- Page 1 Revision Date: Rev: Document Number: 01/12/2017 MAN – FD141CV-TS-HDSDI Page 1 of 13 Installation and Operation Manual FD141CV-TS-HDSDI 14.1” High-Definition Touchscreen LCD © 2017 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com...
-
Page 2: Table Of Contents
Power & Ground Wiring ......................6 Power/Video ..........................7 Operation Instructions ........................8 Button Control ..........................8 Installation Drawings ......................9-10 Technical Support ........................11 Instructions for Continued Airworthiness ................11 Warranty ............................12 Log of Revisions .........................13 © 2017 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com... -
Page 3: General Information
It is an excellent flat panel display for use in rugged environments or anywhere daylight applications are required. Front View Rear View (with connector cover) Rear View (inputs) HD-SDI HD-SDI POWER/COMPOSITE LOOP OUT INPUT (SEE PINOUT) © 2017 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com... -
Page 4: Additional Information
Page 4 of 13 Additional Information The FD141CV-TS-HDSDI utilizes a state of the art digital video decoding chipset for the analog video input. The unit includes 4 video source inputs. They are in order of picture quality: (1)HD-SDI (High Definition camera), (1) DVI (computer input), (1)VGA (computer graphics like Moving Maps) and (1) Composite. -
Page 5: Installation Instructions
Page 5 of 13 Installation Instructions All cabin entertainment equipment, such as the FD141CV-TS-HDSDI, should be installed on a non-essential bus and have a dedicated circuit breaker. It is a requirement that a switch be installed in the cockpit so that the pilot can de-energize the entertainment system should it become necessary. -
Page 6: Power & Ground Wiring
Also, use short heavy gauge wire and a clean tight connection for ground. It is the installer's responsibility to understand the product's requirements to install the product in compliance with industry standards and safety. © 2017 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. -
Page 7: Power/Video
Composite Video - Signal Composite Video - Ground RS232 – Request to Send (RTS) RS232 – Received Data (RxD) RS232 – Transmit Data (TxD) RS232 – Ground (GND) © 2017 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com... -
Page 8: Operation Instructions
If no input is found, the display will go to standby mode. Pressing the Select button will select new video input. Button Controls Located at the right of the FD141CV-TS-HDSDI are 8 buttons. Their functions are shown below as well as labelled on the left side of the monitor. BUTTON... -
Page 9: Installation Drawings
Revision Date: Rev: Document Number: 01/12/2017 MAN – FD141CV-TS-HDSDI Page 9 of 13 Installation Drawing © 2017 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com... -
Page 10: Installation Drawings
Revision Date: Rev: Document Number: 01/12/2017 MAN – FD141CV-TS-HDSDI Page 10 of 13 Installation Drawing © 2017 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com... -
Page 11: Technical Support
01/12/2017 MAN – FD141CV-TS-HDSDI Page 11 of 13 Technical Support Should you have any questions concerning this product or other FDS Avionics Corp. products, please contact our Product Support representatives at 470-239-7421. FDS Avionics Corp. 6435 Shiloh Road Alpharetta, GA 30005... -
Page 12: Warranty
This warranty is not transferable. Any implied warranties expire at the express limited warranty expiration date. FDS shall not be held liable for any indirect, special, punitive, incidental or consequential damages. Some states do not allow limitation on the length of an implied warranty. In such states, the exclusions or limitations of this limited warranty may not apply. -
Page 13: Log Of Revisions
Updated Warranty info Added a note to the General Information, Updated 03/29/2011 Specifications 06/29/2012 Format and Warranty Update Company name change and formatting. No revision change 1/12/2017 necessary. © 2017 FDS Avionics Corp. TECHNICAL SUPPORT All Rights Reserved. 470-239-7421 or FDSAvionics.com...
