Convision CC-5455 IR Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Manual
CC-5455 IR
Date: January 2011
Convision Systems GmbH
Manual CC 5455IR
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CC-5455 IR and is the answer not in the manual?

Questions and answers

Related Manuals for Convision CC-5455 IR

Summary of Contents for Convision CC-5455 IR

  • Page 1 Manual CC-5455 IR Date: January 2011 Convision Systems GmbH Manual CC 5455IR...
  • Page 2 The lightning flash with an arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
  • Page 3 Warning The camera requires periodic inspection. Contact an authorised technician to carry out the inspection. Stop using your camera when you find it malfunctioning. If the camera emits smoke or is unusually hot for a long period, a fire may be caused. Do not install the camera on a surface that can not support it.

  • Page 4: Table Of Contents

    Contents NOTICE Important Safeguard Precautions Features Components Names and Functions of Parts Dimensions Installation Cable Connections How to Operate the Bracket Communication Control Connector Control via the RS-485 Interface How to Use the Camera Menu Settings Lens Exposure White Balance BACKLIGHT Day / Night Image Adj.

  • Page 5: Notice

    NOTICE Important Safeguard 1. Read Instructions Read all of the safety and operating instructions before using the product. 2. Retain Instructions Save these instructions for future reference. 3. Attachments / Accessories Do not use attachments or accessories unless recommended by the appliance manufacturer as they may cause hazards, damage product and void warranty.

  • Page 6: Features

    Features Ultra High Resolution Motion Detection By adopting a double-speed 410.000 pixel The camera detects motion and generates a Sony CCD, the camera produces clear screen message without an external sensor. picture quality with a horizontal resolution of 560 TV lines for color, and 600 TV lines for Day &...

  • Page 7: Components

    Components 1. Day & Night IR Bullet Camera 2. Screws 3. Allen Head Bolt 4. Wrench 5. Instruction Guide • Names and Functions of Parts 1. Sunshield 2. Lens: Vari Focal Auto Iris Lens 3. Photo Sensor 4. Remote Controller (optional item) Set: Used to access menu mode and for configuration :OSD Modus →...

  • Page 8: Dimensions

    : OSD Modus → Cursor left in the menu screen. → Parameter change :OSD Modus → Cursor right in the menu screen. → Parameter change Names and Functions of Parts Service connector for easy installation of the camera. - A service monitor can be connected to the camera, allowing the operator to easily atjust camera angles and settings locally during installation.

  • Page 9: Installation

    Installation 1. Bracket & Camera Mounting - Affix the bracket to the mounting surface. - Use the supplied screws to attach to the mounting surface using the pre-drilled holes in the bracket. 2. Power Connect & Monitor Impedance - Use a DC12V/1A regulated PSU or AC24V 1A. - To avoid fire or shock hazard, always use a CE marked PSU.

  • Page 10: Cable Connections

    Cable Connections How to Operate the Bracket 1. Loosen the Bolt Rotate the camera body what want your direction and tighten the Bolt. (360° rotation) 2. Loosen the Bolt Rotate the camera body what want your direction and tighten the Bolt. (90° rotation) * Due to the size and weight of this product, it is recommended that that installer hold on to the mounting bracket junction instead of the camera itself while tightening the bold 3.

  • Page 11: Communication Control Connector

    Communication Control Connector The camera can be controlled by using external controllers. (RS-485 Communication) Control via the RS-485 Interface The camera can be controlled by using external controller equipped with RS-485 communications. - To control using a DVR or keyboard controller Connect the RS-485 cable (TRX+, TRX-) to the connection port of the 485 control board in the DVR or controller.

  • Page 12: How To Use The Camera

    How to Use the Camera Menu Main Setup Menu Lens Manual Exposure Shutter Sens-Up Return White Balance AWC SET Manual Outdoor Indoor Backlight Day / Night Color B/W Auto Extern Image Adjustment Freeze V-REV H-REV D-Zoom Sharpness Return Special Function Cam Title Sync Motion Det Privacy DIS Comm Adj Language Reset Return Exit...

  • Page 13: Lens

    2. Select the desired feature using the UP or DOWN button. Each pressing of the UP or DOWN button moves the indicator to the next or previous features. Move the arrow indicator to the desired feature item. 3. Change the status of the selected feature using the LEFT or RIGHT button. 4.

  • Page 14: Exposure

    Note Some lenses my not work properly, depending on the settings for Brightness Level. When Using a Video-Type Auto Iris Lens 1. Check that the ALC adjustment on the lens is appropriate. In general, set it to AV (Average). 2. It may not work properly depending on the installed lens. Set the Level VR of the lens of the optional value.
  • Page 15 AGC (Auto Gain Control) : The higher the gain level, the brighter the screen – but the higher the noise. OFF: Deactivates the AGC function LOW: Allows automatic gain control from 0 to 24dB. HIGH: Allows automatic gain control from 0 to 42dB. SENS UP: When it is night or dark, the camera automatically detects the light level and maintains a clear picture if this mode is activated.

  • Page 16: White Balance

    White Balance Use the White Balance function to adjust the screen colors. 1. Position the cursor to point to WHITE BAL on the SETUP menu screen, select using the Up and Down buttons. 2. Select a desired mode using the Up and Down buttons. Select one of the following 5 modes, as appropriate.

  • Page 17: Backlight

    BACKLIGHT This camera is designed to deliver a clear and distinct image of both subject and background, even when the subject is backlit. 1. Please position the arrow to point to 'BACKLIGHT' on the SETUP menu by using the UP and DOWN buttons.

  • Page 18: Dnr

    Note • The WDR cannot be used when MANUAL mode or A.FLK mode in the 'SHUTTER' menu is selected. • If the following symptoms occur when WDR is selected, deactivate it. 1. Color of screen changes unnaturally. 2. Noise appears in the brightest part of the screen. •...

  • Page 19: Image Adj

    2. Select the desired mode using the Left and Right buttons. o Color: The picture is displayed in color. o B/W: The picture is always displayed in black and white. o Auto: This camera has an IR Cut-Filter and automatically changes to the appropriate mode according to lighting levels.

  • Page 20: Special

    Special 1. When the Setup menu screen is displayed, select SPECIAL using the Up and Down buttons. 2. Select the desired mode using Left and Right buttons. o Cam Title: If a title is entered, the title appears on the monitor. - When the Special menu screen is displayed, use the Up and Down buttons to point the cursor to Cam Title - Set to ON using the Left and Right buttons.
  • Page 21 - Use the 4 directional buttons to move to a character, and select it by pressing the Set button. Repeat this action to enter multiple characters. Up to 15 alphanumeric characters can be used. Note If the cursor is moved to CLR and Set button is pressed, all letters are deleted. To edit a letter, change the cursor to the bottom left arrow and press the Set button.

  • Page 22: Exit

    o Privacy: Hide an area so that it is not displayed on the monitor. - When the Special menu screen is displayed, press the Up and Down buttons so that the cursor points to PRIVACY. - Set up using the 4 directional buttons. * AREA SEL: Up to 8 areas are selectable.

  • Page 23: Troubleshooting

    Troubleshooting If there are problems in operation, please refer to the items below. If the problem persists, please contact the agent you purchased this product from. Problems Troubleshooting Nothing appears on the screen. • Please check the power connection. • Please check the video signal line connection. •...

  • Page 24: Specifications

    Specifications ITEM NTSC Input Voltage AC 24 V/ DC 12 V DC 12V AC 24 V/ DC 12 V DC 12V Power Power Consumption 700mA(AC24V/DC12V) 700 mA 700mA(AC24V/DC12V) 700 mA Size Sony 1/3“ Vertical Double Density Color CCD Total Pixels 811(H) x 508(V) 795(H) x 596(V) Effective Pixels...
