HumEvap Mobile Plus Humidifier
Operating, Installation and Instruction Manual
WARNING: This Humidifier must be installed, operated and maintained in
accordance with this manual. Failure to do so could result in contamination that
might cause Legionnaires' disease, which can be fatal.
WARNING: Failure to maintain this humidifier as recommended in this manual
will invalidate warranty.
JS Humidifiers plc
Artex Avenue, Rustington, LITTLEHAMPTON,
West Sussex, BN16 3LN, UK
Tel: (+44) 01903 850 200. Fax (+44) 01903 850 345
email: sales@jshumidifiers
JS Humidifiers plc
Version 1.00 June 2006
Humidity Group
of the HEVAC Association
www.jshumidifiers.com
INVESTORS IN PEOPLE
Advertisement
Table of Contents
Related Manuals for JS Humidifiers HumEvap Mobile Plus
Summary of Contents for JS Humidifiers HumEvap Mobile Plus
- Page 1 HumEvap Mobile Plus Humidifier Operating, Installation and Instruction Manual Version 1.00 June 2006 WARNING: This Humidifier must be installed, operated and maintained in accordance with this manual. Failure to do so could result in contamination that might cause Legionnaires’ disease, which can be fatal.
- Page 2 MUST be responsible for ensuring their suitability. No liability will attach to JS Humidifiers plc if any damage, injury or accident is attributable to inattentive, inappropriate, negligent or incorrect installation and operation of the machinery whether or not caused deliberately.
-
Page 3: Table Of Contents
HumEvap Mobile Plus Humidifier Introduction Contents Safety....................i Introduction Contents....................ii Standards and Certificates..............iii Technical Specification................iv Principle of Operation................v Operating Parameters.................1 Operation Unit Positioning and Installation............2 Installation Water Supply..................3 Routine Maintenance................4 Maintenance Maintenance Frequency..............5 Replacement of Ionic Silver Stick............6 Troubleshooting & Spares..............7... -
Page 4: Standards And Certificates
Distributor’s Name JS Humidifiers plc And Address Artex Avenue, Rustington, LITTLEHAMPTON, WEST SUSSEX, UK BN16 3LN Tel: 01903 850200 Type of Equipment HumEvap Mobile Plus Humidifier HumEvap Mobile Plus - Series 1.00 Model Name(s) & Series 2006 Year of Manufacture... -
Page 5: Technical Specification
If you have any queries regarding water sampling and testing please contact JS Humidifiers plc on 01903 850200. -
Page 6: Principle Of Operation
Air, drawn from the room through the ‘Air Care’ filter, travels through the wetted evaporator cassette and absorbs water as it passes. This humidified air is distributed into the room through the air outlet grilles. on the top of the HumEvap Mobile Plus. Air outlet grilles Humidity control... -
Page 7: Operation Operating Parameters
Tank Cover Humidity Control Speed Refill Indicator HumEvap Mobile Plus Humidifier Control Panel Start-up and Operation The humidity controller maintains the humidity level in the room at the required level. Operating Parameters Water Tank Cover The tank cover sits over the water tanks. When removed, the tanks are exposed, and can be removed for re-filing. -
Page 8: Installation Unit Positioning And Installation
Legionnaires’ disease, which can be fatal. Unit Positioning Position the HumEvap Mobile Plus close to the electrical and water supply in such a way that air inlet and outlets are not blocked. Do not position the unit directly against a wall. -
Page 9: Water Supply
If you have any queries regarding water sampling and testing please contact JS Humidifiers plc on 01903 850200. -
Page 10: Maintenance Routine Maintenance
HumEvap Mobile Plus Humidifier Maintenance Routine Maintenance Warning! This humidifier must be installed, operated and maintained in accordance with this manual. Failure to do so could result in contamination that might cause Legionnaires’ disease, which can be fatal. The Evaporator Cassette is located within the humidifier housing, Cleaning the beneath the Fan. - Page 11 HumEvap Mobile Plus Humidifier Introduction Routine Maintenance Warning! This humidifier must be installed, operated and maintained in accordance with this manual. Failure to do so could result in contamination that might cause Legionnaires’ disease, which can be fatal. Cleaning Water Tanks To clean and refresh the system, Drain the water reservoir fully.
-
Page 12: Maintenance Frequency
Replace Ionic Stick Inspect air filter and replace air filter if necessary Replace the evaporator cassette Replace air filter. 6 Monthly Inspections If you have any questions regarding water sampling and testing please contact JS Humidifiers plc on 01903 850200. -
Page 13: Replacement Of Ionic Silver Stick
HumEvap Mobile Plus Humidifier Maintenance Replacement of Ionic Silver Stick Replacing the Ionic Stick The HumEvap Mobile Plus is supplied with an Ionic Silver Stick to reduce bacterial contamination of the water. This Stick requires replacing every three months to ensure proper bacterial control. -
Page 14: Troubleshooting & Spares
HumEvap Mobile Plus Humidifier Maintenance Troubleshooting & Spares Malfunction Cause Remedy Water in reservoir has become Flush reservoir and place a Stale smelling unit stagnant Disifin tablet into the reservoir and allow to dissolve. Unit is switched OFF at its... - Page 15 HumEvap Mobile Plus Humidifier Installation & Instruction Manual (Version 1.00) © JS Humidifiers plc June 2006 All rights reserved. No parts of this publication may be reproduced without the express consent of the publishers.
