SmartWitness SVC400GPS
Installation Guide
v.1.2
WARNING: SmartWitness installations should be performed by a qualified individual or
installation professional only. Working with a vehicle's power system can be dangerous to
both you and your vehicle. This installation is intended only to be a guide since vehicle
designs and power/input sources can vary significantly from vehicle to vehicle.
www.smartwitness.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SmartWitness SVC400GPS
Summary of Contents for SmartWitness SVC400GPS
- Page 1 Installation Guide v.1.2 WARNING: SmartWitness installations should be performed by a qualified individual or installation professional only. Working with a vehicle's power system can be dangerous to both you and your vehicle. This installation is intended only to be a guide since vehicle designs and power/input sources can vary significantly from vehicle to vehicle.
-
Page 2: Package Contents
SVC400GPS is installed in nearly 50,000 thousand vehicles around the world, including school buses, taxis, semi-trucks, tow trucks, fork-lifts, ambulances, garbage trucks, concrete trucks, and more. An LCD display can be connected to SVC400GPS, making it double as a rearview/360° view system to increase the driver’s visibility. - Page 3 SmartWitness Remote / Panic GPS Antenna SVC400 recorder Switch module SD Card Audio/Video Power Cable (PC Viewer software is output cable on the provided SD card.) 3M Adhesive Pad Wire clips RCA to 2.5mm (5pcs) stereo adaptor (3ea) Microphone User Manual...
- Page 4 31-day Vehicle Tracking History, showing vehicle location, speed and driving style regardless if event video was recorded or not. Save/Print Event Reports. Free Software & Firmware Updates. With optional LCD monitor connected, view all four cameras at once or playback recorded videos in the vehicle. www.smartwitness.com...
-
Page 5: Front View
SD Card Slot Camera 3 Input SD Door Rear View Buzzer Internal Microphone Power Input & 12v Alarm Input Triggers Rear View (Turn left, Turn right, Camera 4 Input Break, Speed pulse) Remote Control Input Camera 1,2 Inputs GPS Input www.smartwitness.com... -
Page 6: Shutter Button
3-wire connection between the SVC400 recorder and the vehicle (IGN +, BAT+, and BAT-) It will automatically cut off the battery power when battery voltage drops below 12v or 24v, or via timed delay shutoff (times are adjustable via dip switch setting on the adaptor) SmartWitness Model # SVCSPWK-BW2 www.smartwitness.com... - Page 7 Input) Connecting Cameras 1, 2, & 3 (5V, 2.5mm stereo) All SmartWitness 5V cameras can plug n play into camera channels 1, 2, & 3 on SVC400 Compatible camera models end in “-S”, such as the SVA033-S All”-S” cameras have a 1ft. lead from the camera lens and include a 16ft. extension cable (33ft cable also available) Simply plug the 2.5.mm stereo cable into the desired camera input.
- Page 8 Connecting Camera 4: (RCA input) Rear backup camera (any SmartWitness camera ending in “-C”, ( i.e. SVA036-C ) 20M extension cable for rear backup camera. RCA adaptor cable. 12v power and ground for rear backup camera connect to IGN (+) and Bat (-).
- Page 9 Install all interior and exterior cameras with 3M dual sided adhesive or hard mounting screws (confirm with customer as to the desired installation method). Below is an example: Driver Camera Road Camera Install Remote Control onto dash next to the steering wheel and within reach of the driver. www.smartwitness.com...
-
Page 10: Final Steps
(so it can have a view of the sky to acquire GPS signal). 7. Final Steps After installation of the SVC400GPS and accessories into the vehicle you can turn on vehicle ignition and the SVC400 recorder will power on. There will be a sequence of red & blue LED lights on the Remote/Panic Button during boot process. - Page 11 8. Remote Controller LED status Indicators www.smartwitness.com...
