DEVOS -- Enterprise Video System
Using the same vendor manual, find other codes
that you wish to use, for example selecting HDMI
input. Use the "+Add Command" function to add
as many additional commands as desired.

IR Control

When controlling devices via IR, the system must
communicate not with the controlled device directly, but with an iTach IR transmitter
which then sends the command via IR to the controlled device. The brand setup
procedure is similar, but you will enter ASCII command strings for the brand.
For example, for Samsung TVs, the commands are
Power On:
sendir,1:1,1,38000,1,1,172,172,22,64,22,64,22,64,22,21,22,21,22,21,22,21,22,21,22,64,22,64,22,64,22,21,22,21,22,21,22,2
1,22,21,22,64,22,21,22,21,22,64,22,64,22,21,22,21,22,64,22,21,22,64,22,64,22,21,22,21,22,64,22,64,22,21,22,1820
Power Off:
sendir,1:1,1,38000,1,1,173,173,21,65,21,65,21,65,21,21,21,21,21,21,21,21,21,21,21,65,21,65,21,65,21,21,21,21,21,21,21,2
1,21,21,21,21,21,21,21,21,21,65,21,65,21,21,21,21,21,65,21,65,21,65,21,65,21,21,21,21,21,65,21,65,21,21,21,1832
There are several methods to obtain these commands for your brand, including
learning it directly from a handheld IR remote control
(see ).
http://demo1.devosvideo.com/show?video=ee41c48fc082
Discover Video support can provide you with codes for virtually any brand and model
from our library. Contact support with the exact model number.
Save your brand when done.
Page 81
