netvox ZigBee Z207 User Manual

Integrated wireless smart home controller
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TM
ZigBee
- Integrated Wireless Smart Home Controller

User Manual

Integrated Wireless Smart Home Controller
Model: Z207
20151124
For firmware V0.0.0.25 and later

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZigBee Z207 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for netvox ZigBee Z207

Summary of Contents for netvox ZigBee Z207

  • Page 1: User Manual

    ZigBee - Integrated Wireless Smart Home Controller User Manual Integrated Wireless Smart Home Controller Model: Z207 20151124 For firmware V0.0.0.25 and later...

  • Page 2: Table Of Contents

    Model: Z207 Table of Contents 1. Introduction..................................2 2. Product Appearance................................2 3. Specification..................................2 4. Installation and Preparation...............................3 4-1. Port introduction..............................3 4-2. Power on Z207 and connection diagram....................... 3 4-3. Reset Z207................................4 4-4. Indicators................................4 5. Set up Z207..................................5 5-1. Set up..................................5 5-2.

  • Page 3: Introduction

    Model: Z207 1. Introduction Netvox Z207 is a Cloud-Based Wireless Smart Home (CWSH) Controller. It is equipped with ZigBee, and Cloud technology. As the main character of Netvox Smart Home Cloud Platform, Z207 provides Cloud services and ZigBee network communication. Users are able to control the ZigBee network devices through Z207 with mobile App. Netvox Smart Home Cloud service allows users to remotely control home devices anytime and anywhere to achieve low power consumption and environmental protection.

  • Page 4: Installation And Preparation

    Model: Z207 4. Installation and Preparation 4-1. Port introduction 4-2. Power on Z207 and connection diagram Power on Z207 with DC 5V / 0.5A power adapter (Micro USB Port). The power indicator light stays on. IP CAM Micro USB DC 5V/0.5A Internet Z207 WIFI ROUTER...

  • Page 5: Reset Z207

    Model: Z207 4-3. Reset Z207 utton To reset Z207, press Reset B when Z207 is powered on. 4-4. Indicators A. Power Indicator: Light on: power-on. Light off :power-off. B. Cloud Indicator: Light flash: connection fail Light on: connection complete...

  • Page 6: Set Up Z207

    5. Set up Z207 5-1. Set up Connect the router to the LAN port of Netvox Z207 with a web line. 5-2. Search Z207 IP Login router settings interface with browser. Connect the computer to router with either cable or WIFI. Login setup interface (login and password method, please refer to manual).

  • Page 7: View Z207 Status

    Model: Z207 Key in the Username & Password (default for customer: admin / admin ; for user: operator / operator ) and login the management system including status, internet setting, administration and home automation. 5-4. View Z207 Status Click Status to view the system and web data as below page. 5-5.

  • Page 8: (A) Lan Settings

    Model: Z207 (A) LAN Settings This page is used to configure the parameters for local area network which connects to the LAN port of your access point. Here you may change the setting for IP address, subnet mask, DHCP, etc.. (B) WAN Settings This page is used to configure the parameters for local area network which connects to the WAN port of your access point.

  • Page 9: Administration

    Model: Z207 5-6. Administration Click administration to advance set up including statistics, time zone setting, denial-of-service, system log, upgrade firmware, save/load setting, password. (A) Statistic This page shows the packet counter for transmission and reception regarding to wireless and Ethernet. (B) Time zone setting Users can maintain the system by synchronizing with a public time server over the internet.

  • Page 10: (D) System Log

    Model: Z207 (D) System Log This page can be used to set remote log server and show the system log.

  • Page 11: (E) Upgrade Firmware

    Model: Z207 (E) Upgrade Firmware This page allows you upgrade the access point firmware to new version. Please note, do not power off the device during the upgrade because it may crash the system. (F) Save/Reload Setting This page allows you save current settings to a file or reload the settings from the file which was saved previously. Besides, you could reset the current configuration to factory default.

  • Page 12: Device List

    Model: Z207 6-1. Device List The device data such as IEEE address, data code, and device details. For the first-time use, please power on / wake up all of the devices, and then refresh the list and check all device names are listed. 6-2.

  • Page 13: (B) Add Devices

    Model: Z207 (B) Add Devices Users could also add the devices manually using device’s IEEE number. Operation tip as listed below: (C) IP Camera List To manage the IP camera automatically and manually. (I) Select automatic: (II) Select manual:...

  • Page 14: Initiate Smart Home

    Model: Z207 6-3. Initiate Smart Home Select Zigbee network channel to be used. For the first time, after the network is completed, users need to initialize the smart home system . Select the device to be initialized, click [ Initialize smart home ] button to initialize the smart home system. Users are able to check the completeness of the network.

  • Page 15: User Management

    Model: Z207 6-4. User management Click User Management on the left of the page as below. In this page, users can add and generate new verification code . Click once to generate a verification code, the status updated in the list. Click User Management [Add] button, following page as below, enter a user name, password, password confirmation and verification code and click submit to add new users.

  • Page 16: Upgrade Firmware

    Model: Z207 6-5. Upgrade Firmware Click on the left of the page to Upgrade Firmware. Click [ Browse ] button , select a upgrade file, then click [ upgrade ] button. 6-6. Data Management (backup, restore, or delete setting) Click on the left side of data management as interface in below. Users can choose to back up, restore, delete data to local or cloud systems, according to the backup date.

  • Page 17: Communication Setting

    Model: Z207 6-8. Communication Setting To manage security key or Cloud link.

  • Page 18: Switch Z207 To Z202 Gateway Mode

    Model: Z207 7. Switch Z207 to Z202 Gateway mode 1. Login to Z207 web page, select communication setting amend secret key un-tick secure communication Click “OK” : 2.Open a new Web page, enter below cgi configuration to switch Z207 into Z202 mode. (Note: IP address is your real Z207 IP) http://192.168.11.103/cgi-bin/rest/network/SystemConfigure.cgi?opt=101&value=1&callback=1234&encodemethod= NONE&sign=AAA...

  • Page 19: Important Maintenance Instructions

    Model: Z207 8. Important Maintenance Instructions  This device is NOT truly waterproof/ resistant and is for indoor use.  Please keep the device in a dry place. Precipitation, humidity, and all types of liquids or moisture can contain minerals that corrode electronic circuits. In cases of accidental liquid spills to a device, please leave the device dry properly before storing or using.
