SeGUin
Europa 7 | Super 9 | Visio 8 Plus
inStallation & USer GUiDe
1. SpecificationS
2. preliminary inStall GUiDe
3. componentS liSt
4.0 inBUilt aGainSt comBUStiBle Wall
4.1 maSonry BricK inStallation
4.2 HeBel inStallation
4.3 SKamol: refer to SKamotec 225 manUal
5. inBUilt into iSlanD Wall
no comBUStiBle SUrroUnDinGS
6. eXiStinG cHimney inStall
7. free StanDinG inStall
8. lift Up Door aSSemBly
9. operation & maintenance
10. Warranty
notice to inStaller:
these instructions must be left with the owner, who should keep them for future use.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Europa 7 and is the answer not in the manual?

Questions and answers

Related Manuals for Sculpt Fireplaces Europa 7

Summary of Contents for Sculpt Fireplaces Europa 7

  • Page 1 SeGUin Europa 7 | Super 9 | Visio 8 Plus inStallation & USer GUiDe 1. SpecificationS 2. preliminary inStall GUiDe 3. componentS liSt 4.0 inBUilt aGainSt comBUStiBle Wall 4.1 maSonry BricK inStallation 4.2 HeBel inStallation 4.3 SKamol: refer to SKamotec 225 manUal 5.
  • Page 2 ComplianCe plate and serial number. the instructions in this manual are recommendations only, the distributor and manufacturer bears no liability to the interpretation of these instructions.
  • Page 3 Congratulations! thank you for choosing Sculpt fireplaces as your heater of choice. Your fireplace is the result of careful design, artisan engineering and safety tests. If it is properly installed, used and maintained, you may be sure that you will have an outstanding heating feature in your home for years to come.
  • Page 4 all fireplaCes in this manual Conform to australian and new Zealand standards as/nZs 2918;2001 domestiC solid fuel burning applianCes & as/nZs 4012/4013(2014). iMPortant *Heating capacity of the following appliances are a guide only and refers to areas with 2.4m ceilings and 6 or more star rated buildings.

  • Page 5: Specifications

    1. SpecificationS SeGUin eUropa 7 100% Pure cast iron, 8-12mm thickness material 17.9kW KW output Up to 150-250m2 Heating capacity* Clean frame-less design(trim options available) facace Secure swing or lift up door opening system glass door 4.5m minimum flue HeigHt...
  • Page 6 1. SpecificationS SeGUin ViSio 8 100% Pure cast iron, 8-12mm thickness material 27.8kW KW output Up to 240-340m2 Heating capacity* Clean frame-less design(trim options available) facace Secure swing or lift up door opening system glass door 4.5m minimum flue HeigHt 200mm, 250mm, 300mm flue sizes A duct and a register...
  • Page 7 1. SpecificationS SeGUin SUper 9 100% Pure cast iron, 8-12mm thickness material 26.9kW KW output Up to 200-300m2 Heating capacity* Clean frame-less design(trim options available) facade Secure swing or lift up door opening system glass door 4.5m minimum flue HeigHt 250mm, 300mm, 350mm flue sizes A duct and a register...

  • Page 8: Important Warning

    2. preliminary inStall GUiDe it is the users duty to make themselves aware of and apply all national or more restrictive local standards and instructions(aS/nZS 2918:2001). iMPortant Prior to unpacking and installation check that the appliance has not been damaged during transport. Ensure you check the glass, the door(s), the damper operation and the door locking mechanism Before any work is carried out, as per local and national regulations and laws, this appliance Must be installed by a licensed professional as per australian and new Zealand standards 2918:2001.
  • Page 9 Sculpt Fireplaces & Seguin Duteriez reserves the right to change these specifications without prior notice.
  • Page 11 2. preliminary inStall GUiDe PlEasE rEaD Prior to install fresh air inlet, reCommended for all installations the air inlet is recommended for installation and is essential for the proper function of the appliance. the fresh combustion air inlet must be a minimum 300mm2 and ideally positioned (see point a & B on diagram). Air vents False Ceiling Hot air grid...

  • Page 12: Components List

    4 Zero type: aluminium inner core, aluminium outer, poly insulated, minimum ri.0) by the retailer. 4.5m inbuilt triple skin flue kit - seguin europa 7 & Visio 8 Quantity...
  • Page 13 900mm StainleSS flUe - 250mm Diameter 900mm GalVaniSeD flUe - 300mm Diameter WinD rim option B coWl to SUit 4.5m freestanding blaCk flue kit - seguin europa 7 & Visio 8 plus Quantity Components 900mm StainleSS flUe - 200mm Diameter...
  • Page 14 maSonry BricK inStallation step 1: base lay a masonry base, minimum 75mm thick (ie. solid bricks). the base should be laid on a adequate ground supporting it’s weight. **important** if using the optional outdoor air kit please leave a 125mm air gap behind the firebox.
  • Page 15 maSonry BricK inStallation step 4: positioning of the unit Place the firebox into position on top of the sheet metal. Remember to leave a 25mm air gap on all sides of the firebox. (if an outdoor air-kit is to be connected please leave a 125mm air-gap at the rear of the firebox).
  • Page 16 maSonry BricK inStallation step 7: layla 3 trim with lift door (if not reQuired go to step 8) **important** Trim must be fitted onto the firebox PRIOR to installing the front of the masonry enclosure. Put the trim on the front of the firebox On the side of the façade of the firebox drill two holes at 4.2mm the holes must match with the slotted holes on the trim...
  • Page 17 maSonry BricK inStallation step 10: CaVity lid **important** side Vents it is highly recommended the cavity lid be installed flat to 300mm ensure sufficient air flow around the appliance if 2 vents are below used. Ceiling front Vents it is highly recommended the cavity lid be installed on an angle of 15°...
  • Page 18 maSonry BricK inStallation step 13: flue installation the triple skin flue will then be continued into the roof cavity and above the roof line, as per australian & new Zealand Standard aS/nZ 2918:2001. there must be a 25mm clearance around the outer triple skin flue. the flue must extend a minimum 1m above the roof line and have a 3m clearance from any combustibles in a horizontal direction.
  • Page 19 maSonry BricK inStallation step 17: baffle plate ensuring the wider end of the baffle plate is facing the inside back wall of the firebox, and the flat surfaces are positioned downwards, proceed to gently position the plate on the lugs located on the inside ceiling of the firebox.
  • Page 20 HeBel inStallation liGHt WeiGHt inStallation step 1: base lay a masonry base of Hebel blocks, minimum 75mm thick. the base should be laid on a adequate ground supporting it’s weight. **important** if using the optional outdoor air kit please leave a 125mm air gap behind the firebox.
  • Page 21 HeBel inStallation step 4: side walls - seCond layer & Ventilation **important** Ventilation is required on the enclosure to help with air circulation. a minimum of two air intake grills are required at the bottom and a minimum of two air out-take grills are required on top of the masonry enclosure (2X inflow 2X outflow).
  • Page 22 HeBel inStallation step 7: side walls - final layer Using recommended fibretex 650 rockwool(minimum 300mm thick) place a layer on each inside wall panel. step 8: lift up door assembly (if not reQuired go to step 9) **iMPortant** refer to images on page 37. liFt uP Door assEMBly. three bolts mount the lift up door mechanism.
  • Page 23 HeBel inStallation step 10: layla 3 trim with lift door (if not reQuired go to step 11) **important** Trim must be fitted onto the firebox PRIOR to installing the front of the masonry enclosure. Put the trim on the front of the firebox On the side of the façade of the firebox drill two holes at 4.2mm the holes must match with the slotted holes on the trim...
  • Page 24 HeBel inStallation step 13: flue installation triple skin flue is to then be continued on top of the cavity lid. The lower end of the middle skin casing shall be close fitting against the lid and the outer casing must be ventilated. air vents on the first length of triple skin flue must be cut (please use diagram as a guide).
  • Page 25 HeBel inStallation STEP 16: FRONT: FINAL LAYER place a layer of 12mm minimum thick heat resistant material on the exterior and finish. step 17: hearth (floor proteCtor) the hearth must be constructed from masonry or a non combustible material, and must extend 500mm in front of the appliance, 250mm on either side of the appliance and a thickness of 75mm.
  • Page 26 SKamotec inStallation SKamotec 225 is light weight material providing several advantages- excellent r-value, high mechanical strength, low thermal conductivity and maximum service temperatures of 1000 c°. the exceptional heat resistance makes the SKamotec 225 able to withstand continuous heat cycles to full service temperature limit and the low thermal conductivity provides maximum insulation throughout the temperature range making it the ideal product when building custom fireplace enclosures.* PlEasE rEFEr to sKaMotEC 225 installation Manual...
  • Page 27 inBUilt into iSlanD Wall non comBUStiBle SUrroUnDinG step 1: base lay a masonry base of (ie. clay bricks or Hebel), minimum 75mm thick. the base should be laid on a adequate ground supporting it’s weight. step 2: sheet metal layer (optional step) place a thin piece of sheet metal on top of the bricks in order to level the base and safely manoeuvre the firebox.
  • Page 28 inBUilt into iSlanD Wall step 4: positioning of the unit & baCk frame Place the firebox into position onto the sheet metal. For structural support place a steel frame (minimum 51mm thick) on the back wall and connect to the two side steel frames, remembering to leave a 25mm air gap to all sides of the firebox.
  • Page 29 inBUilt into iSlanD Wall step 8: lift up door assembly (if not reQuired go to step 9) **iMPortant** refer to images page 37. liFt uP Door assEMBly. three bolts mount the lift up door mechanism. it is recommended that you use two solid pieces of timber approximately 450mm long in order to assist in the assembly of the door.
  • Page 30 inBUilt into iSlanD Wall step 10: CaVity lid 300mm **important** below side Vents Ceiling it is highly recommended the cavity lid be installed flat to ensure sufficient air flow around the appliance if 2 vents are 15° used. front Vents it is highly recommended the cavity lid be installed on an angle of 15°...
  • Page 31 inBUilt into iSlanD Wall step 14: duCting the duct must be 4 Zero type(aluminium inner core, aluminium outer, poly insulated, minimum ri.0) and tested to as 4254.1-2012. outlet must be metal. this unit has been supplied with a ducting kit (consisting of one duct and one metal register), while it is highly recommended that it be installed, if not installed it will have no implication on the functioning of the unit.
  • Page 32 inBUilt into iSlanD Wall step 17: hearth (floor proteCtor) the hearth must be constructed from masonry or a non combustible material, and must extend 500mm in front of the appliance, 250mm on either side of the appliance and a thickness of 75mm. step 18: baffle plate ensuring the wider end of the baffle plate is facing the inside back wall of the firebox, and the flat surfaces are positioned...

  • Page 33: Baffle Plate

    eXiStinG BricK cHimney inStallation eXisting briCk Chimney installation please read all instruCtions before CommenCing installation Install unit into cavity with a sufficient amount of air flow on the back and sides (recommended 25mm air gap) of the appliance. Single skin flue must run from the spigot of the unit through to the top of the chimney, alternatively a funnel system can be custom made by a qualified trades person to the specifications of the existing brick chimney, the manufacturer and distributor bears no liability to the performance of the appliance once the custom panel has been fitted to the firebox.

  • Page 34: Ventilation Options

    eXiStinG BricK cHimney inStallation Ventilation options Ventilation is required on the enclosure to help with air circulation. option 1: install unit free standing recommended 100mm clearance on the sides and back of the firebox option 2: inbuilt with Vents on the bottom and top of the fireboX custom made vent facade can be made with a minimum metal vent size of 100mm x 600mm on the top of the firebox and...

  • Page 35: Free Standing

    free StanDinG step 1: hearth (floor proteCtor) Where combustible flooring is concerned, lay a masonry base. this can be made from tiles, granite, slate, concrete, hebel blocks, etc. the base must be a minimum 75mm thick and must protrude 500mm on all sides of the firebox. step 2: ClearanCes **important** the unit must maintain a 1200mm clearance horizontally in...
  • Page 36 free StanDinG step 5: installing free standing flue system The first length of black double skin flue does not have a crimped end on either side of the flue piece. Place this first length on the outside of the firebox spigot and ensure the inner lugs are facing down closest to the firebox so that the second skin can’t move down and impede on the damper system.
  • Page 37 lift Up Door aSSemBly lift up door assembly three bolts mount the lift up door mechanism. it is recommended that you use two solid pieces of timber approximately 450mm long in order to assist in the assembly of the door. lift the door into position and place door lift mechanism in position above fireplace door.

  • Page 38: Operation And Maintenance

    Misty or foggy weather may possibly favour back flow of the smoke, which may be a health hazard. In this case, only use the fireplace as is necessary. for safety reasons, assemblies of appliances and accessories not provided or recommended by seguin duteriez or sculpt fireplaces are not permitted. unsuitable equipment may cause dysfunctions and disorder upon use).

  • Page 39: Slow Burning

    operation & maintenance iMPortant Warning storing any flammable materials (paper, linen, furniture, solvents, flammable liquids, spray containers, gas bottle, etc.) close to the fireplace is strictly forbidden. all these products should never be stored even for a short while in wood storages or recesses laid out under or near the appliance.

  • Page 40: Test Results

    1.2/kg of hard wood that complies to AS/NZS 4014.1 and the average efficiency of the appliance for all burn rates was 60%. conclUSion the europa 7 evolution plus solid fuel appliance complies with the requirements of aS/nZS 4014/4013 (2014).

  • Page 41: Test Reports

    teSt reSUltS test reports Visio 8 applianCe power output test teStinG laBoratory Hrl technology manUfactUrer Seguin Duteriez moDel Visio 8 plus iSSUe Date 09.12.2015 inVeStiGatinG officer Steve marland reSUltS testing of the maximum power(kW) output of the Visio 8 insert solid fuel appliance was performed at the high burn rate prescribed in aSnZS4013 (2014) on the 24th of november 2015.

  • Page 42: Warranty Does Not Cover

    10. Warranty warranty Seguin fireboxes are guaranteed for 10 years. This excludes the ash pan, bricks and fire grate retainers which are guaranteed for 1 year. the warranty becomes effective at the date of purchase. warranty does not CoVer 1. Door seals, ropes, gaskets and glass Any form of rust and/or corrosion to the painted finish of the heater 3.

  • Page 43: Warranty Card

    9. Warranty warranty Card date of purChase plaCe of purChase date of installation ComplianCe CertifiCate no. model no. name and address of purChaser phone no. email address Please include a copy of your receipt and compliance certificate email or post warranty information to info@sculptfireplaces.com.au po Box, 1232 mornington, Vic 3931 1300 851 304...
  • Page 44 Whilst every effort is taken to avoid errors, ScUlpt fireplace collection cannot accept responsibility for the accuracy of any statement, extract or information contained within this manual nor can any of its contributors who have submitted material for inclusion. ScUlpt fireplace collection may change or update this manual and anything described in it without notice.

  • Page 45: Final Words

    11. final WorDS Sculpt fireplace collection is an australian owned company who exclusively supply some of world’s most sought after high-end luxury fireplaces. Intent on providing Australians with a dynamic collection of designer fires, Sculpt fireplace collection has strategically gathered not only award winning fireplace designs, but also fireplaces that have been manufactured with high quality materials and the best raw steel that is built to last.
  • Page 46 1300 851 304 info@sculptfireplaces.com.au po Box, 1232 mornington, Vic 3931 edition 18.05.17...
