This product is a lead free model.
Lead free solder is used in PWB stamped LF mark.
Please keep the following conditions when you repair.
1. Use lead free solder.
* Koki's lead free solder S3X-55M 0.6mm
(CLARION Parts No.642-0231-01)
* Koki's lead free solder S3X-55M 1.0mm
(CLARION Parts No.642-0231-02)
2. Use a nitrogen solder system.
3. Do not use "General solder" and "Lead free solder"
together.
Clarion Co., Ltd.
7-2,Shintoshin,Chuo-ku,Saitama-shi 330-0081 Japan
After Service Department: Phone +81-48-601-3792 / Fax +81-48-601-3804
- 1 -
Service Manual
NISSAN Motor Genuine
2DIN HDD Navigation
BOSE Specifi cations
for CANADA
NAU-3225KCA-C
QX-3870N-A
Model
(Genuine Parts Number 25915 ZZ60D)
1. NOTES
*
iPod is a trademark of Apple Inc., registered in the U.S. and
other countries.
*
Bluetooth is a trademark owned by Bluetooth SIG, Inc., U.S.A.
and licensed to Clarion.
*
We cannot supply the parts not listed in this manual.
*
Specifi cation and design are subject to change without notice
for further improvement.
*
© Copyright 2012 Clarion Company,Ltd. All rights reserved.
No portion of this manual can be reproduced in any way, elec-
tronically or otherwise, without the express prior permission of
the copyright owner.
Published by After Service Dept.
Printed in Japan
2012/06
No.E7297-00
QX-3870N-A
