Cree GWH09UC-D3DNA4A/I Owner's Manual

Hide thumbs

Advertisement

Table of Contents

Split Air Conditioner
Models:
GWH09UC-D3DNA4A/I
GWH12UC-D3DNA4A/I
GWH18UC-D3DNA4A/I
Thank you for choosing our product.
For proper operation, please read and keep this manual carefully.
If you have lost the Owner's Manual, please contact the local agent or visit www.gree.com
or sent email to global@gree.com.cn for electronic version.
GWH09UC-D3DNA4C/I
GWH12UC-D3DNA4C/I
GWH18UC-D3DNA4C/I
.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GWH09UC-D3DNA4A/I and is the answer not in the manual?

Questions and answers

Related Manuals for Cree GWH09UC-D3DNA4A/I

Summary of Contents for Cree GWH09UC-D3DNA4A/I

  • Page 1 Split Air Conditioner Models: GWH09UC-D3DNA4A/I GWH09UC-D3DNA4C/I GWH12UC-D3DNA4A/I GWH12UC-D3DNA4C/I GWH18UC-D3DNA4A/I GWH18UC-D3DNA4C/I Thank you for choosing our product. For proper operation, please read and keep this manual carefully. If you have lost the Owner’s Manual, please contact the local agent or visit www.gree.com...
  • Page 2 Specialties note Matching instructions This model adopts RF remote control. The remote controller shall be matched with the air conditioner before operation, otherwise the remote control will be invalid. Before operation, please read the instructions in this page carefully and then do the corresponding matching operation. Note Please do the following operation within 2m from the unit.

  • Page 3: Table Of Contents

    Content Operation Notices Precautions......................1 Parts name ......................9 Screen Operation Guide Buttons on remote controller ................10 Introduction for icons on display screen ...............10 Introduction for buttons on remote controller ............11 Function introduction for combination buttons ............17 Operation guide ....................18 Replacement of batteries in remote controller ............18 Operation of Smart Control (Smart Phone, Tablet PC) ........

  • Page 4: Explanation Of Symbols

    Explanation of Symbols Indicates a hazardous situation that, if not avoided, will result in death or serious injury. Indicates a hazardous situation that, if not avoided, could result in death or serious injury. Indicates a hazardous situation that, if not avoided, may result in minor or moderate injury.

  • Page 5: Precautions

    Precautions WARNING Operation and Maintenance This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
  • Page 6 Precautions WARNING Maintenance must be performed by qualified professionals. Otherwise, it may cause personal injury or damage. Do not repair air conditioner by yourself. It may cause electric shock or damage. Please contact dealer when you need to repair air conditioner. Do not extend fingers or objects into air inlet or air outlet.
  • Page 7 Precautions WARNING Attachment Installation must be performed by qualified professionals. Otherwise, it may cause personal injury or damage. Must follow the electric safety regulations when installing the unit. According to the local safety regulations, use qualified power supply circuit and circuit break. Do install the circuit break.
  • Page 8 Precautions WARNING Do not put through the power before finishing installation. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. The temperature of refrigerant circuit will be high, please keep the interconnection cable away from the copper tube.
  • Page 9 Precautions WARNING For the air conditioner with plug, the plug should be reachable after finishing installation. For the air conditioner without plug, an circuit break must be installed in the line. If you need to relocate the air conditioner to another place, only the qualified person can perform the work.
  • Page 10 Precautions FCC STATEMENT (1) this device may not cause harmful interference, and (2) this device must accept any interference received,including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
  • Page 11 Precautions IC STATEMENT This device complies with Industry Canada licence- exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
  • Page 12 Precautions IC STATEMENT antennes utilisées pour cet émetteur doivent être installées et doivent fonctionner à au moins 20 cm de distance des utilisateurs et ne doivent pas être placées près d’autres antennes ou émetteurs ou fonctionner avec ceux-ci. Les installateurs doivent s’assurer qu’une distance de 20 cm sépare l’appareil (à...

  • Page 13: Parts Name

    Parts name Indoor Unit air inlet panel power wire filter horizontal louver air outlet remote controller power display tem.display NOTICE: Actual product may be different from above graphics, please refer to actual products.

  • Page 14: Buttons On Remote Controller

    Buttons on remote controller ON/OFF button +/- button Cool button Heat button Fan button I FEEL button up down swing button Mode button Left right swing button T-ON/T-OFF button Clock button Humidity button/Health button Air button X-fan button Light button Sleep button WIFI button Introduction for icons on display screen...

  • Page 15: Introduction For Buttons On Remote Controller

    Introduction for buttons on remote controller Note: After putting through the power, the air conditioner will give out a sound. Operation indictor " " is ON (red indicator). After that, you can operate the air conditioner by using remote controller. Under on status, pressing the button on the remote controller, the signal icon "...
  • Page 16 Introduction for buttons on remote controller I FEEL button Press this button to start I FEEL function and " " will be displayed on the remote controller. After this function is set, the remote controller will send the detected ambient temperature to the controller and the unit will automatically adjust the indoor temperature according to the detected temperature.
  • Page 17 Introduction for buttons on remote controller When selecting auto mode, air conditioner will operate automatically according to ambient temperature. Set temperature can’t be adjusted and will not be displayed as well. Press "FAN" button can adjust fan speed. Press " "...
  • Page 18 Introduction for buttons on remote controller T-ON/T-OFF button T-ON button “T-ON” button can set the time for timer on. After pressing this button, " " icon disappears and the word “ON" on remote controller blinks. Press “+” or “-”button to adjust T-ON setting. After each pressing “+” or “-”button, T-ON setting will increase or decrease 1min.
  • Page 19 Introduction for buttons on remote controller Humdity/health button Press this button to select your required operation mode. cancel INTELLIGENT INTELLIGENT Note:there is no this function for this unit. If press this button,the main unit will click, but it also runs under original status. X-FAN button Pressing this button in COOL or DRY mode, the icon "...
  • Page 20 Introduction for buttons on remote controller In Sleep 1 and Sleep 2, the air conditioner will run according to a group of presetting temperature curves. Sleep 3 - the sleep curve setting under DIY Sleep mode: (1) Under Sleep 3 mode, long press "AIR" button, the remote controller will enter the setting of personalized sleep.

  • Page 21: Function Introduction For Combination Buttons

    Function introduction for combination buttons About X-FAN function This function indicates that moisture on evaporator of indoor unit will be blowed after the unit is stopped to avoid mould. 1. Having set X-FAN function on: After turning off the unit by pressing ON/OFF button indoor fan will continue running for about 2 min.

  • Page 22: Operation Guide

    Operation guide After putting through the power, press "ON/OFF" button on remote controller to turn on the air conditioner. Press "MODE" button to select your required mode: AUTO, COOL, DRY, FAN, HEAT. Press "+" or " - " button to set your required temperature. (Temperature can’t be adjusted under auto mode).

  • Page 23: Operation Of Smart Control (Smart Phone, Tablet Pc)

    Operation of Smart Control (Smart Phone, Tablet PC) Special Function How to operate AC or auxiliary device with smart phone or tablet PC after matching: First of all: before using smart connection function, please make sure your smart phone or tablet computer uses the standard Android or iOS operating system. Please refer to the application program for the specific version.
  • Page 24 Operation of Smart Control (Smart Phone, Tablet PC) 2. Turn on the AC WiFi: Turn the AC on. First, make sure the remote controller is matched. Then, long-press “WiFi” button on the remote controller for at least 3 seconds. If WiFi icon is shown, it means the WiFi function is turned on.
  • Page 25 Operation of Smart Control (Smart Phone, Tablet PC) Attention: please change the name and key of the network during the first setting! 6. Left-slide the bottom function bar to “Settings” and click it to enter into internet setting interface. Click “Network Setting”, and input user name and password (the defaulted user name and password is admin) in the “Login”...
