OPERATION
MANUAL
UFM-30DEMUX
3G/HD/SD Digital Audio Demultiplexer
UFM-3DMXAO
st
1
Edition - Rev. 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UFM-30DEMUX and is the answer not in the manual?

Questions and answers

Summary of Contents for FOR-A UFM-30DEMUX

  • Page 1 OPERATION MANUAL UFM-30DEMUX 3G/HD/SD Digital Audio Demultiplexer UFM-3DMXAO Edition - Rev. 1...
  • Page 2 Added "no signal" indication in SDI AUDIO IN SYNC Sec. 6-5-4 Added "no signal" indication in SDI AUDIO IN PCM Sec. 6-5-5 Spec details added to Audio Input (SDI embedded) Sec. 10-1-1 and Audio Output (SDI embedded, AES/EBU) UFM-30DEMUX power current changed Sec. 10-1-1...
  • Page 3 Precautions Important Safety Warnings [Power] Do not place or drop heavy or sharp-edged objects on power cord. A damaged cord can cause fire or electrical shock hazards. Regularly check power cord for excessive wear or damage to avoid possible fire / electrical hazards. Stop [Circuitry Access] Do not touch any parts / circuitry with a high heat factor.
  • Page 4 For connection to UFM-30DEMUX Gasket For attachment to UFM-30DEMUX UFM-30DEMUX and UFM-3DMXAO modules are used by installing them into a UF-106B or UF-112 UFM Frame. UF-106B supports up to 6 pairs of modules (up to 4 pairs if UF-106BPS is installed) UF-112 supports up to 12 pairs of modules.
  • Page 5: Table Of Contents

    2-1. UFM-30DEMUX........................8 2-2. UFM-3DMXAO (Option) ...................... 9 3. Connection ..........................10 3-1. Installing to a UFM frame ....................10 3-2. Basic Configuration (UFM-30DEMUX)................12 3-3. Optional Configuration (UFM-3DMXAO) ................12 3-3-1. Analog Audio Connection .................... 13 4. Operation ........................... 14 4-1.
  • Page 6 8-1. Digital Output Level versus Analog Input Level ..............33 9. Troubleshooting ......................... 34 10. Specifications and Dimensions ....................35 10-1. Specifications ........................35 10-1-1. UFM-30DEMUX ......................35 10-1-2. UFM-3DMXAO ......................36 10-2. External Dimensions ......................37 10-2-1. UFM-30DEMUX ......................37...
  • Page 7: Prior To Starting

    Congratulations! By purchasing UFM-30DEMUX Digital Audio De-multiplexer modules you have entered the world of FOR-A and its many innovative products. Thank you for your patronage and we hope you will turn to FOR-A products again and again to satisfy your video and audio needs.
  • Page 8: Panel Descriptions

    2. Panel Descriptions 2-1. UFM-30DEMUX  Front Panel PUSH OPERATE LOCK UFM-30DEMUX Name Description If set to OPERATE, the switch is set to Menu mode and menu settings can be made. OPERATE/LOCK If set to LOCK, the switch is set to Menu Lock mode and menu settings cannot be made.
  • Page 9: Ufm-3Dmxao (Option)

    2-2. UFM-3DMXAO (Option)  Front Panel POWER UFM-3DMXAO  Rear Panel LTC OUT ANALOG AUDIO OUT UFM-3DMXAO Name Description POWER LED Displays the power status. Used to output analog audio. ANALOG AUDIO OUT See section 3-3-1. "Analog Audio Connection." LTC OUT Used to output LTC time code.
  • Page 10: Connection

     UFM-30DEMUX UFM-30DEMUX modules can be installed in any empty slot on UFM frames. A UFM-30DEMUX module set consists of a front and rear module. Be sure to always install the front and rear modules in the same slot positions.
  • Page 11 (4) A UFM-3DMXAO module set consists of a front and rear module. Be sure to install the front and rear modules in the same slot positions. UF-106B front panel UFM-30DEMUX PO W ER PO W ER P OW E R RE F...
  • Page 12: Basic Configuration (Ufm-30Demux)

    3-2. Basic Configuration (UFM-30DEMUX) Connect UFM-30DEMUX modules to peripheral devices referring to the figure below. DIGITAL AUDIO OUT SDI signal INPUT OUTPUT 7/8-LTC UFM-30DEMUX 3G/HD/SD-SDI 3G/HD/SD-SDI DIGITAL AUDIO OUT UFM-30DEMUX Audio embedded SDI signal 3-3. Optional Configuration (UFM-3DMXAO) UFM-30DEMUX INPUT...
  • Page 13: Analog Audio Connection

    3-3-1. Analog Audio Connection For balanced audio signals, connect the hot, cold and shield conductor to "+"," - " and "COM" pins respectively. For unbalanced audio signals, connect the conductor that carries audio to a "+" pin and ground to "COM." ...
  • Page 14: Operation

    UFM-30DEMUX 4-2. Operation and Menu Modes 4-2-1. Operation (Normal) Mode After powering itself on, the UFM-30DEMUX will enter Operation mode and display the SDI signal status. If the SDI signal is normal, "READY" will be displayed. If the SDI signal is abnormal, an error message will be displayed. (See the table below.)
  • Page 15: Menu Mode

    OPERATE LOCK UFM-30DEMUX Down: Menu mode The UFM-30DEMUX menu is composed of three or four levels or hierarchies: menus, parameters, channels and values. Channels are not included in some menus. See section 5-3. "Menu Details" for details.  Menu Display...
  • Page 16: Menu Operation Example

    SDI CH6 | (1) Turn the control knob to select the Mapping menu. PUSH OPERATE LOCK UFM-30DEMUX (2) Press the control or move the switch down to go to the parameter level. PUSH OPERATE LOCK UFM-30DEMUX (3) Turn the control to select the AES MAP (AES OUT MAPPING) parameter.
  • Page 17 (5) Turn the control to select CH2. PUSH OPERATE LOCK UFM-30DEMUX (6) Press the control or move the switch down. The current setting (SDI CH2) will blink. PUSH OPERATE LOCK UFM-30DEMUX (7) Turn the control to select SDI CH6. PUSH...
  • Page 18: Menu List

    4-3. Menu List Menu Description Input Sets up SDI input embedded audio. Mapping Assigns SDI de-embedded audio channels to AES, SDI-embedded or analog output channels. Output Sets up audio output. System Sets up the system and SDI signals. Status (Display only) Displays the embedded audio and LTC input status.
  • Page 19 Parameter Setting Refer to Full name Menu name SDI OUT RESOLUTION SDI RESO CH1 to 16 24bit 6-3-3 20bit AES OUT RESOLUTION AES RESO CH1/2 to CH7/8 16bit +20.0dB SDI OUT GAIN SDI Gain CH1 to 16 6-3-4 +19.9dB | AES OUT GAIN AES Gain CH1 to 8...
  • Page 20  Status Menu (Display only) Parameter Channel Display Refer to Full name Menu name SDI STATUS SDI ERR No Error 6-5-1 No SIG CRC ERR SDI TV SYSTEM Format (See the "Format 6-5-2 settings" table on the previous page.) SDI AUDIO IN ON/OFF SDI AUD Group 1 6-5-3...
  • Page 21: Operation Examples

    5. Operation Examples 5-1. SDI CH5/6 >> AES CH1/2 This example assigns CH5/6 SDI de-embedded audio to CH1/2 AES audio output. Audio source SDI input CH 5 and CH 6 Output channels AES output CH 1 and CH 2 UFM- 30DEMUX ...
  • Page 22: Sdi Grp1 >> Sdi Grp2

    5-2. SDI GRP1 >> SDI GRP2 This example remaps asynchronous SDI embedded audio channels. Embedded audio Group 1 (CH1-4) is assigned to Group 2(CH5-8). Audio source SDI input audio Group 1 (CH1 to 4) Output channels SDI output audio Group 2 (CH5 to 8 ) GRP 1 GRP 1 UFM-...
  • Page 23: Synchronous / Asynchronous Audio Mapping

    5-3. Synchronous / Asynchronous Audio Mapping If audio source channels are synchronized with the SDI input, they can be freely mapped to audio output channels on a per-channel basis. If audio source channels are asynchronous, they are mapped on a per-group basis. ...
  • Page 24: Menu Details

    6. Menu Details 6-1. Input Menu 6-1-1. SDI IN SYNC MODE Parameter Channel Default Description SDI SYNC Group1 to 4 Auto Selects the sync mode for embedded audio processing. (3G/HD-SDI) Auto Automatically selects Sync or Async mode according to the information in embedded audio.
  • Page 25: Sdi In Gain

    6-1-3. SDI IN GAIN Parameter Channel Default Description SDI Gain CH1 to 16 0.0dB Adjusts the input gain for each embedded audio channel. Gain adjustment cannot be performed for non-PCM audio channels. (See section 6-1-2.) -20.0dB to +20.0dB (in 0.1dB steps) 6-2.
  • Page 26: Output Menu

    6-3. Output Menu 6-3-1. EMB THRU Parameter Channel Default Description Embed Embed Embeds the selected channels under Group THRU 1 to 4 SDI MAP to the SDI output. Through Passes through the SDI input audio without modification. For 3G/HD-SDI signals, set the parameter for each group.
  • Page 27: System Menu

    6-4. System Menu 6-4-1. SDI BYPASS Parameter Default Description SDI BYPS Operate Selects whether the SDI input is processed or bypassed when powered On. Basically, the SDI input signal is directly sent to the SDI output via relay when powered Off. Operate Processes and sends the SDI input signal to the SDI output.
  • Page 28: Ref Level

    6-4-5. REF LEVEL Parameter Default Description REF LVL -20dB Selects the digital audio reference level. (See section 8-1. "Digital Output Level versus Analog Input Level.") -20dB -18dB 6-4-6. TEST MODE Parameter Default Description Test SIG Setting to ON outputs an audio test signal. Outputs an internally generated 1 kHz audio test signal to SDI embedded, AES, and Analog outputs.
  • Page 29: Status Menu (Display Only)

    6-5. Status Menu (Display only) 6-5-1. SDI STATUS Parameter Description SDI ERR Displays the SDI input status. No Error Normal No SIG No SDI signal detected CRC ERR CRC error detected 6-5-2. SDI TV SYSTEM Parameter Description Format Displays the detected SDI input signal format. If TV standard detection has failed, "UNKNOWN"...
  • Page 30: Ltc In On/Off

    6-5-6. LTC IN ON/OFF Parameter Description LTC In Displays the presence or absence of LTC signal. LTC present LTC absent 6-5-7. SLOT Parameter Description Slot Displays the installed slot number of the UFM frame. 6-5-8. OPTION Parameter Description Option Displays the option module status. No Opt No option installed.
  • Page 31: Workflow Block Diagrams

    7. Workflow Block Diagrams 7-1. AUDIO Processing RELAY PASS THROUGH SYNCGEN SDI OUT SDI IN + TV system Detection Detection 1H DLY Output Input process process 1kHz TEST SG MAPPING AES OUT Output process ANALOG ANALOG OUT Output (OPTION) process Process Menu Parameter Reference SDI input signal detection...
  • Page 32: Minimum Delay

    7-3. MINIMUM DELAY Minimum Delay mode allows users to perform signal processing from input to output in a minimum amount of time, within 4 μsec. (See section 6-4-4.) In normal processing mode, processing takes about 1 H and can control all menu parameters. In minimum delay mode, the SDI input audio channels cannot be remapped to the SDI output channels.
  • Page 33: Analog Audio Option (Ufm-3Demux)

    8. Analog Audio Option (UFM-3DEMUX) If a UFM-3DEMUX option module is configured, 4 stereo pairs (8 ch) of analog audio output is available. For details on the module installation, see section 3-1. "Installing to a UFM frame." For details on the audio connection, see section 3-3. "Optional Configuration (UFM-3DMXAO)." 8-1.
  • Page 34: Troubleshooting

    9. Troubleshooting If any of the following problems occur while operating your UFM-30DEMUX, proceed as indicated below to see if the problem can be corrected before assuming a unit malfunction has occurred. Problem Check Action Set the switch to Cannot operate...
  • Page 35: Specifications And Dimensions

    10. Specifications and Dimensions 10-1. Specifications 10-1-1. UFM-30DEMUX Video formats 3G-SDI: 1080/59.94p, 50p, 60p (Level A and Level B) HD-SDI: 1080/59.94i, 50i, 60i 1080/30p, 29.97p, 25p, 24p, 23.98p, 24PsF, 23.98PsF 720/59.94p, 50p, 60p, 24p, 23.98p 1035/59.94i, 60i SD-SDI: 525/60,625/50 (Auto format detection) SDI input 3G-SDI: 2.97/1.001 Gbps or 2.97 Gbps...
  • Page 36: Ufm-3Dmxao

    Analog output option for UFM-30DEMUX UFM-30CTL: Control card 10-1-2. UFM-3DMXAO Audio Input SDI-embedded Input from the SDI OUT on the UFM-30DEMUX as embedded audio. (Free-assignable) Audio Output Analog output Balanced/Unbalanced 8 ch (4 stereo pairs) 25-pin D-sub (female) x 1,...
  • Page 37: External Dimensions

    10-2. External Dimensions 10-2-1. UFM-30DEMUX (All dimensions in mm)
  • Page 38: Ufm-3Dmxao

    10-2-2. UFM-3DMXAO (All dimensions in mm)
  • Page 39 Warning This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
  • Page 40 FOR-A America East Coast Office 2 Executive Drive, Suite 670, Fort Lee Executive Park, Fort Lee, NJ 07024, USA Phone: +1-201-944-1120 Fax : +1-201-944-1132 FOR-A America Distribution & Service Center 2400 N.E. Waldo Road, Gainesville, FL 32609, USA Phone: +1-352-371-1505 Fax: +1-352-378-5320...
