Sharp 28LF-94E Service Manual

PAL / SECAM
B/G
ELECTRICAL SPECIFICATIONS ........................................................................................ 3
IMPORTANT SERVICING NOTES ...................................................................................... 4
CONTROLS & TERMINALS ................................................................................................ 5
PRINTED WIRING BOARD LAYOUT ................................................................................. 7
PARTS LISTING ................................................................................................................... 9
HOW TO UPDATE THE TECHNICAL INFORMATION ...................................................... 19

SHARP CORPORATION

SERVICE MANUAL

SYSTEM COLOUR TELEVISION
L/L', B/G, D/K
MODEL
In the interests of user safety (required by safety
regulations in some countries) the set should be re-
stored to its original condition and only parts identi-
cal to those specified should be used.
In order to service the model 28LF-94E, refer to
the AK-53 Chassis
(SE00AK53CHA00).
CONTENTS
1
SE0028LF94S00
Issued: 7
AK- 53
CHASSIS
28LF-94E
Service Manual
This document has been published to
be used for after sales service only.
28LF-94E
July 2004
th
