- Page 1 GemTek Technology Co., Ltd. 11Mbps Wireless LAN Access Point WX-1590 User's Manual Nov. 2001...
- Page 2 Copyright statement No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, whether electronic, mechanical, photocopying, recording, or otherwise without the prior writing of the publisher. Printed in Taiwan, Nov. 2001...
- Page 3 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio...
- Page 4 R&TTE Compliance Statement This equipment complies with all the requirements of the DIRECTIVE 1999/5/EC OF THE EUROPEAN PARLIAMENT AND THE COUNCIL of 9 March 1999 on radio equipment and telecommunication terminal Equipment and the mutual recognition of their conformity (R&TTE). The R&TTE Directive repeals and replaces in the directive 98/13/EEC (Telecommunications Terminal Equipment and Satellite Earth Station Equipment) As of April 8, 2000.
-
Page 5: Table Of Contents
1 Contents Contents....................5 Introduction ....................6 Installation ....................7 Glossary ....................15 Technical specifications Series Access Points........16 Standards supported ..............16 Environmental ................16 Power specifications...............16 Radio specifications ...............16 Specific features................16 Physical Dimensions ..............16 Weight……………………………………………………………………16... -
Page 6: Introduction
2 Introduction Thank you for purchasing your 11Mbps Wireless LAN Access Point. This manual will assist you in the installation procedure for PCMCIA 11Mbps PC Card models The package you have received should contain the following items: •= User's manual •= Access Point •=... -
Page 7: Installation
3 Installation Mount the Access Point firmly to the wall on the position that is determined during the site survey. A drill model is supplied as a separate sheet with this manual. Make sure the antennas are in a vertical position (if not, rotate over 90 degrees). Insert the power connector. - Page 8 Step 3. Modify IP address to same subnet Under DOS prompt and type c:\>arp -s [IP address] [MAC address] Note: Arp: address resolution protocol -s: change IP address [IP address]: target IP address [MAC address]: MAC address of Access Point...
- Page 9 Step 4. Confirm IP address by using “ARP” instruction Under DOS prompt and type c:\>arp -a...
- Page 10 Step 5. Trace IP address by using “Ping” Under DOS prompt and type c:\>ping [IP address] Step 6. Launch “AP SNMP” program “Start” “Programs” “SNMP” “SNMP manager.
- Page 11 Step 7. Finding the associated Access Point “File” “Find Access Point” The list below shows all available Access Points, Select the Access Point, which requires to control Type “public” on community and select “Administrator” for logo-on authority, then click “OK” After Log-on the system, more function shows on the menu...
- Page 12 Step 8. Function settings (Standard AP, AP Client, Wireless Bridge) Here allow user to enter different configure settings.
- Page 13 Click on Advanced button for different Operational Mode. 1. Click Access Point for standard AP function. Then click OK button. 2. For Access Point Client mode, please enter MAC address of the AP (the AP you wish to associate with) in the Preferred BSS box. Then click OK button.
- Page 14 3. For Wireless Bridge mode, there are 2 options. Point-to-Point: please enter the MAC address of remote Wireless Bridge. Point to Multipoint Then click OK button. After finish the setting, please Commit Changes.
-
Page 15: Glossary
4. Glossary “Basic Service Set”. De facto an alias for Access Point. Cell Area in which the radio signal of an Access Point is sufficiently good to join with it. “Extended Service Set”. A group of Access Points with identical settings among which a client system can roam. -
Page 16: Technical Specifications Series Access Points
Technical specifications of Series Access Points 5.1 Standards supported IEEE 802.11b standard for Wireless LAN A ll major networking standards (including IP, IPX) 5.2 Environmental Operating temperature (ambient): - 10 ~ 55°C Humidity: M ax. 95% Non-condensing 5.3 Power specifications DC power supply ...
