User Manual

PIXPRO 360 VR Remote Viewer
(Smart Device Version)
for
KODAK PIXPRO ORBIT360 4K/4KVR360
VR Camera
Ver. 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PIXPRO ORBIT360 4K/4KVR360 and is the answer not in the manual?

Questions and answers

Related Manuals for Kodak PIXPRO ORBIT360 4K/4KVR360

Summary of Contents for Kodak PIXPRO ORBIT360 4K/4KVR360

  • Page 1: User Manual

    User Manual PIXPRO 360 VR Remote Viewer (Smart Device Version) KODAK PIXPRO ORBIT360 4K/4KVR360 VR Camera Ver. 1.0...

  • Page 2: Before You Start

    Before You Start Declaration of Conformity Responsible Party: JK Imaging Ltd. Address: JK Imaging Ltd., 17239 So. Main Street, Gardena, CA 90248 USA JK Imaging Europe, 71 Clarendon Road, Watford, WD17 1DS, UK Company Website: kodakpixpro.com About this Manual JK Imaging reserves all rights of this document. No part of this published manual may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form, by any means, without the prior written permission of JK Imaging Ltd.
  • Page 3 Matters Needing Attention Your Smart Device operating system needs to be version iOS 9 or higher, or ANDROID 5.0 or higher. iPad mini1 / iPad 4 / iPad Air 1 / iPhone 5S and earlier models (using any system versions) will not support this APP. Do not use in places with high intensity magnetic fields, electrostatic and electric wave interference (for example near a microwave oven), which may or may not cause failure in the camera receiving proper signals.

  • Page 4: Table Of Contents

    Contents Before You Start ......................1 Contents ........................3 Connecting the Camera with your Smart Device ............6 Downloading and Installing the APP ............................. 6 Establishing Connection ................................ 7 Wi-Fi Connections (iOS and ANDROID Systems) ......................7 BLUETOOH Connection (ANDROID System) ........................ 7 NFC Connection (ANDROID System) ..........................
  • Page 5 Movie Size ................................14 Unfold Mode ................................15 Camera Modes ..............................16 Function Menu ............................... 17 Menu ..................................21 Shooting Settings ............................22 General Settings ............................24 Shooting Methods ................................. 28 Shooting ................................28 Video Recording ..............................29 Playback ....................................30 Switching of the Remote Viewfinder Mode and Playback Mode.................
  • Page 6 Rotate (Smart Device Single Playback Mode) ....................35 Select One or More File(s) (Camera and Smart Device Index Playback Mode) ..........36 Download (Camera Single Playback and Index Playback Mode) ..............39 Editing Video Files (Smart Device Single Playback Mode) ................40 Sharing ................................

  • Page 7: Connecting The Camera With Your Smart Device

    Connecting the Camera with your Smart Device Downloading and Installing the APP Please download the APP installation package (APP Name: PIXPRO 360 VR Remote Viewer ) to your Smart Device from the path below and install it. ANDROID System For ANDROID devices, search and download the “PIXPRO 360 VR Remote Viewer ” APP in Google Play and install it following the instructions on the interface.

  • Page 8: Establishing Connection

    Establishing Connection Wi-Fi Connections (iOS and ANDROID Systems) 1. Camera: Check the SSID (PIXPRO-ORBIT360_XXXX / PIXPRO-4KVR360_KXXXX) and password (default factory password: 12345678) as indicated on the label inside the battery compartment of the camera. In the main interface, press the button to switch to Wi-Fi mode.

  • Page 9: Nfc Connection (Android System)

    NFC Connection (ANDROID System) 1. Enable NFC mode on your Smart Device. 2. Use your Smart Device to lightly touch the NFC mark on the camera; if the Smart Device has a prompt tone or vibration, it means the connection is successful. 3.

  • Page 10: Operation Methods

    Operation Methods Remote Viewfinder Remote Viewfinder Interface On the Remote Viewfinder Interface, tap the icon to hide information , and tap to restore initial display. 1234567 1234567...
  • Page 11 Shooting Interface Video Interface 1234567 00:00:00 1234567 Start Video Recording Camera Mode Menu Shutter Stop Video Recording Function Menu Color Effects Movie Size Frame Rate Shooting Mode Battery State Wind Cut Motion Detection Number of Photos that Can Electronic Image Image Size be Taken/ No Memory Card in Stabilizer(EIS)

  • Page 12: Parameter Settings

    Parameter Settings Shooting Mode Tap the Shooting Mode icon to enter the Mode Selection screen. Tap any of the options to confirm your selection. Photo Video Burst High Speed Movie 1234567 Photo Mode Enables photo shooting. Video Mode Enables video recording.
  • Page 13 Burst Mode Automatically stops after 10 photos are shot at a time (the shutter is pressed down and not holding). High Speed Video Mode This camera shoots ultra high speed movies and plays back with normal 30fps speed. The video is not capable of recording audio and does not support Electronic Image Stabilization (EIS). High Speed Video shooting can not be used in the 235°...

  • Page 14: Image Size

    Image Size Setting photo resolution sizes. 7360x3680 27M 5520x2760 15M 7360x3680 27M - Global 360x3680 27M 5520x2760 15M - Global 5520x2760 15M - G 1234567 There are 7 options: Type Icon Image Size 7360x3680 27M 5520x2760 15M 7360x3680 27M - Global 5520x2760 15M - Global 3680x3680 13M 1:1 3525x2644 9M 4:3...

  • Page 15: Movie Size

    Movie Size Setting video resolution. 3840x1920 24fps - Global 3840x1920 15fps 840x1920 15fp 1920x960 30fps 1920x960 30fps 00:00:00 There are 10 options: Supported Supported Type Icon Movie Size Recording Type Icon Movie Size Recording Mode Mode 3840x1920 24fps - Global 3840x2160 30fps 3840x1920 15fps 1920x1080 60fps...

  • Page 16: Unfold Mode

    Unfold Mode Select from several different viewing modes. Equirectangular Magic Flat Fish Eye h Eye Little Planet ttle Planet 1234567 Type Icon Mode Operating Methods (Using Smart Devices touch screen) Equirectangular Magic Flat Move up/down, move to the left/right Slide up and down to preview the vertical direction; slide left Fish Eye and right to preview the horizontal direction.

  • Page 17: Camera Modes

    Camera Modes You may select different Camera Modes to shoot still photos. 360° Lens - VR Mode 235° Lens - Round Mode 197° Ultra Wide 4K - Front Mode 1234567 There are 3 options: • 360° Lens - VR Mode •...

  • Page 18: Function Menu

    Function Menu or slide from the left to the right of the screen to display the function menu. Tap the Menu Items to be set to enter the Item Options screen. Tap Options to return to the Menu screen. Tap the non-selection area of the interface to access the Remote Viewfinder screen.
  • Page 19 EV Settings Adjust the brightness of the framing interface. This setting can be applied where the contrast of the subject shot and background brightness are vastly different. EV value can be adjusted by sliding your finger up and down. 3 0 . EV+1.0 3 0 .
  • Page 20 Vieiwing Modes Select the icon according to the direction that the camera lens is facing, so the image will be displayed in the upright direction. 1234567 Type Icon Mode Description Means the image will be displayed upright when the LCD is facing LCD (Up) upward.
  • Page 21 Field of View Field of View sets the desired viewing angle. This function is only available when selecting FHD video size in the Front Mode setting ( ) while recording ( There are 3 options: • Ultra Wide • Middle •...

  • Page 22: Menu

    Menu 1. Tap to display the Menu Icon. 2. Tap to switch between different settings. 3. Tap the Menu Items to be set to enter the Item Options screen. Tap Options to return to the Menu screen. Tap return to the Remote Viewfinder screen. Volume (DV) Color Effects Date Imprint...

  • Page 23: Shooting Settings

    Shooting Settings Motion Detection Color Effects Motion detection means that if the product detects Set the color effects of photos and videos. moving objects entering into the camera's LCD There are 3 options: screen, it will automatically start recording. During the recording process, if there is no moving object •...
  • Page 24 Electronic Image Stabilizer (EIS) Set the electronic image stabilization modes. There are 2 options: • • When selecting ( ) mode, this option will not appear and EIS is automatically disabled and not available by default. The Dome ( ) and Front( ) modes in Recording mode ( ) are available for selection.

  • Page 25: General Settings

    General Settings Volume (DV) Geotagging Set the audio volume of the camera while recording. Photos will be tagged with the geographic location where they are taken. There are 4 options: There are 2 options: • Mute • • Level Three •...
  • Page 26 Wi-Fi Password Change To change the Wi-Fi connection password. Enter the old password following the screen prompts then enter your new password twice. Finally Tap “Update”. If you forget the Wi-Fi connection password, you can use the factory default reset function on the camera to reset it back to the original password: 12345678.
  • Page 27 Reset Reset settings (except for Date and Time, Wireless APP point, SSID and Password ) you can recover all initial product settings to the factory defaults. There are 2 options: • RESET • CANCEL After resetting, the camera will automatically power off. About PIXPRO 360 VR Remote Viewer APP •...
  • Page 28 Menu can be adjusted in each Mode: ( O: Optional X: Not Optional ) Mode Menu Camera Mode EV Value White Balance Unfold Mode Viewing Mode Image Size Movie Size Field of View Motion Detection Electronic Image Stabilizer(EIS) Color Effects Wind Cut Touch Capture Volume (DV)

  • Page 29: Shooting Methods

    Shooting Methods All files are saved on the microSD memory card in the camera. Select and the stored video or photo files will be rectangle; select and the stored video or photo files will be global; select and the stored video or photo files are 2:1 Global with 2:1 Stitched. Shooting 1.

  • Page 30: Video Recording

    Video Recording Tap the Shooting Mode Icon on the Shooting screen to enter the Mode Selection screen and tap to enter the Video Recording screen. 1. Tap the icons on the interface to set the corresponding parameters. 2. Tap to start recording and then tap to stop recording.

  • Page 31: Playback

    Playback There are two Playback Modes: •. Single Playback (video / photo); •. Index Playback (camera/smart device). Switching of the Remote Viewfinder Mode and Playback Mode 1. Tap to enter the camera’s Single Playback Interface. 2. Tap to enter the Index Playback Interface. 3.

  • Page 32: Switching Camera And Smart Device Index Playback

    Switching Camera and Smart Device Index Playback 1. On the camera Index Playback Interface, tap to enter into the Smart Device Index Playback Interface. 2. On the Smart Device Index Playback Interface, tap to enter into the camera Index Playback Interface. Camera Smart Device Index Playback Interface...

  • Page 33: Introduction Of Icons In The Playback Mode

    Introduction of Icons in the Playback Mode Single Playback Camera Photo Video 00:00 00:00 Enter Index Playback screen Enter photo or video mode Share the current photo or video to social Download the current photo or video to the Smart networks Device Delete the current photo or video...
  • Page 34 Smart Device Photo Video 00:00 00:00 LCD (Up) LCD (Down) Front Lens (Up) Front Lens (Down) LCD (Up) LCD (Down) Lens Up Lens Down Magic Flat Equirectangular Fish Eye Little Planet Dome Magic Flat For synthesized photos and videos, there are only two options while selecting viewing mode.

  • Page 35: Index Playback

    Index Playback Camera Smart Device 2016 DEC 25 2016 DEC 25 2016 DEC 25 2016 DEC 25 2016 DEC 24 2016 DEC 24 2016 DEC 24 2016 DEC 24 Menu Return to the previous interface Enter photo or video mode To select all files Enter the download mode to move the files in Select multiple files to share...

  • Page 36: Description Of Functions In Playback Mode

    Description of Functions in Playback Mode Gestures in Playback Mode 1. Hide/display the icons: Tap the photo or video once with a single finger. 2. Zoom in (except for front video): Quickly tap the photo or video twice or use two fingers to expand the photo or video.

  • Page 37: Select One Or More File(S) (Camera And Smart Device Index Playback Mode)

    Select One or More File(s) (Camera and Smart Device Index Playback Mode) 1. Hold down a file thumbnail to enter into the Multiple Selection Screen. 2016 DEC 25 2016 DEC 25 2016 DEC 24 2016 DEC 24 2. View fore and aft files by sliding your finger up and down on the screen. 2016 DEC 25 2016 DEC 24...
  • Page 38 3. Select one or more file(s). 3.1. Tap before the date folder to select all files under the date folder; 2016 DEC 25 2016 DEC 25 2016 DEC 24 2016 DEC 24 3.2. Tap a file thumbnail to select a single file (tap again to cancel the selection); 2016 DEC 25 2016 DEC 25 2016 DEC 25...
  • Page 39 3.3. Tap to select all files; tap to cancel the selections and return to the Index Playback Interface. 2016 DEC 25 2016 DEC 25 2016 DEC 25 2016 DEC 24 2016 DEC 24 2016 DEC 24...

  • Page 40: Download (Camera Single Playback And Index Playback Mode)

    Download (Camera Single Playback and Index Playback Mode) Download the photos or video in the camera to your Smart Device. Camera Single Playback Mode: 1. Select the file you want to download and tap to start downloading. 2. Tap “Download Later” in the downloading process to cancel downloading. 3.

  • Page 41: Editing Video Files (Smart Device Single Playback Mode)

    Editing Video Files (Smart Device Single Playback Mode) You may crop Spherical / VR videos downloaded to your Smart Device. Trimming Video: 1. Select the file you want to Trim, tap to enter the trim interface. 2. Use your finger to press on the and move it onto the cropping axis.
  • Page 42 Unfold Mode Select from several different viewing modes. Trim Video Trim Video Trim Video Trim Maximum1:00 Trim Maximum1:00 Film Length 4:00 Film Length 4:00 Start Time End Time Start Time End Time Vieiwing Modes Select the icon according to the direction that the camera lens is facing, so the image will be displayed in the upright direction.
  • Page 43 Enter Trim Time Select the time endpoint to be cropped from the "Start Time" and "End Time" time box on the Crop screen. Trim Video Trim Video Start Time End Time Trim 1:00 Maximum Maximum Film Length 4:00 Film Length 4:00 Start Time End Time Start Time...

  • Page 44: Sharing

    Sharing Sharing photos or videos to social network sites. Single Playback Mode: Spherical and VR Files 1. Select the file you want to share and tap to start downloading. 2. Select the type of image you want to share. If the selected image type is "Global ", the file will be shared in its' original format. The sharing process varies with different type of video files you select.
  • Page 45 VR Stitch (2:1) Photo File Good things are worth waiting for. Share Download Later Dual Global (2:1) Video File XXXXXXXXXXXXXXXXXXX. XXXXXXXXXXXXXXXXXXX XXXXXXXXXXXXXXXXXXX Good things are worth waiting for. 00:00 XXXXXXX Download Later 3. Tap “Download Later” in the downloading process to cancel downloading. 4.
  • Page 46 ANDROID System After downloading, select the shooting orientation of the camera: Global Equirectangular Good things are worth waiting for. Choose image type to share Share Download Later • If the mobile data network is enabled on your Smart Device, the current file can be shared. •...
  • Page 47 iOS System After downloading, select the shooting orientation of the camera: Global Equirectangular Choose image type to share Share The file cannot be shared before it is downloaded. • If the mobile data network is enabled on your Smart Device, the current file can be shared. •...
  • Page 48 Global (1:1) and VR Stitch Video File: XXXXXXXXXXXXXXXXXXXXXXXXXXXXXX XXXXXXXXXXXXXXXXXXXXXXXXXXXXXX XXXXXXXXXXXX Good things are worth waiting for. 00:00 SETTING NETWORK Download Later CANCEL Front File 1. Slide one finger to select a file to share and tap to start downloading. 2. Tap “Download Later” in the downloading process to cancel downloading. 3.
  • Page 49 Index Playback Mode: Select one or more file(s) that you want to share, tap , (for sharing "Equirectangular" photo files, please select a photo) and tap "OK" to start the download. Refer to the operating method of Single Playback Mode sharing. 2016 DEC 25 2016 DEC 25 XXXXXXXXXXXXXXXXXXXXXXXXXXXXXX...

  • Page 50: Delete

    Delete Delete the selected photos or videos. Index Playback Mode: 1. Select one or more file(s) you want to download and tap 2. Select “DELETE” to confirm the deletion in the pop-up prompt screen. Single Playback Mode: 1. Select the file you want to delete and tap 2.

  • Page 51: Playing Videos (Camera And Smart Device Single Playback Mode)

    Playing Videos (Camera and Smart Device Single Playback Mode) Slow wireless transmission may impact seamless viewing. We suggest downloading the file to your Smart Device before viewing. 1. Tap to play the video. 2. Select “OK” to play in the pop-up prompt screen. 3.

  • Page 52: Vr / Global Photos Playback (Camera And Smart Device Single Playback Mode)

    VR / Global Photos Playback (Camera and Smart Device Single Playback Mode) 1. Tap to play the photo. 2. Tap to switch viewing mode. 3. Tap to switch Unfold Mode. 4. Tap to export newly crected files. Type Icon Mode Operating methods (Using Smart Devices touch screen) Equirectangular Magic Flat...

  • Page 53: Vr Cardboard (Vr Glasses Playback)

    VR Cardboard (VR Glasses Playback) You can use VR Cardboard to watch the downloaded Spherical and VR files from your Smart Device. Icon will display on the single playback screen of these files. , select a direction that is consistent with the camera body shooting, and then tap ”NEXT” to play in VR. Please select a direction when you've taken the file.
  • Page 54 Spherical and VR Video Play Exit VR Replay Exit VR Replay Exit VR Replay Exit VR Replay Exit VR Play Replay Play Pause Return to the previous Cursor Control interface Switch to Single Screen VR Switch to Dual VR Timeline...
  • Page 55 Spherical (1:1) and VR Stitch Photo Play If the VR Cardboard you use has a neodymium magnet ring on one side and it is compatible with the magnetic gyro sensors of your Smart Device, you can use this method to control video playback and interaction. Exit VR Replay Exit VR...

  • Page 56: Menu (Camera And Smart Device Index Playback Mode)

    Menu (Camera and Smart Device Index Playback Mode) 1. Tap to display the menu. 2. Tap your desired setup item. 2016 DEC 25 You Tube Not logged in 3. Tap the option to return to the Menu. About PIXPRO 360 VR Remote Viewer APP 4.
  • Page 57 All other logos, products or company names that are referred to in this document are trade names, trademarks or registered trademarks of their holders. The holders are not affiliated with JK Imaging Ltd., our products or our website. © 2017 JK Imaging Ltd. All Rights Reserved. JK Imaging Ltd., 17239 So.
