Summary of Contents for Mazda 3 Sport 2017

Page 3 HIROSHIMA, JAPAN Important Notes About This Manual Keep this manual in the glove compartment as a handy reference for the safe and enjoyable use of your Mazda. Should you resell the vehicle, leave this manual with it for the next owner.
Page 4: How To Use This Manual
Mazda. By reading your manual, you part. can ﬁ nd out about the features, important Please refer to the manual for a detailed safety information, and driving under explanation.
Page 5: Table Of Contents
Table of Contents Pictorial Index Interior, exterior views and part identification of your Mazda. Essential Safety Equipment Important information about safety equipment, including seats, seat belt system, child-restraint systems and SRS air bags. Before Driving Use of various features, including keys, doors, mirrors and windows.
Page 7: Pictorial Index
Pictorial Index Interior, exterior views and part identiﬁ cation of your Mazda. Interior Overview ................1-2 Interior Equipment (View A) ............1-2 Interior Equipment (View B) ............1-4 Interior Equipment (View C) ............1-5 Exterior Overview ................1-6 (4-Door) ..................1-6 (5-Door) ..................
Page 8: Interior Overview
Pictorial Index Interior Overview Interior Equipment (View A) Door-lock knob ..................... page 3-20 Turn and lane-change signal ................. page 4-49 Lighting control..................... page 4-43 Wiper and washer lever ..................page 4-50 Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) OFF switch ........page 4-120 DSC OFF switch ....................
Page 9 Pictorial Index Interior Overview Audio control switches..................page 5-55 Instrument cluster ....................page 4-12 Dashboard illumination knob ................page 4-18 Cruise control switches ................page 4-110 , 4-146 Hazard warning ﬂ asher switch ................page 4-56 Seat warmer switches ....................page 2-7 Heated steering wheel switch ................
Page 10 Pictorial Index Interior Overview Interior Equipment (View B) SRS air bags ......................page 2-41 Active driving display ................... page 4-21 Climate control system.................... page 5-2 Rear window defogger switch................page 4-54 Audio system......................page 5-16 Glove compartment ..................... page 5-117 Shift lever/Selector lever ................page 4-29 , 4-32 Commander switch ....................
Page 11 Pictorial Index Interior Overview Interior Equipment (View C) Seat belts ....................... page 2-14 SRS air bag......................page 2-41 Bottle holder ......................page 5-116 Overhead lights ....................page 5-111 Moonroof switch ....................page 3-40 Sunvisor ......................page 5-110 Vanity mirror ....................... page 5-110 Rearview mirror ....................
Page 12: Exterior Overview
Pictorial Index Exterior Overview (4-Door) Hood ........................page 6-22 Windshield wiper blades ..................page 6-31 Moonroof ......................page 3-40 Doors and keys ...................... page 3-14 Fuel-ﬁ ller lid ......................page 3-31 Wheels and Tires ....................page 6-40 Exterior lights ......................page 6-44 Trunk lid ........................
Page 13 Pictorial Index Exterior Overview (5-Door) Hood ........................page 6-22 Windshield wiper blades ..................page 6-31 Moonroof ......................page 3-40 Doors and keys ...................... page 3-14 Fuel-ﬁ ller lid ......................page 3-31 Wheels and Tires ....................page 6-40 Exterior lights ......................page 6-44 Rear window wiper blade ..................
Page 14 MEMO 1–8...
Page 15 Essential Safety Equipment Important information about safety equipment, including seats, seat belt system, child-restraint systems and SRS air bags. Seats ..................... 2-2 Seat Precautions ................2-2 Front Seat ..................2-5 Rear Seat ..................2-8 Head Restraints ................2-12 Seat Belt Systems ................2-14 Seat Belt Precautions ..............
Page 16: Essential Safety Equipment
The front seats contain air bag components essential to the supplemental restraint system. Such modifi cations could damage the supplemental restraint system and result in serious injury. Consult an Authorized Mazda Dealer if there is any need to remove or reinstall the front seats.
Page 17 Essential Safety Equipment Seats Do not drive with either front seats reclined: Sitting in a reclined position while the vehicle is moving is dangerous because you do not get the full protection from seat belts. During sudden braking or a collision, you can slide under the lap belt and suff er serious internal injuries.
Page 18 Essential Safety Equipment Seats Always leave your car locked and keep the car keys safely away from children (4– Door): Leaving your car unlocked or the keys in reach of children is dangerous. Children who fi nd their way into the trunk through an unlocked rear seatback or an open trunk can become accidentally locked in the trunk.
Page 19: Front Seat
Essential Safety Equipment Seats Front Seat Seat Operation Power operation *1: With power operation seat only Seat Slide (Manual Seat) To move a seat forward or backward, raise the lever and slide the seat to the desired position and release the lever. Make sure the lever returns to its original position and the seat is locked in place by attempting to push it forward and backward.
Page 20 Essential Safety Equipment Seats Seat Recline (Manual Seat) To change the seatback angle, lean forward slightly while raising the lever. Then lean back to the desired position and release the lever. Make sure the lever returns to its original position and the seatback is locked in place by attempting to push it forward and backward.
Page 21: Seat Warmer
Essential Safety Equipment Seats Seat Warmer WARNING The front seats are electrically heated. The Be careful when using the seat warmer: ignition must be switched ON. The heat from the seat warmer may be Press the seat warmer switch while the too hot for some people, as indicated ignition is switched ON to operate the seat below, and could cause a low-...
Page 22: Rear Seat
Essential Safety Equipment Seats Rear Seat CAUTION Split/One-piece Folding the Do not use organic solvents to clean Seatback the seat. It may damage the seat surface and the heater. By lowering the rear seatback(s) the luggage compartment space can be NOTE expanded.
Page 23 Essential Safety Equipment Seats Lowering the seatback(s) WARNING CAUTION Do not drive the vehicle with occupants on folded down seatback(s) or in the Check the position of a front seat luggage compartment. before folding a rear seatback. Putting occupants in the luggage Depending on the position of a front compartment is dangerous because seat, it may not be possible to fold...
Page 24 Essential Safety Equipment Seats (5–Door) To return the seatback to its upright position: Press the push knob to fold down the seatback. WARNING When returning a seatback to its upright position, make sure the 3-point seat belt is not caught in the seatback and the 3-point seat belt is not twisted.
Page 25 Essential Safety Equipment Seats Armrest 1. Make sure that the seat belt passes through the seat belt guide correctly The rear armrest in the center of the rear and it is not twisted, then raise the seatback can be used (no occupant in the seatback while preventing the seat belt center seat) or placed upright.
Page 26: Head Restraints
Essential Safety Equipment Seats Head Restraints Front outboard seat Your vehicle is equipped with head restraints on all outboard seats and the rear center seat. The head restraints are intended to help protect you and the passengers from neck injury. WARNING Always drive with the head restraints installed when seats are being used and...
Page 27 Essential Safety Equipment Seats Removal/Installation To remove the head restraint, pull it up while pressing the stop-catch. To install the head restraint, insert the legs into the holes while pressing the stop- catch. WARNING Always drive with the head restraints installed when seats are being used and make sure they are properly installed: Driving with the head restraints not...
Page 28: Seat Belt Systems
Seat Belt Precautions Seat belts help to decrease the possibility of severe injury during accidents and sudden stops. Mazda recommends that the driver and all passengers always wear seat belts. (Except Mexico) All of the seat belt retractors are designed to keep the lap/shoulder belts out of the way when not in use.
Page 29 Using a damaged seat belt is dangerous. An accident could damage the belt webbing of the seat belt in use. A damaged seat belt cannot provide adequate protection in a collision. Have an Authorized Mazda Dealer inspect all seat belt systems in use during an accident before they are used again.
Page 30: Automatic Locking Mode
Essential Safety Equipment Seat Belt Systems Pregnant Women and Persons with Serious Medical Conditions Pregnant women should always wear seat belts. Ask your doctor for speciﬁ c recommendations. The lap belt should be worn SNUGLY AND AS LOW AS POSSIBLE OVER THE HIPS. The shoulder belt should be worn across your shoulder properly, but never across the stomach area.
Page 31: Seat Belt
If a belt does not fully retract, inspect it for kinks and twists. If it is still not retracting properly, have it inspected at an Authorized Mazda Dealer. Take up slack Keep low on Front Shoulder Belt Adjuster...
Page 32: Seat Belt Warning Systems
Essential Safety Equipment Seat Belt Systems Seat Belt Warning Systems Front Seat Belt Pretensioner and Load If it detects that the occupant seat belt is unfastened, the warning light or beep Limiting Systems alerts the occupant. Refer to Warning/Indicator Lights on page For optimum protection, the driver and 4-23 .
Page 33 In addition, the pretensioner system for limiter has been expended: the front passenger, like the front and side Always have an Authorized Mazda passenger air bag, is designed to only Dealer immediately inspect the seat deploy when the front passenger occupant belt pretensioners and air bags after classiﬁ...
Page 34: Seat Belt Extender
If residue from the Please contact your Authorized Mazda deployment of the air bags or the front Dealer for more information. pretensioner system gets on the skin...
Page 35 (or front extender in a diff erent vehicle or seat. passenger) is wearing the seat belt If you sell your Mazda, do not leave your seat belt extender in the vehicle. It even if the driver (or front passenger) could be used accidentally by the new is not wearing it.
Page 36: Child-Restraint
Even if the front passenger air bag is shut off, Mazda strongly recommends that children be properly restrained and child-restraint systems of all kinds are properly secured on the rear seats which are the best place for children.
Page 37 Essential Safety Equipment Child-Restraint WARNING Use the correct size child-restraint system: For eff ective protection in vehicle accidents and sudden stops, a child must be properly restrained using a seat belt or child-restraint system depending on age and size. If not, the child could be seriously injured or even killed in an accident.
Page 38 Essential Safety Equipment Child-Restraint Never use a rear-facing child-restraint system in the front seat with an air bag that could deploy: Rear-facing child-restraint systems on the front seat are particularly dangerous even though you may feel assured that a front passenger air bag will not deploy based on the fact that the front passenger air bag deactivation indicator light illuminates.
Page 39 Essential Safety Equipment Child-Restraint Do not install a front-facing child-restraint system on the front passenger seat unless it is unavoidable: In a collision, the force of a deploying air bag could cause serious injury or death to the child. If installing a front-facing child-restraint system on the front passenger seat is unavoidable, move the front passenger seat as far back as possible.
Page 40 NOTE Your Mazda is equipped with LATCH lower anchors for attachment of specially designed LATCH child-restraint systems in the rear seats. When using these anchors to secure a child-restraint system, refer to "Using LATCH Lower Anchor" (page 2-37 ).
Page 41: Child-Restraint System Installation
Essential Safety Equipment Child-Restraint Child-Restraint System Child seat A child seat restrains a child's body using Installation the harness. Child-Restraint System Types In this owner's manual, explanation of child-restraint systems is provided for the following three types of popular child- restraint systems: infant seat, child seat, booster seat.
Page 42: Installing Child-Restraint Systems
Some child-restraint systems now come with tethers and therefore must be installed on the seats that take tethers to be effective. In your Mazda, tethered child-restraint systems can only be accommodated in the three positions on the rear seat.
Page 43 Essential Safety Equipment Child-Restraint Anchor Bracket WARNING Anchor brackets for securing child- Always attach the tether strap to the restraint systems are equipped in the correct tether anchor position: vehicle. Locate each anchor position using Attaching the tether strap to the the illustration.
Page 44 Essential Safety Equipment Child-Restraint Using Automatic Locking Mode (5-Door) Follow these instructions when using Tether strap a child-restraint system, unless you are attaching a LATCH-equipped child- restraint system to the rear LATCH lower anchors. Refer to “Using LATCH Lower Forward Anchor”...
Page 45 Essential Safety Equipment Child-Restraint 4. To get the retractor into the automatic NOTE locking mode, pull the shoulder belt Inspect this function before each use of portion of the seat belt until the entire the child-restraint system. You should length of the belt is out of the retractor. not be able to pull the shoulder belt out of the retractor while the system is in the automatic locking mode.
Page 46 Essential Safety Equipment Child-Restraint Always remove the head restraint (5-Door) and set the tether strap (except when Tether strap installing a backless booster seat): Routing the tether strap on top of the head restraint is dangerous. In a collision the tether strap could slide off the head restraint and loosen the child- Forward restraint system.
Page 47        bags: after removing the child-restraint Mazda vehicles equipped with side air system:   bag will have a "SRS AIRBAG" tag on Driving with the head restraint the outboard shoulder of the front seats.
Page 48 Essential Safety Equipment Child-Restraint Front Passenger's Seat Child-Restraint Never use a rear-facing child-restraint System Installation (With Front system in the front seat with an air bag Passenger Occupant Classiﬁ cation that could deploy: System) Rear-facing child-restraint systems on the front seat are particularly 1.
Page 49 Essential Safety Equipment Child-Restraint 5. Push the child-restraint system ﬁ rmly 7. Switch the ignition ON and make sure into the vehicle seat. Be sure the the front passenger air bag deactivation belt retracts as snugly as possible. A indicator light illuminates after clicking noise from the retractor will installing a child-restraint system on be heard during retraction if the system...
Page 50 If the indicator light does not illuminate after seating a child in a child-restraint system on the front passenger seat, seat a child in a child-restraint system on the rear seat and consult an Authorized Mazda Dealer as soon as possible. 2–36...
Page 51 Child-Restraint Using LATCH Lower Anchor Your Mazda is equipped with LATCH lower anchors for attachment of specially designed LATCH child-restraint systems in the rear seats. Both anchors must be used, otherwise the seat will bounce around and put the child in danger. Most LATCH child-restraint systems must also be used in conjunction with a tether to be effective.
Page 52 Essential Safety Equipment Child-Restraint Installation on rear outboard seats 6. If your child-restraint system came equipped with a tether, that means it is 1. First, adjust the front seat to allow very important to properly secure the clearance between the child-restraint tether for child safety.
Page 53 Essential Safety Equipment Child-Restraint Installation on rear center seat (5-Door) The LATCH lower anchors at the center Tether strap of the rear seat are much further apart than the sets of LATCH lower anchors for child-restraint system installation at other seating positions. Child-restraint systems with rigid LATCH attachments Forward cannot be installed on the center seating...
Page 54 Essential Safety Equipment Child-Restraint Always install the head restraint and WARNING adjust it to the appropriate position after removing the child-restraint Always remove the head restraint and system: set the tether strap: Driving with the head restraint Routing the tether strap on top of removed is dangerous as impact to the the head restraint is dangerous.
Page 55: Srs Air Bags
Essential Safety Equipment SRS Air Bags Supplemental Restraint System (SRS) Precautions The front and side supplemental restraint systems (SRS) include different types of air bags. Please verify the different types of air bags which are equipped on your vehicle by locating the “SRS AIRBAG”...
Page 56 Essential Safety Equipment SRS Air Bags If your vehicle is also equipped with a front passenger occupant classiﬁ cation system, refer to the Front Passenger Occupant Classiﬁ cation System (page 2-57 ) for details. If your vehicle is equipped with a front passenger occupant classiﬁ cation system, the front passenger air bag deactivation indicator light illuminates for a speciﬁ...
Page 57 Essential Safety Equipment SRS Air Bags Never use a rear-facing child-restraint system in the front seat with an air bag that could deploy: Rear-facing child-restraint systems on the front seat are particularly dangerous even though you may feel assured that a front passenger air bag will not deploy based on the fact that the front passenger air bag deactivation indicator light illuminates.
Page 58 Essential Safety Equipment SRS Air Bags Do not attach objects on or around the area where a side air bag deploys: Attaching objects to the front seat in such a way as to cover the outboard side of the seat in any way is dangerous. In an accident the object could interfere with the side air bag, which infl ates from the outboard side of the front seats, impeding the added protection of the side air bag system or redirecting the air bag in a way that is dangerous.
Page 59 Do not use tires or wheels other than those specifi ed for your Mazda:   Use of any tire or wheel other than those specifi ed for your Mazda (page 9-10 ) is dangerous. Use of such wheels will prevent the vehicle's accident detections system from accurately detecting a collision or roll-over accident resulting in incorrect or unexpected air bag deployment and the possibility of serious injuries.
Page 60 Only a trained Authorized Mazda Dealer can fully evaluate these systems to see that they will work in any subsequent accident. Driving with an expended or damaged air bag or pretensioner unit will not aff ord you the necessary protection in the event of any subsequent accident which could result in serious injury or death.
Page 61 Neither is likely to cause injury, however, the texture of the air bags may cause light skin injuries on body parts not covered with clothing through friction. Should you sell your Mazda, we urge you to tell the new owner of its air bag systems       ...
Page 62: Supplemental Restraint System Components
Essential Safety Equipment SRS Air Bags Supplemental Restraint System Components (With Front Passenger Occupant Classiﬁ cation System) 2–48...
Page 63 Essential Safety Equipment SRS Air Bags (Without Front Passenger Occupant Classiﬁ cation System) Driver/Front passenger inﬂ ators and air bags Roll-over sensor , crash sensors, and diagnostic module (SAS unit) Seat belt pretensioners (page 2-18 ) Front air bag sensors Side crash sensors Air bag/seat belt pretensioner system warning light (page 4-24 ) Side and curtain inﬂ...
Page 64: How The Srs Air Bags Work
SRS Air Bags How the SRS Air Bags Work Your Mazda is equipped with the following types of SRS air bags. SRS air bags are designed to work together with the seat belts to help to reduce injuries during an accident.
Page 65 Essential Safety Equipment SRS Air Bags Front Passenger Air Bag The front passenger air bag is mounted in the front passenger dashboard. The inﬂ ation mechanism for the front passenger air bag is the same as the driver's air bag. For more details about air bag deployment, refer to "SRS Air Bag Deployment Criteria"...
Page 66 Essential Safety Equipment SRS Air Bags (With Front Passenger Occupant Classiﬁ cation System) In addition, the front passenger side bag is designed to only deploy when the front passenger occupant classiﬁ cation sensor detects a passenger sitting on the front passenger's seat. For details, refer to the front passenger occupant classiﬁ...
Page 67 Essential Safety Equipment SRS Air Bags (With Front Passenger Occupant Classiﬁ cation System) In a roll-over: In response to a vehicle roll-over, both curtain air bags inﬂ ate. Both curtain air bags will deploy after the roll-over accident is detected. (With Front Passenger Occupant Classiﬁ...
Page 68: Srs Air Bag Deployment Criteria
Essential Safety Equipment SRS Air Bags SRS Air Bag Deployment Criteria This chart indicates the applicable SRS equipment that will deploy depending on the type of collision. (The illustrations are the representative cases of collisions.) Types of collision A severe frontal/near frontal A severe side A roll-over/near A rear collision...
Page 69: Limitations To Srs Air Bag
Essential Safety Equipment SRS Air Bags Limitations to SRS Air Bag In severe collisions such as those described previously in "SRS Air Bag Deployment Criteria", the applicable SRS air bag equipment will deploy. However, in some accidents, the equipment may not deploy depending on the type of collision and its severity. Limitations to front/near front collision detection: The following illustrations are examples of front/near front collisions that may not be detected as severe enough to deploy the SRS air bag equipment.
Page 70 Essential Safety Equipment SRS Air Bags Limitations to side collision detection: The following illustrations are examples of side collisions that may not be detected as severe enough to deploy the SRS air bag equipment. Side impacts with two-wheeled vehicles Side impacts involving trees or poles Roll-over (Without Front Passenger Occupant Classification System) (With Front Passenger Occupant Classiﬁ...
Page 71: Front Passenger Occupant Classiﬁ Cation System
Essential Safety Equipment SRS Air Bags Front Passenger Occupant Classiﬁ cation System First, please read "Supplemental Restraint System (SRS) Precautions" (page 2-41 ) carefully. Front Passenger Occupant Classiﬁ cation Sensor Your vehicle is equipped with a front passenger occupant classiﬁ cation sensor as a part of the supplemental restraint system.
Page 72 ON and does not turn on as indicated in the front passenger air bag deactivation indicator light on/off condition chart, do not allow an occupant to sit in the front passenger seat and consult an Authorized Mazda Dealer as soon as possible. The system may not work properly in an accident.
Page 73 Essential Safety Equipment SRS Air Bags WARNING Do not allow an occupant in the front passenger's seat to sit with a posture which makes it diffi cult for the front passenger occupant classifi cation sensor to detect the occupant correctly: Sitting in the front passenger's seat with a posture which makes it diffi cult for the front passenger occupant classifi cation sensor to detect the occupant correctly is dangerous.
Page 74 Essential Safety Equipment SRS Air Bags        An object, such as a seat cushion, is put on the front passenger's seat or between the passenger's back and the seatback.        A seat cover is put on the front passenger's seat.
Page 75 Authorized Mazda Dealer as soon as possible. If the front passenger air bag deactivation indicator light turns on when an occupant ...
Page 76: Constant Monitoring
Essential Safety Equipment SRS Air Bags Constant Monitoring The following components of the air bag systems are monitored by a diagnostic system: Crash sensors, and diagnostic module (SAS unit)        Front air bag sensors ...
Page 77 Before Driving Use of various features, including keys, doors, mirrors and windows. Keys ............3-2 Security System ......... 3-42 Keys ..........3-2 Modiﬁ cation and Add-On Keyless Entry System ....3-3 Equipment ........3-42 Immobilizer System ..... 3-42 Advanced Keyless Entry System ..3-10 Theft-Deterrent System ....
Page 78: Before Driving
       Non-Mazda genuine electronic other controls to operate, or even make equipment is installed in the vehicle. the vehicle move.
Page 79 It can also help you signal for attention or If your key (auxiliary key) is lost, consult help. your Authorized Mazda Dealer and have Operating the theft-deterrent system is your code number ready. also possible on theft-deterrent system- equipped vehicles.
Page 80 Additional keys can be obtained at        an Authorized Mazda Dealer. Up to 6 keys can be used with the keyless functions per vehicle. Bring all keys to an Authorized Mazda Dealer when additional keys are required.
Page 81 Before Driving Keys Transmitter (With the advanced keyless function)        A beep sound can be heard for   conﬁ rmation when the doors and the Operation indicator light liftgate/trunk lid are locked/unlocked Operation buttons using the key.
Page 82 Before Driving Keys The operation indicator light ﬂ ashes when Unlock button the buttons are pressed. To unlock the driver's door, press the unlock button and the hazard warning Lock button lights will ﬂ ash twice. To lock the doors and the liftgate/trunk (With the advanced keyless function) lid, press the lock button and the hazard A beep sound will be heard twice.
Page 83 Before Driving Keys (Auto re-lock function) NOTE          After unlocking with the key, all The system can be set to unlock all          doors and the liftgate/trunk lid will doors by performing a single operation.
Page 84 Before Driving Keys Operational Range Trunk button (4–door) To open the trunk lid, press and hold the The system operates only when the driver trunk button until the trunk lid opens. is in the vehicle or within operational range while the key is being carried. Starting the Engine NOTE Starting the engine may be possible...
Page 85 Before Driving Keys Without the advanced keyless function Interior antenna Operational range NOTE The engine may not start if the key is placed in the following areas: Around the dashboard        In the storage compartments such as ...
Page 86 Consult an Authorized Before using the key near people who Mazda Dealer for details. If the advanced use medical devices, ask the medical keyless entry system has been deactivated, device manufacturer or your physician...
Page 87 Before Driving Advanced Keyless Entry System Operational Range NOTE The system may not operate if you      The system operates only when the driver are too close to the windows or door is in the vehicle or within operational handles, or liftgate.
Page 88 Before Driving Doors and Locks Door Locks After closing the doors and the liftgate/ trunk lid, always verify that they are securely closed: WARNING Doors and the liftgate/trunk lid not securely closed are dangerous, if the Always take all children and pets with vehicle is driven with a door and the you or leave a responsible person with liftgate/trunk lid not securely closed,...
Page 89: Doors And Locks
Before Driving Doors and Locks (Door unlock (control) system with NOTE        collision detection) Always stop the engine and lock the      This system automatically unlocks doors. In addition, to prevent theft of ...
Page 90 Before Driving Doors and Locks Locking, Unlocking with Auxiliary Locking, Unlocking with Request Switch (With the advanced keyless function) Turn the auxiliary key toward the front to lock, toward the back to unlock. All doors and the liftgate/trunk lid can be locked/unlocked by pressing the request To lock switch on the front doors while the key is...
Page 91 Before Driving Doors and Locks To unlock NOTE The system can be set to unlock all        Driver's door request switch doors by performing a single operation. Refer to Personalization Features on To unlock the driver's door, press the ...
Page 92 Before Driving Doors and Locks (With theft-deterrent system) All doors and the liftgate/trunk lid                 cannot be locked when any door or the The hazard warning lights ﬂ ash when ...
Page 93 Before Driving Doors and Locks Auto re-lock function Locking, Unlocking with Door-        After unlocking with the request switch, Lock Switch   all doors and the liftgate/trunk lid All doors and the liftgate/trunk lid lock will automatically lock if any of the automatically when the lock side is following operations are not performed...
Page 94 Before Driving Doors and Locks Auto Lock/Unlock Function NOTE Function number 3 in the following        table is the factory setting for your WARNING vehicle. There are only a total of ﬁ ve auto lock/ Do not pull the inner handle on a front ...
Page 95 Press 3 times *1 Other settings for the auto door lock function are Wait for 3 second available at an Authorized Mazda Dealer. For Function Number 3 details consult an Authorized Mazda Dealer. Refer to Personalization Features on page 9-12 .
Page 96 Before Driving Doors and Locks NOTE Operation from outside The doors cannot be locked or unlocked To lock the rear and front passenger        while the setting function is being doors with the door-lock knob from the performed.
Page 97 Before Driving Doors and Locks Rear Door Child Safety Locks Liftgate/Trunk Lid These locks are intended to help prevent children from accidentally opening the WARNING rear doors. Use them on both rear doors Never allow a person to ride in the whenever a child rides in the rear seat of luggage compartment/trunk: the vehicle.
Page 98: Trunk Lid
      Do not modify or replace the liftgate damper stay. Consult an Authorized Mazda Dealer if a liftgate damper stay is deformed or damaged for reasons such as a collision or if there is some other problem.
Page 99 Before Driving Doors and Locks NOTE Opening the trunk lid (4–door) (With the advanced keyless function) Using the remote release button A locked liftgate can also be opened        Push the release button. while the key is being carried. When opening the liftgate with the ...
Page 100 Before Driving Doors and Locks NOTE Closing the liftgate/trunk lid When opening the trunk lid with the Lower the liftgate/trunk lid slowly using        doors locked, it may require a few the liftgate/trunk lid grip recess, then push seconds for the trunk lid latch to release the liftgate/trunk lid closed using both after the electric trunk lid opener is...
Page 101 Before Driving Doors and Locks Luggage Compartment The luggage compartment can be accessed by opening the liftgate when the straps are attached to the sides of the liftgate. Luggage compartment cover (5-door) WARNING Do not place anything on top of the cover: Placing luggage or other cargo on top of the luggage compartment cover is...
Page 102 Before Driving Doors and Locks Inside Trunk Release WARNING Lever (4-Door) Close the trunk lid, be sure the seat Your vehicle is equipped with an inside backs are latched and do not allow trunk release lever that provides a means children to play inside the vehicle: of escape for children and adults in the Leaving the trunk lid open or leaving...
Page 103 Before Driving Doors and Locks Opening the Trunk Lid from the Inside Slide the inside trunk release lever in the direction of the arrow. The lever is made of material that will glow for hours in the darkness of the trunk following a brief exposure to ambient light.
Page 104: Fuel Requirements
       Never add fuel system additives, otherwise the emission control system could be damaged. Consult an Authorized Mazda Dealer for details. Gasoline blended with oxygenates such as alcohol or ether compounds are generally referred to as oxygenated fuels. The common gasoline blend that can be used with your vehicle is ethanol blended at no more than 10 %.
Page 105: Emission Control System
       USE ONLY UNLEADED FUEL.        Do not drive your Mazda with any sign of engine malfunction.        Do not coast with the ignition switched off .
Page 106 When inhaled, it can cause loss of consciousness and death. If you smell exhaust gas inside the vehicle, keep all windows fully open and contact an Authorized Mazda Dealer immediately. Do not run the engine when inside an enclosed area: Running the engine inside an enclosed area, such as a garage, is dangerous.
Page 107 Fuel-Filler Lid and Cap CAUTION (U.S.A. and Canada) WARNING Always use only a genuine Mazda fuel- When removing the fuel-fi ller cap, fi ller cap or an approved equivalent, loosen the cap slightly and wait for any available at an Authorized Mazda hissing to stop, then remove it: Dealer.
Page 108 Before Driving Fuel and Emission Fuel-Filler Cap To remove the fuel-ﬁ ller cap, turn it counterclockwise. Attach the removed cap to the inner side of the fuel lid. To close the fuel-ﬁ ller cap, turn it clockwise until a click is heard. Open Close CAUTION...
Page 109: Steering Wheel
Before Driving Steering Wheel Steering Wheel Heated Steering Wheel The grips on the left and right of the steering wheel can be warmed up. WARNING Heated steering Never adjust the steering wheel while Heating area wheel switch the vehicle is moving: Adjusting the steering wheel while the vehicle is moving is dangerous.
Page 110: Outside Mirrors
Before Driving Mirrors Mirrors 2. Press the mirror switch in the appropriate direction. Before driving, adjust the inside and outside mirrors. Center position Mirror switch Outside Mirrors WARNING Be sure to look over your shoulder before changing lanes: Changing lanes without taking into account the actual distance of the vehicle in the convex mirror is dangerous.
Page 111: Rearview Mirror
Before Driving Mirrors Rearview Mirror Reducing glare from headlights Manual day/night mirror WARNING Push the day/night lever forward for day Do not stack cargo or objects higher driving. Pull it back to reduce glare of than the seatbacks: headlights from vehicles at the rear. Cargo stacked higher than the seatbacks is dangerous.
Page 112 Before Driving Mirrors (Without Homelink wireless control NOTE system) Do not use glass cleaner or suspend        Press the ON/OFF button to cancel the objects on or around the light sensor. auto-dimming function. The indicator light Otherwise, light sensor sensitivity will turn off.
Page 113 Before Driving Windows Power Windows NOTE A power window may no longer open/     The ignition must be switched ON for the close if you continue to press the switch power windows to operate. after fully opening/closing the power window.
Page 114 Before Driving Windows Auto-opening/closing WARNING To fully open the window automatically, press the switch completely down, then Make sure nothing blocks the window release. The window will fully open just before it reaches the fully closed automatically. position or while holding up the power To fully close the window automatically, window switch: pull the switch completely up, then...
Page 115: Power Window Lock Switch
Before Driving Windows Operating the Passenger Power Power Window Lock Switch Windows This feature prevents all power windows To open the window to the desired from operating, except the driver's power position, hold down the switch. window. Keep this switch in the locked To close the window to the desired position while children are in the vehicle.
Page 116: Tilt Operation
ON. After washing your Mazda or after it rains, wipe the water off the moonroof before Tilt/Slide switch operating it to avoid water penetration which could cause rust and water damage to your headliner.
Page 117 Before Driving Windows Slide Operation Sunshade To fully open automatically, momentarily The sunshade can be opened and closed press the tilt/slide switch in the backward by hand. direction. To stop sliding partway, press the tilt/slide The sunshade opens automatically when switch.
Page 118: Security System
Immobilizer System Equipment The immobilizer system allows the engine to start only with a key the system Mazda cannot guarantee the immobilizer recognizes. and the theft-deterrent systems' operation if the system has been modiﬁ ed or if any If someone attempts to start the engine add-on equipment has been installed.
Page 119        is lost. If a key is lost, consult an Authorized Mazda Dealer as soon as possible. If you lose a key, an Authorized Mazda        Disarming Dealer will reset the electronic codes of...
Page 120 Before Driving Security System Theft-Deterrent System NOTE If the battery goes dead while the theft- If the theft-deterrent system detects an deterrent system is armed, the horn will inappropriate entry into the vehicle, activate and the hazard warning lights which could result in the vehicle or its will ﬂ...
Page 121 Before Driving Security System To Stop the Alarm NOTE The theft-deterrent system can also be        A triggered alarm can be turned off using armed by activating the auto relock any one of the following methods: function with all the doors, the liftgate/ Pressing the unlock button on the trunk lid and the hood closed.
Page 122: Driving Tips
Environment (600 miles) may add to the performance, economy, and life of the vehicle. How you operate your Mazda determines how far it will travel on a tank of fuel. Use Do not race the engine.       ...
Page 123 Driving Tips Hazardous Driving Floor Mat We recommend the use of Genuine WARNING Mazda ﬂ oor mats. Be extremely careful if it is necessary to WARNING downshift on slippery surfaces: Downshifting into lower gear Make sure the fl oor mats are secured...
Page 124 Before Driving Driving Tips Rocking the Vehicle Do not install two fl oor mats, one on top of the other, on the driver's side: Installing two fl oor mats, one on top WARNING of the other, on the driver's side is dangerous as the retention pins can Do not spin the wheels at more than only keep one fl oor mat from sliding...
Page 125 P with an automatic transaxle and to sand or salt. 1 or R with a manual transaxle. Block Ask an Authorized Mazda Dealer to check the rear wheels. the following: Remove snow before driving. Snow left ...
Page 126: Tire Chains
       Do not use chains on a temporary spare covered roads, Mazda recommends that tire; it may result in damage to the you replace the tires originally equipped vehicle and to the tire.
Page 127 Do not drive the vehicle on fl ooded roads as it could cause short circuiting of electrical/electronic parts, or engine damage or stalling from water absorption. If the vehicle has been immersed in water, consult an Authorized Mazda Dealer. 3–51...
Page 128 Before Driving Driving Tips Driving on Uneven Road Your vehicle's suspension and underbody can be damaged if driven on rough/uneven roads or over speed bumps at excessive speeds. Use care and reduce speed when traveling on rough/uneven roads or over speed bumps. Use care not to damage the vehicle's underbody, bumpers or mufﬂ...
Page 129 Before Driving Towing Trailer Towing Recreational Towing Your Mazda is not designed for towing. An example of "recreational towing" is Never tow a trailer with your Mazda. towing your vehicle behind a motorhome. The transaxle is not designed for towing this vehicle on all 4 wheels.
Page 130 MEMO 3–54...
Page 131 When Driving Information concerning safe driving and stopping. Start/Stop Engine ........ 4-4 Brake ..........4-61 Ignition Switch ....... 4-4 Brake System ....... 4-61 Starting the Engine ......4-5 Hill Launch Assist (HLA) .... 4-67 Turning the Engine Off ....4-10 ABS/TCS/DSC ........
Page 132 .......... 4-94 Distance Recognition Support System (DRSS) ......4-101 Rear Cross Trafﬁ c Alert (RCTA) ........4-103 Mazda Radar Cruise Control (MRCC) ........4-107 Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) ........4-117 Smart City Brake Support (SCBS) ........
Page 133 MEMO 4–3...
Page 134: When Driving
When Driving Start/Stop Engine Ignition Switch The power supply to electrical devices turns off and the push button start indicator Push Button Start Positions light (amber) also turns off. The system operates only when the key is within operational range. WARNING Each time the push button start is pressed, Before leaving the driver's seat, always...
Page 135 ON, the sound of the fuel pump motor the engine by carrying the key. Consult operating near the fuel tank can be heard. an Authorized Mazda Dealer for details. This does not indicate an abnormality. If the push button start system functions...
Page 136 When Driving Start/Stop Engine 1. Make sure you are carrying the key. 6. Verify that the KEY indicator light 2. Occupants should fasten their seat (green) in the instrument cluster and the belts. push button start indicator light (green) 3. Make sure the parking brake is on. illuminate.
Page 137 ON. Have your vehicle inspected at an The key is placed in areas where it is        Authorized Mazda Dealer as soon as difﬁ cult for the system to detect the possible. signal (page 3-8 ).
Page 138 Starting a Flooded Engine under Emergency Starting. If the engine still does not start, have your vehicle inspected by an Authorized Mazda Dealer (page 7-19 ).        Devices for electronic purchases, or security passage touch or come near the key.
Page 139 In this case, the engine may start, ﬁ rmly until the engine has completely however, have the vehicle checked at an started. Authorized Mazda Dealer as soon as 3. Verify that the push button start possible. indication light (green) ﬂ ashes.
Page 140 Stopping the engine while the vehicle starting method. Have your vehicle is moving for any reason other than in inspected at an Authorized Mazda Dealer an emergency is dangerous. Stopping as soon as possible. If this occurs, the the engine while the vehicle is moving engine can be force-started.
Page 141: Emergency Engine Stop
When Driving Start/Stop Engine NOTE The cooling fan in the engine        compartment could turn on for a few minutes after the ignition is switched from ON to OFF, whether or not the A/C is on or off, to cool the engine compartment quickly.
Page 142 When Driving Instrument Cluster and Display Meters and Gauges Instrument Cluster Type A (Digital Speed Meter Type) Type B (Analog Speed Meter Type (With Tachometer)) Type C (Analog Speed Meter Type (Without Tachometer)) Steering Switch Some models. 4–12...
Page 143 When Driving Instrument Cluster and Display Speedometer ......................page 4-14 Odometer, Trip Meter and Trip Meter Selector ............ page 4-14 Tachometer ......................page 4-16 Fuel Gauge ......................page 4-17 Dashboard Illumination..................page 4-18 Outside Temperature Display ................page 4-19 Cruise Control Set Vehicle Speed Display ............page 4-19 Active Driving Display ..................
Page 144: Instrument Cluster
When Driving Instrument Cluster and Display Speedometer Odometer, Trip Meter and Trip Meter Selector The speedometer indicates the speed of the vehicle. The display mode can be changed from odometer to trip meter A to trip meter B Speed Unit Selector (Type A and then back to odometer by pressing the Instrument Cluster) selector while one of them is displayed.
Page 145 When Driving Instrument Cluster and Display Type C Odometer The odometer records the total distance the vehicle has been driven. Selector Trip meter The trip meter can record the total distance of two trips. One is recorded in trip meter A, and the other is recorded in trip meter For instance, trip meter A can record the distance from the point of origin, and...
Page 146 When Driving Instrument Cluster and Display Tachometer NOTE (Vehicles with type B audio)        The tachometer shows engine speed in If the fuel economy data is reset using   thousands of revolutions per minute (rpm). the fuel economy monitor, or trip A is reset using the trip meter when the CAUTION...
Page 147 When Driving Instrument Cluster and Display Fuel Gauge NOTE After refueling, it may require some        The fuel gauge shows approximately time for the indicator to stabilize. In how much fuel is remaining in the tank addition, the indicator may deviate when the ignition is switched ON.
Page 148 When Driving Instrument Cluster and Display Dashboard Illumination Function for cancelling illumination dimmer When the position lights are turned The illumination dimmer can be canceled on with the ignition switched ON, by rotating the dashboard illumination the brightness of the instrument panel knob to the right until a beep sound is illumination is dimmed.
Page 149 Current fuel economy mode        Average vehicle speed    If you have any problems with your trip computer, consult an Authorized Mazda Dealer. Distance-to-empty mode NOTE This mode displays the approximate Under the following conditions, the...
Page 150 When Driving Instrument Cluster and Display NOTE Current fuel economy mode Even though the distance-to-empty This mode displays the current fuel        display may indicate a sufﬁ cient amount economy by calculating the amount of fuel of remaining driving distance before consumption and the distance traveled.
Page 151 When Driving Instrument Cluster and Display Active Driving Display Combiner Mirror Optical receiver WARNING Always adjust the display brightness and position with the vehicle stopped: Adjusting the display brightness and position while driving the vehicle is dangerous as doing so could distract your attention from the road ahead and lead to an accident. CAUTION ...
Page 152 Mazda Radar Cruise Control (MRCC) Operation Conditions and Warnings        Refer to Mazda Radar Cruise Control (MRCC) on page 4-107 .   Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) Operation ...
Page 153 When Driving Instrument Cluster and Display Warning/Indicator Lights Instrument Cluster varies depending on model and speciﬁ cations. Instrument Cluster Type A (Digital Speed Meter Type) Type B (Analog Speed Meter Type (With Tachometer)) Type C (Analog Speed Meter Type (Without Tachometer)) Center of Dashboard Warning/Indicator lights will appear in any of the highlighted areas 4–23...
Page 154: Warning Lights
When Driving Instrument Cluster and Display Warning Lights These lights turn on or ﬂ ash to notify the user of the system operation status or a system malfunction. Signal Warning Page Brake System Warning Light 7-26 *1*2 Electronic Brake Force Distribution ABS Warning Light System Warning...
Page 155 Except malfunction (Red) 7-33 High Beam Control System (HBC) Warning Light 7-29 (Amber) Mazda Radar Cruise Control (MRCC) Warning Light 7-29 (Amber) Lane-keep Assist System (LAS) & Lane Departure Warning System 7-29 (LDWS) Warning Light LED Headlight Warning Light 7-29...
Page 156: Indicator Lights
When Driving Instrument Cluster and Display Indicator Lights These lights turn on or ﬂ ash to notify the user of the system operation status or a system malfunction. Signal Indicator Lights Page Blind Spot Monitoring (BSM) OFF Indicator Light 4-93 Lane-keep Assist System (LAS) &...
Page 157 DSC OFF Indicator Light 4-71 Select Mode Indicator Light 4-79 High Beam Control System (HBC) Indicator Light 4-87 (Green) Mazda Radar Cruise Control (MRCC) Indicator Light 4-110 (Green) Smart City Brake Support (SCBS) 4-131 Smart Brake Support/Smart City Brake Support (SBS/SCBS) Indicator...
Page 158 If the low engine coolant temperature indicator light remains illuminated after the engine has been sufﬁ ciently warmed up, the temperature sensor could have a malfunction. Consult an Authorized Mazda Dealer. 4–28...
Page 159: Manual Transaxle Operation
When Driving Manual Transaxle Operation Manual Transaxle Shift WARNING Pattern Do not use sudden engine braking on slippery road surfaces or at high speeds: Shifting down while driving on wet, snowy, or frozen roads, or while driving at high speeds causes sudden engine braking, which is dangerous.
Page 160 *1 To determine which instrument by the driver before shifting. cluster is equipped on your Mazda, Refer to Meters and Gauges on page 4-12 . NOTE The Gear Shift Indicator (GSI) turns If shifting to R is difﬁ...
Page 161 3 to 4 60 km/h (37 mph) 4 to 5 75 km/h (46 mph) 5 to 6 79 km/h (49 mph) For cruising, Mazda recommends these shift points: (U.S.A. and Canada) Gear Vehicle speed 1 to 2 13 km/h (8 mph)
Page 162: Automatic Transaxle
When Driving Automatic Transaxle Automatic Transaxle Controls Lock-release button Various Lockouts: Indicates that you must depress the brake pedal and hold in the lock-release button to shift (The ignition must be switched ON). Indicates the selector lever can be shifted freely into any position. Indicates that you must hold in the lock-release button to shift.
Page 163        if the selector lever is not in P. 3. Press and hold the lock-release button. 4. Move the selector lever. Take the vehicle to an Authorized Mazda Dealer to have the system checked. 4–33...
Page 164 When Driving Automatic Transaxle Transaxle Ranges WARNING The shift position indicator light in the                  If the engine is running faster than idle, instrument cluster illuminates. Refer do not shift from N or P into a driving to Warning/Indicator Lights on page gear:...
Page 165 When Driving Automatic Transaxle Shift Position Indication Manual Shift Mode The manual shift mode gives you the feel of driving a manual transaxle vehicle by allowing you to operate the selector lever manually. This allows you to control engine rpm and torque to the drive wheels much like a manual transaxle when more The selector position is indicated when the control is desired.
Page 166 When Driving Automatic Transaxle Indicators Type C Manual shift mode indication In manual shift mode, the “M” of the shift position indication in the instrument panel illuminates. Gear position indication The numeral for the selected gear illuminates. Gear position indication Type A Manual shift mode indication NOTE...
Page 167 When Driving Automatic Transaxle Manually Shifting Up WARNING You can shift gears up by operating Keep your hands on the steering wheel the selector lever or the steering shift rim when using fi ngers on the steering switches shift switches: M1 →...
Page 168 When Driving Automatic Transaxle Manually Shifting Down WARNING You can shift gears down by operating Do not use engine braking on slippery the selector lever or the steering shift road surfaces or at high speeds: switches Shifting down while driving on wet, M6 →...
Page 169 When Driving Automatic Transaxle Shift Gear (Shifting) Speed Limit For each gear position while in the manual mode, the speed limit is set as follows: When the selector lever is operated within the range of the speed limit, the gear is shifted. Shift up The gear does not shift up while the vehicle speed is lower than the speed limit.
Page 170 When Driving Automatic Transaxle Recommendations for Shifting Upshifting For normal acceleration and cruising, Mazda recommends these shift points: (U.S.A. and Canada) Gear Vehicle speed M1 to M2 24 km/h (15 mph) M2 to M3 40 km/h (25 mph) M3 to M4...
Page 171 When Driving Automatic Transaxle Direct Mode Type B Direct mode can be used for temporarily switching gears by operating the steering shift switch while the vehicle is being driven with the selector lever in the D range. While in direct mode, the D and M indication illuminate and the gear position in use is illuminated.
Page 172 When Driving Automatic Transaxle Driving Tips Climbing steep grades from a stop To climb a steep grade from a stopped position: WARNING 1. Depress the brake pedal. Do not let the vehicle move in a 2. Shift to D or M1, depending on the direction opposite to the direction load weight and grade steepness.
Page 173 When Driving Switches and Controls Lighting Control Headlights Turn the headlight switch to turn the headlights and other exterior lights on or off. When the lights are turned on, the lights-on indicator light in the instrument cluster turns on. NOTE If the light switch is left on, the lights will automatically switch off approximately 30 ...
Page 174 When Driving Switches and Controls With auto-light control Switch Position Ignition Position or OFF or OFF or OFF or OFF Headlights Auto Auto Daytime running lights Taillights Parking lights Auto Auto License lights Side-marker lights *1 The lights are turned on while the vehicle is driven. *2 The lights are turned on by the auto light function.
Page 175 When Driving Switches and Controls Auto-light control When the headlight switch is in the position and the ignition is switched ON, the light sensor senses the surrounding lightness or darkness and automatically turns the headlights and other exterior lights on or off. CAUTION ...
Page 176 When Driving Switches and Controls Headlight High-Low Beam Flashing the Headlights The headlights switch between high and To ﬂ ash the headlights, pull the lever fully low beams by moving the lever forward or towards you (the headlight switch does not backward.
Page 177 When Driving Switches and Controls Coming Home Light Leaving Home Light The coming home light turns on the The leaving home light turns on the lights headlights (low beams) when the lever is when the transmitter unlock button is operated. pressed while away from the vehicle.
Page 178: Daytime Running Lights
When Driving Switches and Controls Headlight Leveling Fog Lights The number of passengers and weight of The fog lights can be used when the cargo in the luggage compartment change ignition is switched ON. the angle of the headlights. Use this switch to turn on the fog lights. The fog lights will improve visibility at The angle of the headlights will be night and during foggy conditions.
Page 179 When Driving Switches and Controls Turn and Lane-Change NOTE If an indicator light stays on without        Signals ﬂ ashing or if it ﬂ ashes abnormally, one of the turn signal bulbs may be burned The ignition must be switched ON to use out.
Page 180: Windshield Wipers
OFF, the wipers will operate. If INT ring the wipers do not operate even though the Fast wiper switch is turned to a position other than OFF, consult an Authorized Mazda Dealer as soon as possible. 4–50...
Page 181 When Driving Switches and Controls With auto-wiper control Auto-wiper control When the wiper lever is in the position, the rain sensor senses the amount of rainfall on the windshield and turns the wipers on or off automatically (off— intermittent—low speed—high speed). The sensitivity of the rain sensor can be adjusted by turning the switch on the wiper lever.
Page 182 When Driving Switches and Controls NOTE CAUTION Switching the auto-wiper lever from the        to the position while driving        Do not shade the rain sensor by activates the windshield wipers once, adhering a sticker or a label on the after which they operate according to windshield.
Page 183 If the washer does not work, inspect the Turn the wiper on by turning the rear ﬂ uid level (page 6-29 ). If the ﬂ uid level wiper/washer switch. is normal, consult an Authorized Mazda Dealer. Switch Wiper operation Position...
Page 184 When Driving Switches and Controls Rear Window Defogger Dual-Zone Automatic Climate Control The rear window defogger clears fog from Indicator light the rear window. The ignition must be switched ON to use the defogger. Press the switch to turn on the rear window defogger.
Page 185 When Driving Switches and Controls Mirror Defogger Dual-Zone Automatic Climate Control The mirror defoggers defrost the outside Indicator light mirrors. The mirror defoggers operate in conjunction with the rear window defogger. To turn on the mirror defoggers, switch the ignition ON and press the rear window defogger switch (page 4-54 ).
Page 186 When Driving Switches and Controls Horn Hazard Warning Flasher To sound the horn, press the mark on The hazard warning lights should always the steering wheel. be used when you stop on or near a roadway in an emergency. The hazard warning lights warn other drivers that your vehicle is a trafﬁ...
Page 187 For further information, contact your home. HomeLink at 1-800-355-3515 or www. homelink.com or an Authorized Mazda Dealer. Indicator light Always check the areas surrounding garage doors and gates for people...
Page 188 When Driving Switches and Controls Pre-programming the HomeLink 3. Simultaneously press and hold both System the chosen HomeLink and hand-held transmitter buttons. Do not release the buttons until step 3 has been NOTE completed. It is recommended that a new battery be placed in the hand-held transmitter of the NOTE device being programmed to HomeLink...
Page 189 When Driving Switches and Controls NOTE NOTE To program the remaining two HomeLink To program the remaining two HomeLink buttons, begin with “Programming” — buttons, begin with “Programming” — step 1 step 1 If the indicator light blinks rapidly For questions or comments, please contact for two seconds and then turns HomeLink at www.homelink.com or 1- to a constant light, continue with...
Page 190 When Driving Switches and Controls Operating the HomeLink System Press the programmed HomeLink button to operate a programmed device. The code will continue being transmitted for a maximum of 20 seconds. Reprogramming the HomeLink system To program a device to HomeLink using a HomeLink button previously trained, follow these steps: 1.
Page 191: Foot Brake
When Driving Brake Brake System WARNING Do not coast with the engine stalled or Foot Brake turned off , fi nd a safe place to stop: This vehicle has power-assisted brakes Coasting with the engine stalled or that adjust automatically through normal turned off is dangerous.
Page 192 When Driving Brake Parking Brake CAUTION CAUTION        Do not drive with your foot held on the clutch pedal or brake pedal, or hold Driving with the parking brake on the clutch pedal depressed halfway will cause excessive wear of the brake unnecessarily.
Page 193 When Driving Brake Electric Parking Brake (EPB) Releasing the parking brake Depress the brake pedal and pull the The electric parking brake (EPB) parking brake lever upwards, then press equipment applies the parking brake the release button. While holding the using an electric motor.
Page 194 When Driving Brake NOTE When applying the electric parking brake (EPB) The electric parking brake (EPB)      cannot be applied or released while the The electric parking brake (EPB) can be vehicle battery is dead. applied regardless of the ignition switch An operation sound occurs when position.
Page 195: Warning Light
When Driving Brake When releasing the electric parking electric parking brake (EPB) automatic brake (EPB) release The electric parking brake (EPB) can be If the accelerator pedal is depressed with released while the ignition is switched ON the electric parking brake (EPB) applied or the engine is running.
Page 196 ﬁ rmly. This is a normal effect of When you hear this noise, consult an the brake assist operation and does not Authorized Mazda Dealer as soon as indicate a malfunction. possible. When the brake pedal is depressed ...
Page 197 When Driving Brake Hill Launch Assist (HLA) NOTE Hill Launch Assist (HLA) does not        Hill Launch Assist (HLA) is a function operate on a gentle slope. In addition, which assists the driver in accelerating the gradient of the slope on which the from a stop while on a slope.
Page 198 When Driving ABS/TCS/DSC Antilock Brake System NOTE Braking distances may be longer on        (ABS) loose surfaces (snow or gravel, for example) which usually have a hard The ABS control unit continuously foundation. A vehicle with a normal monitors the speed of each wheel.
Page 199 Refer to Warning Lights on page 4-24 . malfunction and they may not operate correctly. Take your vehicle to an WARNING Authorized Mazda Dealer. Do not rely on the Traction Control System (TCS) as a substitute for safe NOTE driving: In addition to the indicator light ...
Page 200        Use tires of the correct size specifi ed torque in conjunction with systems such for your Mazda on all four wheels. as ABS and TCS to help control side slip       ...
Page 201 OFF switch malfunction detection TCS/DSC is not switched off, take your function operates and the DSC system vehicle to an Authorized Mazda Dealer. activates automatically. The DSC OFF The DSC may have a malfunction. indicator light turns off while the DSC system is operative.
Page 202 When Driving i-ELOOP i-ELOOP i-ELOOP is a regenerative braking system. When you depress the brake pedal or use engine braking, the kinetic energy that occurs is converted to electrical energy by the power generator and the converted electrical energy is stored in the rechargeable battery (capacitor and battery).
Page 203 A difference in the fuel economy may occur depending on how the vehicle's electrical        devices are used. If the capacitor is to be disposed of, always consult an Authorized Mazda Dealer.        For details, go to the following URL.
Page 204 When Driving i-ELOOP i-ELOOP Indicator Light/Control NOTE Status Display The beep will sound if the vehicle is        driven while the i-ELOOP indicator The driver is notiﬁ ed of the i-ELOOP light is ﬂ ashing. In addition, if you power generating status and the vehicle turn the steering wheel while the light conditions by the i-ELOOP indicator light...
Page 205 When Driving Fuel Economy Monitor Fuel Economy Monitor For vehicles with type B audio, the Control Status and Fuel Consumption are switched and displayed by operating each icon in the display. In addition, after completing a trip, the total energy efﬁ ciency to date is displayed in the ending display when the ending display is turned on.
Page 206 When Driving Fuel Economy Monitor Fuel Consumption Display Information regarding the fuel economy is displayed. Indication on display Control status Displays the fuel economy for the past 60 minutes. Displays the fuel economy every minute for the  past 1 to 10 minutes. Displays the fuel economy every 10 minutes for the ...
Page 207 When Driving Fuel Economy Monitor Control Status Display The power generating status is displayed Indication on display Control status Displays the level of electricity generated by regenerative braking. Displays the amount of the electricity stored in the capacitor. Displays the status of the electricity stored in the capacitor and being supplied to the electrical devices (whole vehicle in display is illuminated simultaneously).
Page 208 When the sport mode is selected, driving at higher engine speeds increases and it may        increase fuel consumption. Mazda recommends that you cancel the sport mode on normal driving. Drive mode cannot be switched in the following conditions: ...
Page 209 When Driving Drive Selection Drive Selection Switch Select Mode Indicator Light Press the drive selection switch forward When the sport mode is selected, the (“ ”) to select the sport mode. select mode indicator light turns on in the Pull the drive selection switch back instrument cluster.
Page 210: Power Steering
If the steering feels stiffer than usual   during normal driving or the steering vibrates, consult an Authorized Mazda Dealer. The warning light notiﬁ es the driver        of system abnormalities and operation conditions.
Page 211 Distance Recognition Support System (DRSS) ..............4-101 Rear obstruction detection when leaving a parking space Rear Cross Trafﬁ c Alert (RCTA) ..................4-103 Driver support systems Inter-vehicle distance Mazda Radar Cruise Control (MRCC) ................4-107 Lane departure Lane-keep Assist System (LAS) ..................4-117 4–81...
Page 212 The radar sensor (front) functions by detecting the radio waves reﬂ ected off a vehicle ahead sent from the radar sensor. The following systems also use the radar sensor (front). Mazda Radar Cruise Control (MRCC)       ...
Page 213 When Driving i-ACTIVSENSE Radar sensors (rear) The radar sensors (rear) function by detecting the radio waves reﬂ ected off a vehicle approaching from the rear or an obstruction sent from the radar sensors. The following systems also use the radar sensors (rear). Blind Spot Monitoring (BSM) ...
Page 214 When Driving i-ACTIVSENSE Adaptive Front Lighting System (AFS) The adaptive front lighting system (AFS) automatically adjusts the headlight beams to the left or right in conjunction with the operation of the steering wheel after the headlights have been turned on. 4–84 *Some models.
Page 215 When Driving i-ACTIVSENSE High Beam Control System (HBC) The High Beam Control System (HBC) determines the conditions in front of the vehicle using the Forward Sensing Camera (FSC) while driving in darkness to automatically switch the headlights between high and low beams. Refer to Warning/Indicator Lights on page 4-23 .
Page 216 When Driving i-ACTIVSENSE CAUTION        Do not adjust the vehicle height, modify the headlight units, or remove the camera, otherwise the system will not operate normally.        Do not rely excessively on the High Beam Control System (HBC) and drive the vehicle while paying suffi cient attention to safety.
Page 217 When Driving i-ACTIVSENSE To Operate the System Manual Switching The High Beam Control System (HBC) Switching to low beams operates to switch the headlights Shift the lever to the low beam position. automatically between high and low The High Beam Control System (HBC) beams after the ignition is switched ON indicator light (green) turns off.
Page 218 When Driving i-ACTIVSENSE Blind Spot Monitoring (BSM) The Blind Spot Monitoring (BSM) is designed to assist the driver in checking the area to the rear of the vehicle on both sides during lane changes by notifying the driver of the presence of vehicles approaching from the rear in an adjacent lane.
Page 219 If the Blind Spot Monitoring (BSM) warning indication/warning light remains illuminated, have the vehicle inspected at an Authorized Mazda Dealer as soon as possible. Some problem with the system including the Blind Spot Monitoring (BSM) warning ...
Page 220 When Driving i-ACTIVSENSE In the following case, the ﬂ ashing of the Blind Spot Monitoring (BSM) warning indicator        light, and the activation of the warning sound and the warning screen indicator display may not occur or they may be delayed. A vehicle makes a lane change from a driving lane two lanes over to an adjacent lane.
Page 221 When Driving i-ACTIVSENSE The radar sensors (rear) of the Blind Spot Monitoring (BSM) may be regulated under        the radio wave related laws of the country where the vehicle is driven. The sensors in this system are approved for use in the U.S.A. (including territories), Canada, and Mexico.
Page 222 When Driving i-ACTIVSENSE Forward driving (Blind Spot Monitoring (BSM) operation) The Blind Spot Monitoring (BSM) detects vehicles approaching from the rear and turns on the Blind Spot Monitoring (BSM) warning indicator lights equipped on the door mirrors according to the conditions. Additionally, while a Blind Spot Monitoring (BSM) warning indicator light is illuminated, if the turn signal lever is operated to signal a turn in the direction in which the Blind Spot Monitoring (BSM) warning indicator light is illuminated, the Blind Spot Monitoring (BSM) warning indicator light ﬂ...
Page 223 When Driving i-ACTIVSENSE Canceling Operation of Blind Spot NOTE Monitoring (BSM) When the ignition is switched OFF, the system status before it was turned off is The Blind Spot Monitoring (BSM) maintained. For example, if the ignition and Rear Cross Trafﬁ c Alert (RCTA) is switched OFF while the Blind Spot systems are turned off and the Blind Spot Monitoring (BSM) and Rear Cross Trafﬁ...
Page 224 The Trafﬁ c Sign Recognition System (TSR) operates only if the navigation system SD card        (Mazda genuine) is inserted in the SD card slot. Consult an Authorized Mazda Dealer for details. Speed limit signs and do not enter signs 4–94...
Page 225 When Driving i-ACTIVSENSE Stop sign WARNING Always check the traffi c signs visually while driving. The Traffi c Sign Recognition System (TSR) helps prevent the driver from overlooking traffi c signs and provides support for safer driving. Depending on the weather conditions or problems with traffi c signs, a traffi c sign may not be recognized or a traffi c sign diff erent from the actual traffi c sign may be displayed.
Page 226 When Driving i-ACTIVSENSE NOTE The Trafﬁ c Sign Recognition System (TSR) does not operate if there is a malfunction in        the Forward Sensing Camera (FSC). Under the following conditions, the Trafﬁ c Sign Recognition System (TSR) may not ...
Page 227 When Driving i-ACTIVSENSE Trafﬁ c Sign Display Indication The following trafﬁ c signs are displayed on the active driving display. Speed limit signs Do not enter signs Stop signs The above indications are some examples. 4–97...
Page 228 When Driving i-ACTIVSENSE NOTE Speed limit signs When the vehicle speed is about 1 km/h (0.6 mph) or faster, the speed limit sign is        displayed when any one of the following conditions are met. The Forward Sensing Camera (FSC) recognizes a speed limit sign as a sign targeted ...
Page 229 When Driving i-ACTIVSENSE Stop sign A stop sign is displayed when all of the following conditions are met:        The vehicle speed is about 30 km/h (19 mph) or slower.        The Forward Sensing Camera (FSC) recognizes a stop sign as a sign targeted for your ...
Page 230 When Driving i-ACTIVSENSE NOTE The excessive speed warning is initially set to inoperable. If you want to activate the        excessive speed warning, change the setting in the personalization features. Off: The excessive speed warning is not activated. ...
Page 231 When Driving i-ACTIVSENSE Distance Recognition Support System (DRSS) The Distance Recognition Support System (DRSS) measures the distance between your vehicle and a vehicle ahead using a radar sensor (front) while the vehicle speed is about 30 km/h (19 mph) or faster, and if your vehicle approaches a vehicle ahead more closely than what is appropriate for maintaining distance between the vehicles according to the vehicle speed, a notiﬁ...
Page 232 The Distance Recognition Support System (DRSS) operation status is indicated in the active driving display. Regarding malfunctions, check the vehicle conditions or have it inspected by an Authorized Mazda Dealer according to the content of the displayed message. Refer to Warning/Indicator Lights on page 4-23 .
Page 233 When Driving i-ACTIVSENSE Rear Cross Trafﬁ c Alert (RCTA) The Rear Cross Trafﬁ c Alert (RCTA) system is designed to assist the driver in checking the area to the rear of the vehicle on both sides while the vehicle is reversing by alerting the driver to the presence of vehicles approaching the rear of the vehicle.
Page 234 When Driving i-ACTIVSENSE Rear Cross Trafﬁ c Alert (RCTA) operation 1. The Rear Cross Trafﬁ c Alert (RCTA) system operates when the shift lever (manual transaxle) or the selector lever (automatic transaxle) is shifted to the reverse (R) position. 2. If there is the possibility of a collision with an approaching vehicle, the Blind Spot Monitoring (BSM) warning indicator lights ﬂ...
Page 235 If the Blind Spot Monitoring (BSM) warning indication/warning light remains illuminated, have the vehicle inspected at an Authorized Mazda Dealer as soon as possible. Some problem with the system including the Blind Spot Monitoring (BSM) warning ...
Page 236 When Driving i-ACTIVSENSE Under the following conditions, the radar sensors (rear) cannot detect target objects or it        may be difﬁ cult to detect them. The vehicle speed when reversing is about 15 km/h (9 mph) or faster. ...
Page 237 Do not rely completely on the Mazda Radar Cruise Control (MRCC) system and always drive carefully: The Mazda Radar Cruise Control (MRCC) system is designed to reduce load on the driver, and although it maintains a constant vehicle speed, or specifi cally, it maintains a constant...
Page 238 When Driving i-ACTIVSENSE CAUTION If the vehicle is towed or you are towing something, switch the Mazda Radar Cruise Control (MRCC) system off to prevent an incorrect operation. NOTE The Mazda Radar Cruise Control (MRCC) system operates when all of the following ...
Page 239 While the Mazda Radar Cruise Control (MRCC) system is in use, it does not cancel even    if the selector lever (automatic transaxle)/shift lever (manual transaxle) is operated and any intended engine braking will not occur.
Page 240 NOTE When the ignition is switched to ACC or OFF while the Mazda Radar Cruise Control        (MRCC) is ON, the Mazda Radar Cruise Control (MRCC) remains ON automatically.
Page 241 When Driving i-ACTIVSENSE NOTE If a vehicle ahead is detected while traveling at a constant speed, the vehicle-ahead        indication is displayed and headway control is performed. Additionally, when a vehicle ahead is no longer detected, the vehicle-ahead indication turns off and the system switches back to travel at constant speed.
Page 242 When the system is temporarily accelerator pedal. canceled In the following cases, the Mazda Radar CAUTION Cruise Control (MRCC) is temporarily canceled, the Mazda Radar Cruise Control The warnings and brake control do not...
Page 243 . of the radiator grille is dirty. If you have temporarily canceled the        In the following cases, the “Mazda    Mazda Radar Cruise Control (MRCC), Radar Cruise Control Canceled” you can return to your previously set...
Page 244 If the gears are not shifted up even though the shift-up request indication is displayed,        load will be applied to the engine and the Mazda Radar Cruise Control (MRCC) system may be automatically canceled or engine damage could occur.
Page 245 Switching to cruise control function When the MODE switch is pressed while While this function is operating, the the Mazda Radar Cruise Control (MRCC) headway control operation is canceled and system is turned on, the system switches to only the cruise control function operates.
Page 246 When Driving i-ACTIVSENSE How to increase the set speed Cancelling using MODE switch The set speed can be increased using the When the MODE switch is pressed, the following operations: cruise control function is canceled and the headway control function is made To increase speed using the SET available for operation.
Page 247 When Driving i-ACTIVSENSE Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) The Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) alerts the driver that the vehicle may be deviating from its lane and it provides steering assistance to help the driver stay within the vehicle lanes.
Page 248        Always use wheels of the specifi ed type and size for the front and rear wheels. Consult an Authorized Mazda Dealer for tire replacement. NOTE When the turn signal lever is operated for a lane change, the Lane-keep Assist System ...
Page 249 When Driving i-ACTIVSENSE If the steering wheel, accelerator pedal, or brake pedal is operated abruptly and the vehicle        moves close to a white (yellow) line, the system determines that the driver is making a lane change and the Lane-keep Assist System (LAS) &...
Page 250: System Operation
When Driving i-ACTIVSENSE System Operation If the Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) OFF indicator light in the instrument cluster turns off when the ignition is switched ON, the system goes on standby. If the Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) OFF indicator light in the instrument cluster turns on when the ignition is switched ON, press the Lane-keep Assist System (LAS) &...
Page 251 When Driving i-ACTIVSENSE The Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) goes on stand-by status in the following cases: The system cannot detect white (yellow) lane lines.        The vehicle speed is less than about 60 km/h (37 mph). ...
Page 252 When Driving i-ACTIVSENSE Vehicle lane line display When the Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) detects white (yellow) lines on both the left and right sides and becomes operational, the vehicle lane lines are indicated in the active driving display. Auto cancel In the following cases, the Lane-keep Assist System (LAS) &...
Page 253 When Driving i-ACTIVSENSE NOTE After the operation, the Lane-keep Assist System (LAS) & Lane Departure Warning        System (LDWS) operation may not operate for a period of 5 seconds at the most until the lane lines are detected.
Page 254 When Driving i-ACTIVSENSE Drive the vehicle in the center of the vehicle lane while the system is on standby. The system becomes operational when all of the following conditions are met. The system detects white (yellow) lane lines on both the right and left sides, or on either ...
Page 255 Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) OFF indicator light turns on. Have your vehicle inspected at an Authorized Mazda Dealer. There is a malfunction in the power       ...
Page 256 When Driving i-ACTIVSENSE Lane Departure Warning If the system determines that the vehicle may deviate from its lane, the lane departure warning (beep sound, rumble sound , or steering wheel vibration) is activated and the direction in which the system determines that the vehicle may deviate is indicated in the active driving display.
Page 257 When Driving i-ACTIVSENSE NOTE If you have set the lane departure warning sound to the beep sound/rumble sound        setting, the warning sound may not be heard depending on the surrounding noise conditions. If you have set the lane departure warning system to the steering wheel vibrations setting, ...
Page 258 When Driving i-ACTIVSENSE Smart City Brake Support (SCBS) The Smart City Brake Support (SCBS) system alerts the driver of a possible collision using an indication in the display and a warning sound when the Forward Sensing Camera (FSC) detects a vehicle ahead and determines that a collision with a vehicle ahead is unavoidable while the vehicle is being driven at a vehicle speed of about 4 to 80 km/h (2 to 50 mph).
Page 259 When Driving i-ACTIVSENSE WARNING Do not rely completely on the Smart City Brake Support (SCBS) system:        The Smart City Brake Support (SCBS) system is only designed to reduce damage in the event of a collision. Over reliance on the system leading to the accelerator pedal or brake pedal being mistakenly operated could result in an accident.
Page 260 When Driving i-ACTIVSENSE NOTE The Smart City Brake Support (SCBS) system will operate under the following conditions.        The engine is running.        The Smart Brake Support/Smart City Brake Support (SBS/SCBS) system warning light ...
Page 261   the collision warning can be changed. When the Smart City Brake Support Consult an Authorized Mazda Dealer. (SCBS) system is turned off, the Smart City Brake Support (SCBS) OFF indicator light turns on.
Page 262 When Driving i-ACTIVSENSE Without SCBS OFF switch Refer to Personalization Features on page 9-12 . NOTE When the Smart City Brake Support (SCBS) system is set to inoperable, the Smart Brake Support (SBS) are also set to inoperable. With SCBS OFF switch Press the SCBS OFF switch to turn off the system.
Page 263 When Driving i-ACTIVSENSE Smart Brake Support (SBS) The Smart Brake Support (SBS) system alerts the driver of a possible collision using a display and warning sound if the radar sensor (front) and the Forward Sensing Camera (FSC) determine that there is the possibility of a collision with a vehicle ahead while the vehicle is being driven at about 15 km/h or faster (10 mph or faster).
Page 264 When Driving i-ACTIVSENSE NOTE The Smart Brake Support (SBS) system operates when all of the following conditions are        met: The ignition is switched ON.        The Smart Brake Support (SBS) system is on. ...
Page 265 When Driving i-ACTIVSENSE Smart Brake Support (SBS) NOTE Indicator Light (Red) If the Smart Brake Support (SBS) system operation is turned off, the Smart City If the Smart Brake Support (SBS) is Brake Support (SCBS) system operation is operating, the indicator light (red) ﬂ ashes. turned off simultaneously.
Page 266 When Driving i-ACTIVSENSE Forward Sensing Camera (FSC) Your vehicle is equipped with a Forward Sensing Camera (FSC). The Forward Sensing Camera (FSC) is positioned near the rearview mirror and used by the following systems. High Beam Control System (HBC)        Lane-keep Assist System (LAS) &...
Page 267 Use the windshield defroster to remove fogging on the windshield.        Consult an Authorized Mazda Dealer regarding cleaning the interior side of the windshield around the Forward Sensing Camera (FSC).       ...
Page 268 When Driving i-ACTIVSENSE NOTE In the following cases, the Forward Sensing Camera (FSC) cannot detect target objects        correctly, and each system may be unable to operate normally. The height of the vehicle ahead is low. ...
Page 269 When Driving i-ACTIVSENSE In the following cases, the Forward Sensing Camera (FSC) may not be able to detect        target objects correctly. Under bad weather condition, such as rain, fog and snow.        The window washer is being used or the windshield wipers are not used when it's ...
Page 270        If there are recognizable cracks or damage caused by ﬂ ying gravel or debris on the     windshield, always have the windshield replaced. Consult an Authorized Mazda Dealer for replacement. 4–140...
Page 271 The following systems also use the radar sensor (front). Distance Recognition Support System (DRSS)        Mazda Radar Cruise Control (MRCC)        Smart Brake Support (SBS)       ...
Page 272 If the front part of the vehicle has been damaged in a vehicle accident, the position of the radar sensor (front) may have moved. Stop the system immediately and always have the vehicle inspected at an Authorized Mazda Dealer.       ...
Page 273 When Driving i-ACTIVSENSE NOTE Under the following conditions, the radar sensor (front) may not be able to detect        vehicles ahead or obstructions correctly and each system may not operate normally. The rear surface of a vehicle ahead does not reﬂ ect radio waves effectively, such as ...
Page 274 (rear) operate normally. Also, do not apply items such as stickers. Refer to Exterior Care on page 6-65 . CAUTION If the rear bumper receives a severe impact, the system may no longer operate normally. Stop the system immediately and have the vehicle inspected at an Authorized Mazda Dealer. 4–144...
Page 275 For repairs or replacement of the radar sensors (rear), or bumper repairs, paintwork,        and replacement near the radar sensors, consult an Authorized Mazda Dealer. Turn off the system while pulling a trailer or while an accessory such as a bicycle carrier ...
Page 276: Cruise Control
RES/+ switch OFF/CAN SET- switch switch NOTE If your Mazda has the following steering switch, your Mazda is equipped with the Mazda Radar Cruise Control (MRCC) system. Refer to Mazda Radar Cruise Control (MRCC) on page 4-107 . switch SET+ switch...
Page 277 When Driving Cruise Control Cruise Main Indication (White), Activation/Deactivation Cruise Set Indication (white)/ To activate the system, press the ON Indicator Light (Green) switch. The cruise main indication (white) is displayed. Cruise main indication (white) To deactivate the system, press the OFF/ The cruise main indication (white) is CAN switch.
Page 278 When Driving Cruise Control To Set Speed NOTE The cruise control speed setting cannot        1. Activate the cruise control system by be performed under the following pressing the ON switch. The cruise conditions: main indication (white) is displayed.
Page 279 When Driving Cruise Control To Increase Cruising Speed To Decrease Cruising Speed Follow either of these procedures. Press the SET switch and hold it. The vehicle will gradually slow. To increase speed using cruise control Release the switch at the desired speed. switch Press the RES / switch and hold it.
Page 280 When Driving Cruise Control NOTE If any of the following conditions occur,        the cruise control system is temporarily canceled. The parking brake is applied.        (Automatic transaxle) ...
Page 281: Tire Pressure Monitoring System
When Driving Tire Pressure Monitoring System Tire Pressure Monitoring System The Tire Pressure Monitoring System (TPMS) monitors the air pressure of all four tires. If the air pressure of one or more tires is too low, the system warns the driver by indicating the tire pressure monitoring system warning light in the instrument cluster and operating a beep sound.
Page 282 When Driving Tire Pressure Monitoring System CAUTION        Each tire, including the spare (if provided), should be checked monthly when cold and infl ated to the infl ation pressure recommended by the vehicle manufacturer on the vehicle placard or tire infl ation pressure label.
Page 283 When Driving Tire Pressure Monitoring System NOTE Because this system detects slight changes in tire conditions, the timing of the warning may be faster or slower in the following cases: The size, manufacturer, or the type of tires is different from the speciﬁ cation. ...
Page 284 When Driving Tire Pressure Monitoring System Tire Pressure Monitoring System CAUTION Initialization In the following cases, system If the system initialization is performed initialization must be performed so that the without adjusting the tire pressure, system operates normally. the system cannot detect the normal tire pressure and it may not illuminate A tire pressure is adjusted.
Page 285: Rear View Monitor
When Driving Rear View Monitor Rear View Monitor The rear view monitor provides visual images of the rear of the vehicle when reversing. WARNING Always drive carefully confi rming the safety of the rear and the surrounding conditions by looking directly with your eyes: Reversing the vehicle by only looking at the screen is dangerous as it may cause an accident or a collision with an object.
Page 286: Rear View Parking Camera Location
       monitor may not operate correctly. When replacing the tires, consult an Authorized Mazda Dealer. Replacing the tires could        result in deviation of the guide lines which appear on the display.
Page 287 When Driving Rear View Monitor Displayable Range on the Screen The images on the screen may be different from the actual conditions. (Screen display) Trunk lid (sedan)/ Obstruction detection garnish (hatchback) indication in parking sensor system. Bumper (Actual view) Object Some models NOTE The displayable range varies depending on the vehicle and road conditions.
Page 288: Rear View Monitor Operation
When Driving Rear View Monitor Viewing the Display Guide lines which indicate the width of the vehicle (yellow) are displayed on the screen as a reference to the approximate width of the vehicle in comparison to the width of the parking space you are about to back into.
Page 289 When Driving Rear View Monitor 1. Shift the shift lever to R to switch the display to the rear view monitor display. 2. Conﬁ rming the surrounding conditions, reverse the vehicle. (Display condition) (Vehicle condition) 3. After your vehicle begins entering the parking space, continue backing up slowly so that the distance between the vehicle width lines and the sides of the parking space on the left and right are roughly equal.
Page 290 When Driving Rear View Monitor NOTE Because there may be a difference between the displayed image, such as indicated below, and the actual conditions when parking, always verify the safety at the rear of the vehicle and the surrounding area directly with your eyes. In the image of the parking space (or garage) displayed on the screen, the back end and ...
Page 291 When Driving Rear View Monitor When there is a steep grade behind the vehicle When there is a steep upgrade (downgrade) behind the vehicle, the object displayed on the screen appears farther (downgrade: closer) than the actual distance. Appears Appears farther than closer than actual...
Page 292 When Driving Rear View Monitor Picture Quality Adjustment WARNING Always adjust the picture quality of the rear view monitor while the vehicle is stopped: Do not adjust the picture quality of the rear view monitor while driving the vehicle. Adjusting the picture quality of the rear view monitor such as brightness, contrast, color, and tint while driving the vehicle is dangerous as it could distract your attention from the vehicle operation which could lead to an accident.
Page 293 Interior Features Use of various features for ride comfort, including air-conditioning and audio system. Climate Control System..............5-2 Operating Tips ................5-2 Vent Operation ................5-3 Manual Climate Control ............... 5-5 Automatic Climate Control ............5-9 Dual-Zone Automatic Climate Control ........5-12 Audio System ..................
Page 294: Interior Features
       For details, consult an Authorized   when driving through tunnels or while in Mazda Dealer. a trafﬁ c jam, or when you would like to shut off outside air for quick cooling of the interior.
Page 295: Vent Operation
Interior Features Climate Control System Vent Operation Adjusting the Vents Directing airﬂ ow To adjust the direction of airﬂ ow, move the adjustment knob. NOTE When using the air conditioner under        humid ambient temperature conditions, the system may blow fog from the vents.
Page 296 Interior Features Climate Control System Selecting the Airﬂ ow Mode Dashboard Vents Defroster and Floor Vents Defroster Vents Dashboard and Floor Vents Floor Vents 5–4...
Page 297: Manual Climate Control
Interior Features Climate Control System Manual Climate Control Temperature control dial Rear window defogger switch Fan control dial Mode selector dial A/C switch Air intake selector Air intake selector (recirculated air (outside air position) position) With A/C switch NOTE Control Switches The mode selector dial can be set at the ...
Page 298 Interior Features Climate Control System Heating Air intake selector This switch controls the source of air 1. Set the mode selector dial to the entering the vehicle. position. 2. Set the air intake selector to the outside Press the air intake selector switch to air position.
Page 299 Interior Features Climate Control System Windshield Defrosting and CAUTION Defogging 1. Set the mode selector dial to the If the air conditioner is used while position. driving up long hills or in heavy 2. Set the temperature control dial to the traffi c, monitor the engine coolant desired position.
Page 300 Interior Features Climate Control System Dehumidifying (With air conditioner) Operate the air conditioner in cool or cold weather to help defog the windshield and side windows. 1. Set the mode selector dial to the desired position. 2. Set the air intake selector to the outside air position.
Page 301: Automatic Climate Control
Interior Features Climate Control System Automatic Climate Control Temperature control dial Fan control dial Mode selector dial A/C switch Air intake selector switch Rear window defogger switch Control Switches AUTO position The airﬂ ow mode automatically adjusts to Temperature control dial the selected temperature.
Page 302 Interior Features Climate Control System A/C switch Rear window defogger switch The air-conditioning (cooling/ Press the rear window defogger switch to dehumidifying functions) can be turned on defrost the rear window. or off by pressing the switch while the fan Refer to Rear Window Defogger on page control dial is at a position other than 0.
Page 303 Interior Features Climate Control System Windshield Defrosting and Sunlight/Temperature Sensor Defogging The climate control system measures Set the mode selector dial to the inside and outside temperatures, and position and turn the fan control dial to the sunlight. It then sets temperatures inside desired speed.
Page 304: Dual-Zone Automatic Climate Control
Interior Features Climate Control System Dual-Zone Automatic Climate Control Climate control information is displayed on the display. Temperature setting display (driver’s side) Windshield defroster switch Driver temperature control dial Rear window defogger switch Air intake selector (recirculated air position) Air intake selector Passenger temperature A/C mode display (outside air position)
Page 305 Interior Features Climate Control System OFF switch Mode selector switch Pressing the OFF switch shuts off the The desired airﬂ ow mode can be selected climate control system. (page 5-4 ). Temperature control dial NOTE This dial controls temperature. Turn it With the airﬂ...
Page 306 Interior Features Climate Control System Air intake selector Windshield defroster switch Outside or recirculated air positions can be Press the switch to defrost the windshield selected. Press the switch to select outside/ and front door windows. recirculated air positions. Refer to Windshield Defrosting and Defogging on page 5-15 .
Page 307 Interior Features Climate Control System Windshield Defrosting and Sunlight/Temperature Sensor Defogging The climate control system measures Press the windshield defroster switch. inside and outside temperatures, and In this position, the outside air position sunlight. It then sets temperatures inside is automatically selected, and the air the passenger compartment accordingly.
Page 308: Audio System
Interior Features Audio System Antenna Antenna (5-Door) AM/FM Radio Antenna Antenna (4-Door) The AM/FM radio antenna receives both AM and FM signals. AM/FM Radio Antenna The AM/FM radio antenna receives both (Type A) AM and FM signals. To remove the antenna, turn it The antenna is embedded into the window counterclockwise.
Page 309: Operating Tips For Audio System
Interior Features Audio System Operating Tips for Audio (Type B) System Antenna WARNING Always adjust the audio while the vehicle is stopped: Do not adjust the audio control switches while driving the vehicle. Adjusting the audio while driving the vehicle is dangerous as it could distract your attention from the vehicle operation which could lead to a Antenna for AM/FM and Satellite Radio...
Page 310: Radio Reception
Interior Features Audio System Do not spill any liquid on the audio FM characteristics system. An FM broadcast range is usually about 40—50 km (25—30 miles) from the source. Because of extra coding needed to break the sound into two channels, stereo FM has even less range than monaural (non-stereo) FM.
Page 311 Interior Features Audio System Multipath noise Weak signal noise Since FM signals can be reﬂ ected by In suburban areas, broadcast signals obstructions, it is possible to receive both become weak because of distance from the the direct signal and the reﬂ ected signal transmitter.
Page 312 Interior Features Audio System Operating Tips for CD Player If the memory portion of the CD is        transparent or translucent, do not use the disc. Condensation phenomenon Immediately after turning on the heater when the vehicle is cold, the CD or optical components (prism and lens) in the CD player may become clouded with...
Page 313 Interior Features Audio System CDs bearing the logo shown in the The CD player ejects the CD if the CD               illustration can be played. No other discs is inserted upside down.
Page 314 Interior Features Audio System Operating Tips for MP3 This audio system handles MP3 ﬁ les        that have been recorded on CD-R/CD- MP3 stands for MPEG Audio Layer 3, RW/CD-ROMs. which is standardized voice compression When naming an MP3 ﬁ...
Page 315 Interior Features Audio System Operating Tips for AAC Operating Tips for OGG AAC stands for Advanced Audio Coding, OGG is the audio compression format for which is standardized voice compression Xiph. Org Foundation. established by the ISO working group Audio data can be created and stored at a (MPEG).
Page 316 Interior Features Audio System Operating Tips for USB device NOTE Playback may not be possible      This unit plays audio ﬁ les as follows: depending on the type and condition of the USB ﬂ ash memory even if the audio Extension Playback with this unit ﬁ...
Page 317        If data in the iPod is lost while it is connected to the unit, Mazda cannot guarantee recovery of any lost data.        If the iPod battery is deteriorated, the...
Page 318: Audio Set [Type A (Non-Touchscreen)]
Interior Features Audio System Audio set [Type A (non-touchscreen)] Power/Volume/Sound Controls ................page 5-28 Clock ........................page 5-30 Operating the Radio ....................page 5-32 How to use Auxiliary jack/USB port ..............page 5-33 5–26...
Page 319 MEMO 5–27...
Page 320: Volume Adjustment
Interior Features Audio System Power/Volume/Sound Controls Audio display Menu button Power/Volume/Audio control dial Power ON/OFF Audio sound adjustment Switch the ignition to ACC or ON. Press 1. Press the menu button ( ) to select the power/volume dial to turn the audio the function.
Page 321 Interior Features Audio System NOTE If not operated for several seconds, the display returns to the previous display. To reset bass, treble, fade, and balance, press the menu button ( ) for 2 seconds. The unit will beep and “ CLEAR ” will be displayed.
Page 322 Interior Features Audio System Clock :00 button Audio control dial Audio display Clock button Menu button Hour/Minute set switch NOTE Setting the time When the :00 button ( 1 ) is pressed, the        The clock can be set at any time when the seconds will start at “...
Page 323 MEMO 5–31...
Page 324 Interior Features Audio System Operating the Radio Audio display Channel preset buttons Tuning button Scan button Auto memory button Band selector button Radio ON Seek tuning Press a band selector button ( ) to Automatic search for radio stations starts turn the radio on.
Page 325 2 seconds until a beep is heard. impedance (3.5 ) stereo mini plug cable. The preset channel number or station Contact an Authorized Mazda Dealer for frequency will be displayed. The details. station is now held in the memory.
Page 326: Audio Set [Type B (Touchscreen)]
Interior Features Audio System Audio set [Type B (touchscreen)] NOTE The explanation of functions described in this manual may differ from the actual operation, and the shapes of screens and buttons and the letters and characters displayed may also differ from the actual appearance. Additionally, depending on future software updates, the content may successively change without notice.
Page 327 Interior Features Audio System Switches around commander knob The following operations can be done by pressing the switches around the commander knob. : Displays the home screen. : Displays the Entertainment screen. : Displays the Navigation screen (Only navigation-equipped vehicles). For operation of the Navigation screen, refer to the navigation system manual.
Page 328 Interior Features Audio System Touch panel operation CAUTION Do not press the screen strongly or press it with a sharp-pointed object. Otherwise, the screen could be damaged. NOTE For safety reasons, operation of the center display is disabled while the vehicle is being driven.
Page 329 Interior Features Audio System SLIDE 1. Touch the setting item displaying a slider bar. 2. Touch the slider with your ﬁ nger and move to the desired level. SWIPE 1. Touch the screen with your ﬁ nger and move up or down. 2.
Page 330 Interior Features Audio System Home screen Icon Function Applications Information such as average fuel economy, maintenance, and warnings can be veriﬁ ed. Depending on the grade and speciﬁ cation, the screen display may differ. Entertainment Operates audio such as the radio and CDs. The audio source most recently used is displayed.
Page 331 MEMO 5–39...
Page 332 Interior Features Audio System Volume/Display/Sound Controls Audio control switch Commander switch Volume dial Volume switch Volume adjustment Daytime/nighttime (System) screen setting Turn the commander switch volume dial. The volume switch on the steering switch The daytime or nighttime screen can be can also be pressed.
Page 333 Interior Features Audio System Audio sound adjustment ALC (Automatic volume adjustment) The automatic level control (ALC) is a Select the icon on the home screen to feature that automatically adjusts audio display the Settings screen. volume and sound quality according to Select the tab to select the item you the vehicle speed.
Page 334 Interior Features Audio System Operating the Radio Radio ON Select the icon on the home screen to display the Entertainment screen. When selecting the desired radio, the following icons are indicated in the lower part of the center display. AM/FM Radio Icon Function Displays the Entertainment menu.
Page 335 Interior Features Audio System Favorites Radio Changing Favorites list order Selected stations can be registered for 1. Select the icon to display the convenient operation. Up to 50 stations Favorites list. can be registered. The Favorites list is 2. Select common to AM, FM, and satellite radio.
Page 336 Interior Features Audio System NOTE HD Radio To change the desired genre, select the What is HD Radio Technology and ™ icon. how does it work? HD Radio Technology is the digital ™ Ex.) evolution of analog AM/FM radio. Your 89.3 is currently being received.
Page 337 Interior Features Audio System NOTE iTunes Tagging (for Apple devices with USB use only) If an analog broadcast is received once        is received while HD1 is By tagging a song currently being aired, selected, the audio unit switches to the the song can later be purchased from station automatically.
Page 338        877-209-0079 (Canada) to activate. For more information, visit www. siriusxm.com (U.S.A.)/www.siriusxm. ca (Canada). Satellite radio is only available in regions providing satellite radio service (some areas of the United States and Canada). Contact Authorized Mazda Dealer for details. 5–46...
Page 339 Interior Features Audio System SiriusXM operation Select the icon on the home screen to display the Entertainment screen. When selected, the following icons are indicated in the bottom part of the center display. Icon Function Displays the Entertainment menu. Use to switch to a different audio source. Displays the channel list of the current category.
Page 340 Interior Features Audio System Selection from channel list PIN code reset Receivable channels can be displayed on If the registered code has been forgotten, the channel list screen. You can easily reset the code to the default [0000] code. select the channel you want to listen 1.
Page 341 MEMO 5–49...
Page 342 Interior Features Audio System Operating the Compact Disc (CD) Player CD eject button CD slot Inserting the CD Type Playable data Insert the CD into the slot, label-side up. Music/MP3/WMA/ Music data (CD-DA)  AAC CD player MP3/WMA/AAC ﬁ le ...
Page 343 Interior Features Audio System Playback Select the icon on the home screen with a CD inserted and display the Entertainment screen. When is selected, the following icons are indicated in the lower part of the center display. Icon Function Displays the Entertainment menu. Use to switch to a different audio source. (Music CD) Displays the track list of the CD.
Page 344 Interior Features Audio System Icon Function Plays a CD. When selected again, playback is temporarily stopped. Advances to the beginning of the next song. Long-press to fast forward. It stops when you remove your hand from the icon or the commander knob.
Page 345 Interior Features Audio System Settings NOTE Depending on the grade and speciﬁ cation, the screen display may differ. Select the icon on the home screen and display the Settings screen. Switch the tab and select the setting item you want to change. You can customize settings in the setup display as follows: Item Function...
Page 346 2. Voice recognition assistance for Play Artist Music Database Update and Play Album System Gracenote can be downloaded from the Mazda Handsfree Website. Refer to Gracenote Database (Type B) on page 5-72 . Memory and settings are initialized to the factory settings.
Page 347: Audio Control Switch Operation
Interior Features Audio System Applications Audio Control Switch Operation NOTE Depending on the grade and speciﬁ cation, the screen display may differ. Select the icon on the home screen to display the Applications screen. The following information can be veriﬁ ed. Top screen Item Function...
Page 348 Interior Features Audio System Seek Switch Pandora /Aha /Stitcher Radio ® ™ ™ Press the seek switch ( ) to skip forward AM/FM radio to the beginning of the next track. Press and hold the seek switch ( ) to Press the seek switch ( , ).
Page 349: Aux/Usb Mode
Type B (Without CD player) (Type B) The SD card slot is for the navigation system. For vehicles with the navigation system, the SD card (Mazda genuine) with stored map data is inserted into the SD card slot and used. USB port Auxiliary jack 5–57...
Page 350 Interior Features Audio System Type B (With CD player) WARNING Do not adjust the portable audio unit With Electric or a similar product while driving the Parking Brake (EPB) vehicle: Auxiliary jack Adjusting the portable audio unit or a similar product while driving the vehicle is dangerous as it could distract your attention from the vehicle operation which could lead to a serious...
Page 351 Interior Features Audio System How to connect USB port/ NOTE Auxiliary jack This mode may not be usable depending        on the portable audio device to be Type A connected. Before using the auxiliary jack/USB ...
Page 352 Interior Features Audio System Type B (With CD player) WARNING Do not allow the connection plug cord With Electric to get tangled with the parking brake Parking Brake (EPB) (without electric parking brake (EPB)) or USB port Auxiliary jack the shift lever (manual transaxle) or the selector lever (automatic transaxle): Allowing the plug cord to become tangled with the parking brake...
Page 353 Interior Features Audio System How to use AUX mode (Type A) 1. Switch the ignition to ACC or ON. 2. Press the power/volume dial to turn the audio system on. 3. Press the media button ( ) of the audio unit to change to the AUX mode. NOTE When the device is not connected to the ...
Page 354 Interior Features Audio System How to use USB mode (Type A) Random button Audio display Repeat button Text button Play/Pause button Track down/Reverse button Folder up button Media/Scan button Track up/Fast-forward button Folder down button NOTE Type Playable data Some devices such as smart phones ...
Page 355 Interior Features Audio System Track search Folder repeat Press the track up button ( ) once to skip 1. Press the repeat button ( 1 ) during forward to the beginning of the next track. playback, and then press the button Press the track down button ( ) within a again within 3 seconds to play the few seconds after playback begins to track...
Page 356 USB device has MP3/WMA/AAC ﬁ les and re-connect Information displayed Button correctly. If the message reappears, have on audio display the unit checked by an Authorized Mazda File number/Elapsed time Dealer. Folder number/File number File name...
Page 357 MEMO 5–65...
Page 358 Interior Features Audio System How to use iPod mode (Type A) Audio display Text button Play/Pause button Random button Category down button Repeat button Category up button Track down/Reverse button List up button Track up/Fast-forward button List down button Media/Scan button An iPod may not be compatible depending Fast-forward/Reverse on the model or OS version.
Page 359 Interior Features Audio System List search Song random Press the list down button ( ) to select the 1. Press the random button ( 2 ) during previous list and press the list up button playback to play the tracks in the list ( ) to select the next list.
Page 360 This unit cannot display some        vehicle to an Authorized Mazda Dealer. characters. Characters which cannot be displayed are indicated by an asterisk Indication...
Page 361 Interior Features Audio System How to use AUX mode (Type B) 1. Select the icon on the home screen to display the Entertainment screen. 2. Select to switch to the AUX mode. The following icons are displayed in the lower part of the center display.
Page 362 Interior Features Audio System Playback 1. Select the icon on the home screen to display the Entertainment screen. 2. Select to switch the USB mode. The following icons are displayed in the lower part of the center display. Icon Function Displays the Entertainment menu.
Page 363: Category List
Interior Features Audio System The appearance of the repeat and shufﬂ e icons changes depending on the type of        operation in which the function is used. Category list Select the icon to display the following category list. Select a desired category and item.
Page 364 ® For information related to the most recent Gracenote database which can be used and how to install it, go to the Mazda Hands Free Website: http://www.mazdahandsfree.com Introduction Gracenote, the Gracenote logo and logotype are either a registered trademark or a trademark of Gracenote, Inc.
Page 365 4. Select . The list of the update package stored in the USB device and the version are displayed. 5. Select the package to use the update. 6. Select NOTE Gracenote can be downloaded from the Mazda Hands-free Website. ® 5–73...
Page 366: Bluetooth
Interior Features Bluetooth ® Bluetooth ® * Bluetooth Hands-Free outline ® When a Bluetooth device (mobile phone) is connected to the vehicle's Bluetooth unit via ® ® radio wave transmission, a call can be made or received by pressing the talk button, pick- up button, or hang-up button on the audio remote control switch, or by operating the center display.
Page 367 ® CAUTION Some Bluetooth ® mobile devices are not compatible with the vehicle. Consult an Authorized Mazda Dealer, Mazda's call center or Web support center for information regarding Bluetooth ® mobile device compatibility:       ...
Page 368: Component Parts
Interior Features Bluetooth ® Component Parts Audio unit Talk button, Pick-up button and Hang-up button Talk button Pick-up button Hang-up button Microphone Microphone Microphone (hands-free) The microphone is used for speaking voice commands or when making a Hands-free call. Talk button, Pick-Up button and Hang-Up button (hands-free) The basic functions of Bluetooth Hands-Free can be used for such things as making calls or ®...
Page 369 The Bluetooth system may not operate ®        7. Select “Mazda” from the device list for 1 or 2 minutes after the ignition searched by the device. is switched to ACC or ON. However, 8.
Page 370 NOTE          mobile phone device, ﬁ rst clear The following functions can be used for “Mazda” displayed on the Bluetooth ® the Hands-free or audio. setting screen of the mobile device. Hands-free: Phone calls and E-mail/ When the OS of the device is updated, ...
Page 371 Interior Features Bluetooth ® Voice Recognition Deleting a device In this section, the basic operation of the Selecting and deleting devices voice recognition is explained. 1. Select the icon on the home screen Activating Voice Recognition to display the Settings screen. 2.
Page 372 Interior Features Bluetooth ® To prevent a deterioration in the voice recognition rate and voice quality, the following points should be observed: The voice recognition cannot be          performed while voice guidance or the beep sound is operating.
Page 373: Voice Command
Interior Features Bluetooth ® Audio Operation Using Voice Recognition Voice command When the talk button is pressed and the following command is spoken, the audio or navigation can be operated. The commands in the () can be omitted. The speciﬁ ed name and number are put into the {}.
Page 374 Interior Features Bluetooth ® Entertainment (audio) related command Corresponding audio Voice command Function source (Go to/Play) AM (Radio) Switches the audio source to AM radio. (Go to/Play) FM (Radio) Switches the audio source to FM radio. (Go to/Play) Bluetooth (Audio) Switches the audio source to BT audio. (Go to/Play) Pandora Switches the audio source to Pandora ®...
Page 375: Bluetooth
Interior Features Bluetooth ® Bluetooth Hands-Free (Manually downloading) ® If the “Auto Download Contacts” setting is off, download the phonebook using the Making a Call following procedure. Phonebook Usage 1. Select the icon on the home screen to display the Communication screen. Telephone calls can be made by saying 2.
Page 376 Interior Features Bluetooth ® Favorites Contacts Deleting a favorite A maximum of 50 contacts can be 1. Select the icon on the home screen registered. It will take less time to make a to display the Communication screen. call after registering the telephone number. 2.
Page 377 Communication screen. not call 911, doing so will defeat 2. When is pressed, the dial pad the purpose of the system. Mazda is displayed. recommends that the Mobile 911 3. Input the telephone number using the system remain activated.
Page 378: Receiving An Incoming Call
Interior Features Bluetooth ® Receiving an Incoming Call When an incoming call is received, the incoming call notiﬁ cation screen is displayed. The “Incoming Call Notiﬁ cations” setting must be on. Refer to Communication Settings on page 5-91 . To accept the call, press the pick-up button on the audio control switch or select the screen.
Page 379 Interior Features Bluetooth ® Receiving and Replying to NOTE Messages (available only with If the ignition is switched off during a        E-mail/SMS compatible phones) hands-free call, the line is transferred to the device (Mobile phone) SMS (Short Message Service) messages, automatically.
Page 380 Interior Features Bluetooth ® NOTE Attached data is not downloaded.        Messages up to 1 kilobyte (E-mail)/140-        bytes (SMS) can be downloaded. A message list is created for each ...
Page 381 Interior Features Bluetooth ® The following icons are displayed in the lower part of the details on the message. Icons which can be used differ depending on use conditions. Icon Function Displays the Communication menu. Displays the inbox. Plays back a message. When selected again, playback is temporarily stopped.
Page 382 Interior Features Bluetooth ® Example of use (verify unread E-mail) NOTE Select the icon to change the 1. Select the icon on the home screen        language. to display the Communication screen. Select the icon to switch between 2.
Page 383 Interior Features Bluetooth ® Communication Settings Select the icon on the home screen to display the Communication screen. Select to change the setting. Item Setting Function Go to Bluetooth setting menu. ® Bluetooth — ® Refer to Bluetooth Preparation on page 5-77 . ®...
Page 384: Bluetooth ® Audio
Interior Features Bluetooth ® Bluetooth Audio ® AVRCP Function A2DP Ver. 1.0 Ver. 1.3 Ver. 1.4 Applicable Bluetooth speciﬁ cation ® Playback (Recommended) Pause Ver. 1.1/1.2/2.0 EDR/2.1 EDR/3.0 File (conformity) (Track) — Response proﬁ le up/down A2DP (Advanced Audio Distribution Reverse —...
Page 385 Interior Features Bluetooth ® How to Use the Bluetooth Audio System ® Switching to Bluetooth audio mode ® To listen to music or voice audio recorded to a Bluetooth audio device, switch to the ® Bluetooth audio mode to operate the audio device using the audio system control panel. ®...
Page 386 Interior Features Bluetooth ® Playback To listen to a Bluetooth audio device over the vehicle's speaker system, switch the mode to ® Bluetooth audio mode. (Refer to “Switching to Bluetooth audio mode”) ® ® After switching to the Bluetooth audio mode, the following icons are displayed in the ®...
Page 387: Information Display
Interior Features Bluetooth ® Bluetooth Audio Device ® Information Display If a Bluetooth audio device is connected, ® the following information is displayed in the center display. AVRCP AVRCP AVRCP Ver. lower Ver. 1.4 or Ver. 1.3 than 1.3 higher Device name Remaining battery...
Page 388 Interior Features Bluetooth ® How to Use Pandora ® * What is Pandora ® Pandora is free personalized Internet radio. Simply enter a favorite artist, track, genre, ® *1 and Pandora will create a personalized station that plays their music and more like it. ®...
Page 389 Interior Features Bluetooth ® Playback Select the icon on the home screen to display the Entertainment screen. When selected, the following icons are indicated in the bottom part of the center display. Icon Function Displays the Entertainment menu. Use to switch to a different audio source. Displays the station list.
Page 390 Interior Features Bluetooth ® Selection from station list Selection can be made from a programmed radio station list. 1. Select the icon. 2. Select the desired radio station. NOTE When is selected, songs randomly selected from the radio station list are played.
Page 391 Interior Features Bluetooth ® How to Use Aha ™ What is Aha ™ is an application which can be used to enjoy various Internet content such as Internet radio and podcasts. Stay connected to your friends activities by getting updates from Facebook and Twitter. Using the location-based service, nearby services and destinations can be searched or real- time local information can be obtained.
Page 392 Interior Features Bluetooth ® Icon Function Like Evaluates the current content as “Like”. Dislike Evaluates the current content as “Dislike”. Reverses for 15 seconds. Map (vehicles with navigation system) Displays the destination searched by the location based services on the navigation system. Call A call can be made to the telephone number of a shop searched using the Location Based Services.
Page 393: Main Menu
Interior Features Bluetooth ® Main menu Select the icon. Switch the tab and select the station category. Function Displays the preset station list set on the device. Presets Select the preset station name to play the station content. Select the desired station. Guidance is provided to the searched destination near the vehicle's position.
Page 394 Interior Features Bluetooth ® Example of use (Location Based Shout Services) Some social stations, such as Facebook or 1. Select the desired station from the Caraoke, support the ability to record and “Nearby” tab on the main menu. share voice messages using the “Shout” The destination name or address function.
Page 395 Interior Features Bluetooth ® How to Use Stitcher Radio ™ What is Stitcher Radio? ™ Stitcher radio is an application which can be used to listen to Internet radio or stream ™ *1 podcasts. Recommended content is automatically selected by registering content which you put into your favorites, or by pressing the Like or Dislike button.
Page 396 Interior Features Bluetooth ® Icon Function Plays the station. Select it again to pause playback. Goes to the next station. Displays sound settings to adjust audio quality level. Refer to Volume/Display/Sound Controls on page 5-40 . Station list 1. Select the icon to display the station list.
Page 397 Interior Features Bluetooth ® Add to your favorites If the current program has not been registered to your favorites, it can be registered to your favorites. 1. Select the icon to display the favorites station which the registration can be added. 2.
Page 398: Troubleshooting
The pairing information paired to procedure. Pairing cannot be performed again the Bluetooth unit or device is not ® recognized correctly. Clear “Mazda” stored in the device.  Perform pairing again.  Unable to perform pairing The Bluetooth function and the ®...
Page 399 If you pair your phone which has already been paired to your vehicle more than once in        the past, you need to delete “Mazda” on your mobile device. Then, execute the Bluetooth ®...
Page 400 There is a malfunction in the with the microphone may have Poor voice recognition microphone. occurred. Consult an Authorized Mazda Dealer. If there is any malfunction after There is a problem with the Phone-related voice recognition is checking the pairing situation, check connection between the Bluetooth ®...
Page 401 Interior Features Bluetooth ® Other problems Symptom Cause Solution method The indication for the remaining The indication method is different battery is different between the — between the vehicle and the device. vehicle and the device When a call is made from the If the number has been registered vehicle, the telephone number is into the phonebook, the incoming/...
Page 402: Interior Equipment
Interior Features Interior Equipment Sunvisors Vanity Mirrors To use the vanity mirror, lower the When you need a sunvisor, lower it for use sunvisor. in front or swing it to the side. If your vehicle is equipped with a vanity Sunvisor mirror light, it will illuminate when you open the cover.
Page 403: Interior Lights
Interior Features Interior Equipment Interior Lights Without Map Lights NOTE Do not leave the lights on for long periods while the engine is turned off. Otherwise the battery power could be depleted. Overhead Lights Switch Overhead Lights Position Light off NOTE Light is on when any door is open ...
Page 404 Interior Features Interior Equipment Illuminated Entry System Luggage Compartment Lights (5–door) When the illuminated entry system operates, the overhead lights turn on in the following conditions: The driver's door is unlocked after the      ignition is switched OFF. The ignition is switched OFF with all ...
Page 405: Accessory Sockets
Interior Features Interior Equipment Accessory Sockets With CD Player Only use genuine Mazdaaccessories or the With Electric Parking equivalent requiring no greater than 120 W Brake (EPB) (DC 12 V, 10 A). Type A The accessory sockets can be used regardless of whether the ignition is on or off.
Page 406 120 W (DC 12 V, 10 A).        Do not use accessories that are not genuine Mazda accessories or the equivalent.        Close the cover when the accessory...
Page 407: Cup Holder
Interior Features Interior Equipment Cup Holder Connecting the accessory socket 1. Open the lid. 2. Pass the connection plug cord through WARNING the cutout of the console and insert the plug into the accessory socket. Never use a cup holder to hold hot liquids while the vehicle is moving: Using a cup holder to hold hot With Electric Parking...
Page 408: Bottle Holder
Interior Features Interior Equipment Bottle Holder Without electric parking brake (EPB) Bottle holders are on the inside of the doors. Front Rear The rear cup holder is on the rear center Bottle holder armrest. Rear Bottle holder CAUTION Do not use the bottle holders for containers without caps.
Page 409: Storage Compartments
Interior Features Interior Equipment Storage Compartments Overhead Console This console box is designed to store eyeglasses or other accessories. WARNING Push and release to open. Keep storage boxes closed when driving: Driving with the storage boxes open is dangerous. To reduce the possibility of injury in an accident or a sudden stop, keep the storage boxes closed when driving.
Page 410 Interior Features Interior Equipment Center Console Storage tray The storage tray can be removed. To open, pull the release latch. With Electric Parking With Electric Parking Brake (EPB) Brake (EPB) Storage tray Without Electric Parking Without Electric Parking Brake (EPB) Brake (EPB) Storage tray 5–118...
Page 411 Interior Features Interior Equipment Luggage Compartment NOTE Loading golf bags (only 4 door) (Some golf bags may not ﬁ t using the following methods depending on their sizes.) Up to two golf bags can be carried in the trunk. First golf bag: Place the golf bag in the luggage compartment with its bottom pointed to the left and ﬁ...
Page 412 MEMO 5–120...
Page 413 Maintenance and Care How to keep your Mazda in top condition. Essential Information ................ 6-2 Introduction ................... 6-2 Scheduled Maintenance ..............6-4 Scheduled Maintenance (U.S.A., Canada, and Puerto Rico) ..6-4 Scheduled Maintenance (Mexico) ..........6-11 Maintenance Monitor ..............6-18 Owner Maintenance .................
Page 414: Maintenance And Care
If you elect to perform maintenance yourself or have your vehicle serviced at a location other than an Authorized Mazda Dealer, Mazda requires that all ﬂ uids, parts and materials must meet Mazda standards for durability and performance as described in this manual.
Page 415 Claims against the warranty resulting from lack of maintenance, as opposed to defective materials or authorized Mazda workmanship, will not be honored. Any auto repair shop using parts equivalent to your Mazda's original equipment may perform maintenance. But we recommend that it always be done by an Authorized Mazda Dealer using genuine Mazda parts.
Page 416: Scheduled Maintenance
Change the oil as soon as possible within the next 1,000 km (600 mile) or 15 days. Refer page 6-18 for the details. Mazda Genuine 0W-20 Oil and Castrol 0W-20 Oil are required to achieve optimum ®...
Page 417: Scheduled Maintenance (Mexico)
Maintenance and Care Scheduled Maintenance Schedule 1 U.S.A. and Puerto Rico residents - Engine oil ﬂ exible maintenance interval Use when the maintenance monitor for “Oil Change” is set to “Flexible”. For details, see maintenance monitor. (page 6-18 ) Number of months or kilometers (miles), whichever comes ﬁ rst. Months Maintenance Interval ×1000 km...
Page 418 *3 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or mileage/kilometer period to ensure long-term reliability.
Page 419 Maintenance and Care Scheduled Maintenance Schedule 2 U.S.A. and Puerto Rico residents - Severe driving conditions maintenance interval Number of months or kilometers (miles), whichever comes ﬁ rst. Months Maintenance Interval ×1000 km ×1000 miles ENGINE Drive belts Replace when wrench indicator light is ON. (Max interval: 12 Flexible months or 12,000 km (7,500 miles)) Engine oil &...
Page 420 *4 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or mileage/kilometer period to ensure long-term reliability.
Page 421 Maintenance and Care Scheduled Maintenance Canada residents Number of months or kilometers (miles), whichever comes ﬁ rst. Months Maintenance Interval ×1000 km ×1000 miles ENGINE Drive belts Engine oil & ﬁ lter COOLING SYSTEM Replace at ﬁ rst 192,000 km (120,000 miles) or 10 years; after Engine coolant that, every 96,000 km (60,000 miles) or 5 years.
Page 422 *3 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or mileage/kilometer period to ensure long-term reliability.
Page 423 Maintenance and Care Scheduled Maintenance Scheduled Maintenance (Mexico) Follow Schedule 1 if the vehicle is operated mainly where none of the following conditions (severe driving conditions) apply. Repeated short-distance driving        Driving in dusty conditions ...
Page 424 Maintenance and Care Scheduled Maintenance Schedule 1 Number of months or kilometers, whichever comes ﬁ rst Maintenance Interval Months ×1000 km 90 100 110 120 ENGINE Drive belts Engine oil & ﬁ lter COOLING SYSTEM Cooling system Replace at ﬁ rst 200,000 km or 10 years; after that, every Engine coolant 100,000 km or 5 years FUEL SYSTEM...
Page 425 *2 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or kilometer period to ensure long-term reliability.
Page 426 Maintenance and Care Scheduled Maintenance Schedule 2 Number of months or kilometers, whichever comes ﬁ rst Maintenance Interval Months ×1000 km ENGINE Drive belts Engine oil & ﬁ lter COOLING SYSTEM Cooling system Replace at ﬁ rst 200,000 km or 10 years; after that, every Engine coolant 100,000 km or 5 years Engine coolant level...
Page 427 *2 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or kilometer period to ensure long-term reliability.
Page 428 Maintenance and Care Scheduled Maintenance (Cont.) Number of months or kilometers, whichever comes ﬁ rst Maintenance Interval Months ×1000 km 95 100 105 110 115 120 ENGINE Drive belts Engine oil & ﬁ lter COOLING SYSTEM Cooling system Replace at ﬁ rst 200,000 km or 10 years; after that, every Engine coolant 100,000 km or 5 years Engine coolant level...
Page 429 *2 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or kilometer period to ensure long-term reliability.
Page 430: Maintenance Monitor
Maintenance and Care Scheduled Maintenance Maintenance Monitor Maintenance Monitor (Type A audio) Based on the engine operating conditions, the onboard computer in your vehicle calculates the remaining oil life in the United States and Puerto Rico. The wrench indicator light in the instrument cluster will be illuminated when remaining oil life becomes less than 1,000 km (600 mile), or remaining days are less than 15 (whichever comes ﬁ...
Page 431 Maintenance and Care Scheduled Maintenance You can customize settings in the setup display as follows: Item Explanation Setting Notiﬁ cation can be switched on/off. Displays the time or distance until maintenance is due. Time (months) Select this item to set the maintenance period. The wrench indication/indicator light in the instrument cluster will be illuminated when the remaining distance is less than 1,000 Scheduled...
Page 432: Owner Maintenance
The owner or a qualiﬁ ed service technician should make these vehicle inspections at the indicated intervals to ensure safe and dependable operation. Bring any problem to the attention of an Authorized Mazda Dealer or qualiﬁ ed service technician as soon as possible.
Page 433 Maintenance and Care Owner Maintenance WARNING Do not perform maintenance work if you lack suffi cient knowledge and experience or the proper tools and equipment to do the work. Have maintenance work done by a qualifi ed technician: Performing maintenance work on a vehicle is dangerous if not done properly. You can be seriously injured while performing some maintenance procedures.
Page 434: Hood
Maintenance and Care Owner Maintenance Hood NOTE The lever is located a little to the left of center when facing the vehicle. WARNING 3. Grasp the support rod in the padded Always check that the hood is closed area and secure it in the support rod and securely locked: hole indicated by the arrow to hold the A hood that is not closed and securely...
Page 435 Maintenance and Care Owner Maintenance Closing the Hood 1. Check under the hood area to make certain all ﬁ ller caps are in place and all loose items (e.g. tools, oil containers, etc.) have been removed. 2. Lift the hood, grasp the padded area on the support rod, and secure the support rod in the clip.
Page 436: Engine Compartment Overview
Maintenance and Care Owner Maintenance Engine Compartment Overview Windshield washer fluid reservoir Brake/Clutch fluid reservoir Battery Fuse block Engine oil dipstick Cooling system cap Engine coolant reservoir Engine oil-filler cap 6–24...
Page 437: Engine Oil
–30 –10 U.S.A., Canada, and Puerto Rico –40 –20 Use SAE 0W-20 engine oil. Mazda Genuine Oil is used in your Mazda vehicle. Mazda Genuine 0W-20 Oil is required to achieve optimum fuel economy. For maintenance service, Mazda recommends Mazda Genuine Parts and Castrol (U.S.A.
Page 438 Procedure After replacing the engine oil, it is recommended to have a repair shop such as an Authorized Mazda Dealer perform the initialization (engine oil data resetting) of the recorded value. If the value recorded by the computer is not initialized, the...
Page 439: Engine Coolant
7. Reinsert the dipstick fully. When the engine and radiator are hot, scalding coolant and steam may shoot out under pressure and cause serious injury. NOTE Changing the coolant should be done by an Authorized Mazda Dealer. 6–27...
Page 440 F. Securely tighten the coolant reservoir tank cap after adding coolant. If the coolant reservoir is empty or new coolant is required frequently, consult an Authorized Mazda Dealer. 6–28...
Page 441: Brake/Clutch Fluid
If it is excessively low, have the brake/clutch system inspected by an Authorized Mazda Dealer. NOTE State or local regulations may restrict the use of volatile organic compounds (VOCs), which are commonly used as anti-freeze agents in washer ﬂ...
Page 442: Body Lubrication
Maintenance and Care Owner Maintenance Body Lubrication Inspect ﬂ uid level in the washer ﬂ uid reservoir; add ﬂ uid if necessary. All moving points of the body, such as door and hood hinges and locks, should be lubricated each time the engine oil is changed.
Page 443: Wiper Blades
Maintenance and Care Owner Maintenance Wiper Blades Replacing Windshield Wiper Blades When the wipers no longer clean well, the CAUTION blades are probably worn or cracked. Replace them.        Hot waxes applied by automatic car washers have been known to aff ect the CAUTION wiper's ability to clean windows.
Page 444 Maintenance and Care Owner Maintenance 3. Tilt the blade assembly and remove it CAUTION from the arm.        Do not bend or discard the stiff eners. You need to use them again.        If the metal stiff eners are switched, the blade's wiping effi ciency could be reduced.
Page 445 Maintenance and Care Owner Maintenance 1. Remove the cover. CAUTION To prevent damage to the rear window, do not let the wiper arm fall on it. 4. Pull down the blade rubber and slide it out of the blade holder. 2.
Page 446 Maintenance and Care Owner Maintenance 6. Carefully insert the new blade rubber. Then install the blade assembly in the reverse order of removal. 6–34...
Page 447: Battery
Maintenance and Care Owner Maintenance Battery WARNING Wash hands after handling the battery and related accessories: Battery posts, terminals and related accessories contain lead and lead compounds, chemicals known to the State of California to cause cancer and reproductive harm. Read the following precautions carefully before using the battery or inspecting to ensure safe and correct handling: Always wear eye protection when working near the battery:...
Page 448 Maintenance and Care Owner Maintenance Keep all fl ames, including cigarettes, and sparks away from open battery cells: Flames and sparks near open battery cells are dangerous. Hydrogen gas, produced during normal battery operation, could ignite and cause the battery to explode. An exploding battery can cause serious burns and injuries.
Page 449: Key Battery Replacement
Never disassemble. Battery Replacement        Never throw the battery into fi re or Contact an Authorized Mazda Dealer for a water. battery replacement purchase.        Never deform or crush.
Page 450 The system's operational range is        reduced. Replacing the battery at an Authorized Mazda Dealer is recommended to prevent damage to the key. If replacing the battery 3. Insert the tape-wrapped ﬂ athead by yourself, follow the instruction.
Page 451 Maintenance and Care Owner Maintenance 5. Remove the battery cap, then remove CAUTION the battery.        Be careful not to allow the rubber ring shown in the fi gure to be scratched or damaged. ...
Page 452: Tires
Using Diff erent Tire Types: Refer to Tires on page 9-10 . Driving your vehicle with diff erent types of tires is dangerous. It could Use only a Mazda-genuine tire valve cause poor handling and poor braking; cap: leading to loss of control.
Page 453 After adjusting the tire pressure, braking, rotate the tires every 12,000 initialization of the tire pressure km (7,500 miles). However Mazda monitoring system is necessary to make recommends to rotate every 8,000 km the system operate normally.
Page 454 4-digit number. could cause poor handling and poor Refer to Tire Labeling on page 8-25 . braking resulting in loss of vehicle control. Mazda strongly recommends that you replace all four tires at the Temporary Spare Tire same time. Inspect the temporary spare tire at least...
Page 455 For details, contact an Authorized        is recommended that tires generally be Mazda Dealer. replaced when they are 6 years or older. Heat caused by hot climates or frequent high loading conditions can accelerate Proper tire balancing provides the best the aging process.
Page 456: Light Bulbs
Maintenance and Care Owner Maintenance Light Bulbs With LED Headlights With Halogen Headlights Side turn signal lights Side turn signal lights Overhead lights (Front)/ Overhead lights (Front)/ Map lights Map lights Vanity mirror Vanity mirror lights lights Front side-marker lights Front side-marker lights Headlights (Low/High beam) Headlights (Low beam)
Page 457 When a halogen bulb breaks, it is The LED bulb has to be replaced with the dangerous. These bulbs contain unit. We recommend an Authorized Mazda pressurized gas. If one is broken, it will Dealer when the replacement is necessary.
Page 458 Maintenance and Care Owner Maintenance 4. Turn the screw counterclockwise and 6. Turn the socket and bulb assembly remove it, and then partially peel back to remove it. Carefully remove the the mudguard. bulb from its socket in the reﬂ ector by gently pulling it straight backward out of the socket.
Page 459 Maintenance and Care Owner Maintenance High-beam bulbs/Daytime running Front turn signal lights, Parking lights/ lights Front side-marker lights (With halogen headlights), Front side-marker lights 1. Make sure the ignition is switched off, (With LED headlights) and the headlight switch is off. 2.
Page 460 Maintenance and Care Owner Maintenance 4. Turn the screw counterclockwise and 7. Disconnect the bulb from the socket. Front turn signal lights remove it, and then partially peel back the mudguard. Parking lights/Front side-marker lights (With halogen headlights), Front side-marker lights (With LED 5.
Page 461 The LED bulb cannot be replaced as a single unit because it is an integrated unit. The LED bulb has to be replaced with the unit. We recommend an Authorized Mazda Installation Dealer when the replacement is necessary. Rear turn signal lights, Brake lights/...
Page 462 Maintenance and Care Owner Maintenance 7. Disconnect the connector from the unit 8. Disconnect the bulb by pulling it out. Rear turn signal lights, Brake lights/ by pressing the tab on the connector with your ﬁ nger and pulling the Taillights/Rear side-marker lights (Bulb type) connector.
Page 463 Maintenance and Care Owner Maintenance 3. Turn the socket and bulb assembly 4. Disconnect the connector from the unit counterclockwise and remove it. by pressing the tab on the connector Rear turn signal lights with your ﬁ nger and pulling the connector.
Page 464 Maintenance and Care Owner Maintenance 5. Disconnect the bulb by pulling it out. (Right side) Rear turn signal lights, Brake lights/ 1. Make sure the ignition is switched off, Taillights/Rear side-marker lights and the headlight switch is off. (Bulb type) 2.
Page 465 Maintenance and Care Owner Maintenance 5. Turn the socket and bulb assembly 6. Disconnect the connector from the unit counterclockwise and remove it. by pressing the tab on the connector Rear turn signal lights with your ﬁ nger and pulling the connector.
Page 466 Maintenance and Care Owner Maintenance 7. Disconnect the bulb by pulling it out. 12. Install the cover in the reverse order of Rear turn signal lights, Brake lights/ the removal procedure. Taillights/Rear side-marker lights 13. Insert the cover tabs and install the (Bulb type) cover.
Page 467 Maintenance and Care Owner Maintenance 4. Disconnect the electrical connector 5–Door from the bulb by pressing the tab on the 1. Make sure the ignition is switched off, connector with your ﬁ nger and pulling and the headlight switch is off. the connector.
Page 468 Maintenance and Care Owner Maintenance 5. Disconnect the bulb from the socket. 4. Disconnect the connector from the unit by pressing the tab on the connector with your ﬁ nger and pulling the connector. 6. Install the new bulb in the reverse order of the removal procedure.
Page 469 Maintenance and Care Owner Maintenance Replacing Interior Light Bulbs 5–Door 1. Make sure the ignition is switched off, Overhead lights (Front)/Map lights and the headlight switch is off. Overhead lights (Front) , Overhead 2. Wrap a ﬂ athead screwdriver with a soft lights (Rear) , Vanity mirror lights cloth to prevent damage to the lens,...
Page 470 Maintenance and Care Owner Maintenance Overhead lights (Front) Trunk light (4–Door) 1. Press both sides of the lens cap to remove it. 2. Disconnect the bulb by pulling it out. Edge Overhead lights (Rear) 3. Install the new bulb in the reverse order of the removal procedure.
Page 471: Fuses
If the same fuse blows again, avoid using that system and consult an Authorized Mazda Dealer as soon as possible. Fuse Replacement Replacing the fuses on the vehicle's left 3. Disconnect the bulb by pulling it out.
Page 472 AUDIO or OUTLET circuit. CAUTION Normal Blown Always replace a fuse with a genuine Mazda fuse or equivalent of the same rating. Otherwise you may damage the electric system. 6–60...
Page 473 Maintenance and Care Owner Maintenance WARNING Do not replace the main fuse and multiplex slow blow fuse by yourself. Have an Authorized Mazda Dealer perform the replacement: Replacing these fuses by yourself is dangerous because they are high current fuses. Incorrect replacement could cause an electrical shock or a short circuit resulting in a fi re.
Page 474: Fuse Panel Description
Maintenance and Care Owner Maintenance Fuse Panel Description Fuse block (Engine compartment) Multiplex slow blow fuse FUSE DESCRIPTION PROTECTED COMPONENT RATING 15 A Fog lights H/L HI 20 A Headlight high beam H/CLEAN 20 A — STOP 10 A Brake lights ROOM 15 A Overhead light...
Page 475 Maintenance and Care Owner Maintenance FUSE DESCRIPTION PROTECTED COMPONENT RATING 15 A Transaxle control system R.WIPER 15 A Rear window wiper 7.5 A Air conditioner ENGINE3 15 A Engine control system ENGINE2 15 A Engine control system ENGINE1 15 A Engine control system GLOW SIG —...
Page 476 Maintenance and Care Owner Maintenance Fuse block (Left side) FUSE DESCRIPTION PROTECTED COMPONENT RATING P.WINDOW3 30 A Power seat P.SEAT D D.LOCK 25 A Power door locks P.WINDOW2 25 A Power windows SEAT WARM 20 A Seat warmer R.OUTLET3 15 A Accessory sockets SRS2/ESCL 15 A...
Page 477: Appearance Care
ﬁ nish. As the water evaporates, Prevention the acid becomes concentrated and can It is necessary to have your Mazda washed damage the ﬁ nish. and waxed to preserve its ﬁ nish according And the longer the acid remains on the to the instructions in this section.
Page 478 Chipped paint can lead to rust forming form white rings. The rings can damage        on your Mazda. Before this happens, your vehicle's ﬁ nish. repair the damage by using Mazda Prevention touch-up paint according to the instructions in this section.
Page 479 ON as fi ngers could be pinched NOTE or the wipers and wiper blades damaged Mazda is not responsible for scratches when the wipers activate automatically.        caused by automatic car washes or ...
Page 480 Maintenance and Care Appearance Care WARNING CAUTION Dry off brakes that have become Do not use steel wool, abrasive wet by driving slowly, releasing the cleaners, or strong detergents accelerator pedal and lightly applying containing highly alkaline or caustic the brakes several times until the brake agents on chrome-plated or anodized performance returns to normal: aluminum parts.
Page 481 Exposed metal quickly rusts and can lead to major repairs. CAUTION If your Mazda is damaged and needs metal parts repaired or replaced, make sure the body shop applies anti- corrosion materials to all parts, both repaired and new.
Page 482: Underbody Maintenance
Maintenance and Care Appearance Care Underbody Maintenance Aluminum Wheel Maintenance Road chemicals and salt used for ice and A protective coating is provided over the snow removal and solvents used for dust aluminum wheels. Special care is needed control may collect on the underbody. If to protect this coating.
Page 483: Interior Care
Maintenance and Care Appearance Care Plastic Part Maintenance Interior Care When cleaning the plastic lenses of the                  lights, do not use gasoline, kerosene, WARNING rectiﬁ...
Page 484 If a seat belt appears frayed or has wrung out well. abrasions, have it replaced by an Authorized Mazda Dealer: Synthetic leather If a seat belts is used under such a condition, it cannot function at its full 1.
Page 485 Maintenance and Care Appearance Care Plastic Part Maintenance NOTE Because genuine leather is a natural        material, its surface is not uniform and CAUTION it may have natural scars, scratches, and wrinkles. Do not use polishing agents. To maintain the quality for as long as ...
Page 486 Maintenance and Care Appearance Care Panel Maintenance Cleaning the Floor Mats If a panel becomes soiled, wipe it off with Rubber ﬂ oor mats should be cleaned with a soft cloth soaked in clean water and mild soap and water only. thoroughly wrung out.
Page 487 If Trouble Arises Helpful information on what to do if a problem arises with the vehicle. Parking in an Emergency ..............7-2 Parking in an Emergency .............. 7-2 Flat Tire....................7-3 Spare Tire and Tool Storage ............7-3 Changing a Flat Tire ..............7-6 Battery Runs Out ................
Page 488: If Trouble Arises
If Trouble Arises Parking in an Emergency Parking in an Emergency The hazard warning lights should always be used when you stop on or near a roadway in an emergency. The hazard warning lights warn other drivers that your vehicle is a trafﬁ c hazard and that they must take extreme caution when near it.
Page 489: Flat Tire
If Trouble Arises Flat Tire Spare Tire and Tool Storage Spare tire and tools are stored in the locations illustrated in the diagram. 4-Door Spare tire hold-down bolt Tiedown eyelet Jack Jack lever Flat tire belt Spare tire Tool bag Lug wrench 5-Door Spare tire hold-down bolt...
Page 490 If Trouble Arises Flat Tire Jack 2. Turn the wing bolt and jack screw counterclockwise. To remove the jack 1. (4–Door) Push the tabs and remove the cover. Tabs To secure the jack 1. Insert the wing bolt into the jack with the jack screw pointing to the down (5–Door) and turn the wing bolt clockwise to...
Page 491 Use only one temporary spare tire on Spare Tire your vehicle at the same time. Your Mazda has a temporary spare tire. The temporary spare tire is lighter and smaller than a conventional tire, and is designed only for emergency use and should be used only for VERY short periods.
Page 492: Changing A Flat Tire
If Trouble Arises Flat Tire Changing a Flat Tire To remove the spare tire 1. Lift the trunk/luggage compartment mat. NOTE If the following occurs while driving, it Trunk/Luggage compartment mat could indicate a ﬂ at tire. Steering becomes difﬁ cult. ...
Page 493 If Trouble Arises Flat Tire Removing a Flat Tire 1. Park on a hard, level surface off the right-of-way and ﬁ rmly set the parking brake. WARNING 2. Put a vehicle with an automatic transaxle in Park (P), a manual When jacking-up a vehicle, always transaxle in Reverse (R) or 1, and turn shift the shift lever to 1st or R (manual...
Page 494 If Trouble Arises Flat Tire 4. Turn the jack screw in the direction CAUTION shown in the ﬁ gure and adjust the jack head so that it is close to the jack-up Align the notch on the wheel cover position. with the valve stem when installing it.
Page 495 Use only the jack provided with your Mazda: Using a jack that is not designed for Jacking position your Mazda is dangerous. The vehicle could slip off the jack and seriously injure someone. Never place objects under the jack: Jacking the vehicle with an object under the jack is dangerous.
Page 496: Locking Lug Nuts
Before wheel and center cap. removing the lug nuts, make sure your Mazda is ﬁ rmly in position and that it Locking Lug Nuts cannot slip or move. If your vehicle has Mazda optional...
Page 497 If Trouble Arises Flat Tire 3. Place the lug wrench on top of the key WARNING and apply pressure. Turn the wrench counterclockwise. Make sure the mounting surfaces of the wheel, hub and lug nuts are clean To install the antitheft lug nut before changing or replacing tires: 1.
Page 498 Because the wheel studs and lug nuts on your Mazda have metric threads, using a non-metric nut is dangerous. On a metric stud, it would not secure If you are unsure of how tight the nuts...
Page 499 If Trouble Arises Flat Tire 7. Remove the belt for securing the ﬂ at 11. Pass the belt through the rear seatback tire. as shown in the ﬁ gure. 8. Put the ﬂ at tire into the trunk/luggage After passing the belt through, return compartment on the left and toward the the rear seatback to the original back.
Page 500 If Trouble Arises Flat Tire NOTE 12. Pass the buckle through the wheel as shown in the ﬁ gure and secure it so that Pass the belt underneath the seatbelts. the buckle does not contact the wheel. (Aluminum wheel) Seat belt Belt (Steel wheel) 13.
Page 501 If Trouble Arises Flat Tire 14. (Split-folding type seat) Return the rear seatback on the right side of the rear seatback to its original position. 15. Remove the tire blocks and store the tools and jack. 16. Check the inﬂ ation pressure. Refer to Tires on page 9-10 .
Page 502: Battery Runs Out
If Trouble Arises Battery Runs Out Jump-Starting Jump-starting is dangerous if done incorrectly. So follow the procedure carefully. If you feel unsure about jump-starting, we strongly recommend that you have a competent service technician do the work. WARNING Follow These Precautions Carefully: To ensure safe and correct handling of the battery, read the following precautions carefully before using the battery or inspecting it.
Page 503 If Trouble Arises Battery Runs Out CAUTION Use only a 12 V booster system. You can damage a 12 V starter, ignition system, and other electrical parts beyond repair with a 24 V power supply (two 12 V batteries in series or a 24 V motor generator set).
Page 504 If Trouble Arises Battery Runs Out 1. Remove the battery cover. 6. (With i-ELOOP system) The i-ELOOP indicator light may ﬂ ash after the engine is started. The indicator light turns off when the engine is running and the charging is completed. Make sure the i-ELOOP indicator light is turns off before driving.
Page 505: Emergency Starting
You cannot start a vehicle with an 5. If the engine fails to start, crank it automatic transaxle by pushing it. without depressing the accelerator. If the engine still does not start using the previous procedure, have your vehicle inspected by an Authorized Mazda Dealer. 7–19...
Page 506: Overheating
Stop the out under pressure and cause serious engine and call an Authorized Mazda injury. Dealer. Open the hood ONLY after steam is no 6.
Page 507 Carefully add coolant as required (page 6-27 ). CAUTION If the engine continues to overheat or frequently overheats, have the cooling system inspected. The engine could be seriously damaged unless repairs are made. Consult an Authorized Mazda Dealer. 7–21...
Page 508: Emergency Towing
We recommend that towing be done only        Do not tow the vehicle pointed by an Authorized Mazda Dealer or a backward with driving wheels on the commercial tow-truck service. ground. This may cause internal damage to the transaxle.
Page 509: Tiedown Hooks
If Trouble Arises Emergency Towing Tiedown Hooks           (With Electric Parking Brake (EPB))       If the electric parking brake (EPB) cannot be released when towing the vehicle, CAUTION transport the vehicle with all front and rear wheels raised off the ground...
Page 510 If Trouble Arises Emergency Towing Rear 3. Securely install the tiedown eyelet (4–Door) using the lug wrench. Front Lug wrench Tiedown eyelet (5–Door) Rear Lug wrench CAUTION Tiedown eyelet Do not use excessive force as it may 4. Hook the tying rope to the tiedown damage the cap or scratch the painted eyelet.
Page 511: Warning/Indicator Lights And Warning Sounds
If any warning light turns on/ﬂ ashes, take appropriate action for each light. There is no problem if the light turns off, however if the light does not turn off or turns on/ﬂ ashes again, consult an Authorized Mazda Dealer. (Vehicles with type B audio) The warning contents can be veriﬁ...
Page 512 If the brake warning light remains illuminated even though the parking brake is released, the brake ﬂ uid may be low or there could be a problem with the brake system. Park the vehicle in a safe place immediately and contact an Authorized Mazda Dealer. WARNING Do not drive with the brake system warning light illuminated.
Page 513 Do not drive with both the ABS warning light and brake warning light illuminated. Warning Have the vehicle towed to an Authorized Mazda Dealer to have the brakes inspected as soon as possible: Driving when the brake system warning light and ABS warning light are illuminated simultaneously is dangerous.
Page 514 If the light illuminates/ﬂ ashes, stop the vehicle in a safe place and do not operate the steering wheel. There is no problem if the light turns off after a while. Contact an Authorized Mazda Dealer if the light illuminates/ﬂ ashes continuously. NOTE If the indicator light illuminates/ﬂ...
Page 515 Contact Authorized Mazda Dealer and Have Vehicle Inspected If any of the following warning lights or the indicator light turns on/ﬂ ashes, the system may have a malfunction. Contact an Authorized Mazda Dealer to have your vehicle inspected. Signal Warning If the ABS warning light stays on while you're driving, the ABS control unit has detected a system malfunction.
Page 516 A system malfunction is indicated if the warning light constantly ﬂ ashes, constantly illuminates or does not illuminate at all when the ignition is switched ON. If any of these occur, consult an Authorized Mazda Dealer as soon as possible. The system may not operate in an accident.
Page 517 If the tire pressure monitoring system has a malfunction, the tire pressure warning light ﬂ ashes for about 1 minute when the ignition is switched ON and then continues illuminating. Have your vehicle checked by an Authorized Mazda Dealer as soon as possible.
Page 518 However, it does not indicate a malfunction. The “Front radar sensor system malfunction” is displayed if there is a malfunction in the (Amber) system while the Mazda Radar Cruise Control (MRCC) system is on. Have your vehicle Mazda Radar Cruise inspected at an Authorized Mazda Dealer.
Page 519 ﬂ at. However, when you ﬁ nd Authorized Mazda Dealer or a tire repair one low tire in a set of four-that is an indication station.
Page 520 SCBS)Smart dirty radar sensor, clean the front emblem. City Brake For any other reasons, have the vehicle Support inspected at an Authorized Mazda Dealer. (SCBS) Warning Light The light turns on when the remaining fuel is about 9.0 L (2.3 US gal, 1.9 Imp gal).
Page 521 If Trouble Arises Warning/Indicator Lights and Warning Sounds Signal Warning Action to be taken Except Mexico The seat belt warning light turns on if the driver or front passenger's seat is occupied and the seat belt is not fastened with the ignition switched If the driver or front passenger's seat belt is unfastened (only when the front passenger's seat is occupied) and the vehicle is driven at a speed...
Page 522 If Trouble Arises Warning/Indicator Lights and Warning Sounds Signal Warning Action to be taken This warning light indicates that little washer Low Washer Add washer ﬂ uid (page 6-29 ). ﬂ uid remains. Fluid Level Warning Light The light turns on if any door/liftgate is not Close the door/liftgate securely.
Page 523: Message Indicated On Display
Stop Vehicle in Safe Place Immediately If the following messages are displayed in the center display (Type B audio), a vehicle system may be malfunctioning. Stop the vehicle in a safe place and contact an Authorized Mazda Dealer. Display Indicated Condition Displays if the engine coolant temperature has increased excessively.
Page 524 If Trouble Arises Warning/Indicator Lights and Warning Sounds Make Sure the Message is No Longer Displayed Displays in the following cases: Display Indicated Condition/Action to be taken Displays if i-ELOOP requires charging. Leave the engine idling and wait until the message disappears. NOTE If the vehicle is driven while the message is displayed, ...
Page 525: Warning Sound Is Activated
35 opened. minutes. Have your vehicle inspected at *1 If the light switch is left on, the auto an Authorized Mazda Dealer as soon as headlight off function automatically possible. turns off the lights about 30 seconds after switching the ignition off.
Page 526 If Trouble Arises Warning/Indicator Lights and Warning Sounds Seat Belt Warning Beep Key Removed from Vehicle Warning Beep If the driver's seat belt is not fastened when the ignition is switched ON, a beep Vehicles with advanced keyless function sound will be heard for about 6 seconds. If If the key is taken out of the vehicle while the driver or the front passenger's seat belt the ignition is not switched OFF and...
Page 527 If Trouble Arises Warning/Indicator Lights and Warning Sounds Key Left-in-luggage Compartment i-ELOOP Warning Beep Warning Beep (With the advanced The beep will activate if you attempt to keyless function) drive the vehicle under the following If the key is left in the luggage conditions.
Page 528 Blind Spot Monitoring (BSM) Mazda Radar Cruise Control Warning Beep (MRCC) System Warnings The Mazda Radar Cruise Control (MRCC) Driving forward system warnings notify the driver of The warning beep operates when the turn system malfunctions and cautions on use signal lever is operated to the side where when required.
Page 529 If Trouble Arises Warning/Indicator Lights and Warning Sounds Power Steering Warning Buzzer If the power steering system has a malfunction, the power steering malfunction light turns on or ﬂ ashes and the buzzer operates at the same time. Refer to Warning Lights on page 4-24 . Over Rev.
Page 530: When Liftgate/Trunk Lid Cannot Be Opened
If Trouble Arises When Liftgate/Trunk Lid Cannot be Opened When Liftgate/Trunk Lid (4–door) 1. Open the cover. Cannot be Opened 2. (With theft-prevention cover) Open the cap. If the vehicle battery is dead or there is a malfunction in the electrical system and the liftgate/trunk lid cannot be opened, Cover perform the following procedure as an...
Page 531 4. Move the lever to the left to fold the 5. Move the lever to the left to open the seatback. trunk lid. (Type A) Cover Lever (Type B) After performing this emergency measure, have the vehicle inspected at an Authorized Mazda Dealer as soon as possible. 7–45...
Page 532: Active Driving Display Does Not Operate
If the active driving display does not operate, switch the ignition off and then restart the engine. If the active driving display does not operate even with the engine restarted, have the vehicle inspected at an Authorized Mazda Dealer. 7–46...
Page 533: Customer Information And Reporting Safety Defects
Reporting Safety Defects (Canada) ........8-15 Steps for Determining the Correct Load Limit ........8-42 Warranty ..........8-16 Warranties for Your Mazda ..8-16 Declaration of Conformity ....8-43 Outside the United States/ Declaration of Conformity ... 8-43 Canada .......... 8-17...
Page 534: Customer Information And Reporting Safety Defects
Air Bag FAQs > Air Bag Deactivation). STEP 1: Contact Your Mazda Dealer Discuss the matter with an Authorized Mazda Dealer. This is the quickest and best way to address the issue. If your concern has not been resolved by the CUSTOMER RELATIONS, SALES, ...
Page 535 Answers to many questions, including how to locate or contact a local Mazda dealership in the U.S., can be found here. E-mail: click on “Contact Us” located on the “Inside Mazda” tab, or at the bottom of the page at www.MazdaUSA.com...
Page 536 Being truly committed to customer satisfaction is more than a phrase with Mazda. We hope to satisfy every customer directly, but if there is ever a question about our decision, Mazda believes in providing a fast, fair and free method such as the BBB AUTO LINE to ensure Mazda delivers on our commitment to do the right thing for our customers! 8–4...
Page 537 The arbitrator's decision should ordinarily be issued within 40 days from the time your complaint is ﬁ led; there may be a delay of 7 days if you did not ﬁ rst contact Mazda about your problem, or a delay of up to 30 days if the arbitrator requests an inspection/report by an impartial technical expert or further investigation and report by BBB AUTO LINE.
Page 538 AND the nonconformity has been subject to repair two or more times by Mazda or its agents AND the buyer or lessee has directly notiﬁ ed Mazda of the need for the repair of the nonconformity; OR The same nonconformity has been subject to repair 4 or more times by Mazda ...
Page 539 Your complete and permanent satisfaction is of primary concern to Mazda. All Authorized Mazda Dealers have both the knowledge and tools to keep your Mazda in top condition. In our experience, any questions, problems, or complaints regarding the operation of your Mazda or any other general service transactions are most effectively resolved by your dealer.
Page 540 If a speciﬁ c item of concern arises, where a solution cannot be reached between an owner, Mazda, and/or one of its dealers (that all parties cannot agree upon), the owner may wish to use the services offered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
Page 541 Ontario 1 (800) 207-0685 Atlantic Canada 1 (800) 207-0685 Quebec 1 (800) 207-0685 Regional Ofﬁ ces REGIONAL OFFICES COVERING AREAS MAZDA CANADA INC. WESTERN REGION ALBERTA, 5011 275 STREET BRITISH COLUMBIA, LANGLEY, BRITISH COLUMBIA MANITOBA, V4W 0A8 SASKATCHEWAN, (778) 369-2100...
Page 542 STEP 1 Discuss the matter with an Authorized Mazda Dealer. This is the quickest and best way to address the issue. If your concern has not been resolved by the CUSTOMER RELATIONS, SALES, SERVICE, or PARTS MANAGER, then please contact the GENERAL MANAGER of the dealership or the OWNER.
Page 543 Mazda vehicle or servicing by Mazda Dealer personnel, we recommend that you take the following steps: Contact Your Mazda Dealer Discuss the matter with an Authorized Mazda Dealer. This is the quickest and best way to address the issue. If your concern has not been resolved by the CUSTOMER RELATIONS, SALES, ...
Page 544 Customer Information and Reporting Safety Defects Customer Assistance In order to serve you efﬁ ciently and effectively, please help us by providing the following information: 1. Your name, address, and telephone number 2. Year and model of vehicle 3. Vehicle Identiﬁ cation Number (17 digits, noted on your registration or title or located on the upper driver's side corner of the dash) 4.
Page 545 TEL: (684) 699-9347 TEL: 1 (800) 263-4680 (in Canada) (905) 787-7000 (outside Canada) PUERTO RICO/U.S. Virgin Island International Automotive Distributor Group, LLC. (Mazda de Puerto Rico) P.O. Box 191850, San Juan, Puerto Rico 00919-1850 TEL: (787) 641-1777 MEXICO Mazda Motor de Mexico Mario Pani # 150, PB Col.
Page 546: Reporting Safety Defects
Irvine, California 92618-2922 P.O. Box 19734 Irvine, CA 92623-9734 Customer Experience Center or toll free at 1 (800) 222-5500 If you live outside of the U.S.A., please contact the nearest Mazda Distributor shown (page 8-13 ) in this manual. 8–14...
Page 547 Customer Information and Reporting Safety Defects Reporting Safety Defects Reporting Safety Defects (Canada) Canadian customers who wish to report a safety-related defect to Transport Canada, Defect Investigations and Recalls, may telephone the toll free hotline 1-800-333-0510, or contact Transport Canada by mail at: Transport Canada, ASFAD, Place de Ville Tower C, 330 Sparks Street, Ottawa ON K1A 0N5.
Page 548 Customer Information and Reporting Safety Defects Warranty Warranties for Your Mazda New Vehicle Limited Warranty          Powertrain Limited Warranty        Safety Restraint System Limited Warranty       ...
Page 549 Canadian Motor Vehicle Safety Standards (CMVSS). Canada However, in the event that you are moving to the United States permanently, Mazda vehicles built for use in Canada could be eligible for exportation to the United States with speciﬁ c vehicle modiﬁ...
Page 550 Parts, servicing techniques, and tools necessary to maintain and repair your vehicle may be unavailable. There might not be an Authorized Mazda Dealer in the country you plan to take your vehicle. The Mazda warranty is valid only in certain countries.
Page 551 Non-genuine parts and accessories for Mazda vehicles can be found in stores. These may ﬁ t your vehicle, but they are not approved by Mazda for use with Mazda vehicles. When you install non-genuine parts or accessories, they could affect your vehicle's performance or safety systems;...
Page 552: Cell Phones
Customer Information and Reporting Safety Defects Cell Phones Cell Phones Warning WARNING Please comply with the legal regulations concerning the use of communication equipment in vehicles in your country: Use of any electrical devices such as cell phones, computers, portable radios, vehicle navigation or other devices by the driver while the vehicle is moving is dangerous.
Page 553: Event Data Recorder
EDR. Mazda will not disclose any of the data recorded in an EDR to a third party unless: A written agreement from the vehicle owner or the lessee is obtained ...
Page 554 Mazda and its subcontracting parties may obtain and use the recorded data for vehicle malfunction diagnosis, research and development, and quality improvement. Mazda will not disclose or provide any of the obtained data to a third party unless: An agreement from the vehicle owner (agreements from lessor and lessee for leased ...
Page 555 Customer Information and Reporting Safety Defects Uniform Tire Quality Grading System (UTQGS) Uniform Tire Quality Grading System (UTQGS) This information relates to the tire grading system developed by the U.S. National Highway Trafﬁ c Safety Administration for grading tires by tread wear, traction, and temperature performance.
Page 556: Uniform Tire Quality Grading
These grades will be added to the sidewalls of passenger vehicle tires over the next several years according to a schedule established by the NHTSA and the tire manufacturers. The grade of tires available as standard or optional equipment on Mazda vehicles may vary with respect to grade.
Page 557 Customer Information and Reporting Safety Defects Tire Information (U.S.A.) Tire Labeling Federal law requires tire manufacturers to place standardized information on the sidewall of all tires. This information identiﬁ es and describes the fundamental characteristics of the tire and also provides a tire identiﬁ cation number for safety standard certiﬁ cation and in case of a recall.
Page 558 Customer Information and Reporting Safety Defects Tire Information (U.S.A.) Indicates a tire that may be installed on cars, SUVs, minivans and light trucks as designated by the Tire and Rim Association (T&RA). NOTE If your tire size does not begin with a letter this may mean it is designated by either ETRTO (European Tire and Rim Technical Organization) or JATMA (Japan Tire Manufacturing Association).
Page 559 Customer Information and Reporting Safety Defects Tire Information (U.S.A.) M S or M/S: Mud and Snow AT: All Terrain. AS: All Season. The “M S” or “M/S” indicates that the tire has some functional use in mud and snow. U.S. DOT Tire Identiﬁ cation Number (TIN) This begins with the letters “DOT”...
Page 560 Customer Information and Reporting Safety Defects Tire Information (U.S.A.) Snow Tires In some heavy snow areas, local governments may require true snow tires, those with very deeply cut tread. These tires should only be used in pairs or placed on all four wheels. Make sure you purchase snow tires that are the same size and construction type as the other tires on your vehicle.
Page 561 Customer Information and Reporting Safety Defects Tire Information (U.S.A.) Indicates a tire that may be installed on cars, SUVs, minivans and light trucks as designated by the Tire and Rim Association (T&RA). “115” is the nominal width of the tire in millimeters. This three-digit number gives the width in millimeters of the tire from sidewall edge to sidewall edge.
Page 562 Customer Information and Reporting Safety Defects Tire Information (U.S.A.) Location of the Tire Label (Placard) You will ﬁ nd the tire label containing tire inﬂ ation pressure by tire size and other important information on the driver's side B-pillar or on the edge of the driver's door frame. SAMPLE Recommended Tire Inﬂ...
Page 563 Customer Information and Reporting Safety Defects Tire Information (U.S.A.) WARNING Always check the tire infl ation pressures on a regular basis according to the recommended tire infl ation pressure on the tire label and in conjunction with the information in this owner's manual: Driving your vehicle with under-infl ated tires is dangerous.
Page 564 Customer Information and Reporting Safety Defects Tire Information (U.S.A.) Glossary of Terms Tire Placard: A label indicating the OE tire sizes, recommended inﬂ ation pressure, and the maximum weight the vehicle can carry. Tire Identiﬁ cation Number (TIN): A number on the sidewall of each tire providing information about the tire brand and manufacturing plant, tire size, and date of manufacture.
Page 565 To equalize tread wear, rotate the tires every 12,000 km (7,500 miles) at the latest or sooner if irregular wear develops. Mazda recommends to rotate every 8,000 km (5,000 miles) to help increase tire life and distribute wear more evenly.
Page 566 Customer Information and Reporting Safety Defects Tire Information (U.S.A.) Replacing a Tire WARNING Always use tires that are in good condition: Driving with worn tires is dangerous. Reduced braking, steering, and traction could result in an accident. If a tire wears evenly, a wear indicator will appear as a solid band across the tread. Replace the tire when this happens.
Page 567 Customer Information and Reporting Safety Defects Tire Information (U.S.A.) Safety Practices The way you drive has a great deal to do with your tire mileage and safety. So cultivate good driving habits for your own beneﬁ t. Observe posted speed limits and drive at speeds that are safe for the existing weather ...
Page 568 Customer Information and Reporting Safety Defects Tire Information (U.S.A.) Vehicle Loading WARNING Do not tow a trailer with this vehicle: Towing a trailer with this vehicle is dangerous because it has not been designed to tow a trailer and doing so will aff ect the drive system which could result in vehicle damage. This section will guide you in the proper loading of your vehicle, to keep your loaded vehicle weight within its design rating capability.
Page 569 Customer Information and Reporting Safety Defects Tire Information (U.S.A.) Base Curb Weight is the weight of the vehicle including a full tank of fuel and all standard equipment. It does not include passengers, cargo, or optional equipment. Vehicle Curb Weight is the weight of your new vehicle when you picked it up from your dealer plus any aftermarket equipment.
Page 570 Customer Information and Reporting Safety Defects Tire Information (U.S.A.) SAMPLE CARGO Cargo Weight includes all weight added to the Base Curb Weight, including cargo and optional equipment. The cargo weight limit decreases depending on the number of vehicle occupants. The cargo weight limit can be calculated by subtracting the total weight of the vehicle occupants from the “combination weight of occupants and cargo should never exceed”...
Page 571 Customer Information and Reporting Safety Defects Tire Information (U.S.A.) Examples: Based on a single occupant weight of 68 kg (150 lbs), and a value of 385 kg (849 lbs) for the “combination weight of occupants and cargo should never exceed”: The cargo weight limit with one occupant is 385 kg (849 lbs) - 68 kg (150 lbs) = 317 kg (699 lbs) The cargo weight limit with two occupants is 385 kg (849 lbs) - (68 ×...
Page 572 Customer Information and Reporting Safety Defects Tire Information (U.S.A.) SAMPLE WARNING Never Exceed Axle Weight Rating Limits: Exceeding the Safety Certifi cation Label axle weight rating limits is dangerous and could result in death or serious injury as a result of substandard vehicle handling, performance, engine, transmission and/or structural damage, serious damage to the vehicle, or loss of control.
Page 573 Customer Information and Reporting Safety Defects Tire Information (U.S.A.) GCW (Gross Combination Weight) is the weight of the loaded vehicle (GVW). GCWR (Gross Combination Weight Rating) is the maximum allowable weight of the vehicle - including all cargo and passengers - that the vehicle can handle without risking damage.
Page 574 Customer Information and Reporting Safety Defects Tire Information (U.S.A.) Steps for Determining the Correct Load Limit Steps for Determining Correct Load Limit- (1) Locate the statement “The combined weight of occupants and cargo should never exceed XXX kg or XXX lbs.” on your vehicle's placard. (2) Determine the combined weight of the driver and passengers that will be riding in your vehicle.
Page 575: Declaration Of Conformity
Customer Information and Reporting Safety Defects Declaration of Conformity Declaration of Conformity Keyless Entry System/Immobilizer System 8–43...
Page 576 Customer Information and Reporting Safety Defects Declaration of Conformity Blind Spot Monitoring (BSM) System NOTE During printing time of this user manual the approvals listed above are granted. WARNING Change or modifi cations not expressively approved by the party responsible for compliance could void the use's authority to operate the equipment.
Page 577 Customer Information and Reporting Safety Defects Declaration of Conformity HomeLink Wireless Control System CAUTION HomeLink has been tested and complies with FCC and Industry Canada rules. Changes or modifi cations not expressly approved by the party responsible for compliance could void the user's authority to operate the device.
Page 578 The antenna used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with installation instructions and transmitter operating conditions for satisfying RF exposure compliance. Mazda Bluetooth Hands-Free Customer Service ® U.S.A.
Page 579 Customer Information and Reporting Safety Defects Declaration of Conformity Type B U.S.A. and Canada 8–47...
Page 580 Customer Information and Reporting Safety Defects Declaration of Conformity Mexico 8–48...
Page 581 Customer Information and Reporting Safety Defects Declaration of Conformity Distance Recognition Support System (DRSS)/Mazda Radar Cruise Control (MRCC)/Smart Brake Support (SBS) 8–49...
Page 582 MEMO 8–50...
Page 583 Speciﬁ cations Technical information about your Mazda. Identiﬁ cation Numbers ..............9-2 Vehicle Information Labels ............9-2 Speciﬁ cations ..................9-4 Speciﬁ cations ................9-4 Personalization Features ..............9-12 Personalization Features ............. 9-12 9–1...
Page 584: Specifications
Speciﬁ cations Identiﬁ cation Numbers Vehicle Information Labels Type B Vehicle Identiﬁ cation Number The vehicle identiﬁ cation number legally identiﬁ es your vehicle. The number is on a plate attached to the cowl panel located on the left corner of the dashboard. This plate can easily be seen through the windshield.
Page 585 Speciﬁ cations Identiﬁ cation Numbers Vehicle Emission Control Type B Information Label (U.S.A. and Canada) Engine Number Tire Pressure Label Type A Forward 9–3...
Page 586: Electrical System
*1 Q-85 is designed for i-ELOOP system. Only Q-85 should be used to ensure correct operation of i-ELOOP system. Consult an Authorized Mazda Dealer for details. *2 Not for i-ELOOP system. *3 This spark plug provides the SKYACTIV-G engine with optimum performance. Contact an Authorized Mazda Dealer for details. CAUTION When cleaning the iridium plugs, do not use a wire brush.
Page 587 Refer to Recommended Oil on page 6-25 . API Service GL-4 Manual transaxle oil 75W-80 Automatic transaxle ﬂ uid Mazda Genuine ATF FZ Brake/Clutch ﬂ uid SAE J1703 or FMVSS116 DOT-3 NOTE Refer to Introduction on (page 6-2 ) for owner's responsibility in protecting your investment.
Page 588 Speciﬁ cations Speciﬁ cations Dimensions 4-Door Item Vehicle speciﬁ cation Overall length 4,580 mm (180.3 in) Overall width 1,795 mm (70.7 in) Overall height 1,455 mm (57.3 in) Front tread 1,555 mm (61.2 in) Rear tread 1,560 mm (61.4 in) Wheelbase 2,700 mm (106.3 in) 5-Door...
Page 589 Speciﬁ cations Speciﬁ cations Weights U.S.A. and Canada SKYACTIV-G 2.0 (4-Door) Weight Item Manual transaxle Automatic transaxle GVWR (Gross Vehicle Weight Rating) 1,788 kg (3,942 lbs) 1,823 kg (4,019 lbs) Front 940 kg (2,072 lbs) 975 kg (2,149 lbs) GAWR (Gross Axle Weight Rating) Rear 855 kg (1,885 lbs) 856 kg (1,887 lbs)
Page 590: Air Conditioner
Speciﬁ cations Speciﬁ cations Mexico SKYACTIV-G 2.0 Weight Item Manual transaxle Automatic transaxle Total 1,815 kg (4,001 lbs) 1,835 kg (4,045 lbs) GVW (Gross Vehicle Weight) Front 920 kg (2,028 lbs) 940 kg (2,072 lbs) Rear 895 kg (1,973 lbs) 895 kg (1,973 lbs) Front 945 kg (2,083 lbs)
Page 591: Exterior Light
Speciﬁ cations Speciﬁ cations Light Bulbs Exterior light Category Light bulb Wattage UNECE (SAE) High beam HB3 (9005) Halogen Headlights Low beam H11 (H11) High/Low beam — (—) With halogen bulb headlights HB3 (9005) Daytime running lights With LED headlights —...
Page 592 NOTE The tires have been optimally matched with the chassis of your vehicle. When replacing tires, Mazda recommends that you replace tires of the same type originally ﬁ tted to your vehicle. For details, contact an Authorized Mazda Dealer. Check the tire pressure label for tire size and inﬂ ation pressure.
Page 593 Speciﬁ cations Speciﬁ cations Standard tire (U.S.A. and Canada) Inﬂ ation pressure Tire size Front Rear P205/60R16 91H 250 kPa (36 psi) 250 kPa (36 psi) 215/45R18 89W 250 kPa (36 psi) 250 kPa (36 psi) (Mexico) Inﬂ ation pressure Tire size Front Rear...
Page 594: Personalization Features
Personalization Features The following personalization features can be set or changed by the customer or an Authorized Mazda Dealer. Consult an Authorized Mazda Dealer for details. Additionally, some of the personalization features can be changed by the customer depending on the feature.
Page 595 Speciﬁ cations Personalization Features Settings Change Factory Available Item Feature Method Setting Settings The system can be changed so that the steering On/Off — wheel assist does not operate. The cancel sensitivity of the steering assistance for the Lane-keep Assist System High High/Low —...
Page 596 Speciﬁ cations Personalization Features Settings Change Factory Available Item Feature Method Setting Settings The system can be changed so that Blind Spot On/Off — Blind Spot Monitoring (BSM) does not operate. Monitoring High/ (BSM) (page Warning beep volume High Low/ —...
Page 597 Speciﬁ cations Personalization Features Settings Change Factory Available Item Feature Method Setting Settings Vehicle OFF/ Lock: When Driving/ Lock: When Driving, Unlock: IGN Lock: OFF/ When Door locks Operation condition of auto lock/unlock Lock: When Driving, (page 3-18 ) function Driving, Unlock: Unlock: In...
Page 598 Speciﬁ cations Personalization Features Settings Change Factory Available Item Feature Method Setting Settings Auto-wiper control (page Operational/non-operational On/Off — 4-50 ) Daytime running lights Operational/non-operational On/Off — — (page 4-48 ) 120 seconds/ Auto headlight 90 seconds/ (page Time until headlights turn off 30 seconds 60 seconds/ —...
Page 599 Speciﬁ cations Personalization Features Settings Change Factory Available Item Feature Method Setting Settings System Depends on Language Language indicated in display English — market Temperature Temperature unit indicated in display °F or °C °F/°C — Distance Distance unit indicated in display mi or km mi/km —...
Page 600 Turn/ Turn *1 Though these systems can be turned Off, doing so will defeat the purpose of the system and Mazda recommends that these systems remain On. *2 Only the volume of the warning beep during Blind Spot Monitoring (BSM) operation can be changed. The volume of the warning beep during Rear Cross Trafﬁ...
Page 601: Index
Index 10–1...
Page 602 Index Accessory Socket ......5-113 Battery ..........6-35 Active Driving Display ....... 4-21 Maintenance ........6-37 Adaptive Front Lighting System Replacement ........6-37 (AFS)........... 4-84 Speciﬁ cations ........9-4 Add-On Non-Genuine Parts and Battery runs out ........7-16 Accessories ......... 8-19 Jump-Starting ........
Page 603 Index Driving on Uneven Road ....3-52 Climate Control System ......5-2 Automatic Climate Control ..... 5-9 Dynamic Stability Control (DSC) ..4-70 Dual-Zone Automatic Climate DSC OFF Indicator Light....4-71 DSC OFF Switch......4-71 Control........... 5-12 Gas speciﬁ cations ......9-8 TCS/DSC Indicator Light .....
Page 604 Index Flasher Hazard Warning Flasher ...... 4-56 Hazard warning ......4-56 Hazardous Driving ......3-47 Headlights ........4-43 Head Restraint ........2-12 Flat Tire ..........7-3 Headlights Mounting the Spare Tire....7-11 Coming home light ......4-47 Removing a Flat Tire ....... 7-7 Control...........
Page 605 Instrument panel top (Soft pad) Lane Departure Warning System maintenance........6-73 (LDWS) ........4-117 Leather upholstery maintenance ... 6-72 Mazda Radar Cruise Control Panel maintenance ......6-74 (MRCC)........4-107 Plastic part maintenance ....6-73 Pre-crash safety technology ..4-82 Seat belt maintenance ....6-72 Radar sensor (front).....
Page 606 Key left-in-vehicle warning beep (With the Shift-up/shift-down request advanced keyless function) ....7-41 display ......... 4-114 Keyless Entry System ......3-3 Mazda Radar Cruise Control (MRCC) Key removed from vehicle warning System warnings ......... 7-42 beep ............. 7-40 Meters and Gauges ......4-12 Keys ............
Page 607 Index Radar Sensor (Front) ......4-141 SRS Air Bags Radar Sensors (Rear) ......4-144 Front passenger occupant classiﬁ cation Rear Coat Hooks ....... 5-119 system ..........2-57 Rear Cross Trafﬁ c Alert (RCTA) ..4-103 How the SRS air bags work ..2-50 Rear Door Child Safety Locks ....
Page 608 Index Trafﬁ c Sign Recognition System Spare Tire ..........7-5 Speciﬁ cations ........9-4 (TSR)........... 4-94 Speed Unit Selector ......4-14 Transmitter ..........3-5 Trip Computer ........4-19 Speedometer ........4-14 Starting the Engine ........ 4-5 Trip Meter ........... 4-14 Steering Wheel ........
Page 609 Key removed from vehicle warning beep ..........7-40 Lane Departure Warning sound ..7-41 Lights-on reminder ......7-39 Mazda Radar Cruise Control (MRCC) System warnings ......7-42 Over Rev. buzzer ......7-43 Power steering warning buzzer ..7-43 Seat belt warning beep ....7-40 Tire inﬂ...
Page 610 MEMO 10–10...

This manual is also suitable for:

Zoom-zoom

Mazda 3 Sport 2017 Manual

Index 10

2 Essential Safety Equipment

Seats

Seat Belt Systems

Child-Restraint

SRS Air Bags

5 Interior Features

Climate Control System

Audio System

Bluetooth

Interior Equipment

6 Maintenance and Care

Essential Information

Scheduled Maintenance

Owner Maintenance

Appearance Care

7 If Trouble Arises

Parking in an Emergency

Flat Tire

Battery Runs out

Emergency Starting

Overheating

Emergency Towing

Warning/Indicator Lights and Warning Sounds

When Liftgate/Trunk Lid Cannot be Opened

Active Driving Display Does Not Operate

Quick Links

Chapters

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mazda 3 Sport 2017

Summary of Contents for Mazda 3 Sport 2017
