- Page 1 Home Central Audio System HM6812 User's Manual Home Central Audio System HM6812 Remote Control Pad HM6812 Infrared Remote Controller HM21R Welcome to use DSPPA Home Central Audio System. Please read the manual carefully before your operation. Guangzhou DSPPA Audio Co., Ltd. http://www.DSPPA.com...
-
Page 2: Table Of Contents
Table of Contents ABOUT HOME CENTRAL AUDIO SYSTEM ..................1 FEATURES..............................1 PANEL DESCRIPTION........................... 1 3.1. Front Panel............................1 Rear Panel ............................2 SYSTEM CONNECTION........................3 Legend of System Connection ......................3 Legend of Zone Connection....................... 4 SYSTEM OPERATION ........................... 4 Room Turn On/Off .......................... -
Page 3: About Home Central Audio System
1. About Home Central Audio System HM6812 System is an ideal modern family music control system, which is composed of control unit (HM6812), remote control pad (HM20R), infrared remote controller (HM21) and some speaker units. The system is simple in operation and complete in function. The control unit has built-in zone distributor and amplifier, with 6 external music source input ports, 6-room stereo outputs and 6-room volume independent control. -
Page 4: Rear Panel
Family Music Control System Power indicator The indicator is on while turn on the power. Power switch Press down this button for turn on the power. Receiving window for infrared remote control Music selection button To select the music source for each room and turn on/off the room, the corresponding indicator is on when one music source is selected. -
Page 5: System Connection
Family Music Control System For data exchange between remote control pad and system control unit (Attention! don’t make polarity reversal between control pad and control unit.) Zone left audio output channel Connect with speaker unit in each room. Attention to the polarity connection between control unit and speaker unit. -
Page 6: Legend Of Zone Connection
Family Music Control System 4.2 Legend of Zone Connection Room 1-6 Room 1 Room 6 ATTENTION: don’t make polarity reversal between control unit and control pad / speaker units in each room 5. System Operation Connect the system properly as per the diagram given above. Press down the power switch of control unit to turn on the power. -
Page 7: Music Source Selection
Family Music Control System ③ A room will be turned off after press the music selection button of this room over 3 seconds. ④ Press button “ ” on the room remote control pad can turn on/off the room. ⑤ Press button “ ”... -
Page 8: Functions Of Keys Of Hm21 (Infrared Remote Controller)
Family Music Control System 6. Functions of Keys of HM21 (Infrared Remote Controller) Power Button Music Source Treble Increase Selection Button Button Volume Increase Bass Increase Button Button Volume Decrease Button Bass Attenuate Treble Attenuate Button Button Remind: When the infrared remote controller send signal to control unit directly, it can manage all system functions in room 1. -
Page 9: Precautions
Family Music Control System 7. Precautions 7.1 Safety Operation l Please don’t insert the power plug of the equipment into the power network before connecting the system properly. l It should be ensured that the voltage provided for the equipment is completely same with the voltage required by the equipment;... -
Page 10: Packing List
Family Music Control System l As to the terms or precautions not mentioned in the User’s Manual, please contact the distributor or visit the web page of our company: http://www.dsppa.com. 8. Packing List Model HM6812 control unit, 1 set Infrared remote controller (HM21), 1 piece User’s Manual, Card of Guarantee and Quality Certificate, 3-pin power cord (AC220 V/10A), and 1.5...
