Sharp SD-AS10 Service Manual

1-bit digital home theater with dvd player
Hide thumbs Also See for SD-AS10:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operating Manual
[1]
Specifications ......................................... . ....... 1-1
[2]
Names of parts....................................... . ....... 1-2
[1]
1-bit section............................................ . ....... 2-1
[2]
DVD/CD section ..................................... . ....... 2-1
[3]
TEST Mode ............................................ . ....... 2-1
[4]
6-22.)...................................................... . ....... 2-6
[5]
Line of the Protect Circuit....................... . ....... 2-7
[6]
Protect Circuit Explanation..................... . ....... 2-7
[1]
Caution on disassembly ......................... . ....... 3-1
[2]
DVD Changer mechanism section ......... . ....... 3-5
[1]
Block diagram ........................................ . ....... 4-1
Parts marked with "
" are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for
maintaining the safety and performance of the set.
SERVICE MANUAL
1-BIT DIGITAL HOME THEATER WITH DVD PLAYER
CONTENTS
SHARP CORPORATION
MODEL
SD-AS10 1-Bit Digital Home Theater with DVD Player consist-
ing of SD-AS10 (main unit and amplifier unit), CP-AS10F (front
speakers), CP-AS10C (center speaker), CP-AS10R (surround
speakers) and CP-AS10W (subwoofer).
In the interests of user-safety the set should be restored to its
original condition and only parts identical to those specified be
used.
[1]
Notes on schematic diagram .........................5-1
[2]
Types of transistor and LED ..........................5-1
[3]
Waveforms of 1-BIT circuit ............................5-2
[4]
Waveforms of DVD circuit..............................5-3
[5]
Voltage...........................................................5-5
[1]
Wiring side of PWB........................................6-1
[2]
Schematic diagram...................................... 6-11
[1]
Troubleshooting .............................................7-1
[1]
Function table of IC .......................................8-1
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
SD-AS10
No. SX473SDAS10U/
SD-AS10
