Page 1: User Manual
ZigBee - ZigBee Remote User Manual ZigBee Remote Model: Z501A Firmware: V5.1 Hardware: V2.0... -
Page 2: Table Of Contents
Table of Contents 1. Introduction................................2 2. Product Appearance..............................3 3. Specification................................4 4. Installation.................................5 5. Setting up Z501A..............................5 5-1. Join the ZigBee Network..........................5 5-2. Add Group (ZLL Network)..........................6 5-3. Binding (HA Network)........................... 6 5-4. Store Scene..............................7 5-5. Control the Device Wirelessly........................7 5.6. -
Page 3: Introduction
Netvox Z501A, ZigBee remote controller, acts as an End Device in ZigBee network. It does not perform permit-join function as a coordinator or a router for other devices to join the network. Z501A can be bound with the On/Off or dimmer devices for users to control the devices wirelessly. It also equipped with an emergency button. -
Page 4: Product Appearance
2. Product Appearance Indicator Level Up Level Down Toggle Power On Power Switch Power Off... -
Page 5: Specification
3. Specification Fully IEEE 802.15.4 compliant Utilizes 2.4GHz ISM band; up to 16 channels Power supply: 3V CR2032 button cell battery Operating consumption: ≤ 38mA Standby consumption: ≤ 0.8uA Up to 150 meters wireless transmission range in non-obstacle space ... -
Page 6: Installation
5. Setting up Z501A 5-1. Join the ZigBee Network While Z501A is under the coverage from a coordinator or a router whose permit-join feature is enabled, Z501A will be permitted to join the network. Step1. Enable the permit-join function (valid for 60 seconds) of a coordinator or a router (please refer to... -
Page 7: Add Group (Zll Network)
). The indicator flashes 6 times to show success, otherwise, the indicator will flash 4 times. Step 6. Z501A will enter sleeping mode if it fails to join network within 3minutes. Z501A will wake up every 15 minutes to try to join to network. -
Page 8: Store Scene
5-4. Store Scene To create and store the scene control, please follow the steps: Step1. Identify the devices which you would like to control. Step2. Press and hold for 4 seconds and then press ／ ／ ／ within 2 seconds to create Scene 1, Scene 2, Scene 3, or Scene 4. 5-5. -
Page 9: Sleeping Mode
C. Once Z501A was joined to a network and by any chance the network is no longer existed or the device is out of the network → Z501A will wake up every 15 minutes to find the network it joined before. -
Page 10: Battery
5-10. Rejoin to Network When the router device is not working in the network, Z501A will immediately look for a new router to join back to network. If Z501A fails to rejoin back to original network, it will enter sleeping mode for 15 minutes. - Page 11 Note：(1) It is not suggested to set: Min Interval =0, Reportable Change=0. Otherwise, Z501A will report very densely (every second) to block up the network. (2) Different attributes have different units, please refer to the product specific instructions for units of reportable change.
- Page 12 A cluster is a set of related attributes and commands which are grouped together to provide a specific function. A simple example of a cluster would be the On/Off cluster which defines how an on/off switch behaves. This table lists the clusters which are supported by Z501A. 1 、End Point(s)：0x01，0x02 2、...
-
Page 13: Netvox App Control Interface
SW build id Character 0- 16 0x4000 Read only string bytes 7. Netvox App Control Interface 1. After joining in Netvox App system, device IEEE address will show up in device management interface. For example, Z501A (Level Control Switch) as shown below:... - Page 14 2. Select “Level Control Switch” to enter setting interface. In the setting interface, respectively, users can select the device to be bound with as shown below: 3. Enter device bind interface: Select the "controlled device" to binding devices. Select the device to be bound, such as wireless ZC07 dimmable LED bulb 1, and then click on the upper right corner to bind (before binding operation, make sure the device is in the activated state, if the device is in sleep mode, users need to activate the device).
-
Page 15: Related Devices
Information" "Settings" "About Device" interface to switch interfaces to check detail information of the device. As shown below. 8. Related Devices Devices which are related to Z501A: Z501C：ZigBee Remote ZB02C：ZigBee Switch Z806：ZigBee Output Unit... -
Page 16: Important Maintenance Instructions
Z811：Wireless Switch Control 9. Important Maintenance Instructions Please keep the device in a dry place. Precipitation, humidity, and all types of liquids or moisture can contain minerals that corrode electronic circuits. In cases of accidental liquid spills to a device, please leave the device dry properly before storing or using.
