FOR-A USF-1013MUX Operator's Manual

FOR-A USF-1013MUX Operator's Manual

Digital audio multiplexer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OPERATION
MANUAL
USF-1013MUX
Digital Audio Multiplexer
st
1
Edition - Rev. 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the USF-1013MUX and is the answer not in the manual?

Questions and answers

Related Manuals for FOR-A USF-1013MUX

Summary of Contents for FOR-A USF-1013MUX

  • Page 1 OPERATION MANUAL USF-1013MUX Digital Audio Multiplexer Edition - Rev. 1...
  • Page 2 Precautions Important Safety Warnings [Power] Do not place or drop heavy or sharp-edged objects on the power cord. A damaged cord can cause fire or electrical shock hazards. Regularly check the power cord for excessive wear or damage to avoid possible fire / electrical hazards. Stop [Circuitry Access] Do not touch any parts / circuitry with a high heat factor.
  • Page 3 Upon Receipt The USF-1013MUX module is fully inspected and adjusted prior to shipment. Check your received items against the packing lists below. Check to ensure no damage has occurred during shipment. If damage has occurred, or items are missing, inform your supplier immediately.

  • Page 4: Table Of Contents

    5-5-6. Module Status ........................16 5-6. SNMP Settings ..........................16 5-6-1. Trap ............................17 6. About SNMP ............................18 6-1. Overview ...........................18 6-2. USF-1013MUX GET/SET List ....................18 6-3. USF-1013MUX TRAP List......................20 7. Work Block Chart ..........................21 7-1. Audio Processing ........................21 8. Troubleshooting ..........................22 9. Specifications and Dimensions ......................23 9-1.

  • Page 5: Prior To Starting

    1. Prior to Starting 1-1. Overview The USF-1013MUX is a module type digital audio multiplexer to be mounted into a USF-212S frame. The USF-1013 MUX is a plug-in module. The USF-1013MUX multiplexes and outputs 3G-SDI signal, HD-SDI signal or SD-SDI signal, and 8 channels (stereo 4 sets) of AES/EBU signal.

  • Page 6: Panel Descriptions

    Lights green when SDI signal is normally input. (Lights green : SD input SDI-IN : 1.5G-SDI input : 3G-SDI input μSD card Used when upgrading USF-1013MUX software. （Do not insert μSD card in normal operation.） connector 2-2. Rear Panel -LTC DIGITAL AUDIO IN...

  • Page 7: Operation Examples

    4. Operation Examples 4-1. SDI Embedded Output of AES Audio This example embeds synchronous/ asynchronous digital audio input (Ch.1-4) to SDI embedded audio Group 1 (Ch. 1-4). Audio source AES input Ch1 to 4 Channel to be embedded SDI output Ch1 to 4 (Group 1) Group 1 USF- 1013MUX...

  • Page 8: Synchronous / Asynchronous Audio Mapping

    4-2. Synchronous / Asynchronous Audio Mapping If audio source channels are synchronized with VIDEO, they can be freely mapped to SDI audio output channels. If audio source channels are asynchronous, they are mapped on a per-group basis.  Synchronous Audio Mapping Example (Freely assignable on a per-channel basis) Input Audio Channels Mapping Channels after Mapping...

  • Page 9: Web Gui

    5. Web GUI Start up a web browser on the PC and connect to the USF-1013MUX installed in a USF-212S frame. The following window will open. Refer to the USF-212S operation manual for details on how to connect to a USF-1013MUX from the web browser.

  • Page 10: Audio Input Settings

    5-1. Audio Input Settings Click Input. 5-1-1. SDI Audio Clock Channel Default Selection Description Selects the Sync. Mode for embedded audio processing. Auto: Automatically selects Sync. or Async. Auto Mode according to the flag in embedded audio. Group1-4 Auto Sync SDI Audio Clock Sync SDI: Processes audio in Sync.

  • Page 11: Sdi Pcm Mode／Aes Pcm Mode

    5-1-3. SDI PCM Mode／AES PCM Mode Parameter Channel Default Selection Description SDI PCM Ch. 1/2 to Auto Auto Selects PCM (linear PCM, Mode 15/16 uncompressed) or non-PCM NON-PCM (non-linear PCM) mode for embedded and AES audio processing. AES PCM Ch. 1/2 to Auto: Automatically selects PCM Mode or NON-PCM mode...

  • Page 12: Sdi Audio Output Mapping

    5-2-1. SDI Audio Output Mapping Channel Default Setting Range Description Ch. 1 to 16 Same SDI Ch1 to 16 Assigns audio input channels to output as SDI AES Ch1 to 8 channels. Audio assignments can be performed on a per-channel basis, but asynchronous (non-PCM) audio must be assigned on a per-group basis.

  • Page 13: Sdi Audio Resolution

    5-3-3. SDI Audio Resolution Channel Default Selection Description Sets the sampling resolution (bit depth) for output audio. 24bit Ch1 to 16 24bit 20bit 24bit: Outputs 24-bit audio. 16bit 20bit: Outputs 20-bit audio. 16bit: Outputs16-bit audio. 5-3-4. SDI Audio Mute Channel Default Selection Description...

  • Page 14: Parameter

    Item Default Selection Description Sync Auto (See the Selects video format of SDI signal. Format table The formats listed on the table as shown on next “Format page can be selected. Settings” as Multiple video formats that are used need to be shown on selected each time a format is switched.

  • Page 15: Status (Display Only)

    5-5. Status (Display Only) Click Status. 5-5-1. SDI Audio Clock Channel Description Group1 to 4 Displays if SDI input embedded audio is synchronous or asynchronous per group. Sync SDI: Synchronous mode Audio Clock: Asynchronous mode Loss: No audio 5-5-2. SDI Audio Mode Channel Description Ch.

  • Page 16: Signal Input Status

    Parameter Description Slot Slot no. of USF-212S on which the module is installed. Serial no. of USF-1013MUX Install Cards Indicates whether or not the front and rear modules match. Matched: Correct (front/rear) modules are installed. Mismatched: Incorrect rear module is installed. Install correct rear module.
  • Page 17 5-6-1. Trap Parameter Selection Description Sends SNMP traps when change occurs Video Input on SDI input signal format. Sends SNMP traps when change occurs Disable: Does not send SDI Audio Input on embedded audio input. SNMP traps. Enable: Sends SNMP Sends SNMP traps when change occurs AES Audio Input traps.

  • Page 18: Trap

    6. About SNMP 6-1. Overview The USF-1013MUX can be remotely monitored using an external SNMP monitoring system that supports SNMPv2C. MIB （ Management Information Base ） files required for the SNMP monitoring system can be downloaded from web GUI. Refer to Sec.5-6. “SNMP Settings, Downloading the MIB (Management Information Base) File”...
  • Page 19 SDI Audio  usf1013MuxAudioInCh10 Same as above GET INTEGER Info Ch10 SDI Audio  usf1013MuxAudioInCh11 Same as above GET INTEGER Info Ch11 SDI Audio  usf1013MuxAudioInCh12 Same as above GET INTEGER Info Ch12 SDI Audio  usf1013MuxAudioInCh13 Same as above GET INTEGER Info Ch13 SDI Audio...

  • Page 20: Usf-1013Mux Trap List

    6-3. USF-1013MUX TRAP List Object Item Name Object name in MIB file Type Reference Object group OID: 1.3.6.1.4.1.20175.1.315.0. ( TRAP ) INTEGER usf1013MuxSlotNumber Video In usf1013MuxInputVideoChange INTEGER usf1013MuxInputVideoStatus INTEGER usf1013MuxSlotNumber SDI Audio Info Ch1 usf1013MuxAudioInCh1Change INTEGER usf1013MuxAudioInCh1 INTEGER usf1013MuxSlotNumber SDI Audio Info Ch 2...

  • Page 21: Work Block Chart

    7. Work Block Chart 7-1. Audio Processing ⑧ Audio Embedded ⑦ Test Tone ⑨ LTC Input Process Menu Parameter Reference Chapters SDI Input Signal Detection 5-4-1 Video Format Identification 5-5-4 PLL & SYNC GEN 5-4-1 AUDIO De-embedding Process 5-1-1 5-1-3 5-5-1 5-5-2 AES AUDIO Input Process...

  • Page 22: Troubleshooting

    8. Troubleshooting If any of the following problems occur while operating the USF-1013MUX, follow the troubleshooting procedures below to see if the problem can be corrected before assuming a unit malfunction has occurred. IMPORTANT If a problem is not corrected by performing the procedure described below, turn the unit off and then on again.

  • Page 23: Specifications And Dimensions

    9. Specifications and Dimensions 9-1. Specifications Video formats 3G-SDI: 1080/59.94p, 50p, 60p (Level-A and Level-B) HD-SDI: 1080/59.94i, 50i, 60i 1080/30p, 29.97p, 25p, 24p, 23.98p, 24PsF, 23.98PsF 720/59.94p, 50p, 60p, 24p, 23.98p 1035/59.94i, 60i SD-SDI: 525/60,625/50 SDI Input 3G-SDI: 3 Gbps HD-SDI: 1.5 Gbps SD-SDI: 270 Mbps 75Ω...

  • Page 24: External Dimensions

    Power +12V DC (Supplied by USF frame) Power consumption Dimensions Front Module: 106 (W) x 356 (D) mm Rear module: 114(W) x 20.2 (H) Weight 0.5 kg Consumables None 9-2. External Dimensions (All dimensions in mm) 13.5 20.2 (23.6)
