Page 2: Important Safety Instructions
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure, that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the... -
Page 3: Norme Di Installazione E Uso
1. Introduzione 3. Pannello connessioni (fig. 2) Congratulazioni l'acquisto diffusori 1. Connettori XLR + JACK collegati in parallelo PERFORMANCE! (LINK) per l’ingresso ed il rilancio del segnale. Per un impiego corretto dei diffusori seguite le istruzioni 2. Connettori STEREO XLR-F + JACK collegati in riportate in questo manuale. -
Page 4: Specifiche Tecniche
5. Specifiche tecniche PFM 10.2 PFM 12.2 PFM 15.2 PFM 15.3 PFM 15.3XL SPECIFICHE del DIFFUSORE Alti Tweeter a tromba al Niobium Driver da 1" EWT™ COMPONENTI Medi Midrange da 6" Bassi Woofer da 10" Woofer da 12" Woofer da 15"... - Page 5 1. Introduction 3. Connection panel (fig. 2) Congratulations for having chosen PERFORMANCE 1. XLR-F + JACK sockets connected in parallel for loudspeaker systems! the signal input and linking. To make the best use of the PERFORMANCE systems, 2. XLR-F + JACK sockets connected in parallel for please read this manual thoroughly before operating the the signal input and linking (only PFM15SA and equipment.
-
Page 6: Technical Specifications
5. Technical specifications PFM 10.2 PFM 12.2 PFM 15.2 PFM 15.3 PFM 15.3XL LOUDSPEAKER SPECIFICATIONS High Niobium horn tweeter 1" EWT™ driver COMPONENTS 6" midrange 10" woofer 12" woofer 15" woofer 15" woofer 2 x 15" Woofer POWER HANDLING W continuous... - Page 7 FIG. 1 - MODELS...
- Page 8 FIG. 2 - CONNECTION PANELS...
- Page 9 FIG. 3 - PFM 15SA & PFM 18SA CONNECTION EXAMPLES...
- Page 10 FIG. 4 - CONNECTION CABLES Balanced M-XLR Unbalanced M-XLR Balanced F-XLR Unbalanced F-XLR Balanced 1/4”JACK Unbalanced 1/4”JACK...
-
Page 11: Federal Communications Commission
FEDERAL COMMUNICATIONS COMMISSION NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. - Page 12 Sales Division: 47842 S.Giovanni in Marignano (RN) – Via delle Rose, 12 – tel. +39-0541-959511 – fax +39-0541-957404 Internet: http://www.lemaudio.com...
