 1 slot Connection Primary IDE device Table 105: Technical data - 4PP452.0571-45 Power Panel 300/400 User's Manual V 2.30...
  • Page 310 Typ. 12 mcd (yellow) and 20 mcd (green) Pressing more than one key at a time may result in so-called phantom keys, and may trigger unintended actions. Table 105: Technical data - 4PP452.0571-45 (Forts.) Power Panel 300/400 User's Manual V 2.30...
  • Page 311 Maximum lifespan in 24-hour operation (no buffer) 6 years at +25°C or 5 years at +50°C. Maximum lifespan switched off: 2 years at +25°C or 1 year at +50°C. 4) The actual value depends on the operating system or diver being used. Power Panel 300/400 User's Manual V 2.30...

  • Page 312: Temperature Humidity Diagram

    7) Depending on the process or batch, there may be visible deviations in the color and surface structure. 8) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 4.21.2 Temperature humidity diagram Operation Temperature [°C] Figure 197: Temperature humidity diagram - 4PP452.0571-45 Power Panel 300/400 User's Manual V 2.30...

  • Page 313: Dimensions

    6 to 30 mm ± 0.3 mm over 30 to 120 mm ± 0.5 mm over 120 to 400 mm ± 0.8 mm over 400 to 1000 mm Figure 198: Dimensions - 4PP452.0571-45 Power Panel 300/400 User's Manual V 2.30...

  • Page 314: Cutout Installation

    The following components are included in the delivery of the Power Panel device: Amount Component Power Panel PP452 5.7" QVGA, 1 aPCI, keys Retaining clips included Lithium battery 3 V / 950 mAh included Table 106: Contents of delivery - 4PP452.0571-45 Power Panel 300/400 User's Manual V 2.30...

  • Page 315: Device 4Pp452.0571-65

    Figure 200: Front view - 4PP452.0571-65 Battery compartment aPCI slot 1 Grounding clip Power button CompactFlash slot (with latch) Reset button Supply voltage Ethernet Status LEDs (x1) (x16) Figure 201: Rear view - 4PP452.0571-65 Power Panel 300/400 User's Manual V 2.30...

  • Page 316: Technical Data

    Connection RJ45 twisted pair (10 Base T / 100 Base T) Cables S/STP (category 5) NE2000-compatible CompactFlash Type Type I Amount 1 slot Connection Primary IDE device Table 107: Technical data - 4PP452.0571-65 Power Panel 300/400 User's Manual V 2.30...
  • Page 317 Typ. 12 mcd (yellow) and 20 mcd (green) Pressing more than one key at a time may result in so-called phantom keys, and may trigger unintended actions. Table 107: Technical data - 4PP452.0571-65 (Forts.) Power Panel 300/400 User's Manual V 2.30...
  • Page 318 Maximum lifespan in 24-hour operation (no buffer) 6 years at +25°C or 5 years at +50°C. Maximum lifespan switched off: 2 years at +25°C or 1 year at +50°C. 4) The actual value depends on the operating system or diver being used. Power Panel 300/400 User's Manual V 2.30...

  • Page 319: Temperature Humidity Diagram

    7) Depending on the process or batch, there may be visible deviations in the color and surface structure. 8) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 4.22.2 Temperature humidity diagram Operation Temperature [°C] Figure 202: Temperature humidity diagram - 4PP452.0571-65 Power Panel 300/400 User's Manual V 2.30...

  • Page 320: Dimensions

    6 to 30 mm ± 0.3 mm over 30 to 120 mm ± 0.5 mm over 120 to 400 mm ± 0.8 mm over 400 to 1000 mm Figure 203: Dimensions - 4PP452.0571-65 Power Panel 300/400 User's Manual V 2.30...

  • Page 321: Cutout Installation

    The following components are included in the delivery of the Power Panel device: Amount Component Power Panel PP452 5.7" QVGA, 1 aPCI, keys Retaining clips included Lithium battery 3 V / 950 mAh included Table 108: Contents of delivery - 4PP452.0571-65 Power Panel 300/400 User's Manual V 2.30...

  • Page 322: Device 4Pp452.0571-75

    Figure 205: Front view - 4PP452.0571-75 Battery compartment aPCI slot 1 Grounding clip Power button CompactFlash slot (with latch) Reset button Supply voltage Ethernet Status LEDs (x1) (x16) Figure 206: Rear view - 4PP452.0571-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 323: Technical Data

    Connection RJ45 twisted pair (10 Base T / 100 Base T) Cables S/STP (category 5) NE2000-compatible CompactFlash Type Type I Amount 1 slot Connection Primary IDE device Table 109: Technical data - 4PP452.0571-75 Power Panel 300/400 User's Manual V 2.30...
  • Page 324 Typ. 12 mcd (yellow) and 20 mcd (green) Pressing more than one key at a time may result in so-called phantom keys, and may trigger unintended actions. Table 109: Technical data - 4PP452.0571-75 (Forts.) Power Panel 300/400 User's Manual V 2.30...
  • Page 325 Maximum lifespan in 24-hour operation (no buffer) 6 years at +25°C or 5 years at +50°C. Maximum lifespan switched off: 2 years at +25°C or 1 year at +50°C. 4) The actual value depends on the operating system or diver being used. Power Panel 300/400 User's Manual V 2.30...

  • Page 326: Temperature Humidity Diagram

    7) Depending on the process or batch, there may be visible deviations in the color and surface structure. 8) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 4.23.2 Temperature humidity diagram Operation Temperature [°C] Figure 207: Temperature humidity diagram - 4PP452.0571-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 327: Dimensions

    6 to 30 mm ± 0.3 mm over 30 to 120 mm ± 0.5 mm over 120 to 400 mm ± 0.8 mm over 400 to 1000 mm Figure 208: Dimensions - 4PP452.0571-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 328: Cutout Installation

    The following components are included in the delivery of the Power Panel device: Amount Component Power Panel PP452 5.7" QVGA, 1 aPCI, keys Retaining clips included Lithium battery 3 V / 950 mAh included Table 110: Contents of delivery - 4PP452.0571-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 329: Device 4Pp452.0571-B5

    Figure 210: Front view - 4PP452.0571-B5 Battery compartment aPCI slot 2 aPCI slot 1 Grounding clip Power button CompactFlash slot (with latch) Reset button Supply voltage Ethernet Status LEDs (x1) (x16) Figure 211: Rear view - 4PP452.0571-B5 Power Panel 300/400 User's Manual V 2.30...

  • Page 330: Technical Data

    Connection RJ45 twisted pair (10 Base T / 100 Base T) Cables S/STP (category 5) NE2000-compatible CompactFlash Type Type I Amount 1 slot Connection Primary IDE device Table 111: Technical data - 4PP452.0571-B5 Power Panel 300/400 User's Manual V 2.30...
  • Page 331 Typ. 12 mcd (yellow) and 20 mcd (green) Pressing more than one key at a time may result in so-called phantom keys, and may trigger unintended actions. Table 111: Technical data - 4PP452.0571-B5 (Forts.) Power Panel 300/400 User's Manual V 2.30...
  • Page 332 Maximum lifespan in 24-hour operation (no buffer) 6 years at +25°C or 5 years at +50°C. Maximum lifespan switched off: 2 years at +25°C or 1 year at +50°C. 4) The actual value depends on the operating system or diver being used. Power Panel 300/400 User's Manual V 2.30...

  • Page 333: Temperature Humidity Diagram

    7) Depending on the process or batch, there may be visible deviations in the color and surface structure. 8) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 4.24.2 Temperature humidity diagram Operation Temperature [°C] Figure 212: Temperature humidity diagram - 4PP452.0571-B5 Power Panel 300/400 User's Manual V 2.30...

  • Page 334: Dimensions

    6 to 30 mm ± 0.2 mm over 30 to 120 mm ± 0.3 mm over 120 to 400 ± 0.5 mm over 400 to 1000 ± 0.8 mm Figure 213: Dimensions - 4PP452.0571-B5 Power Panel 300/400 User's Manual V 2.30...

  • Page 335: Cutout Installation

    The following components are included in the delivery of the Power Panel device: Amount Component Power Panel PP452 5.7" QVGA, 1 aPCI, keys Retaining clips included Lithium battery 3 V / 950 mAh included Table 112: Contents of delivery - 4PP452.0571-B5 Power Panel 300/400 User's Manual V 2.30...

  • Page 336: Device 4Pp452.1043-75

    Figure 215: Front view - 4PP452.1043-75 Battery compartment aPCI slot 1 CompactFlash slot (with latch) Grounding clip Power button (x1) Reset button (x16) Supply voltage Status Ethernet LEDs Figure 216: Rear view - 4PP452.1043-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 337: Technical Data

    Connection RJ45 twisted pair (10 Base T / 100 Base T) Cables S/STP (category 5) NE2000-compatible CompactFlash Type Type I Amount 1 slot Connection Primary IDE device Table 113: Technical data - 4PP452.1043-75 Power Panel 300/400 User's Manual V 2.30...
  • Page 338 Typ. 12 mcd (yellow) and 20 mcd (green) Pressing more than one key at a time may result in so-called phantom keys, and may trigger unintended actions. Table 113: Technical data - 4PP452.1043-75 (Forts.) Power Panel 300/400 User's Manual V 2.30...
  • Page 339 Maximum lifespan in 24-hour operation (no buffer) 6 years at +25°C or 5 years at +50°C. Maximum lifespan switched off: 2 years at +25°C or 1 year at +50°C. 4) The actual value depends on the operating system or diver being used. Power Panel 300/400 User's Manual V 2.30...

  • Page 340: Temperature Humidity Diagram

    7) Depending on the process or batch, there may be visible deviations in the color and surface structure. 8) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 4.25.2 Temperature humidity diagram Operation Temperature [°C] Figure 217: Temperature humidity diagram - 4PP452.1043-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 341: Dimensions

    6 to 30 mm ± 0.2 mm over 30 to 120 mm ± 0.3 mm over 120 to 400 ± 0.5 mm over 400 to 1000 ± 0.8 mm 27.5 Figure 218: Dimensions - 4PP452.1043-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 342: Cutout Installation

    The following components are included in the delivery of the Power Panel device: Amount Component Power Panel PP482 10.4" VGA, 1 aPCI, keys Retaining clips included Lithium battery 3 V / 950 mAh included Table 114: Contents of delivery - 4PP452.1043-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 343: Device 4Pp480.1043-75

    Figure 220: Front view - 4PP480.1043-75 aPCI Slot 1 Battery compartment Grounding clip Power button CompactFlash slot (with latch) Reset button Supply voltage (x1) (x16) Ethernet Status LEDs Figure 221: Rear view - 4PP480.1043-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 344: Technical Data

    Connection RJ45 twisted pair (10 Base T / 100 Base T) Cables S/STP (category 5) NE2000-compatible CompactFlash Type Type I Amount 1 slot Connection Primary IDE device Table 115: Technical data - 4PP480.1043-75 Power Panel 300/400 User's Manual V 2.30...
  • Page 345 Typ. 12 mcd (yellow) and 20 mcd (green) Pressing more than one key at a time may result in so-called phantom keys, and may trigger unintended actions. Table 115: Technical data - 4PP480.1043-75 (Forts.) Power Panel 300/400 User's Manual V 2.30...
  • Page 346 4) The actual value depends on the operating system or diver being used. 5) At +25°C ambient temperature. Reducing the brightness by 50% can result in an approximate 50% increase of the half-brightness time. Power Panel 300/400 User's Manual V 2.30...

  • Page 347: Temperature Humidity Diagram

    7) Depending on the process or batch, there may be visible deviations in the color and surface structure. 8) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 4.26.2 Temperature humidity diagram Operation Temperature [°C] Figure 222: Temperature humidity diagram - 4PP480.1043-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 348: Dimensions

    6 to 30 mm ± 0.3 mm over 30 to 120 mm ± 0.5 mm over 120 to 400 mm ± 0.8 mm over 400 to 1000 mm 27.5 Figure 223: Dimensions - 4PP480.1043-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 349: Cutout Installation

    The following components are included in the delivery of the Power Panel device: Amount Component Power Panel PP480 10.4" VGA, 1 aPCI, touch screen, keys Retaining clips included Lithium battery 3 V / 950 mAh included Table 116: Contents of delivery - 4PP480.1043-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 350: Device 4Pp480.1505-75

    Figure 225: Front view - 4PP480.1505-75 aPCI Slot 1 Battery compartment CompactFlash slot Grounding clip (with latch) Power button Reset button Supply (x1) voltage (x16) Status LEDs Ethernet Figure 226: Rear view - 4PP480.1505-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 351: Technical Data

    Connection RJ45 twisted pair (10 Base T / 100 Base T) Cables S/STP (category 5) NE2000-compatible CompactFlash Type Type I Amount 1 slot Connection Primary IDE device Table 117: Technical data - 4PP480.1505-75 Power Panel 300/400 User's Manual V 2.30...
  • Page 352 Typ. 12 mcd (yellow) and 20 mcd (green) Pressing more than one key at a time may result in so-called phantom keys, and may trigger unintended actions. Table 117: Technical data - 4PP480.1505-75 (Forts.) Power Panel 300/400 User's Manual V 2.30...
  • Page 353 4) The actual value depends on the operating system or diver being used. 5) At +25°C ambient temperature. Reducing the brightness by 50% can result in an approximate 50% increase of the half-brightness time. Power Panel 300/400 User's Manual V 2.30...

  • Page 354: Temperature Humidity Diagram

    7) Depending on the process or batch, there may be visible deviations in the color and surface structure. 8) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 4.27.2 Temperature humidity diagram Operation Temperature [°C] Figure 227: Temperature humidity diagram - 4PP480.1505-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 355: Dimensions

    6 to 30 mm ± 0.3 mm over 30 to 120 mm ± 0.5 mm over 120 to 400 mm ± 0.8 mm over 400 to 1000 mm 28.5 Figure 228: Dimensions - 4PP480.1505-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 356: Cutout Installation

    The following components are included in the delivery of the Power Panel device: Amount Component Power Panel PP480 15" XGA, 1 aPCI, touch screen, keys Retaining clips included Lithium battery 3 V / 950 mAh included Table 118: Contents of delivery - 4PP480.1505-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 357: Device 4Pp480.1505-B5

    Figure 230: Front view - 4PP480.1505-B5 aPCI Slot 2 aPCI Slot 1 Battery compartment CompactFlash slot Grounding clip (with latch) Power button Reset button Supply (x1) voltage (x16) Status LEDs Ethernet Figure 231: Rear view - 4PP480.1505-B5 Power Panel 300/400 User's Manual V 2.30...

  • Page 358: Technical Data

    Connection RJ45 twisted pair (10 Base T / 100 Base T) Cables S/STP (category 5) NE2000-compatible CompactFlash Type Type I Amount 1 slot Connection Primary IDE device Table 119: Technical data - 4PP480.1505-B5 Power Panel 300/400 User's Manual V 2.30...
  • Page 359 Typ. 12 mcd (yellow) and 20 mcd (green) Pressing more than one key at a time may result in so-called phantom keys, and may trigger unintended actions. Table 119: Technical data - 4PP480.1505-B5 (Forts.) Power Panel 300/400 User's Manual V 2.30...
  • Page 360 4) The actual value depends on the operating system or diver being used. 5) At +25°C ambient temperature. Reducing the brightness by 50% can result in an approximate 50% increase of the half-brightness time. Power Panel 300/400 User's Manual V 2.30...

  • Page 361: Temperature Humidity Diagram

    7) Depending on the process or batch, there may be visible deviations in the color and surface structure. 8) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 4.28.2 Temperature humidity diagram Operation Temperature [°C] Figure 232: Temperature humidity diagram - 4PP480.1505-B5 Power Panel 300/400 User's Manual V 2.30...

  • Page 362: Dimensions

    6 to 30 mm ± 0.2 mm ± 0.3 mm over 30 to 120 mm over 120 to 400 ± 0.5 mm over 400 to 1000 ± 0.8 mm 28.5 Figure 233: Dimensions - 4PP480.1505-B5 Power Panel 300/400 User's Manual V 2.30...

  • Page 363: Cutout Installation

    The following components are included in the delivery of the Power Panel device: Amount Component Power Panel PP480 15" XGA, 1 aPCI, touch screen, keys Retaining clips included Lithium battery 3 V / 950 mAh included Table 120: Contents of delivery - 4PP480.1505-B5 Power Panel 300/400 User's Manual V 2.30...

  • Page 364: Device 4Pp481.1043-75

    Figure 235: Front view - 4PP481.1043-75 Battery compartment aPCI Slot 1 CompactFlash slot (with latch) Grounding clip Power button Reset button (x1) Supply (x16) voltage Status Ethernet LEDs Figure 236: Rear view - 4PP481.1043-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 365: Technical Data

    Connection RJ45 twisted pair (10 Base T / 100 Base T) Cables S/STP (category 5) NE2000-compatible CompactFlash Type Type I Amount 1 slot Connection Primary IDE device Table 121: Technical data - 4PP481.1043-75 Power Panel 300/400 User's Manual V 2.30...
  • Page 366 Typ. 12 mcd (yellow) and 20 mcd (green) Pressing more than one key at a time may result in so-called phantom keys, and may trigger unintended actions. Table 121: Technical data - 4PP481.1043-75 (Forts.) Power Panel 300/400 User's Manual V 2.30...
  • Page 367 Maximum lifespan in 24-hour operation (no buffer) 6 years at +25°C or 5 years at +50°C. Maximum lifespan switched off: 2 years at +25°C or 1 year at +50°C. 4) The actual value depends on the operating system or diver being used. Power Panel 300/400 User's Manual V 2.30...

  • Page 368: Temperature Humidity Diagram

    7) Depending on the process or batch, there may be visible deviations in the color and surface structure. 8) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 4.29.2 Temperature humidity diagram Operation Temperature [°C] Figure 237: Temperature humidity diagram - 4PP481.1043-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 369: Dimensions

    6 to 30 mm ± 0.3 mm over 30 to 120 mm ± 0.5 mm over 120 to 400 mm ± 0.8 mm over 400 to 1000 mm 27.5 Figure 238: Dimensions - 4PP481.1043-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 370: Cutout Installation

    The following components are included in the delivery of the Power Panel device: Amount Component Power Panel PP481 10.4" VGA, 1 aPCI, touch screen, keys Retaining clips included Lithium battery 3 V / 950 mAh included Table 122: Contents of delivery - 4PP481.1043-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 371: Device 4Pp481.1043-B5

    Figure 240: Front view - 4PP481.1043-B5 Battery compartment aPCI slot 2 aPCI slot 1 CompactFlash slot (with latch) Grounding clip Power button Reset button Supply (x1) voltage (x16) Ethernet Status LEDs Figure 241: Rear view - 4PP481.1043-B5 Power Panel 300/400 User's Manual V 2.30...

  • Page 372: Technical Data

    Connection RJ45 twisted pair (10 Base T / 100 Base T) Cables S/STP (category 5) NE2000-compatible CompactFlash Type Type I Amount 1 slot Connection Primary IDE device Table 123: Technical data - 4PP481.1043-B5 Power Panel 300/400 User's Manual V 2.30...
  • Page 373 Typ. 12 mcd (yellow) and 20 mcd (green) Pressing more than one key at a time may result in so-called phantom keys, and may trigger unintended actions. Table 123: Technical data - 4PP481.1043-B5 (Forts.) Power Panel 300/400 User's Manual V 2.30...
  • Page 374 Maximum lifespan in 24-hour operation (no buffer) 6 years at +25°C or 5 years at +50°C. Maximum lifespan switched off: 2 years at +25°C or 1 year at +50°C. 4) The actual value depends on the operating system or diver being used. Power Panel 300/400 User's Manual V 2.30...

  • Page 375: Temperature Humidity Diagram

    7) Depending on the process or batch, there may be visible deviations in the color and surface structure. 8) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 4.30.2 Temperature humidity diagram Operation Temperature [°C] Figure 242: Temperature humidity diagram - 4PP481.1043-B5 Power Panel 300/400 User's Manual V 2.30...

  • Page 376: Dimensions

    6 to 30 mm ± 0.3 mm over 30 to 120 mm ± 0.5 mm over 120 to 400 mm ± 0.8 mm over 400 to 1000 mm 27.5 Figure 243: Dimensions - 4PP481.1043-B5 Power Panel 300/400 User's Manual V 2.30...

  • Page 377: Cutout Installation

    The following components are included in the delivery of the Power Panel device: Amount Component Power Panel PP481 10.4" VGA, 2 aPCI, touch screen, keys Retaining clips included Lithium battery 3 V / 950 mAh included Table 124: Contents of delivery - 4PP481.1043-B5 Power Panel 300/400 User's Manual V 2.30...

  • Page 378: Device 4Pp481.1505-75

    Figure 245: Front view - 4PP481.1505-75 Battery compartment aPCI slot 1 CompactFlash slot (with latch) (x1) Grounding clip (x16) Power button Status LEDs Reset button Supply voltage Ethernet Figure 246: Rear view - 4PP481.1505-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 379: Technical Data

    Connection RJ45 twisted pair (10 Base T / 100 Base T) Cables S/STP (category 5) NE2000-compatible CompactFlash Type Type I Amount 1 slot Connection Primary IDE device Table 125: Technical data - 4PP481.1505-75 Power Panel 300/400 User's Manual V 2.30...
  • Page 380 Typ. 12 mcd (yellow) and 20 mcd (green) Pressing more than one key at a time may result in so-called phantom keys, and may trigger unintended actions. Table 125: Technical data - 4PP481.1505-75 (Forts.) Power Panel 300/400 User's Manual V 2.30...
  • Page 381 Maximum lifespan in 24-hour operation (no buffer) 6 years at +25°C or 5 years at +50°C. Maximum lifespan switched off: 2 years at +25°C or 1 year at +50°C. 4) The actual value depends on the operating system or diver being used. Power Panel 300/400 User's Manual V 2.30...

  • Page 382: Temperature Humidity Diagram

    7) Depending on the process or batch, there may be visible deviations in the color and surface structure. 8) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 4.31.2 Temperature humidity diagram Operation Temperature [°C] Figure 247: Temperature humidity diagram - 4PP481.1505-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 383: Dimensions

    ± 0.2 mm ± 0.3 mm over 30 to 120 mm over 120 to 400 mm ± 0.5 mm ± 0.8 mm over 400 to 1000 mm 28.5 Figure 248: Dimensions - 4PP481.1505-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 384: Cutout Installation

    The following components are included in the delivery of the Power Panel device: Amount Component Power Panel PP481 15" XGA, 1 aPCI, touch screen, keys Retaining clips included Lithium battery 3 V / 950 mAh included Table 126: Contents of delivery - 4PP481.1505-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 385: Device 4Pp482.1043-75

    Figure 250: Front view - 4PP482.1043-75 Battery compartment aPCI slot 1 CompactFlash slot (with latch) Grounding clip Power button (x1) Reset button (x16) Supply voltage Status Ethernet LEDs Figure 251: Rear view - 4PP482.1043-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 386: Technical Data

    Connection RJ45 twisted pair (10 Base T / 100 Base T) Cables S/STP (category 5) NE2000-compatible CompactFlash Type Type I Amount 1 slot Connection Primary IDE device Table 127: Technical data - 4PP482.1043-75 Power Panel 300/400 User's Manual V 2.30...
  • Page 387 Typ. 12 mcd (yellow) and 20 mcd (green) Pressing more than one key at a time may result in so-called phantom keys, and may trigger unintended actions. Table 127: Technical data - 4PP482.1043-75 (Forts.) Power Panel 300/400 User's Manual V 2.30...
  • Page 388 Maximum lifespan in 24-hour operation (no buffer) 6 years at +25°C or 5 years at +50°C. Maximum lifespan switched off: 2 years at +25°C or 1 year at +50°C. 4) The actual value depends on the operating system or diver being used. Power Panel 300/400 User's Manual V 2.30...

  • Page 389: Temperature Humidity Diagram

    7) Depending on the process or batch, there may be visible deviations in the color and surface structure. 8) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 4.32.2 Temperature humidity diagram Operation Temperature [°C] Figure 252: Temperature humidity diagram - 4PP482.1043-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 390: Dimensions

    6 to 30 mm ± 0.3 mm over 30 to 120 mm ± 0.5 mm over 120 to 400 mm ± 0.8 mm over 400 to 1000 mm 27.5 Figure 253: Dimensions - 4PP482.1043-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 391: Cutout Installation

    The following components are included in the delivery of the Power Panel device: Amount Component Power Panel PP482 10.4" VGA, 1 aPCI, touch screen, keys Retaining clips included Lithium battery 3 V / 950 mAh included Table 128: Contents of delivery - 4PP482.1043-75 Power Panel 300/400 User's Manual V 2.30...

  • Page 392: Power Panel Light / Compact

    MTCX Power failure logic Controller MTCX Buffer time 10 ms Real-time clock (RTC) Battery-buffered Accuracy At +25°C: typically 30 ppm (2.5 seconds) per day Table 129: Technical data - Power Panel 420 light Power Panel 300/400 User's Manual V 2.30...
  • Page 393 (3IF771.9) (3IF791.9) (3IF771.9) (3IF791.9) (3IF771.9) (3IF791.9) inserted inserted inserted inserted inserted inserted Holding torque for aPCI module Max. 0.7 Nm Table 129: Technical data - Power Panel 420 light Power Panel 300/400 User's Manual V 2.30...
  • Page 394 Gray Membrane Polyester Dark gray border around display Similar to Pantone 432CV Light background Similar to Pantone 427CV Gasket Flat gasket around display front Table 129: Technical data - Power Panel 420 light Power Panel 300/400 User's Manual V 2.30...
  • Page 395 6) Depending on the process or batch, there may be visible deviations in the color and surface structure. 7) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). Power Panel 300/400 User's Manual V 2.30...

  • Page 396: Temperature Humidity Diagram - Pp420 Light Lcd Monochrome

    5.1.3 Temperature humidity diagram - PP420 light LCD color and TFT color The following diagram is valid for the devices 4PP420:0571-L25, 4PP420:0571-L65, 4PP420:0571-L35 and 4PP420:0571-L75. Operation Temperature [°C] Figure 256: Temperature humidity diagram - PP420 light LCD color and TFT color Power Panel 300/400 User's Manual V 2.30...

  • Page 397: Technical Data - Power Panel 420 Compact

    RJ45 twisted pair (10 Base T / 100 Base T) Cables S/STP (category 5) NE2000-compatible CompactFlash Type Type I Amount 1 slot Connection Primary IDE device Table 130: Technical data - Power Panel 420 compact Power Panel 300/400 User's Manual V 2.30...
  • Page 398 Touch screen type Gunze Technology Analog, resistive Controller Elo, serial, 12- bit Up to 80% ±5% Degree of transmission Filter glass Degree of transmission Coating Table 130: Technical data - Power Panel 420 compact Power Panel 300/400 User's Manual V 2.30...
  • Page 399 2 - 8 Hz: 7.5 mm amplitude / 8 - 200 Hz: 2 g / 200 - 500 Hz: 4 g Shock Operation 15 g, 11 ms Storage 30 g, 15 ms Transport 30 g, 15 ms Table 130: Technical data - Power Panel 420 compact Power Panel 300/400 User's Manual V 2.30...

  • Page 400: Temperature Humidity Diagram - Pp420 Compact Lcd Monochrome

    5.1.5 Temperature humidity diagram - PP420 compact LCD monochrome The following diagram is valid for the devices 4PP420:0571-C05 and 4PP420:0571-C45. Operation Temperature [°C] Figure 257: Temperature humidity diagram - PP420 compact LCD monochrome Power Panel 300/400 User's Manual V 2.30...

  • Page 401: Temperature Humidity Diagram - Pp420 Compact Lcd Color And Tft Color

    5.1.6 Temperature humidity diagram - PP420 compact LCD color and TFT color The following diagram is valid for the devices 4PP420:0571-C25, 4PP420:0571-C65, 4PP420:0571-C35 and 4PP420:0571-C75. Operation Temperature [°C] Figure 258: Temperature humidity diagram - PP420 compact LCD color and TFT color Power Panel 300/400 User's Manual V 2.30...

  • Page 402: Power Panel 451 Light / Compact

    Backup capacitor (for changing battery) Buffer time 10 minutes Ethernet Controller Transfer rate Connection Cables NE2000-compatible CompactFlash Type Type I Amount 1 slot Connection Primary IDE device Table 131: Technical data - Power Panel 451 light Power Panel 300/400 User's Manual V 2.30...
  • Page 403 "Screen rotation" on page 426 Touch screen Touch screen type Technology Controller Degree of transmission Filter glass Degree of transmission Coating On both sides Table 131: Technical data - Power Panel 451 light Power Panel 300/400 User's Manual V 2.30...
  • Page 404 2 - 8 Hz: 7.5 mm amplitude / 8 - 200 Hz: 2 g / 200 - 500 Hz: 4 g Shock Operation 15 g, 11 ms Storage 30 g, 15 ms Transport 30 g, 15 ms Table 131: Technical data - Power Panel 451 light Power Panel 300/400 User's Manual V 2.30...

  • Page 405: Temperature Humidity Diagram

    8) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 5.2.2 Temperature humidity diagram Operation Temperature [°C] Figure 259: Temperature humidity diagram - PP451 light Power Panel 300/400 User's Manual V 2.30...

  • Page 406: Technical Data - Power Panel 451 Compact

    RJ45 twisted pair (10 Base T / 100 Base T) Cables S/STP (category 5) NE2000-compatible CompactFlash Type Type I Amount 1 slot Connection Primary IDE device Table 132: Technical data - Power Panel 451 compact Power Panel 300/400 User's Manual V 2.30...
  • Page 407 "Screen rotation" on page 426 Touch screen Touch screen type Technology Controller Degree of transmission Filter glass Degree of transmission Coating On both sides Table 132: Technical data - Power Panel 451 compact Power Panel 300/400 User's Manual V 2.30...
  • Page 408 2 - 8 Hz: 7.5 mm amplitude / 8 - 200 Hz: 2 g / 200 - 500 Hz: 4 g Shock Operation 15 g, 11 ms Storage 30 g, 15 ms Transport 30 g, 15 ms Table 132: Technical data - Power Panel 451 compact Power Panel 300/400 User's Manual V 2.30...

  • Page 409: Temperature Humidity Diagram

    8) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 5.2.4 Temperature humidity diagram Operation Temperature [°C] Figure 260: Temperature humidity diagram - PP451 compact Power Panel 300/400 User's Manual V 2.30...

  • Page 410: Power Panel 452 Light / Compact

    Backup capacitor (for changing battery) Buffer time 10 minutes Ethernet Controller Transfer rate Connection Cables NE2000-compatible CompactFlash Type Type I Amount 1 slot Connection Primary IDE device Table 133: Technical data - Power Panel 452 light Power Panel 300/400 User's Manual V 2.30...
  • Page 411 "Screen rotation" on page 426 Touch screen Touch screen type Technology Controller Degree of transmission Filter glass Degree of transmission Coating On both sides Table 133: Technical data - Power Panel 452 light Power Panel 300/400 User's Manual V 2.30...
  • Page 412 2 - 8 Hz: 7.5 mm amplitude / 8 - 200 Hz: 2 g / 200 - 500 Hz: 4 g Shock Operation 15 g, 11 ms Storage 30 g, 15 ms Transport 30 g, 15 ms Table 133: Technical data - Power Panel 452 light Power Panel 300/400 User's Manual V 2.30...

  • Page 413: Temperature Humidity Diagram

    8) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 5.3.2 Temperature humidity diagram Operation Temperature [°C] Figure 261: Temperature humidity diagram - PP452 light Power Panel 300/400 User's Manual V 2.30...

  • Page 414: Technical Data - Power Panel 452 Compact

    RJ45 twisted pair (10 Base T / 100 Base T) Cables S/STP (category 5) NE2000-compatible CompactFlash Type Type I Amount 1 slot Connection Primary IDE device Table 134: Technical data - Power Panel 452 compact Power Panel 300/400 User's Manual V 2.30...
  • Page 415 "Screen rotation" on page 426 Touch screen Touch screen type Technology Controller Degree of transmission Filter glass Degree of transmission Coating On both sides Table 134: Technical data - Power Panel 452 compact Power Panel 300/400 User's Manual V 2.30...
  • Page 416 2 - 8 Hz: 7.5 mm amplitude / 8 - 200 Hz: 2 g / 200 - 500 Hz: 4 g Shock Operation 15 g, 11 ms Storage 30 g, 15 ms Transport 30 g, 15 ms Table 134: Technical data - Power Panel 452 compact Power Panel 300/400 User's Manual V 2.30...

  • Page 417: Temperature Humidity Diagram

    8) Derating the maximum ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). 5.3.4 Temperature humidity diagram Operation Temperature [°C] Figure 262: Temperature humidity diagram - PP452 compact Power Panel 300/400 User's Manual V 2.30...

  • Page 418: Block Diagram

    Technical data • Block diagram 6. Block diagram The following block diagrams show the simplified system unit structure with a CPU board. 6.1 Power Panel 300 (with no aPCI slots) Serial Key Touch Touch Power SPI prog. RS232 3-pin 6-pin...

  • Page 419: Power Panel 400 With 1 Apci Slot

    Companion device Compact BGA208 controller Flash UART2 yellow RxD, TxD UART1 Internal connections RS232 int. AC97 External connections JTAG 4-pin header Figure 264: Block diagram - Power Panel 400 with 1 aPCI slot Power Panel 300/400 User's Manual V 2.30...

  • Page 420: Power Panel 400 With 2 Apci Slots

    Companion Device Compact BGA208 controller Flash UART2 yellow RxD, TxD UART1 interne Anschlüsse RS232 int. AC97 JTAG externe Anschlüsse 4-pin header Figure 265: Block diagram - Power Panel 400 with 2 aPCI slots Power Panel 300/400 User's Manual V 2.30...

  • Page 421: Chapter 3: Commissioning

    Power Panel device. The minimum specified free space can be found in the diagram below. Free space specifications apply to all Power Panel versions (with/without aPCI slots and keys). Power Panel 300/400 User's Manual V 2.30...
  • Page 422 Commissioning • Mounting instructions Side view At least 80 mm Rear view At least 40 mm At least 40 mm Table 135: Space for air circulation Power Panel 300/400 User's Manual V 2.30...

  • Page 423: Mounting Orientation

    The following diagram displays the specified mounting orientation for the Power Panel device. The mounting orientation applies to all Power Panel versions (with/without aPCI slots and keys). Mounting orientation 0° 0° Table 136: Mounting orientation 0° Power Panel 300/400 User's Manual V 2.30...
  • Page 424 0° Connection side down Connection side down Table 137: Mounting orientation -45° and +45°. Caution! The maximum permitted ambient temperature can be found in the technical data for the respective Power Panel device. Power Panel 300/400 User's Manual V 2.30...

  • Page 425: Touch Screen Calibration

    3.3 Automation Runtime / Visual Components The first time the touch screen is used, it must be calibrated once in the customer application for the existing device and project. Power Panel 300/400 User's Manual V 2.30...

  • Page 426: Screen Rotation

    4.3 Automation Runtime / Visual Components Automation Runtime supports the screen rotation function. When developing a project using Automation Studio 2.7.x or 3.0.x, you can select the orientation of the display before getting started. Power Panel 300/400 User's Manual V 2.30...

  • Page 427: User Tips For Increasing The Display Lifespan

    • avoiding excessive brightness contrast between foreground and background display • use of colors with similar brightness • use of complementary colors in subsequent images • use of screensavers Power Panel 300/400 User's Manual V 2.30...
  • Page 428 Commissioning • User tips for increasing the display lifespan Power Panel 300/400 User's Manual V 2.30...

  • Page 429: Chapter 4: Software

    Software • Power Panel 300 with BIOS Chapter 4 • Software 1. Power Panel 300 with BIOS Information: The following diagrams and BIOS menu items including descriptions refer to BIOS version 1.14. It is therefore possible that these diagrams and BIOS descriptions do not correspond with the installed BIOS version.

  • Page 430: Summary Screen

    Software • Power Panel 300 with BIOS 1.2 Summary screen Power Panel Rev: V01.14 (1.02.15) Built: 07/18/2007 07:38:15 Geode LX Rev: C0 @ 500MHz PCI: 33MHz 5536 Rev: B1 Memory: 57024k @ 333MHz/DDR CAS: 2.5 Floppy A: 1.44M COM1: 03F8 GeodeROM: 4.52.36...
  • Page 431 Software • Power Panel 300 with BIOS To make changes in the BIOS setup, the DEL key must be pressed when booting the Power Panel device as soon as the following message appears in the upper margin of the display...
  • Page 432 Software • Power Panel 300 with BIOS Function - (Minus) Decreases the numerical value or selects the previous parameter value. + (Plus) Increases the numerical value or selects the next parameter value. Table 138: BIOS-relevant keys (Forts.) Power Panel 300/400 User's Manual V 2.30...

  • Page 433: Bios Settings For Vga, Svga And Xga Power Panel Devices

    Software • Power Panel 300 with BIOS 1.3 BIOS settings for VGA, SVGA and XGA Power Panel devices Information: The BIOS default values can be found in the section 1.5 "BIOS default values" on page 477. 1.3.1 Main menu Immediately after the DEL button is pressed during startup, the main BIOS setup menu appears.

  • Page 434: Time

    Software • Power Panel 300 with BIOS Shortcut BIOS setup menu Function Device information Important parameters (e.g. temperature, mode/node position, etc.) for a Power Panel device are displayed here. Miscellaneous configuration The various BIOS settings can be configured here (Summary screen, Halt on errors, etc.) Boot order The boot order can be set here.

  • Page 435: Date

    Software • Power Panel 300 with BIOS • 13:00:00 - Confirm with Enter • 01:00:00 PM - Confirm with Enter • 13: - Confirm with Enter Information: If using a German keyboard, press the "Shift+ö" key to enter ":". 1.3.3 Date...

  • Page 436: Motherboard Device Configuration

    Software • Power Panel 300 with BIOS 1.3.4 Motherboard device configuration XpressROM Setup F1/ALT+H:Show Help ESC:Exit ALT+Q:Go to Main Menu ENTER:Select +/-:Choice Motherboard Device Configuration A. Drive Configuration B. I/O Configuration F. Video and Flat Panel Configuration G. PCI Configuration U.
  • Page 437 Software • Power Panel 300 with BIOS Motherboard device configuration - drive configuration XpressROM Setup F1/ALT+H:Show Help ESC:Exit ALT+Q:Go to Main Menu ENTER:Select +/-:Choice Drive Configuration IDE Configuration IDE BIOS Support: Enabled DMA/UDMA BIOS Support: Enabled Force mode for CF Card:...
  • Page 438 Software • Power Panel 300 with BIOS Motherboard device configuration - I/O configuration XpressROM Setup F1/ALT+H:Show Help ESC:Exit ALT+Q:Go to Main Menu ENTER:Select +/-:Choice Super I/O Configuration Serial Port Configuration COM A: Disabled COM C: 0x3f8 IRQ 4 COM D: 0x2f8 IRQ 3 Configure the 1st on-board UART.
  • Page 439 Software • Power Panel 300 with BIOS BIOS setting Meaning Setting options Effect COM D Configures the UART address range and Disabled No assignment. The touch screen is disabled and the corresponding interrupt for the touch does not function. controller.
  • Page 440 Software • Power Panel 300 with BIOS BIOS setting Meaning Setting options Effect Contrast Setting for the contrast of the display. Auto The optimal contrast is automatically configured using the factory settings. A contrast value between 100% and 0% is set.
  • Page 441 Software • Power Panel 300 with BIOS BIOS setting Meaning Setting options Effect PCI INTD# Disabled No IRQ is reserved. IRQ setting for the USB interface. 3, 4, 5, 6, 7, 9, 10, 11, 12, Manual configuration of the IRQ.
  • Page 442 Software • Power Panel 300 with BIOS BIOS setting Meaning Setting options Effect Overcurrent This function enables an automatic Enabled Enables this function. reporting message Disabled Disables this function. This function enables an automatic error message to be sent to the system when the USB hub is overloaded (e.g.

  • Page 443: Memory And Cache Optimization

    Software • Power Panel 300 with BIOS BIOS setting Meaning Setting options Effect Close submenu Close submenu Enter Closes the submenu. Table 146: BIOS thermal configuration menu (Forts.) 1.3.5 Memory and cache optimization Warning! The parameters in this screen are for system designers, service personnel, and technically competent users only.
  • Page 444 Software • Power Panel 300 with BIOS XpressROM Setup F1/ALT+H:Show Help ESC:Exit ALT+Q:Go to Main Menu ENTER:Select +/-:Choice Memory and Cache Optimization Cache Mode: Write-Back Cache Allocate: Disabled Refresh Rate: Auto Figure 280: Memory and cache optimization BIOS setting Meaning...

  • Page 445: System Clock/Pll Configuration

    Software • Power Panel 300 with BIOS 1.3.6 System clock/PLL configuration XpressROM Setup F1/ALT+H:Show Help ESC:Exit ALT+Q:Go to Main Menu ENTER:Select +/-:Choice System Clock/PLL Configuration Clock Mode Clock Determined By: H/W Strapping Manual PLL Settings CPU Multiplier: 500 MHz RAM Multiplier:...

  • Page 446: Power Management

    Software • Power Panel 300 with BIOS 1.3.7 Power management XpressROM Setup F1/ALT+H:Show Help ESC:Exit ALT+Q:Go to Main Menu ENTER:Select +/-:Choice Power Management BIOS PM at Boot: Disabled APM Available: ACPI Available: S1 Clocks: CPU Clock Gating: Enabled Chipset Clock Gating:...

  • Page 447: Device Information

    Software • Power Panel 300 with BIOS 1.3.8 Device information XpressROM Setup F1/ALT+H:Show Help ESC:Exit ALT+Q:Go to Main Menu ENTER:Select +/-:Choice Device Information Version Factory Settings MTCX FPGA: V1.00 Device ID: 000023BE MTCX PX32: V1.14 Comp. ID: 0000 MTCX KCF : V0.00...

  • Page 448: Miscellaneous Configuration

    Software • Power Panel 300 with BIOS BIOS setting Meaning Setting options Effect User ID Displays the User ID. None This 8 digit hex value can be freely assigned by the user (e.g. to give the device a unique ID) and can only be changed with using the "B&R Control...
  • Page 449 Software • Power Panel 300 with BIOS BIOS setting Meaning Setting options Effect Boot logo timeout Defines the duration of the "Press DEL for No waiting. Setup" message on the display and how much time the user has to change to the...

  • Page 450: Boot Order

    Software • Power Panel 300 with BIOS 1.3.10 Boot order XpressROM Setup F1/ALT+H:Show Help ESC:Exit ALT+Q:Go to Main Menu ENTER:Select +/-:Choice Boot Order Boot Order Configuration 1. USB Floppy Disk 2. USB CD-ROM Drive . Hard Drive 4. USB Hard Drive/Flash Drive...
  • Page 451 Software • Power Panel 300 with BIOS BIOS setting Meaning Setting options Effect Boot order Configures the order in which memory USB floppy disk The device attempts to boot from this drive first. configuration media is booted. USB CD-ROM If two identical devices are selected, a drive conflict warning is displayed.

  • Page 452: Load Defaults

    Software • Power Panel 300 with BIOS 1.3.11 Load defaults XpressROM Setup F1/ALT+H:Show Help ESC:Exit ALT+Q:Go to Main Menu ENTER:Select +/-:Choice Main Menu T. Time 21:56:12 Info D. Date 08/21/2006 Defaults set! B. Motherboard Device Configuration M. Memory an Cache Optimization C.

  • Page 453: Save Values Without Exit

    Software • Power Panel 300 with BIOS 1.3.12 Save values without exit XpressROM Setup F1/ALT+H:Show Help ESC:Exit ALT+Q:Go to Main Menu ENTER:Select +/-:Choice Main Menu T. Time 21:56:12 Info D. Date 08/21/2006 Settings Saved! B. Motherboard Device Configuration M. Memory an Cache Optimization C.

  • Page 454: Exit Without Save

    Software • Power Panel 300 with BIOS 1.3.13 Exit without save XpressROM Setup F1/ALT+H:Show Help ESC:Exit ALT+Q:Go to Main Menu ENTER:Select +/-:Choice Main Menu Exit Without Save T. Time 21:56:12 D. Date 08/21/2006 Are you sure you want to exit without Saving? B.

  • Page 455: Save Values And Exit

    Software • Power Panel 300 with BIOS 1.3.14 Save values and exit XpressROM Setup F1/ALT+H:Show Help ESC:Exit ALT+Q:Go to Main Menu ENTER:Select +/-:Choice Main Menu Save Values and Exit T. Time 21:56:12 D. Date 08/21/2006 Are you sure you want to save all values and exit? B.

  • Page 456: Bios Settings For Qvga Power Panel Devices

    Software • Power Panel 300 with BIOS 1.4 BIOS settings for QVGA Power Panel devices Information: The BIOS default values can be found in the section 1.5 "BIOS default values" on page 477. 1.4.1 Main menu Immediately after the DEL button is pressed during startup, the main BIOS setup menu appears.

  • Page 457: Time

    Software • Power Panel 300 with BIOS Shortcut BIOS setup menu Function Load defaults Load the optimal BIOS settings for best performance. Save values without exit Saves BIOS values without exiting BIOS setup. Exit without save Exits BIOS setup without saving any changes.

  • Page 458: Date

    Software • Power Panel 300 with BIOS 1.4.3 Date XpressROM Setup Main Menu T. Time 12:30:25 >> D. Date 04/19/2007 B. Motherboard Device Configuration M. Memory and Cache Optimization C. System Clock/PLL Configuration P. Power Management I. Device Information H. Micellaneous Configuration O.

  • Page 459: Motherboard Device Configuration

    Software • Power Panel 300 with BIOS 1.4.4 Motherboard device configuration XpressROM Setup Motherboard Device Configuration >>A. Drive Configuration B. I/O Configuration F. Video and Flat Panel G. PCI Configuration U. USB Configuration T. Thermal Configuration R. Return to Main Menu...
  • Page 460 Software • Power Panel 300 with BIOS Motherboard device configuration - drive configuration XpressROM Setup Drive Configuration IDE Configuration IDE BIOS Support: Enabled DMA/UDMA BIOS Support: Enabled >>Force mode for CF Card: Auto Boot Support Configuration Floppy BIOS Support: Enabled...
  • Page 461 Software • Power Panel 300 with BIOS Motherboard device configuration - I/O configuration XpressROM Setup I/O Configuration Serial Port Configuration >>COM A: Disabled COM C: 0x3f8 IRQ COM D: 0x2f8 IRQ Configure the 1st on-board UART. Figure 295: Motherboard device configuration - I/O configuration...
  • Page 462 Software • Power Panel 300 with BIOS BIOS setting Meaning Setting options Effect COM D Configures the UART address range and Disabled No assignment. The touch screen is disabled and the corresponding interrupt for the touch does not function. controller.
  • Page 463 Software • Power Panel 300 with BIOS BIOS setting Meaning Setting options Effect Contrast Setting for the contrast of the display. Auto The optimal contrast is automatically configured using the factory settings. A contrast value Information: between 100% and 0% is set.
  • Page 464 Software • Power Panel 300 with BIOS BIOS setting Meaning Setting options Effect PCI INTC# Disabled No IRQ is reserved. Activates IRQ for aPCI slot 2. First IRQ for aPCI slot 2 and IRQ for 3, 4, 5, 6, 7, 9, 10, 11, 12, Manual configuration of the IRQ.
  • Page 465 Software • Power Panel 300 with BIOS BIOS setting Meaning Setting options Effect Overcurrent This function enables an automatic Enabled Enables this function. reporting message Disabled Disables this function. This function enables an automatic error message to be sent to the system when the USB hub is overloaded (e.g.

  • Page 466: Memory And Cache Optimization

    Software • Power Panel 300 with BIOS 1.4.5 Memory and cache optimization Warning! The parameters in this screen are for system designers, service personnel, and technically competent users only. Only modify those settings that you completely understand. Incorrectly setting "Memory optimization" values can cause instability and even cause the entire system not to boot.

  • Page 467: System Clock/Pll Configuration

    Software • Power Panel 300 with BIOS BIOS setting Meaning Setting options Effect Refresh rate The refresh cycle can be set here. Auto Value selected automatically. 15μs, 3μs, 7μs, 31μs, Manually setting the value. Information: 62μs or 125μs Enter the clock frequency, the chipset does the rest.

  • Page 468: Power Management

    Software • Power Panel 300 with BIOS 1.4.7 Power management XpressROM Setup Power Management >>BIOS PM at Boot: Disabled APM Available: ACPI Available: S1 Clocks: CPU Clock Gating: Enabled Chipset Clock Gating: Enabled Power Button Configuration Power Button: ACPI Mode...

  • Page 469: Device Information

    Software • Power Panel 300 with BIOS 1.4.8 Device information XpressROM Setup Device Information Version MTCX FPGA: V1.00 MTCX PX32: V1.14 MTCX KCF : V0.00 BIOS: V1.14 Fact: V2.01 Switches Mode/Node: 02h Factory Settings Device ID: 000023BA Comp. ID: 0000...

  • Page 470: Miscellaneous Configuration

    Software • Power Panel 300 with BIOS BIOS setting Meaning Setting options Effect The MAC address of the Ethernet None interface is displayed here. Table 164: BIOS device information menu (Forts.) 1.4.9 Miscellaneous configuration XpressROM Setup Miscellaneous Boot Logo Configuration >>Boot Logo:...
  • Page 471 Software • Power Panel 300 with BIOS BIOS setting Meaning Setting options Effect Summary timeout Defines how long the summary screen is No waiting. displayed. 1-65535 [milliseconds] The manually set value in milliseconds that must pass before the boot process Information: continues.

  • Page 472: Boot Order

    Software • Power Panel 300 with BIOS 1.4.10 Boot order XpressROM Setup Boot Order Boot Order Configuration >>1. USB Floppy Disk 2. USB CD-ROM Drive 3. Hard Drive 4. USB Hard/Flash Drv. CF Card Info Model:No CF Card Cap.: Phy.: Log.:...
  • Page 473 Software • Power Panel 300 with BIOS BIOS setting Meaning Setting options Effect Boot order Configures the order in which memory USB floppy disk The device attempts to boot from this drive first. configuration media is booted. USB CD-ROM If two identical devices are selected, a drive conflict warning is displayed.

  • Page 474: Load Defaults

    Software • Power Panel 300 with BIOS 1.4.11 Load defaults XpressROM Setup Main Menu T. Time 00:02:56 D. Date 03/12/2007 B. Motherboard Device Configuration M. Memory and Cache Optimization C. System Clock/PLL Configuration Info Defaults set! Hit any key to continue S.

  • Page 475: Save Values Without Exit

    Software • Power Panel 300 with BIOS 1.4.12 Save values without exit XpressROM Setup Main Menu T. Time 00:02:56 D. Date 03/12/2007 B. Motherboard Device Configuration M. Memory and Cache Optimization C. System Clock/PLL Configuration Info Settings Saved! Hit any key to continue >>S.

  • Page 476: Save Values And Exit

    Software • Power Panel 300 with BIOS Information: If using a German keyboard, press the "z" key to enter "y". 1.4.14 Save values and exit XpressROM Setup Main Menu T. Time 00:02:56 Save Values and Exit Are you sure you want to save all values and exit? >>No...

  • Page 477: Bios Default Values

    Software • Power Panel 300 with BIOS 1.5 BIOS default values The BIOS default values are the BIOS settings that were already configured when the PPC300 was delivered. The BIOS default values are identical in all variants (QVGA, VGA, SVGA and XGA).

  • Page 478: Memory And Cache Optimization

    Software • Power Panel 300 with BIOS Drive configuration Default value Battery Table 167: Motherboard device configuration default values (Forts.) 1.5.2 Memory and cache optimization Setting Default value Cache mode Write back Cache allocate Disabled Refresh rate Auto Table 168: Memory and cache optimization default values 1.5.3 System clock/PLL configuration...

  • Page 479: Miscellaneous Configuration

    Software • Power Panel 300 with BIOS 1.5.6 Miscellaneous configuration Setting Default value Boot logo Enabled Clear boot logo Enabled Boot logo timeout 00000 Summary screen Enabled Summary screen timeout 00000 AC beeper Enabled Password None Table 171: Miscellaneous configuration default values 1.5.7 Boot order...

  • Page 480: Software Updates

    Software • Power Panel 300 with BIOS 1.6 Software updates The following Power Panel device software and firmware can be updated: • BIOS (see page 488) • MTCX firmware (see page 491) • aPCI firmware (see page 493) • User Boot Logo (see page 494) Current software can be downloaded directly from the service portal on the B&R homepage...

  • Page 481: Distribution Of Resources

    Software • Power Panel 300 with BIOS 1.8 Distribution of resources 1.8.1 RAM address assignment RAM address Resource 00000000 - 000003FF Interrupt vectors 00000400 - 000004FF BIOS data area 00000500 - 0009FBFF Freely available for the operating system (MS-DOS program area)

  • Page 482: I/O Address Assignment

    Software • Power Panel 300 with BIOS 1.8.3 I/O address assignment I/O address Resource 0000 - 000F DMA controller channels 0-3 0020 - 0021 Master programmable interrupt controller 0022 - 0023 CPU configuration registers 0040 - 0043 Programmable interval timer...

  • Page 483: Interrupt Assignment

    Software • Power Panel 300 with BIOS 1.8.4 Interrupt assignment Interrupt Resource IRQ 0 System timer IRQ 1 Keyboard (Legacy USB emulation) IRQ 2 2nd PIC IRQ cascade IRQ 3 COM2 IRQ 4 COM1 IRQ 5 PCI configuration space IRQ 6...

  • Page 484: Power Panel 300/400 With Automation Runtime

    An extensive project can be divided into small individual tasks. This way of working increases modularity and makes it much easier to maintain projects. 2.1.1 Summary screen When switching on a Power Panel 300/400 device, a summary screen displays the most important parameters of an Automation Runtime Power Panel device: 4PP420.1043-75 PX32: V01.11...

  • Page 485: Control And Visualization With The Power Panel 300 Device

    Software • Power Panel 300/400 with Automation Runtime 2.2 Control and visualization with the Power Panel 300 device The visualization project runs on the Power Panel 300. Serial RS232 or Ethernet TCP/IP provides the communication to the controller system. Flexible programming with frame drivers or Ethernet socket services allows a connection to be made to any control system.

  • Page 486: Power Panel 400 With Power Panel 300 Terminals

    Remote I/O systems ACOPOS ACOPOS Drive technology Figure 312: Power Panel 400 with, e.g. Power Panel 300 terminals A CompactFlash is required in the Power Panel 300 and Power Panel 400 terminal devices. Power Panel 300/400 User's Manual V 2.30...

  • Page 487: Software Updates

    Software • Power Panel 300/400 with Automation Runtime 2.4 Software updates The following Power Panel Automation Runtime device software and firmware can be updated: • BIOS (see page 488) • MTCX firmware (see page 491) Current software can be downloaded directly from the service portal on the B&R homepage (www.br-automation.com).

  • Page 488: Upgrade Information

    A current BIOS upgrade can be downloaded directly from the service portal on the B&R homepage (www.br-automation.com). 3.1.1 What information do I need? Information: Individually saved BIOS settings are deleted when upgrading the BIOS. Power Panel 300/400 User's Manual V 2.30...

  • Page 489: Procedure

    Power Panel device when booting from a diskette. • The following start menu will be shown after booting. Microsoft Windows Startup Menu =================================== 1. Update BIOS 2. Save BIOS 3. Exit Enter a choice:_ Figure 313: BIOS upgrade start menu Power Panel 300/400 User's Manual V 2.30...
  • Page 490 If you do not press a button within 5 seconds, then step 1 "Update BIOS" is automatically carried out and the Power Panel is automatically updated. • The system must be rebooted after a successful upgrade. Power Panel 300/400 User's Manual V 2.30...

  • Page 491: Mtcx Firmware Upgrade (Mtcx Fpga, Mtcx Px32)

    A boot menu with the following options is displayed after booting: Microsoft Windows Startup Menu =================================== 1. Upgrade MTCX Firmware FPGA and PX32 (PC3F/PC3P) 2. Exit Enter a choice:_ Figure 314: MTCX upgrade start menu Power Panel 300/400 User's Manual V 2.30...
  • Page 492 WITHOUT restarting the Power Panel, e.g. by starting the batch file UPDMTCX.BAT directly. Concerning point 2: Return to the shell (MS-DOS). • Select the desired action. • Remove the bootable media and reboot the device (only after a successful update!). Power Panel 300/400 User's Manual V 2.30...

  • Page 493: Apci Firmware Upgrade Disk

    "Motherboard device configuration - drive configuration" on page 437 for Power Panel devices for the necessary settings for the Power Panel device when booting from a diskette. • The following start menu will be shown after booting: Power Panel 300/400 User's Manual V 2.30...

  • Page 494: User Boot Logo Upgrade Disk

    The system must be rebooted after a successful upgrade. 3.4 User boot logo upgrade disk A software tool for updating, backing up, or deleting the user boot logo can be downloaded directly from the service portal of the B&R homepage (www.br-automation.com). Power Panel 300/400 User's Manual V 2.30...

  • Page 495: Procedure

    The user boot logo is automatically updated with the file USERLOGO.ROM (default after 5 seconds). Update BIOS default boot logo The BIOS default boot logo for the device is automatically updated with the correct resolution. Table 180: User boot logo upgrade menu description Power Panel 300/400 User's Manual V 2.30...

  • Page 496: Guidelines For Creating A User Boot Logo

    192 KB. If this size is exceeded, a warning appears. The user can e.g. reduce the details in the Windows bitmap in order not to exceed the maximum byte size. 5) After this, the userlogo.rom file should be copied to the disk. Power Panel 300/400 User's Manual V 2.30...

  • Page 497: Creating A Dos Boot Diskette In Windows Xp

    Then select the checkbox "Create an MS-DOS startup disk", press "Start" and acknowledge the warning message with "OK". Figure 318: Creating a bootable diskette in Windows XP - step 2 Figure 319: Creating a bootable diskette in Windows XP - step 3 Power Panel 300/400 User's Manual V 2.30...
  • Page 498 Figure 320: Creating a bootable diskette in Windows XP - step 4 Figure 321: Creating a bootable diskette in Windows XP - step 5 Now all files (marked) except Command.com, IO.sys and MSDOS.sys can be deleted. Power Panel 300/400 User's Manual V 2.30...

  • Page 499: Creating A Bootable Usb Flash Drive For B&R Upgrade Files

    In the B&R Upgrade text box, it's also possible to enter the path to the ZIP file for the B&R Upgrade Disk and select the file. • Click on the Start action button in the toolbar. Power Panel 300/400 User's Manual V 2.30...

  • Page 500: Where Do I Get Ms-Dos

    Information concerning creating an MS-DOS boot diskette can be found in section 3.5 "Creating a DOS boot diskette in Windows XP" on page 497. Then the files from the diskette are to be copied to your hard drive. Power Panel 300/400 User's Manual V 2.30...

  • Page 501: Creating A Bootable Compactflash Card For B&R Upgrade Files

    In the B&R Upgrade text box, it's also possible to enter the path to the ZIP file for the B&R Upgrade Disk and select the file. • Click on the Start action button in the toolbar. Power Panel 300/400 User's Manual V 2.30...

  • Page 502: Where Do I Get Ms-Dos

    Information concerning creating an MS-DOS boot diskette can be found in section 3.5 "Creating a DOS boot diskette in Windows XP" on page 497. Then the files from the diskette are to be copied to your hard drive. Power Panel 300/400 User's Manual V 2.30...

  • Page 503: Power Panel With Windows Ce

    This makes this operating system extremely robust and stable. A further advantage of B&R Windows CE compared to other operating systems are the low licensing costs. Power Panel 300/400 User's Manual V 2.30...

  • Page 504: Windows Ce 5.0 Features

    Table 182: Windows CE 5.0 features 1) The color depth depends on the display used. 2) Use the function "Compress Windows CE Image" in the B&R Embedded OS Installer to reduce the image size. Power Panel 300/400 User's Manual V 2.30...

  • Page 505: Windows Ce 6.0 Features

    4.4 Differences between Windows CE 6.0 and Windows CE 5.0 • 2 GB of virtual RAM per process (Windows CE 5.0: 32 MB). • Simultaneous operation of up to 32,000 processes (Windows CE 5.0: 32 processes). Power Panel 300/400 User's Manual V 2.30...

  • Page 506: Requirements

    B&R Windows CE installation. The B&R Embedded OS Installer can be downloaded from the download area on the B&R homepage (www.br-automation.com). Further information is available in the online help for the B&R Embedded OS Installer. Power Panel 300/400 User's Manual V 2.30...

  • Page 507: Power Panel With Windows Xp Embedded

    Present ✓ Enhanced write filter (EWF) ✓ File Based Write Filter Page file configurable ✓ Administrator account User account configurable ✓ Explorer shell Table 185: Device functions in Windows XP Embedded with FP2007 Power Panel 300/400 User's Manual V 2.30...

  • Page 508: Installation

    Brief instructions for creating your own Windows XP Embedded images or a suitable Target Designer export file can be downloaded from the download area on the B&R homepage (www.br-automation.com). Power Panel 300/400 User's Manual V 2.30...

  • Page 509: Power Panel With Windows Embedded Standard 2009

    Short description Note Windows Embedded Standard 2009 PP300 LX800 5SWWXP.0721-ENG Microsoft OEM Windows embedded Standard 2009, English; for Power Panel 300; please or- der CompactFlash separately (minimum 1 GB). 5SWWXP.0722-ENG Windows Embedded Standard 2009 PP400 LX800 Microsoft OEM Windows embedded Standard 2009, English; for Power Panel 400; please or- der CompactFlash separately (minimum 1 GB).

  • Page 510: Features With Wes2009 (Windows Embedded Standard 2009)

    Disk Management Service ✓ Windows Installer Service ✓ Class Installer ✓ CoDevice Installer ✓ Media Player 6.4 ✓ DirectX 9.0c ✓ Accessories Number of fonts Table 187: Device functions in Windows Embedded Standard 2009 Power Panel 300/400 User's Manual V 2.30...

  • Page 511: Installation

    B&R homepage (www.br-automation.com). A potentially activated "Enhanced Write Filter (EWF)" must be taken into consideration. Information: Required drivers can only be downloaded from the B&R homepage, not from manufacturers' pages. Power Panel 300/400 User's Manual V 2.30...

  • Page 512: Vesa Mode Support

    1600 x 1200 x 24 135h 1920 x 1440 x 8 136h 1920 x 1440 x 15 137h 1920 x 1440 x 16 138h 1920 x 1440 x 24 Table 188: Setting options - VESA mode Power Panel 300/400 User's Manual V 2.30...

  • Page 513: B&R Automation Device Interface (Adi) Driver - Control Center

    These cannot be used to draw any conclusions about any hardware alarms or error conditions. The hardware components used have automatic diagnostics functions that can be applied in the event of error. Power Panel 300/400 User's Manual V 2.30...

  • Page 514: Functions

    Content of B&R Windows XP Embedded image Panel PC 700 Windows CE Content of B&R Windows CE image Windows Embedded Standard 2009 Content of B&R Windows Embedded Standard 2009 image Table 189: System support - ADI driver Power Panel 300/400 User's Manual V 2.30...
  • Page 515 A detailed description of the Control Center can be found in the integrated online help. The B&R Automation Device Interface (ADI) driver (also contains Control Center) can be downloaded for free from the download area on the B&R homepage (www.br- automation.com). Power Panel 300/400 User's Manual V 2.30...

  • Page 516: Installation

    If a more current ADI driver version exists (see the B&R homepage download area), it can be installed later. A potentially activated "Enhanced Write Filter (EWF)" must be taken into consideration when installing. Power Panel 300/400 User's Manual V 2.30...

  • Page 517: Chapter 5: Standards And Certifications

    • Low-voltage guidelines 2006/95/EG • Machine guidelines 98/37/EG beginning 12/29/2009: 2006/42/EG 2. Overview of standards The Power Panel 300/400 devices collectively meet the following standards: Standard Description EN 55011 Electromagnetic compatibility (EMC), radio disturbance product standard, industrial, scientific, and Class A, B medical high-frequency devices (ISM devices), limit values and measurement procedure;...
  • Page 518 UL protection against sprayed water UL 508 Industrial control equipment (UL = Underwriters Laboratories) 47 CFR Federal Communications Commission (FCC), 47 CFR Part 15 Subpart B Class A Table 190: Overview of standards (Forts.) Power Panel 300/400 User's Manual V 2.30...

  • Page 519: Emission Requirements

    Other connections 87 dB (µV) and 43 dB (µA) 500 kHz - 30 MHz Quasi-peak value 74 dB (µV) and 30 dB (µA) Average Table 192: Test requirements - Network-related emissions for industrial areas Power Panel 300/400 User's Manual V 2.30...

  • Page 520: Emissions, Electromagnetic Emissions

    10 m Quasi-peak value >960 MHz < 300 dB (µV/m) measured at a distance of 10 m Quasi-peak value Table 193: Test requirements - Electromagnetic emissions for industrial areas Power Panel 300/400 User's Manual V 2.30...

  • Page 521: Requirements For Immunity To Disturbances

    Criteria C: A temporary function failure is permitted when the function restores itself, or the function can be restored by activating configuration and control elements. Power Panel 300/400 User's Manual V 2.30...

  • Page 522: Electrostatic Discharge (Esd)

    1 kHz, length 3 seconds, seconds, criteria A criteria A 800-960 MHz (GSM), 10 V/m, pulse modulation with 50% duty cycle, criteria A Table 196: Test requirements - High-frequency electromagnetic fields (HF field) Power Panel 300/400 User's Manual V 2.30...

  • Page 523: High-Speed Transient Electrical Disturbances (Burst)

    1 kHz, amplitude modulation with 1 kHz, amplitude modulation with 1 kHz, length 3 seconds, criteria A length 3 seconds, criteria A criteria A Table 199: Test requirements - Conducted disturbances Power Panel 300/400 User's Manual V 2.30...

  • Page 524: Magnetic Fields With Electrical Frequencies

    AC power inputs 20 interruptions, 0.5 periods, criteria A DC power inputs 20 interruptions for 10 ms < UN - 15%, criteria A Table 201: Test requirements - Voltage dips, fluctuations, and short-term interruptions Power Panel 300/400 User's Manual V 2.30...

  • Page 525: Damped Vibration

    2 m, criteria B Power I/O, L to PE ±2.5 kV, 1 MHz, repeat rate 400/seconds, length 2 seconds, connection lengths 2 m, criteria B Table 202: Test requirements - Damped vibration Power Panel 300/400 User's Manual V 2.30...

  • Page 526: Mechanical Conditions

    5 - 9 Hz Amplitude 2 - 9 Hz Amplitude 3.5 mm 3 mm 9 - 150 Hz Acceleration 9 - 200 Hz Acceleration Table 204: Test requirements - Vibration during operation Power Panel 300/400 User's Manual V 2.30...

  • Page 527: Vibration During Transport (Packaged)

    Required Weight Required <20 kg <20 kg <20 kg 20 - 100 kg 20 - 100 kg 20 - 100 kg >100 kg >100 kg >100 kg Table 208: Test requirements - Toppling Power Panel 300/400 User's Manual V 2.30...

  • Page 528: Free Fall (Packaged)

    Weight Height <10 kg 0.3 m 10 - 40 kg 0.3 m >40 kg 0.25 m Limits according to B&R Devices packaged Weight Height <40 kg Table 209: Test requirements - Toppling Power Panel 300/400 User's Manual V 2.30...

  • Page 529: Climate Conditions

    Limits according to EN 60068-2-1 EN 61131-2 Dry cold 16 hours at -40°C for 1 cycle, then 1 hour acclimatization and function testing, duration approximately 17 hours Table 213: Test requirements - Dry cold Power Panel 300/400 User's Manual V 2.30...

  • Page 530: Large Temperature Fluctuations

    EN 60068-2-3 EN 61131-2 Humid heat, constant (storage) 48 hours at +40°C and 92.5% RH, then insulation test within 3 hours, duration approximately 49 hours Table 217: Test requirements - Humid heat, constant (storage) Power Panel 300/400 User's Manual V 2.30...

  • Page 531: Sprayed Water (Front Side)

    Spraying using a 25.4 mm (diameter) water jet nozzle Distance: 3 to 3.7 meters (all angles) Water flow: 246 liters/minute Duration: 48 seconds, 5 seconds minimum Table 218: Test requirements - Sprayed water (front side) Power Panel 300/400 User's Manual V 2.30...

  • Page 532: Safety

    Limits according to EN 60204-1 Insulation resistance: main circuits >1 MΩ at 500 V DC voltage to protective ground conductor Table 221: Test requirements - Insulation resistance 1) See EN 60204-1:1997 page 62, table 9. Power Panel 300/400 User's Manual V 2.30...

  • Page 533: High Voltage

    24 VDC -15% 48 VDC +20% 125 VDC 24 VAC 48 VAC 100 VAC 110 VAC 120 VAC +10% 200 VAC 230 VAC 240 VAC 400 VAC Table 223: Test requirements - Voltage range Power Panel 300/400 User's Manual V 2.30...

  • Page 534: Other Tests

    Protection against touching Protection against touching dangerous parts with finger dangerous parts with conductor Protection against water IP.0 IP.5 permeation with damaging Not protected Protected against sprayed water consequences Table 225: Test requirements - Protection Power Panel 300/400 User's Manual V 2.30...

  • Page 535: International Certifications

    This mark is valid for the USA and Canada and simplifies certification of your machines and systems in these areas. Europe All harmonized EN standards for the applicable guidelines are met. Table 226: International certifications Power Panel 300/400 User's Manual V 2.30...
  • Page 536 Standards and certifications • International certifications Power Panel 300/400 User's Manual V 2.30...

  • Page 537: Chapter 6: Accessories

    CompactFlash card with 16 GB SLC NAND flash and IDE/ATA interface 5CFCRD.0064-03 CompactFlash 64 MB SSI CompactFlash card with 64 MB SLC NAND flash and IDE/ATA interface Table 227: Model numbers - Accessories Power Panel 300/400 User's Manual V 2.30...
  • Page 538 9A0017.02 RS232 DB9 null modem cable 1.8 m Null modem cable RS232 1.8 m to connect UPS and IPC (9-pin DSUB socket - 9-pin DSUB socket) Table 227: Model numbers - Accessories Power Panel 300/400 User's Manual V 2.30...

  • Page 539: Replacement Cmos Batteries

    Self discharge at +23°C < 1% per year Storage time Max. 3 years at +30°C Environmental characteristics Storage temperature -20 to +60°C Relative humidity 0 to 95%, non-condensing Table 229: Technical data - Lithium batteries Power Panel 300/400 User's Manual V 2.30...

  • Page 540: Contents Of Delivery

    Accessories • Replacement CMOS batteries 2.3 Contents of delivery Amount Component 1 or 4 Lithium batteries Table 230: Contents of delivery - Lithium batteries Power Panel 300/400 User's Manual V 2.30...

  • Page 541: Tb103 3-Pin Supply Voltage Connector

    Model number Description Figure 0TB103.9 Plug for the 24 V supply voltage (screw clamps) 0TB103.91 Plug for the 24 V supply voltage (cage clamps) 0TB103.9 0TB103.91 Table 231: Order data - TB103 supply plug Power Panel 300/400 User's Manual V 2.30...

  • Page 542: Technical Data

    Copper wires only (no aluminum wires!) Table 232: Technical data - TB103 supply plug 3.4 Contents of delivery Amount Component Supply plug in desired design. Table 233: Contents of delivery - TB103 supply plug Power Panel 300/400 User's Manual V 2.30...

  • Page 543: Legend Strip Templates

    -40 to +125°C. A print template (available for Corel Draw version 7, 9 and 10) for the respective legend strip template can be downloaded from the B&R homepage www.br-automation.com. Power Panel 300/400 User's Manual V 2.30...

  • Page 544: Order Data

    Legend strip template for Power Panel 4PP481.1505-75 and 4PP480.1505-75. For 4 devices. NEL EINSCHUBSTREIFENVORDRUCK PASSEND FÜR Identnummer: C0030768 Format: A4 NEL KEY TEMPLATE FOR 1-65 Table 234: Order data - Legend strip templates Power Panel 300/400 User's Manual V 2.30...

  • Page 545: Compactflash Cards 5Cfcrd.xxxx-04

    5CFCRD.2048-04 2048 MB B&R CompactFlash card 5CFCRD.4096-04 4096 MB B&R CompactFlash card 5CFCRD.8192-04 8192 MB B&R CompactFlash card 5CFCRD.016G-04 16 GB B&R CompactFlash card CompactFlash card Table 235: Order data - CompactFlash cards Power Panel 300/400 User's Manual V 2.30...

  • Page 546: Technical Data

    54.79 GB/day 109.59 GB/day 219.18 GB/day 438.36 GB/day 876.72 GB/day Clear/write cycles Guaranteed 100,000 Typical 2,000,000 SLC flash Wear leveling Static Error Correction Coding (ECC) Table 236: Technical data - CompactFlash cards 5CFCRD.xxxx-04 Power Panel 300/400 User's Manual V 2.30...
  • Page 547 2) The file is written/read sequentially in True IDE mode with the DOS program Thruput.exe. 3) Endurance of B&R CF cards (linear written block size with 128 kB) 4) Depending on the average file size. 5) Not supported by B&R Embedded OS installer. Power Panel 300/400 User's Manual V 2.30...

  • Page 548: Temperature Humidity Diagram - Operation And Storage

    Figure 329: Temperature humidity diagram - CompactFlash cards 5CFCRD.xxxx-04 5.4 Dimensions 1.01 ±0.07 1.01 ±0.07 3.30 ±0.1 CompactFlash type I 2.44 ±0.07 1.65 0.63 ±0.07 41.66 ±0.13 4 x R0.5 ±0.1 42.8 ±0.1 Figure 330: Dimensions - CompactFlash card Type I Power Panel 300/400 User's Manual V 2.30...

  • Page 549: Benchmark

    5CFCRD.0512-04 5CFCRD.4096-04 5CFCRD.016G-04 5CFCRD.0512-03 5CFCRD.4096-03 Figure 331: ATTO disk benchmark v2.34 comparison (reading) 1024 2048 4096 8192 Transfer size [kb] 5CFCRD.0512-04 5CFCRD.4096-04 5CFCRD.016G-04 5CFCRD.0512-03 5CFCRD.4096-03 Figure 332: ATTO disk benchmark v2.34 comparison (writing) Power Panel 300/400 User's Manual V 2.30...

  • Page 550: Compactflash Cards 5Cfcrd.xxxx-03

    CompactFlash 512 MB SSI 5CFCRD.1024-03 CompactFlash 1024 MB SSI 5CFCRD.2048-03 CompactFlash 2048 MB SSI 5CFCRD.4096-03 CompactFlash 4096 MB SSI 5CFCRD.8192-03 CompactFlash 8192 MB SSI CompactFlash card Table 237: Order data - CompactFlash cards Power Panel 300/400 User's Manual V 2.30...

  • Page 551: Technical Data

    MP100/200, PP100/200, PP300/400, PPC700, PPC300, Provit 2000, Provit 5000, APC620, APC680, APC810, APC820 Windows XP Professional Windows XP Embedded Windows CE 6.0 Windows CE 5.0 Table 238: Technical data - CompactFlash cards 5CFCRD.xxxx-03 Power Panel 300/400 User's Manual V 2.30...

  • Page 552: Temperature Humidity Diagram - Operation And Storage

    Table 238: Technical data - CompactFlash cards 5CFCRD.xxxx-03 (Forts.) 1) Not supported by B&R Embedded OS installer. 6.3.1 Temperature humidity diagram - Operation and storage Storage Operation Transport Temperature [°C] Figure 333: Temperature humidity diagram - CompactFlash cards 5CFCRD.xxxx-03 Power Panel 300/400 User's Manual V 2.30...

  • Page 553: Dimensions

    Accessories • CompactFlash cards 5CFCRD.xxxx-03 6.4 Dimensions 1.01 ±0.07 1.01 ±0.07 3.30 ±0.1 CompactFlash type I 2.44 ±0.07 1.65 0.63 ±0.07 41.66 ±0.13 4 x R0.5 ±0.1 42.8 ±0.1 Figure 334: Dimensions - CompactFlash card Type I Power Panel 300/400 User's Manual V 2.30...

  • Page 554: Usb Flash Drive

    7.2 Order data Model number Description Figure 5MMUSB.2048-00 USB flash drive 2 GB SanDisk Cruzer Micro 5MMUSB.2048-01 USB flash drive 2 GB B&R Table 239: Order data - USB flash drives Power Panel 300/400 User's Manual V 2.30...

  • Page 555: Technical Data 5Mmusb.2048-00

    2 g (10 to 500 Hz), oscillation rate 1/minute Bearings 4 g (10 to 500 Hz), oscillation rate 1/minute Transport 4 g (10 to 500 Hz), oscillation rate 1/minute Table 240: Technical data - USB flash drive 5MMUSB.2048-00 Power Panel 300/400 User's Manual V 2.30...

  • Page 556: Temperature Humidity Diagram - Operation And Storage

    12,192 meters Table 240: Technical data - USB flash drive 5MMUSB.2048-00 (Forts.) 7.3.1 Temperature humidity diagram - Operation and storage Operation Temperature [°C] Figure 335: Temperature humidity diagram - USB flash drive - 5MMUSB.2048-00 Power Panel 300/400 User's Manual V 2.30...

  • Page 557: Technical Data 5Mmusb.2048-01

    20 - 2000 Hz: 20 g (peak) Shock Operation Max. 1500 g (peak) Bearings Max. 1500 g (peak) Transport Max. 1500 g (peak) Table 241: Technical data - USB flash drive 5MMUSB.2048-01 Power Panel 300/400 User's Manual V 2.30...

  • Page 558: Temperature Humidity Diagram

    12,192 meters Transport 12,192 meters Table 241: Technical data - USB flash drive 5MMUSB.2048-01 (Forts.) 7.4.1 Temperature humidity diagram Betrieb Temperatur [°C] Figure 336: Temperature humidity diagram - USB flash drive - 5MMUSB.2048-01 Power Panel 300/400 User's Manual V 2.30...

  • Page 559: Null Modem Cable 9A0017.0X

    Max. 5 mm Shielding Entire cable Connector type 2 9-pin DSUB sockets - female Wire cross section AWG 22, Flexibility Flexible Flex radius Min. 100 mm Table 243: Technical data - Null modem cable Power Panel 300/400 User's Manual V 2.30...

  • Page 560: Cable Specifications

    Accessories • Null modem cable 9A0017.0x 8.3 Cable specifications DSUB (9-pin), male DSUB (9-pin), female Pin assignments DSUB (9-pin), female DSUB (9-pin), female Shield Shield Figure 338: Pin assignments - null modem cable Power Panel 300/400 User's Manual V 2.30...

  • Page 561: Chapter 7: Maintenance / Servicing

    Power Panel device! Never use aggressive solvents, chemicals, scouring agents, pressurized air or steam jet. Information: Displays with touch screens should be cleaned at regular intervals. Power Panel 300/400 User's Manual V 2.30...

  • Page 562: Changing The Battery

    Touch the housing or ground connection (not the power supply!) in order to discharge any electrostatic charge from your body. • Remove the battery cover: The battery cover is found on the rear side of the Power Panel device. Power Panel 300/400 User's Manual V 2.30...
  • Page 563 • Reconnect the power supply to the Power Panel. • The data and time in BIOS may have to be set again (see section "Power Panel 300 with BIOS" on page 429). Warning! Lithium batteries are considered hazardous waste. Used batteries should be disposed of accordingly.

  • Page 564: Preventing After-Image Effect In Lcd/Tft Monitors

    Use screen savers (moving) when the display is not in use • Frequent picture change • Shut off the display when not in use Turning off the background lighting (backlight) does not influence the prevention of the after- image effect. Power Panel 300/400 User's Manual V 2.30...

  • Page 565: Touch Screen

    Finger, pointer, credit card, glove Table 246: Technical data - Elo Accu touch screen 5-wire 1) The active area of the touch screen is resistant to these chemicals for a timeframe of one hour at +21°C. Power Panel 300/400 User's Manual V 2.30...

  • Page 566: Temperature Humidity Diagram

    (ethanol). The cleaning agent should be applied to the cloth beforehand and not sprayed directly onto the touch screen itself. Never use aggressive solvents, chemicals, scouring agents, pressurized air or steam jet. Power Panel 300/400 User's Manual V 2.30...

  • Page 567: Gunze Touch

    Activation Finger, pencil Table 247: Technical data - Gunze touch screen pen 1) The active area of the touch screen is resistant to these chemicals for a timeframe of one hour at +21°C. Power Panel 300/400 User's Manual V 2.30...

  • Page 568: Temperature Humidity Diagram

    (ethanol). The cleaning agent should be applied to the cloth beforehand and not sprayed directly onto the touch screen itself. Never use aggressive solvents, chemicals, scouring agents, pressurized air or steam jet. Power Panel 300/400 User's Manual V 2.30...

  • Page 569: Décor Foil

    Sea water Decon Table 248: Chemical resistance of the décor foil The décor foil conforms to DIN 42115 section 2 for exposure to glacial acetic acid for less than one hour without visible damage. Power Panel 300/400 User's Manual V 2.30...

  • Page 570: Viewing Angles

    Appendix A • Viewing angles 3. Viewing angles The perspective information (R,L,U,D) can be seen in the technical data for the individual components. 6 o’clock direction Figure 342: Viewing angles Power Panel 300/400 User's Manual V 2.30...

  • Page 571: Mounting Compatibilities

    4. Mounting compatibilities This section describes the compatibility of the installation dimensions for the Power Panel 100/200, Power Panel 300/400, Automation Panel 900 and Panel PC 700 units according to the respective device diagonals. The outer dimensions of the device types are identical for the respective diagonals.
  • Page 572 ▲ Installation dimensions ■ ■ ■ ■ Outer dimensions ● ● ● ● Installation dimensions 15“ ■ ■ ■ ■ Outer dimensions ● ● ● ● Installation dimensions Table 250: Device compatibility overview Power Panel 300/400 User's Manual V 2.30...

  • Page 573: Compatibility Details

    Outer counter of device Cutout for device Figure 344: Mounting compatibility - 5.7" device format - Horizontal1 5.7" Power Panel 100/200 and Power Panel 300/400 devices in Horizontal1 format are 100% mounting compatible. Power Panel 300/400 User's Manual V 2.30...
  • Page 574 Outer contour of device Cutout for device Figure 345: Mounting compatibility - 5.7" device format - Horizontal2 5.7" Power Panel 100/200 and Power Panel 300/400 devices in Vertical1 format are 100% mounting compatible. 212 x 245 199 x 226.8 ± 0.5 PP100/200/300/400 11.7...

  • Page 575: Devices

    Outer contour of device Cutout for device Figure 347: Mounting compatibility - 10.4" device format - Horizontal1 10.4" Power Panel 100/200, Power Panel 300/400, Automation Panel 900 and Panel PC 700 devices in Horizontal1 format are 100% mounting compatible. 423 x 288 402 x 266,5 0.5...
  • Page 576 AP900/PPC700 device cutout Figure 349: Mounting compatibility - 10.4" device format - Vertical1 10.4" Power Panel 100/200 and Power Panel 300/400 are not 100% mounting compatible with the Vertical1 format for the Automation Panel 900 and Panel PC 700 devices. The Automation Panel 900 and Panel PC 700 devices require a cutout that is 5 mm larger vertically (lower edge).

  • Page 577: Devices

    12.1" Power Panel 100/200 and Power Panel 300/400 are not 100% mounting compatible with the Horizontal1 format for the Automation Panel 900 and Panel PC 700 devices. The Power Panel 100/200 and Power Panel 300/400 devices require a cut that is 1.5 mm wider (left and right).

  • Page 578: 15" Devices

    Outer contour of device Device cutout Figure 351: Mounting compatibility - 15" device format - Horizontal1 15" Power Panel 100/200, Power Panel 300/400, Automation Panel 900 and Panel PC 700 devices in Horizontal1 format are 100% mounting compatible. 435 x 430 415 x 412 ±...

  • Page 579: B&R Key Editor Information

    Assign functions to LEDs (HDD access, power, etc.) • 4 assignments per key possible (using layer function) • Configuration of panel locking time when multiple Automation Panel 900 devices are connected to Automation PC 620 and Panel PC 700 devices Power Panel 300/400 User's Manual V 2.30...
  • Page 580 The B&R Key Editor can be downloaded for free from the download area on the B&R homepage (www.br-automation.com). Additionally, it can also be found on the B&R HMI Drivers & Utilities DVD (model number 5SWHMI.0000-00). Power Panel 300/400 User's Manual V 2.30...

  • Page 581: B&R Automation Device Interface (Adi) Development Kit

    Visual C++ 4.0. • Help files for Visual Basic and Visual C++. • Sample projects for Visual Basic and Visual C++. • ADI DLL (for testing the applications, if no ADI drive is installed). Power Panel 300/400 User's Manual V 2.30...
  • Page 582 ADI functions can be found in the integrated online help. The B&R Automation Device Interface (ADI) development kit can be downloaded for free from the download area on the B&R homepage (www.br-automation.com). Power Panel 300/400 User's Manual V 2.30...

  • Page 583: Glossary

    Data format [1 byte = 8 bits] and a unit for characterizing information amounts and memory capacity. The following units are the commonly used units of progression: KB, MB, GB. B&R Automation Runtime Windows-based program for creating installation disks to install B&R Automation Runtime™ on the target system. Power Panel 300/400 User's Manual V 2.30...
  • Page 584 A device component which allows access to other devices on a computer subsystem. A disk controller, for example, allows access to hard disks and disk drives and is responsible both for physical and logic drive access. Power Panel 300/400 User's Manual V 2.30...
  • Page 585 An abbreviation for "Data Terminal Ready". A signal used in serial data transfer that is sent by the computer to the modem it is connected to, indicating the computer's readiness to accept incoming signals. Power Panel 300/400 User's Manual V 2.30...
  • Page 586 The first element inserted is the first one removed. Such an organization method is typical for a list of documents that are waiting to be printed. Power Panel 300/400 User's Manual V 2.30...
  • Page 587 Standardization > Worldwide federation national standardization institutions from over 130 countries. ISO is not an acronym for the name of the organization; it is derived from the Greek word "isos", meaning "equal" (www.iso.ch). Power Panel 300/400 User's Manual V 2.30...
  • Page 588 (POH). Multitasking Multitasking is an operating mode in an operating system that allows several computer tasks to be executed virtually simultaneously. Node Branching point in a network. Power Panel 300/400 User's Manual V 2.30...
  • Page 589 The term RAM refers to a more temporary memory that can be written to as well as read. An abbreviation for "Read-Only Memory". Semiconductor memory where programs or data were permanently stored during the production process. Power Panel 300/400 User's Manual V 2.30...
  • Page 590 Transmission Control Protocol/Internet Suit of Protocols. Network protocol that has become the generally accepted standard for data exchange in heterogeneous networks. TCP/IP is used both in local networks for communication between various computer and also for LAN to WAN access. Power Panel 300/400 User's Manual V 2.30...
  • Page 591 CD drives, printers, modems as well as the mouse and keyboard). This is done by connecting the devices in a row. USB allows devices to be changed when the power supply is switched on (hot plugging) and multi-layered data flow. Power Panel 300/400 User's Manual V 2.30...
  • Page 592 An abbreviation for "EXtended Graphics Array". An expanded standard for graphics controllers and monitors that was introduced by IBM in 1990. This standard supports 640x480 resolution with 65,536 colors or 1024x768 resolution with 256 colors. This standard is generally used in workstation systems. Power Panel 300/400 User's Manual V 2.30...
  • Page 593 Figure index Figure 1: Power Panel 300 and Power Panel 400 devices ........... 39 Figure 2: Different plug and key positions (PP100/200 - PP300/400) ......41 Figure 3: Supply voltage connection ................42 Figure 4: Functional grounding clip ................43 Figure 5: BIOS boot mode switch..................
  • Page 594 Dimensions - 4PP352.0571-35 ..............162 Figure 91: Cutout installation - 5PP352.0571-35............163 Figure 92: Front view - 4PP381.1043-31............... 164 Figure 93: Rear view - 4PP381.1043-31 ............... 164 Figure 94: Temperature humidity diagram - 4PP381.1043-31 ........168 Power Panel 300/400 User's Manual V 2.30...
  • Page 595 Temperature humidity diagram - 4PP420.0573-75 ........228 Figure 138: Dimensions - 4PP420.0573-75 ..............229 Figure 139: Cutout installation - 4PP420.0573-75............230 Figure 140: Front view - 4PP420.1043-75............... 231 Figure 141: Rear view - 4PP420.1043-75 ............... 231 Power Panel 300/400 User's Manual V 2.30...
  • Page 596 Cutout installation - 4PP451.0571-B5 ............293 Figure 185: Front view - 4PP451.1043-75............... 294 Figure 186: Rear view - 4PP451.1043-75 ............... 294 Figure 187: Temperature humidity diagram - 4PP451.1043-75 ........298 Figure 188: Dimensions - 4PP451.1043-75 ..............299 Power Panel 300/400 User's Manual V 2.30...
  • Page 597 Rear view - 4PP480.1505-B5............... 357 Figure 232: Temperature humidity diagram - 4PP480.1505-B5........361 Figure 233: Dimensions - 4PP480.1505-B5 ..............362 Figure 234: Cutout installation - 4PP480.1505-B5 ............363 Figure 235: Front view - 4PP481.1043-75............... 364 Power Panel 300/400 User's Manual V 2.30...
  • Page 598 Temperature humidity diagram - PP452 light..........413 Figure 262: Temperature humidity diagram - PP452 compact........417 Figure 263: Block diagram - Power Panel 300 ..............418 Figure 264: Block diagram - Power Panel 400 with 1 aPCI slot ........419 Figure 265: Block diagram - Power Panel 400 with 2 aPCI slots ........
  • Page 599 Save values and exit ..................476 Figure 310: Automation Runtime summary screen - ex. 4PP420.1043-75 ..... 484 Figure 311: Power Panel 300 as an intelligent visualization system ....... 485 Figure 312: Power Panel 400 with, e.g. Power Panel 300 terminals....... 486 Figure 313: BIOS upgrade start menu................
  • Page 600 Mounting compatibility - 15" device format - Horizontal1 ......578 Figure 352: Mounting compatibility - 15" device format - Vertical1 ......... 578 Figure 353: B&R Key Editor screenshots (Version 3.00) ..........579 Figure 354: ADI development kit screenshots (Version 2.40) ......... 581 Power Panel 300/400 User's Manual V 2.30...
  • Page 601 Environmentally-friendly separation of materials..........28 Table 3: Organization of safety notices ................29 Table 4: Model number overview - Power Panel 300 devices .......... 30 Table 5: Model number overview - Power Panel 300 devices .......... 31 Table 6: Model number overview - Power Panel 400 devices .......... 32 Table 7: Model number overview - Power Panel light / compact devices ......
  • Page 602 Contents of delivery - 4PP420.1505-B5 ............258 Table 91: Technical data - 4PP451.0571-45..............260 Table 92: Contents of delivery - 4PP451.0571-45 ............265 Table 93: Technical data - 4PP451.0571-65..............267 Table 94: Contents of delivery - 4PP451.0571-65 ............272 Power Panel 300/400 User's Manual V 2.30...
  • Page 603 Table 138: BIOS-relevant keys ................... 431 Table 139: Overview of BIOS main menu functions ............433 Table 140: BIOS motherboard device configuration menu ..........436 Table 141: BIOS drive configuration menu ................. 437 Power Panel 300/400 User's Manual V 2.30...
  • Page 604 Device functions in Windows XP Embedded with FP2007 ....... 507 Table 186: Model numbers - Windows Embedded Standard 2009........509 Table 187: Device functions in Windows Embedded Standard 2009 ......... 510 Table 188: Setting options - VESA mode................512 Power Panel 300/400 User's Manual V 2.30...
  • Page 605 Technical data - TB103 supply plug ..............542 Table 233: Contents of delivery - TB103 supply plug ............542 Table 234: Order data - Legend strip templates ..............544 Table 235: Order data - CompactFlash cards ..............545 Power Panel 300/400 User's Manual V 2.30...
  • Page 606 Table 247: Technical data - Gunze touch screen pen ............567 Table 248: Chemical resistance of the décor foil ..............569 Table 249: Product abbreviations ..................571 Table 250: Device compatibility overview ................571 Power Panel 300/400 User's Manual V 2.30...
  • Page 607 4PP452.0571-75........ 34 5SWWXP.0421-ENG......37 4PP452.0571-B5 ....... 34 5SWWXP.0422-ENG......37 4PP452.1043-75........ 34 5SWWXP.0721-ENG......37 4PP480.1043-75........ 34 5SWWXP.0722-ENG......37 4PP480.1505-75........ 34 4PP480.1505-B5 ....... 34 4PP481.1043-75........ 34 4PP481.1043-B5 ....... 34 4PP481.1505-75........ 34 9A0017.01 ......... 38 4PP482.1043-75........ 34 9A0017.02 ......... 38 Power Panel 300/400 User's Manual V 2.30...
  • Page 608 Model number index Power Panel 300/400 User's Manual V 2.30...
  • Page 609 Individual components ......26 CompactFlash ........554, 584 Packaging ..........25 Dimensions ........548, 553 Proper handling ........25 General information ......545, 550 Ethernet ........... 586 Order data ........545, 550 Ethernet connection ....49, 117, 177 Power Panel 300/400 User's Manual V 2.30...
  • Page 610 Environmentally-friendly disposal ... 28 Model numbers ..........30 Installation ..........27 MS-DOS ..........500, 502 Intended use .......... 25 MTBF ............588 Operation ..........27 MTCX ............50 Organization ........... 29 MTCX Firmware Upgrade ......491 Policy and procedures ......26 Power Panel 300/400 User's Manual V 2.30...
  • Page 611 Installation ..........511 Visual Components ......425 Touch screen driver ......511 Windows CE .........425 Windows XP Embedded Windows XP embedded .......425 General information ......507 TXD ............591 Installation ..........508 UART ............591 XGA ............592 Power Panel 300/400 User's Manual V 2.30...
  • Page 612 Index Power Panel 300/400 User's Manual V 2.30...

This manual is also suitable for:

Power panel 400

Table of Contents

Save PDF
