HumEvap Mobile Humidifier
Operating, Installation and Instruction Manual
WARNING: This Humidifier must be installed, operated and maintained in
accordance with this manual. Failure to do so could result in contamination that
might cause Legionnaires' disease, which can be fatal.
WARNING: Failure to maintain this humidifier as recommended in this manual
will invalidate warranty.
JS Humidifiers plc
Artex Avenue, Rustington, LITTLEHAMPTON,
West Sussex, BN16 3LN, UK
Tel: (+44) 01903 850 200. Fax (+44) 01903 850 345
email: sales@jshumidifiers
JS Humidifiers plc
Version 1.71 February 2006
Humidity Group
of the HEVAC Association
www.jshumidifiers.com
INVESTORS IN PEOPLE
Advertisement
Table of Contents
Related Manuals for JS Humidifiers HumEvap
Summary of Contents for JS Humidifiers HumEvap
- Page 1 HumEvap Mobile Humidifier Operating, Installation and Instruction Manual Version 1.71 February 2006 WARNING: This Humidifier must be installed, operated and maintained in accordance with this manual. Failure to do so could result in contamination that might cause Legionnaires’ disease, which can be fatal.
- Page 2 MUST be responsible for ensuring their suitability. No liability will attach to JS Humidifiers plc if any damage, injury or accident is attributable to inattentive, inappropriate, negligent or incorrect installation and operation of the machinery whether or not caused deliberately.
- Page 3 LITTLEHAMPTON, WEST SUSSEX, UK BN16 3LN Tel: 01903 850200 Type of Equipment HumEvap Mobile Humidifier HumEvap Mobile - Series 1.70 Model Name(s) & Series 2006 Year of Manufacture We the undersigned, hereby declare that the equipment specified above conforms to the above Directive(s) and Standard(s)
-
Page 4: Table Of Contents
(ii) Safety (iii) Standards and Certificates (iv) Contents INTRODUCTION Page 1 Technical Specification Two types of HumEvap Mobile Unit Page 2 Principle of Operation Introduction Principle of Operation Rear View of Manually filled Unit OPERATION Page 3 Operating Parameters Start-Up and Operation... - Page 5 If you have any queries regarding water sampling and testing please contact JS Humidifiers plc on 01903 850200. Two Types of HumEvap The HumEvap Mobile Unit is available in two configurations: Mobile Units 1 - Manual filling of the Water Reservoir.
- Page 6 Introduction Principle of Operation Introduction The energy efficient HumEvap humidification system operates by the principle of evaporation, where the energy required to evaporate moisture is taken from the passing air flow. This in turn increases the relative humidity of the air, while decreasing the dry bulb temperature, producing an adiabatic cooling effect.
-
Page 7: Warning! This Humidifier Must Be Installed, Operated And Maintained In
Refill Indicator Fill Hatch Humidity Fan Speed Control HumEvap Mobile Humidifier Control Panel Start-up and Operation The Humidity Control maintains the humidity level in the room at the required level. Operating Parameters Fill Hatch Use for filling water into the Water Reservoir. -
Page 8: Installation
Failure to do so could result in contamination that might cause Legionnaires’ disease, which can be fatal. Position the HumEvap unit close to the electrical and water facilities Manual Unit Positioning in such a way that air inlet and outlets are not blocked. -
Page 9: Manual Unit Water Supply
HumEvap Mobile Humidifier Installation Manual Unit Water Supply Water Reservoir Open the Fill Hatch located on the control panel of the Unit and carefully fill with mains or demineralised water. Do not overfill the tank: Make sure that water level does not exceed the MAX mark on the Water Reservoir. -
Page 10: Auto- Fill Unit Installation And Water Supply
HumEvap Mobile Humidifier Installation Auto - fill Unit Installation and Water Supply Auto-fill Unit Positioning Position the Unit within one meter of the electrical, water and drain pipe facilities. Follow the advice stated above for the Manual unit plus the following: Isolation of Water Supply Ensure that the water supply is turned OFF. -
Page 11: Auto-Fill Unit Water Supply (Cont)
HumEvap Mobile Humidifier Installation Auto-fill Unit Water Supply (cont) Flow control Fitting Self- cutting Valve to Existing 15mm Tube cutter Existing Copper Pipework On/Off tap and seal supply Chrome Saddle locknut Rubber seal Valve outlet Backplate The self-cutting valve is suitable for 15mm copper tube and should be fitted... -
Page 12: Maintenance
If you have any queries regarding water sampling and testing please contact JS Humidifiers plc on 01903 850200. De-scaling the Rotating Remove the Evaporative Disk from the humidifier housing. -
Page 13: Maintenance Frequency
To refesh the system, every month, place 1 small Disiifin tablet into the water tank and allow to dissolve. Disifin tablets are available from JS Humidifiers on 01903 850200. Always disconnect the unit from the power socket before cleaning and maintenance. -
Page 14: Replacement Of Ionic Silver Stick
HumEvap Mobile Humidifier Maintenance Replacement of Ionic Silver Stick Replacing the Ionic Stick The HumEvap unit is supplied with an Ionic Silver Stick to reduce bacterial contamination of the water. This Stick requires replacing every three months to ensure proper bacterial control. -
Page 15: Troubleshooting And Spares
Turn Fan switch to Hi or Lo Evaporative Disk rotating but Fan speed. not running Fan Motor defective Contact JS Humidifiers plc for more information. Water level in the Reservoir is Red light is illuminated Check water level too low... - Page 16 HumEvap Mobile Humidifier Installation & Instruction Manual (Version 1.71) © JS Humidifiers plc March 2006 MWR All rights reserved. No parts of this publication may be reproduced without the express consent of the publishers.
