- Page 1 Discover Video DEVOS System Installation Planning Guide Version 2.0 Discover Video LLC 5/30/2017 www.discovervideo.com...
-
Page 2: General Description
DEVOS System Planning General Description The Discover Video DEVOS system consists of at least one DEVOS or DVExpress server. A typical system also includes some number of other system components such as video encoders, video players, and digital signage display systems. -
Page 3: Digital Signage
DEVOS System Planning Digital Signage Digital Signage is provided by the SignStick®, Signage Media Player, or web browser which simply requires an IP connection, either wired or WiFi. Limited Digital Signage is also supported on certain consumer-grade Roku Box/Stick. DEVOS Server(s) The DEVOS Server connects to the network via up to four (4) GigE network connections that are configured for teaming (to increase the network capacity). -
Page 4: Public Internet
DEVOS Cloud DEVOS is available where the server is hosted by Discover Video on the public Internet. In this case, all IP signal flow travels over the customer's public Internet access connection, and special attention should be paid to local capacity issues. - Page 5 DEVOS System Planning StreamPump® StreamPump may be installed at any location, such as a remote branch office or satellite site. StreamPump connects to the DEVOS server and it receives one of each available live video streams as needed. When a viewer wishes to watch a live video and they are on the same network as the StreamPump, the stream automatically comes from the StreamPump rather than from the DEVOS, thus allowing hundreds of...
- Page 6 DEVOS System Planning IP Multicast Unlike many other systems, the Discover Video solution does not depend on IP multicast. Encoders always send video streams to the DEVOS server, not directly to viewers. If desired, a live stream can be configured to deliver IP multicast from the server.
- Page 7 Installation Drawings and Connectors DEVOS Server The DEVOS 16 is a 2U server with 16 disk slots. Leave enough clearance in front of the rack to enable you to open a door (~25 inches) and approx. 30 inches of clearance in the back to allow for airflow and servicing.
- Page 8 DEVOS System Planning Quad-Core Intel® Xeon® Processor E3-1220 v3 3.10GHz 8MB Cache (80W) 8GB RAM 120GB Solid State Drive 2 TB Drive for content Stinger 1.7 x 17.2 x 14.4 in (43 x 427 x 369 mm) Approx. 14 lbs 19”...
- Page 9 DEVOS System Planning Installation Drawing (2U shown, 1U is similar) Page 9 DEVOS System Planning 5-30-2017...
- Page 10 220GB Drive C 100+GB Drive D (content storage) Adequate network I/O (>1Gbps) Discover Video must have remote access via RDP on port 3389 to the server for installation and maintenance. If desired for security, this may be open only to Discover Video’s company IP address.
- Page 11 DEVOS System Planning StreamPump® StreamPump provides video distribution at remote locations. StreamPump Standard StreamPump Standard supports approx. 1,000 simultaneous viewers, (depending on streaming bit rate) and caches up to 1 TB of content. Specs (Subject to change) 1.7 x 17.2 x 14.4 in (43 x 427 x 369 mm) Approx.
- Page 12 DEVOS System Planning Spirit 3 Spirit-3 is a live encoding station that provides live streaming and/or recording from a two, universal inputs. Typically used for video production where input may be camera, computer VGA, or other sources. Streamsie is installed on Spirit 3. Input of the two inputs may be: HDMI, or SDI, or...
- Page 13 DEVOS System Planning Rover Rover is a laptop computer optimized for video capture and streaming. It includes two Captiva MISO input dongles. Typically used for portable streaming. The dongles may be used in USB 2 ports for live video capture. Specs (Subject to change) 15.6"...
- Page 14 DEVOS System Planning Mantis The Mantis is an SD/HD video streaming appliance that provides live video to the DEVOS system. Mantis supports HDMI, Composite, Component, DVI, and SDI input. Recording to USB device (not included). Does not support HDMI HDCP. Mantis does not deinterlace video and if used with composite video, external deinterlace is recommended.
-
Page 15: Digital Signage Media Player
DEVOS System Planning SignStick® The DEVOS system supports the SignStick Digital Signage player. The SignStick can plug directly into a TV via the HDMI connector. The SignStick has 2 USB ports, one may be used for a wired Ethernet adapter, included. (WiFi is supported but wired Ethernet recommended for live video). -
Page 16: Set Top Box
DEVOS System Planning Set Top Box The Set Top Box receives live video from a DEVOS or DVExpress System and allows the viewer to select live TV channels using a hand- held IR Remote Control (included). Specs (subject to change) Ethernet Input HDMI Output Composite Video Output via included adapter cable... - Page 17 DEVOS System Planning StreamEngine 4, 8 Channels The StreamEngine supports up to 8 channels of live HD video via HDMI inputs. 4-Channel HDMI Input 8-Channel HDMI Input HDCP is not supported. The capacity of additional (secondary) output streams depends on output resolution and related settings.
- Page 18 DEVOS System Planning iTach The iTach sends IR commands to up to three devices under command of the DEVOS (V4.5 and above) system. Specs (Subject to change) 9.0” x 3.5” x 2.0” Approx. 1 lbs. 10/100 Ethernet AC Power supply adapter (5V) Supports PoE iTach includes IR emitter that can be affixed to the IR receiver of controlled devices (approx.
-
Page 19: Priority Alert
DEVOS System Planning Streamsie® Streamsie is a software application for Windows 7/10 computers and for Mac OS X (10.10.X and above) computers. Streamsie PC and Mac provide advanced live streaming and capture capabilities using webcam, Captiva® devices, and/or screen capture. Streamsie may be installed on any number of computers that have access to a DEVOS system, and use is controlled by a license on the DEVOS server. - Page 20 DEVOS System Planning A/V INPUT QUICK REFERENCE PRODUCT A/V Input Application 2 x Single Channel All-In-One HDMI, Event broadcast SPIRIT-3 SDI/HDSDI, Lecture Capture Component, Streaming with Production Value SVideo, Composite, DVI, VGA Analog Audio Continuous live streaming HDMI Video Archive StreamEngine VGA Monitor Out 2 x Captiva MISO for USB...
- Page 21 DEVOS System Planning Network The system uses the following ports: 1935 for live ingest and flash streaming 80 / 443 (SSL) 9999 and/or 8410 for low delay video delivery 3380 RDP Cables, Connectors & Accessories Cables, adapters, connectors and similar are NOT included and are the responsibility of the system...
- Page 22 DEVOS System Planning DEVOS System Installation The vast majority of the time required for a system installation is less the physical install and more familiarization and training of the system owner/administrator. Successful installation can be measured by the ability of the system owner to perform basic system features and functions.
-
Page 23: End User License Agreement (Eula)
DEVOS System Planning End User License Agreement (EULA) The EULA for each product is shown during installation and appears in the product manual. Installation and use of the product(s) indicates acceptance of the EULA terms and conditions. End user signature for server products required before shipment. Page 23 DEVOS System Planning 5-30-2017... - Page 24 The products sold by Discover Video are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical systems whose failure to perform be reasonably expected to result in significant injury or loss of life or catastrophic property damage.
