- Page 1 Installation & Operations Manual 2100 Series VoIP Phone N56W24720 N. Corporate Circle Sussex, WI 53089 RP8500SIP 800-451-1460 262-246-4828 (fax) Made in the USA Ver. 6 www.rathmicrotech.com www.area-of-refuge.com www.rathsecurity.com 3 Year Warranty 09/16...
- Page 2 Thank you for purchasing Rath’s VoIP Phone. We are the largest Emergency Phone Manufacturer in North America and have been in business for over 35 years. We take great pride in our products, service, and support. Our Emergency Phones are of the highest quality.
- Page 3 Items Needed • Rath 2100-VoIP Phone • Static IP address for VoIP Phone • IP address of SIP Server Note: Address for VoIP Phone must be on the same network as SIP Server • Name, Authentication Password, and Authentication ID for SIP Extension •...
- Page 4 7. Change IP address settings of VoIP Phone a. Click BASIC SETTINGS under the menu options on the top of the screen b. Under IP address, click on circle next to Statically Configure As c. Enter desired IP address, subnet mask, and default router for VoIP Interface d.
-
Page 5: Remote Programming
Remote Programming: Step 1. To Begin Program Mode A. Call into phone by dialing the number of the phone B. After first simulated ring, Press #, # (Wait for 4 tones) C. Key in security code (Default is 1111) (Wait for confirmation tones) Step 2. -
Page 6: Adjusting The Volume
Adjusting the Volume If the volume is too low or high, adjust it by referring to the diagram and instructions below. Rath SmartPhone Volume Adjust VR1 Mic Sensitivity VR2 Adjusting the Microphone: If the person you are calling reports your voice is not loud enough, increase the Microphone Sensitivity by adjusting VR2 a 1/4 turn clockwise (requires a small Phillips screwdriver).
